Page 1
5502A
Multi-Product Calibrator
September 2012
© 2012 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
Operators Manual
Page 2
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under
normal use and service. The warranty period is one year and begins on the date of shipment.
Parts, product repairs, and services are warranted for 90 days. This warranty extends only to the
original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses,
disposable batteries, or to any product which, in Fluke's opinion, has been misused, altered,
neglected, contaminated, or damaged by accident or abnormal conditions of operation or
handling. Fluke warrants that software will operate substantially in accordance with its functional
specifications for 90 days and that it has been properly recorded on non-defective media. Fluke
does not warrant that software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user
customers only but have no authority to extend a greater or different warranty on behalf of Fluke.
Warranty support is available only if product is purchased through a Fluke authorized sales outlet
or Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for
importation costs of repair/replacement parts when product purchased in one country is submitted
for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of
charge repair, or replacement of a defective product which is returned to a Fluke authorized
service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center to obtain return
authorization information, then send the product to that service center, with a description of the
difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk for damage in
transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid
(FOB Destination). If Fluke determines that failure was caused by neglect, misuse, contamination,
alteration, accident, or abnormal condition of operation or handling, including overvoltage failures
caused by use outside the product’s specified rating, or normal wear and tear of mechanical
components, Fluke will provide an estimate of repair costs and obtain authorization before
commencing the work. Following repair, the product will be returned to the Buyer transportation
prepaid and the Buyer will be billed for the repair and return transportation charges (FOB
Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM
ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or
exclusion or limitation of incidental or consequential damages, the limitations and exclusions of
this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or
unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not
affect the validity or enforceability of any other provision.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99
Page 3
OPERATOR SAFETY
SUMMARY
WARNING
HIGH VOLTAGE
is used in the operation of this equipment
LETHAL VOLTAGE
may be present on the terminals, observe all safety precautions!
To prevent electrical shock hazard, the operator should not electrically contact the
output HI or sense HI terminals or circuits connected to these terminals. During
operation, lethal voltages of up to 1020 V ac or dc may be present on these
terminals.
When the nature of the operation permits, keep one hand away from equipment to
reduce the hazard of current flowing through vital organs of the body.
Page 4
Page 5
Table of Contents
Chapter Title Page
1 Introduction and Specifications ......................................................... 1-1
Introduction ........................................................................................................ 1-3
Safety Information ............................................................................................. 1-4
Overload Protection ........................................................................................... 1-6
Operation Overview ........................................................................................... 1-6
Local Operation ............................................................................................. 1-6
Remote Operation (RS-232) .......................................................................... 1-6
Remote Operation (IEEE-488) ...................................................................... 1-7
Instruction Manuals ........................................................................................... 1-8
5502A Getting Started Manual ...................................................................... 1-8
5502A Operators Manual .............................................................................. 1-8
Contact Fluke Calibration .................................................................................. 1-8
Specifications ..................................................................................................... 1-9
General Specifications ....................................................................................... 1-9
Detailed Specifications ...................................................................................... 1-10
DC Voltage .................................................................................................... 1-10
DC Current .................................................................................................... 1-11
Resistance ...................................................................................................... 1-12
AC Voltage (Sine Wave) ............................................................................... 1-13
AC Voltage (Sine Wave) (cont.) ................................................................... 1-14
AC Current (Sine Wave) ............................................................................... 1-15
AC Current (Sine Wave) (cont.) .................................................................... 1-16
Capacitance.................................................................................................... 1-17
Temperature Calibration (Thermocouple) ..................................................... 1-18
Temperature Calibration (RTD) .................................................................... 1-19
Phase .............................................................................................................. 1-19
AC and DC Power Specifications ................................................................. 1-20
Specification Limits for Power and Dual Output Operation ......................... 1-20
Calculate the Uncertainty Specifications of Power and Dual Output
Settings ....................................................................................................... 1-21
Examples of Specified Power Uncertainties at Various Output Settings: ..... 1-22
Calculate Power Uncertainty ......................................................................... 1-22
Additional Specifications ................................................................................... 1-23
Frequency ...................................................................................................... 1-23
v
Page 6
5502A
Operators Manual
Harmonics (2nd to 50th) .................................................................................. 1-23
AC Voltage (Sine Wave) Extended Bandwidth ............................................ 1-24
AC Voltage (Non-Sine Wave) ....................................................................... 1-24
AC Voltage (Non-Sine Wave) (cont.) ........................................................... 1-25
AC Voltage, DC Offset ................................................................................. 1-26
AC Voltage, Square Wave Characteristics .................................................... 1-26
AC Voltage, Triangle Wave Characteristics (typical) ................................... 1-26
AC Current (Non-Sine Wave) ....................................................................... 1-27
AC Current (Non-Sine Wave) (cont.) ............................................................ 1-27
AC Current, Square Wave Characteristics (typical) ...................................... 1-28
AC Current, Triangle Wave Characteristics (typical) ................................... 1-28
2 Prepare for Operation ......................................................................... 2-1
Introduction ........................................................................................................ 2-3
Unpack and Inspection ....................................................................................... 2-3
Select Line Voltage ............................................................................................ 2-4
Connect to Line Power ...................................................................................... 2-4
Select Line Frequency ....................................................................................... 2-5
Placement ........................................................................................................... 2-6
Airflow Considerations ...................................................................................... 2-7
3 Features ............................................................................................... 3-1
Introduction ........................................................................................................ 3-3
Front-Panel Features .......................................................................................... 3-3
Rear-Panel Features ........................................................................................... 3-3
Softkey Menu Trees ........................................................................................... 3-3
4 Front-Panel Operation ........................................................................ 4-1
Introduction ........................................................................................................ 4-3
Turn on the Calibrator ........................................................................................ 4-3
Warm up the Calibrator ..................................................................................... 4-4
Use the Softkeys ................................................................................................ 4-4
Use the Setup Menu ........................................................................................... 4-4
Use the Instrument Setup Menu .................................................................... 4-5
Utility Functions Menu .................................................................................. 4-6
Use the NV Memory Menu ........................................................................... 4-6
Reset the Calibrator ........................................................................................... 4-7
Zero the Calibrator ............................................................................................. 4-7
Operate and Standby Modes .............................................................................. 4-8
Connect the Calibrator to a UUT ....................................................................... 4-9
Recommended Cable and Connector Types .................................................. 4-9
When to Use EARTH .................................................................................... 4-10
Four-Wire versus Two-Wire Connections .................................................... 4-11
Four-Wire Connection .............................................................................. 4-11
Two-Wire Compensation .......................................................................... 4-11
Compensation Off ..................................................................................... 4-11
Cable Connections Instructions ..................................................................... 4-12
RMS Versus p-p Amplitude............................................................................... 4-17
Auto Range Versus Locked Range .................................................................... 4-18
Set Output .......................................................................................................... 4-18
Set DC Voltage Output .................................................................................. 4-19
Set AC Voltage Output .................................................................................. 4-20
Set DC Current Output .................................................................................. 4-23
Set AC Current Output .................................................................................. 4-24
vi
Page 7
Contents (continued)
Set DC Power Output .................................................................................... 4-25
Set AC Power Output .................................................................................... 4-27
Set a Dual DC Voltage Output ...................................................................... 4-30
Set a Dual AC Voltage Output ...................................................................... 4-31
Set Resistance Output .................................................................................... 4-34
Set Capacitance Output ................................................................................. 4-35
Set Temperature Simulation (Thermocouple) ............................................... 4-37
Set Temperature Simulation (RTD) .............................................................. 4-39
Measure Thermocouple Temperatures .......................................................... 4-41
Waveform Types ................................................................................................ 4-44
Sine Wave ...................................................................................................... 4-44
Triangle Waves .............................................................................................. 4-44
Square Wave .................................................................................................. 4-45
Truncated Sine Wave .................................................................................... 4-45
Set Harmonics .................................................................................................... 4-46
Adjust the Phase ................................................................................................. 4-47
Record a Phase Angle .................................................................................... 4-49
Record a Power Factor .................................................................................. 4-49
Record a DC Offset ............................................................................................ 4-50
Edit and Error Output Settings ........................................................................... 4-51
Edit the Output Setting .................................................................................. 4-51
Show the UUT Error ..................................................................................... 4-52
Use Multiply and Divide ............................................................................... 4-53
Set Output Limits ............................................................................................... 4-53
Sample Applications .......................................................................................... 4-54
How Calibrate an 80 Series Digital Multimeter ............................................ 4-55
Cables ........................................................................................................ 4-55
EARTH Connection .................................................................................. 4-55
Verify the Meter ........................................................................................ 4-55
Calibrate the Meter .................................................................................... 4-61
Verify a Model 41 Power Harmonics Analyzer ............................................ 4-61
Verify Watts, VA, VAR Performance ...................................................... 4-61
Verify Harmonics Volts Performance ....................................................... 4-63
Verify Harmonics Amps Performance ...................................................... 4-64
Calibrate a Fluke 51 Thermometer ................................................................ 4-65
Verify the Thermometer ............................................................................ 4-65
Calibrate the Thermometer ....................................................................... 4-66
5 Remote Operation ............................................................................... 5-1
Introduction ........................................................................................................ 5-3
Set up the IEEE-488 Port for Remote Control ................................................... 5-5
IEEE-488 Port Setup Procedure .................................................................... 5-7
Verify the IEEE-488 Port .............................................................................. 5-8
Set up the RS-232 Host Port for Remote Control .............................................. 5-9
RS-232 Host Port Setup Procedure ............................................................... 5-9
Verify the RS-232 Host Port ......................................................................... 5-12
Verify RS-232 Host Port Operation with a Terminal ................................ 5-12
Verify RS-232 Host Port Operation with Visual Basic ............................. 5-14
Set up the RS-232 UUT Port for Remote Control ............................................. 5-16
RS-232 UUT Port Setup Procedure ............................................................... 5-16
Verify the RS-232 UUT Port with RS-232 Host Port ................................... 5-17
Test RS-232 UUT Port Operation with a Terminal .................................. 5-18
Verify RS-232 UUT Port Operation with Visual Basic ............................ 5-19
Verify the RS-232 UUT Port with IEEE-488 Port ........................................ 5-19
Change between Remote and Local Operation .................................................. 5-21
vii
Page 8
5502A
Operators Manual
Local State ..................................................................................................... 5-21
Local with Lockout State ............................................................................... 5-21
Remote Condition .......................................................................................... 5-22
Remote with Lockout Condition ................................................................... 5-22
RS-232 Interface Overview ............................................................................... 5-23
IEEE-488 Interface Overview ............................................................................ 5-24
Use Commands .................................................................................................. 5-27
Types of Commands ...................................................................................... 5-27
Device-Dependent Commands .................................................................. 5-27
Common Commands ................................................................................. 5-27
Query Commands ...................................................................................... 5-28
Interface Messages (IEEE-488) ................................................................ 5-28
Compound Commands .................................................................................. 5-30
Coupled Commands .................................................................................. 5-30
Overlapped Commands ............................................................................. 5-30
Sequential Commands ............................................................................... 5-31
Commands where a Calibration Switch is Necessary ............................... 5-31
Commands for RS-232 Only ..................................................................... 5-32
Commands for IEEE-488 Only ................................................................. 5-33
Command Syntax .......................................................................................... 5-33
Parameter Syntax Rules ............................................................................ 5-33
Extra Space or Tab Characters .................................................................. 5-34
Terminators ............................................................................................... 5-35
Incoming Character Processing ................................................................. 5-35
Response Message Syntax ........................................................................ 5-36
Check 5502A Status ........................................................................................... 5-37
Serial Poll Status Byte (STB) ........................................................................ 5-38
Service Request (SRQ) Line ..................................................................... 5-40
Service Request Enable Register (SRE) .................................................... 5-40
Programming the STB and SRE................................................................ 5-41
Event Status Register (ESR) .......................................................................... 5-41
Event Status Enable (ESE) Register .......................................................... 5-41
Bit Assignments for the ESR and ESE ...................................................... 5-41
Program the ESR and ESE ........................................................................ 5-42
Instrument Status Register (ISR) ................................................................... 5-43
Instrument Status Change Registers .......................................................... 5-43
Instrument Status Change Enable Registers .............................................. 5-43
Bit Assignments for the ISR, ISCR, and ISCE ......................................... 5-43
Program the ISR, ISCR, and ISCE ............................................................ 5-45
Output Queue ................................................................................................. 5-45
Error Queue ................................................................................................... 5-45
Remote Program Examples................................................................................ 5-46
Guidelines to Program the Calibrator ............................................................ 5-46
Write an SRQ and Error Handler .................................................................. 5-47
Verify a Meter on the IEEE-488 Bus ............................................................ 5-48
Verify a Meter on the RS-232 UUT Serial Port ............................................ 5-48
Use *OPC?, *OPC, and *WAI ...................................................................... 5-48
Get a Thermocouple Measurement ................................................................ 5-49
Use the RS-232 UUT Port to Control an Instrument ..................................... 5-49
Input Buffer Operation .................................................................................. 5-50
viii
Page 9
Contents (continued)
6 Remote Commands ............................................................................. 6-1
Introduction ........................................................................................................ 6-3
Command Summary by Function ...................................................................... 6-3
Commands ......................................................................................................... 6-10
7 Maintenance ......................................................................................... 7-1
Introduction ........................................................................................................ 7-3
Replace the Mains Power Fuse .......................................................................... 7-3
Replace the Line Fuse ........................................................................................ 7-4
Replace the Current Fuses ................................................................................. 7-6
Clean the Air Filter ............................................................................................ 7-7
Clean the Calibrator ........................................................................................... 7-8
Performance Tests .............................................................................................. 7-8
8 Accessories ......................................................................................... 8-1
Introduction ........................................................................................................ 8-3
Rack Mount Kit ................................................................................................. 8-4
IEEE-488 Interface Cable .................................................................................. 8-4
5500A/LEADS ................................................................................................... 8-4
9 SC600 Oscilloscope Calibration Option ............................................ 9-1
Introduction ........................................................................................................ 9-3
SC600 Oscilloscope Calibration Option Specifications .................................... 9-4
Voltage Function Specifications .................................................................... 9-4
Edge Specifications ....................................................................................... 9-4
Leveled Sine Wave Specifications ................................................................ 9-5
Time Marker Specifications .......................................................................... 9-5
Wave Generator Specifications ..................................................................... 9-5
Pulse Generator Specifications ...................................................................... 9-6
Trigger Signal Specifications (Pulse Function) ............................................. 9-6
Trigger Signal Specifications (Time Marker Function) ................................ 9-6
Trigger Signal Specifications (Edge Function) ............................................. 9-6
Trigger Signal Specifications (Square Wave Voltage Function)................... 9-6
Trigger Signal Specifications ........................................................................ 9-6
Oscilloscope Input Resistance Measurement Specifications ......................... 9-6
Oscilloscope Input Capacitance Measurement Specifications ...................... 9-6
Overload Measurement Specifications .......................................................... 9-7
Oscilloscope Connections .................................................................................. 9-7
Start the SC600 Option ...................................................................................... 9-7
The Output Signal .......................................................................................... 9-8
Adjust the Output Signal ............................................................................... 9-8
Key in a Value ........................................................................................... 9-9
Adjust Values with the Rotary Knob ........................................................ 9-9
Use
and
.................................................................................... 9-10
Reset the Oscilloscope Option ....................................................................... 9-10
Calibrate the Voltage Amplitude on an Oscilloscope ........................................ 9-10
The Volt Function .......................................................................................... 9-10
The V/DIV Menu .......................................................................................... 9-12
Shortcuts to Set the Voltage Amplitude ........................................................ 9-12
Amplitude Calibration Procedure for an Oscilloscope .................................. 9-13
Calibrate the Pulse and Frequency Response on an Oscilloscope ..................... 9-14
The Edge Function ........................................................................................ 9-14
ix
Page 10
5502A
Operators Manual
Pulse Response Calibration Procedure for an Oscilloscope .......................... 9-15
Pulse Response Calibration with a Tunnel Diode Pulser .............................. 9-16
The Leveled Sine Wave Function ................................................................. 9-16
Shortcuts to Set the Frequency and Voltage .................................................. 9-17
The MORE OPTIONS Menu ........................................................................ 9-18
Sweep Through a Frequency Range .............................................................. 9-19
Frequency Response Calibration Procedure for an Oscilloscope .................. 9-19
Calibrate the Time Base of an Oscilloscope ...................................................... 9-21
The Time Marker Function ........................................................................... 9-21
Time Base Marker Calibration Procedure for an Oscilloscope ..................... 9-22
Test the Trigger SC600 Option .......................................................................... 9-23
Test Video Triggers ........................................................................................... 9-25
Verify Pulse Capture .......................................................................................... 9-26
Measure Input Resistance and Capacitance ....................................................... 9-27
Input Impedance Measurement ..................................................................... 9-27
Input Capacitance Measurement ................................................................... 9-27
Test Overload Protection ................................................................................... 9-28
Remote Commands and Queries ........................................................................ 9-29
General Commands ....................................................................................... 9-29
Edge Function Commands ............................................................................ 9-33
Marker Function Commands ......................................................................... 9-33
Video Function Commands ........................................................................... 9-34
Overload Function Commands ...................................................................... 9-34
Impedance/Capacitance Function Commands ............................................... 9-35
Verification Tables ............................................................................................ 9-36
10 SC300 Oscilloscope Calibration Option ............................................ 10-1
Introduction ........................................................................................................ 10-3
SC300 Oscilloscope Calibration Option Specifications .................................... 10-4
Volt Function Specifications ......................................................................... 10-4
Edge Function Specifications ........................................................................ 10-5
Leveled Sine Wave Function Specifications ................................................. 10-5
Time Marker Function Specifications ........................................................... 10-6
Wave Generator Specifications ..................................................................... 10-6
Trigger Signal Specifications for the Time Marker Function ....................... 10-6
Trigger Signal Specifications for the Edge Function .................................... 10-6
Oscilloscope Connections .................................................................................. 10-7
Start the Oscilloscope Calibration Option ......................................................... 10-8
The Output Signal .......................................................................................... 10-8
Adjust the Output Signal ............................................................................... 10-9
Key in a Value ........................................................................................... 10-9
Adjust Values with the Rotary Knob ........................................................ 10-9
Use and .................................................................................. 10-10
Reset the Oscilloscope Option ....................................................................... 10-10
Calibrate the Voltage Amplitude on an Oscilloscope ........................................ 10-11
The Volt Function .......................................................................................... 10-11
The V/DIV Menu .......................................................................................... 10-12
Shortcuts to Set the Voltage Amplitude ........................................................ 10-13
Amplitude Calibration Procedure for an Oscilloscope .................................. 10-13
Calibrate the Pulse and Frequency Response on an Oscilloscope ..................... 10-14
The Edge Function ........................................................................................ 10-14
Pulse Response Calibration Procedure for an Oscilloscope .......................... 10-15
The Leveled Sine Wave Function ................................................................. 10-16
Shortcuts to Set the Frequency and Voltage .................................................. 10-17
The MORE OPTIONS Menu ........................................................................ 10-18
x
Page 11
Contents (continued)
Sweep through a Frequency Range ............................................................... 10-19
Frequency Response Calibration Procedure for an Oscilloscope .................. 10-20
Calibrate the Time Base of an Oscilloscope ...................................................... 10-22
The Time Marker Function ........................................................................... 10-22
Time Base Marker Calibration Procedure for an Oscilloscope ..................... 10-23
Test the Trigger .................................................................................................. 10-24
Summary of Commands and Queries ................................................................ 10-25
Verification Tables ............................................................................................ 10-28
Appendices
A Glossary ....................................................................................................... A-1
B ASCII and IEEE-488 Bus Codes ................................................................. B-1
C RS-232/IEEE-488 Cables and Connectors .................................................. C-1
D Error Messages ............................................................................................ D-1
xi
Page 12
5502A
Operators Manual
xii
Page 13
List of Tables
Table Title Page
1-1. Symbols .................................................................................................................. 1-5
2-1. Standard Equipment ............................................................................................... 2-3
2-2. Mains-Power Cord Types Available from Fluke Calibration ................................ 2-6
3-1. Front-Panel Features .............................................................................................. 3-4
3-2. Rear-Panel Features ............................................................................................... 3-10
3-3. Factory Defaults for SETUP Menus Power-Up Defaults ...................................... 3-22
4-1. UUT Connections ................................................................................................... 4-12
4-2. Keys That Exit Error Mode .................................................................................... 4-51
4-3. Verification Voltages and Frequencies .................................................................. 4-57
4-4. Watts Performance, Text Screen ............................................................................ 4-62
4-5. Harmonics Performance for Volts, Harmonics Screen .......................................... 4-64
4-6. Harmonics Performance for Amps, Harmonics Screen ......................................... 4-65
4-7. Thermocouple Performance ................................................................................... 4-66
5-1. Operation State Transitions .................................................................................... 5-23
5-2. RS-232 Interface Wiring ........................................................................................ 5-24
5-3. RS-232 Emulation of IEEE-488 Messages ............................................................ 5-25
5-4. IEEE-488 Interface Messages (Received) .............................................................. 5-29
5-5. IEEE-488 Interface Messages (Sent) ..................................................................... 5-30
5-6. Commands for RS-232 Only .................................................................................. 5-32
5-7. Commands for IEEE-488 Only .............................................................................. 5-33
5-8. Units Accepted in Parameters and Used in Responses .......................................... 5-33
5-9. Terminator Characters ............................................................................................ 5-35
5-10. Response Data Types ............................................................................................. 5-36
5-11. Status Register Summary ....................................................................................... 5-37
6-1. Common Commands .............................................................................................. 6-3
6-2. Error Mode Commands .......................................................................................... 6-4
6-3. External Connection Commands ............................................................................ 6-4
6-4. Oscilloscope Commands ........................................................................................ 6-5
6-5. Output Commands ................................................................................................. 6-6
6-6. RS-232 Host Port Commands ................................................................................ 6-7
6-7. RS-232 UUT Port Commands................................................................................ 6-7
6-8. Setup and Utility Commands ................................................................................. 6-8
6-9. Status Commands ................................................................................................... 6-9
6-10. Thermocouple (TC) Measurement Commands ...................................................... 6-9
7-1. Replacement Line Fuses......................................................................................... 7-4
xiii
Page 14
5502A
Operators Manual
7-2. Replacement Current Fuses .................................................................................... 7-6
7-3. Verification Tests for DC Voltage (Normal) ......................................................... 7-8
7-4. Verification Tests for DC Voltage (AUX) ............................................................. 7-9
7-5. Verification Tests for DC Current (AUX) ............................................................. 7-9
7-6. Verification Tests for Resistance ........................................................................... 7-10
7-7. Verification Tests for AC Voltage (Normal) ......................................................... 7-11
7-8. Verification Tests for AC Voltage (AUX) ............................................................. 7-13
7-9. Verification Tests for AC Current .......................................................................... 7-14
7-10. Verification Tests for Capacitance ......................................................................... 7-16
7-11. Verification Tests for Thermocouple Simulation ................................................... 7-18
7-12. Verification Tests for Thermocouple Measurement .............................................. 7-18
7-13. Verification Tests for Phase Accuracy, V and V ................................................... 7-19
7-14. Verification Tests for Phase Accuracy, V and I ..................................................... 7-20
7-15. Verification Tests for Frequency ............................................................................ 7-21
8-1. Options and Accessories ........................................................................................ 8-3
9-1. SCOPE Command Parameters ............................................................................... 9-29
9-2. SC600 Option DC Voltage Verification ................................................................ 9-36
9-3. SC600 Option AC Voltage Amplitude Verification .............................................. 9-37
9-4. SC600 Option AC Voltage Frequency Verification ............................................... 9-38
9-5. SC600 Option Wave Generator Amplitude Verification
(1 M output impedance) ................................................................................. 9-38
9-6. SC600 Option Wave Generator Amplitude Verification
(50 output impedance) .................................................................................... 9-40
9-7. SC600 Option Leveled Sine Wave Verification: Amplitude ................................. 9-41
9-8. SC600 Option Leveled Sine Wave Verification: Frequency ................................. 9-42
9-9. SC600 Option Leveled Sine Wave Verification: Harmonics ................................. 9-42
9-10. SC600 Option Leveled Sine Wave Verification: Flatness ..................................... 9-43
9-11. SC600 Option Edge Verification: Amplitude ........................................................ 9-51
9-12. SC600 Option Edge Verification: Frequency ........................................................ 9-51
9-13. SC600 Option Edge Verification: Duty Cycle ....................................................... 9-52
9-14. SC600 Option Edge Verification: Rise Time ......................................................... 9-52
9-15. SC600 Option Tunnel Diode Pulser Verification................................................... 9-52
9-16. SC600 Option Marker Generator Verification ....................................................... 9-53
9-17. SC600 Option Pulse Generator Verification: Period ............................................. 9-53
9-18. SC600 Option Pulse Generator Verification: Pulse Width .................................... 9-53
9-19. SC600 Option Input Impedance Verification: Resistance ..................................... 9-54
9-20. SC600 Option Input Impedance Verification: Capacitance ................................... 9-54
10-1. Voltage Function Verification: AC Voltage into a 1 MΩ Load ............................. 10-28
10-2. Voltage Function Verification: AC Voltage into a 50 Ω Load .............................. 10-29
10-3. Voltage Function Verification: DC Voltage into a 50 Ω Load .............................. 10-30
10-4. Voltage Function Verification: DC Voltage into a 1 MΩ Load ............................. 10-31
10-5. Edge Function Verification .................................................................................... 10-32
10-6. Wave Generator Function Verification: 1 MΩ Load ............................................. 10-32
10-7. Wave Generator Function Verification: 50 Ω Load .............................................. 10-33
10-8. Leveled Sine Wave Function Verification: Amplitude .......................................... 10-33
10-9. Leveled Sine Wave Function Verification: Flatness .............................................. 10-34
10-10. Leveled Sine Wave Function Verification: Frequency .......................................... 10-37
10-11. Marker Generator Function Verification ................................................................ 10-38
xiv
Page 15
List of Figures
Figure Title Page
1-1. 5502A Multi-Product Calibrator ............................................................................ 1-3
1-2. RS-232 Remote Connection ................................................................................... 1-7
1-3. Allowable Duration of Current >11 A ................................................................... 1-11
1-4. Permissible Combinations of AC Voltage and AC Current for Power
and Dual Output ................................................................................................... 1-21
2-1. Access the Fuse and Select Line Voltage ............................................................... 2-5
2-2. Line-Power Cord Types Available from Fluke Calibration ................................... 2-6
3-1. Front-Panel Features .............................................................................................. 3-4
3-2. Rear-Panel Features ............................................................................................... 3-10
3-3. Setup Softkey Menu Tree ....................................................................................... 3-12
3-4. SETUP Softkey Menu Displays ............................................................................. 3-13
4-1. EARTH Internal Connections ................................................................................ 4-10
4-2. UUT Connection: Resistance (Four-Wire Compensation) .................................... 4-13
4-3. UUT Connection: Resistance (Two-Wire Compensation) ..................................... 4-13
4-4. UUT Connection: Resistance (Compensation Off) ................................................ 4-14
4-5. UUT Connection: Capacitance (Two-Wire Compensation) .................................. 4-14
4-6. UUT Connection: Capacitance (Compensation Off) ............................................. 4-15
4-7. UUT Connection: DC Voltage/AC Voltage ........................................................... 4-15
4-8. UUT Connection: DC Current/AC Current ........................................................... 4-16
4-9. UUT Connection: Temperature (RTD) .................................................................. 4-16
4-10. UUT Connection: Temperature (Thermocouple) ................................................... 4-17
4-11. Sine Wave .............................................................................................................. 4-44
4-12. Triangle Wave ........................................................................................................ 4-44
4-13. Square Wave and Duty Cycle ................................................................................ 4-45
4-14. Truncated Sine Wav ............................................................................................... 4-45
4-15. Cable Connections to Verify 80 Series General Functions .................................... 4-56
4-16. Cable Connections to Verify an 80 Series Current Function ................................. 4-58
4-17. Cable Connections to Verify an 80 Series High Amps Function ........................... 4-60
4-18. Cable Connections to Verify a 40 Series Watts Function ...................................... 4-62
4-19. Cable Connections to Verify a 50 Series Thermometer ......................................... 4-65
5-1. Typical IEEE-488 Remote Control Connections ................................................... 5-4
5-2. Typical RS-232 Remote Control Connections ....................................................... 5-6
5-3. IEEE-488 Port Verification .................................................................................... 5-8
5-4. RS-232 Host Port Verification ............................................................................... 5-12
5-5. Testing the RS-232 UUT Port with RS-232 Host Port .......................................... 5-18
xv
Page 16
5502A
Operators Manual
5-6. Verify the RS-232 UUT Port with IEEE-488 Port ................................................. 5-20
5-7. IEEE-488 Remote Message Coding ....................................................................... 5-26
5-8. Status Register Overview ....................................................................................... 5-39
5-9. Serial Poll Status Byte (STB) and Service Request Enable (SRE) ........................ 5-40
5-10. Event Status Register (ESR) and Event Status Enable (ESE) ................................ 5-42
5-11. Bit Assignments for the ISR, ISCEs and ISCR ...................................................... 5-44
7-1. Accessing the Fuse ................................................................................................. 7-5
7-2. Current Fuse Replacement ..................................................................................... 7-6
7-3. Access the Air Filter ............................................................................................... 7-7
9-1. Oscilloscope Connection: Channel and External Trigger ...................................... 9-7
9-2. Tunnel Diode Pulser Connections .......................................................................... 9-16
10-3. Oscilloscope Connection: Channel and External Trigger ...................................... 10-7
xvi
Page 17
Chapter 1
Introduction and Specifications
Title Page
Introduction .......................................................................................................... 1-3
Safety Information ............................................................................................... 1-4
Overload Protection ............................................................................................. 1-6
Operation Overview ............................................................................................. 1-6
Local Operation ............................................................................................... 1-6
Remote Operation (RS-232) ............................................................................ 1-6
Remote Operation (IEEE-488) ........................................................................ 1-7
Instruction Manuals ............................................................................................. 1-8
5502A Getting Started Manual ........................................................................ 1-8
5502A Operators Manual ................................................................................ 1-8
Contact Fluke Calibration .................................................................................... 1-8
Specifications ....................................................................................................... 1-9
General Specifications ......................................................................................... 1-9
Detailed Specifications ........................................................................................ 1-10
DC Voltage ...................................................................................................... 1-10
DC Current ...................................................................................................... 1-11
Resistance ........................................................................................................ 1-12
AC Voltage (Sine Wave) ................................................................................. 1-13
AC Voltage (Sine Wave) (cont.) ..................................................................... 1-14
AC Current (Sine Wave) ................................................................................. 1-15
AC Current (Sine Wave) (cont.) ...................................................................... 1-16
Capacitance...................................................................................................... 1-17
Temperature Calibration (Thermocouple) ....................................................... 1-18
Temperature Calibration (RTD) ...................................................................... 1-19
Phase ................................................................................................................ 1-19
AC and DC Power Specifications ................................................................... 1-20
Specification Limits for Power and Dual Output Operation ........................... 1-20
Calculate the Uncertainty Specifications of Power and
Dual Output Settings .................................................................................... 1-21
Examples of Specified Power Uncertainties at Various Output Settings ........ 1-22
Calculate Power Uncertainty ........................................................................... 1-22
Additional Specifications ..................................................................................... 1-23
Frequency ........................................................................................................ 1-23
Harmonics (2
AC Voltage (Sine Wave) Extended Bandwidth .............................................. 1-24
AC Voltage (Non-Sine Wave) ......................................................................... 1-24
AC Voltage (Non-Sine Wave) (cont.) ............................................................. 1-25
AC Voltage, DC Offset ................................................................................... 1-26
nd
to 50th) .................................................................................... 1-23
1-1
Page 18
5502A
Operators Manual
AC Voltage, Square Wave Characteristics ...................................................... 1-26
AC Voltage, Triangle Wave Characteristics (typical) ..................................... 1-26
AC Current (Non-Sine Wave) ......................................................................... 1-27
AC Current (Non-Sine Wave) (cont.) .............................................................. 1-28
AC Current, Square Wave Characteristics (typical) ........................................ 1-28
AC Current, Triangle Wave Characteristics (typical) ..................................... 1-28
1-2
Page 19
Introduction
To prevent possible electrical shock, fire, or personal injury,
read all safety Information before you use the Product.
The 5502A Calibrator (“the Product” or “the Calibrator”) in Figure 1-1 can be configured
to source:
• DC voltage from 0 V to ±1020 V.
• AC voltage from 1 mV to 1020 V, with output from 10 Hz to 500 kHz.
• AC current from 29 μA to 20.5 A, with variable frequency limits.
• DC current from 0 to ±20.5 A.
• Resistance values from a short circuit to 1100 MΩ.
• Capacitance values from 220 pF to 110 mF.
• Simulated output for eight types of Resistance Temperature Detectors (RTDs).
• Simulated output for 11 types of thermocouples.
5502A
Warning
CALIBRATOR
STBY
OPR
EARTH
7
8 9
4
5
6
123
+
/
0
•
SCOPE
PREV
TRIG
OUT
ME
NU
dBm
sec
m
V Hz
n
W
k
A
p
M
SHIFT
ENTER
SETUP
¡F
¡C
F
RESET
NEW
CE
REF
MEAS
ZERO
TC
CAL
MULT
DIV
x
EDIT
FIELD
POWER
gvx001.eps
Figure 1-1. 5502A Multi-Product Calibrator
Calibrator features include:
• Automatic meter error calculation, with reference values that you can select.
• and keys that change the output value to predetermined values for various
functions.
• Programmable entry limits. These limits do not let you go above preset output limits.
• Voltage and current that can be output at the same time, to an equivalent of 20.9 kW.
• 10 MHz reference input and output. Use this to input a high-accuracy 10 MHz
reference to move the frequency accuracy to the 5502A, or to put one or more
Calibrators in the control of a master 5502A.
• The power to output two voltages at the same time.
• Extended bandwidth mode outputs multiple waveforms down to 0.01 Hz, and sine
1-3
Page 20
5502A
Operators Manual
Safety Information
waves to 2 MHz.
• A Standard IEEE-488 (GPIB) interface that complies with ANSI/IEEE Standards
488.1-1987 and 488.2-1987.
• A EIA Standard RS-232 serial data interface to print, show, or move internally stored
calibration constants, and for remote control of the 5502A.
• A pass-through RS-232 serial data interface to send data to the Unit Under Test
(UUT).
In this manual, A Warning identifies conditions and procedures that are dangerous to the
user. A
Caution identifies conditions and procedures that can cause damage to the
Product or the equipment under test.
Warning
To prevent possible electrical shock, fire, or personal injury:
• Use the Product only as specified, or the protection
supplied by the Product can be compromised.
• Carefully read all instructions.
• Do not use the Product around explosive gas, vapor, or in
damp or wet environments.
• Use this Product indoors only.
• Do not touch voltages > 30 V ac rms, 42 V ac peak, or
60 V dc.
• Do not use the Product if it operates incorrectly.
• Do not use and disable the Product if it is damaged.
• Do not use test leads if they are damaged. Examine the test
leads for damaged insulation, exposed metal, or if the wear
indicator shows. Check test lead continuity.
• Use only cables with correct voltage ratings.
• Connect the common test lead before the live test lead and
remove the live test lead before the common test lead.
• Use only the mains power cord and connector approved for
the voltage and plug configuration in your country and rated
for the Product.
• Make sure the ground conductor in the mains power cord is
connected to a protective earth ground. Disruption of the
protective earth could put voltage on the chassis that could
cause death.
1-4
Page 21
Introduction and Specifications
Safety Information 1
• Replace the mains power cord if the insulation is damaged
or if the insulation shows signs of wear.
• Do not connect directly to mains.
• Do not use an extension cord or adapter plug.
• For safe operation and maintenance of the Product, make
sure that the space around the Product meets minimum
requirements.
This Calibrator complies with:
• ANSI/ISA-61010-1 (82.02.01)
• CAN/CSA C22.2 No. 61010-1-04
• ANSI/UL 61010-1:2004
• EN 61010-1:2001
• ANSI/IEEE Standards 488.1-1987 and 488.2-1987.
Symbols used in this manual and on the Product are in Table 1-1.
Table 1-1. Symbols
Symbol Description Symbol Description
CAT I
IEC Measurement Category I – CAT I
is for measurements not directly
connected to mains. Maximum
transient Overvoltage is as specified
by terminal markings.
Conforms to European Union
directives.
Risk of Danger. Important
information. See manual.
Earth ground
Conforms to relevant North American
Safety Standards.
Do not dispose of this product as
unsorted municipal waste. Go to the
Fluke Calibration website for recycling
information.
Hazardous voltage
Conforms to relevant Australian EMC
requirements.
1-5
Page 22
5502A
Operators Manual
Overload Protection
Operation Overview
The Calibrator supplies reverse-power protection, fast output disconnection, and/or fuse
protection on the output terminals for all functions.
Reverse-power protection prevents damage to the calibrator from occasional, accidental,
normal-mode, and common-mode overloads to a maximum of ±300 V peak. It is not
intended as protection against frequent (systematic and repeated) abuse. Such abuse will
cause the Calibrator to fail.
For volts, ohms, capacitance, and thermocouple functions, there is fast output
disconnection protection. This protection senses applied voltages higher than 20 volts on
the output terminals. It quickly disconnects the internal circuits from the output terminals
and resets the calibrator when such overloads occur.
For current and aux voltage functions, user replaceable fuses supply protection from
overloads applied to the Current/Aux Voltage output terminals. The fuses are accessed by
an access door on the bottom of the calibrator. You must use replacement fuses of the
same rating and type specified in this manual, or the protection supplied by the Calibrator
will be compromised.
The Calibrator can be operated at the front panel or remotely with the RS-232 or IEEE488 ports. For remote operations, software is available to integrate 5502A operation into
a wide variety of calibration requirements.
Local Operation
Typical local operations include front-panel connections to the UUT, and then manual
keystroke entries at the front panel to put the Calibrator in the necessary output mode.
and make it easy to step up or down at the push of a key. You can also examine
Calibrator specifications at the push of two buttons. The backlit LCD is easy to read from
many different angles and can be read in dim or bright light. The large, easy-to-read keys
are color-coded and give tactile feedback.
Remote Operation (RS-232)
There are two rear-panel serial data RS-232 ports: SERIAL 1 FROM HOST, and
SERIAL 2 TO UUT (see Figure 1-2). Each port is dedicated to serial-data
communications to operate and control the Product during calibration procedures. For
complete information on remote operation, see Chapter 5.
The SERIAL 1 FROM HOST serial data port connects a host terminal or personal
computer (PC) to the Calibrator. To send commands to the Calibrator: enter commands
from a terminal (or a PC running a terminal program), write your own procedures with
BASIC, or use optional Windows-based software such as MET/CAL Plus.
1-6
Page 23
Introduction and Specifications
Operation Overview 1
The SERIAL 2 TO UUT serial data port connects a UUT to a PC or terminal with the
5502A (see Figure 1-2). This “pass-through” configuration removes the requirement for
two COM ports at the PC or terminal. A set of four commands control the operation of
the SERIAL 2 TO UUT serial port. See Chapter 6 for a discussion of the UUT_
commands.
SERIAL 1 FROM HOST port
5502A
CALIBRATOR
STBY EARTH
OPR
SCOPE
7 8 9
m
n
4
5
6
k
p
123
M
+
/
0
•
SHIFT
5502A
SERIAL 2
TO UUT port
COM port
PREV
TRIG
OUT
ME
NU
dBm sec
V Hz
SETUP
RESET
EDIT
W
A
ENTER
FIELD
¡F
NEW
¡C
CE
REF
MEAS
ZERO
F
TC
CAL
MULT
DIV
x
POWER
RS-232 Remote Operation using the
SERIAL 1 FROM HOST port
PC or Terminal
SERIAL 1 FROM HOST port
COM port
5502A
CALIBRATOR
PREV
STBY
OPR
TRIG
EARTH
SCOPE
OUT
ME
NU
dBm
7
sec
8
9
m
V
SETUP
Hz
RESET
EDIT
4
1
+
/
5
6
23
0•
5502A
n
W
k
p
M
SHIFT
FIELD
¡F
NEW
A
¡C
CE
REF
MEAS
ZERO
F
TC
CAL
MULT
ENTER
DIV
x
POWER
RS-232 Remote Operation using the
PC or Terminal
Unit Under Test
SERIAL 1 FROM HOST and
SERIAL 2 TO UUT ports
Figure 1-2. RS-232 Remote Connection
Remote Operation (IEEE-488)
The rear-panel IEEE-488 port is a fully programmable parallel interface bus that
complies with standard IEEE-488.1 and supplemental standard IEEE-488.2. When the
Calibrator is used by remote control of an instrument controller, the Calibrator operates
exclusively as a “talker/listener.” You can write your own programs with the IEEE-488
command set or run the optional Windows-based MET/CAL Plus software. See Chapter
6 for a discussion of the commands available for IEEE-488 operation.
gvx002.eps
1-7
Page 24
5502A
Operators Manual
Instruction Manuals
5502A Getting Started Manual
5502A Operators Manual
The 5502A Manual Set includes:
• 5502A Operators Manual on included CD-ROM (PN 4155227)
• 5502A Getting Started (PN 4155209)
One of each manual above comes with the instrument. Refer to the Fluke Calibration
Catalog or speak to a Fluke Calibration sales representative (see “Contact Fluke
Calibration” in this chapter) if more printed copies are necessary. The manuals are also
available on the Fluke Calibration website.
The 5502A Getting Started Manual contains a brief introduction to the 5502A Manual
Set, instructions on how to get your calibrator prepared for operation and a complete set
of specifications.
This 5502A Operators Manual supplies complete information to install the Calibrator and
operate it from the front-panel keys and in remote configurations. The manual also has a
glossary of calibration, specifications, and error-code information. The Operators Manual
includes:
• Installation
• Controls and features, front-panel operation
• Remote operation (IEEE-488 bus or serial port remote control)
• Serial port operation (print, show, or transfer data, and setup for serial port remote
control)
• Operator maintenance, with verification and calibration procedures
• Accessories
• SC600 and SC300 oscilloscope calibration options
Contact Fluke Calibration
To contact Fluke Calibration, call one of the following telephone numbers:
• Technical Support USA: 1-877-355-3225
• Calibration/Repair USA: 1-877-355-3225
• Canada: 1-800-36-FLUKE (1-800-363-5853)
• Europe: +31-40-2675-200
• Japan: +81-3-6714-3114
• Singapore: +65-6799-5566
• China: +86-400-810-3435
• Brazil: +55-11-3759-7600
• Anywhere in the world: +1-425-446-6110
To see product information and download the latest manual supplements, visit Fluke
Calibration’s website at www.flukecal.com.
To register your product, visit http://flukecal.com/register-product .
1-8
Page 25
Introduction and Specifications
Specifications 1
Specifications
General Specifications
The following tables list the 5502A specifications. All specifications are valid after allowing a warm-up period of
30 minutes, or twice the time the 5502A has been turned off. (For example, if the 5502A has been turned off for
5 minutes, the warm-up period is 10 minutes.)
All specifications apply for the temperature and time period indicated. For temperatures outside of tcal ±5 °C (tcal is the
ambient temperature when the 5502A was calibrated), the temperature coefficient as stated in the General Specifications
must be applied.
The specifications also assume the Calibrator is zeroed every seven days or whenever the ambient temperature changes
more than 5 °C. The tightest ohms specifications are maintained with a zero cal every 12 hours within ±1 °C of use.
Also see additional specifications later in this chapter for information on extended specifications for ac voltage and
current.
Warmup Time ........................................................ Twice the time since last warmed up, to a maximum of 30 minutes.
Settling Time ......................................................... Less than 5 seconds for all functions and ranges except as noted.
Standard Interfaces .............................................. IEEE-488 (GPIB), RS-232
Temperature
Operating ............................................................ 0 °C to 50 °C
Calibration (tcal) .................................................. 15 °C to 35 °C
Storage ............................................................... -20 °C to +70 °C; The DC current ranges 0 to 1.09999 A and 1.1 A to
Temperature Coefficient ....................................... Temperature coefficient for temperatures outside of tcal ±5 °C is 10 %
Relative Humidity
Operating ............................................................ <80 % to 30 °C, <70 % to 40 °C, <40 % to 50 °C
Storage ............................................................... <95 %, non-condensing. After long periods of storage at high humidity,
Altitude
Operating ............................................................ 3,050 m (10,000 ft) maximum
Non-operating ..................................................... 12,200 m (40,000 ft) maximum
Safety ..................................................................... Complies with EN/IEC 61010-1:2001, CAN/CSA-C22.2 No.
Output Terminal Electrical Overload Protection Provides reverse-power protection, immediate output disconnection,
Analog Low Isolation ............................................ 20 V normal operation, 400 V peak transient
EMC ........................................................................ Complies with EN/IEC 61326-1:2006, EN/IEC 61326-2-1:2
Line Power ............................................................. Line Voltage (selectable): 100 V, 120 V, 220 V, 240 V
2.99999 A are sensitive to storage temperatures above 50 °C. If the
5502A is stored above 50 °C for greater than 30 minutes, these ranges
must be re-calibrated. Otherwise, the 90 day and 1 year uncertainties
of these ranges double.
of the stated specification per °C.
a drying-out period (with power on) of at least one week may be
required.
61010-1-04, ANSI/UL 61010-1:2004;
and/or fuse protection on the output terminals for all functions. This
protection is for applied external voltages up to ±300 V peak.
006 for
controlled EM environments under the following conditions. If used in
areas with Electromagnetic fields of 1 to 3 V/m from 0.08-1GHz,
resistance outputs have a floor adder of 0.508 Ω Performance not
specified above 3 V/m. This instrument may be susceptible to electrostatic discharge (ESD) to the binding posts. Good static awareness
practices should be followed when handling this and other pieces of
electronic equipment. Additionally this instrument may be susceptible
to electrical fast transients on the mains terminals. If any disturbances
in operation are observed, it is recommended that the rear panel
chassis ground terminal be connected to a known good earth ground
with a low inductance ground strap. Note that a mains power outlet
while providing a suitable ground for protection against electric shock
hazard may not provide an adequate ground to properly drain away
conducted rf disturbances and may in fact be the source of the
disturbance. This instrument was certified for EMC performance with
data I/O cables not in excess of 3m.
Line Frequency: 47 Hz to 63 Hz
Line Voltage Variation: ±10 % about line voltage
setting. For optimal performance at full dual
1-9
Page 26
5502A
Operators Manual
Power Consumption ............................................. 600 VA
Dimensions (HxWxL) .............................................. 17.8 cm x 43.2 cm x 47.3 cm (7 in x 17 in x 18.6 in) Standard rack
Weight (without options) ......................................... 22 kg (49 lb)
Absolute Uncertainty Definition .......................... The 5502A specifications include stability, temperature coefficient,
Specification Confidence Level ........................... 99 %
Detailed Specifications
DC Voltage
0 to 329.9999 mV 0.005 + 3 0.006 + 3 5 + 1 0.1 65 Ω
0 to 3.299999 V 0.004 + 5 0.005 + 5 4 + 3 1 10 mA
0 to 32.99999 V 0.004 + 50 0.005 + 50 4 + 30 10 10 mA
30 to 329.9999 V 0.0045 + 500 0.0055 + 500 4.5 + 300 100 5 mA
100 to 1020.000 V 0.0045 + 1500 0.0055 + 1500 4.5 + 900 1000 5 mA
0 to 329.999 mV 0.03 + 350 0.04 + 350 30 + 100 1 5 mA
0.33 to 3.29999 V 0.03 + 350 0.04 + 350 30 + 100 10 5 mA
3.3 to 7 V 0.03 + 350 0.04 + 350 30 + 100 100 5 mA
0 to 329.999 mV 0.005 + 3 0.006 + 3 5 + 1 0.1 10 Ω
[1] Remote sensing is not provided. Output resistance is < 5 mΩ for outputs ≥ 0.33 V. The AUX output has an output resistance of
[2] Two channels of dc voltage output are provided.
[3] TC simulating and measuring are not specified for operation in electromagnetic fields above 0.4 V/m.
outputs (e.g. 1000 V, 20 A) choose a ling voltage
setting that is ±7.5 % from nominal.
width and rack increment, plus 1.5 cm (0.6 in) for feet on bottom of
unit.
linearity, line and load regulation, and the traceability of the external
standards used for calibration. You do not need to add anything to
determine the total specification of the 5502A for the temperature
range indicated.
Absolute Uncertainty, tcal ± 5 °C
Range
<1 Ω. TC simulation has an output impedance of 10 Ω ± 1 Ω.
±(% of output + μV)
90 Day 1 Year
Auxiliary Output (dual output mode only)
TC Simulate and Measure in Linear 10 μV/°C and 1 mV/°C modes
Stability
24 hours, ± 1 °C
±(ppm of output + μV)
Resolution (µV) Max Burden
[2]
[3]
[1]
Range
0 to 329.9999 mV 0 + 1
0 to 3. 3.299999 V 0 + 10
0 to 32.99999 V 0 + 100
30 to 329.9999 V 10 + 1000 20 mV
100 to 1020.000 V 10 + 5000 20 mV
0 to 329.999 mV
0.33 to 3.29999 V
3.3 to 7 V
[1] Two channels of dc voltage output are provided.
1-10
Noise
Bandwidth 0.1 Hz to 10 Hz p-p
±(ppm of output + floor in μV)
Auxiliary Output (dual output mode only)
0 + 5 μV 20 μV
0 + 20 μV 300 μV
0 + 100 μV 1000 μV
Bandwidth 10 Hz to 10 kHz rms
6 μV
60 μV
600 μV
[1]
Page 27
Introduction and Specifications
Detailed Specifications 1
DC Current
Absolute Uncertainty, tcal ±5 °C
Range
±(% of output +μA)
Resolution
90 Day 1 Year
0 to 329.999 μA
0 to 3.29999 mA
0 to 32.9999 mA
0 to 329.999 mA
0 to 1.09999 A
1.1 to 2.99999 A 0.030 + 44 0.038 + 44
0 to 10.9999 A
(20 A Range)
11 to 20.5 A
[1] Duty Cycle: Currents <11 A may be provided continuously. For currents >11 A, see Figure 1-3. The current may be provided
[2] Floor specification is 1500 μA within 30 seconds of selecting operate. For operating times >30 seconds, the floor specification is
[1]
0.080 + 750
Formula 60-T-I minutes any 60 minute period where T is the temperature in °C (room temperature is about 23 °C) and I is the
output current in amperes. For example, 17 A, at 23 °C could be provided for 60-23-17 = 20 minutes each hour. When the 5502A
is outputting currents between 5 and 11 amps for long periods, the internal self-heating reduces the duty cycle. Under those
conditions, the allowable "on" time indicated by the formula and Figure 1-3 is achieved only after the 5502A is outputting currents
<5 A for the "off" period first.
750 μA.
0.012 + 0.02 0.015 + 0.02 1 nA
0.010 + 0.05 0.010 + 0.05
0.008 + 0.25 0.010 + 0.25
0.008 + 3.3 0.010 + 2.5
0.023 + 44 0.038 + 44
0.01 μA
0.1 μA
1 μA
10 μA
10 μA
0.038 + 500 0.060 + 500
[2]
0.10 + 750
[2]
100 μA
100 μA
Max Compliance
Voltage V
10
10
7
7
6
6
4
4
Max Inductive
Load mH
400
Range
0 to 329.999 μA
Bandwidth 0.1 Hz to 10 Hz p-p Bandwidth 10 Hz to 10 kHz rms
2 nA 20 nA
0 to 3.29999 mA 20 nA 200 nA
0 to 32.9999 mA 200 nA
0 to 329.999 mA 2000 nA
0 to 2.99999 A
0 to 20.5 A
20 μA
200 μA
Noise
2.0 μA
20 μA
1 mA
10 mA
50
45
40
35
30
25
Minutes per Hour
20
15
10
5
0
11 12 13 14 15 16 17 18 19 20
40 °C
30 °C
Current (Amps)
20 °C
10 °C
Ambient
Figure 1-3. Allowable Duration of Current >11 A
0 °C
80%
70%
60%
50%
40%
Duty Cycle (%)
30%
20%
10%
0%
1-11
Page 28
5502A
Operators Manual
Resistance
[2]
Absolute Uncertainty, tcal ±5 °C ±(% of output + floor)
[1]
Range
% of output
90 Day 1 Year
0 to 10.999 Ω
11 to 32.999 Ω
33 to
109.999 Ω
110 to
329.999 Ω
330 to
1.09999 kΩ
1.1 to
3.29999 kΩ
3.3 to
10.9999 kΩ
11 to
32.9999 kΩ
33 to
109.999 kΩ
110 to
329.999 kΩ
330 kΩ to
1.09999 MΩ
1.1 to
3.29999 MΩ
3.3 to
10.9999 MΩ
11 to
32.9999 MΩ
33 to
109.999 MΩ
110 to
329.999 MΩ
330 to
1100.00 MΩ
[1] Continuously variable from 0 Ω to 1.1 GΩ.
[2] Applies for 4-WIRE compensation only. For 2-WIRE and 2-WIRE COMP, add 5 μV per amp of stimulus current to the floor
specification. For example, in 2-WIRE mode, at 1 kΩ the floor specification within 12 hours of an ohms zero cal for a measurement
current of 1 mA is: 0.002 Ω + 5 μV / 1 mA = (0.002 + 0.005) Ω = 0.007 Ω.
[3] Do not exceed the largest current for each range. For currents lower than shown, the floor adder increases by Floor
I
min/Iactual
an ohms zero calibration within 12 hours.
0.009
0.009
0.007
0.007
0.007
0.007
0.007
0.007
0.008
0.009
0.011
0.011
0.045
0.075
0.4
0.4
0.012
0.012
0.009
0.009
0.009
0.009
0.009
0.009
0.011
0.012
0.015
0.015
0.06
0.1
0.5
0.5
1.2 1.5 500000 500000 10000 1 nA to 13 nA
. For example, a 50 μA stimulus measuring 100 Ω has a floor specification of: 0.0014 Ω x 1 mA/50 μA = 0.028 Ω, assuming
Floor (Ω) Time and temp since ohms
zero cal
12 hrs ±1 °C 7 days ±5 °C
0.001 0. 01 0.001 1 mA to 125 mA
0.0015 0.015 0.001 1 mA to 125 mA
0.0014 0.015 0.001 1 mA to 70 mA
0.002 0.02 0.001 1 mA to 40 mA
0.002 0.02 0.01 1 mA to 18 mA
0.02 0.2 0.01
0.02 0.1 0.1
0.2 1 0.1
0.2 1 1
2 10 1
2 10 10
30 150 10
50 250 100
2500 2500 100 25 nA to 500 nA
3000 3000 1000 25 nA to 180 nA
100000 100000 1000 2.5 nA to 50 nA
Resolution
(Ω)
Allowable Current
100 μA to 5 mA
100 μA to 1.8 mA
10 μA to .5 mA
10 μA to 0.18 mA
1 μA to 50 μA
1 μA to 18 μA
250 nA to 5 μA
250 nA to 1.8 μA
(new)
(A)
= Floor
(old)
[3]
x
1-12
Page 29
Introduction and Specifications
Detailed Specifications 1
AC Voltage (Sine Wave)
Absolute Uncertainty, tcal
Range Frequency
10 Hz to 45 Hz
45 Hz to 10 kHz
1.0 to
32.999 mV
33 mV to
329.999 mV
0.33 V to
3.29999 V
3.3 V to
32.9999 V
33 V to
329.999 V
330 V to
1020 V
[1] Max Distortion for 100 kHz to 200 kHz. For 200 kHz to 500 kHz, the maximum distortion is 0.9 % of output + floor as shown.
Note
Remote sensing is not provided. Output resistance is <5 mΩ for outputs ≥0.33 V. The AUX output resistance is <1 Ω. The maximum
load capacitance is 500 pF, subject to the maximum burden current limits.
10 kHz to 20 kHz
20 kHz to 50 kHz
50 kHz to 100 kHz
100 kHz to 500 kHz
10 Hz to 45 Hz
45 Hz to 10 kHz
10 kHz to 20 kHz
20 kHz to 50 kHz
50 kHz to 100 kHz
100 kHz to 500 kHz
10 Hz to 45 Hz
45 Hz to 10 kHz
10 kHz to 20 kHz
20 kHz to 50 kHz
50 kHz to 100 kHz
100 kHz to 500 kHz
10 Hz to 45 Hz 0.042 + 800 0.050 + 800
45 Hz to 10 kHz 0.025 + 600 0.030 + 600 0.035 + 2 mV
10 kHz to 20 kHz 0.064 + 600 0.070 + 600 0.08 + 2 mV
20 kHz to 50 kHz 0.086 + 600 0.100 + 600 0.2 + 2 mV
50 kHz to 100 kHz 0.192 + 2000 0.230 + 2000 0.5 + 2 mV
45 Hz to 1 kHz 0.039 + 3000 0.050 + 3000
1 kHz to 10 kHz 0.064 + 9000 0.080 + 9000 0.05 +10 mV
10 kHz to 20 kHz 0.079 + 9000 0.090 + 9000 0.6 + 10 mV
20 kHz to 50 kHz 0.096 + 9000 0.120 + 9000 0.8 + 10 mV
50 kHz to 100 kHz 0.192 + 80000 0.240 + 80000 1 + 10 mV
45 Hz to 1 kHz 0.042 + 20000 0.050 + 20000
1 kHz to 5 kHz 0.064 + 20000 0.080 + 20000 0.07 + 30 mV
5 kHz to 10 kHz 0.075 + 20000 0.090 + 20000 0.07 + 30 mV
±5 °C ±(% of output + μV)
90 Day 1 Year
0.120 + 20 0.150 + 20
0.080 + 20 0.100 + 20 0.035 + 90 μV
0.120 + 20 0.150 + 20 0.06 + 90 μV
0.160 + 20 0.200 + 20 0.15 + 90 μV
0.300 + 33 0.350 + 33 0.25 + 90 μV
0.750 + 60 1.000 + 60
0.042 + 20 0.050 + 20
0.029 + 20 0.030 + 20 0.035 + 90 μV
0.066 + 20 0.070 + 20 0.06 + 90 μV
0.086 + 40 0.100 + 40 0.15 + 90 μV
0.173 + 170 0.230 + 170 0.2 + 90 μV
0.400 + 330 0.500 + 330
0.042 + 60 0.050 + 60
0.028 + 60 0.030 + 60 0.035 + 200 μV
0.059 + 60 0.070 + 60 0.06 + 200 μV
0.083 + 60 0.100 + 60 0.15 + 200 μV
0.181 + 200 0.230 + 200 0.2 + 200 μV
0.417 + 900 0.500 + 900
Resolution Max Burden
1 μV 65 Ω
1 μV 65 Ω
10 μV
100 μV
1 mV
10 mV
10 mA
10 mA
5 mA, except
20 mA for
45 Hz to
65 Hz
2 mA, except
20 mA for 45
to 65 Hz
Max Distortion and
Noise 10 Hz to
5 MHz Bandwidth
±(% of output +
floor)
0.15 + 90 μV
0.3 + 90 μV
0.15 + 90 μV
0.2 + 90 μV
0.15 + 200 μV
0.2 + 200 μV
0.15 + 2 mV
0.15 + 10 mV
0.15 + 30 mV
[1]
[1]
[1]
1-13
Page 30
5502A
Operators Manual
AC Voltage (Sine Wave) (cont.)
Range Frequency
1.0 to
329.999 mV
0.33 to
3.29999 V
3.3 to 5 V
[1] There are two channels of voltage output. The maximum frequency of the dual output is 30 kHz.
Note
Remote sensing is not provided. Output resistance is <5 mΩ for outputs ≥0.33 V. The AUX output resistance is <1 Ω. The maximum
load capacitance is 500 pF, subject to the maximum burden current limits.
10 to 20 Hz
20 to 45 Hz
45 to 1 kHz
1 to 5 kHz
5 to 10 kHz
10 to 30 kHz
10 to 20 Hz
20 to 45 Hz
45 to 1 kHz
1 to 5 kHz
5 to 10 kHz
10 to 30 kHz
10 to 20 Hz
20 to 45 Hz
45 to 1 kHz
1 to 5 kHz
5 to 10 kHz
AUX (Auxiliary Output) [dual output mode only]
Absolute Uncertainty, tcal
[1]
±5 °C ±(% of output + μV)
90 Day 1 Year
0.15 + 370 0.20 + 370
0.08 + 370 0.10 + 370 0.06 + 200 μV
0.08 + 370 0.10 + 370 0.08 + 200 μV
0.15 + 450 0.20 + 450 0.30 + 200 μV
0.30 + 450 0.40 + 450 0.60 + 200 μV
4.00 + 900 5.00 + 900 1.00 + 200 μV
0.15 + 450 0.20 + 450
0.08 + 450 0.10 + 450 0.06 + 200 μV
0.07 + 450 0.09 + 450 0.08 + 200 μV
0.15 + 1400 0.20 + 1400 0.30 + 200 μV
0.30 + 1400 0.40 + 1400 0.60 + 200 μV
4.00 + 2800 5.00 + 2800 1.00 + 200 μV
0.15 + 450 0.20 + 450
0.08 + 450 0.10 + 450 0.06 + 200 μV
0.07 + 450 0.09 + 450 0.08 + 200 μV
0.15 + 1400 0.20 + 1400 0.30 + 200 μV
0.30 + 1400 0.40 + 1400 0.60 + 200 μV
Resolution Max Burden
1 μV
10 μV
100 μV
5 mA
5 mA
5 mA
Max Distortion and
Noise 10 Hz to
5 MHz Bandwidth
±(% of output +
floor)
0.20 + 200 μV
0.20 + 200 μV
0.20 + 200 μV
1-14
Page 31
Introduction and Specifications
Detailed Specifications 1
AC Current (Sine Wave)
Absolute Uncertainty, tcal ±5
Range Frequency
°C ±(% of output + μA)
90 Day 1 Year
Compliance
adder ±(μA/V)
and Noise 10 Hz
to 100 kHz BW
±(% of output +
floor)
LCOMP Off
Max Distortion
29 to 329.99 μA
0.33 to
3.29999 mA
3.3 to
32.9999 mA
33 to
329.999 mA
0.33 to
1.09999 A
1.1 to
2.99999 A
10 to 20 Hz 0.16 + 0.1 0.2 + 0.1 0.05
20 to 45 Hz 0.12 + 0.1 0.15 + 0.1 0.05
45 Hz to 1 kHz 0.1 + 0.1 0.125 + 0.1 0.05
1 to 5 kHz 0.25 + 0.15 0.3 + 0.15 1.5
5 to 10 kHz 0.6 + 0.2 0.8 + 0.2 1.5
10 to 30 kHz 1.2 + 0.4 1.6 + 0.4 10
10 to 20 Hz 0.16 + 0.15 0.2 + 0.15 0.05
20 to 45 Hz 0.1 + 0.15 0.125 + 0.15 0.05
45 Hz to 1 kHz 0.08 + 0.15 0.1 + 0.15 0.05
1 to 5 kHz 0.16 + 0.2 0.2 + 0.2 1.5
5 to 10 kHz 0.4 + 0.3 0.5 + 0.3 1.5
10 to 30 kHz 0.8 + 0.6 1.0 + 0.6 10
10 to 20 Hz 0.15 + 2 0.18 + 2 0.05
20 to 45 Hz 0.075 + 2 0.09 + 2 0.05
45 Hz to 1 kHz 0.035 + 2 0.04 + 2 0.05
1 to 5 kHz 0.065 + 2 0.08 + 2 1.5
5 to 10 kHz 0.16 + 3 0.2 + 3 1.5
10 to 30 kHz 0.32 + 4 0.4 + 4 10
10 to 20 Hz 0.15 + 20 0.18 + 20 0.05
20 to 45 Hz 0.075 + 20 0.09 + 20 0.05
45 Hz to 1 kHz 0.035 + 20 0.04 + 20 0.05
1 to 5 kHz 0.08 + 50 0.10 + 50 1.5
5 to 10 kHz 0.16 + 100 0.2 + 100 1.5
10 to 30 kHz 0.32 + 200 0.4 + 200 10
10 to 45 Hz 0.15 + 100 0.18 + 100
45 Hz to 1 kHz 0.036 + 100 0.05 + 100
1 to 5 kHz 0.5 + 1000 0.6 + 1000
5 to 10 kHz 2.0 + 5000 2.5 + 5000
10 to 45 Hz 0.15 + 100 0.18 + 100
45 Hz to 1 kHz 0.05 + 100 0.06 + 100
1 to 5 kHz 0.5 + 1000 0.6 + 1000
5 to 10 kHz 2.0 + 5000 2.5 + 5000
[2]
[3]
[2]
[3]
0.15 + 0.5 μA
0.10 + 0.5 μA
0.05 + 0.5 μA
0.50 + 0.5 μA
1.00 + 0.5 μA
1.20 + 0.5 μA
0.15 + 1.5 μA
0.06 + 1.5 μA
0.02 + 1.5 μA
0.50 + 1.5 μA
1.00 + 1.5 μA
1.20 + 0.5 μA
0.15 + 5 μA
0.05 + 5 μA
0.07 + 5 μA
0.30 + 5 μA
0.70 + 5 μA
1.00 + 0.5 μA
0.15 + 50 μA
0.05 + 50 μA
0.02 + 50 μA
0.03 + 50 μA
0.10 + 50 μA
0.60 + 50 μA
0.20 + 500 μA
0.07 + 500 μA
1.00 + 500 μA
2.00 + 500 μA
0.20 + 500 μA
0.07 + 500 μA
1.00 + 500 μA
2.00 + 500 μA
45 to 100 Hz 0.05 + 2000 0.06 + 2000 0.2 + 3 mA
3 to 10.9999 A
100 Hz to 1 kHz 0.08 + 2000 0.10 + 2000 0.1 + 3 mA
1 kHz to 5 kHz 2.5 + 2000 3.0 + 2000 0.8 + 3 mA
0.1 + 5000 0.12 + 5000 0.2 + 3 mA
11 to 20.5 A
45 to 100 Hz
[1]
100 Hz to 1 kHz 0.13 + 5000 0.15 + 5000 0.1 + 3 mA
1 to 5 kHz 2.5 + 5000 3.0 + 5000 0.8 + 3 mA
[1] Duty Cycle: Currents <11 A may be provided continuously. For currents >11 A, see Figure 1-3. The current may be
provided 60-T-I minutes any 60 minute period where T is the temperature in °C (room temperature is about 23 °C) and I is
the output current in amps. For example, 17 A, at 23 °C could be provided for 60-17-23 = 20 minutes each hour. When the
5502A is outputting currents between 5 and 11 amps for long periods, the internal self-heating reduces the duty cycle.
Under those conditions, the allowable "on" time indicated by the formula and Figure 1-3 is achieved only after the 5502A is
outputting currents <5 A for the "off" period first.
[2] For compliance voltages greater than 1 V, add 1 mA/V to the floor specification from 1 to 5 kHz.
[3] For compliance voltages greater than 1 V, add 5 mA/V to the floor specification from 5 to 10 kHz.
Max
Inductive
Load μH
200
200
50
50
2.5
2.5
1
1
1-15
Page 32
5502A
Operators Manual
AC Current (Sine Wave) (cont.)
29 to 329.99 μA
3.29999 mA
32.9999 mA
33 to 329.999 mA
3.3 A to 20.5 A
Absolute Uncertainty, tcal
Range Frequency
±5 °C ±(% of output + μA)
90 Day 1 Year
Max Distortion and
Noise 10 Hz to
100 kHz BW ±(% of
output + floor)
Max Inductive Load
LCOMP On
10 to 100 Hz 0.20 + 0.2 0.25 + 0.2
100 Hz to 1 kHz 0.50 + 0.5 0.60 + 0.5
330 μA to
10 to 100 Hz 0.20 + 0.3 0.25 + 0.3
100 Hz to 1 kHz 0.50 + 0.8 0.60 + 0.8
3.3 to
10 to 100 Hz 0.07 + 4 0.08 + 4
100 Hz to 1 kHz 0.18 + 10 0.20 + 10
10 to 100 Hz 0.07 + 40 0.08 + 40
100 Hz to 1 kHz 0.18 + 100 0.20 + 100
330 mA to
2.99999 A
[1] Duty Cycle: Currents <11 A may be provided continuously. For currents >11 A, see Figure 1-3. The current may be
provided 60-T-I minutes any 60 minute period where T is the temperature in °C (room temperature is about 23 °C) and I is
the output current in amps. For example, 17 A, at 23 °C could be provided for 60-17-23 = 20 minutes each hour. When the
5502A is outputting currents between 5 and 11 amps for long periods, the internal self-heating reduces the duty cycle.
Under those conditions, the allowable "on" time indicated by the formula and Figure 1-3 is achieved only after the 5502A is
outputting currents <5 A for the "off" period first.
[2] For currents >11 A, Floor specification is 4000 μA within 30 seconds of selecting operate. For operating times >30 seconds,
the floor specification is 2000 μA.
[3] For currents >11 A, Floor specification is 1000 μA within 30 seconds of selecting operate. For operating times >30 seconds,
the floor specification is 5000 μA.
[4] Subject to compliance voltages limits.
29 to 329.99 μA
10 to 100 Hz 0.10 + 200 0.12 + 200
100 to 440 Hz 0.25 + 1000 0.30 + 1000
[1]
Range
45 to 100 Hz
100 to 440 Hz
0.10 + 2000
0.80 + 5000
[2]
[3]
Resolution μA
0.01 7
0.12 + 2000
1.00 + 5000
[2]
[3]
0.1 + 1.0 μA
0.05 + 1.0 μA
0.15 + 1.5 μA
0.06 + 1.5 μA
0.15 + 5 μA
0.05 + 5 μA
400 μH
0.15 + 50 μA
0.05 + 50 μA
0.2 + 500 μA
0.25 + 500 μA
0.1 + 0 μA
0.5 + 0 μA
400 μH
Max Compliance Voltage V rms
[4]
[1]
0.33 to 3.29999 mA 0.01 7
3.3 to 32.9999 mA 0.1 5
33 to 329.999 mA 1 5
0.33 to 2.99999 A 10 4
3 to 20.5 A 100 3
[1] Subject to specification adder for compliance voltages greater than 1 V rms.
1-16
Page 33
Introduction and Specifications
Detailed Specifications 1
Capacitance
Absolute Uncertainty, tcal ±5 °C
Range
220.0 to 399.9 pF 0.38 + 0.01 nF 0.5 + 0.01 nF 0.1 pF 10 Hz to 10 kHz 20 kHz 40 kHz
0.4 to 1.0999 nF 0.38 + 0.01 nF 0.5 + 0.01 nF 0.1 pF 10 Hz to 10 kHz 30 kHz 50 kHz
1.1 to 3.2999 nF 0.38 + 0.01 nF 0.5 + 0.01 nF 0.1 pF 10 Hz to 3 kHz 30 kHz 50 kHz
3.3 to 10.999 nF 0.19 + 0.01 nF 0.25 + 0.01 nF 1 pF 10 Hz to 1 kHz 20 kHz 25 kHz
11 to 32.999 nF 0.19 + 0.1 nF 0.25 + 0.1 nF 1 pF 10 Hz to 1 kHz 8 kHz 10 kHz
33 to 109.99 nF 0.19 + 0.1 nF 0.25 + 0.1 nF 10 pF 10 Hz to 1 kHz 4 kHz 6 kHz
110 to 329.99 nF 0.19 + 0.3 nF 0.25 + 0.3 nF 10 pF 10 Hz to 1 kHz 2.5 kHz 3.5 kHz
0.33 to
1.0999 μF
1.1 to 3.2999 μF
3.3 to 10.999 μF
11 to 32.999 μF
33 to 109.99 μF
110 to 329.99 μF
0.33 to
1.0999 mF
1.1 to 3.2999 mF
3.3 to 10.999 mF
11 to 32.999 mF
33 to 110.00 mF
[1] The output is continuously variable from 220 pF to 110 mF.
[2] Specifications apply to both dc charge/discharge capacitance meters and ac RCL meters. The maximum allowable peak voltage is
3 V. The maximum allowable peak current is 150 mA, with an rms limitation of 30 mA below 1.1 μF and 100 mA for 1.1 μF and
above.
[3] The maximum lead resistance for no additional error in 2-wire COMP mode is 10 Ω.
±(% of output + floor)
90 Day 1 Year
0.19 + 1 nF 0.25 + 1 nF 100 pF 10 to 600 Hz 1.5 kHz 2 kHz
0.19 + 3 nF 0.25 + 3 nF 100 pF 10 to 300 Hz 800 Hz 1 kHz
0.19 + 10 nF 0.25 + 10 nF 1 nF 10 to 150 Hz 450 Hz 650 Hz
0.30 + 30 nF 0.40 + 30 nF 1 nF 10 to 120 Hz 250 Hz 350 Hz
0.34 + 100 nF 0.45 + 100 nF 10 nF 10 to 80 Hz 150 Hz 200 Hz
0.34 + 300 nF 0.45 + 300 nF 10 nF 0 to 50 Hz 80 Hz 120 Hz
0.34 + 1 μF 0.45 + 1 μF
0.34 + 3 μF 0.45 + 3 μF
0.34 + 10 μF 0.45 + 10 μF 1 μF
0.7 + 30 μF 0.75 + 30 μF 1 μF
1.0 + 100 μF 1.1 + 100 μF 10 μF
[1] [2] [3]
Resolution
100 nF 0 to 20 Hz 45 Hz 65 Hz
100 nF 0 to 6 Hz 30 Hz 40 Hz
Allowed Frequency or Charge-Discharge Rate
Min and Max to
Meet
Specification
0 to 2 Hz 15 Hz 20 Hz
0 to 0.6 Hz 7.5 Hz 10 Hz
0 to 0.2 Hz 3 Hz 5 Hz
Typical Max for
<0.5 % Error
Typical Max for
<1 % Error
1-17
Page 34
5502A
Operators Manual
Temperature Calibration (Thermocouple)
TC Type
[1] Temperature standard ITS-90 or IPTS-68 is selectable.
[2] Resolution is 0.01 °C
[3] Does not include thermocouple error
Range °C
[1]
[2]
Absolute Uncertainty
Source/Measure tcal ±5 °C ±
°C
[3]
90 Day 1 Year 90 Day 1 Year
600 to 800 0.42 0.44
B
800 to 1000 0.34 0.34 -100 to 800 0.26 0.26
1000 to 1550 0.30 0.30 800 to 900 0.17 0.17
1550 to 1820 0.26 0.33
TC
Type
[1]
L
Range °C
[2]
-200 to -100 0.37 0.37
-200 to -100 0.30 0.40
0 to 150 0.23 0.30 -100 to -25 0.17 0.22
150 to 650 0.19 0.26 -25 to 120 0.15 0.19
C
650 to 1000 0.23 0.31 120 to 410 0.14 0.18
N
1000 to 1800 0.38 0.50 410 to 1300 0.21 0.27
1800 to 2316 0.63 0.84
-250 to -100 0.38 0.50 250 to 400 0.28 0.35
-100 to -25 0.12 0.16 400 to 1000 0.26 0.33
E
-25 to 350 0.10 0.14 1000 to 1767 0.30 0.40
R
350 to 650 0.12 0.16
650 to 1000 0.16 0.21 250 to 1000 0.30 0.36
-210 to -100 0.20 0.27 1000 to 1400 0.28 0.37
S
0 to 250 0.48 0.57
0 to 250 0.47 0.47
-100 to -30 0.12 0.16 1400 to 1767 0.34 0.46
J
-30 to 150 0.10 0.14
150 to 760 0.13 0.17 -150 to 0 0.18 0.24
760 to 1200 0.18 0.23 0 to 120 0.12 0.16
-250 to -150 0.48 0.63
T
-200 to -100 0.25 0.33 120 to 400 0.10 0.14
-100 to -25 0.14 0.18
K
-25 to 120 0.12 0.16 0 to 600 0.27 0.27
U
-200 to 0 0.56 0.56
120 to 1000 0.19 0.26
1000 to 1372 0.30 0.40
TC simulating and measuring are not specified for operation in electromagnetic fields above 0.4 V/m.
Absolute Uncertainty
Source/Measure tcal
±5 °C ± °C
[3]
1-18
Page 35
Introduction and Specifications
Detailed Specifications 1
Temperature Calibration (RTD)
RTD Type
Range °C
Absolute Uncertainty tcal
[1]
±5 °C ± °C
[2]
RTD Type
Range °C
90 Day 1 Year 90 Day 1 Year
-200 to -80 0.04 0.05
-200 to -80 0.03 0.04
-80 to 0 0.05 0.05 -80 to 0 0.04 0.05
Pt 385,
100 Ω
0 to 100 0.07 0.07 0 to 100 0.05 0.05
100 to 300 0.08 0.09 100 to 260 0.06 0.06
300 to 400 0.09 0.10 260 to 300 0.07 0.08
Pt 385,
500 Ω
400 to 630 0.10 0.12 300 to 400 0.07 0.08
630 to 800 0.21 0.23 400 to 600 0.08 0.09
-200 to -80 0.04 0.05 600 to 630 0.09 0.11
Pt 3926,
100 Ω
-80 to 0 0.05 0.05
0 to 100 0.07 0.07 -80 to 0 0.03 0.03
100 to 300 0.08 0.09 0 to 100 0.03 0.04
300 to 400 0.09 0.10 100 to 260 0.04 0.05
400 to 630 0.10 0.12 260 to 300 0.05 0.06
Pt 385,
1000 Ω
-200 to -80 0.03 0.03
-200 to -190 0.25 0.25 300 to 400 0.05 0.07
-190 to -80 0.04 0.04 400 to 600 0.06 0.07
-80 to 0 0.05 0.05 600 to 630 0.22 0.23
Pt 3916,
100 Ω
0 to 100 0.06 0.06
100 to 260 0.06 0.07 0 to 100 0.07 0.08
260 to 300 0.07 0.08 100 to 260 0.13 0.14
300 to 400 0.08 0.09
400 to 600 0.08 0.10
PtNi 385,
120 Ω
(Ni120)
Cu 427
[3]
10 Ω
-80 to 0 0.06 0.08
-100 to 260 0.3 0.3
600 to 630 0.21 0.23
-200 to -80 0.03 0.04
-80 to 0 0.03 0.04
0 to 100 0.04 0.04
Pt 385,
200 Ω
100 to 260 0.04 0.05
260 to 300 0.11 0.12
300 to 400 0.12 0.13
400 to 600 0.12 0.14
600 to 630 0.14 0.16
[1] Resolution is 0.003 °C
[2] Applies for COMP OFF (to the 5502A Calibrator front panel NORMAL terminals) and 2-wire and 4-wire compensation.
[3] Based on MINCO Application Aid No. 18
Absolute Uncertainty
[1]
tcal ±5 °C ± °C
[2]
Phase
10 to 65 Hz 65 to 500 Hz 500 Hz to 1 kHz 1 to 5 kHz 5 to 10 kHz 10 to 30 kHz
0.15 ° 0.9 ° 2 ° 6 ° 10 ° 15 °
Note
See Power and Dual Output Limit Specifications for applicable outputs.
1-Year Absolute Uncertainty, tcal ±5 °C, (Δ Φ °)
Frequency (Hz)
1-19
Page 36
5502A
Operators Manual
Phase (Φ)
Watts
Phase (Φ)
VARs
0.00 % 0.01 % 0.06 % 0.55 % 1.52 %
5 ° 85 °
10 ° 80 °
15 ° 75 °
20 ° 70 °
25 ° 65 °
30 ° 60 °
35 ° 55 °
40 ° 50 °
45 ° 45 °
50 ° 40 °
55 ° 35 °
60 ° 30 °
65 ° 25 °
70 ° 20 °
75 ° 15 °
80 ° 10 °
85 ° 5 °
90 ° 0 °
To calculate exact ac watts power adders due to phase uncertainty for values not shown, use the subsequent formula:
()
Adder
For example: For a PF of .9205 (Φ = 23) and a phase uncertainty of
()
Adder
PF
0.996
0.985
0.966
0.940
0.906
0.866
0.819
0.766
0.707
0.643
0.574
0.500
0.423
0.342
0.259
0.174
0.087
0.000 — —
−=
1(100%
1(100% =
−=
10 to 65 Hz 65 to 500 Hz 500 Hz to 1 kHz 1 to 5 kHz 5 to 10 kHz
0.02 % 0.15 % 0.37 % 1.46 % 3.04 %
0.05 % 0.29 % 0.68 % 2.39 % 4.58 %
0.07 % 0.43 % 1.00 % 3.35 % 6.17 %
0.10 % 0.58 % 1.33 % 4.35 % 7.84 %
0.12 % 0.74 % 1.69 % 5.42 % 9.62 %
0.15 % 0.92 % 2.08 % 6.58 % 11.54 %
0.18 % 1.11 % 2.50 % 7.87 % 13.68 %
0.22 % 1.33 % 2.99 % 9.32 % 16.09 %
0.26 % 1.58 % 3.55 % 11.00 % 18.88 %
0.31 % 1.88 % 4.22 % 13.01 % 22.21 %
0.37 % 2.26 % 5.05 % 15.48 % 26.32 %
0.45 % 2.73 % 6.11 % 18.65 % 31.60 %
0.56 % 3.38 % 7.55 % 22.96 % 38.76 %
0.72 % 4.33 % 9.65 % 29.27 % 49.23 %
0.98 % 5.87 % 13.09 % 39.56 % 66.33 %
1.49 % 8.92 % 19.85 % 59.83 % 100.00 %
2.99 % 17.97 % 39.95 %
Cos
Cos
Cos
Cos
ΔΦ+Φ
()
Φ
+
()
23
Power Uncertainty Adder due to Phase Error
)(
)
= 0.15, the ac watts power adder is:
ΔΦ
)15.(23
%11.0)
1-20
AC and DC Power Specifications
Power is simulated through the controlled simultaneous outputs of voltage and current from the Calibrator. While the
amplitude and frequency ranges of the outputs are broad, there are certain combinations of voltage and current where the
specifications are valid. In general these are for all dc voltages and currents, and AC voltages of 30 mV to 1020 V, ac
currents from 33 mA to 20.5 A, for frequencies from 10 Hz to 30 kHz. Operation outside of these areas, within the overall
calibrator capabilities, is possible, but it is not specified. The table and figure below illustrate the specified areas where
power and dual output are possible.
Specification Limits for Power and Dual Output Operation
Frequency Voltages (NORMAL) Currents Voltages (AUX)
dc
10 to 45 Hz 33 mV to 32.9999 V 3.3 mA to 2.99999 A 10 mV to 5 V 0 to 1
45 to 65 Hz 33 mV to 1020 V 3.3 mA to 20.5 A 10 mV to 5 V 0 to 1
65 to 500 Hz 330 mV to 1020 V 33 mA to 2.99999 A 100 mV to 5 V 0 to 1
65 to 500 Hz 3.3 to 1020 V 33 mA to 20.5 A 100 mV to 5 V 0 to 1
500 Hz to 1 kHz 330 mV to 1020 V 33 mA to 20.5 A 100 mV to 5 V 0 to 1
1 to 5 kHz 3.3 to 500 V 33 mA to 2.99999 A 100 mV to 5 V 0 to 1
5 to 10 kHz 3.3 to 250 V 33 to 329.99 mA 1 to 5 V 0 to 1
10 to 30 kHz 3.3 V to 250 V 33 mA to 329.99 mA 1 V to 3.29999 V 0 to 1
Notes
The range of voltages and currents shown in “DC Voltage Specifications,” “DC Current Specifications,” “AC Voltage (Sine Wave)
Specifications,” and “AC Current (Sine Wave) Specifications” are available in the power and dual output modes (except minimum
current for ac power is 0.33 mA). Only those limits shown in this table and illustrated in the following figure are specified.
See “Calculate Power Uncertainty” to determine the uncertainty at these points.
The phase adjustment range for dual ac outputs is 0 ° to ±179.99 °. The phase resolution for dual ac outputs is 0.01 °.
0 to ±1020 V 0 to ±20.5 A 0 to ±7 V
Power Factor
(PF)
⎯
Page 37
Introduction and Specifications
Detailed Specifications 1
1020 V
33 mA - 20.5 A
3.3 V
33 mA - 3 A
330 mV
Not Specified
500 V
33 mA - 3 A
Not Specified
Frequency
250 V
33 mA - 330 mA
AC
Voltage
100 mV
10 mV
and
Below
1000
100
1.0
10
10 Hz
32.999 V
3.3 mA - 20.5 A
3.3 mA - 3 A
33 mV
45 65 100 500 1 K 5 K 10 K - 30 K 100 K 500 K
Figure 1-4. Permissible Combinations of AC Voltage and AC Current for Power and Dual Output
Calculate the Uncertainty Specifications of Power and Dual Output Settings
Overall uncertainty for power output in watts (or VARs) is based on the root sum square (rss) of the individual
uncertainties in percent for the selected voltage, current, and, if AC power, the phase parameters:
Watts uncertainty
2
Voltagepower UUUU
2
Current
2
Phase
++=
VARs uncertainty
Dual Output uncertainty
2
VoltageVARs UUUU
2
Current
2
VoltageDual UUUU
2
++=
2
AuxVoltage
Phase
2
Phase
++=
Because there are an infinite number of combinations, you must calculate the actual ac power uncertainty for your
selected parameters. The results of this method of calculation are shown in the subsequent example. These examples are
at various selected calibrator settings (with 1-year specifications):
1-21
Page 38
5502A
V
Operators Manual
Examples of Specified Power Uncertainties at Various Output Settings:
oltage
Setting
(Volts)
+10.000 +0.500.000 DC
15.000 +2.0000 DC 30 0.00533 % 0.03220 % 0.033 %
100.000 +20.000 DC 2000 0.00600 % 0.10375 % 0.104 %
1000.00 20.000 DC 20000 0.00565 % 0.10375 % 0.104 %
120.000 1.00000 60 1 0.0 120 0.05250 % 0.06000 % 0.000 % 0.080 %
120.000 1.00000 60 0.766 40.0 91.92 0.05250 % 0.06000 % 0.220 % 0.234 %
240.000 1.00000 50 1 0.0 240 0.05125 % 0.06000 % 0.000 % 0.079 %
240.000 1.00000 50 0.766 40.0 183.84 0.05125 % 0.06000 % 0.220 % 0.234 %
1000.00 20 55 1 0.0 20000 0.05200 % 0.14500 % 0.000 % 0.154 %
1000.00 20 55 0.766 40.0 15320 0.05200 % 0.14500 % 0.220 % 0.269 %
1000.00 20 55 -0.906 -25.0 18120 0.05200 % 0.14500 % 0.122 % 0.196 %
100 0.30 30000 1 0.0 30.0 0.12900 % 0.4667 % 3.407 % 3.442 %
100 0.30 30000 0.766 40.0 22.98 0.12900 % 0.4667 % 25.128 % 25.133 %
[1] Add 0.02 % unless a settling time of 30 seconds is allowed for output currents >10 A or for currents on the highest two current
Selected Output Settings
Current
Setting
(Amps)
Frequency
Hz
Phase
Setting
(units of PF)
Phase
Setting
(Degrees)
ranges within 30 seconds of an output current >10 A.
Absolute Uncertainty as
specified for tcal ±5 °C, ±(% of
output setting)
Selected
U
Power
U
Voltage
(Watts)
5 0.00550 % 0.04680 %
U
Current
Power
Absolute
Uncerainty
±(% of
Watts)
U
Phase
Power
0.047 %
[1]
Calculate Power Uncertainty
Overall uncertainty for power output in watts (or VARs) is based on the root sum square (RSS) of the individual
uncertainties in percent for the selected voltage, current, and phase parameters:
Watts uncertainty
VARs uncertainty
2
VoltagePower UUUU
2
VoltageVARs UUUU
2
Current
2
Current
Because there are an infinite number of combinations, you must calculate the actual ac power uncertainty for your
selected parameters. The method of calculation is best shown in the subsequent examples (with 1-year specifications):
Example 1 Output: 100 V, 1 A, 60 Hz, Power Factor = 1.0 (Φ=0).
Voltage Uncertainty Uncertainty for 100 V at 60 Hz is 0.050 % + 3 mV, totaling: 100 V x .0.0005 = 50 mV added to
3 mV = 53 mV. Expressed in percent: 53 mV/100 V x 100 = 0.053 % (see “AC Voltage (Sine Wave) Specifications”).
Current Uncertainty Uncertainty for 1 A at 60 Hz is 0.05 % +100 μA, totaling: 1 A x 0.0005 = 500 μA added to
100 μA = 0.6 mA. Expressed in percent: 0. 6 mA/1 A x 100 = 0.06 % (see “AC Current (Sine Waves) Specifications”).
Phase Uncertainty (Watts) Adder for PF = 1 (Φ=0) at 60 Hz is 0 % (see “Phase Specifications”).
Total Power Uncertainty =
power
2
Example 2 Output: 100 V, 1 A, 400 Hz, Power Factor = 0.5 (Φ=60)
Voltage Uncertainty Uncertainty for 100 V at 400 Hz is 0.050% + 3 mV, totaling: 100 V x .0.0005 = 50 mV added to
3 mV = 53 mV. Expressed in percent: 53 mV/100 V x 100 = 0.053 % (see “AC Voltage (Sine Wave) Specifications”).
Current Uncertainty Uncertainty for 1 A at 400 Hz is 0.05 % +100 μA, totaling: 1 A x 0.0005 = 500 μA added to
100 μA = 0.6 mA. Expressed in percent: 0. 6 mA/1 A x 100 = 0.06 % (see “AC Current (Sine Waves) Specifications”).
Phase Uncertainty (Watts) Adder for PF = 0.5 (Φ=60) at 400 Hz is 2.73 % (see “Phase Specifications”).
Total Power Uncertainty =
power
2
VARs When the Power Factor approaches 0.0, the Watts output uncertainty becomes unrealistic because the dominant
characteristic is the VARs (volts-amps-reactive) output. In these cases, calculate the Total VARs Output Uncertainty, as
shown in example 3:
Example 3 Output: 100 V, 1 A, 60 Hz, Power Factor = 0.174 (Φ=80)
Voltage Uncertainty Uncertainty for 100 V at 60 Hz is 0.050% + 3 mV, totaling: 100 V x .0.0005 = 50 mV added to
3 mV = 53 mV. Expressed in percent: 53 mV/100 V x 100 = 0.053 % (see “AC Voltage (Sine Wave) Specifications”).
Current Uncertainty Uncertainty for 1 A at 60 Hz is 0.05 % +100 μA, totaling: 1 A x 0.0005 = 500 μA added to
100 μA = 0.6 mA. Expressed in percent: 0. 6 mA/1 A x 100 = 0.06 % (see “AC Current (Sine Waves) Specifications”).
2
Phase
++=
++=
22
=++=
22
=++=
2
Phase
%080.0006.0053.0U
%73.273.206.0021.0U
1-22
Page 39
Introduction and Specifications
Additional Specifications 1
Phase Uncertainty (VARs) Adder for Φ=80 at 60 Hz is 0.05 % (see “Phase Specifications”).
Total VARS Uncertainty =
VARs
2
22
=++
%094.005.006.0053.0=U
Additional Specifications
The subsequent paragraphs provide additional specifications for the 5502A Calibrator ac voltage and ac current functions.
These specifications are valid after allowing a warm-up period of 30 minutes, or twice the time the 5502A has been turned
off. All extended range specifications are based on performing the internal zero-cal function at weekly intervals, or when
the ambient temperature changes by more than 5 °C.
Frequency
Frequency Range Resolution
0.01 to 119.99 Hz 0.01 Hz
120.0 to 1199.9 Hz 0.1 Hz 25 + 1
1.2 to 11.999 kHz 1 Hz 25 + 1
12 to 119.99 kHz 10 Hz 25 + 15 140 ns
120.0 to 1199.9 kHz 100 Hz 25 + 15 140 ns
1.2 to 2.000 MHz 1 kHz 25 + 15 140 ns
Harmonics (2nd to 50th)
Fundamental
Frequency
10 to 45 Hz 33 mV to 32.9999 V 3.3 mA to 2.99999 A 10 mV to 5 V
45 to 65 Hz 33 mV to 1020 V 3.3 mA to 20.5 A 10 mV to 5 V
65 to 500 Hz 33 mV to 1020 V 33 mA to 20.5 A 100 mV to 5 V
500 Hz to 5 kHz 330 mV to 1020 V 33 mA to 20.5 A 100 mV to 5 V
5 to 10 kHz 3.3 to 1020 V 33 to 329.9999 mA 100 mV to 5 V
10 to 30 kHz 3.3 to 1020 V 33 to 329.9999 mA 100 mV to 3.29999 V
[1] The maximum frequency of the harmonic output is 30 kHz (10 kHz for 3.3 to 5 V on the Aux terminals). For example, if the
Phase Uncertainty ................................................. Phase uncertainty for harmonic outputs is 1 degree or the phase
Example of determining Amplitude Uncertainty in a Dual Output Harmonic Mode
What are the amplitude uncertainties for the following dual outputs?
NORMAL (Fundamental) Output:
100 V, 100 Hz ................................................. From “AC Voltage (Sine Wave) 90 Day Specifications” the single
AUX (50th Harmonic) Output:
100 mV, 5 kHz ................................................ From “AC Voltage (Sine Wave) 90 Day Specifications” the auxiliary
[1]
fundamental output is 5 kHz, the maximum selection is the 6th harmonic (30 kHz). All harmonic frequencies (2nd to 50th) are
available for fundamental outputs between 10 Hz and 600 Hz (200 Hz for 3.3 to 5 V on the Aux terminals).
Voltages NORMAL
Terminals
Currents
uncertainty shown in “Phase Specifications” for the particular output,
whichever is greater. For example, the phase uncertainty of a 400 Hz
fundamental output and 10 kHz harmonic output is 10 ° (from “Phase
Specifications”). Another example, the phase uncertainty of a 50 Hz
fundamental output and a 400 Hz harmonic output is 1 degree.
output specification for 100 V, 100 Hz, is 0.039 % + 3 mV. For the dual
output in this example, the specification is 0.039 % + 6 mV as the
0.039 % is the same, and the floor is twice the value (2 x 3 mV).
output specification for 100 mV, 5 kHz, is 0.15 % + 450 μV. For the
dual output in this example, the specification is 0.15 % + 900 μV as the
0.15 % is the same, and the floor is twice the value (2 x 450 μV).
1-Year Absolute Uncertainty, tcal
±5 °C ±(ppm + mHz)
25 + 1
Voltages AUX
Terminals
Same % of
output as the
equivalent single
output, but twice
the floor adder.
Jitter
2 μs
2 μs
2 μs
Amplitude
Uncertainty
1-23
Page 40
5502A
Y
Operators Manual
AC Voltage (Sine Wave) Extended Bandwidth
AC Voltage (Non-Sine Wave)
Triangle Wave &
93 to 929.999 mV
0.93 to 9.29999 V
29 to 929.999 mV
0.93 to 9.29999 V
ear Absolute Uncertainty
Range Frequency
1-
tcal ±5 °C
Max Voltage Resolution
Normal Channel (Single Output Mode)
1.0 to 33 mV
34 to 330 mV Three digits
0.01 to 9.99 Hz
0.4 to 33 V Two digits
0.3 to 3.3 V
500.1 kHz to 1 MHz -10 dB at 1 MHz, typical
1.001 to 2 MHz -31 dB at 2 MHz, typical
±(5.0 % of output
+0.5 % of range)
Two digits, e.g., 25 mV
Two digits
Auxiliary Output (Dual Output Mode)
10 to 330 mV
0.4 to 5 V Two digits
0.01 to 9.99 Hz
±(5.0 % of output
+0.5 % of range)
Three digits
1-Year Absolute Uncertainty,
Truncated Sine
Range, p-p
[1]
Frequency
tcal ±5 °C, ±(% of output + % of
range)
[2]
Max Voltage Resolution
Normal Channel (Single Output Mode)
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
2.9 to 92.999 mV
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz
[3]
5.0 + 0.5
Six digits on each range
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz
[3]
5.0 + 0.5
Six digits on each range
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz
[3]
5.0 + 0.5
Six digits on each range
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
9.3 to 93 V
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz
[3]
5.0 + 0.5
Six digits on each range
Auxiliary Output (Dual Output Mode)
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
Six digits on each range
1 to 10 kHz 5.0 + 0.5
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
Six digits on each range
1 to 10 kHz 5.0 + 0.5
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
9.3 to 14.0000 V
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
Six digits on each range
1 to 10 kHz 5.0 + 0.5
[1] To convert p-p to rms for triangle wave, multiply the p-p value by 0.2886751. To convert p-p to rms for truncated sine wave,
multiply the p-p value by 0.2165063.
[2] Uncertainty is stated in p-p. Amplitude is verified using an rms-responding DMM.
[3] Uncertainty for Truncated Sine outputs is typical over this frequency band.
1-24
Page 41
Introduction and Specifications
Additional Specifications 1
AC Voltage (Non-Sine Wave) (cont.)
Square Wave
Range (p-p)
2.9 to 65.999 mV
66 to 659.999 mV
0.66 to 6.59999 V
6.6 to 66.0000 V
29 to 659.999 mV
0.66 to 6.59999 V
6.6 to 14.0000 V
[1] To convert p-p to rms for square wave, multiply the p-p value by 0.5.
[2] Uncertainty is stated in p-p. Amplitude is verified using an rms-responding DMM.
[3] Limited to 1 kHz for Auxiliary outputs ≥6.6 V p-p.
[1]
Frequency
Normal Channel (Single Output Mode)
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz 5.0 + 0.5
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz 5.0 + 0.5
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz 5.0 + 0.5
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 20 kHz 0.5 + 0.25
20 to 100 kHz 5.0 + 0.5
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz
0.01 to 10 Hz 5.0 + 0.5 Two digits on each range
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz
[3]
[3]
[3]
1-Year Absolute Uncertainty, tcal
±5 °C, ±(% of output + % of range)
Auxiliary Output (Dual Output Mode)
5.0 + 0.5
5.0 + 0.5
5.0 + 0.5
Max Voltage Resolution
[2]
Six digits on each range
Six digits on each range
Six digits on each range
Six digits on each range
Six digits on each range
Six digits on each range
Six digits on each range
1-25
Page 42
5502A
Operators Manual
AC Voltage, DC Offset
[1]
Range
[1] Offsets are not allowed on ranges above the highest range shown above.
[2] The maximum offset value is determined by the difference between the peak value of the selected voltage output and the
[3] For frequencies 0.01 to 10 Hz, and 500 kHz to 2 MHz, the offset uncertainty is 5 % of output, ±1 % of the offset range.
(Normal Channel) Offset Range
Sine Waves (rms)
3.3 to 32.999 mV 0 to 50 mV 80 mV
33 to 329.999 mV 0 to 500 mV 800 mV
0.33 to 3.29999 V 0 to 5 V 8 V
3.3 to 32.9999 V 0 to 50 V 55 V 0.1 + 33 mV
Triangle Waves and Truncated Sine Waves (p-p)
9.3 to 92.999 mV 0 to 50 mV 80 mV
93 to 929.999 mV 0 to 500 mV 800 mV
0.93 to 9.29999 V 0 to 5 V 8 V
9.3 to 93.0000 V 0 to 50 V 55 V 0.1 + 93 mV
Square Waves (p-p)
6.6 to 65.999 mV 0 to 50 mV 80 mV
66 to 659.999 mV 0 to 500 mV 800 mV
0.66 to 6.59999 V 0 to 5 V 8 V
6.6 to 66.0000 V 0 to 50 V 55 V 0.1 + 66 mV
allowable maximum peak signal. For example, a 10 V p-p square wave output has a peak value of 5 V, allowing a maximum
offset up to ± 50 V to not exceed the 55 V maximum peak signal. The maximum offset values shown above are for the
minimum outputs in each range.
[2]
Max Peak
Signal
1-Year Absolute Uncertainty, tcal
[3]
±5 °C
±(% of dc output + floor)
0.1 + 33 μV
0.1 + 330 μV
0.1 + 3300 μV
0.1 + 93 μV
0.1 + 930 μV
0.1 + 9300 μV
0.1 + 66 μV
0.1 + 660 μV
0.1 + 6600 μV
AC Voltage, Square Wave Characteristics
Risetime @
1 kHz
Typical
<1 μs
Settling Time @
1 kHz Typical
<10 μs to 1 % of
final value
Overshoot
@ 1 kHz
Typical
<2 %
Duty Cycle Range Duty Cycle Uncertainty
1 % to 99 % <3.3 V p-p.
0,01 Hz to 100 kHz
±(0.02 % of period + 100 ns), 50 % duty cycle
±(0.05 % of period + 100 ns), other duty cycles
from 10 % to 90 %
AC Voltage, Triangle Wave Characteristics (typical)
Linearity to 1 kHz Aberrations
0.3 % of p-p value, from 10 % to 90 % point <1 % of p-p value, with amplitude >50 % of range
1-26
Page 43
Introduction and Specifications
Additional Specifications 1
AC Current (Non-Sine Wave)
Triangle Wave &
Truncated Sine Wave
Frequency
Range p-p
10 to 45 Hz 0.25 + 0.5
0.047 to 0.92999 mA
[1]
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz 10 + 2
10 to 45 Hz 0.25 + 0.5
0.93 to 9.29999 mA
[1]
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz 10 + 2
10 to 45 Hz 0.25 + 0.5
9.3 to 92.9999 mA
[1]
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz 10 + 2
10 to 45 Hz 0.25 + 0.5
93 to 929.999 mA
[1]
45 Hz to 1 kHz 0.25 + 0.5
1 to 10 kHz 10 + 2
10 to 45 Hz 0.5 + 1.0
0.93 to 8.49999 A
[2]
45 Hz to 1 kHz 0.5 + 0.5
1 to 10 kHz 10 + 2
8.5 to 57 A
[1] Frequency limited to 1 kHz with LCOMP on.
[2] Frequency limited to 440 Hz with LCOMP on.
[2]
45 to 500 Hz 0.5 + 0.5
500 Hz to 1 kHz 1.0 + 1.0
1-Year Absolute Uncertainty tcal ±5 °C
±(% of output + % of range)
Max Current
Resolution
Six digits
Six digits
Six digits
Six digits
Six digits
1-27
Page 44
5502A
Operators Manual
AC Current (Non-Sine Wave) (cont.)
Square Wave Range p-p Frequency
0.047 to 0.65999 mA
0.66 to 6.59999 mA
6.6 to 65.9999 mA
66 to 659.999 mA
0.66 to 5.99999 A
10 to 45 Hz 0.25 + 0.5
[1]
[1]
[1]
[1]
[2]
6 to 41 A
[1] Frequency limited to 1 kHz with LCOMP on.
[2] Frequency limited to 440 Hz with LCOMP on.
[2]
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz 10 + 2
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz 10 + 2
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.25
1 to 10 kHz 10 + 2
10 to 45 Hz 0.25 + 0.5
45 Hz to 1 kHz 0.25 + 0.5
1 to 10 kHz 10 + 2
10 to 45 Hz 0.5 + 1.0
45 Hz to 1 kHz 0.5 + 0.5
1 to 10 kHz 10 + 2
45 to 500 Hz 0.5 + 0.5
500 Hz to 1 kHz 1.0 + 1.0
1-Year Absolute Uncertainty tcal ±5 °C
±(% of output + % of range)
Max Current
Resolution
Six digits
Six digits
Six digits
Six digits
AC Current, Square Wave Characteristics (typical)
Range LCOMP Risetime Settling Time Overshoot
I <6 A @ 400 Hz off
3 A & 20 A Ranges on
25 μs 40 μs to 1 % of final value
100 μs 200 μs to 1 % of final value
<10 % for <1 V Compliance
<10 % for <1 V Compliance
AC Current, Triangle Wave Characteristics (typical)
Linearity to 400 Hz Aberrations
0.3 % of p-p value, from 10 % to 90 % point <1 % of p-p value, with amplitude >50 % of range
1-28
Page 45
Chapter 2
Prepare for Operation
Title Page
Introduction .......................................................................................................... 2-3
Unpack and Inspection ......................................................................................... 2-3
Select Line Voltage .............................................................................................. 2-4
Connect to Line Power ........................................................................................ 2-4
Select Line Frequency ......................................................................................... 2-5
Placement ............................................................................................................. 2-6
Airflow Considerations ........................................................................................ 2-7
2-1
Page 46
5502A
Operators Manual
2-2
Page 47
Introduction
This chapter has instructions to unpack and install the Calibrator, select the line voltage,
replace the fuse, and connect to line power. Instructions for cable connections other than
line power are in these chapters:
• UUT (Unit Under Test) connections: Chapter 4, “Front Panel Operation”
• IEEE-488 parallel interface connection: Chapter 5, “Remote Operation”
• RS-232 serial interface connection: Chapter 5, “Remote Operation”
To prevent possible electrical shock, fire, or personal injury:
• Properly terminate the sense leads to prevent exposure to
hazardous voltages on the sense terminals. The voltage
sense terminals are at output voltage when the two-wire
function is set.
• Do not touch exposed metal on banana plugs, they can have
voltages that could cause death.
• Do not use a two-conductor mains power cord unless you
install a protective ground wire to the Product ground
terminal before you operate the Product.
• Make sure that the Product is grounded before use.
Warning
Unpack and Inspection
The calibrator is shipped in a container to prevent damage. Examine the calibrator
carefully for damage and immediately report damage to the shipper. Instructions for
inspection and claims are included in the shipping container.
When you unpack the calibrator, make sure that you have all the standard equipment in
Table 2-1. Examine the shipping list to make sure other items that you purchased are
included. Refer to the “Accessories” section in Chapter 8 for more information. Report
missing items to the point of purchase or to the nearest Fluke Calibration Service Center
(see “Contact Fluke Calibration” in Chapter 1). A performance test is in the
“Maintenance” section of Chapter 7.
If you ship the calibrator to Fluke Calibration, use the initial container. If it is not
available, you can get a new container from Fluke Calibration with the Calibrator model
and serial number.
Table 2-1. Standard Equipment
Item Model or Part Number
Calibrator 5502A
Mains Power Cord See Table 2-2 and Figure 2-2
5502A Getting Started Manual 4155209
5502A Operators Manual on CD-ROM 4155227
2-3
Page 48
5502A
Operators Manual
Select Line Voltage
The calibrator comes from the factory configured for the line voltage typically applicable
for the country of purchase, or as specified at the time of your purchase order. You can
operate the Calibrator from one of four line-voltage settings: 100 V, 120 V, 200 V, and
240 V (47 Hz to 63 Hz). To verify the line-voltage setting, note the voltage setting that
you can see through the window in the power-line fuse compartment cover (Figure 2-1).
The permitted line-voltage variation is 10 % above or below the line-voltage setting.
To change the line-voltage setting, complete the following procedure:
1. Disconnect line power.
2. To open the fuse compartment, put a screwdriver blade in the tab on the left side of
the compartment and pry until it can be removed.
3. To remove the line-voltage selector assembly, hold the line-voltage indicator tab with
pliers and pull it straight out of its connector.
4. Turn the line-voltage selector assembly to the necessary voltage and reinsert.
5. Make sure to use the correct fuse for the selected line voltage (100 V/120 V, use
5 A/250 V slow blow, 220 V/240 V, use 2.5 A/250 V slow blow). To install the fuse
compartment, push it into position until the tab locks.
Connect to Line Power
To prevent possible electrical shock, fire, or personal injury:
• Do not use a two-conductor mains power cord unless you
install a protective ground wire to the Product ground
terminal before you operate the Product.
• Do not use an extension cord or adapter plug.
Make sure that the Product is grounded before use. The calibrator is shipped with the
correct line-power plug for the country of purchase. If it is necessary to use a different
type, refer to Table 2-2 and Figure 2-2 for a list and illustration of the line-power plug
types available from Fluke Calibration.
After you make sure that the line voltage selection is set correctly and that the correct
fuse for that line voltage is installed, connect the calibrator to a correctly-grounded
three-prong outlet.
Warning
2-4
Page 49
Prepare for Operation
WARNING:
TO AVOID PHYSICAL INJURY, INSURE THA
IS PROPERLY INSTALLED BEFORE ENERGIZING INSTRU
CAUTION
FOR FIRE PROTECTION REPLACE O
WITH A 250V FUSE OF INDICATED RATING
Select Line Frequency 2
Select Line Frequency
The calibrator is shipped from the factory for nominal operation at 60 Hz line frequency.
If you use 50 Hz line voltage, re-configure the Calibrator for optimal performance at
50 Hz. To do this:
1. From the front panel, go into SETUP, INSTMT SETUP, OTHER SETUP.
2. Push the softkey below MAINS to change the selection to 50 Hz.
3. Store the change.
After a correct instrument warmup (on for 30 minutes or longer), you must zero the
complete instrument again. See the section on “Zero the Calibrator” in Chapter 4.
MAINS SUPPLY
FUSE
100V/120V
220V/240V
T5.0A 250V
(SB)
T2.5A 250V
47Hz
(SB)
/63Hz
600VA MAX
CHASSIS
GROUND
WARNING:
CONNECTOR IN POWER CORD MUST BE CONNECTED
Line Voltage
Indicator
Changing Line Fuse
Changing Line
Voltage
240
120
Figure 2-1. Access the Fuse and Select Line Voltage
TO AVOID ELECTRIC SHOCK GROUNDING
0V
(SB)
120
gjh004.eps
2-5
Page 50
5502A
Operators Manual
Table 2-2. Mains-Power Cord Types Available from Fluke Calibration
Type Voltage/Current
North America 120 V/15 A LC-1
North America 240 V/15 A LC-2
Universal Euro 220 V/15 A LC-3
United Kingdom 240 V/13 A LC-4
Switzerland 220 V/10 A LC-5
Australia 240 V/10 A LC-6
South Africa 240 V/5 A LC-7
LC-1 LC-2 LC-3 LC-4
Fluke Calibration Option
Number
LC-5 LC-6
Figure 2-2. Mains-Power Cord Types Available from Fluke Calibration
Placement
You can put the Product on a bench top or install it in a standard-width 24 inch (61 cm)
depth equipment rack. For bench-top use, the Calibrator has a non-slip feet. To install the
Calibrator in an equipment rack, use the 5502A Rack-Mount Kit, Model Y5537.
Instructions to install the Calibrator into a rack come with the kit.
LC-7
nn008f.eps
2-6
Page 51
Prepare for Operation
Airflow Considerations 2
Airflow Considerations
Warning
For safe operation and maintenance of the Product, make sure
that the space around the Product meets minimum
requirements.
Baffles put cool air from the fan into the chassis to internally dissipate heat when the
Calibrator is in operation. The accuracy and dependability of all internal parts of the
calibrator are enhanced by a cool internal temperature. You can increase the life of the
Calibrator and enhance its performance by these rules:
• The area around the air filter must be a minimum 3 inches from close walls or rack
enclosures.
• The exhaust perforations on the sides of the Calibrator must be clear of blockage.
• The air that gets to the Calibrator must be at room temperature. Make sure the
exhaust air from other instruments does not enter into the fan inlet.
• Clean the air filter after 30 days or more frequently if the calibrator is operated in a
dusty environment. (See the “Maintenance” chapter for instructions to clean the air
filter.)
2-7
Page 52
5502A
Operators Manual
2-8
Page 53
Chapter 3
Features
Title Page
Introduction .......................................................................................................... 3-3
Front-Panel Features ............................................................................................ 3-3
Rear-Panel Features ............................................................................................. 3-3
Softkey Menu Trees ............................................................................................. 3-3
3-1
Page 54
5502A
Operators Manual
3-2
Page 55
Features
Introduction 3
Introduction
Refer to this chapter for the functions and locations of the 5502A Calibrator front and
rear-panel features. Please read this information before you use the Calibrator. See the
“Front-Panel Operation” section of Chapter 4 for front-panel operation instructions. For
remote-operation instructions, see the “Remote Operation” section of Chapter 5.
Front-Panel Features
Front-panel features (including all controls, displays, indicators, and terminals) are shown
in Figure 3-1. Each front-panel feature is given in Table 3-1.
Rear-Panel Features
Rear-panel features (including all terminals, sockets, and connectors) are shown in
Figure 3-2. Each rear-panel feature is given in Table 3-2.
Softkey Menu Trees
The Setup softkeys are identified in Figures 3-3 and 3-4. The Setup softkeys go with the
Calibrator front-panel key. The functions of the five softkeys are identified by name
information shown directly above each key. The softkey names change during operation
so you can quickly access many different functions.
A group of softkey names is a menu. A group of connected menus is a menu tree.
Figure 3-3 shows the SETUP menu tree structure. Figure 3-4 tells you about each SETUP
menu tree display. Table 3-3 shows the factory-default parameters for the SETUP menu
tree. To change the SETUP menus to their default values, use the softkey SETUP in the
Format NV Memory menu (see Figure 3-4, menu F).
3-3
Page 56
5502A
Operators Manual
5502A
1 2
3 4 5 6 7 8 9
CALIBRATOR
m
M
k
TRIG
OUT
dBm sec
W
PREV
MENU
V Hz
F
A
ENTER
RESET
SETUP
NEW
MEAS
MULT
CE
REF
ZERO
TC
CAL
DIV
x
C
F
EDIT
FIELD
POWER
gvx005.eps
STBY
OPR EARTH
8 9
7
456
23
1
+
/
•
0
SCOPE
p
n
p
SHIFT
Figure 3-1. Front-Panel Features
Table 3-1. Front-Panel Features
Output Display
The Output Display is a two-line backlit LCD that shows output amplitudes, frequency, and
calibrator status. Output values (or potential output values if in standby) are shown with a
maximum of seven digits plus a polarity sign. Output frequencies (or potential output frequencies
if the Calibrator is in standby) are shown with four digits. Calibrator status is shown by these
abbreviations:
OPR Shown when an output is active at the front panel terminals.
STBY Shown when the Calibrator is in standby.
u When you change the output, “u” (unsettled) is shown until the output moves in to the
specified accuracy.
m Shown while the Calibrator measures. (Thermocouple and impedance measurement
only.)
? Shown when the amplitude is specified as typical only, and/or decreased resolution.
This occurs when you operate the Calibrator in extended-bandwidth mode.
C Shown when the amplitude is specified as typical only, and/or decreased resolution.
This occurs when you operate the Calibrator in extended-bandwidth mode.
Control Display
The Control Display is a multipurpose backlit LCD used to show data entries, UUT error
adjustments, softkey names, phase angles, watts, power factors, and other prompts and
messages. When there is not room on the Output Display, output frequency is shown on the
Control Display. Softkey names tell you the function of the softkey directly below them. Groups of
softkey names together make a menu. The menus give access to many different functions with the
five softkeys plus the PREV MENU key. (See Figure3-3, Softkey Menu Tree.)
3-4
Page 57
Features
Softkey Menu Trees 3
The STBY (Standby) key puts the Calibrator in standby mode. Standby mode is shown by “STBY”
in the lower left corner of the Output Display. In standby mode, the NORMAL, AUX and 20A
output terminals are internally disconnected from the Calibrator. The Calibrator starts in standby
mode. The Calibrator automatically changes to standby if:
• is pushed.
• A voltage ≥33 V is selected when the previous output voltage was <33 V.
• The output function changes. When you change from ac or dc voltage <33 V, the Calibrator
does not change to STBY.
• A current output more than 3 A is selected. This is when the output location changes to the
20A terminal.
• An overload condition is sensed.
The OPR (Operate) key puts the Calibrator in operate mode. Operate mode is shown by “OPR” in
the lower left corner of the Output Display and the illuminated indicator on .
The EARTH (Earth Ground) key opens and closes an internal connection from the NORMAL
LO terminal to earth ground. An indicator on the key shows when this connection is made. The
power-up default condition is earth disabled (indicator off).
The SCOPE (Oscilloscope) key starts or stops an oscilloscope calibration option (if it is installed).
An indicator on the key shows when the option is active. If an oscilloscope calibration option is not
installed in the Calibrator and the SCOPE key is pushed, the calibrator shows an error message.
The TRIG OUT (Trigger Out) key sets the external trigger when in the scope mode. An indicator
on the key shows when external trigger output is active. If the Calibrator is not in scope mode
when is pushed, the beeper will sound.
The PREV MENU (Previous Menu) key recalls the previous set of menu selections. Each push of
this key retreats up one level of the menu tree until the display shows the top-level menu selection
of the function selected.
Softkeys
The functions of the five unlabeled blue softkeys are shown by names on the Control Display
above each key. The functions change when in operation so that many different functions can be
accessed with these keys. A group of softkey names is a menu. A group of connected menus is
called a menu tree.
3-5
Page 58
5502A
Operators Manual
5502A
CALIBRATOR
STBY
OPR EARTH
8 9
7
456
23
1
+
/
•
0
10
SCOPE
PREV
TRIG
MENU
OUT
p
dBm sec
m
V Hz
n
W
k
A
p
M
ENTER
SHIFT
11 12 13 14
RESET
SETUP
F
NEW
MEAS
MULT
CE
REF
ZERO
TC
CAL
DIV
x
C
F
Figure 3-1. Front-Panel Features (cont.)
Table 3-1. Front-Panel Features (cont.)
EDIT
FIELD
POWER
1619
15171821 20
gvx009.eps
The NEW REF (New Reference) key is active when error mode is in operation, and sets the
current output value as a new reference for meter error computation.
The SETUP (Setup Menu) key puts the Calibrator into setup mode. The setup menu is shown in
the Control Display. Choose Setup options with the softkeys below the Control Display.
The RESET (Reset Calibrator) key aborts the Calibrators current operation and changes it to the
power-up default condition, except when it is used by remote control.
The CE (Clear Entry) key clears a partially-completed keypad entry from the Control Display. If
there is a partially-completed entry when is pushed, the output is unaffected.
The EDIT FIELD (Edit Output Display Field) key and its left/right arrow keys provide step
adjustment of the output signals. If any of these keys are pushed or the knob is rotated, a digit on
the Output Display is highlighted and the output increments or decrements as the knob is rotated.
If a digit goes past 0 or 9, the digit to its left or right is carried. An error shows on the Control
Display. The difference between the original (reference) output and the new output is shown.
The and keys adjust the magnitude of changes by moving the highlighted digit. lets
you move from voltage or current to frequency and back. In practice, for voltage and current
outputs, the knob and arrow keys are used to adjust output until the UUT reads correctly. The error
display then shows the UUT deviation from the reference.
3-6
Page 59
Features
Softkey Menu Trees 3
The power switch turns on and off Calibrator power. The switch is a latching push-push type. When
the switch is latched in, Calibrator power is on.
The ZERO CAL key lets you do an ohms zero or a full-zero calibration.
The DIV (Divide) key immediately changes the output to 1/10th reference value (not necessarily the
present output value) if the value is in performance limits. In the SCOPE mode, changes the
output to the next lower range.
The MULT (Multiply) key immediately changes the output to 10X the reference value (not
necessarily the present output value) if the value is in performance limits. This key sets the
Calibrator to standby if this change is from <33 V. In the SCOPE mode, changes the output to
the next higher range.
The MEAS TC (Measure Thermocouple) key starts the TC (Thermocouple) input connection and
makes the Calibrator calculate a temperature derived from the voltage that is at the input.
Output Units Keys
The output units keys choose the function of the Calibrator. Some keys have a secondary unit if
is pushed just before the units key. The output units are:
Voltage or Decibels relative to 1 mW into 600 Ω
(impedance changeable).
Watts or Current
Resistance
Frequency or Seconds (seconds applies to the SCOPE functions only)
Capacitance
Temperature in Fahrenheit or Celsius
Multiplier Keys
Select output value multipliers. Some keys have a secondary function if is pushed just before
the multiplier key. For example, if you record 33, then push , then , then , and then
, the Calibrator output value is 33 μF. The multiplier keys are:
-3
milli (10
kilo (10
mega (10
or 0.001) or micro (10-6 or 0.000001)
3
or 1,000) or nano (10
6
or 1,000,000) or pico (10
-9
or 0.000000001)
-12
or 0.000000000001)
3-7
Page 60
5502A
Operators Manual
5502A
CALIBRATOR
31 30
m
M
k
TRIG
OUT
dBm sec
W
PREV
MENU
V Hz
A
ENTER
RESET
SETUP
F
NEW
MEAS
MULT
CE
REF
ZERO
TC
CAL
DIV
x
C
F
EDIT
FIELD
POWER
STBY
OPR EARTH
8 9
7
456
23
1
+
/
•
0
SCOPE
p
n
p
SHIFT
28
29 27
26 25 24 23 22
gvx010.eps
Figure 3-1. Front-Panel Features (cont.)
Table 3-1. Front-Panel Features (cont.)
The ENTER key loads a newly-entered output value, shown on the Control Display, into the
Calibrator, which shows on the Output Display. The new value can come from the numeric keypad.
If you push without identifying the units for the entry, in most cases the Calibrator keeps the
units that were last used. This lets you, for example, enter 1 mV, and then later enter 10 to get 10 V.
(The "V" units were saved from the last entry, but not the multiplier, "m".) In the error (edit) mode,
with no value puts the output to the value of the reference.
3-8
The SHIFT key selects an alternative function of the units key and alternative multipliers of the
multiplier keys. These alternative selections are named with small letters in the upper-left hand
corner of the keys.
Numeric Keypad
Use to record the digits of the output amplitude and frequency. The correct sequence to record a
value is to push the digits of the output value, a multiplier key (if necessary), an output units key,
and then . For example, to obtain an output of 20 mV, you would push this sequence of
keys: . Push to enable the output. If you push a digit key once the entry
field is full, or push the decimal point key more than once in a single number, the beeper will
sound.
The (Polarity) key changes the polarity of the output for dc voltage or dc current functions.
Push the key and then to toggle the output polarity.
The SCOPE TRIG (Scope Trigger) BNC connector is used to trigger the oscilloscope during
oscilloscope calibration. This is active only when an oscilloscope option is installed.
The SCOPE OUT (Oscilloscope) A BNC connector is used for outputs during oscilloscope
calibration. This is active only when an oscilloscope calibration option is installed.
Page 61
Features
Softkey Menu Trees 3
Table 3-1. Front-Panel Features (cont.)
b
c
d
e
The TC (Thermocouple) minijackis used for thermocouple simulation during thermometer
calibration, and thermocouple measurements. You must use the correct thermocouple wire and
plug when you use this connector. For example, if you will simulate a type-K thermocouple, use
type-K thermocouple wire and type-K plug to make connections.
The 20A terminal is the source of current output when the 20 A range is selected (3 A to 20 A).
The AUX (Auxiliary Output) terminals are used for ac and dc current outputs, the second voltage
output in dual-voltage modes, and ohms sense for 2-wire and 4-wire compensated resistance and
capacitance measurements, and RTD simulation.
The NORMAL (Normal Output) terminals are used to source ac and dc voltage, ohms, and
capacitance. The terminals are also used for Resistance Temperature Detector (RTD) simulation.
3-9
Page 62
5502A
Operators Manual
MAINS SUPPLY
100V/120V
220V/240V
FUSE
T5.0A 250V
T2.5A 250V
(SB)
(SB)
CAUTION
FOR FIRE PROTECTION REPLACE ONLY
WITH A 250V FUSE OF INDICATED RATING
/63Hz 47Hz
600VA MAX
WARNING:
CHASSIS
GROUND
IS PROPERLY INSTALLED BEFORE ENERGIZING INSTRUMENT
TO AVOID ELECTRIC SHOCK GROUNDING
WARNING:
CONNECTOR IN POWER CORD MUST BE CONNECTED
67
1 2
TO AVOID PHYSICAL INJURY, INSURE THAT THE FILTER
CALIBRATION
IEEE-488
TO CLEAN THE FILTER:
-UNPLUG INSTRUMENT
-REMOVE FILTER
-FLUSH WITH SOAPY WATER
-DRY BEFORE REINSTALLATION
5
NORMAL
ENABLE
SERIAL 2
TO UUT
SERIAL 1
FROM HOST
3 4
INSTALLED
OPTIONS
- SC600
- SC1100
- PQ
FLUKE CORPORATION
EVERETT WA, USA
NO INTERNAL USER SERVICEABLE
PARTS. REFER SERVICE TO
QUALIFIED SERVICE PERSONNEL
LR65268C
(LEM CERTIFIED)
10MHZ
IN OUT
5V
PK - PK
MAX
gjh011.eps
Figure 3-2. Rear-Panel Features
Table 3-2. Rear-Panel Features
The Fan Filtercovers the air intake to keep dust and contamination out of the chassis air baffles.
The fan supplies a constant cool air flow to the inner chassis. Instructions for fan filter maintenance
are in Chapter 7.
The CALIBRATION NORMAL/ENABLE slide switch is used to write enable and disable the
nonvolatile memory that stores calibration constants. Change to ENABLE to let changes be written
into memory, and change to NORMAL to protect data in memory from being overwritten. The
switch is recessed to let it to be covered with a calibration sticker to guarantee calibration integrity.
The SERIAL 2 TO UUT connector is used to transmit and receive RS-232 serial data between the
Calibrator and a UUT. Chapter 6, “Remote Commands” tells you how to use the RS-232 serial
interface for UUT communications.
The SERIAL 1 FROM HOST connector is for remote control of the Calibrator and for transmitting
internal-constant RS-232 serial data to a printer, monitor, or host computer. Chapter 5, “Remote
Operation” tells you how to use the RS-232 serial interface for remote control.
The IEEE-488 connectorError! Bookmark not defined. is a standard parallel interface for
operating the Calibrator in remote control as a Talker/Listener on the IEEE-488 bus. Refer to
Chapter 5, “Remote Operation” for bus connection and remote programming instructions.
3-10
Page 63
Features
Softkey Menu Trees 3
Table 3-2. Rear-Panel Features (cont.)
Warning
To prevent possible electrical shock, fire, or personal injury:
• Do not use a two-conductor mains power cord unless you
install a protective ground wire to the Product ground terminal
before you operate the Product.
• Make sure that the Product is grounded before use.
The CHASSIS GROUNDterminal is internally grounded to the chassis. If the Calibrator is the
location of the ground reference point in a system, this binding post can be used to connect other
instruments to earth ground. Refer to the “Connect the Calibrator to a UUT” section in Chapter 4.
The AC Power Input Module gives you a grounded three-prong connector that takes the line
power cord, a switch mechanism to select the line voltage, and a line power fuse. See the
“Prepare for Operation” section in Chapter 2 for information on selecting the operating line
voltage, and fuse rating and replacement information.
3-11
Page 64
5502A
Operators Manual
Z
AE
SETUP
A
W
X
Y
AA
AC
AD
AF
AB
GI
G2
Front Panel Key
B
F
C
E
D
G
AG
AJ
S
S1
P
RQ
H
O
K
L
T
M
U
V
N
AK AL
AH
AF
Next
Section
AH
I
AF
3-12
Figure 3-3. Setup Softkey Menu Tree
gvx006.eps
Page 65
Features
Softkey Menu Trees 3
A
to X W to G to B
SHOW SPECS is an online summary of the programmed output specifications.
B
to AG
If self test does not pass, error codes are displayed. (See chapter 7, "Maintenance")
to F to C
C
to E to D
SERIAL # displays the serial number of the instrument. When corresponding with the factory,
always include the serial number of the instrument.
D
USER REPORT STRING CONTENTS refer to a string of characters entered by the user for
reporting purposes.
Figure 3-4. SETUP Softkey Menu Displays
gjh007.eps
3-13
Page 66
5502A
Operators Manual
E
Actual revision numbers replace the numbers in each of the above.
F
Format NV (non-volatile) Memory should be used with caution. Changes are non reversible. The
softkeys function only when the rear-panel CALIBRATION switch is set to ENABLE, except for the
softkey SETUP, which is not dependent on the CALIBRATION switch position.
All sets all calibration and setup constants to factory setting. CAL set only calibration constants
to factory settings. SETUP resets instrument setup to factory default settings (see Table 3-3).
G
G1
G2
to S to P to Hto G1
TMP STD (temperature degree standard) refers to ITS-90 (1990 International Temperature
Standard) (factory default) and IPTS-68 (1968 International Provisional Temperature Standard).
Figure 3-4. SETUP Softkey Menu Displays (cont.)
3-14
gjh008.eps
Page 67
Features
Softkey Menu Trees 3
H
to K to Ito O
HOST selects the IEEE-488 (GPIB) (factory default) parallel port or RS-232 (serial) port. You cannot
operate both IEEE-488 and RS-232 simultaneously.
I
STALL refers to the method of controlling data flow: software control (xon/off), hardware control
(rts/cts) or none.
K
to L
STALL refers to the method of controlling data flow: software control (xon/off), hardware control
(rts/cts) or none.
Figure 3-4. SETUP Softkey Menu Displays (cont.)
gjh030.eps
3-15
Page 68
5502A
Operators Manual
L
to M
REMOTE I/F (Interface) has selections term (terminal) (factory default) and comp (computer). EOL
(End of Line character) is either Carriage Return/Line Feed (CRLF), CR (Carriage Return) or LF
(Line Feed).
M
to N to K
EOF (End of File) indicates the action taken at the end of a file by entering one or two ASCII
characters.
N
EOF (End of File) ASCII characters are entered with a range of 000 to 255 (first character) and 000
to 255 (second character). The factory defaults are 012,000, where the FF (form feed) character
signals an advance to the next page, and the NULL (ignore) character holds position. When the
NULL character is 000 (^@), then effectively the EOF is only the FF character, or ^L for the factory.
Figure 3-4. SETUP Softkey Menu Displays (cont.)
3-16
gjh003.eps
Page 69
Features
Softkey Menu Trees 3
O
GPIB (General Purpose Interface Bus) selects the port address when using the IEEE-488 bus. The
factory default is 4.
P
to R to Q
DISPLAY BRIGHTNESS and DISPLAY CONTRAST apply to both the Output Display and Control
Display.
Q
levels 0,1,2,3,4,5,6,7 levels 0,1,2,3,4,5,6,7
There are eight levels of contrast, 0 to 7, for the Output Display and Control Display. Each may
have its own level of contrast. The factory defaults are 7 and 7.
R
There are eight levels of brightness, 0 to 7, for the Output Display and Control Display. Each may
have its own level of contrast. The factory defaults are 1 and 0.
Figure 3-4. SETUP Softkey Menu Displays (cont.)
levels 0,1,2,3,4,5,6,7 levels 0,1,2,3,4,5,6,7
gjh031.eps
3-17
Page 70
5502A
Operators Manual
S
S1
to S1
to T
Figure 3-4. SETUP Softkey Menu Displays (cont.)
3-18
gvx032.eps
Page 71
Features
Softkey Menu Trees 3
T
to V to U
The values set here become the new limits and can be changed only with new entries or
returned to factory defaults using Format NV Memory SETUP (see menu F).
U
V
W
X
SHOW SPECS is an online summary of the programmed output specifications.
to ACto Y
to AA
Figure 3-4. SETUP Softkey Menu Displays (cont.)
gvx012.eps
3-19
Page 72
5502A
Operators Manual
Select the desired CAL (Calibration) feature: CAL to calibrate the 5502A.
CAL DATES to review when the 5502A Calibrator was last calibrated. CAL REPORTS to
printout the calibration data.
Y
to Z
Z
to Y
AA
AB
AC
(Only if scope
option installed)
to AB
to ADto AE
5502A CAL opens the calibration menu. ZERO zeros the 5502A Calibrator. OHMS ZERO
zeros the ohms portion of the 5502A Calibrator; ERR ACT (Error Action) set backup, abort,
or cont (continue).
Figure 3-4. SETUP Softkey Menu Displays (cont.)
3-20
gjh013eps
Page 73
Features
Softkey Menu Trees 3
AD
to AF
GO ON and ABORT softkeys are used in the 5502A Calibrator calibration procedure.
(Only if scope
option installed)
AE
to AF
AF
AG
AH
to AG
to AH to AJ
Figure 3-4. SETUP Softkey Menu Displays (cont.)
gjh033.eps
3-21
Page 74
5502A
Operators Manual
Table 3-3. Factory Defaults for SETUP Menus Power-Up Defaults
Parameter Setting
User report string (*PUD string) Cleared D
Error units > 0.1% G1
SC-600 option overload test safety
timeout
Temperature standard its-90 G1
Host interface gpib (IEEE-488) G1
UUT serial interface
Host serial interface
GPIB Port Address 4 O
Display brightness (Note) level 1,0 P
Display contrast (Note) level 7,7 P
dBm impedance 600 Ω S
RTD type pt385 S1
10 s G1
8 bits, 1 stop bit, xon/xoff, parity
none, 9600 baud
term, 8 bits, 1 stop bit, xon/xoff,
parity none, 9600 baud, CRLF,
012,000
SETUP Menu
(Figure 3-4)
I
K, L, M, N
Thermocouple type K S1
Current limits ±20.5 A U
Voltage limits ±1020 V V
Note:
Output Display and Control Display, respectively. There are 8 levels: 0,1,2,3,4,5,6, and 7
3-22
Page 75
Chapter 4
Front-Panel Operation
Title Page
Introduction .......................................................................................................... 4-3
Turn on the Calibrator .......................................................................................... 4-3
Warm up the Calibrator ....................................................................................... 4-4
Use the Softkeys .................................................................................................. 4-4
Use the Setup Menu ............................................................................................. 4-4
Use the Instrument Setup Menu ...................................................................... 4-5
Utility Functions Menu .................................................................................... 4-6
Use the NV Memory Menu ............................................................................. 4-6
Reset the Calibrator ............................................................................................. 4-7
Zero the Calibrator ............................................................................................... 4-7
Operate and Standby Modes ................................................................................ 4-8
Connect the Calibrator to a UUT ......................................................................... 4-9
Recommended Cable and Connector Types .................................................... 4-9
When to Use EARTH ...................................................................................... 4-10
Four-Wire versus Two-Wire Connections ...................................................... 4-11
Four-Wire Connection ................................................................................ 4-11
Two-Wire Compensation ............................................................................ 4-11
Compensation Off ....................................................................................... 4-11
Cable Connections Instructions ....................................................................... 4-12
RMS Versus p-p Amplitude................................................................................. 4-17
Auto Range Versus Locked Range ...................................................................... 4-18
Set Output ............................................................................................................ 4-18
Set DC Voltage Output .................................................................................... 4-19
Set AC Voltage Output .................................................................................... 4-20
Set DC Current Output .................................................................................... 4-23
Set AC Current Output .................................................................................... 4-24
Set DC Power Output ...................................................................................... 4-25
Set AC Power Output ...................................................................................... 4-27
Set a Dual DC Voltage Output ........................................................................ 4-30
Set a Dual AC Voltage Output ........................................................................ 4-31
Set Resistance Output ...................................................................................... 4-34
Set Capacitance Output ................................................................................... 4-35
Set Temperature Simulation (Thermocouple) ................................................. 4-37
Set Temperature Simulation (RTD) ................................................................ 4-39
Measure Thermocouple Temperatures ............................................................ 4-41
Waveform Types .................................................................................................. 4-44
Sine Wave ........................................................................................................ 4-44
Triangle Waves ................................................................................................ 4-44
4-1
Page 76
5502A
Operators Manual
Square Wave .................................................................................................... 4-45
Truncated Sine Wave ...................................................................................... 4-45
Set Harmonics ...................................................................................................... 4-46
Adjust the Phase ................................................................................................... 4-47
Record a Phase Angle ...................................................................................... 4-49
Record a Power Factor .................................................................................... 4-49
Record a DC Offset .............................................................................................. 4-50
Edit and Error Output Settings ............................................................................. 4-51
Edit the Output Setting .................................................................................... 4-51
Show the UUT Error ....................................................................................... 4-52
Use Multiply and Divide ................................................................................. 4-53
Set Output Limits ................................................................................................. 4-53
Sample Applications ............................................................................................ 4-54
How Calibrate an 80 Series Digital Multimeter .............................................. 4-55
Cables .......................................................................................................... 4-55
EARTH Connection .................................................................................... 4-55
Verify the Meter .......................................................................................... 4-55
Calibrate the Meter ...................................................................................... 4-61
Verify a Model 41 Power Harmonics Analyzer .............................................. 4-61
Verify Watts, VA, VAR Performance ........................................................ 4-61
Verify Harmonics Volts Performance ......................................................... 4-63
Verify Harmonics Amps Performance ........................................................ 4-64
Calibrate a Fluke 51 Thermometer .................................................................. 4-65
Verify the Thermometer .............................................................................. 4-65
Calibrate the Thermometer ......................................................................... 4-66
4-2
Page 77
Introduction
To prevent possible electrical shock, fire, or personal injury, do
not make connections to the output terminals when voltage is
present. Standby mode is not sufficient to prevent shock
hazard because could be pushed accidently. Push
and make sure that the Calibrator is in standby before you
make connections to the output terminals.
This chapter gives instructions to operate the Calibrator from the front panel. For a
description of front-panel controls, displays, and terminals, see Chapter 3, “Features”.
Turn on the Calibrator
When the Calibrator is on, the initial display is “Starting Up...” (see below) and it
completes a self-test routine. If a self-test fails, the Control Display shows an error code.
For a description of error codes, see Chapter 7, “Maintenance.”
Warning
nn062f.eps
After self-test, the control display shows the reset condition (see below).
nn063f.eps
For a discussion of the softkey selection shown above (auto/locked), see “Auto Range
Versus Locked Range” in this chapter.
4-3
Page 78
5502A
Operators Manual
Warm up the Calibrator
Use the Softkeys
When you turn on the Calibrator, let it warm up for 30 minutes to let the internal
components become stable. Specifications given in Chapter 1 apply to a Calibrator that
has completed its warm-up procedure.
If you turn off the Calibrator after warm up and then on again, give it a warm-up period of
no less than two times the length of time it was turned off (maximum of 30 minutes). For
example, if the Calibrator is turned off for 10 minutes and then on again, give it a warm-up
period of no less than 20 minutes.
The five keys to the right of are called softkeys. Softkey functions come from the
name that shows directly above the key in the Control Display. Push a softkey to change
a value or cause a submenu with new selections to be shown on the Control Display.
Softkey menus are put in different levels, as given in the “Softkey Menu Tree” section in
Chapter 3. You can move back through the menu selections with . Although
will return you to the top-level menu, it will also reset all volatile settings and return the
Calibrator to 0 V dc in the standby mode. Use as your main navigation tool to move
through the menu levels.
Use the Setup Menu
Push the front-panel key to access various operations and changeable parameters.
Most parameters are nonvolatile. This means they will be stored during reset or when you
turn off the power. Chapter 3 shows a map of the menu tree, the parameters, and has a
table of factory-default values.
When you push from power-up, the display changes to:
This is the primary instrument setup menu. The list below tells you about the submenus
that available through each softkey and tells you where you can find more information in
the manuals.
• CAL (Calibration)
Opens the calibration menu. You use softkeys in this menu to see the calibration
dates, print a calibration report, calibrate, and to do the Zero calibration routine. Zero
calibration is given in this chapter.
• SHOW SPECS (Show Specifications)
nn064f.eps
Shows published Calibrator specifications for the output value that is currently
selected.
4-4
Page 79
Front-Panel Operation
Use the Setup Menu 4
• INSTMT SETUP (Instrument Setup)
Lets you change the power-up or reset default setting for different instrument
parameters. Many of the same parameters in this menu can be changed during
operation, but the changes you make during operation are volatile. Change them here
to makes them nonvolatile. To set the Calibrator to its factory defaults, use the
Format NV Memory menu in the UTILITY FUNCTNS menu.
• UTILITY FUNCTNS (Utility Functions)
Lets you to start self-tests, format the nonvolatile memory (set the factory defaults),
and examine the instrument configuration software versions and user report string.
These features are given in the “Utilities Function Menu” section of this chapter.
Use the Instrument Setup Menu
The softkeys in the instrument setup menu (accessed by pressing INSTMT SETUP
softkey in the Setup Menu) are shown below.
The list below gives submenus accessed by each softkey.
• OTHER SETUP
Opens a menu that lets you toggle the degree reference between the 1968
International Provisional Temperature Standard (IPTS-68) and the 1990 International
Temperature Standard (ITS-90) (factory default). This is also where you set the
clock, and set the power-up and reset defaults for the SC-600 Oscilloscope
Calibration Option Overload test safety timeout function (OVLD T), and shown error
units. You can also configure the Calibrator for best operation with a 50 Hz line
frequency.
• OUTPUT SETUP
Opens a menu to change the power-up and reset defaults for current and voltage
output limits, default thermocouple and RTD types, set the phase reference, internal
or external phase reference source, and impedance for dBm display.
• DISPLAY SETUP
Opens submenus to set the intensity and contrast of the Control and Output
Displays.
• REMOTE SETUP
Lets you change the configuration of the two RS-232 ports, SERIAL 1 FROM HOST
and SERIAL 2 TO UUT, and IEEE-488 General Purpose Interface Bus (GPIB). (See
Chapter 5, “Remote Operation”.)
nn065f.eps
4-5
Page 80
5502A
Operators Manual
Utility Functions Menu
The Setup Menu softkey UTILITY FUNCTNS (Utility Functions) gives access to Self
Test, Format Nonvolatile Memory, and Instrument Configuration.
• SELF TEST
This softkey opens a menu with Calibrator self-test selections.
• FORMAT NV MEM (Format Nonvolatile Memory)
Opens a menu to put all or part of the data in the nonvolatile memory (EEPROM) to
factory defaults.
• INSTMT CONFIG (Instrument Configuration)
Lets you see the versions of software installed in the Calibrator as well as the userentered report string.
Use the NV Memory Menu
The Format Nonvolatile Memory menu softkeys permanently
erase calibration constants. If you push ALL or CAL, this will
invalidate the condition of calibration of the 5502A.
Push FORMAT NV MEM in the utility functions menu to open:
Caution
nn066f.eps
It is necessary that the rear-panel CALIBRATION switch to be in the ENABLE position
for the ALL and CAL softkeys in this menu. The nonvolatile memory has calibration
constants and dates, setup parameters, and the user report string. With calibration
constants, factory defaults are the same for all calibrators. They are not the calibration
constants received when the Calibrator was calibrated by the factory before shipment.
4-6
nn067f.eps
Page 81
Front-Panel Operation
Reset the Calibrator 4
The softkeys are:
• ALL
replaces all contents of the EEPROM with factory defaults. This is used by service
personnel after they replace the EEPROM, for example. It is not typically necessary.
• CAL
replaces all calibration constants with factory defaults but keeps the setup parameters
unchanged. This is also not typically necessary.
• SETUP
replaces the setup parameters with factory defaults (Table 3-3) but keeps the
calibration unchanged. You do not have to break the calibration seal for this
operation. Remote commands can also change the setup parameters. (See these
commands in Chapter 6: SRQSTR, SPLSTR, *PUD, SP_SET, UUT_SET,
TEMP_STD, DATEFMT, RTD_TYPE_D, TC_TYPE_D, LIMIT.)
Reset the Calibrator
When you use front panel-operation (not remote operation), you can put the Calibrator to
the power-up condition with , except after an error message, which is cleared by a
push of the blue softkey.
Push to:
• Put the Calibrator into the power-up condition: 0 V dc, standby, 330 mV range and
all OUTPUT SETUP menus set to their most recent default values.
• Erases the stored values for limits and error mode reference.
Zero the Calibrator
When you zero the Calibrator, the Calibrator recalibrates internal circuitry, most notably
dc offsets in all ranges of operation. Zero the Calibrator each seven days to make sure the
Calibrator outputs are not more or less than the limits of its specification, or when the
Calibrator ambient temperature changes by more than 5 °C. The tightest ohms
specifications are kept by a zero calibration each 12 hours within ±1 °C of use. The
Calibrator shows a message when it is necessary to zero the Calibrator. To zero the
Calibrator is very important when your calibration workload has 1 mΩ or 1 μV
resolution, and when there has been a significant temperature change in the Calibrator
work environment. There are two functions that zero the Calibrator: total instrument zero
(ZERO) and ohms-only zero (OHMS ZERO).
Complete these procedures to zero the Calibrator.
4-7
Page 82
5502A
Operators Manual
Note
The Calibrator rear-panel CALIBRATION switch does not have to be
enabled for this procedure.
1. Turn on the Calibrator and let it warm-up for no less than 30 minutes.
2. Push .
3. Push . This opens the setup menu (see below).
4. Push the CAL softkey. This opens the calibration information menu (see below).
5. Push the CAL softkey. This opens the calibration activity menu (see below). SCOPE
CAL is shown as an option if it is installed:
6. Push the ZERO softkey to zero the Calibrator. Push the OHMS ZERO softkey to zero
only the ohms function. After the zero routine is complete (several minutes), push
to reset the Calibrator. For a complete zero calibration, a short circuit that can
pass 20 A must to be applied between the 20A and AUX LO terminals.
Operate and Standby Modes
When the OPERATE annunciator is illuminated and OPR is shown, the output value and
function shown on the Output Display is live at the selected terminals. When STBY is
shown in the Output Display, most of the Calibrator outputs are open-circuited. The
front-panel thermocouple (TC) terminals are not open-circuited. To start the operate
mode, push . To put the Calibrator in standby, push .
nn068f.eps
nn069f.eps
gvx034.eps
If the Calibrator operates and these things occur, the Calibrator automatically goes to the
standby mode:
• is pushed.
• A voltage ≥33 V is selected when the previous output voltage was less than 33 V.
• Output function is changed between ac or dc voltage when the output voltage is
≥33 V, ac or dc current, temperature and any other function; resistance and any other
function; capacitance and any other function.
4-8
Page 83
Front-Panel Operation
Connect the Calibrator to a UUT 4
• A p-p voltage output (square wave, triangle wave, or truncated sine wave) changes to
rms voltage output ≥33 V (sine wave). For example, if a p-p output of 40 V is
changed to rms output of 40 V by a change to the wave form with the WAVE
softkey, the Calibrator goes to the standby mode.
• The output location for current is changed from AUX to 20 A, or from 20 A to
AUX .
• An overload condition occurs.
Connect the Calibrator to a UUT
Warning
To prevent possible electrical shock, fire, or personal injury, do
not make connections to the output terminals when voltage is
present. Standby mode is not sufficient to prevent shock
hazard because could be pushed accidently. Push
and make sure that the Calibrator is in standby before you
make connections to the output terminals.
The NORMAL (HI and LO) outputs are used to source voltages, resistances, capacitance,
and simulate resistance temperature detector (RTD) outputs. The LO terminal connects to
the analog signal ground in the guard shield. This signal line can or cannot be connected
to the chassis ground. This depends on how is set. See “When to Use EARTH” in
this chapter for more about these internal connections.
The AUX (HI and LO) outputs source current and low voltages in the dual voltage
function. These outputs are also used for four-wire or remote sensing in the resistance,
capacitance, and RTD functions.
When an oscilloscope calibration option is installed, the SCOPE OUT BNC connectors
and TRIG give signals for oscilloscope calibration.
Use the TC socket to measure thermocouples and to supply simulated thermocouple
outputs.
Recommended Cable and Connector Types
Warning
To prevent possible electrical shock, fire, or personal injury:
• Do not use test leads if they are damaged. Examine the test
leads for damaged insulation, exposed metal, or if the wear
indicator shows. Check test lead continuity.
• Use only cables with correct voltage ratings.
• Connect the common test lead before the live test lead and
remove the live test lead before the common test lead.
• Use only the mains power cord and connector approved for
the voltage and plug configuration in your country and rated
for the Product.
4-9
Page 84
5502A
Operators Manual
When to Use EARTH
• Properly terminate the sense leads to prevent exposure to
hazardous voltages on the sense terminals. The voltage
sense terminals are at output voltage when the two-wire
function is set.
• Do not touch exposed metal on banana plugs, they can have
voltages that could cause death.
• Do not use a two-conductor mains power cord unless you
install a protective ground wire to the Product ground
terminal before you operate the Product.
• Make sure that the Product is grounded before use.
Cables to the Calibrator are connected to the NORMAL and AUX terminals. To prevent
errors caused by thermal voltages (thermal emfs), use connectors and conductors made of
copper or materials that supply small thermal emfs when connected to copper. Do not use
nickel-plated connectors. For best results use the Fluke Model 5440A-7002 Low Thermal
EMF Test Leads, which are made of well-insulated copper wire and tellurium copper
connectors. See Chapter 8, “Accessories.”
Figure 4-1 shows the internal connections made by .
Internal guard shield
NORMAL LO
signal ground
NORMAL LO
binding
post
Chassis ground
EARTH
Not lit = open
Figure 4-1. EARTH Internal Connections
Safety ground
through
ac line cord
gvx003f.eps
4-10
Page 85
Front-Panel Operation
Connect the Calibrator to a UUT 4
The Calibrator front panel NORMAL LO terminal is typically isolated from earth
(chassis) ground. When it is necessary to make a connection from the NORMAL LO
terminal and earth ground, push the key, this lights the key annunciator. When the
earth key is pushed, the NORMAL LO terminal is connected to earth ground through
approximately 30 Ω.
To prevent ground loops and noise you must have only one earth ground-to-LO terminal
connection in the system. Typically you make all signal ground connections at the UUT
and make sure that the annunciator is off. In most cases, is on only for ac and
dc volts where the UUT is isolated from earth ground. There must be a safety ground for
the Calibrator. See “Connect to Line Power” in Chapter 2. When the sourced output is
live, a softkey LO is shown, which lets you tie or open an internal connection from the
NORMAL LO terminal to the AUX LO terminal. When tied and is on, then both
LO terminals are tied to chassis ground.
Four-Wire versus Two-Wire Connections
Four-wire and two-wire connections are methods to connect the Calibrator to the UUT to
cancel out test lead resistance to make sure the highest precision of the calibration output.
Figures 4-2 through 4-4 show the connection configurations for resistance. Figures 4-5
and 4-6 show connection configurations for capacitance. The external-sensing function of
the four- and two-wire compensated connections gives increased precision for resistance
values less than 110 kΩ and capacitance values 110 nF and above. A part of the
Calibrator output setup for resistance and capacitance includes selections for four-wire
compensation (COMP 4-wire), two-wire compensation (COMP 2-wire) and two-wire no
compensation (COMP off). (See “Set Resistance Output” and “Set Capacitance Output”
in this chapter.) Note that compensated connections for capacitance are to compensate for
lead and internal resistances, not for lead and internal capacitances.
Four-Wire Connection
The four-wire connection is typical for calibration of laboratory measurement equipment.
Increased precision is supplied for resistance values less than 110 kΩ. For other values,
the lead resistances do not degrade the calibration and the Calibrator changes the
compensation to off (COMP off).
Two-Wire Compensation
The two-wire connection is typical for calibration of precision handheld Digital
Multimeters (DMMs) with a two-wire input. Increased precision is supplied for resistance
values less than 110 kΩ and capacitance values 110 nF and above. For other values, the
Calibrator changes the compensation to off (COMP off).
Compensation Off
Compensation off is a typical connection for calibration of handheld analog meters or
DMMs with a two-wire input. This connection is used for all values of resistance and
capacitance and is typically selected when more precision is not necessary for the analog
meter or DMM level of accuracy. This is the default condition when an ohms or
capacitance output is made after an output that was not ohms or capacitance.
4-11
Page 86
5502A
Operators Manual
Cable Connections Instructions
Table 4-1 shows the figure names for each type of connection from a UUT to the
Calibrator.
When you calibrate Resistance Temperature Detectors (RTDs) with the three-terminal
connection shown in Figure 4-9, make sure the test leads have with resistances to cancel
errors from lead resistance. This can be done, for example, with three test leads of the
same length and with the same connector styles.
When you calibrate thermocouples, it is especially important to use the correct hookup
wire and miniconnector between the Calibrator front panel TC terminal and the UUT.
You must use the correct thermocouple wire and miniconnectors for the type of
thermocouple. For example, if you simulate a temperature output for a type K
thermocouple, use type K thermocouple wire and type K miniplugs for the hookup.
To connect the Calibrator to a UUT:
1. If the Calibrator is turned on, push to remove the output from the Calibrator
terminals.
2. Select the correct figure from Table 4-1 to make the connections to the UUT.
3. For capacitance outputs, connect the test leads to the UUT to null out stray
capacitance. Put the cables (but do not connect them) to the Calibrator on a
non-conductive surface. Null out the indication on the UUT with “rel,”
“offset,” or “null,” (use the necessary method), and then connect the test leads
to the Calibrator.
Table 4-1. UUT Connections
5502A Output Figure Reference
Resistance
Capacitance
DC Voltage
AC Voltage
DC Current
AC Current
RTD Simulation
Thermocouple Simulation
Note:
See the discussion under “Four-Wire versus Two-Wire Connections” above.
4-2 Resistance - four-wire compensation
4-3 Resistance - two-wire compensation
4-4 Resistance - compensation off
4-5 Capacitance - two-wire compensation
4-6 Capacitance - compensation off
4-7 DC Voltage/AC Voltage
4-7 DC Voltage/AC Voltage
4-8 DC Current/AC Current
4-8 DC Current/AC Current
4-9 Temperature (RTD)
4-10 Temperature (Thermocouple)
4-12
Page 87
Front-Panel Operation
Connect the Calibrator to a UUT 4
CALIBRATOR
UUT
5502A
HI
LO
INPUT
A
SENSE
4-WIRE
W
HI
LO
SENSE
SOURCE
UUT
5502A
SOURCE
SENSE
Figure 4-2. UUT Connection: Resistance (Four-Wire Compensation)
TRUE RMS MULTIMETER
87
RANGE HOLD
REL Hz
H
mA
A
A
m
MIN MAX
PEAK MIN MAX
mV
V
V
OFF
5502A
CALIBRATOR
gvx014.eps
COM
V
UUT
5502A
mA A
A
Figure 4-3. UUT Connection: Resistance (Two-Wire Compensation)
gvx015.eps
4-13
Page 88
5502A
Operators Manual
TRUE RMS MULTIMETER
87
5502A
CALIBRATOR
RANGE HOLD
REL Hz
COM
UUT
H
mA
A
A
m
V
5502A
gvx016.eps
MIN MAX
PEAK MIN MAX
mV
V
V
OFF
mA A
A
Figure 4-4. UUT Connection: Resistance (Compensation Off)
TRUE RMS MULTIMETER
87
5502A
CALIBRATOR
RANGE HOLD
REL Hz
COM
H
mA
A
m
A
V
MIN MAX
PEAK MIN MAX
mV
V
V
OFF
mA A
A
Figure 4-5. UUT Connection: Capacitance (Two-Wire Compensation)
gvx017.eps
4-14
Page 89
Front-Panel Operation
Connect the Calibrator to a UUT 4
TRUE RMS MULTIMETER
87
5502A
CALIBRATOR
RANGE HOLD
REL Hz
mA
COM
H
A
m
A
V
gvx018.eps
MIN MAX
PEAK MIN MAX
mV
V
V
OFF
mA A
A
Figure 4-6. UUT Connection: Capacitance (Compensation Off)
TRUE RMS MULTIMETER
87
RANGE HOLD
REL Hz
H
mA
A
A
m
MIN MAX
PEAK MIN MAX
mV
V
V
OFF
5502A
CALIBRATOR
COM
V
gvx019.eps
mA A
A
Figure 4-7. UUT Connection: DC Voltage/AC Voltage
4-15
Page 90
5502A
Operators Manual
TRUE RMS MULTIMETER
87
5502A
CALIBRATOR
RANGE HOLD
REL Hz
COM
H
mA
A
A
m
V
MIN MAX
PEAK MIN MAX
mV
V
V
OFF
mA A
A
Figure 4-8. UUT Connection: DC Current/AC Current
CHART RECORDER INPUT
5502A
CALIBRATOR
gvx020.eps
Figure 4-9. UUT Connection: Temperature (RTD)
4-16
gvx021.eps
Page 91
Front-Panel Operation
RMS Versus p-p Amplitude 4
CALIBRATOR
K/J THERMOMETER
51
ON/OFF
F/C
HOLD
OFFSET
60V
24V
MAX
!
5502A
Connection wiring must match thermocouple type, e.g., K, J, etc.
Figure 4-10. UUT Connection: Temperature (Thermocouple)
RMS Versus p-p Amplitude
The Calibrator ranges for sinusoidal ac functions are specified in rms (root-mean-square,
the effective value of the wave form). For example, 1.0 to 32.999 mV, 33 to 329.999 mV,
0.33 to 3.29999 V, etc. The sine wave outputs are in rms, while the triangle wave, square
wave, and truncated sine wave outputs are in p-p. The relationship between p-p and rms
for the non-sine wave types are:
• Square wave p-p x 0.5000000 = rms
• Triangle wave p-p x 0.2886751 = rms
• Truncated Sine wave p-p x 0.2165063 = rms
While the ac function ranges are compatible for sine waves, the rms content of the
other waveforms is less apparent. This quality leads to subtle Calibrator range changes.
For example, if you record a sine wave voltage of 6 V (rms assumed), the selected
range is 3.3 to 32.9999 V. If you then use the softkeys to change from a sine wave to a
triangle wave, for example, the display changes from 6 V rms to 6 V p-p. This
translates to 6 V p-p x 0.2886751 = 1.73205 V rms, and the range switches to 0.33 to
3.29999 V. The Output Display shows the range change because the sine wave voltage
is shown as 6.0000, the resolution for the 3.3 to 32.9999 V range, while the triangle
wave is shown as 6.00000, the resolution for the 0.33 to 3.29999 V range.
You must know the range in operation to record the correct values for voltage offset
because the maximum offsets are specified to the range. For example, the maximum peak
signal for the 3.3 to 32.9999 V range is 55 V while the maximum peak signal for the 0.33
to 3.29999 V range is 8 V. This means in the example above, the 6 V rms sine wave
could have offsets applied to a maximum peak signal of 55 V because the current range is
3.3 to 32.9999 V, while the 6 V p-p triangle wave could have offsets applied to a
maximum peak signal of 8 V because the current range is 0.93 to 9.29999 V. See
“Specifications” in Chapter 1 and “Record a DC Offset” in this chapter for more about dc
offset voltages.
gvx022.eps
4-17
Page 92
5502A
Operators Manual
Auto Range Versus Locked Range
A softkey is supplied to toggle between the ranging methods auto or locked. This feature
is available only for single-output dc volts and dc current outputs.
When you select auto (the default), the Calibrator automatically selects the range that
gives the best output resolution. When you select locked, the Calibrator locks the selected
range and will not change ranges when you edit the output, or record new outputs. Values
lower or higher than the locked range are not permitted. The locked selection is typically
made to prevent range changes that can cause a small perturbation in the output, for
example, when you measure the linearity of a given multimeter range.
Set Output
To set the Calibrator output, push the keys for the necessary values and then push a units
key to identify which of the volts, amps, hertz, etc., that the values are for. The control
display shows the value and units you select as you type them into the Calibrator. When
you are satisfied with the value and units, push . If the output display shows
STBY, push to output the selection. A small “u” (unsettled) in the Output Display
shows that the Calibrators internal circuitry must become stable.
For example, to set the output to 10 V dc, push:
→ → → →
To set the output to 20 V ac at 60 Hz push:
→ → → → → → →
To change the output to dc, push:
nn063f.eps
→→ or →
Step-by-step procedures are given for each output function:
• DC voltage
• AC voltage
• DC current
• AC current
• DC power
• AC power
• Dual DC voltage
• Dual AC voltage
• Capacitance
• Temperature - RTD
• Temperature - Thermocouple
• Resistance
4-18
Page 93
Front-Panel Operation
Set Output 4
Set DC Voltage Output
Do these procedures to set a dc voltage output from the front-panel NORMAL terminals.
If you make an entry error, push to clear the display, then record the value again.
Caution
To prevent damage to the UUT, make sure the applied voltage
to the UUT is not larger than the rating of the UUT insulation
and the connection wires.
1. Push to clear outputs from the Calibrator.
2. Connect the UUT as in the “Connect the Calibrator to a UUT” section of this chapter.
3. Set the UUT to measure dc voltage on the necessary range.
4. Push the numeric keys and decimal point key to record the necessary voltage output
(maximum seven numeric keys). For example, 123.4567.
Note
At voltage outputs of 100 V and above (nominal), the Calibrator usually
makes a small high-pitched sound.
5. Push to select the polarity of the voltage (default is +)
6. Push a multiplier key, if necessary. For example, push .
7. Push .
8. The Control Display shows the amplitude of your entry. For example,
123.4567 mV (see below).
nn071f.eps
9. Push . The Calibrator erases your entry from the Control Display and copies
it into the Output Display (below is typical).
nn072f.eps
4-19
Page 94
5502A
Operators Manual
10. Push to turn on the Calibrator output.
A softkey name for range is shown on the Control Display in the dc voltage function:
Range (Operating Range) selects autorange (auto) or lock (locked) for the current
range. When auto (the default) is selected, the Calibrator automatically selects the
range that gives the best output resolution. When locked is selected, the Calibrator
will not change ranges when you edit the output. The locked selection is typically
made to prevent range changes that can cause a small agitation in the output, for
example, when you measure the linearity of a given multimeter range.
Set AC Voltage Output
You can select an ac voltage output in volts or as a power output in dBm, where dBm is
10 log (Pout/.001), where Pout is shown in watts. The output range is 1 mV to 1000 V.
When you select dBm outputs, the Calibrator calculates dBm at a selected impedance
level. For this instance, the formula is:
20 log(V) - 10 log(Impedance * .001) = dBm.
Do this procedure to set an ac voltage output at the front panel NORMAL terminals. If
you make an entry error, push to erase the display, then record the value again.
To prevent damage to the UUT, makes sure the applied voltage to
the UUT is not larger than the rating of the UUT insulation and the
connection wires.
1. Push to clear output from the Calibrator.
Caution
nn063f.eps
1. Connect the UUT as in the “Connect the Calibrator to a UUT” section of this chapter.
2. Set the UUT to measure ac voltage on the necessary range.
Output in volts:
Push the numeric keys and decimal point key to record the necessary voltage
output (maximum six numeric keys). For example, 2.44949.
4-20
Page 95
Front-Panel Operation
Set Output 4
Output in dBm:
Push the numeric keys and decimal point key to record the necessary power
output (maximum six numeric keys). For example, 10.0000. For a power output
less than 1 mW (negative dBm values), push to append the numeric entry
with the negative (−) symbol.
When you push the dBm key, the right-most softkey turns on. This lets the dBm
value and output impedance to be recorded as a unit.
When output is recorded in dBm, the Control Display changes to:
nn227f.eps
Note
At voltage outputs of 100 V and above (nominal), the Calibrator usually
makes a small high-pitched sound.
1. Push a multiplier key, if necessary. For example, push .
2. Output in volts. Push .
Output in dBm. Push . Select an impedance for dBm from a list on the
Control Display with the right-most softkey.
3. The Control Display shows the amplitude of your entry. For example, 2.44949 V (see
below).
nn073f.eps
4-21
Page 96
5502A
Operators Manual
4. Push the numeric keys and decimal point key to record the necessary frequency
output (maximum five numeric keys). Push a multiplier key, if necessary. For
example, push the kilo multiplier key . Then push the key. For example,
1.1234 kHz (see below).
nn074f.eps
5. Push . The Calibrator erases your entry from the Control Display and copies
it into the Output Display (below is typical).
nn075f.eps
6. Push to start the Calibrator output.
Software names are shown on the Control Display in the ac voltage function, in
reference to which waveform is selected: DUTY, OFFSET and WAVE.
• DUTY (Duty Cycle) When the square wave is selected, DUTY shows and lets you
change the duty cycle of the square wave. The range is 1.00 % to 99.00 %. The
default is 50.00 %. The duty cycle must be 50.00 % if it is necessary to record an
OFFSET (see below).
• OFFSET (Voltage Offset) shows when the necessary output is less than 33 V (sine
waves), 65 V (square waves) or 93 V (triangle waves and truncated sine waves). This
softkey lets you to add a positive or negative dc offset voltage to the ac output signal.
See “Record a DC Offset” in this chapter for more information. When a voltage
output is shown in dBm, voltage offset is not available. You can record an offset for
a square wave output only when the duty cycle is 50.00 % (see DUTY above).
• WAVE (Waveform) lets you select one of four different types of waveforms: sine
wave, triangle wave, square wave, and truncated sine wave. (See “Waveform Types”
in this chapter). When a non-sinusoidal waveform is selected, the Output Display
shows Pp (p-p). Output in dBm is sine wave only.
4-22
gvx076f.eps
Page 97
Front-Panel Operation
Set Output 4
Set DC Current Output
Do the subsequent procedure to set a dc current output between AUX HI and LO or AUX
20A and LO. Choose the inputs for the current level selected. Current larger than ±3 A is
sourced between the AUX 20A and LO terminals. If you make an entry error, push
to clear the display, and then record the value again.
Note
See the “Specifications” section in Chapter 1 for a chart that shows
duration or duty-cycle limits for current larger than 11 A. If the Calibrator
goes above the duration or duty cycle, the Calibrator will turn off. After a
cool-off period, the Calibrator changes to usual operation.
1. Push to clear output from the Calibrator.
2. Connect the UUT as in the “Connect the Calibrator to a UUT” section of this chapter.
3. Set the UUT to measure dc current on the necessary range.
4. Push the numeric keys and decimal point key to record the necessary current output
(maximum six numeric keys). For example, 234.567.
5. Push to select the polarity of the current (default is +).
6. Push a multiplier key, if necessary. For example, .
7. Push .
8. The Control Display shows the amplitude of the entry. For example, 234.567 mA.
nn077f.eps
9. Push . The Calibrator removes the entry from the Control Display and copies
it into the Output Display (below is typical).
nn078f.eps
10. Push to start the Calibrator output.
4-23
Page 98
5502A
Operators Manual
Set AC Current Output
A range softkey is shown on the Control Display in the dc current function (operating
range). This selects autorange (auto) or lock (locked) for the given range. When auto (the
default) is selected, the Calibrator automatically selects the range that gives the best
output resolution. When locked is selected, the Calibrator will not change ranges when
you edit the output. The locked selection is typically made to prevent range changes that
can cause a small agitation in the output, for example, when you measure the linearity of
a given multimeter range.
A different softkey shows: OUTPUT. When you select 20 A for this parameter, or you
select a current more than 3 A, the Calibrator switches to standby, and you must change
the test lead to the 20A terminal and push to activate the output.
Do the subsequent procedure to set an ac current output at the AUX or 20A terminals. If
you make an entry error, push to clear the display, then reenter the value.
1. Push to clear any output from the Calibrator,
2. Connect the UUT as in the “Connect the Calibrator to a UUT” section of this chapter.
3. Set the UUT to measure ac current on the necessary range.
4. Push the numeric keys and decimal point key to record the necessary current output
(maximum six numeric keys). For example, 123.456.
5. Push a multiplier key, if necessary. For example, push .
6. Push .
7. The Control Display shows the amplitude of your entry. For example, 123.456 mA
(see below).
nn079f.eps
8. Push the numeric keys and decimal point key to record the necessary frequency
output (maximum five numeric keys). Push a multiplier key, if necessary. For
example, push the kilo multiplier key . Then push the key. For example,
1.1234 kHz (see below).
nn080f.eps
4-24
Page 99
Front-Panel Operation
Set Output 4
9. Push . The Calibrator erases your entry from the Control Display and copies
it into the Output Display (below is typical).
nn081f.eps
10. Push to activate the Calibrator output.
gvx321f.eps
• LCOMP turns inductive compensation on and off. Inductive compensation is
available for frequencies to a maximum of 1 kHz at outputs to a maximum of
239.999 mA, and for frequencies to a maximum of 440 Hz more than 239.999 mA.
• OUTPUT shows if the output is on the AUX or 20A terminals. Outputs 3 A or above
are always on the 20A terminals.
• WAVE (waveform) selects one of four different types of waveforms: sine wave,
triangle wave, square wave, and truncated sine wave. (See “Waveform Types” later
in this chapter for more information). When a non-sinusoidal waveform is selected,
the Output Display changes the RMS indication to p-p (P
).
P
Set DC Power Output
Tie the terminals NORMAL LO and AUX LO together at the UUT or at the
Calibrator, with the “LO”s softkey selection “tied.”
The Calibrator makes a dc power output by sourcing a dc voltage on the NORMAL
outputs and a dc current on the AUX outputs. Complete the subsequent procedure to set a
dc power output. If you make an entry error, push one or more times to clear the
display, then reenter the value.
Note
4-25
Page 100
5502A
Operators Manual
Caution
To prevent damage to the UUT, makes sure the applied voltage to
the UUT is not larger than the rating of the UUT insulation and the
connection wires.
1. Push to clear any output from the Calibrator.
2. Connect the UUT as in the “Connect the Calibrator to a UUT” section of this chapter.
Change the voltage and current connections to this procedure.
3. Set the UUT to measure dc power on the necessary range.
4. Push the numeric keys and decimal point key to record the necessary voltage output
(maximum seven numeric keys). For example, 123.4567.
Note
At voltage outputs of 100 V and above (nominal), the Calibrator usually
makes a small high-pitched sound.
5. Push to select the polarity of the voltage (default is +).
6. Push a multiplier key, if necessary. For example, push .
7. Push .
8. The Control Display shows the amplitude of your entry. For example, 123.4567 mV
(see below).
nn071f.eps
9. Push the numeric keys and decimal point key to record the necessary current output
(maximum six numeric keys). For example, 234.567.
10. Push to select the polarity of the current (default is +).
11. Push a multiplier key, if necessary. For example, push .
12. Push .
13. The Control Display shows the amplitude of your entries. For example, 123.4567 mV
and 234.567 mA ( see below).
nn082f.eps
4-26
Loading...
