E105
User Manual
(Version 1.0)
1
Contents
Contents.........................................2
Important safety precautions..........3
Special features of your phone ....13
Get started....................................16
Entertext.......................................22
Overview of menu functions.........23
Phonebook (Menu 1)....................26
Message Center (Menu 2)... ........27
Call History (Menu 3)....................31
Music (Menu 4).............................33
Camera (Menu 5).........................34
FM Radio (Menu 6)......................37
2
Organizer (Menu 7)......................37
Services (Menu 8)........................38
Entertainment (Menu 9)................40
Settings (Menu 10).....................41
Bluetooth (Menu 11)...................49
File Manager (Menu 12).............52
Important safety precautions
This section contains important information on the
safe and efficient operation of your mobile device.
For your safety, please refer to the guideline prior
to using the phone.
Note: Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refueling
Do not use the phone at a refueling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
3
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules
in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
4
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only approved batteries and accessories, such
as headsets and PC data cables. Use of any
unauthorized accessories could damage you and
your phone and may be dangerous.
If jewelry, keys, beaded chains, or other conductive
materials touch exposed battery terminals, this
could complete an electrical circuit (short circuit),
become very hot, and could cause damage or
injury. Be careful when handling a charged battery,
particularly when placing it inside a pocket, purse,
or other container with metal objects.
Never use a charger or battery that is damaged
in any way.
Use the battery only for its intended purpose.
If you use the phone near the network’s base
station, it uses less power. Talk and standby
time are greatly affected by the signal strength
on the cellular network and the parameters set
by the network operator.
Battery charging time depends on the remaining
battery charge, the type of battery, and the
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time is
noticeably shorter than normal, it is time to buy
a new battery.
If left unused, a fully charged battery will
discharge itself over time.
Use only approved batteries, and recharges
your battery only approved chargers.
Disconnect the charger from the power source
when it is not in use. Do not leave the battery
connected to a charger for more than a week,
since overcharging may shorten its life.
Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
5
Do not leave the battery in hot or cold places
because the capacity and lifetime of the battery
will be reduced. Try to keep the battery at room
temperature. A phone with a hot or cold battery
may not work temporarily, even when the
battery is fully charged.
Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object like a
coin, clip or pen causes a direct connection
between the + and – terminals of the battery
(metal strips on the battery). For example, do
not carry a spare battery in a pocket or bag
where the battery may contact metal objects.
Short-circuiting the terminals may damage the
battery or the object causing the short-circuiting.
6
Dispose of used batteries in accordance with
local regulations. Always recycle. Do not
dispose of batteries in a fire.
Road safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold. When driving a car,
driving is your first responsibility. When using your
wireless phone while driving, follow local
regulations in the country or region you are in.
Operating Environment
Remember to follow any special regulations in
force in the area you are in, and always switch off
your phone whenever it is forbidden to use it, or
when it may cause interference or danger. When
connecting the phone or any accessory to another
device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are
consistent with the independent research and
recommendations of Wireless Technology
Research. If you have any reason to suspect that
interference is taking place, switch you’re your
phone immediately.
Hearing aids
Some digital wireless phones may interfere with
7
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives.
Radio frequency (RF) exposure and SAR
This phone meets European Union (EU)
requirements concerning exposure to radio waves.
Your mobile phone is a radio transmitter and
receiver. It is designed and manufactured to not
exceed the limits for exposure to radiofrequency
(RF) energy, as recommended by the EU Council.
These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the
general population. The guidelines were developed
by independent scientific organizations through the
periodic and thorough evaluation of scientific
8
studies. The limits include a substantial safety
margin designed to ensure the safety of all persons,
regardless of age and health. The exposure
standard for mobile phones employs a unit of
measurement known as Specific Absorption Rate
(SAR).
Specific Absorption Rate (SAR) is the unit of
measurement for the amount of radio frequency
energy absorbed by the body when using a mobile
phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but
the actual SAR level of the mobile phone while it is
operating can be well below this value. This is
because the mobile phone is designed to use the
minimum power required to reach the network.
Variations in SAR below the radio frequency
exposure guidelines do not mean that there are
variations in safety. While there may be differences
in SAR levels among mobile phones, all mobile
phone models are designed to meet radio
frequency exposure guidelines. Before a phone
model is available for sale to the public, it must be
tested and certified by the Federal
Communications Commission (FCC) that it does
not exceed the limit established by the
government-adopted requirement for safe
exposure. The tests are performed in positions and
locations (that is, at the ear and worn on the body)
as required by the FCC for each model. For bodyworn operation, this phone has been tested and
meets FCC RF exposure guidelines when the
handset is positioned a minimum of 15 mm from
the body without any metal parts in the vicinity of
the phone or when used with the original accessory
intended for this phone and worn on the body. Use
of other accessories may not ensure compliance
with FCC RF exposure guidelines.
The SAR limit recommended by the EU Council is
A
2.0W/kg
The highest SAR value for this model phone was
0.954 W/kg.
SAR tests are conducted using standard operating
positions with the phone transmitting at its highest
certified power level in all tested frequency bands.
------------------------------------------------------------A. The SAR limit for mobile phones used by
the public is 2.0 watts/kilogram (W/kg)
9
averaged over ten grams of body tissue.
The limit incorporates a substantial margin
of safety to give additional protection for
the public and to account for any variations
in measurements. The SAR values may
vary, depending on national reporting
requirements and the network band.
SIM AT Service
SIM Card provides several value-added services.
These functions will only display and work on the
menu of the phone when your SIM card is
supported. The content and the terms of the
function lists will depend on your network service
provider.
Please contact your network service provider (a
10
network operator or the service provider) in regards
with availability of any services related to the SIM
card, application information and the costs.
Other medical devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist
you in obtaining this information. Switch off your
phone in health care facilities when regulations
posted in these areas instruct you to do so.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially explosive environments
Switch off your phone when in any area with a
potentially explosive atmosphere, and obey all
signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury
or even death.
Users are advised to switch off the phone while at
a refueling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants, or where
blasting operations are in progress. Areas with a
potentially explosive atmosphere are often but not
always clearly marked. They include the areas
below decks on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas,
such as propane or butane, areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Emergency calls
This phone, like any wireless phone, operates
using radio signals, wireless, and landline networks
11
as well as user-programmed functions, which
cannot guarantee connection in all conditions.
Therefore, you should never rely solely on any
wireless phone for essential communications like
medical emergencies. To make or receive calls,
the phone must be switched on and in a service
area with adequate signal strength. Emergency
calls may not be possible on all wireless phone
networks or when certain network services and/or
phone features are in use. Check with local service
providers.
To make an emergency call:
1. Key in the emergency number for your present
location. Emergency numbers may vary by location.
2. Press the Send Key.
12
3. Inform your location. Do not end the call until
given permission to do so.
Certain features like Call Barring may need to be
deactivated before you can make an emergency
call. Consult this document and your local cellular
service provider.
Other important safety information
Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
Do not store or carry flammable liquids, gases,
or explosive materials in the same compartment
as the phone, its parts, or accessories.
For vehicles equipped with an air bag,
remember that an air bag inflates with great
force. Do not place objects, including installed or
portable wireless equipment, in the area over
the air bag or in the air bag deployment area.
Improperly installed wireless equipment could
result in serious injury if the air bag inflates.
Switch off your phone before boarding an
aircraft. It is dangerous and illegal to use
wireless phones in an aircraft because they can
interfere with the operation of the aircraft.
Failure to observe these instructions may lead
to the suspension or denial of telephone
services to the offender, or legal action, or both.
Qualified service
Only qualified service personnel may repair your
phone.
It is highly recommended to have a repair service
by qualified service personnel. Use only the
approved accessories and batteries
Special features of your phone
• Camera and camcorder
Use the camera module on your phone to take a
photo or record a video.
• Music player
13
Play music files using your phone as a music
player.
• FM Radio and Recording
Listen to FM Radio with search function and
schedule FM Record
• Bluetooth
Transfer media files and personal data and
connect to other devices using free, wireless
Bluetooth technology.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
• Flight mode
Switch your phone to use its none-wireless function
in an airplane.
14
• Java
Enjoy Java™-based embedded game and
download new games.
• Alarm
Use your phone as an alarm clock to wake you up
in the morning or notify you of an impending event.
• Get personal with caller ID
See who’s calling you when their own photo, video
and Ring Tone plays.
• vCard
Create name cards with your number and profile.
Whenever introducing yourself to others, use this
convenient electronic name card.
Unpack
Make sure you have each item
• Phone
• Travel Adapter
• Battery
• User’s Guide
• Earphone
• PC Sync Manager CD & USB Data Cable.
You can obtain various accessories from your local
dealer.
Note:
The items supplied with your phone and the
accessories available at your dealer may vary,
depending on your country or service provider.
Your phone
Keys, features, and locations
15
16
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you
receive a plug-in SIM (Subscriber Identity Module)
card loaded with your subscription details, such as
your PIN, and available optional services.
Install and charge the phone
1. Remove the battery
If the phone is already on, first turn it off by
pressing and holding End key.
2. Insert the SIM card.
Make sure that the gold-colored contacts on the
.
card are face down.
3. Install the battery.
4. Replace the battery cover.
5. Plug the travel adapter into the phone.
6. Plug the adapter into a standard AC wall
outlet.
7. When the phone is completely charged
(the battery icon becomes still), unplug the
adapter from the power outlet.
8. Remove the adapter from the phone.
9. Switch the Phone On/Off
10. Enter Your Pin (Access Codes)
11. Dial the Phone Number Required
Power On or Off
1. Hold down the power on/off key for more than
17
one second to switch on.
2. Enter your SIM card PIN, if requested. The
phone searches for your network and when
detected, will display the idle screen. The
external display shows the signal strength,
battery strength and current time and date.
3. When you wish to switch off the phone, hold
down the power on/off key for more than two
seconds.
Customize your phone
Time and Date
Set time and date for your phone
[10.Settings] [10.2 Phone
[Menu]
Setup]
[10.1.1. Time and Date]
Display language
18
Select the language for your phone menus.
[10.Settings] [10.1 Phone
[Menu]
Setup]
[10.1.2. Language]
Set Dedicated key
Set up a menu for your own favorite menu
items.
[10.Settings] [10.1 Phone
[Menu]
Setup]
[10.1.5. Dedicated key]
Idle mode Wallpaper
Set wallpaper for the idle screen on the
display.
[10.Settings] [10.2 Display
[Menu]
Setup]
[10.2.1.Idle Screen] [10.2.1.1
Wallpaper]
Call ringer melody
[Menu] [10.Settings] [10.3 Sounds &
Alerts]
Phone lock
Protect the phone against unauthorized use
with a phone password. The phone will
require the password on power-up.
[10.Settings] [10.6 Security
[Menu]
Setup]
Keys and display
Key Definition
Soft Keys
Perform functions identified by
left/right display prompt.
Right button: Cancel numbers &
letters when you make a call or
input letter for phonebook,
message or WAP.
Navigation Keys
Scroll through the menu options.
Move the cursor up and down in
the normal editing mode.
Move the cursor to left and right in
all editing mode.
Send Key
Dial or answer a call.
Recall the last call numbers in the
idle mode.
19
20
Power on/off Key & End Key
End a call.
Switch the phone on and off.
(press this key and hold)
Cancel your input in the menu
facility and return to the idle mode.
Alphanumeric Keys
You may enter numbers, letters
and special characters.
It changes camera settings in
camera mode.
Special Function Keys
Enter Special Characters / Perform
Various Functions
Left: Access to “Message”
Right: Access to “F.M. Radio”
Up: Access to “Bluetooth”
Down: Access to “Music Player”
from an idle mode
You may dedicate the left navigation
key for favorite menu in ‘Dedicated
key’ setting menu
(Menu > 11.Settings > 1.Phone
Setup > 5.Dedicated Key)
WAP Key
Access to WAP menu (press
shortly), and launch WAP browser
(press and hold).
Camera Hot Key (side)
Press and hold to start the camera
preview mode.
In camera and video preview mode,
works as a shutter.
Icons
The following icons may appear on the screen to
indicate your phone’s status. The icons shown on
the display may vary depending on your country or
service provider.
Signal Strength
GPRS
Roaming
Missed Calls
New Message
MMS Unread
MMS Busy
Broadcast Message
WAP Mail
Call Barring On
Call Forward
Bluetooth
Bluetooth Headset
Bluetooth Connected
21
Vibrate and Ring
Vibrate then Ring
Vibrator On
Alarm On
Lock
Battery Strength
Headset
* Depending on your country or service provider,
the icons shown on the display may vary.
Access menu functions
22
Use the soft keys
The roles of the soft keys vary depending on the
function you are using. The bottom line of the
display indicates their current role.
By pressing the soft keys and Navigation key:
1. Press a desired soft key.
2. Scroll through the menu options with Navigation
keys.
- Move the cursor up and down in the normal
editing mode.
- Move the cursor to left and right in all editing
mode.
3. Choose [Select] soft key or press the [
confirm the function displayed or option
OK] key to
highlighted.
4. To exit, choose either of the following methods.
- Select [Back] to move up one level.
- Press and hold [End] to return to idle mode.
* From the screen supporting <
open an option list by selecting an item.
Options>, you can
Enter text
Using Keypad
ABC, T9, Number, and Symbol modes
You can enter text in some features such as
Messages, Phone Book, or Calendar, using ABC
mode, T9 mode, Number mode, and Symbol mode.
Press the appropriate key until the character you
want appears on the screen.
Text Input Options:
While you are in text editing mode, you will be in
several modes.
When you select the soft key (left) for option, you
can save the entry or change the Text Input
Method. To erase a character, press the cancel key
next to the character you want to erase. There can
be more than two options depending on what
contents you are editing.
T9 Text Editing Mode
T9 Text Editing Mode is a predictive text input
mode that allows you to key in any character using
single keystrokes.
While you are in T9 editing mode, press the
alphanumeric key once for one character. You will
see T9 suggested words.
23
Overview of menu
functions
To access Menu mode, press [Menu] in Idle mode.
* Some menus are operator-, network- and
subscription-dependent
1. Phone Book
1.1 Quick Search
1.2 Search Entry
1.3 Add New Entry
1.4 Copy All
1.5 Move All
1.6 Delete
1.7 Caller Group
1.8 Speed Dial
1.9 Special Number
1.10 Settings
24
2. Message Center
2.1 Messages
2.2 E-mail
2.3 Voice Mail
2.4 Broadcast Message
3. Call History
3.1 Missed Calls
3.2 Dialed Calls
3.3 Received Calls
3.4 Delete Call Log
3.5 Call Time
3.6 Call Cost
3.7 SMS Counter
3.8 GPRS Counter
4. Music
4.1 Music Player
4.2 Audio Equalizer
5. Camera
5.1 Camera
5.2 Album
5.3 Video Recorder
5.4 Video Player
5.5 Photo Editor
6. FM Radio
6.1 FM Radio
6.2 Schedule FM Record
7. Organizer
7.1 Calendar
7.2 To Do List
7.3 Alarm
7.4 World Clock
7.5 Calculator
7.6 Unit Converter
7.7 Stopwatch
8. Services
8.1 Opera Mini
8.2 WAP
8.3 Data Account
8.4 SIM Toolkit
(Depends on SIM)
9. Entertainment
9.1 Java
9.2 Java Settings
9.3 Games
9.4 Sound Recorder
9.5 Melody composer
9.6.Health
25
9.7 E-Book Reader
10. Settings
10.1 Profiles
10.2 Phone Setup
10.3 Display Setup
10.4 Call Setup
10.5 Network Setup
10.6 Security Setup
10.7 Pen Setup
10.8 TV Out
10.9 Restore Factory Settings
11. Bluetooth
11.1 Bluetooth Mode
11.2 My Devices
11.3 Active Device
26
11.4 Remote Control
11.5 Settings
11.6About
12. File Manager
When you select the Search Entry, after storing
numbers to the phone book, you can search them
by Name.
1. Phone Book (Menu 1)
You can store phone numbers on your SIM card
and in your phone’s memory. The SIM card and
phone’s memory are physically separate, but they
are used as a single entity called Phone Book. To
access this menu, press [
select
Phone Book.
1.1 QUICK SEARCH
Use this menu to search for numbers in Phone
Book.
1.2 SEARCH ENTRY
Menu] in Idle mode and
1.3 ADD NEW ENTRY
Use this menu to add a new contact to Phone
Book.
1.4 COPY ALL
You can copy all phone book data from SIM card
to Phone or from Phone to SIM. I
1.5 MOVE ALL
You can move all phone book data from SIM card
to Phone or from Phone to SIM.
1.6 DELETE
You can delete all phone book data in SIM card or
Phone.
27
1.7 CALLER GROUP
Use this menu to organize your contacts in caller
groups.
1.8 SPEED DIAL
Use this menu to assign speed dial numbers (2 to
9) for your most frequently called numbers.
1.9 SPECIAL NUMBER
You can view and edit your mobile phone number
(owner Number), Service Dial Number and SOS
Number.
1.10 SETTINGS
You can view and edit the settings for the Phone
book.
You may change Human voice volume by
adjusting Ring tone volume.
28
2. Message Center (Menu 2)
Use this menu to send and receive short messages
and multimedia messages, and e-mails. You can
also use a voice-mail and broadcast message
features. Message functions are available
depending on network services that your service
provider supports.
2.1 MESSAGES
Write Message
Text Message
Use this menu to create and send a message as
following
1. Select [Text Message] menu in the
[Writing Message] menu.
2. Make a message.
3. Press [Done] soft key (Right). Then
choose appropriate options.
4. You can input the number directly or get
from the phone book by pressing the
[Search] soft key (left).
5. The phone will display the Message
sending Success or Fail message on the
screen for all recipients.
Multimedia Message
Use this menu to create and send a message
as following
1. Select [Multimedia Message] menu in
the [Writing Message] menu.
2. Compose a message.
3. Press [Option] soft key (left) and then select
“Done.” Then choose appropriate options.
Inbox
This folder stores all of the messages you
have received, except for e-mails.
Outbox
You can view the messages that the phone
has failed to send.
Sent
You can view the sent messages you have
saved.
Drafts
This folder stores messages you have saved
29
to send at a later time.
Delete Folder
This folder helps you to delete all mails in
selected folder as Inbox, Outbox, Sent, Draft
and Delete All Folders.
Template
Use this menu to make and use templates of
frequently used messages.
Message Settings
Within the Message Settings sub-menu, you
can define default values on common
parameters for mobile-originated messages.
2.2 E-MAIL
The E-Mail application allows you to send and
30
receive e-mails. The application supports text and
attachments. The e-mail application could be
either normal POP3 e-mail client or IMAP4 based
e-mail service.
When highlighting on Inbox, Sent, Unsent and
Draft, the number of mails shall be displayed as a
popup hint, e.g., “10 mails”.
Note: If current incoming protocol is set to
IMAP4, and the phone is not currently
connected to the network, when before
entering this screen, shall popup a
confirmation screen for the user with
message “Do you want to connect to the
network?”. If the user selects “Yes”, then
can send list folder request to network;
otherwise, directly enter this screen, and
all popup hint displays “0 mails.”
Send and Receive
In order to exchange the email, the user has
to provide appropriate settings (described in
E-mail Profile).
section
Write E-mail
This menu allows you to write an email.
Inbox
This folder stores the list of emails you have
received.
Unsent
This folder displays the list of unsent e-mails.
Sent
This folder displays the list of sent mails.
Drafts
This folder displays the list of e-mail Draft
you saved.
Delete All Folder
This folder helps you to delete all mails in
selected folder.
Delete All Mark
This folder helps you to delete all mails
marked
E-mail Profile
This folder helps you to configure various
31
servers and Profile related settings. All the
configurable items are grouped into entities
Profiles.
called
Template
voice-mail.
Note: Please contact your service provider for
more information.
2.3 Voice Mail
Your phone is capable of dialing with voice-mail
server number (if provided by your network). If
you receive any voice-mail, your phone displays
New Message in the idle screen.
Select the Voice Mail from the list and press
[Option] soft key (left). You can
Mail server number.
By selecting the
will dial to the configured number that has been
stored in Voice Mail list. You can then listen to the
Connect to Voice, your phone
Edit the Voice
32
2.4 Broadcast Message
This network service allows you to receive the
broadcast messages on various topics such as
weather, traffic, local district code, local hospitals,
taxis or pharmacy in your area.
For more information about broadcast message
topics, please contact your service provider.
The phone will display the Broadcast Messages
immediately when received, on the following
condition:
1) When the phone is in the idle mode
2) When the
to
3) When the message channel is currently
active in the channel list.
Note: This service may not be available on all
Receive Mode (2.4.1) option is set
On
networks. For more information about the
available subjects, please contact your
network service provider.
3. Call History (Menu 3)
Use this menu to view the calls you have dialed,
received, or missed, and the length of the calls.
You can also check the cost of your calls, if the SIM
card supports this function.
To access this menu, press [
and select
Call History.
3.1 Missed Calls
1) This menu displays the most recent 20
received calls that you did not answer. In the
missed calls list, you can view the details of
the record by pressing the [Ok] soft key (left).
In the view screen, you can make a call to the
number by pressing the Send Key.
3.2 Dialed Calls
This menu displays the most recent 20 calls you
have dialed. In the dialed calls list, you can view
the details of the record by pressing the [
Menu] in Idle mode
Ok] soft
33
key (left). In the view screen, you can make a call
to the number by pressing the Send Key.
3.3 Received Calls
This menu displays the most recent 20 calls you
have received.
In the list of received calls, you can view the
details of the record by pressing the [
(left). In the view screen, you can make a call to
the number by pressing the Send Key.
3.4 Delete Call Log
This menu lets you delete all call data of each
category at once.
3.5 Call Time
This menu displays the time log for calls made
Ok] soft key
34
and received. The actual time invoiced by your
service provider will vary.
Note: The actual time invoiced for calls by your
service provider may vary, depending on
network features, rounding-off for billing
purposes and so forth.
3.6 Call Cost
This network feature displays the cost of calls.
This menu is available only if your SIM card
supports this feature. Note that this is not
intended to be used for billing purposes.
Note: Not all SIM cards support this feature. The
number of items in these lists depends on
the contents of your SIM card.
3.7 SMS Counter
You can view the numbers of sent and received
SMS.
3.8 GPRS Counter
You can view how many GPRS message has
been sent and received, and reset the counter.
Settings.
And with the Up Navigation Key, the main display
will be rotated to Play List, Spectrum, ID3 Tag and
Detail. ID3 Tag allows you to provide the music
title, album title and singer and Detail allows you
to provide the output of the song, memory size
and play time.
4. Music (Menu 4)
4.1 Music Player
You can listen to MP3, MIDI, WAV, AMR, iMelody
music files with
Use the Left & Right Navigation Key to view the
play list. It will display available music list from the
Memory Card or Phone depending on Player
Music Player.
To play the music, from the music player screen,
▶ or from [Option] soft key (left), select
select
Current List or My Album then play the song
you want.
4.2 Audio Equalizer
Allows you to set equalizer as Normal,
Bass, Dance, Classical, Treble, Party,
Pop and Rock.
35
5. Camera (Menu 5)
5.1 Camera
Taking and Saving a Photo
1. Choose [Camera] menu or press the side
camera hot key.
2. Set your camera by using [Option] or
alphanumeric keys.
3. After setting the view and take a picture by
pressing the [OK] key.
4. If you want to send the picture by MMS
promptly, select the [MMS] soft key (left).
You can attach the picture automatically.
5 If you want to take more pictures, select the
[Back] soft key (right). The screen will
display the camera preview.
You can view the image in the Photo Viewer.
Key Usages in Camera Preview
※ Left & Right Navigation Keys
• Camera and Video Recorder (Left & Right
Navigation Key): allows you to switch to
[Video Recorder] menu and [Camera] menu.
• Brightness Setting (Left & Right Navigation
Key): allows you to adjust the brightness
(Exposure Value). When you press the right
navigation key, the camera preview screen will
become brighter, and the left navigation key
the opposite.
※ Function Keys
There are more functions. You can use these
functions by pressing the keys.
36
• Zoom Setting (Side volume Key): By
pressing the side volume key up or down, you
can zoom in and out the preview.
• Option (Left Soft key) – press the [Option]
soft key (left) to view and select options for the
Camera settings and viewer. See details the
following descriptions for Options.
• Cancel or Back (Right Soft key)– if you want
to cancel your key-input or go back to upper
menu, press the [Back] soft key (right).
5.2 Album
You can see your photos in your phone by
choosing [Photo Viewer] menu in [Camera] menu.
It will display the photos with thumbnail, image
name, and image size.
5.3 Video Recorder
With this phone, you may record a video with the
Video Recorder menu.
Recording and Saving a Video
1. Choose [Video Recorder] menu.
2. Set your video recorder by using [Option]
3. After setting the view, start to record a video
by pressing the [OK] key.
4. The video will be saved automatically to the
Video Player when you press the [Stop] soft
key (right).
5.4 Video Player
You can view the recorded video with the Video
Player. Press the side volume key to adjust the
volume.
37
By pressing the key, you can view the
5.5 Photo Editor
recorded video with the width screen.
By pressing the
image. The captured image will be displayed in
[Photo Viewer] menu.
Photo Manager
You can edit photo image with this function.
1. Select the image file you want to edit in the
File Manager storage.
2. Choose ‘Auto Resize’, ‘Main LCD Clip’.
(1) Auto Resize function resizes the selected
image to full image
(2) Main LCD Clip function clips a part of
image to fit in 320x240 pixels.
key, you can capture the
38
Image Tile
You can edit photo image by using several shots
you saved at Photo Viewer and combine them in
one frame.
Slide Show
You can view your images as a slide show, a
sequential presentation of each image in the
current folder.
6. FM Radio (Menu 6)
6.1 FM Radio
To listen to the radio:
From the FM Radio mode, you can access to
the FM Radio options by pressing the <option>
soft key (left).
6.2 Schedule FM Record
This menu allows you to set the Schedule FM
Radio to record at a specific time. You can save
up to 4 channels.
Press the [Save] soft key (right) to save the
changes.
7. Organizer (Menu 7)
Use this menu to keep track of your schedule.
You can also use convenient features, such as
Alarm, World Clock, Calculator, Unit Converter,
Health and Stopwatch.
To access this menu, press [Menu] in Idle mode
and select
7.1 Calendar
You can keep track of your monthly schedule.
7.2 To Do List
You can view all saved tasks.
7.3 Alarm
This menu allows you to set the alarm to ring at
a specific time. You can save up to five alarms.
7.4 World Clock
Set your local time zone and find out the current
time in another part of the world.
7.5 Calculator
Perform basic arithmetic functions.
7.6 Unit Converter
Organizer.
39
You can convert from one type of unit to another.
7.7 Stopwatch
Measure elapsed time.
8. Services (Menu 8)
This menu allows you to use services including
SIM card additional services, WAP and Data
Service.
8.1 Opera Mini.
8.2 WAP
The Wireless Application Protocol (WAP) on your
phone allows you to access the wireless web.
Using the web browser, you can access up-todate information and a wide variety of media
content, such as wallpapers, ring tones, and
music files.
To access this menu, press [Menu] and select
Services then WAP. You can also press the WAP
key in the idle mode.
Homepage
When you choose [Homepage] menu, WAP
browser opens the main page of home site that
you had activated among the sites in [Profile].
Bookmarks
You can make bookmark data in your phone.
And you can connect to the site directly.
Recent Pages
When you choose [Recent Pages] menu, WAP
browser opens the latest WAP page.
40
Enter Address
If you know the URL of the site, you can go to
the site directly by inputting the URL.
WAP Push
This menu stores the list of WAP Push you have
received.
Settings
This option allows you to set the WAP settings.
There are several profiles of sites in this phone.
You can activate one of them as a home site
and change or set each profile.
8.3 Data Account
This menu allows you to change the settings for
the GSM and GPRS network services. For further
details, contact your service provider.
GSM
This setting allows you to change the settings
for the GSM network.
GPRS
This setting allows you to change the settings
for the GSM Data network.
8. 4 SIM Toolkit (depends on SIM)
If you use a SIM card that provides additional
services, the STK menu displays. For details,
please refer to your SIM card instructions or
contact your service provider.
9. Entertainment (Menu 9)
The Fun provides you with Java interface and
41
Games. You can use your phone as your
entertainment center.
9.1 Java
Using this menu you can enjoy the embedded
Java games and downloaded Java games or Java
Applications from WAP.
9.2 Java Settings
You can setup audio, network profile, and free
data space.
9.3 Games
This phone provides you embedded games.
9.4 Sound Recorder
With this menu, you can record sound in AMR,
WAV and AWB format and use it as voice memo,
42
ring tone, MMS and EMS attachment.
9.5 Melody Composer
With this menu, you can create an iMelody file.
You can use this melody as your Ring Tone, MMS
and EMS attachment.
9.6 Health
With the Health menu, you can check your BMI
(Body Mass Index).
9.7 E-Book Reader
The viewer application provides an easy way for
you to read documents stored in the phone’s
memory or a memory card.
10. Settings (Menu 10)
The Settings menu provides you with various
setting options to customize the phone to your
preferences and needs. You can also reset the
settings to their default values.
To access this menu, press [
and select
Settings.
10.1 Profiles
Use this menu to customize various sound and
change settings for the light.
You may change intelligent call and English voice
volume by adjusting Ring tone volume.
10.2 Phone Setup
Many different features of your phone’s system
Menu] in Idle mode
can be customized to suit your preferences.
Time and Date
You can set time and date for your phone.
Language
Use this menu to select one of several
languages for the display text.
Select your preferred language and press [Ok]
soft key (left) to save the setting.
Preferred Input Methods
The preferred input method changes the input
languages automatically under the Language
setting.
Dedicated Key
You can use the dedicated keys as shortcut
keys to access specific menus directly from idle
43
mode.
Select from the menu lists, and press [Ok] key
to change the dedicated menu.
Default Dedicated Keys:
Up: Bluetooth
Down: Music Player
Left : Messaging
Right: FM Radio
Flight Mode
This menu allows you to set Flight Mode. Press
the [Edit] soft key (left) to set the Flight Mode.
• Normal Mode
• Flight Mode
• Query When Power On
10.3 Display Setup
44
This menu allows you to customize desired
phone display items.
10.4 Call Setup
The following Call Setup features are network
services. Please contact your network service
provider to check availability and subscribe to the
feature.
Caller ID
This network service informs your Caller ID to
the recipient when you call out.
You can set the following options for the Caller
ID function.
Call Waiting
This network service informs when someone is
trying to reach you during another call. You can
specify the call waiting option for voice calls only.
Call Divert
This network service reroutes incoming calls to
the number that you specify.
: you may wish to divert your business
Example
calls to a colleague while you are busy.
Note: The phone sends your settings to the
network and the network will acknowledge
the settings. You can deactivate all call
diverting settings by selecting the Cancel
All.
You can also cancel all call barring settings. You
will be able to make and receive calls normally.
You can set and change the call barring
password obtained from your service provider
using this option. You must enter the current
password before you can specify a new one.
Note: The phone sends your settings to the
network and the network returns the
acknowledgement. You can deactivate all
call barring settings by selecting the
Cancel All.
Call Barring
This network service allows you to restrict your
call for Outgoing Calls, Incoming Calls.
Call Time Reminder
You can set the call time reminder. Options are
Off, Single, and Periodic.
45
Call Time Display
If you want, you can set the phone to display the
call time.
Auto Redial
This option allows you to set redial automatically
when the call receiver is busy. If you set [Auto
Redial] on, it will redial 10 times to make a call.
10.5 Network Setup
Network Setup helps you in Network Selection,
selection of Preferred Network, and GPRS
connection.
Network Selection
The Network Selection feature enables you to
select automatically or manually the network
used when roaming outside of your home
46
network.
Note: You can select a network other than your
home network only if it has a valid roaming
agreement with your home network.
Preferred Networks
You can set your preferred networks from PLMN
list. You can add From List, Create New,
Change Priority and Delete
Band Selection
This menu allows you to select the service
bandwidth to 900, 1800, 1900, Dual Band and
Auto.
GPRS Connection
Press [Change] soft key (left) to change the
setting for the GPRS connection.
It will switch and save the GPRS connection to
set on:
1) When Needed.
2) Always
10.6 Security Setup
Use this menu to protect the phone against
unauthorized use by managing the several
access codes of y0our phone and SIM card.
There are six types of security setting categories,
and you can optimize security mode by choosing
sub menus in “Security Setup” in “Settings” menu.
These security settings will help you to keep
privacy and to prevent other people from using
the phone without your permission.
Note: If you enter an incorrect PIN/PIN2 three
times in succession, the SIM card is blocked. To
unblock it, you need to enter your PUK/PUK2.
The codes are supplied by your network operator.
PIN Lock
When the PIN Lock feature is on, the phone
only works when you enter PIN code for the SIM
card. If you turn on the phone with the SIM card,
the phone will ask for the password. Once the
correct password is entered, the phone will work
with the SIM card.
Phone Lock
When the Phone Lock feature is on, user must
enter the password each time you turn on the
47
phone. Making a call or operating the phone is
not available without the password.
Auto Key Lock
To prevent unwanted accidental key presses,
you can use this auto keypad lock function. You
may not make a call or operate the phone until
you press the unlock code. However, answering
a call, receiving messages are available without
entering the unlocking key sequence.
To change the Keypad Lock setting,
1. Press and hold the Camera key or
2. Press the menu key and select 10. Settings
/ 10.6 Security Setup / 10.6.3 Auto Keypad
Lock.
48
To unlock the Keypad Lock time setting,
1. Press the [unlock] touch screen in sequence,
each time you need to release the keypad
lock.
Fixed Dial
When the Fixed Dial mode is enabled, the
person using this phone can call to the
phone numbers stored in the Fixed Dial List
only.
To make a call to the number not starting
the numbers stored in Fixed Dial List, you
must enter the PIN2 to disable Fixed Dial
mode. If the SIM card does not have PIN2,
this feature is not supported.
Barred Dial
When the Barred Dial mode is enabled, the
person using the phone cannot call numbers in
the barred dial list. To call a barred number, you
must enter the PIN2 to disable the barred dial
mode. If the SIM card does not have PIN2, it will
not support the Barred Dial feature.
Change Password
To change the password, input the current
password, and then enter the new password.
Note: The initial password is “0000.” After you
change your password, you will need to
input the password. If you forgot your
password, contact the service center.
10.7 Pen Setup
In case of the failure to operate Touch Point, the
user can adjust the coordinates for optimal use.
10.8 TV Out
Use this menu to select a video system for a TV.
You can view the display of your phone on a TV
screen by connecting the phone and TV with the
TV out cable. This enables you to enjoy the
photos, videos and music stored in the phone’s
memory with your family or friends on a larger
screen.
49
Important TV information
Depending on your particular TV
model, the location and shape of the
video input and audio output ports
may vary.
Match cable connector and TV port
colors.
Depending on the video system, the
image may vibrate or in some other
way be less than optimal.
Depending on the video quality, some
video clips may not display.
You cannot use a Bluetooth stereo
50
headset or the zooming feature in TV
Out mode.
You cannot use the touch feature in
TV Out mode.
Transfer phone display to a TV
1. With the TV switched on, connect your phone to
the TV with a TV out cable, as shown.
2. Switch the TV to External Input mode. The
display switches to TV
Out mode and you can view the phone’s display
on the TV screen.
3. If necessary, set the video system for your TV in
TV-out.
the
10.9 Restore Factory Settings
This feature would reset the phone to the same
settings as those configured at the factory. In this
case, it does not delete the downloaded objects
and phone book records.
You will need to input password to restore factory
settings. The initial password is 0000.
11. Bluetooth (Menu 11)
11.1 Bluetooth Mode
To connect this phone to other Bluetooth device,
set this option to On.
icon will appear on the idle screen.
The phone’s Bluetooth power will be turned on,
until you turn the Bluetooth Mode off. When you
turn off your phone’s power, and turn on the next
time, the Bluetooth power will be On. If the
Bluetooth device was connected, the phone will
connect to the device when the phone’s power is
back on.
Note: When you are not using the Bluetooth
feature, set the Bluetooth Mode to Off,
in order to save the battery power.
11.2 My Devices
This menu will search for the Bluetooth device(s)
within the range of your phone. You can
conveniently connect to the frequently using
Bluetooth device by using this menu.
51
1. Put the device nearest possible when you
search a new device.
2. Check to turn on your phone and the new
device. For turning on your new device, see
instruction provided by the device manufacturer.
Make sure your phone is in Bluetooth Mode.
3. Select “Inquiry New Device” to find the
new device.
4. After your phone finds the device, press [Bond]
soft key (left), it might ask for a pass code.
Default pass code is depending on the
Bluetooth device. You might try 0000 as a pass
code. Usually the Bluetooth audio device
provides a guide with this pass code.
5. The phone and device will be paired and
52
connected. If you fail this pair procedure, try
again or contact the device manufacturer, or
change to other device.
Note: Please use recommended Bluetooth
devices for optimal use.
11.3 Active Device
This menu activates the Bluetooth device(s) of
your phone.
11.4 Remote Control
1) Prepare MEGA4 Handset and PC with
Bluetooth(V1.2) installed.
2) Menu – Settings – Bluetooth – Bluetooth
Mode : On
3) Menu – Settings – Bluetooth – My Devices –
Option – Search for Devices – Select PC
Bluetooth Device – Bond – Insert Code
No.(0000) – Complete the connection.
4) When the paring is completed, you can find
and connect the HID Profile from your PC to
Handset. (The connection mode can be
different by each BT Vendor application tool.)
5) Automatically connect to Remote control
menu in Bluetooth mode.
① Desktop : Window Desktop Control menu
② Media Player : Window Media Player Control
menu
③ Presenter : MS Power Point Control menu
6) You can operate the Remote Control function
by inserting the GUI Key in each menu table.
11.5 Settings
Visibility
You can set your phone visible to other
Bluetooth devices. If you set this On, other
devices can search your phone as a Bluetooth
device. You can only change this option when
the Bluetooth Mode is On.
My Phone Name
Name your phone name by using this option.
When other Bluetooth device searches your
phone, this name will be displayed.
Authentication
Set Authentication On or Off. You can only
change this option when the Bluetooth Mode is
On.
53
Audio Path
(1)Leave in Phone
(2)Forward to BT Headset
FTP Settings
Set shared folders of File manager when you
send data by Bluetooth.
11.7 About
This menu will display your Bluetooth’s profile.
(Hands free, Headset, SPP, DUN, OPP, FTP,
A2DP, AVRCP)
12. File Manager (Menu 12)
Use this menu to navigate the stored files in the
phone or the Micro SD (T-Flash) Card. You can
open files and use them in a way the phone
supports, and see the total memory used and free
space in the storage.
Note:
After selecting Copy or Move option, press the
left or right navigation keys to access to the
upper or lower folder.
Note:
Depending on the software installed or your
service provider or country, some of the
descriptions in this guide may not match your
phone exactly.
Depending on your country, your phone and
accessories may appear different from the
54
illustrations in this guide.
55
Loading...
