3130
Portable Pressure Calibrator
PN 4222409 February 2013
© 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is one year and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days. This warranty extends only to the original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses, disposable batteries, or to any product which, in Fluke's opinion, has been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions of operation or handling. Fluke warrants that software will operate substantially in accordance with its functional specifications for 90 days and that it has been properly recorded on non-defective media. Fluke does not warrant that software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for importation costs of repair/replacement parts when product purchased in one country is submitted for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of charge repair, or replacement of a defective product which is returned to a Fluke authorized service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center to obtain return authorization information, then send the product to that service center, with a description of the difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk for damage in transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid (FOB Destination). If Fluke determines that failure was caused by neglect, misuse, contamination, alteration, accident, or abnormal condition of operation or handling, including overvoltage failures caused by use outside the product’s specified rating, or normal wear and tear of mechanical components, Fluke will provide an estimate of repair costs and obtain authorization before commencing the work. Following repair, the product will be returned to the Buyer transportation prepaid and the Buyer will be billed for the repair and return transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential damages, the limitations and exclusions of this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not affect the validity or enforceability of any other provision.
Fluke Corporation P.O. Box 9090 Everett, WA 98206-9090 U.S.A.
Fluke Europe B.V. P.O. Box 1186 5602 BD Eindhoven The Netherlands
11/99
To register your product online, visit register.fluke.com

Table of Contents

Title Page
Introduction ........................................................................................................ 1
How to Contact Fluke Calibration ..................................................................... 2
Safety Information ............................................................................................. 2
Standard Equipment ........................................................................................... 3
Features .............................................................................................................. 4
Buttons ........................................................................................................... 4
Display ........................................................................................................... 5
Calibrator Interface ........................................................................................ 6
Typical Connections ...................................................................................... 7
Power Options .................................................................................................... 9
Product Startup .................................................................................................. 9
Product Menus ................................................................................................... 9
Top-Level Menu ............................................................................................ 11
Main Menu .................................................................................................... 11
Display Configuration Menu ......................................................................... 12
Zero Function ..................................................................................................... 13
Internal Sensor and Pressure Module (non-absolute) .................................... 13
Absolute Pressure .......................................................................................... 13
Other Menu Controlled Functions ..................................................................... 14
Contrast Main Menu ...................................................................................... 14
Lock or Unlock the Display Configuration ................................................... 14
Save and Recall Menu Setups ....................................................................... 15
Automatic Shutdown ..................................................................................... 15
Activate and Deactivate a Display ................................................................. 16
Damping ........................................................................................................ 16
HART Resistor .............................................................................................. 16
Pump Limits .................................................................................................. 16
Initial Setup and Basic Pressure Generation ...................................................... 17
Pressure Measurement ....................................................................................... 17
Media Compatibility ...................................................................................... 18
External Modules ........................................................................................... 18
Measure and Source Current (4… 20 mA) .................................................... 18
Measure Voltage ............................................................................................ 20
Pressure Switch Test ...................................................................................... 21
Calibrate Transmitters ................................................................................... 23
Use the mA Measurement Function .......................................................... 23
i
3130
Users Manual
Calibrate a Pressure-to-Current Transmitter ............................................. 24
Calibrate a Pressure-to-Voltage Transmitter ............................................. 25
%-Error Function ...................................................................................... 26
Storage Capability .............................................................................................. 29
Remote Operation .............................................................................................. 29
Set Up the RS-232 Port for Remote Control ................................................. 30
Change from Remote to Local Operation ...................................................... 31
Command Use ............................................................................................... 31
Character Processing ..................................................................................... 32
Response Data Types .................................................................................... 32
Calibrator Status ............................................................................................ 33
Error Queue ............................................................................................... 33
Input Buffer ............................................................................................... 33
Remote Commands and Error Codes ............................................................ 33
Enter Commands ........................................................................................... 36
Common Commands ................................................................................. 36
Calibrator Commands ............................................................................... 37
Maintenance ....................................................................................................... 43
User-Replaceable Parts and Accessories ........................................................... 43
Specifications ..................................................................................................... 44
Electrical Specification .................................................................................. 44
Pressure ......................................................................................................... 44
Accuracy ........................................................................................................ 44
Loop Power ................................................................................................... 44
Mechanical Specification .............................................................................. 44
Environmental ............................................................................................... 44
Standards and Agency Approval ................................................................... 45
Power ............................................................................................................. 45
ii

List of Tables

Table Title Page
1. Symbols .................................................................................................................. 3
2. Mode Concurrency ................................................................................................. 13
3. Common Commands .............................................................................................. 33
4. Product Commands ................................................................................................ 34
5. Parameter Units ...................................................................................................... 35
6. Error Codes ............................................................................................................ 36
7. Replaceable Parts ................................................................................................... 43
iii
3130
Users Manual
iv

List of Figures

Figure Title Page
1. Buttons ................................................................................................................... 4
2. Display ................................................................................................................... 5
3. Controls .................................................................................................................. 6
4. External Pressure Supply ....................................................................................... 7
5. Pressure Supply with Internal Pump ...................................................................... 8
6. Pressure Measurement ........................................................................................... 8
7. Menu Map .............................................................................................................. 10
8. Top-Level Menu ..................................................................................................... 11
9. Main Menu ............................................................................................................. 12
10. Display Configuration Menu .................................................................................. 12
11. Absolute Pressure ................................................................................................... 13
12. Contrast Menu ........................................................................................................ 14
13. Display Configuration Menu .................................................................................. 14
14. Setups Menu ........................................................................................................... 15
15. Auto Shutdown Menu ............................................................................................ 15
16. Active Display Menu ............................................................................................. 16
17. Pressure Module ..................................................................................................... 18
18. Measure and Sourcing Current ............................................................................... 19
19. Measure Voltage .................................................................................................... 20
20. Switch Test Connections ........................................................................................ 21
21. Switch Test Screen ................................................................................................. 21
22. Switch Test Screen (Open) ..................................................................................... 22
23. Opened Switch Reading ......................................................................................... 22
24. Switch Test and Deadband Results ........................................................................ 23
25. Passive and Active Screens .................................................................................... 23
26. Calibrate a Pressure-to-Current Transmitter .......................................................... 24
27. Calibrate a Pressure-to-Voltage Transmitter .......................................................... 25
28. Connections with a Pressure Transmitter with % Error Function .......................... 26
29. Port Setting Screen ................................................................................................. 27
30. Loop Power Screen ................................................................................................ 27
31. Set Unit Screen ....................................................................................................... 27
32. Setting the Upper Limit .......................................................................................... 28
33. % ERROR Screen .................................................................................................. 28
34. Saved Upper and Lower Limits ............................................................................. 28
35. Remote Operation .................................................................................................. 29
v
3130
Users Manual
vi
Introduction
The Fluke 3130 (the Product) is a portable pressure calibrator that can use two methods to source pressure:
• An internal, electronic pump that has a range of -12 psi to 300 psi (-0.8 bar to 20 bar)
• An external connection that lets you use externally-sourced, clean, dry air to regulate
pressures to a maximum of 300 psi
Product features include:
• A built-in needle valve for metering in pressure
• Variable volume for small pressure changes
• An internal pressure sensor
• Measurement of 0 V dc to 30 V dc and 0 mA to 24 mA from a unit under test (UUT).
• Sourcing current of 0 mA to 24 mA to a UUT also available
• A 24 V dc loop power supply that uses dedicated front panel jacks. For voltage
transmitters, a dedicated 24 V dc loop power supply is available in volts measure mode. mA loop power is supplied from the left-most jacks.
• An internal, high-capacity NiMH battery
• A universal power supply (90 V ac to 250 V ac) that can charge the battery pack
while it powers the Product
• Pressure measurement with the internal pressure sensor or with a Fluke 700 Series
external pressure module
• The Product can show pressure units in these different values:
• psi
• mH2O20°C
• MPa
• kPa
• inHg 0°C
• mmHg 0°C
• kg/cm
• mmH
2
O 4°C
2
• inH
• inH
2
2
• cmH
• cmH
• bar
• mbar
O 4°C O 60°C
O 4°C
2
O 20°C
2
1
3130
Users Manual
How to Contact Fluke Calibration
To contact Fluke Calibration, call one of the subsequent telephone numbers:
• Technical Support USA: 1-877-355-3225
• Calibration/Repair USA: 1-877-355-3225
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31-40-2675-200
• Japan: +81-3-6714-3114
• Singapore: +65-6799-5566
• China: +86-400-810-3435
• Brazil: +55-11-3759-7600
• Anywhere in the world: +1-425-446-6110
To see product information and download the latest manual supplements, visit Fluke Calibration’s website at www.flukecal.com. To register your product, visit http://flukecal.com/register-product.
Safety Information
A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the
equipment under test.
To prevent possible electrical shock, fire, or personal injury:
• Read all safety Information before you use the Product.
• Use the Product only as specified, or the protection
supplied by the Product can be compromised.
• Do not use the Product around explosive gas, vapor, or in
damp or wet environments.
• Do not use and disable the Product if it is damaged.
• Only assemble and operate high-pressure systems if you
know the correct safety procedures. High-pressure liquids and gases are hazardous and the energy from them can be released without warning.
For safe operation and maintenance of the Product:
• Use only Fluke approved power adapters to charge the
battery. See the “User-Replaceable Parts and Accessories” section.
Warnings
2
Portable Pressure Calibrator
Standard Equipment
Symbols used on the Product and in this manual are in Table 1.
Table 1. Symbols
Symbol Meaning Symbol Meaning
Risk of danger. Important information. See manual.
Pressure Battery
Hazardous voltage. Risk of electrical shock.
Standard Equipment
Items included with the Product are in the list below. If the Product is damaged or something is missing, immediately contact Fluke Calibration. See the “How to Contact Fluke Calibration” section.
Conforms to European Union directives.
This product complies with the WEEE Directive (2002/96/EC) marking requirements. The affixed label indicates that you must not discard this electrical/electronic product in domestic household waste. Product Category: With reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation” product. Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information.
• Printed 3130 Safety Information
• 3130 Manual CD-ROM with multilingual users manuals
• Six 1/8 inch NPT quick connectors for calibration hoses
• Two 3 foot sections of 1/8 inch O.D. hose
• One 1/8 inch NPT female on 1/4 inch NPT female fitting
• One 1/8 inch NPT female on 1/4 inch BSP female fitting
• Thread seal tape
• Test cables (two red, two black)
• Universal power supply
• Traceable calibration certificate
3
3130
Users Manual
Features
Product features and user interface information is in the subsequent sections.
Buttons
The Product buttons are on the left-side of the Product face and are shown in Figure 1.
F1 F2 F3
HOME
ZERO PUMP
Button Description
hbb005.eps
 Push to turn on the Product.
, , 
Push to zero pressure measurements.
Push to start the electric pump.
, , , 
Softkeys to configure the Product and move through the Product menus. The button
function changes in relation to the navigation menu.
Push to control mA source/sim and to set pump and % error limits.
Push to go to the Product main screen.
Figure 1. Buttons
4
Portable Pressure Calibrator

Features

Display
The display can be made up of a maximum of three process measurement sections plus the menu bar which is always at the bottom of the display. The sections of the display are referred to by the Product and in this manual as UPPER, MIDDLE, LOWER, and menu bar. Push the softkeys that correspond to items shown on the menu bar to move through the Product menus. The arrow keys change values for some menu steps. See “Product Menus”.
The Display sections are shown in Figure 2.
3
4
5
1
2
Item Description
Menu Bar- Access the Product menus and parameters from the menu bar. See the “Product Menus” section.
Active Display- On the main menu, the middle of the menu bar shows the active display. In this image, the LOWER display is active. This section of the menu bar can also say UPPER and MIDDLE. This depends on which section is active.
6
7
8
hbb008.eps
UPPER display section MIDDLE display section LOWER display section
Pressure Units- Pressure units are shown in this section of the display. Select from 14 pressure units.
Span Indicator- Percentage of the 4 mA to 20 mA span when the mA or mA loop functions that are used show in this section of the display.
Primary Parameter- Shows the current measured parameter.
Figure 2. Display
5
3130
Users Manual
Calibrator Interface
The pressure controls are shown in Figure 3.
9
PORTABLE PRESSURE CALIBRATOR
EXTERNAL
PRESSURE MODULE
3130
F1 F2 F3
HOME
ZERO PUMP
CLOSE VALVE BEFORE OPERATING PUMP
FILTER
SUPPLY
METERING VALVE
VENT
VENT
FINE
ADJUSTMENT
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
PRESSURE
SENSOR
PRESSURE
VACUUM
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
CLOSED
ISOLATION
VALVE
21
3
LOOP
V mA
SWITCH TEST
COM
24 V DC
CHARGE
30 V MAX
16 V DC
5.6 A
SERIAL NO.
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
4
6
78
5
hbb006.eps
Item Description
Supply metering valve. Use the supply metering valve to regulate the incoming air supply. See the “Typical Connections” section for more.
Isolation valve. This valve isolates the right-most port and pressure sensor from the Vent/Fine adjust, pump, and Supply Metering Valve.
Pump Pressure/Vacuum. In the + position, the pump operates from 0 psi to 300 psi. In the - position, the pump runs in vacuum mode, which is 0 psi to -12 psi.
Fine adjust/vent. Use the small silver knob of this valve to bleed off the pressure in a
controlled manner. If left open, it will vent all pressure off safely. The outer-most knob (black) is a vernier control that varies the volume which finely reduces or increases the pressure.
Power Adapter input.
24 V power for voltage transmitters. This jack only powered when in Voltage Measure mode.
 Common Jack.

Input Jacks. Use the input jacks for volts and milliamp functions. See the “Measure and Source Current (4… 20 mA)” and “Measure Voltage” sections. Also used for switch test.
 External pressure module connection. See the “External Modules” section.
Figure 3. Controls
6
Portable Pressure Calibrator
Features
Typical Connections
Typical connections of the pressure controls, connection port, and electrical inputs are shown in Figures 4, 5, and 6.
Fully Closed
0 psi to 300 psi
Air Supply
PORTABLE PRESSURE CALIBRATOR
EXTERNAL
PRESSURE MODULE
3130
CLOSE VALVE BEFORE OPERATING PUMP
FILTER
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
PRESSURE
SENSOR
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
CLOSED
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
24 V DC
CHARGE
16 V DC
SUPPLY
METERING VALVE
PRESSURE
VENT
VENT
ADJUSTMENT
5.6 A
FINE
ADJUSTMENT
FINE
CAUTION
VENT LINE BEFORE MAKING SELECTION
PUMP
VACUUM
SERIAL NO.
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA
www.flukecal.com
hbb002.eps
Figure 4. External Pressure Supply
7
3130
Users Manual
EXTERNAL
PRESSURE MODULE
PORTABLE PRESSURE CALIBRATOR
3130
Closed Silver Vent Knob
Fully Closed
FILTER
CLOSE VALVE BEFORE OPERATING PUMP
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
PRESSURE
SENSOR
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
CLOSED
EXTERNAL
PRESSURE MODULE
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
3130
24 V DC
PORTABLE PRESSURE CALIBRATOR
CLOSE VALVE BEFORE OPERATING PUMP
CHARGE
16 V DC
SUPPLY
METERING VALVE
PRESSURE
VENT
VENT
ADJUSTMENT
5.6 A
FINE
ADJUSTMENT
FINE
CAUTION
VENT LINE BEFORE MAKING SELECTION
PUMP
VACUUM
SERIAL NO.
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA
www.flukecal.com
Figure 5. Pressure Supply with Internal Pump
FILTER
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
PRESSURE
SENSOR
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
CLOSED
-12 psi to 300 psi Pressure Source
hbb003.eps
8
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
24 V DC
CHARGE
16 V DC
SUPPLY
METERING VALVE
PRESSURE
VENT
VENT
ADJUSTMENT
5.6 A
FINE
ADJUSTMENT
FINE
CAUTION
VENT LINE BEFORE MAKING SELECTION
PUMP
VACUUM
SERIAL NO.
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA
www.flukecal.com
hbb004.eps
Figure 6. Pressure Measurement
Portable Pressure Calibrator
Power Options
Power Options
The Product can be powered with the internal, high-capacity NiMH battery and/or the universal power supply (90 V ac to 250 V ac) that charges the battery pack. The universal power supply can power the Product at the same time it charges the battery pack. A fully­discharged battery can take a maximum of 14 hours to recharge. When the Product is first received, plug it into the universal power supply for that period to ensure the Product is fully charged.
Product Startup
When you turn on the Product, it goes through a short self-test. The display shows the current firmware version, auto-shutdown status, and the range of the internal pressure sensor. The Product also shows the warning “ FOR USE WITH DRY GAS ONLY”.
A minimum 5-minute warm-up is necessary to get the rated accuracy of the Product. If there are large changes in ambient temperature, a longer warm-up is necessary.
Pressure ranges must be zeroed each time the Product is started. See the “Zero Function” section for instructions to zero the pressure sensor displays.
Product Menus
The menu bar at the bottom of the display is controlled with the softkeys or arrow keys, this depends on which menu is in use. Use the menu bar to navigate the Product menus. The menus are explained in the subsequent sections. A menu map is shown in Figure 7.
9
3130
Users Manual
Active
Display
Active
Display
10
Figure 7. Menu Map
hbb001.eps
Portable Pressure Calibrator
Product Menus
Top-Level Menu
The top-level menu is shown in Figure 8. It has three levels.
Figure 8. Top-Level Menu
hbb009.eps
• MENU- Push the MENU softkey to get to the main menu. See the “Main Menu”
section.
• [Active Display]- The active display is shown in the middle field on the top-level
and main menu. In Figure 8 the active display is the LOWER display. This menu item lets you assign the ZERO key to one of the three display sections. Push the softkey that corresponds to the display named on the menu bar to change the active display. If the chosen display is a pressure range, then the ZERO key becomes active.
• LIGHT- The Product has a backlight for low-light situations. To turn on or turn off
the backlight, push the LIGHT softkey on the main menu. The backlight cannot be controlled by the serial interface.
Main Menu
To go to the main menu, push the MENU softkey from the top-level menu. From the main menu, the submenus can be accessed. The main menus are:
• Config- Display Configuration menu
• % Error Main Menu
• MinMax Menu
• Contrast Main Menu
• Lock Config Menu
• Setups Main Menu
• Save/Recall Menu
• Auto Off Main Menu
• Setups Main Menu
• Display Main Menu
• Damp Main Menu
• HART Main Menu
• Pump Limit Main Menu
Some of these menus are broken up into more submenus.
11
3130
Users Manual
The main menu is shown in Figure 7 and has three levels.
• CONFIG (Configuration) - Push  to access the config menu. Push  again to go
to the Display Configuration menu. This will let you change the parameters for each display section. See the Parameter Selection portion of the Figure 7.
• [Active Display] - See the “Top-Level Menu” section.
• MORE- Push to access the % Error Main Menu.
Display Configuration Menu
Use the display configuration menu to set the parameters of the active display. Push the SELECT softkey to move through this menu. See Figure 13.
Figure 10. Display Configuration Menu
Figure 9. Main Menu
hbb010.eps
hbb011.eps
The first parameter is Mode. Since voltage, current, and switch test modes all use the same jacks, two of these functions cannot be used at the same time. What can be selected depends on what is already selected in another display.
Push the NEXT softkey to change the second parameter. Pressure can be read in 14 different engineering units. Only Pressure mode has a second parameter.
These modes are available with a single display:
• P[1] = Pressure internal sensor
• [EXT] = Pressure with external pressure module
• P[1] ST = Switch Test with internal sensor
• [EXT] ST = Switch Test with external pressure module
Note
mA functions are only available on the lower section of the display.
• mA Measure = Milliamps measure.
• mA Source = Milliamps source.
• SIM-2W = Milliamps simulate using an external supply from the UUT.
• VOLTS = Voltage Measure.
• mA MEAS/24v
12
Table 2 shows which functions are available concurrently.
An X in a column indicates that the mode in the active display is not available for selection if the mode in that row is in use in a different display.
Use the MORE option on the main menu to access other menu functions.
Portable Pressure Calibrator
Zero Function
Table 2. Mode Concurrency
Active Display
P[1] [EXT] P[1]ST [EXT]ST mA
P[1] x x x x x x x
[EXT] x x x x x x x
P[1]ST x x
Other Displays
[EXT]ST x x
mA x x x
mA MEAS/24V
Volts x x x
x x x
Zero Function
When is pushed, the Product zeros its active display if a pressure mode is selected, and the pressure is within the zero limit. The zero limits are within 10 % of the full-scale range of the selected sensor. If the display shows “OL,” the zero function will not operate. is only used for pressure.
Internal Sensor and Pressure Module (non-absolute)
When a sensor or pressure module is selected on the active display and is pushed, the Product subtracts the current reading from the output. The zero limits are within 10 % of the full-scale range of the selected sensor. If the display shows “OL,” the zero function will not operate.
mA
MEAS/24V
Volts
Absolute Pressure
When an absolute pressure range is selected on the active display and is pushed, the Product prompts you to enter the barometric reference pressure. Record the barometric reference pressure with the arrow buttons. While you do this procedure, make sure the sensor port is open (vented) to the atmosphere. See Figure 11.
Figure 11. Absolute Pressure
hbb012.eps
13
3130
Users Manual
Other Menu Controlled Functions
There are many submenus below the main menu. These can be accessed through the MORE option of the main menu. A submenu contains three options. The first option is unique to the function. The second and third options are always the same. The NEXT option leads to the subsequent menu. The DONE option goes home. For the last menu, the NEXT option goes home. See Figure 7 for the menu structure.
In this manual, if a submenu has subsequent menus below it, it is referred to as {function} main menu. As an example, the display contrast submenu will be called the Contrast main menu.
Contrast Main Menu
To set the contrast, go through the menu list until CONTRAST is shown. Push the CONTRAST softkey to access the Contrast Adjustment menu.
Push the up arrow or down arrow softkey to change the display to the necessary contrast level. When completed, push the CONTRAST DONE softkey to go home. See Figure 12.
Figure 12. Contrast Menu
Lock or Unlock the Display Configuration
To lock or unlock the display configuration settings, go through the menu list until LOCK CFG is shown. Push the LOCK CFG or UNLOCK CFG softkeys from the Configuration Lock menu. See Figure 13.
Figure 13. Display Configuration Menu
When the LOCK CFG option is used, the menu goes home and the CONFIG option on the main menu shows that it is locked. All menus are now locked except for Min Max, Contrast Adjustment, and Configuration Lock. When the UNLOCK CFG option is used, the configuration is unlocked and the menu goes to the next sub menu.
hbb013.eps
hbb014.eps
14
Portable Pressure Calibrator

Other Menu Controlled Functions

Save and Recall Menu Setups
The current Product setup is saved for recall at the next power up. Five different setups can be saved for later use. To access these setups, go through the menu list until SETUPS is shown. Push the SETUPS softkey from the Setups Main menu. Push the RECALL softkey to recall a setup or the SAVE softkey to save a setup. Push the DONE softkey to do nothing and go to the home menu.
If SAVE or RECALL is selected, push the arrow keys to select the setup location. Then push the SAVE softkey to store the current setup into the selected location. You can also push the RECALL softkey to recall the setup stored in the selected location. The display menu will go to home. See Figure 14.
Automatic Shutdown
The Product can be set to turn off after a preprogrammed time interval, 0 minutes to 30 minutes. To set the automatic shutdown, go through the menu list until AUTO OFF is shown. Select the AUTO OFF option on the Auto Shutdown main menu
Push the arrow softkeys to choose the number of minutes the Product functions. Or push the down arrow softkey until OFF is shown to disable the automatic shutdown. When you have made the selection, push the AUTO OFF DONE softkey to set the selection. The Product menu will go to the home menu. The auto shutdown timer is reset when a button is pushed. See Figure 15.
Figure 14. Setups Menu
Figure 15. Auto Shutdown Menu
hbb015.eps
hbb016.eps
15
3130
Users Manual
Activate and Deactivate a Display
Use the DISPLAY menu to select which display to use. The ON/OFF option turns the selected display on or off. The selected display and current on/off state are shown in the lower display. See Figure 16.
To choose which displays are active:
1. Go through the menu list until DISPLAY is shown.
2. Push the DISPLAY softkey to access the Display Activation menu.
3. Push the UPPER, MIDDLE, or LOWER softkey to make your selection.
4. Push the ON/OFF softkey to the change the display state.
5. Push the DONE softkey to save the changes and go to the home screen.
When a display is deactivated, its configuration is saved. When the display is activated, its configuration is verified against the configurations of the other currently-active displays. If the configurations are in conflict, the recalled-display configuration is changed to prevent the conflict. If all three displays are deactivated, the lower display will turn on automatically.
Damping
Damping can be turned ON or OFF with the DAMP menu selection. Go through the menu list until DAMP is shown. Select ON or OFF. When damping is ON, the Product shows a running average indication of ten measurements. The Product makes approximately three readings per second.
HART Resistor
An internal 250 HART resistor can be enabled when the Product is used in the mA Measure-24V mode. This lets a HART communicator be connected across the mA terminals and makes it unnecessary to add an external resistor.
When the HART resistor is on, the maximum load-driving capacity is
750
Go through the menu list until HART is shown. Use the arrow softkeys to select ON or OFF.
Pump Limits
To prevent overpressure of sensitive devices the maximum pressure (pump limit) can be set. Go through the menu list until PUMP is shown. When in this mode, use SELECT and the arrow buttons to change the pump limit. Push the DONE SET softkey to save the selection and go to the main menu. This limit can be set to 10 % above full scale.
Figure 16. Active Display Menu
hbb017.eps
Note
.
16
Portable Pressure Calibrator
Initial Setup and Basic Pressure Generation
Initial Setup and Basic Pressure Generation
The Product has a special low-volume calibration hose for faster pressure generation and quick pressure stabilization. "Quick-fit" hose connectors and different adapters are included. It is recommended that this hose is used to get the best results. After the fittings are installed and the Product is connected to the UUT (unit under test), the Product is ready for use.
To configure the Product for the appropriate application:
1. Set the pressure/vacuum selection knob to the necessary function (+ for pressure
and - for vacuum).
2. Close the vent knob.
3. Close the supply metering valve.
4. Push and hold and see the pressure rise (or vacuum generation) until you reach
the necessary pressure.
5. Release when the necessary pressure is reached.
Note
The motor speed starts slow while the pressure is low <15 psi (1 bar) for better control at low pressures.
6. The fine pressure adjustment lets you set the correct pressure.
7. To decrease or bleed off all pressure, slowly turn the vent knob counter clockwise to
the open position. When the valve is slowly opened, there is a slow decrease of pressure. Open the valve more to vent the pressure.
Pressure Measurement
To measure pressure:
1. Connect the Product with the correct adapter.
2. Select the pressure parameter for the display used.
3. The Product has an internal sensor and optional external sensors are available. Select
a sensor that is correct for the pressure range and accuracy.
To prevent injury, only assemble and operate high-pressure systems if you know the correct safety procedures. High­pressure liquids and gases are hazardous and the energy from them can be released without warning.
For a better understanding with respect to overpressure and burst pressure, follow the specifications and these operation instructions. See the “Specifications” section. The Product display will show "OL" when an inappropriate pressure is applied. When "OL" is shown on a pressure display, immediately decrease the pressure to prevent damage or possible physical injury. "OL" is shown if the pressure exceeds the nominal range by 110 %. Push to zero the pressure sensor after it is vented to atmospheric pressure.
Warning
17
3130
Users Manual
Media Compatibility
The Product is only to be used with clean, dry gases.
External Modules
The Product has a digital interface to support the Fluke 700P series of pressure modules. These modules are available for different ranges that include gauge, vacuum, differential, and absolute pressure. The modules work in conjunction with the Product. Connect them to the interface and select [EXT] (external sensor). Since the interface between the Product and the module is digital, the accuracy and display resolution depends on the module. See Figure 17.
Valve
Pressure
Module
EXTERNAL
PRESSURE MODULE
PORTABLE PRESSURE CALIBRATOR
3130
F1 F2 F3
HOME
ZERO PUMP
CLOSE VALVE BEFORE OPERATING PUMP
FILTER
SUPPLY
METERING VALVE
VENT
VENT
FINE
ADJUSTMENT
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
PRESSURE
SENSOR
PRESSURE
VACUUM
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
CLOSED
ISOLATION
VALVE
Figure 17. Pressure Module
Measure and Source Current (4… 20 mA)
To measure and source current:
1. To measure current, use the input terminals on the front of the Product. Select the mA
function on the lower display. Current is measured in mA and a percentage of the measuring range. The measuring range on the Product is set to 0 % at 4 mA and 100 % at 20 mA. See Figure 18 for connections.
Example:
If the current measured is shown as 75 %, then the value is 16 mA.
Note
The display shows "OL" when the measured current exceeds the nominal range of current measurement (24 mA).
V mA
SWITCH TEST
30 V MAX
LOOP
COM
24 V DC
CHARGE
16 V DC
5.6 A
SERIAL NO.
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
hbb007.eps
18
Portable Pressure Calibrator
Pressure Measurement
2. The same connections are used for the current source. Select mA-Source or mA
Sim-2W from the configuration display.
3. This selection can only be made in the lower display. Also, in source mode, the
Product generates 0... 24 mA that uses its own internal 24 V supply, whereas in simulation mode the Product acts as a 2-wire transmitter and an external 24 V supply is necessary.
4. Push the arrow key to start the output mode and then use the arrow keys to adjust the
mA output. The function keys can also be used to control the output in 25 % steps (4, 8, 12, 16, 20 mA) or 0 % (4 mA) and 100 % (20 mA). See Figure 18.
5. While in the mA output mode, if the loop is broken or the resistance burden is
exceeded, the Product will flash "OL".
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
24 V DC
30 V MAX
4...20 mA
UUT
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
24 V DC
24 V DC
24 V DC
–
4...20 mA
4...20 mA
UUT
DC 24 V
4...20 mA
UUT
Powe r
+
Supply
+
–
UUT
Figure 18. Measure and Sourcing Current
hbb018.eps
19
3130
Users Manual
Measure Voltage
To measure voltage, use the connections on the front of the Product. Select the VOLTS function on one of the displays. The Product can measure to a maximum of 30 V dc. See Figure 19.
The display shows "OL" when the measured voltage is larger than the nominal range of voltage measurement (30 V).
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
Note
24 V DC
30 V dc Maximum
Test Item
Figure 19. Measure Voltage
hbb019.eps
20
Portable Pressure Calibrator
Pressure Measurement
Pressure Switch Test
To do a pressure switch test:
1. Set the upper display to [P1] ST, all other displays are switched off.
Note
The pressure switch test can be done with these functions: [P1] ST or EXT ST.
2. Connect the Product to the pressure switch with the switch terminals. The polarity of
the terminals is not important. See Figure 20.
Fully Closed
PORTABLE PRESSURE CALIBRATOR
EXTERNAL
PRESSURE MODULE
3130
F1 F2 F3
HOME
ZERO PUMP
CLOSE VALVE BEFORE OPERATING PUMP
METERING VALVE
VENT
FINE
ADJUSTMENT
FILTER
SUPPLY
VENT
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
PRESSURE
SENSOR
PRESSURE
VACUUM
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
CLOSED
ISOLATION
VALVE
Use low volume
hose if possible
LOOP
V mA
SWITCH TEST
COM
24 V DC
30 V MAX
CHARGE
16 V DC
5.6 A
SERIAL NO.
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
Figure 20. Switch Test Connections
3. Connect the Output of the Product to the pressure switch.
4. Open the vent button on the pump and zero the Product.
5. Close the vent after you reset the Product.
The top of the display shows "CLOSE". See Figure 22.
Pressure Switch
hbb020.eps
Figure 21. Switch Test Screen
hbb021.eps
21
3130
Users Manual
6. Apply pressure with the pump slowly until the switch opens.
Note
In the switch test mode, the display-update rate is increased to help capture changes to pressure inputs. Even with this enhanced sample rate, the UUT should be charged slowly with pressure to ensure accurate readings.
7. After the switch is open, "OPEN" will be shown. Bleed the pump slowly until the
pressure switch closes. See Figure 22.
Figure 22. Switch Test Screen (Open)
hbb022.eps
8. The top display now shows "SW OPENED AT" and gives you the pressure at which
the switch opened. See Figure 23.
Figure 23. Opened Switch Reading
hbb023.eps
22
Portable Pressure Calibrator
Pressure Measurement
9. Select the "NEXT" option to show the pressure at which the switch closed and the
deadband. See Figure 24.
Figure 24. Switch Test and Deadband Results
hbb024.eps
10. Select the "NEW TEST" option to clear the data and do another test.
11. Select the "DONE" option to complete the test and go to the standard pressure
setting.
Example:
[P1] ST will return to [P1].
This example uses a normally closed switch. The basic procedure is effectively the same for a normally open switch. The display reads "OPEN" instead of "CLOSE".
Calibrate Transmitters
Use the mA Measurement Function
The mA function lets you read the 4... 20 mA output from the UUT. This can be done in two ways:
1. Passively – the UUT generates 4... 20 mA directly. This can be read on the Product.
2. Actively – the Product supplies a loop power of 24 V dc to the UUT to power the
device while it reads the 4... 20 mA signal. See Figure 25.
Passive Active
Figure 25. Passive and Active Screens
hbb025.eps
23
3130
+
–
Users Manual
Calibrate a Pressure-to-Current Transmitter
To calibrate a pressure-to-current transmitter (P/I):
1. Connect the Product pump to the transmitter.
2. Apply pressure from the pump.
3. Measure the current output of the transmitter.
4. Make sure that the read value is correct. If it is not correct, the transmitter must be
adjusted. See Figure 26.
EXTERNAL
PRESSURE MODULE
3130
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
PORTABLE PRESSURE CALIBRATOR
24 V DC
Fully Closed
CLOSE VALVE BEFORE OPERATING PUMP
CHARGE
16 V DC
5.6 A
FILTER
SUPPLY
METERING VALVE
VENT
VENT
FINE
ADJUSTMENT
Close silver vent knob
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
-12 PSI TO 300 PSI
PRESSURE
SENSOR
PRESSURE
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
OUTPUT
(-8 kPa TO 2 MPa)
VACUUM
SERIAL NO.
CLOSED
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
Figure 26. Calibrate a Pressure-to-Current Transmitter
Use low volume
hose if possible
hbb026.eps
24
Portable Pressure Calibrator
Pressure Measurement
Calibrate a Pressure-to-Voltage Transmitter
To calibrate a pressure-to-voltage transmitter (P/V):
1. Connect the Product pump to the transmitter.
2. Apply pressure from the pump.
3. Connect the 24 V to the transmitter.
4. Measure the voltage output of the transmitter.
5. Make sure that the read value is correct. If it is not correct, the transmitter must be
adjusted. See Figure 27 for connections.
PORTABLE PRESSURE CALIBRATOR
EXTERNAL
PRESSURE MODULE
3130
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
24 V DC
CLOSE VALVE BEFORE OPERATING PUMP
CHARGE
16 V DC
5.6 A
METERING VALVE
VENT
ADJUSTMENT
FILTER
SUPPLY
VENT
FINE
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
PRESSURE
SENSOR
PRESSURE
VACUUM
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
SERIAL NO.
CLOSED
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
Pressure Transmitter
+24 V Power
Common
Signal Output
hbb035.eps
Figure 27. Calibrate a Pressure-to-Voltage Transmitter
25
3130
+
–
Users Manual
%-Error Function
The Product has a special function which can calculate the error in the pressure value from the mA value as a percentage of the 4 ... 20 mA loop span. The %-Error mode uses all three screens and has a special menu structure. It shows pressure, mA and %-Error simultaneously. See Figure 28.
EXTERNAL
PRESSURE MODULE
Close silver vent knob
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
-12 PSI TO 300 PSI
PRESSURE
SENSOR
PRESSURE
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
OUTPUT
(-8 kPa TO 2 MPa)
VACUUM
SERIAL NO.
CLOSED
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
Use low volume
hose if possible
3130
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
PORTABLE PRESSURE CALIBRATOR
24 V DC
Fully Closed
CLOSE VALVE BEFORE OPERATING PUMP
CHARGE
16 V DC
5.6 A
FILTER
SUPPLY
METERING VALVE
VENT
VENT
FINE
ADJUSTMENT
Figure 28. Connections with a Pressure Transmitter with % Error Function
Example:
hbb027.eps
If a pressure transmitter under test has a full-scale range of 2 bar and gives a 4 ... 20 mA output signal, you can program in a 0 ... 2 bar pressure span into the Product. The Product will then calculate and show the deviation or %-Error value from the 4 ... 20 mA output. This makes manual calculations unnecessary.
To use the "%-ERROR" function:
1. Once the Product is turned on, push to start the "MORE" menu option. Then Push to start the "%-ERROR" option.
2. Push to select the "CONFIG" option.
26
Portable Pressure Calibrator
Pressure Measurement
3. The first option is the port setting. Use the "SELECT" option to scroll through the choice of ports (pressure connections). When this is done, select the "NEXT" option. See Figure 29.
Figure 29. Port Setting Screen
hbb028.eps
4. "LOOP POWER" can be toggled on or off. Select "NEXT" when done. See Figure 30.
Figure 30. Loop Power Screen
hbb029.eps
5. Use "SELECT" to scroll through the "UNIT" options, and select "NEXT" to move on. See Figure 31.
Figure 31. Set Unit Screen
hbb030.eps
27
3130
Users Manual
6. Use the arrow keys to set the upper limit of the measurement range. Select DONE SET when finished. See Figure 32.
Figure 32. Setting the Upper Limit
hbb031.eps
7. Use the arrow keys to set lower limit of the measurement range, and select DONE SET when finished. The "%-ERROR" mode will be ready to use. See Figure 33.
Figure 33. % ERROR Screen
hbb032.eps
The lower and upper limit of the measuring range is saved in non-volatile memory until they are changed by the user for the internal sensors and the external pressure modules. See Figure 34.
28
Figure 34. Saved Upper and Lower Limits
hbb033.eps
Portable Pressure Calibrator
Storage Capability
Storage Capability
The Product has a min/max feature to capture the minimum and maximum values of a shown parameter.
The min/max function can be accessed by going through the menu options until the MINMAX menu choice is shown. Push the MINMAX softkey to see the min/max values that are stored in the min/max registers. These readings are live so that the new min/max values are recorded while in this mode.
To reset the min/max registers, push the CLEAR softkey. These registers are also cleared at power-up or when the configuration is changed.
Remote Operation
The Product can be remotely controlled with a PC terminal, or by a computer program that runs the Product in an automated system. An RS-232 serial port connection is used for remote operation.
Note
To use the remote control option, a custom RS-232 cable must be purchased. See the “How to Contact Fluke Calibration” section.
With this connection, you can write programs on the PC. Use Windows languages like Visual Basic to operate the Product, or use a Windows terminal like Hyper Terminal, for single commands. A typical RS-232 remote configuration is shown in Figure 35.
PORTABLE PRESSURE CALIBRATOR
EXTERNAL
PRESSURE MODULE
3130
F1 F2 F3
HOME
ZERO PUMP
LOOP
V mA
SWITCH TEST
COM
30 V MAX
24 V DC
CLOSE VALVE BEFORE OPERATING PUMP
CHARGE
16 V DC
5.6 A
VENT
FILTER
SUPPLY
METERING VALVE
VENT
FINE
ADJUSTMENT
FINE
ADJUSTMENT
AIR SUPPLY
330 PSI MAX
(2.3 MPa)
OUTPUT
-12 PSI TO 300 PSI (-8 kPa TO 2 MPa)
PRESSURE
SENSOR
PRESSURE
VACUUM
PUMP
CAUTION
VENT LINE BEFORE MAKING SELECTION
SERIAL NO.
CLOSED
ISOLATION
VALVE
FLUKE CORPORATION
EVERETT, WA USA www.flukecal.com
COM Port
Figure 35. Remote Operation
hbb034.eps
29
3130
Users Manual
Set Up the RS-232 Port for Remote Control
Note
The RS-232 connection cable must be less than 15 m unless the load capacitance measured at connection points is less than 2500 pF.
Serial parameter values:
1. 9600 baud
2. 8 data bits
3. 1 stop bit
4. no parity
5. Xon/Xoff
6. EOL (End of Line) character or CR (Carriage Return) or both
An RS-232 cable is used for RS-232 communications from the Product to a computer. If the computer only has USB ports, a USB to RS-232 converter will be necessary. To connect the Product to a computer, attach the LEMO connector end of the cable to the pressure module port on the right side of the Product. Then connect the DB-9 connector to the RS-232 port on the computer. The Product must be off before you make the connection.
To set up remote operation of the Product with Windows Hyper Terminal, connect the Product to a COM port on the PC. See Figure 35.
Do the subsequent procedure:
1. Start Hyper Terminal (located on your computer in Accessories/Communications of the Windows Start menu).
2. Select New Connection.
3. For Name enter “Fluke 3130”.
4. Select the serial port that the Product is connected to.
5. Enter the above information for port settings.
6. Select ASCII setup from File/Properties/Settings and mark these choices:
1. Echo typed characters locally
2. Wrap lines that exceed terminal width
7. Select Ok.
8. To see if the port functions, enter *IDN?. This command shows information on the Product.
30
Portable Pressure Calibrator
Remote Operation
Change from Remote to Local Operation
The Product uses three modes of operation:
• Local
• Remote
• Remote with Lockout
Local mode is the default mode. Commands can be entered with the buttons on the Product or with a computer. In Remote mode, the buttons are disabled and commands can only be entered with a computer. Select [GO TO LOCAL] from the menu on the Product display to restore button operation. In Remote with Lockout mode, the buttons cannot be used.
To switch modes:
1. To start Remote mode, enter the serial command “REMOTE” at the computer terminal.
2. To start Remote with Lockout mode, enter “REMOTE LOCKOUT” in either order.
3. To go back to Local Operation mode, enter “LOCAL” at the terminal. This command also turns off LOCKOUT if it is on. For more information on commands, see the “Remote Commands” section.
Command Use
The Product can be controlled by commands and queries. All commands can be entered with upper or lower case. See the Remote Commands section for all available commands.
The commands are divided into these categories:
Calibrator Commands
Only the Product uses these commands.
For example:
VAL?
This command requests the values shown on the Product display.
Common Commands
Standard commands used by most devices. These commands always start with an “*”.
For example:
*IDN?
This command tells the Product to show its identification.
Query Commands
Commands that request information and always end with a “?”.
For example:
FUNC?
This command shows the current modes of the Product displays.
31
3130
Users Manual
Compound Commands
Commands that have more than one command on one line.
For example:
PRES_UNIT LOWER, PSI;PRES_UNIT?
This command sets the pressure unit to PSI on the lower display and queries the Product to verify. In this case, it will show the pressure units of all three displays:
BAR,BAR,PSI
Character Processing
The data entered into the Product is processed as follows:
• ASCII characters are discarded if their decimal equivalent is less than 32 (space), except 10 (LF) and 13 (CR):
• Data is taken as 7-bit ASCII.
• The most significant data bit is ignored.
• Upper or lower case is acceptable.
Response Data Types
The data shown by the Product can be divided into these types:
Integer
For most computers and controllers they are decimal numbers ranging from -32768 to 32768.
For example:
FAULT?
Could show 110
Refer to the Error Codes table (Table 8) for more information on error codes.
Floating
Floating numbers can have a maximum of 15 significant figures and exponents.
For example:
VAL?
Shows 5.830000E01,PSI,0.000000E00,PSI,0.000000E+00,A
Character Response Data (CRD)
Data shown as keywords.
For example:
PRES_UNIT?
Shows BAR,BAR,PSI
32
Indefinite ASCII (IAD)
Any ASCII characters followed by a terminator. For example:
*IDN?
Shows Fluke, 3130, 1234567, 1.00 (1234567 is the serial number)
Portable Pressure Calibrator
Remote Operation
Calibrator Status
Error Queue
If an error occurs from invalid input or buffer overflow, its error code is sent to the error queue. The error code can be read from the queue with the command FAULT?. The error queue holds 15 error codes. When it is empty, FAULT? shows 0. The error queue is cleared when power is reset or when the clear command *CLS is entered.
Input Buffer
The calibrator stores all received data in the input buffer. The buffer holds 250 characters and they are processed on a first in, first out basis.
Remote Commands and Error Codes
This section shows and describes all of the remote commands that are accepted by the Product.
Table 3. Common Commands
Command Description
*CLS (Clear status.) Clears the error queue.
*IDN? Identification query. Shows the manufacturer,
model number, and firmware revision level of the Product.
*RST Resets the Product to the power up state.
33
3130
Users Manual
Table 4. Product Commands
Command Description
DAMP Turns on or off Damp
DAMP? Show if DAMP is on/off
DISPLAY Turns on or off the displays specified in the command
DISPLAY? Shows which displays are on/off
ERROR_LOOP Turns on or off loop power in percent error mode
ERROR_LOOP? Shows the current state of loop power in error mode
ERROR_MODE Turns on or off percent error mode
ERROR_MODE? Shows if percent error mode is on or off
ERROR_PORT Set the pressure port for percent error mode
ERROR_PORT? Shows the pressure port for percent error mode
FAULT? Shows the most recent error code
FUNC Sets the display mode as specified in the command
FUNC? Shows the current mode of the upper, middle, and lower display
HART_ON Turns on the HART resistor
HART_OFF Turns off the HART resistor
HART? Shows the current state of the HART resistor.
HI_ERR Sets the 100 % of span limit for percent error mode
HI_ERR? Shows the 100 % of span limit for percent error mode
IO_STATE Set the Product mA state
IO_STATE? Shows the Product mA state
LOCAL Shows user to manual operation of the Product
LOCKOUT Locks out the keypad of the Product in remote operation
LO_ERR Sets the 0 % of span limit for percent error mode
LO_ERR Shows the 0 % of span limit for percent error mode
MOTOR_ON Turns on the motor
MOTOR_OFF Turns off the motor
MOTOR? Shows the current state of the HART resistor
34
OUT Set the Product to output the requested current
OUT? Shows the value of the current being simulated
Portable Pressure Calibrator
Remote Operation
Table 4. Product Commands (cont.)
Command Description
PRES_UNIT Set the pressure unit for the indicated display
PRES_UNIT? Shows the pressure from the indicated display
PUMP_LIMIT Sets the approximate value at which the pump will turn off
PUMP_LIMIT? Shows the approximate value at which the pump will turn off
REMOTE Puts the Product in remote mode
SIM Set the Product to simulate the requested current
SIM? Shows the value of the current being simulated
ST_CLOSE? Shows pressure value at which the switch closed
ST_DEAD? Shows pressure value of the deadband of the switch
ST_OPEN? Shows pressure value at which the switch opened
ST_START Starts a switch test
VAL? Shows the measured values
ZERO_MEAS Zeros the pressure module
ZERO_MEAS? Shows the zero offset of the pressure module
Table 5. Parameter Units
Units Meaning
DCI Current function
DCV Voltage measure function
EXT External pressure measurement function
LOWER Designates Lower display
MA Milliamps of current
MEASURE Measure state
MEAS_LOOP Measure with loop power state
MIDDLE Designates Middle display
PCT_ERR Percent Error
PERCENT Percent
P1 P1 pressure measurement function
ST_P1 Switch test mode with P1
ST_EXT Switch test mode with external module
SOURCE Source state
SIM Simulate state
UPPER Designates Upper display
V Voltage
35
3130
Users Manual
Table 6. Error Codes
Error Number Error Description
100 A non-numeric entry was received where it should be a numeric entry
101 Too many digits entered
102 Invalid units or parameter value received
103 Entry is above the upper limit of the allowable range
104 Entry is below the lower limit of the allowable range
105 A required command parameter was missing
106 An invalid command parameter was received
107 Pressure not selected
108 Invalid sensor type
109 Pressure module not connected
110 An unknown command was received
111 Bad Parameter received
112 The serial input buffer overflowed
113 Too many entries in the command line
114 The serial output buffer overflowed
Enter Commands
Commands for the Product can be entered in upper or lower case. There is a minimum of one space necessary between the command and parameter. All other spaces are optional. Most of the commands for the Product are sequential. Any overlapped commands will be shown as such. This section describes each of the commands and their general use, which will include any parameters that can be entered with the command as well as what the output of the command is.
Common Commands
*CLS
Clears the error queue. Also ends all pending operations. When you write programs, use this command before each procedure to prevent buffer overflow.
*IDN?
Shows the manufacturer, model number, and firmware revision of the Product.
For example:
*IDN?
Shows Fluke, 3130 0, 1.00
36
Portable Pressure Calibrator
Remote Operation
Calibrator Commands
DAMP
Turns on or off the dampening function.
For example:
If you send DAMP ON, this will turn the dampening function on.
DAMP?
Shows the current state of the dampening function.
For example:
If you send DAMP?, this will show ON if the dampening function is on.
DISPLAY
Turns on or off the indicated display.
For example:
If you send DISPLAY LOWER, ON, this will turn on the lower display.
DISPLAY?
Shows the current state of the each of the displays.
For example:
If you send DISPLAY?, it will show ON, ON, ON if the all the displays are on.
FAULT?
Shows the error code number of an error that has occurred. The command can be entered if the previous command did not do what it was meant to do.
For example, if a value for current output is entered that is larger than the supported range (0-24 mA), FAULT? shows:
103 which is the code number for an entry over range.
Refer to Table 6 for more information about error code numbers.
ERROR _LOOP
Turns on or off loop power in percent error mode.
For example:
To set loop power on, send ERROR_LOOP ON.
37
3130
Users Manual
ERROR _LOOP?
Shows the current state of loop power in percent error mode.
For example:
If you send ERROR_LOOP?, it will show ON if loop power is on in error mode.
ERROR_ MODE
Turns on or off percent error mode.
For example:
To turn on percent error mode, send ERROR_MODE ON.
ERROR _ MODE?
Shows the current state of percent error mode.
For example:
If you send ERROR_MODE?, it will show ON if the Product is in percent error mode.
ERROR_ PORT
Sets the pressure port for percent error.
For example:
To set the pressure port for percent error to [P1] send ERROR_ PORT P1.
ERROR _ PORT?
Shows the current pressure port for percent error mode.
For example:
If you send ERROR _PORT?, it will show P1 if the pressure port in percent error is [P1].
FUNC
Sets the display indicated in argument 1 to the function indicated in argument 2.
For example:
To set the lower display to pressure mode, send FUNC LOWER,[P1].
FUNC?
38
Shows the current mode of all displays. For example if the Product is set to [P2] ST on the upper display, [P1] on the middle, and [P1] on the lower, FUNC? shows:
ST_P2,P1,[P1]
Portable Pressure Calibrator
Remote Operation
HART_ON
Turns on the Hart resistor.
HART_OFF
Turns off the Hart resistor.
HART?
Shows the state of the Hart resistor.
For example:
If the Hart resistor was on, HART? shows ON.
HI_ERR
Sets the 100 % point for the percent error mode calculation in the current engineering units.
For example:
To set the 100 % point to 100 psi, send HI_ERR 100.
HI_ERR?
Shows the 100 % point for the percent error mode calculation.
For example:
If the 100 % point is set to 100 psi, HI_ERR? shows 1.000000E+02, PSI .
IO_STATE
Sets the input/output/simulate state of the mA function of the Product. This does not put the Product into mA if it is not in it already.
For example:
If the Product is in mA simulate modem sending IO_STATE MEASURE would put it into measure mode.
IO_STATE?
Shows the input/output/simulate state of the mA function of the Product.
For example:
If the Product was in mA simulate mode, IO_STATE? shows SIM.
39
3130
Users Manual
LOCAL
Returns the Product to local operation if it was in remote mode. The command also clears LOCKOUT if the Product was in lockout mode.
LOCKOUT
Sending this command sets the lockout state, when the unit is in REMOTE or goes to remote, it stops use of the keypad completely. The lockout state can only be cleared by sending the LOCAL command.
LO_ERR
Sets the 0 % point for the percent error mode calculation in the current engineering units.
For example:
To set the 0 % point to 20 psi, send LO_ERR 20.
LO_ERR?
Shows the 0 % point for the percent error mode calculation.
For example:
If the 0 % point is set to 20 psi, LO_ERR? shows 2.000000E+01, PSI .
MOTOR_ON
Turns on the motor.
MOTOR_OFF
Turns off the motor.
MOTOR?
Shows the state of the motor.
For example:
If the motor was on, MOTOR? shows ON.
40
Portable Pressure Calibrator
Remote Operation
OUT
This command also switches the Product into mA output mode. A number and a unit must be entered after the command.
For example:
OUT 5 MA sets the current output at 5 mA.
OUT?
Shows the output of the Product.
Using the above example, OUT? shows: 5.000000E-03, A.
PRES_UNIT
Used to set the pressure unit for the indicated display.
For example:
To set the pressure unit to psi on the lower display, send PRES_UNIT LOWER, PSI.
PRES_UNIT?
Shows the pressure unit used when measuring pressure for each of the three displays.
PUMP_LIMIT
Sets the approximate pressure in psi at which the pump will turn off.
For example:
PUMP_LIMIT 50 sets the approximate value that the pump will shut off at to 50 psi.
PUMP_LIMIT?
Shows the pump limit. Using the above example, PUMP_LIMIT? Shows:
50.000
REMOTE
Puts the Product into remote mode. From the remote mode the user can still use the keypad to get back to local mode unless the command LOCKOUT was entered before REMOTE. Then the keypad is completely locked out, and the user has to send the LOCAL command to go to local operation.
41
3130
Users Manual
SIM
Sets the output for current simulation. This command also switches the Product into mA simulation mode. A number and a unit must be entered after the command.
For example:
SIM 5 MA sets the current simulation at 5 mA
SIM?
Shows the output of the current simulation. With the example above, the output would be:
5.000000E-03, A
ST_START
Starts a switch test.
ST_CLOSE?
Shows the pressure that the switch closed at in the current pressure units.
ST_OPEN?
Shows the pressure that the switch opened at in the current pressure units.
ST_DEAD?
Shows deadband of the switch in the current pressure units.
VAL?
Shows the value of measurement on a maximum of three displays. For example, if the upper display shows pressure at 0.00 bar on P1, the middle display shows pressure at 0 psi on P1, and the lower display shows 0 mA, then VAL? will return:
0.000000E+00,BAR,0.000000E+00,PSI,0.000000E+00,A
ZERO_MEAS
Zeroes the attached pressure module. Enter the zeroing value in PSI after the command when zeroing an absolute pressure module.
ZERO_MEAS?
42
Shows the zero offset or the reference value for absolute pressure modules.
Portable Pressure Calibrator
Maintenance
Maintenance
Warning
For safe operation and maintenance of the Product:
• Use only Fluke approved power adapters to charge the
battery.
To prevent possible electrical shock, fire, or personal injury:
• Use only specified replacement parts.
• Have an approved technician repair the Product.
Clean the Product and pressure modules with a soft cloth dampened with water or water and mild soap.
Caution
To prevent possible damage to the Product, do not use solvents or abrasive cleansers.
User-Replaceable Parts and Accessories
Table 7 lists the Fluke part number of each user-replaceable part or accessory for the Product.
Table 7. Replaceable Parts
Item Description Fluke Part Number
Test cables (1x red, 1x black), 48 in, stackable 3971218
16 V 5.06 A ac adapter/charger 4312648
Filter Pack and end plates 4296874
43
3130
Users Manual
Specifications
Specifications are valid for one year unless otherwise noted.
Electrical Specification
Measurement Inputs Range Accuracy
mA 0 mA to 24.000 mA 0.015 % of reading ±0.002 mA
Volts 0 mA to 30.000 V dc 0.015 % of reading ±0.002 V
Outputs Range
mA 4 mA to 24.00 mA
Volts 24 V dc
[1] Available in mA or V measurement mode
Pressure
Pressure ............................................................ -12 to 300.00 psi
[1]
mA .................................................................... 0 to 24.000 mA
Volts ................................................................. 0 to 30.000 V dc
Engineering Units ............................................ psi, bar, mbar, kPa, MPa, kgcm
Accuracy
Pressure ........................................................... 1 year: 0.025 % of reading ±0.01 % FS
mA .................................................................... ±0.015 % of reading ±0.002 mA
Volts ................................................................ ±0.015 % of reading ±0.002 V
Temperature Effect (all functions) .................. No effect on accuracy on all functions
Add ±0.002 % F.S. /°C for temps outside
Loop Power
24 V .................................................................. 23 V to 28 V
Mechanical Specification
Size (H X W X L) ............................................. (387 x 305 x 178) mm, (15.3 x 12.0 x 7.0) in
@ 4 °C, mmH 4 °C, cmH
O @ 20 °C, inH2O @ 60 °F, mmHg
inH
2
O @ 20 °C, cmH
2
O @ 20 °C, inH2O @ 4 °C,
2
@ 0 °C, inHg @ 0 °C
from 15 °C to 35 °C
of 15 °C to 35 °C
2
, mmH2O
O @
2
44
Weight ............................................................ ~7.0 kg (15.5 lb)
Environmental
Operating Temperature ..................................... -10 °C to +50 °C (14 °F to 122 °F)
Storage ............................................................. -20 °C to +55 °C (-4 °F to +131 °F)
Humidity .......................................................... 10 % to 95 % RH Non-condensing
Altitude ............................................................. 2000 meters, limited by ac adapter
Portable Pressure Calibrator

Specifications

Media Compatibility ......................................... Any clean, dry, non-corrosive gas
Standards and Agency Approval
Safety ................................................................ IEC 61010-1, 30V Max, Pollution
Degree 2
Electromagnetic Environment .......................... IEC 61326-1: Basic/Portable
Ingress Protection ............................................. IP67 (Case closed), IP40 (Case open)
Vibration ........................................................... MIL-PRF-28800F (Class 3-Random)
Power
Power Requirements ......................................... 16 V dc (Universal AC Adapter/Charger
supplied) Internal 3800 mAhr advanced NiMH pack
Battery life (fully-charged) ............................... Approximately 50 hours (Only
measurement or with external pressure supply)
125 pump cycles to 20 bar
300 pump cycles to 10 bar
1,000 pump cycles to 2 bar
45
3130
Users Manual
46
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
