Fluid OASIS MOTORIZED MP3 MUSIC ISLAND, FL95003 User Manual
3a. Connect the Steering Column to the Nozzle (See Fig. 3).
You will hear a “Click” sound once it has been correctly
connected.
3b. Slide the Steering Column / Nozzle from the bottom of the
inflatable through the Steering Sleeve. You will hear a
“Click” sound once it has completely passed through the
Steering Sleeve (See Fig. 4).
TIP: If the Steering Column Sleeve is stuck, pour some water to
lubricate and then push it down.
4. Attached the Steering Unit to the Steering Column. You will
hear a “Click’ sound once it has been correctly connected
(See Fig. 5).
5. Make sure the Nozzle and the Steering unit are correctly
aligned. (See Fig. 5)
TO USE THE OA SIS MOT ORIZED M P3 MUSI C ISLAND ,
FOLLOW TH ESE INSTR UCTIONS
1. Charge the battery before use - refer to ”Battery Use” for
instructions.
2. Place the OASIS MOTORIZED MP3 MUSIC ISLAND in the
water.
3. When ready to set off, turn the Master Switch to the ON
position (See Fig. 6).
4. Press the controller to start, turn the steering unit to
maneuver and release the controller to stop.
TO CONNECT YOUR MP3 PLAYER TO THE SPEAKER
SYSTEM, FOLLOW THESE INSTRUCTIONS
1. Connect the plug inside the waterproof pouch to your MP3
player and seal the bag. (See Fig. 7)
2. Connect the plug outside the waterproof pouch to the plug
inside the waterproof pocket on the OASIS MOTORIZED
MP3 MUSIC ISLAND and seal the pocket.
3. Turn on your MP3 player. Your MP3 player can then be
used to play music and control the volume.
WARNING: Please disassemble, properly pack into the
box / carrybag and store in in-house area while not in use.
DO NOT storage in garage, outside open area or outdoor
during the Fall/winter season.
8. Unplug the Charger from the mains before you unplug the battery from the charger.
9. Connect the battery and install it, making sure to insert it the right way around
(See Fig. 13, B).
11. Replace the Speaker Battery Cover
1. The battery should be recharged as soon as possible after use.
2. If this product is not used for extended periods, the battery should be removed from the
unit and charged overnight, every three months.
3. Only use the charger supplied with this product
4. Never place the battery in a sealed container when charging.
5. Never short-circuit the battery or battery cable.
6. Never place/store the battery near a radiator/fire, etc.
7. To store the battery, remove it from the Battery Compartment and keep in a place that is
dry and cool with the rest of the unit in the original box.
8. Rechargeable batteries are to be removed from the Battery Compartment before
being charged.
9. Rechargeable batteries are only be charged under adult supervision.
10. The battery charger should be required examined by an adult for potential hazard, such as
damage to the cable or cord, plug, encloser or other parts, and that, in the event of
damage, the charger must not be used until that damage has been properly removed.
11. Remove the battery from the battery compartment immediately after use.
12. Dirt and sand can damage the seals in the battery compartment. Always ensure that the
seals are cleaned and lubricated before closing and sealing the cover.
Parts Diag ram
Getting Started
USER MANUAL
IMPORTANT: Keep all packaging for future reference
Model No. FL95003
OASIS MOTORIZED MP3 MUSIC ISLAND
ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 14 years of age.As with all electrical products,
precautions should be observed during handling and used to reduce the risk of electric shock.
Read the User Manual carefu lly before usi ng this produc t. ● This is not a lifesaving de vice.
● This is not a boat. ● DO NOT leave children unattended while in use. ● Always wear a coast
guard approved personal floatation device. ● Use in a pool or in calm water and close to shore.
● DO NOT use in open waters, high winds, rapid current, dangerous tides, in waves, wakes or
in bad weather conditions as it may not allow you to come back to shore. ● NEVER stick body
parts, clothing or other objects in the vicinity of the propeller. ● DO NOT wear loose or flowing
clothing or equipment that could be drawn into the Propeller. ● Particular care should be
exercised when using this product near any body with long hair. Users with long hair should tie
it up or wear a swimming cap when using this product. ● Always charge battery to its fullest
before using this p roduct. Ensur e suff icient batter y charg e rema ins fo r retu rn to shore.
● ALWAYS inspect the swimming area to ensure it is free of hazards or obstacles such as boats
and swimmers before using this product. ● Be aware of appropriate water levels, tidal changes,
dangerous currents, weather changes and strong offshore winds. Always scout unfamiliar
water. ● DO NOT use alcohol or mind-altering drugs prior to using this product. ● DO NOT
operate this product out of the water to avoid damage. ● ALWAYS keep this product out of
direct sunlight when not in use. HEAT KILLS BATTERIES. ● Children under 14 years old should
NEVER operate this product. ● DO NOT ride over swimmers or other objects ● DO NOT use at
night or in low light situations. ● This product is to be operated only when fully assembled in
accordance with the instructions. ● NEVER leave in or near water when not in use. ● NEVER
tow from any vehicle ● Adults should inflate the chambers in numbered sequence ● NEVER
allow diving into this product ● Not for use of more than 6 people, not exceeding 924lbs/420kgs.
● DO NOT turn up side down of this product while in use. ● Please disassemble, properly pack
into the box/carrybag and store in in-house area while not in use. ● DO NOT store in garage,
outside open area or outdoor during the Fall/Winter season. ● Filled with cold air only. ● DO
NOT over inflate or use high pressure pump to inflate. ● Inflate the small chambers slowly.
WARNING
CAUTION
THIS IS NOT A LIFESAVING DEVICE
Fig. 1 Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
Fig. 14
CHARGING THE PROPELLER BATTERY
For battery charging follow these instructions.
1. Always ensure that the Master Switch is OFF (See Fig. 6).
2. Always ensure that the unit is out of the water and placed
in a dry area.
3. Unscrew the Battery Door using a coin or similar to
remove. (See Fig. 8).
4. Allow two minutes for any gasses to dissipate.
5. Take out the battery from the Battery Compartment.
6. Connect the Battery to the Charger. (See Fig. 9)
7. Plug the Charger into mains, and turns on the supply.
8. Charging will take 6-10 hours for a fully discharged battery.
when the battery is charging the LED on the charger turns
RED. When the battery is charged the LED turns GREEN.
9. Unplug the Charger from the mains.
10. Unplug the battery from the charger.
11. Connect the battery and install it, making su re to insert it
the right way arou nd (See Fig. 10, A), and all wires are
moved clear of the screw area (See Fig. 10, B)
12. Make sure the seal and sealing surfaces are clean and
lubricated before replacing ] the Battery Door ‘ (See fig.11).
Use silicon grease to lubricate the seal - this can be
purchased from your local hardware store.
13. Replace the Battery Door and turn the Battery Door Screw
making sure it is tightened completely. (Se Fig. 12).
REPLACING A FLAT PROPELLER BATTERY
To replace a flat batt ery with a fully charg ed battery,
follow thes e instructi ons.
1. Follow the steps 1 to 5 above.
2. Remove the flat battery.
3. Install and connect the charged battery.
4. Follow steps 12 to 13 above.
CHARGING THE SPEAKER BATTERY
For battery charging follow these instructions.
1. Always ensure that the unit is out of the water and
placed in a dry area.
2. Unscrew the Speaker Battery Cover. (See Fig. 13, A).
3. Allow two minutes for any gasses to dissipate.
4. Take out the battery from the Battery Compartment.
5. Connect the Battery to the Charger. (See Fig. 14)
6. Plug the Charger into mains, and turns on the supply.
7. Charging will take 4-5 hours for a fully discharged
battery. when the battery is charging the LED on the
charger turns RED. When the battery is charged the
LED turns GREEN.
When you use the OASIS MOTORIZED MP3 MUSIC ISLAND for the first time, the Inflatable
needs to be assembled and the battery needs to be charged. Follow the instructions in “Battery
Use”, for charging and connection.
To assemble the OASIS MOTORIZED MP3 MUSIC ISLAND follow these instructions.
1. Slide the Steering Sleeve into the hole in the Inflatable from the top. (See Fig. 1)
2. Use a 12V car adapter pump (i ncluded) to blow up the Island in the sequence shown
(See Fig. 2). 1 - 6 outside cushions, 7 inside ring, 8 outside ring. The n inflate the drink
cooler 9 lid and 10 floatation ring. Clos e the valve for each c hamber once inflated.
NOTE: Recommended inflated pressure is 0.3 psi.
Battery Use
2
1
6
5
4
3
7
8
9
10
ON
OFF
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
A
B
A
B
FLUID® and the LIQUID DRIP logo are trademarks of Stallion Sport or its affiliates, used under licence to Stallion (asia) Ltd. FLP95006
Battery and Charger Care
A repair kit is included in case the inflatable is accidentally punctured, to repair:
1. Locate the puncture - this can be done by inflating the inflatable and looking for air bubbles.
2. Deflate the inflatable and make sure it is completely dry.
3. Clean punctured area and dry the area.
4. Using in flat abl e r epai r k it a ppl y gl ue arou nd punctured area.
5. Use repair PVC sheet, cut so it is 5mm bigger around the punctured area.
6. Stick the repair sheet on top of the punctured area.
7. Let it dry for 2 hours.
8. Inflate the inflatable and check there is no air leakage before use.
REPAIRING T HE INFLATAB LE
19
1. Inflatable
2. Steering Unit
3. Master Switch
4. Steering Column
5. Steering Column
Sleeve
6. Nozzle
7. Battery Door
8. Battery Door Seal
9. Inflatable Repair Kit
and Air Release Kit
10. Rechargeable
Battery
11. Charger
12. Rear Grille
13. Drink Cooler
14.Waterproof Pouch
15. Speaker Battery
Box Cover
16. Speaker Battery
17. Speakers
18. Cup Holders
19. Electric Pump
15
16
14
12
13
10
11
2
1
4
5
3
9
7
6
8
17
18
ALWAYS WASH ALL COMPONENTS IN CLEAN FRESH
WATER AFTER USE
Disassemble and wash all of the components in fresh water after use
to avoid corrosion and unnecessary wear and tear.
ALWAYS DRY ALL COMPONENTS BEFORE STORING
ALWAYS RECHARGE THE BATTERY WITHIN 24 HOURS
OF USE
ALWAYS RECHARGE THE BATTERY EVERY 3 MONTHS
AND AFTER USE
Ensure every valve on the inflatable is completely sealed
after inflation.
Inspect all valves every 2 hours after inflation
Always inspect the pressure of the inflatable when in use.
CARE INSTRUCTIONS
ATTENTION
WARNING
Lead acid battery generates explosive gasses.
Use, recharge and store in a well ventilated area.
IMPORTANT
ALWAYS RECHARGE THE BATTERY WITHIN 24 HOURS OF USE
ALWAYS RECHARGE THE BATTERY EVERY 3 MONTHS AND AFTER USE
DISPOSE OF THE BATTERY ACCORDING TO MUNICIPAL
LAWS AND REGULATION
THIS BATTERY TYPE IS DESIGNED TO BE RECHARGED UP TO 200
TIMES OR 2 YEARS AFTER PURCHASE, WHICHEVER COMES FIRST.
