As with most electronic products, this equipment must be
disposed of in an environmentally friendly way, and in accordance with existing regulations for electronic waste.
Please contact your FLIR Systems representative for
more details.
The documentation must not, in whole or part, be copied,
photocopied, reproduced, translated or transmitted to any
electronic medium or machine readable form without prior
consent, in writing, from FLIR Systems.
Names and marks appearing on the products herein are
either registered trademarks or trademarks of FLIR Systems and/or its subsidiaries. All other trademarks,trade
names or company names referenced herein are used for
identification only and are the property of their respective
owners.
1.2 Quality assurance
The Quality Management System under which these
products are developed and manufactured has been certified in accordance with the ISO 9001 standard.
FLIR Systems is committed to a policy of continuous development; therefore we reserve the right to make
changes and improvements on any of the products without prior notice.
Do not look directly into the laser beam. The laser beam can cause eye
irritation.
WARNING
Do not use the laser pointer near explosive gases or in other possible explosive areas. Injury to persons can occur.
This symbol, adjacent to another symbol or terminal, indicates that
the user must refer to the manual for further information.
This symbol, adjacent to a terminal, indicates that, under normal
use, hazardous voltages may be present.
Double insulation.
2.1 FCC Compliance
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
Note
Before operating the device, you must read, understand, and follow all instructions, dangers, warnings, cautions, and notes.
Note
FLIR Systems reserves the right to discontinue models, parts or accessories,
and other items, or to change specifications at any time without prior notice.
To comply with FCC/IC RF exposure compliance requirements, a separation
distance of at least 20 cm must be maintained between the antenna of this device and all persons. This device must not be co-located or operating in conjunction with any other antenna or transmitter.
WARNING
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
2.2 Industry Canada compliance
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this devicemust accept any interference, including
interference that may cause undesired operation of thedevice.
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To comply with RSS 102 RF exposure compliance requirements, for mobile
configurations, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. This device must not be colocated or operating in conjunction with any other antenna or transmitter.
Congratulations on your purchase of the FLIR MR77 with METERLiNK® Bluetooth capabilities for use with FLIR infrared (IR) cameras.
This pinless moisture meter incorporates a patented built-in IR thermometer and
20-point memory. You can monitor moisture in wood and other building materials
with no surface damage with the pinless moisture sensor (pin-type moisture
probe included), and measure humidity and air temperature with the built-in
probe, plus non-contact IR temperature using its patented IR design. Advanced
functions provide moisture content, dew point, and vapor pressure calculations.
This meter is shipped fully tested and calibrated and, with proper use, will provide
years of reliable service.
3.1 Key features
• Quickly indicates the moisture content of materials with pinless technology
without damaging the surface.
• Optional remote pin-type probe (MR77-P) allows for moisture readings at different penetration levels (0.9 m (3′) cable length).
• Easy to read, large dual display with backlight feature.
• Simultaneously displays the percentage moisture content of wood or material
being tested and the air temperature, IR temperature, or humidity.
• Uses a patented IR design to measure non-contact surface temperature, with
an 8:1 distance-to-spot ratio and 0.95 fixed emissivity.
• Built-in humidity/temperature probe measures relative humidity and air temperature plus the mixing ratio and the dew point.
• Measures ambient and surface vapor pressure.
• Automatically calculates the differential temperature.
• Press the button to enter Hygrometer mode, see section 5.3
Hygrometric measurements, page 14.
• Press the button repeatedly to cycle through the display of relative humidity, dew point temperature, and mix ratio.
• Press and hold the button for 2 seconds to enter Humidity
alarm set mode, see section 5.9 Alarm settings, page 19.
• Press the button to enter Condensation mode, see section
5.5 Condensation measurements, page 16.
• Press the button repeatedly to toggle between Condensation
mode and Vapor pressure mode, see section 5.6 Vapor pres-sure measurements, page 17.
• When in Moisture mode, press and hold the button for 2 seconds to toggle between the relative and absolute readings,
see section 5.2 Moisture measurements, page 12.
• Press the button to enter Moisture mode, see section 5.2
Moisture measurements, page 12.
• Press the button repeatedly to toggle between the internal
sensor and external pin probe measurements.
• Press and hold the button for 2 seconds to enter Moisture
alarm set mode, see section 5.9 Alarm settings, page 19.
Press the button to enable/disable the display backlight.
• Press the button to toggle between Normal and Hold mode. In
Hold mode, the display freezes the last reading and continues
to display this value.
• Press and hold the button for 5 seconds to toggle between
Normal and Locked mode, see section 5.10 Locked mode,
page 20.
Press and hold the button to enable IR temperature measurements, see section 5.4 IR temperature measurements, page 15.
shows that the battery voltage is low or if the me-
ter does not power on, replace the battery. See section 6.2 Battery replace-ment, page 22.
4. Press the
button to switch off the meter.
5.1.1 Auto power off
The meter enters sleep mode after 30 minutes of inactivity. The meter beeps
three times 20 seconds before powering off. Press any function button to prevent
the meter from powering off. The auto power off time-out is then reset.
5.1.1.1 Disable auto power off
1. To disable the auto power off function, start with the meter switched off.
2. Simultaneously press and hold the
andbuttons until thein-
dicator disappears, indicating that the function is disabled.
5.2 Moisture measurements
With the meter in Moisture mode, moisture measurements can be performed using either the internal moisture sensor or by connecting the external pin probe.
The internal moisture sensor can detect moisture to a depth of 19 mm (0.75″).
The internal moisture reading can be relative or absolute.
The three-digit main display shows the moisture reading, and the four-digit secondary display shows the ambient air temperature. The bar graph matches the
reading on the main display.
While in Moisture mode, IR measurements may also be performed, see section
5.4 IR temperature measurements, page 15.
5.1 Powering the meter
1. Remove the protective cap from the humidity sensor/thermometer assembly.
andindicators are displayed. Theindicator is also displayed, indicating that the meter is displaying relative measurements. The
ambient temperature is displayed on the secondary display.
2. Place the internal moisture sensor (located on the rear side of the meter) on
the surface of the material to be tested.
The relative moisture reading is displayed on the main display. No units of
measurement are displayed.
3. Absolute or Zero Mode measurements. This mode allows measurements to
be displayed as a difference between the actual reading and a stored reference reading. Follow the steps below.
1. For best results, keep hands and other surfaces and objects away from
the internal moisture sensor area when turning on the unit.
2. Place the internal moisture sensor on the surface that will be the "refer-
ence" surface. Press and hold the
button for 2 seconds until the
indicator flashes. This will zero the meter at the reference value.
3. Place the internal moisture sensor on the surface of the material to be
tested. The measurement will be read as the offset value of your stored
reference.
4. Press and hold the
button for 2 seconds to return to normal inter-
nal moisture measurement mode.
5.2.2 External pin probe
1. Connect the external pin probe to the EXT connection jack (located at the
bottom of the meter).
2. Press the
button to enter the Moisture mode. Theindicator is
displayed.
3. Press the
button once more to activate external pin probe measure-
indicator shows the currently selected material group number. Refer
to section 7 Material groups, page 23.
To change the material group number, do the following:
1. Press and hold the
andbuttons for 2 seconds to enter the Ma-
terial group selection mode.
The
indicator flashes.
2. Use the
andbuttons to step through the nine material group
numbers.
3. Press the
button to set the group and exit the Material group se-
lection mode.
5. Press the probe pins into the material.
The moisture reading is displayed on the main display, in percent (%).
5.3 Hygrometric measurements
In Hygrometer mode, the meter measures and displays the relative humidity, dew
point temperature, mixing ratio, and ambient air temperature.
The three-digit main display shows the relative humidity, dew point temperature,
or mixing ratio, and the four-digit secondary display shows the ambient air temperature. The bar graph matches the reading on the main display.
While in Hygrometer mode, IR measurements may also be performed, see section 5.4 IR temperature measurements, page 15.
1. Press the
button to enter Hygrometer mode. Theindicator is
displayed.
2. The relative humidity is displayed on the main display. The ambient air temperature is displayed on the secondary display.
button repeatedly to cycle through the display of relative hu-
midity, dew point temperature, and mixing ratio.
• Relative humidity: The
indicator is displayed and the reading is
displayed in percent (%).
• Dew point temperature: The
indicator is displayed and the reading
is displayed in ℃ or ℉, depending on the unit setting.
• Mixing ratio: The reading is displayed in grains per pound (GPP) or grams
per kilogram (g/kg), depending on the unit setting.
5.4 IR temperature measurements
IR temperature measurements can be performed in all operating modes.
The meter is equipped with a laser pointer diode, which is used as a targeting
pointer for the IR temperature measurements. The target of the measurement
should be larger than the size of the laser beam spot. As the distance from an object increases, the spot size of the area measured by the meter becomes larger.
The meter’s field of view ratio is 8:1, meaning that if the meter is 8 inches (20 cm)
from the target, the diameter (spot) of the object under test must be at least 1
inch ( 2.54 cm). Refer to Figure 5.1.
Figure 5.1 IR spot-to-distance ratio
IR measurement notes:
• The object under test should be larger than the than the size of the laser
beam spot.
• If the surface of the object under test is covered with frost, oil, grime, etc.,
clean the surface before measuring.
• If the surface of the object is highly reflective, apply masking tape or flat black
paint to the surface before measuring.
• The meter may not make accurate measurements through transparent surfa-
Do not look directly into the laser beam. The laser beam can cause eye
irritation.
WARNING
Do not use the laser pointer near explosive gases or in other possible explosive areas. Injury to persons can occur.
1. Press and hold the
button to enable the IR sensor and the laser pointer
diode. The
indicator is displayed.
2. Aim the laser pointer at the surface to be measured. The IR temperature
reading is displayed on the four-digit secondary display.
3. Release the
button to disable the IR sensor and the laser pointer diode.
The last IR temperature reading remains on the display for 8 seconds; then
the meter returns to a display of the ambient air temperature, and the
in-
dicator disappears.
5.5 Condensation measurements
In Condensation mode, the meter determines whether a surface is at risk of condensation, based on measurements of the dew point temperature (relative humidity and ambient air temperature) and the IR temperature of the surface.
1. Press the
button to enter the Condensation mode. Theindica-
tor is displayed.
2. Aim the meter at the surface. Press and hold the
button. Theindi-
cator is displayed
• Steam, dust, smoke, etc., may obscure measurements.
• To find a hot spot, aim the meter outside the area of interest, then scan across
(in an up and down motion) until the hot spot is located.
button to disable the IR sensor and the laser pointer diode.
The last IR temperature reading remains on the display for 8 seconds; then
the meter returns to a display of the ambient air temperature and the
in-
dicator disappears.
5.6 Vapor pressure measurements
Vapor pressure measurement is a special variant of condensation measurement.
The meter calculates the vapor pressure based on measurements of the relative
humidity and the IR temperature of the surface.
1. Press the
button to enter Condensation mode. Theindicator is
displayed. The unit of measurement on the main display is ℃ or ℉, depending on the unit setting.
2. Press the
button once more to enter Vapor pressure mode. The unit
of measure on the main display changes to kPa or mBar, depending on unit
setting.
3. Aim the meter at the surface. Press and hold the
button.
4. The vapor pressure is displayed on the main display. The IR temperature of
the surface is displayed on the secondary display.
5. Release the
button to disable the IR sensor and the laser pointer diode.
The last IR temperature reading remains on the display for 8 seconds; then
the meter returns to a display of the ambient air temperature and the
in-
dicator disappears.
3. The dew point temperature is displayed on the main display. The IR temperature of the surface is displayed on the secondary display. The bar graph indicates the level of risk for condensation:
• If the IR temperature is more than 14℃ (25℉) above the dew point tem-
perature, the bar graph is empty.
• If the IR temperature is 3–14℃ (5–25℉) above the dew point tempera-
ture, the bar graph indicates a percentage of full scale.
• If the IR temperature is less than 3℃ (5℉) above the dew point tempera-
The unit setting applies to all modes. It is not possible to, for example, display
moisture in g/kg while showing temperature in ℉.
US unit setting:
• Temperature is displayed in degrees Fahrenheit (℉).
• Mixing ratio is displayed in grains per pound (GPP).
• Vapor pressure is displayed in millibars (mBar).
Metric unit setting:
• Temperature is displayed in degrees Celsius (℃).
• Mixing ratio is displayed in grams per kilogram (g/kg).
• Vapor pressure is displayed in kilopascals (kPa).
5.8 Storing and recalling measurements
5.8.1 Datalogger memory locations
The meter has 20 datalogger memory locations for the storage of measurement
data. Each memory location stores the current readings for all operating modes,
with the current unit settings. Thus, each location contains moisture, humidity,
ambient temperature, and IR temperature data.
5.8.2 Storing a measurement
1. Press the
button to capture and store the currently displayed readings.
The data is saved to the memory location shown by the
indicator.
The memory location indicator then advances to the next location. When the
20 memory locations are full, the meter overwrites saved readings, starting
with memory location 1.
5.7 Selecting measurement units
There are two sets of units; US and metric. The unit setting can be changed at
indicator flashes, and the data stored in that location is
displayed.
2. Press the
orbutton to step through the memory locations.
3. Press the
,, orbutton to display the stored data for the
different modes.
4. Press and hold the
button for 2 seconds until a single beep sounds to
exit View data mode.
5.8.4 Clearing the data from memory
Note
To avoid deleting valuable data when done viewing your data, advance the
memory to an empty location before exiting this mode.
1. Press and hold the
button for 2 seconds to enter View data mode.
2. In View data mode, press and hold the
andbuttons simultaneously
for 3 seconds to clear all data.
5.9 Alarm settings
High and low alarm thresholds can be set for moisture and humidity measurements. If either of the thresholds is exceeded during the measurement, the meter
beeps and the corresponding alarm indicator is displayed: the low alarm indicator
or the high alarm indicator.
The default setting for the moisture and humidity alarms is off.
Some IR cameras from Flir Systems support Bluetooth communication and to
those cameras you can stream measurement data from the meter. The data is
then merged into the result table in the IR image.
Streaming measurement data is a convenient way to add important information
to an IR image. For example, when identifying a water leakage in a wall, you may
want to know the humidity in the wall.
The Bluetooth range is 10m (32ft) maximum.
5.11.2 Procedure
1. Pair the IR camera with the instrument. Refer to the camera manual for information on how to pair Bluetooth devices.
2. Turn on the camera.
3. Turn on the meter.
4. Press and hold the
button on the meter to enable Bluetooth.
5. Take a measurement reading. Results from the meter will now automatically
be displayed in the result table in the top left corner of the IR camera screen.
As with most electronic products, this equipment must be disposed of in an environmentally friendly way, and in accordance with existing regulations for electronic waste.
Please contact your FLIR Systems representative for more details.
6.1 Cleaning and storage
Clean the meter with a damp cloth and mild detergent; do not use abrasives or
solvents.
If the meter is not to be used for an extended period, remove the battery and
store it separately.
6.2 Battery replacement
1. Switch off the meter before attempting to replace the battery.
2. Turn the half turn screw so that the UNLOCK symbol is facing up and then lift
open the battery compartment.
The tables below list woods types along with the material group number that
should be selected for each type.
Table 7.1 Common names of timbers (BS888 & 589:1973) with selectable
FLIR MR77 material group numbers. Note: Material Group No. 9 should be used
for building materials (chip board, dry wall, and plywood)
Calculated from %RH
and Air temperature
measurements.
10Warranties
10.1 FLIR Global Limited Lifetime
Warranty
A qualifying FLIR Test and Measurement product (the
“Product”) purchased either directly from FLIR Commercial Systems Inc and affiliates (FLIR) or from an authorized FLIR distributor or reseller that Purchaser registers
on-line with FLIR is eligible for coverage under FLIR’s Limited Lifetime Warranty,subject to the terms and conditions
in this document. This warranty only applies to purchases
of Qualifying Products (see below) purchased and manufactured after April 1, 2013.
PLEASE READ THIS DOCUMENT CAREFULLY; IT CONTAINS IMPORTANTINFORMATION ABOUT THE PRODUCTS THAT QUALIFY FOR COVERAGE UNDER THE
LIMITED LIFETIME WARRANTY, PURCHASER’S OBLIGATIONS, HOW TO ACTIVATE THE WARRANTY, WARRANTY COVERAGE, AND OTHER IMPORTANT TERMS,
CONDITIONS, EXCLUSIONS AND DISCLAIMERS.
1. PRODUCT REGISTRATION. Toqualify for FLIR’s Limited Lifetime Warranty,Purchaser must fully register the
within Sixty (60) DAYS of the date the Product was purchased by the first retail customer (the “Purchase Date”).
Qualifying PRODUCTS THAT ARE NOT REGISTERED
ON-LINE WITHIN SIXTY (60) DAYS OF THE PURCHASE
DATE WILL HAVE A LIMITED ONE YEARWARRANTY
FROM DATE OF PURCHASE.
2. QUALIFYING PRODUCTS. Upon registration, Test and
Measurement products that qualify for coverage under
FLIR’s Limited Lifetime Warranty are: MR7x, CM7x,
CM8x, DMxx, VP5x not including accessories which may
have their own warranty.
3. WARRANTY PERIODS. For purposes of the TheLimited Lifetime Warranty,Lifetime is defined as seven years
(7) after the product is no longer manufactured, or ten
years (10) from date of purchase, whichever is greater.
This Warranty is only applicable to the original owner of
the Products.
Any Product that is repaired or replaced under warranty is
covered under this Limited Lifetime Warranty for one hundred eighty days (180) days from the date of return shipment by FLIR or for the remaining duration of the
applicable Warranty Period, whichever is longer.
4. LIMITED WARRANTY. In accordance with the terms
and conditions of this Limited Lifetime Warranty, and except as excluded or disclaimed in this document, FLIR
warrants, from the PurchaseDate, that all fullyregistered
Products will conform to FLIR’s published Product specifications and be free from defects in materials and workmanship during the applicable Warranty Period.
PURCHASER’S SOLE AND EXCLUSIVE REMEDY
UNDER THIS WARRANTY, AT FLIR’S SOLE DISCRETION, IS THE REPAIR OR REPLACEMENT OF
DEFECTIVE PRODUCTS IN A MANNER, AND BY A
SERVICE CENTER, AUTHORIZED BY FLIR. IF THIS
REMEDY IS ADJUDICATED TO BE INSUFFICIENT, FLIR
SHALL REFUND PURCHASER’S PAID PURCHASE
PRICE AND HAVE NO OTHER OBLIGATION OR LIABILITY TO BUYER WHATSOEVER.
5. WARRANTY EXCLUSIONS AND DISCLAIMERS.
FLIR MAKES NO OTHER WARRANTY OF ANY KIND
WITH RESPECT TO THE PRODUCTS. ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR APARTICULAR PURPOSE (EVEN IF PURCHASER HAS NOTIFIED FLIR OF
ITS INTENDED USE FOR THE PRODUCTS), AND NONINFRINGEMENT ARE EXPRESSLY EXCLUDED FROM
THIS AGREEMENT.
THIS WARRANTY EXPRESSLY EXCLUDES ROUTINE
PRODUCT MAINTENANCE, SOFTWARE UPDATES,
AND REPLACEMENT OF MANUALS, FUSES, OR DISPOSABLE BATTERIES. FLIR FURTHER EXPRESSLY
DISCLAIMS ANY WARRANTY COVERAGE WHERE
THE ALLEGED NONCONFORMITY IS DUE TO NORMAL WEAR AND TEAR, OTHER ALTERATION, MODIFICATION, REPAIR, ATTEMPTEDREPAIR, IMPROPER
USE, IMPROPER MAINTENANCE, NEGLECT, ABUSE,
IMPROPER STORAGE, FAILURE TO FOLLOW ANY
PRODUCT INSTRUCTIONS, DAMAGE (WHETHER
CAUSED BY ACCIDENT OR OTHERWISE), OR ANY
OTHER IMPROPER CARE OR HANDING OF THE
PRODUCTS CAUSED BY ANYONE OTHER THAN FLIR
OR FLIR’S EXPRESSLYAUTHORIZED DESIGNEE.
THIS DOCUMENT CONTAINSTHE ENTIREWARRANTY AGREEMENT BETWEEN PURCHASER AND
FLIR AND SUPERSEDES ALL PRIOR WARRANTY NEGOTIATIONS,AGREEMENTS, PROMISES AND
UNDERSTANDINGS BETWEEN PURCHASER AND
FLIR. THIS WARRANTY MAY NOT BE ALTERED WITHOUT THE EXPRESS WRITTEN CONSENT OF FLIR.
6. WARRANTY RETURN, REPAIR AND REPLACEMENT. To be eligiblefor warranty repair orreplacement,
Purchaser must notify FLIR within thirty (30)days of discovering of any apparent defect in materials or workmanship. Before Purchaser may return aProduct for warranty
service or repair, Purchaser must first obtain a returned
material authorization (RMA) number from FLIR. To obtain
the RMA number Owner must provide an original proof of
purchase. For additional information, to notify FLIR of an
apparent defect in materials or workmanship, or torequest
solely responsible for complying with all RMAinstructions
provided by FLIR including but not limited to adequately
packaging the Product for shipment to FLIR and for all
packaging and shipping costs. FLIR will pay for returning
to Purchaser any Product that FLIR repairsor replaces
under warranty.
FLIR reserves the right to determine, in its sole discretion,
whether a returned Product is covered under Warranty. If
FLIR determines that any returned Product is not covered
under Warranty or is otherwise excluded from Warranty
coverage, FLIR may charge Purchaser a reasonable handling fee and return the Product to Purchaser, at Purchaser’s expense, or offer Purchaser the option of handling the
Product as a non-warranty return.
7. NON-WARRANTY RETURN. Purchaser may request
that FLIR evaluate and serv ice or repair a Product not covered under warranty, which FLIR may agree to do in its
sole discretion. Before Purchaser returns a Product for
non-warranty evaluation and repair, Purchaser must con-
uation and obtain an RMA. Purchaser issolely
responsible for complying with all RMA instructions provided by FLIR including but not limited to adequately
packaging the Product for shipment to FLIR and forall
packaging and shipping costs. Upon receipt of an authorized non-warranty return, FLIR will evaluate the Product
and contact Purchaser regarding the feasibility of and the
costs and fees associated with Purchaser’s request. Purchaser shall be responsible for the reasonable cost of
FLIR’s evaluation, for the cost of any repairs or services
authorized by Purchaser, and for the cost of repackaging
and returning the Product to Purchaser.
Any non-warranty repair ofa Product is warranted for one
hundred eighty days (180) days from the date of return
shipment by FLIR to be free from defects in materials and
workmanship only, subject to all of the limitations, exclusions and disclaimers in this document.
10.2 FLIR Test and Measurement
Limited 2 Year Warranty
A qualifying FLIR Test and Measurement product (the
“Product”) purchased either directly from FLIR Commercial Systems Inc and affiliates (FLIR) or from an authorized FLIR distributor or reseller that Purchaser registers
on-line with FLIR is eligible for coverage under FLIR’s Limited Warranty, subject to the terms andconditions in this
document. This warranty only applies to purchases of
Qualifying Products (see below) purchased and manufactured after April 1, 2013.
PLEASE READ THIS DOCUMENT CAREFULLY; IT CONTAINS IMPORTANTINFORMATION ABOUT THE PRODUCTS THAT QUALIFY FOR COVERAGE UNDER THE
LIMITED WARRANTY,PURCHASER’S OBLIGATIONS,
HOW TO ACTIVATETHE WARRANTY, WARRANTY
COVERAGE, AND OTHER IMPORTANT TERMS, CONDITIONS, EXCLUSIONS AND DISCLAIMERS.
1. PRODUCT REGISTRATION. Toqualify for FLIR’s Limited Warranty, Purchaser must fully register the Product di-
(60) DAYS of the date the Product was purchased by the
first retail customer (the “Purchase Date”). Qualifying
PRODUCTS THATARE NOT REGISTERED ON-LINE
WITHIN SIXTY (60) DAYS OF THE PURCHASE DATE
WILL HAVE A LIMITED ONE YEAR WARRANTY FROM
DATEOF PURCHASE.
2. QUALIFYING PRODUCTS. Upon registration, Test and
Measurement products that qualify for coverage under
FLIR’s Limited Warranty are: VS70 Videoscope, VSAxx
Articulation Camera, VSCxx Camera, VSSxx Probe Spool,
VST handset, MR02 Pin Extension Probe, and TAxx not
including accessories which may have their own warranty.
3. WARRANTY PERIODS. The applicable LimitedWarranty Period measured fromthe Purchase data are:
ProductsLimited Warranty
VS70, VSAxx, VSCxx,
VSSxx, VST,MR02,
TAxx
Any Product that is repaired or replaced under warranty is
covered under this Limited Warranty for one hundred
eighty days (180) days from the date of return shipment
by FLIR or for the remaining duration of the applicable
Warranty Period, whichever is longer.
4. LIMITED WARRANTY. In accordance with the terms
and conditions of this Limited Warranty, and except as excluded or disclaimed in this document, FLIR warrants,
from the Purchase Date, that all fullyregistered Products
will conform to FLIR’s published product specifications
and be free from defects in materials and workmanship
during the applicable Warranty Period. PURCHASER’S
SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY, AT FLIR’S SOLE DISCRETION, IS THE REPAIR
OR REPLACEMENT OF DEFECTIVE PRODUCTS IN A
MANNER, AND BY A SERVICE CENTER, AUTHORIZED
BY FLIR. IF THIS REMEDY IS ADJUDICATED TO BE INSUFFICIENT, FLIR SHALL REFUND PURCHASER’S
PAID PURCHASE PRICE AND HAVE NO OTHER OBLIGATION OR LIABILITY TO BUYER WHATSOEVER.
5. WARRANTY EXCLUSIONS AND DISCLAIMERS.
FLIR MAKES NO OTHER WARRANTY OF ANY KIND
WITH RESPECT TO THE PRODUCTS. ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR APARTICULAR PURPOSE (EVEN IF PURCHASER HAS NOTIFIED FLIR OF
ITS INTENDED USE FOR THE PRODUCTS), AND NONINFRINGEMENT ARE EXPRESSLY EXCLUDED FROM
THIS AGREEMENT.
THIS WARRANTY EXPRESSLY EXCLUDES ROUTINE
PRODUCT MAINTENANCE, SOFTWARE UPDATES,
AND REPLACEMENT OF FUSES, OR DISPOSABLE
BATTERIES.FLIR FURTHER EXPRESSLY DISCLAIMS
ANY WARRANTY COVERAGE WHERE THE ALLEGED
NONCONFORMITY IS DUE TO NORMAL WEAR AND
TEAR, OTHER ALTERATION, MODIFICATION, REPAIR,
ATTEMPTED REPAIR, IMPROPER USE, IMPROPER
MAINTENANCE, NEGLECT, ABUSE, IMPROPER STORAGE, FAILURE TO FOLLOW ANY PRODUCT INSTRUCTIONS, DAMAGE (WHETHER CAUSED BY ACCIDENT
OR OTHERWISE), OR ANY OTHER IMPROPER CARE
OR HANDING OF THE PRODUCTS CAUSED BYANYONE OTHER THAN FLIR OR FLIR’SEXPRESSLY AUTHORIZED DESIGNEE.
THIS DOCUMENT CONTAINS THE ENTIRE WARRANTY AGREEMENT BETWEEN PURCHASER AND
FLIR AND SUPERSEDES ALL PRIOR WARRANTY NEGOTIATIONS,AGREEMENTS, PROMISES AND
UNDERSTANDINGSBETWEEN PURCHASERAND
FLIR. THIS WARRANTY MAY NOT BE ALTERED WITHOUT THE EXPRESS WRITTEN CONSENT OF FLIR.
6. WARRANTY RETURN, REPAIR AND REPLACEMENT.To be eligible for warranty repair or replacement,
Purchaser must notify FLIR within thirty (30) days of discovering of any apparent defect in materials or workmanship. Before Purchaser may return a Product for warranty
service or repair, Purchaser must first obtain a returned
material authorization (RMA) number from FLIR. To obtain
the RMA number Owner must provide an original proof of
purchase. For additional information,to notify FLIR of an
apparent defect in materials or workmanship, or to request
solely responsible for complying with all RMA instructions
provided by FLIR including but not limited to adequately
packaging the Product for shipment to FLIR and forall
packaging and shipping costs. FLIR will pay for returning
to Purchaser any Product that FLIR repairs or replaces
under warranty.
FLIR reserves the right to determine, in its sole discretion,
whether a returned Product is covered under Warranty.If
FLIR determines that any returned Product is not covered
under Warranty or is otherwise excluded from Warranty
coverage, FLIR may charge Purchaser a reasonable handling fee and return the Product to Purchaser, at Purchaser’s expense, or offer Purchaser the option of handling the
Product as a non-warranty return.
7. NON-WARRANTY RETURN. Purchaser may request
that FLIR evaluate and service orrepair a Product not covered under warranty, which FLIR may agree to do in its
sole discretion. Before Purchaser returns a Productfor
non-warranty evaluation and repair, Purchaser must con-
uation and obtain an RMA. Purchaser is solely
responsible for complying with all RMA instructionsprovided by FLIR including but not limited to adequately
packaging the Product for shipment to FLIR and for all
packaging and shipping costs. Upon receipt of an authorized non-warranty return, FLIR will evaluate the Product
and contact Purchaser regarding the feasibility of and the
costs and fees associated with Purchaser’s request. Purchaser shall be responsible for the reasonable cost of
FLIR’s evaluation, for the cost of any repairs or services
authorized by Purchaser, and for thecost of repackaging
and returning the Product to Purchaser.
Any non-warranty repair ofa Product is warranted for one
hundred eighty days (180) days from the date of return
shipment by FLIR to be free fromdefects in materials and
workmanship only, subject to all of the limitations, exclusions and disclaimers in this document.
