Compact Lev
ch-
el Controller
ro™
C10 and
LC11 Se
ries Man
ual
Flowli
e, Inc. | 10500 H
mbolt Street, Los
Alamitos, CA 907
0 p 562.598.301
f 562.431.8507 w flowline.com MN301510 Rev A1
Introduction / Table of Contents Step One
The LC10 & LC11 Series Controllers
are general-purpose level controllers offered in two configurations for
pump and valve control. The LC10 Series features a single 16A SPDT relay output and can accept one level
sensor as an input. This package has an optional flashing alarm and is ideal for high level or low level
alarm/control. The LC11 Series features a single 16A SPDT latching relay output and can accept one or two
level sensor(s) as an input. This package is ideal for the automatic filling or emptying of a tank. Package this
level controller with our liquid level switch sensors and fittings.
FEATURES
Fail-Safe relay control of pumps, valves or alarms with a 0 to 60 second delay
Optional flashing alarm brings immediate attention to level alarm conditions.
Polypropylene enclosure rated NEMA 4X with swivel base for conduit alignment.
Easy setup with LED indicators for sensor(s), power and relay status.
Invert switch changes relay state from NO to NC without rewiring.
AC powered
TABLE OF CON
TENTS
Specifications: ....................................................................................................................................................... 3
Dimensions: .......................................................................................................................................................... 3
Controller Labels: ...................................................................................................................................... 4
Functional Diagram: .................................................................................................................................. 4
Safety Precautions: ............................................................................................................................................... 5
Make a Fail-Safe System: ......................................................................................................................... 6
Getting Started: ..................................................................................................................................................... 7
Components: ............................................................................................................................................. 7
Features of the LC10 Series Single Input Controller: ............................................................................... 8
Features of the LC11 Series Dual Input Controller: .................................................................................. 9
Guide to Controls: ................................................................................................................................... 10
Wiring: ................................................................................................................................................................ 11
Connecting Switches to Input Terminals: ................................................................................................ 11
LED Indication: ........................................................................................................................................ 11
VAC Power Input Wiring: ........................................................................................................................ 11
Relay Input Wiring: .................................................................................................................................. 11
Strobe Alert Output: ................................................................................................................................ 12
Changing from 120 to 240 VAC:
............................................................................................................. 12
Installation: .......................................................................................................................................................... 13
Application Examples: ........................................................................................................................................ 14
Low Level Alarm: .................................................................................................................................... 14
High Level Alarm: .................................................................................................................................... 14
Pump Protection: .................................................................................................................................... 15
Automatic Fill: ......................................................................................................................................... 15
Automatic Empty: .................................................................................................................................... 16
Leak Detection: ....................................................................................................................................... 16
Appendix: ............................................................................................................................................................ 17
Relay Latching Logic Table (LC11 Series only): ..................................................................................... 18
Controller Logic: ...................................................................................................................................... 18
Time Delay: ............................................................................................................................................. 18
Troubleshooting: ..................................................................................................................................... 19
Warranty: ............................................................................................................................................................ 20
| 2 MN301510 Rev A1
Specifications / Dimensions Step Two
SPECIFICATIONS: DIMENSIONS:
Controller
Supply voltage: 120 / 240 VAC, 50 - 60 Hz.
Consumption: 5 Watts max.
Sensor inputs: LC10: (1) level switch
LC11: (1 or 2) level switches
Sensor supply: 13.5 VDC @ 27 mA
LED indication: Sensor, relay & power status
Contact type: LC10: (1) SPDT Relay
LC11: (1) SPDT Relay, Latched
Contact rating: 250 VAC, 16A – Non CE
250 VAC, 12A – CE version
Contact output: Selectable NO or NC
Contact delay: 0 to 60 seconds
Contact latch: Select On/Off – (LC11 series only)
Electronics temp.: F: -40°to 158°
C: -40°to 70°
Enclosure rating: NEMA 4X (IP65)
Enclosure material: -10_1: PP(U.L. 94 VO)
-10_2: PP(U.L. 94 VO) & Polycarbonate
Enclosure mount.: ¾” NPT (¾” Rc)
Enclosure rotation: 300°swivel base
Conduit entrance: Single, 1/2" NPT
Certificate number: LR 79326-3
CE compliance*: EN 61326 EMC
EN 61010-1 Safety
* Non-CE versions will not have CE mark
Strobe Alert
Flash type: Xenon tube
Flash frequency: 1 per second
Strobe life: 10M cycles
Supply voltage: 120 VAC, 50-60 Hz.
Consumption: 3 Watts max.
Material: Polycarbonate
Enclosure rating: NEMA 4X (IP65)
Color: Amber
LC10 & LC11 Series with Strobe Alert
Side View
LC10 & LC11 Series
Side View
MN301510 Rev A1 3 |
Specifications / Dimensions Step Two
CONTROLLER LABELS
LC10 Series (Non CE Version) LC11 Series (Non CE Version)
LC10 Series (CE Version) LC11 Series (CE Version)
FUNCTIONAL DIAGRAM
| 4 MN301510 Rev A1
Safety Precautions Step Three
About This Manual: PLEASE READ THE ENTIRE MANUAL PRIOR TO INSTALLING OR USING THIS
PRODUCT. This manual includes information on three different models of Compact Relay Controllers from
Flowline: LC10 and LC11 Series. The LC10 series is a single-input controller with an optional Flash Alarm
and the LC11 Series is a dual-input controller. Many aspects of installation and use are similar between
the three models.
User’s Responsibility for Safety: FLOWLINE manufactures several models of controller, with different
mounting and switching configurations. It is the user’s responsibility to select a controller model that is
appropriate for the application, install it properly, perform tests of the installed system, and maintain all
components.
Electrical Shock Hazard: It is possible to contact components on the controller that carry high voltage,
causing serious injury or death. All power to the controller and the relay circuit(s) it controls should be
turned OFF prior to working on the controller. If it is necessary to make adjustments during powered
operation, use extreme caution and use only insulated tools. Making adjustments to powered controllers is
not recommended. Wiring should be performed by qualified personnel in accordance with all applicable
national, state and local electrical codes.
Flammable or Explosive Applications: Sensor mount controllers should not be used with explosive or
flammable liquids, which require an intrinsically safe or explosion proof rating. If you are unsure of the
suitability of a controller for your installation, consult your Flowline representative for further information.
Install In a Dry Location: The LC10 & LC11 Series controller housing is liquid-resistant and made of
Polypropylene (PP). When installed properly, the controller is not designed to be immersed. It should be
mounted in such a way that it does not normally come into contact with fluid. Refer to an industry
reference to ensure that compounds that may splash onto the controller housing will not damage it. Such
damage is not covered by the warranty.
Relay Contact Rating: The relay is rated for a 16 amp (12 amp – CE version) resistive load. Many loads
(such as a motor during start-up or incandescent lights) are reactive and may have an inrush current
characteristic that may be 10 to 20 times their steady-state load rating. The use of a contact protection
circuit may be necessary for your installation if the 16 amp rating does not provide an ample margin for
such inrush currents.
Safety Cover: Based upon the part number selected, a safety cover has been placed within the enclosure.
Always replace the safety cover after any service.
Standard Version (Non-CE)
CE Version (LC1_-10_1-CE / LC1_-10_1-E-CE)
MN301510 Rev A1 5 |
Safety Precautions Step Three
Make a Fail-Safe System: Design a fail-safe system that accommodates the possibility of relay or power
failure. If power is cut off to the controller, it will de-energize the relay. Make sure that the de-energized
state of the relay is the safe state in your process. For example, if controller power is lost, a pump filling a
tank will turn off if it is connected to the Normally Open side of the relay.
While the internal relay is reliable, over the course of time relay failure is possible in two modes: under a
heavy load the contacts may be “welded” or stuck into the energized position, or corrosion may buildup on
a contact so that it will not complete the circuit when it should. In critical applications, redundant backup
systems and alarms must be used in addition to the primary system. Such backup systems should use
different sensor technologies where possible.
While this manual offers some examples and suggestions to help explain the operation of FLOWLINE
products, such examples are for information only and are not intended as a complete guide to installing any
specific system.
| 6 MN301510 Rev A1
Getting Started Step Four
COMPONENTS:
Part Number
LC10-1001
LC10-1051 Rc
LC10-1002
LC10-1052 Rc
LC10-1001-CE
LC10-1051-CE Rc
LC10-1002-CE
LC10-1052-CE Rc
LC11-1001
LC11-1051 Rc
LC11-1002
LC11-1052 Rc
LC11-1001-CE
LC11-1051-CE Rc
LC11-1002-CE
LC11-1052-CE Rc
Owner’s Manual
240 VAC OPTION:
When ordering any 240 VAC version of the LC10 series, the sensor will arrive configured for 240 VAC
operation. If a Strobe Alert is included, then the Strobe Alert will also be configured for 240 VAC power.
240 VAC versions will include a –E to the part number (i.e. LC10-1001-E).
CE
Compliant
NO
YES
NO
NO
YES
NO
CSA
Approval
YES
NO
NO
YES
NO
NO
Thread
NPT
NPT
NPT
NPT
NPT
NPT
NPT
NPT
Strobe
Alert
No
Yes
No
Yes
No
Yes
No
Yes
Input(s) Description
High Level,
Low Level or
Single
Dual
Pump
Protection
Controller
Automatic Fill,
Automatic
Empty, High
Level, Low
Level or
Pump
Protection
Controller
STROBE ALERT OPTION:
When ordering a version of the LC10 series with the Strobe Alert, strobe will require the same power as the
controller. I.e. if you ordered the LC10-1002, the strobe will be powered from 120 VAC, just like the controller.
If you ordered the LC10-1002-E, the strobe will be powered from 240 VAC, just like the controller.
MN301510 Rev A1 7 |
Getting Started Step Four
FEATURES OF THE LC10 SERIES SINGLE INPUT CONTROLLER:
The LC10 Series are designed to receive a signal from a single liquid sensor. It turns its internal relay ON or
OFF (as set by the invert switch) in response to the presence of liquid, and changes the relay status back
again when the sensor is dry.
High Alarm:
Invert is OFF. Relay will energize when the switch becomes Wet and will de-energize when the switch
becomes Dry (out of liquid).
Low Alarm:
Invert is ON. Relay will energize when the switch becomes Dry (out of liquid) and will de-energize when the
switch becomes Wet.
The LC10 Series may be used with almost any kind of sensor signal: current sensing or contact closure. The
relay is a single pole, double throw type; the controlled device can be connected to either the normally open or
normally closed side of the relay. A time delay from 0 to 60 seconds can be set before the relay responds to
the sensor input. Typical applications for the LC10 Series are high level or low level switch/alarm operations
(opening a drain valve whenever liquid level rises to a sensor point) and leak detection (sounding an alarm
when a leak is detected, etc.).
| 8 MN301510 Rev A1
Getting Started Step Four
FEATURES OF THE LC11 SERIES DUAL INPUT CONTROLLER:
The LC11 Series is designed to receive signals from two liquid sensors. It turns its internal relay ON or OFF
(as set by the invert switch) in response to the presence of liquid on both sensors, and changes the relay
status back again when both sensors are dry.
Automatic Empty:
Latch is ON & Invert is OFF. Relay will energize when level reaches high switch (both switches are wet).
Relay will de-energize when level is below the bottom switch (both switches are dry).
Automatic Fill:
Latch is ON & Invert is ON. Relay will energize when level is below the bottom switch (both switches are dry).
Relay will de-energize when level reaches high switch (both switches are wet).
The LC11 Series may be used with almost any kind of sensor signal: current sensing or contact closure. The
relay is a single pole, double throw type; the controlled device can be connected to either the normally open or
normally closed side of the relay. A time delay from 0 to 60 seconds can be set before the relay responds to
the sensor input. Typical applications for the LC11 Series are automatic filling (starting fill pump at a low level
and stopping pump at a high level) or automatic emptying operations (opening a drain valve at a high level and
closing valve at low level).
MN301510 Rev A1 9 |
Getting Started Step Four
GUIDE TO CONTROLS:
Below is a listing and the location of the different components for the controller:
Standard Version (Non-CE)
1. Power indicator: This green LED lights when AC power is ON.
2. Relay indicator: This red LED will light whenever the controller energizes the relay, in response to the
proper condition at the sensor input(s) and after the time delay.
3. AC Power terminals: Connection of 120 VAC power to the controller. The setting may be changed to
240 VAC if desired. This requires changing internal jumpers; this is covered in the Installation section
of the manual. Polarity (neutral and hot) does not matter.
4. Relay terminals (NC, C, NO): Connect the device you wish to control (pump, alarm etc.) to these
terminals: supply to the COM terminal, and the device to the NO or NC terminal as required. The
switched device should be a non inductive load of not more than 16 amps; for reactive loads the current
must be derated or protection circuits used. When the red LED is ON and the relay is in the energized
state, the NO terminal will be closed and the NC terminal will be open.
5. Invert switch: This DIP switch reverses the logic of the relay control in response to the sensor(s):
conditions that used to energize the relay will make it turn off and vice versa.
6. Latch switch (LC11 Series only): This DIP switch determines how the relay will be energized in
response to the two sensor inputs. When LATCH is OFF, the relay responds to sensor Input 1A only;
when LATCH is ON, the relay will energize or de-energize only when both sensors (1A and 1B) are in
the same condition (wet or dry). The relay will remain latched until both sensors change states.
7. Time Delay: After the input(s) change(s) state, this control sets a delay from 0.15 to 60 seconds
before the relay will respond.
8. Input 1A and 1B indicator: These amber LEDs will light immediately whenever the appropriate
sensor attached to the terminals detects liquid, and will turn off when it is dry.
9. Input terminals: Connect the wiring from the sensors to these terminals: A to the upper pair, B (LC11
Series only) to the lower pair. Note the polarity: (+) is a 13.5 VDC, 27 mA power supply (to be
connected to the red wire of a Flowline sensor), and (-) is the return path from the sensor (to be
connected to the black wire of a Flowline sensor). Do not reverse the polarity of the Red and Black
wires, the sensors will not work.
CE Version (LC1_-10_1-CE / LC1_-10_1-E-CE)
| 10 MN301510 Rev A1
Wiring Step Five
CONNECTING SWITCHES TO INPUT TERMINALS:
Please note a difference between FLOWLINE powered level switches and mechanical reed switches. All
powered level switches (series LZ12, LU10, LP15, LP50 & LO10 series) will be wired with the Red wire to the
(+) terminal and the Black wire to the (-) terminal. FLOWLINE mechanical reed switches (series LV10, LV2_,
LV3_, LV4_, LH2_ & LH3_ series) will have a particular wiring based upon part number. See the illustration
below to indicate wiring for your switch.
Note: the Shield wire will be used only for long cable runs or where excessive electrical noise is present.
Powered
Level Switches:
LZ12, LU10
LP15, LP50
& LO10 Series
Mechanical
Reed Switches:
LV10*, LV2_, LV3_,
LV4_, LH2_ &
LH3_ Series
* LV10 series can be wired using the White and Black wires for NO operations or the Red and Black wires for
NC operations.
LED INDICATION:
Use LED's located above the input terminals to indicate whether the switch is in a wet or
dry state. With most switch configurations, an Amber LED indicates the sensor is in
contact with liquid (wet) and no LED indicates the sensor is out of the liquid (dry).
Note: Mechanical reed switches (LV10, LV20, LV30, LV40, LH20, LH30 series etc.) may
be wired in reverse so that Amber indicates a dry state and no LED indicates a wet state.
VAC POWER INPUT WIRING:
Observe the labeling on the LC10 & LC11 series
controller. The terminals for the power share the
same terminal block as the relay.
Note: Polarity does not matter with the AC input
terminal.
RELAY INPUT WIRING:
The relay is a single pole, double throw type rated at 250 Volts AC, 16A (12A CE
version). The two terminals, NO and NC (normally open and normally closed), will be
used in different applications.
Note: The relay contacts are true dry contacts. There is no voltage sourced within
the relay contacts.
Note: The "normal" state is when the relay coil is de-energized and the Red relay
LED is Off / de-energized.
MN301510 Rev A1 11 |
Wiring Step Five
STROBE ALERT OUTPUT:
While wired NO, Strobe Alert can be used as a high or
low level alarm, depending on the setting for the invert
switch. The Strobe Alert can also be wired NC.
Note: Strobe Alert needs to be powered. Since the
relay is a true dry contact, power will need to be
added. Power can be added via a separate power
supply or shared from the supply powering the
controller.
Separate Power Supply Shared Power Supply
CHANGING FROM 120 TO 240 VAC:
1. Remove the two screws from the top of the printed circuit board (PCB) and gently slide the PCB from the
housing. Use caution when removing the PCB.
2. Located jumpers JWA, JWB and JWC on the PCB.
3. To change to 240 VAC, remove jumpers from JWB and JWC and place a single jumper across JWA. To
change to 120 VAC, remove jumper JWA and place jumpers across JWB and JWC.
4. Gently return PCB into housing and replace the two screws.
120 VAC 240 VAC
Controllers
Non-CE Version
CE Version
Controllers
240 VAC OPTION:
When ordering any 240 VAC version of the LC10 series, the sensor will arrive configured for 240 VAC
operation. If a Strobe Alert is included, then the Strobe Alert will also be configured for 240 VAC power.
240 VAC versions will include a –E to the part number (i.e. LC10-1001-E).
| 12 MN301510 Rev A1
Installation Step Six
SENSOR-MOUNT CONTROLLERS:
The LC10 & LC11 Series are a cost-effective, modular liquid level controller whose body incorporates a female
3/4" NPT (3/4" R) fitting, allowing it to be mounted directly onto any Flowline sensor or any 3/4" connection.
Simply provide its required AC power and a controlled device such as a valve, pump, or alarm that can be
switched by the controller’s relay in response to the sensor input.
Sensor-mount controllers are particularly appropriate for simple processes such as high or low alarms. They
can also be a useful part of more complicated systems, providing a fail-safe backup in case a centralized
system fails.
3/4" NPT MOUNTING THREAD:
Installation of the compact relay controller takes advantage of the 3/4" NPT thread located on its base. This
makes the controller fully compatible with any of Flowline's level switches or Smart Trak™ or Switch Pak™
mounting systems.
Mounting directly to a sensor Mounting to Smart Trak
Mounting System
Note: Always tighten the controller
from the wrench flat located on the
swivel base. Never tighten from the
body of the controller.
Mounting to Switch-Pak
Mounting System
SWITCH CABLE:
When installing an Flowline level switch, adjust the
cable away from the printed circuit boards in the
controller body. Avoid breaking the seal between the
top of the level switch and the plastic coated cable.
MN301510 Rev A1 13 |
Application Examples Step Seven
LOW LEVEL ALARM:
The goal is to make sure that an operator is notified if the liquid level falls below a certain point. If it does, an
alarm will sound, alerting the operator of a low level. A level switch must be mounted at the location where the
alarm will sound.
In this application, the level switch will be Wet all the time. When the level switch becomes Dry, the relay
contact will close causing the alarm to activate. Normal status for the application is for the controller to hold
the relay open with the alarm wired through the Normally Closed contact. The Relay will be energized, the
relay LED will be On and Invert will be Off. When the level switch becomes Dry, the relay will de-energize
causing the contact to close allowing the alarm to activate.
To do this, connect the hot lead of the alarm to the NC side of the relay terminal of the controller. If power is
lost, the relay will be de-energized, and the alarm will sound (if there is still power to the alarm circuit itself).
Note: If power is accidentally cut to the controller, the level switch’s ability to notify the operator of a low level
alarm could be lost. To prevent this, the alarm circuit should have a non-interruptible power supply or some
other independent power source.
HIGH LEVEL ALARM:
In the same manor, this system can be used to sound an alarm when fluid reaches a high level, with just a
change in the location of the sensor and the setting of the Invert switch.
The alarm is still connected to the NC side of the relay to allow for a power failure alarm.
The sensor is normally dry. In this condition, we want the relay to be energized so the alarm does not sound:
i.e., the Red relay LED should be on whenever the Input LED is Amber. So we turn Invert On. If the fluid level
rises to the high sensor point, the sensor goes on, the relay de-energizes, and the alarm sounds.
| 14 MN301510 Rev A1
Application Examples Step Seven
PUMP PROTECTION:
The key here is to install a level switch just above the outlet
to the pump. As long as the switch is Wet, the pump can
operate. If the switch ever becomes Dry, the relay will open
preventing the pump from running. To prevent relay chatter,
add a small relay delay.
Note: In this application, the relay to the pump must be
closed while the level switch is Wet. To do this, connect the
relay through the NO side of the relay and set Invert to the
OFF position. If power is lost to the controller, the relay will
de-energize and keep the circuit open preventing the pump
from running.
AUTOMATIC FILL:
This system consists of a tank with a high level sensor, a low level
sensor, and a valve that is controlled by the controller. Part of a
proper fail-safe design for this particular system is that if power is lost
to the controller for any reason, the valve filling the tank must be
closed. Therefore, we connect the valve to the NO side of the relay.
When the relay is energized, the valve will open and fill the tank. In
this case, Invert should be ON. The relay indicator will correspond
directly to the open/close status of the valve.
Determining the settings of LATCH and INVERT: This is the way
the system must operate:
When both the high and low sensors are dry, the valve will
open (relay energized), starting to fill the tank.
When the low sensor gets wet, the valve will remain open
(relay energized).
When the high sensor gets wet, the valve will close (relay de-
energized.
When the high sensor becomes dry, the valve will remain
closed (relay de-energized).
Latch: In any two-sensor control system, LATCH must be ON.
Invert: Referring to the logic chart in Step Eight, we look for the setting that will de-energize the relay (start the
pump) when both inputs are wet (Amber LEDs). In this system, Invert should be ON.
Determining A or B input connections: When LATCH is ON, there is no effective difference between Input
A and B, since both sensors must have the same signal in order for status to change. When wiring any twoinput relay section, the only consideration for hooking a particular sensor to A or B is if LATCH will be OFF.
MN301510 Rev A1 15 |
Application Examples Step Seven
AUTOMATIC EMPTY:
Similar system logic can be used for an automatic empty operation. In
this example, we will use a pump to empty a tank. The system still
consists of a tank with a high level sensor, a low level sensor, and a
pump that is controlled by the controller.
Note: Fail-safe design is critical in an application where the tank is
passively filled. A power failure to the controller or the pump circuits
may cause the tank to overflow. A redundant high alarm is critical to
prevent an overflow.
Connect the pump to the NO side of the relay. In this case, Invert
should be OFF, when the relay is energized, the pump will run and
empty the tank. The relay indicator will correspond directly to the
on/off status of the pump.
Note: If the pump motor load exceeds the rating of the controller’s
relay, a stepper relay of higher capacity must be used as part of the
system design.
LEAK DETECTION:
A leak detection switch is installed either inside the interstitial space of the tank or through the outer wall. The
switch will remain wet 99.99% of the time. Only when liquid comes into contact with the switch will the relay
close to activate an alarm.
The alarm is connected to the NC side of the relay to allow for a power failure alarm.
Note: The sensor is normally dry. In this condition, we want the relay to be energized so the alarm does not
sound: i.e., the Red relay LED should be on whenever the Input LED is Amber. So we turn Invert On. If liquid
comes into contact with the switch, the switch activates, the relay de-energizes, and the alarm sounds.
| 16 MN301510 Rev A1
Appendix Step Eight
RELAY LOGIC – LATCHING RELAY
Latching relay will only switch when both level switches are in the same state.
One Switch Dry, One Wet Both Switches Wet Both Switches Dry
In this state, the relay will never
switch, regardless if this is an Auto
Fill or Auto Empty application.
In this state, the relay will typically
energize for an Auto Empty
application and will typically deenergize for an Auto Fill
In this state, the relay will typically
energize for an Auto Fill application
and will typically de-energize for an
Auto Empty application.
application.
Note: The state of the application (either filling or emptying) can never be confirmed when one switch is Wet
and the other is Dry. Only when both switches are in the same state (both Wet or both Dry) can confirmation
of the relay status (energized or de-energized) occur.
Note: Always check the status of the level switches and compare that status against the Input LEDs. If the
level switches state (Wet or Dry) corresponds to the Input LEDs, proceed to the relay. If the level switches
state (Wet or Dry) does not correspond to the input LEDs, then check the functionality of the level switches.
RELAY LOGIC – INDIEPENDENT RELAY
Relay will act directly based upon the status of the level switch. When the level switch is Wet, the input LED
will be ON (Amber). When the level switch is Dry, the input LED will be Off.
Single Switch Wet Single Switch Dry
In this state, the relay can be energized
with Invert in the OFF setting or can be
de-energized with Invert in the ON
In this state, the relay can be energized
with Invert in the ON setting or can be deenergized with Invert in the OFF setting.
setting.
Note: Always check the status of the level switch and compare that status against the Input LED. If the level
switch state (Wet or Dry) corresponds to the Input LED, proceed to the relay. If the level switch state (Wet or
Dry) does not correspond to the input LED, then check the functionality of the level switch.
MN301510 Rev A1 17 |
Appendix Step Eight
LATCH - ON VS OFF:
The relay can either be an independent relay (high level, low level or pump protection) with Latch OFF or can
be a latching relay (automatic fill or empty) with Latch ON.
With Latch OFF, the relay will only
respond to INPUT A. INPUT B will
be ignored while Latch is OFF.
With Latch ON, the relay will
actuate when INPUT A and INPUT
B are in the same condition. The
relay will not change its condition
until both inputs reverse their
state.
Invert OFF Latch OFF
Input A* Input B* Relay
ON No Effect ON
OFF No Effect OFF
Invert OFF Latch ON
Input A* Input B* Relay
ON ON ON
OFF ON
ON OFF
No
Change
No
Change
OFF OFF ON
Invert ON Latch OFF
Input A* Input B* Relay
ON No Effect OFF
OFF No Effect ON
Invert ON Latch ON
Input A* Input B* Relay
ON ON OFF
OFF ON
ON OFF
OFF OFF ON
No
Change
No
Change
Note: Some sensors (particularly buoyancy sensors) may have their own inverting capability (wired NO or
NC). This will change the logic of the invert switch. Check your system design.
CONTROLLER LOGIC:
Please use the following guide to understand the operation of the controllers.
1. Power LED: Make sure the Green power LED is ON when power is supplied to the controller.
2. Input LED(s): The input LED(s) on the controller will be Amber when the switch(es) is/are wet and OFF
when the switch(es) is/are dry. If the LED's are not switching the input LED, test the level switch.
3. LC10 series only: When the input LED turn OFF and ON, the relay LED will also switch. With invert OFF,
the relay LED will be ON when the input LED is ON and OFF when the input LED is OFF. With invert ON,
the relay LED will be OFF when the input LED is ON and ON when the input LED is OFF.
4. LC11 series only: When both inputs are wet (Amber LED's ON), the relay will be energized (Red LED
ON). After that, if one switch becomes dry, the relay will remain energized. Only when both switches are
dry (both amber LED's OFF) will the controller de-energize the relay. The relay will not energize again until
both switches are wet. See the Relay Latch Logic Chart below for further explanation.
TIME DELAY:
The time delay can be adjusted from 0.15 seconds to 60 seconds. The delay
applies to both the Make and Break side of the relay. The delay can be used
to prevent relay chatter, especially when you have a liquid level that is
turbulent. Typically, a slight rotation clockwise, from a position of all the way
counter-clockwise, is enough to prevent relay chatter.
Note: The delay has stops on each end of its 270° rotation.
| 18 MN301510 Rev A1
Appendix Step Eight
TROUBLESHOOTING
PROBLEM SOLUTION
Relay switches only from input 1A
(ignores input 1B)
Level reaches alarm ON, but relay
is OFF.
Pump or Valve is supposed to
stop, but it does not.
Controller is powered, but nothing
happens.
TESTING RELAYS:
Relay De-energized:
Latch is turned OFF. Flip the latch switch to turn ON.
First, check to make sure the input LED is ON. If not, check wiring to
sensor.
Second, check status of Relay LED. If incorrect, flip the Invert switch to
change the relay state.
First, check to make sure the input LEDs are both in the sate state
(both ON or both OFF). If not, check wiring to sensor each sensor.
Second, check status of Relay LED. If incorrect, flip the Invert switch to
change the relay state.
First check the Power LED to make sure it is Green. If not, check the
wiring, power and make sure the terminal block(s) is(are) seated
correctly over the pins.
The relay contacts are true dry
contacts with no voltage sourced
within the relay contacts. To test,
connect a Multimeter set to read
Ohms.
Relay Energized:
Relay De-energized
Small amount of resistance
across Common (C) and
Normally Closed (NC).
O.L. across Common (C) and
Normally Open (NO)
Relay Energized
O.L. across Common (C) and
Normally Closed (NC).
Small amount of resistance
across Common (C) and
Normally Open (NO).
MN301510 Rev A1 19 |
Warranty, Returns and Limitations Step Ten
WARRANTY
Flowline warrants to the original purchaser of its products that such products will be free from defects in
material and workmanship under normal use and service in accordance with instructions furnished by Flowline
for a period of two years from the date of manufacture of such products. Flowline's obligation under this
warranty is solely and exclusively limited to the repair or replacement, at Flowline's option, of the products or
components, which Flowline's examination determines to its satisfaction to be defective in material or
workmanship within the warranty period. Flowline must be notified pursuant to the instructions below of any
claim under this warranty within thirty (30) days of any claimed lack of conformity of the product. Any product
repaired under this warranty will be warranted only for the remainder of the original warranty period. Any
product provided as a replacement under this warranty will be warranted for the full two years from the date of
manufacture.
RETURNS
Products cannot be returned to Flowline without Flowline's prior authorization. To return a product that is
thought to be defective, go to www.flowline.com, and submit a customer return (MRA) request form and follow
the instructions therein. All warranty and non-warranty product returns to Flowline must be shipped prepaid
and insured. Flowline will not be responsible for any products lost or damaged in shipment.
LIMITATIONS
This warranty does not apply to products which: 1) are beyond the warranty period or are products for which
the original purchaser does not follow the warranty procedures outlined above; 2) have been subjected to
electrical, mechanical or chemical damage due to improper, accidental or negligent use; 3) have been modified
or altered; 4) anyone other than service personnel authorized by Flowline have attempted to repair; 5) have
been involved in accidents or natural disasters; or 6) are damaged during return shipment to Flowline. Flowline
reserves the right to unilaterally waive this warranty and dispose of any product returned to Flowline where: 1)
there is evidence of a potentially hazardous material present with the product; or 2) the product has remained
unclaimed at Flowline for more than 30 days after Flowline has dutifully requested disposition. This warranty
contains the sole express warranty made by Flowline in connection with its products. ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED. The remedies of repair or
replacement as stated above are the exclusive remedies for the breach of this warranty. IN NO EVENT SHALL
FLOWLINE BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY KIND
INCLUDING PERSONAL OR REAL PROPERTY OR FOR INJURY TO ANY PERSON. THIS WARRANTY
CONSTITUTES THE FINAL, COMPLETE AND EXCLUSIVE STATEMENT OF WARRANTY TERMS AND NO
PERSON IS AUTHORIZED TO MAKE ANY OTHER WARRANTIES OR REPRESENTATIONS ON BEHALF
OF FLOWLINE. This warranty will be interpreted pursuant to the laws of the State of California. If any portion
of this warranty is held to be invalid or unenforceable for any reason, such finding will not invalidate any other
provision of this warranty.
For complete product documentation, video training, and technical support, go to www.flowline.com.
For phone support, call 562-598-3015 from 8am to 5pm PST, Mon - Fri.
(Please make sure you have the Part and Serial number available.)
| 20 MN301510 Rev A1
Loading...
