FLIR Systems ETS320 User manual

Download
User’s manual FLIR ETS3xx series
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Table of contents
1 Disclaimers ......... ..... ........................... ..... ........................... ..... ..... ..... 1
1.1 Legal disclaimer .........................................................................1
1.2 Usage statistics ..........................................................................1
1.3 Changes to registry .....................................................................1
1.4 U.S. Government Regulations........................................................1
1.5 Copyright ..................................................................................1
1.6 Quality assurance .......................................................................1
1.7 Patents.....................................................................................1
1.8 EULA Terms ..............................................................................1
1.9 EULA Terms ..............................................................................2
2 Safety information ............................. ................................ .................. 3
3 Notice to user .... ..... ................................ ..... ........................... ..... .......5
3.1 User-to-user forums .................................................................... 5
3.2 Calibration................................................................................. 5
3.3 Accuracy ..................................................................................5
3.4 Disposal of electronic waste .......................................................... 5
3.5 Training .................................................................................... 5
3.6 Documentation updates ...............................................................5
3.7 Important note about this manual.................................................... 6
3.8 Note about authoritative versions....................................................6
4 Customer help ... ........................... ..... ........................... ..... .................7
4.1 General .................................................................................... 7
4.2 Submitting a question .................................................................. 7
4.3 Downloads ................................................................................ 8
5 Introduction................... ..... ........................... ..... ................................ 9
5.1 General description .....................................................................9
5.2 Benefits .................................................................................... 9
5.3 Key features .............................................................................. 9
6 Quick start guide ....................... ..... ........................... ..... ................... 10
7 Description.. ..... ................................ ................................ ................ 11
7.1.1 Figure.......................................................................... 11
7.1.2 Explanation................................................................... 11
7.2.1 Figure.......................................................................... 12
7.2.2 Explanation................................................................... 12
7.4.1 Figure.......................................................................... 13
7.4.2 Explanation................................................................... 13
8 Handling the camera unit........................... ................................ ..... .... 14
8.1.1 Charging the battery using the FLIR power supply ................. 14
8.1.2 Charging the battery using a USB cable connected to a
8.3.1 Figure.......................................................................... 15
8.3.2 Explanation................................................................... 15
computer...................................................................... 14
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
v
Table of contents
8.3.3 Procedure .................................................................... 15
8.4.1 Procedure .................................................................... 16
9 Operation ............... ..... ..... ........................... ..... ..... ..... ...................... 18
9.1.1 General........................................................................ 18
9.1.2 Image capacity .............................................................. 18
9.1.3 Naming convention......................................................... 18
9.1.4 Procedure .................................................................... 18
9.2.1 General........................................................................ 18
9.2.2 Procedure .................................................................... 18
9.3.1 General........................................................................ 18
9.3.2 Procedure .................................................................... 18
9.4.1 General........................................................................ 19
9.4.2 Procedure .................................................................... 19
9.5.1 General........................................................................ 19
9.5.2 Procedure .................................................................... 19
9.6.1 General........................................................................ 19
9.6.2 Procedure .................................................................... 19
9.7.1 General........................................................................ 20
9.7.2 Procedure .................................................................... 20
9.8.1 Procedure .................................................................... 20
9.9.1 General........................................................................ 20
9.9.2 Procedure .................................................................... 20
9.10.1 General........................................................................ 20
9.10.2 Image examples ............................................................ 20
9.10.3 Procedure .................................................................... 21
9.11.1 General........................................................................ 21
9.11.2 When to use Manual mode............................................... 22
9.11.3 Procedure .................................................................... 22
9.12.1 General........................................................................ 22
9.12.2 Procedure .................................................................... 23
9.13.1 General........................................................................ 23
9.13.2 Procedure .................................................................... 23
9.14.1 General........................................................................ 23
9.14.2 Procedure .................................................................... 23
9.15.1 General........................................................................ 24
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
vi
Table of contents
9.15.2 Procedure .................................................................... 24
9.16.1 General........................................................................ 24
9.16.2 Procedure .................................................................... 24
9.17.1 General........................................................................ 25
9.17.2 Procedure .................................................................... 25
9.18.1 General........................................................................ 25
9.18.2 Procedure .................................................................... 26
10 Technical data .................... ..... ........................... ..... .......................... 27
11 Mechanical drawings ................. ..... ........................... ..... ................... 31
12 Cleaning the camera . ................................ ................................ ..... .... 36
12.1.1 Liquids......................................................................... 36
12.1.2 Equipment.................................................................... 36
12.1.3 Procedure .................................................................... 36
12.2.1 Liquids......................................................................... 36
12.2.2 Equipment.................................................................... 36
12.2.3 Procedure .................................................................... 36
13 About FLIR Systems .. ........................... ..... ........................... ..... ........ 38
14 Terms, laws, and definitions. ..... ........................... ..... .......................... 41
15 Thermographic measurement techniques .... ........................... ..... ........ 43
15.2.1 Finding the emissivity of a sample...................................... 43
16 The secret to a good thermal image .... ..... ........................... ..... ..... ..... .. 48
16.4.1 Focus .......................................................................... 49
16.4.2 Temperature range ......................................................... 50
16.4.3 Image detail and distance from the object ............................ 51
16.5 The changeables—image optimization and temperature
measurement........................................................................... 52
16.5.1 Level and span .............................................................. 52
16.5.2 Palettes and isotherms .................................................... 52
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
vii
Table of contents
16.5.3 Object parameters.......................................................... 53
17 About calibration...... ................................ ................................ ..... .... 55
17.4 The differences between a calibration performed by a user and
18 History of infrared technology.................... ................................ ..... .... 58
19 Theory of thermography............................ ................................ ..... .... 61
20 The measurement formula.... ........................... ..... ..... ..... ..... ............... 69
21 Emissivity tables ........................... ..... ........................... ..... ............... 73
that performed directly at FLIR Systems......................................... 56
19.3.1 Planck’s law .................................................................. 63
19.3.2 Wien’s displacement law.................................................. 64
19.3.3 Stefan-Boltzmann's law ................................................... 65
19.3.4 Non-blackbody emitters ................................................... 66
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
viii
1

Disclaimers

1.1 Legal disclaimer

All products manufactured by FLIR Systems are warranted against defective materials and workmanship for a period of one (1) year from the delivery date of the original purchase, provided such products have been under normal stor­age, use and service, and in accordance with FLIR Systems instruction.
Uncooled handheld infrared cameras manufactured by FLIR Systems are war­ranted against defective materials and workmanship for a period of two (2) years from the delivery date of the original purchase, provided such products have been under normal storage, use and ser vice, and in accordancewith FLIR Systems instruction, and provided that the camera has been registered within 60 days of original purchase.
Detectors for uncooled handheld infrared cameras manufacturedby FLIR Sys­tems are warranted against defective materials and workmanship for a period of ten (10) years from the delivery date of the original purchase,provided such products have been under normal storage, use and serv ice, and in accordance with FLIR Systems instruction, and provided that the camera has been regis­tered within 60 days of original purchase.
Products which are not manufactured by FLIR Systems but included in sys­tems delivered by FLIR Systems to the original purchaser, carr y the warranty,if any, of the particular supplier only. FLIR Systems has no responsibility whatso­ever for such products.
The warranty extends only to the original purchaser and is not transferable. It is not applicable to any product whichhas been subjected to misuse, neglect, accident or abnormal conditions of operation. Expendable parts are excluded from the warranty.
In the case of a defect in a product covered by this warranty the product must not be further used in order to prevent additional damage. The purchaser shall promptly report any defect to FLIR Systems or this warranty will not apply.
FLIR Systems will, at its option, repair or replace any such defective product free of charge if, upon inspection, it proves to be defective in material or work­manship and provided that it is returnedto FLIR Systems within the said one­year period.
FLIR Systems has no other obligation or liability for defects than those set forth above.
No other warranty is expressed or implied. FLIR Systems specifically disclaims the implied warranties of merchantability and fitness for a particular purpose.
FLIR Systems shall not be liable forany direct, indirect, special, incidental or consequential loss or damage, whether based oncontract, tort or any other le­gal theory.
This warranty shall begoverned by Swedish law. Any dispute, controversy or claim arising out of or in connection with this war-
ranty, shall be finally settled by arbitration in accordance with the Rules of the Arbitration Institute of the Stockholm Chamber of Commerce. The place of ar­bitration shall be Stockholm. The language to be used in the arbitral proceed­ings shall be English.

1.2 Usage statistics

FLIR Systems reserves the right to gather anonymous usage statistics to help maintain and improve the quality of our software and services.

1.3 Changes to registry

The registry entry HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet \Control\Lsa\LmCompatibilityLevel will be automatically changed to level 2 if the FLIR Camera Monitor service detects a FLIR camera connected to the computer with a USB cable. The modification will only be executed if the cam­era device implements a remote network service that supports network logons.

1.4 U.S. Government Regulations

This product may be subject to U.S. Export Regulations. Please send any in­quiries to exportquestions@flir.com.

1.5 Copyright

© 2016, FLIR Systems, Inc. All rights reserved worldwide. No parts of the soft­ware including source code may be reproduced, transmitted, transcribed or translated into any language or computer languagein any form or by any means, electronic, magnetic, optical, manual or otherwise, without the prior written permission of FLIR Systems.
The documentation must not, in whole orpart, be copied, photocopied, repro­duced, translated or transmitted to any electronic medium or machine read­able form without prior consent, in writing, from FLIR Systems.
Names and marks appearing on the products herein are either registered trademarks or trademarks of FLIR Systems and/or its subsidiaries. All other trademarks, trade names or company names referenced herein are used for identification only and are the property of their respective owners.

1.6 Quality assurance

The Quality Management System under which these products are developed and manufactured has been certified in accordance with the ISO 9001 standard.
FLIR Systems is committed to a policy of continuous development; therefore we reserve the right to make changes and improvements on any of the prod­ucts without prior notice.

1.7 Patents

000439161; 000653423; 000726344; 000859020; 001707738; 001707746; 001707787; 001776519; 001954074; 002021543; 002021543-0002; 002058180; 002249953; 002531178; 002816785; 002816793; 011200326; 014347553; 057692; 061609; 07002405; 100414275; 101796816; 101796817; 101796818; 102334141; 1062100; 11063060001; 11517895; 1226865; 12300216; 12300224; 1285345; 1299699; 1325808; 1336775; 1391114; 1402918; 1404291; 1411581; 1415075; 1421497; 1458284; 1678485; 1732314; 17399650; 1880950; 1886650; 2007301511414; 2007303395047; 2008301285812; 2009301900619; 20100060357; 2010301761271; 2010301761303; 2010301761572; 2010305959313; 2011304423549; 2012304717443; 2012306207318; 2013302676195; 2015202354035; 2015304259171; 204465713; 204967995; 2106017; 2107799; 2115696; 2172004; 2315433; 2381417; 2794760001; 3006596; 3006597; 303330211; 4358936; 483782; 484155; 4889913; 4937897; 4995790001; 5177595; 540838; 579475; 584755; 599392; 60122153; 6020040116815; 602006006500.0; 6020080347796; 6020110003453; 615113; 615116; 664580; 664581; 665004; 665440; 67023029; 6707044; 677298; 68657; 69036179; 70022216; 70028915; 70028923; 70057990; 7034300; 710424; 7110035; 7154093; 7157705; 718801; 723605; 7237946; 7312822; 7332716; 7336823; 734803; 7544944; 7606484; 7634157; 7667198; 7809258; 7826736; 8018649; 8153971; 8212210; 8289372; 8340414; 8354639; 8384783; 8520970; 8565547; 8595689; 8599262; 8654239; 8680468; 8803093; 8823803; 8853631; 8933403; 9171361; 9191583; 9279728; 9280812; 9338352; 9423940; 9471970; 9595087; D549758.

1.8 EULA Terms

• Youhave acquired a device (“INFRARED CAMERA”) that includes soft­ware licensed by FLIR Systems AB from Microsoft Licensing, GP or its af­filiates (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documen­tation (“SOFTWARE”) are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved.
• IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO NOT USE THE DEVICE OR COPYTHE SOFTWARE. IN­STEAD, PROMPTLYCONTACT FLIR Systems AB FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE
OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EU­LA (OR RATIFICATION OF ANY PREVIOUS CONSENT).
• GRANT OF SOFTWARE LICENSE. This EULA grants you the following license:
◦ Youmay use the SOFTWARE only on the DEVICE. ◦ NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULTTOLER-
ANT.FLIR Systems AB HAS INDEPENDENTLYDETERMINED HOW TO USE THESOFTWARE IN THE DEVICE, AND MS HAS RELIED UPON FLIR Systems AB TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE FOR SUCH USE.
◦ NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is
provided “AS IS” and with all faults. THE ENTIRE RISK AS TO SAT­ISFACTORY QUALITY, PERFORMANCE, ACCURACY,AND EF­FORT (INCLUDING LACK OF NEGLIGENCE) IS WITH YOU. ALSO, THERE IS NOWARRANTY AGAINST INTERFERENCE WITH YOUR ENJOYMENT OF THE SOFTWARE OR AGAINST IN­FRINGEMENT.IF YOU HAVE RECEIVED ANY WARRANTIES RE-
GARDING THE DEVICE ORTHE SOFTWARE, THOSE WARRANTIES DO NOT ORIGINATE FROM, AND ARE NOT BINDING ON, MS.
◦ No Liability for Certain Damages. EXCEPTAS PROHIBITED BY
LAW,MS SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPE­CIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM OR IN CONNECTION WITH THE USE OR PERFORM­ANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. IN NO EVENT SHALL MS BE LIABLE FOR ANY AMOUNT IN EX­CESS OF U.S. TWO HUNDRED FIFTY DOLLARS (U.S.$250.00).
◦ Limitations on Reverse Engineering, Decompilation, and Dis-
assembly. Youmay not reverse engineer, decompile, or disassem-
ble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.
◦ SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS.
Youmay permanently transfer rightsunder this EULA only as part of a permanent sale or transfer of the Device, and only if the recipient agrees to this EULA. If the SOFTWARE is an upgrade, any transfer must also include all prior versions of the SOFTWARE.
◦ EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is
subject to U.S. export jurisdiction. You agree to complywith all appli­cable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as end-user, end-use and destination restrictions issued by U.S. and other governments. For additional information see http://www.micro­soft.com/exporting/.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
1
Disclaimers1

1.9 EULA Terms

Qt4 Core and Qt4 GUI, Copyright ©2013 Nokia Corporation and FLIR Sys­tems AB. This Qt library is a free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General Public License as published by the Free Software Foundation; either version2.1 ofthe License, or (at your op­tion) any later version. This library is distributed in the hope that it will be
useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITYor FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License, http://www.gnu.org/licenses/lgpl-2.1.html. The source code for the libraries Qt4 Core and Qt4 GUI may be requested from FLIR Systems AB.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
2
2

Safety information

WARNING
Applicability: Class B digital devices.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular in­stallation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
Applicability: Digital devices subject to 15.19/RSS-210. NOTICE: This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Op-
eration is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired operation.
WARNING
Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems
may void the FCC authorization to operate this equipment.
WARNING
Applicability: Digital devices subject to 2.1091/2.1093/OET Bulletin 65. Radiofrequency radiation exposure Information: The radiated output power of the device is below
the FCC/IC radio frequency exposure limits. Nevertheless, the device shall be used in such a manner that the potential for human contact during normal operation is minimized.
WARNING
Applicability: Cameras with one or more batteries.
Do not continue to charge the battery if it does not become charged in the specified charging time. If you continue to charge the battery, it can become hot and cause an explosion or ignition. Injury to persons can occur.
WARNING
Applicability: Cameras with one or more batteries.
Only use the correct equipment to remove the electrical power from the battery. If you do not use the cor­rect equipment, you can decrease the performance or the life cycle of the battery. If you do not use the correct equipment, an incorrect flow of current to the battery can occur. This can cause the battery to be­come hot, or cause an explosion. Injury to persons can occur.
WARNING
Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on con­tainers before you use a liquid. The liquids can be dangerous. Injury to persons can occur.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
3
2
Safety information
CAUTION
Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example, devices that cause laser radiation, or the sun. This can have an unwanted effect on the accuracy of the camera. It can also cause damage to the detector in the camera.
CAUTION
Do not use the camera in temperatures more than +50°C (+122°F), unless other information is specified in the user documentation or technical data. High temperatures can cause damage to the camera.
CAUTION
Do not attach the camera unit directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a specific adapter to connect the camera unit to a cigarette lighter socket. Damage to the camera unit can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery charger when you charge the battery. Damage to the battery can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can charge the battery is ±0°C to +45°C (+32°F to +113°F), ex­cept for the Korean market where the approved range is +10°C to + 45°C (+50°F to +113°F). If you charge the battery at temperatures out of this range, it can cause the battery to become hot or to break. It can also decrease the performance or the life cycle of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can remove the electrical power from the battery is +10°C to +40°C (+50°F to +104°F), unless other information is specified in the user documentation or technical da­ta. If you operate the battery out of this temperature range, it can decrease the performance or the life cycle of the battery.
CAUTION
Do not apply solvents or equivalent liquids to the camera, the cables, or other items. Damage to the bat­tery and injury to persons can occur.
CAUTION
Be careful when you clean the infrared lens. The lens has an anti-reflective coating which is easily dam­aged. Damage to the infrared lens can occur.
CAUTION
Do not use too much force to clean the infrared lens. This can cause damage to the anti-reflective coating.
Note The encapsulation rating is only applicable when all the openings on the camera are sealed with their correct covers, hatches, or caps. This includes the compartments for data storage, batteries, and connectors.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
4
3

Notice to user

3.1 User-to-user forums

Exchange ideas, problems, and infrared solutions with fellow thermographers around the world in our user-to-user forums. To go to the forums, visit:
http://forum.infraredtraining.com/

3.2 Calibration

We recommend that you send in the camera for calibration once a year. Contact your local sales office for instructions on where to send the camera.

3.3 Accuracy

For very accurate results, we recommend that you wait 5 minutes after you have started the camera before measuring a temperature.

3.4 Disposal of electronic waste

As with most electronic products, this equipment must be disposed of in an environmen­tally friendly way, and in accordance with existing regulations for electronic waste.
Please contact your FLIR Systems representative for more details.

3.5 Training

To read about infrared training, visit:
• http://www.infraredtraining.com
• http://www.irtraining.com
• http://www.irtraining.eu

3.6 Documentation updates

Our manuals are updated several times per year, and we also issue product-critical notifi­cations of changes on a regular basis.
To access the latest manuals, translations of manuals, and notifications, go to the Down­load tab at:
http://support.flir.com It only takes a few minutes to register online. In the download area you will also find the lat-
est releases of manuals for our other products, as well as manuals for our historical and obsolete products.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
5
Notice to user3

3.7 Important note about this manual

FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply
to your particular camera model.

3.8 Note about authoritative versions

The authoritative version of this publication is English. In the event of divergences due to translation errors, the English text has precedence.
Any late changes are first implemented in English.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
6
4

Customer help

4.1 General

For customer help, visit: http://support.flir.com

4.2 Submitting a question

To submit a question to the customer help team, you must be a registered user. It only takes a few minutes to register online. If you only want to search the knowledgebase for existing questions and answers, you do not need to be a registered user.
When you want to submit a question, make sure that you have the following information to hand:
• The camera model
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
7
4
Customer help
• The camera serial number
• The communication protocol, or method, between the camera and your device (for ex­ample, SD card reader, HDMI, Ethernet, USB, or FireWire)
• Device type (PC/Mac/iPhone/iPad/Android device, etc.)
• Version of any programs from FLIR Systems
• Full name, publication number, and revision number of the manual

4.3 Downloads

On the customer help site you can also download the following, when applicable for the product:
• Firmware updates for your infrared camera.
• Program updates for your PC/Mac software.
• Freeware and evaluation versions of PC/Mac software.
• User documentation for current, obsolete, and historical products.
• Mechanical drawings (in *.dxf and *.pdf format).
• Cad data models (in *.stp format).
• Application stories.
• Technical datasheets.
• Product catalogs.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
8
5

Introduction

5.1 General description

The FLIR ETS3xx is FLIR’s first electronic test bench camera, designed for a quick tem­perature check of PCB boards and electronic devices. The FLIR ETS3xx is sensitive enough to detect subtle temperature difference with an accuracy of ±3°C, so you can quickly find hot spots and potential points of failure. The 320 × 240 pixel infrared detector offers more than 76 000 points of temperature measurement, eliminating the guesswork of legacy measurement tools. Designed specifically for bench-top work, the battery-powered FLIR ETS3xx connects to your PC for immediate analysis and sharing of thermal data.

5.2 Benefits

• Reduces test times: Quickly identify hot spots, thermal gradients, and potential points of failure.
• Improves product design: Know where and when to add fans and heatsinks, and en­sure products are operating within specification for their maximum lifetime.
• Saves money: Improve rapid prototyping and reduce product development cycles.
• Optimizes lab time: Battery powered and hands-free, and offers complete measure­ment and analysis in the camera.

5.3 Key features

• >76 000 points of non-contact temperature measurement at the push of a button.
• 320 × 240 pixel detector provides crisp thermal imagery.
• Time versus temperature measurement with FLIR Tools+.
• Small-component measurement, down to 170 µm per pixel spot size.
• Lens offers a 45° thermal view of the target for the quick detection of hot spots.
• Records radiometric imagery in standard JPEG format for easy sharing.
• ±3% accuracy promotes quality assurance and factory acceptance of PCBs.
• Quickly mounts on the supplied stand for immediate use.
• Crisp 3 in. LCD display provides immediate thermal feedback.
• World-class software provided for advanced measurement corrections/capabilities.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
9
6

Quick start guide

6.1 Procedure

Follow this procedure:
1. Charge the battery. You can do this in different ways:
• Charge the battery using the FLIR power supply.
• Charge the battery using a USB cable connected to a computer. Note Charging the camera using a USB cable connected to a computer takes
considerably longer than using the FLIR power supply or the FLIR stand-alone bat­tery charger.
2. Connect a ground cord to the ground stud on the ESD mat of the camera stand.
3. Push the On/off button to turn on the camera.
4. Adjust the position of the camera unit.
5. Push the Save button to save an image. (Optional steps)
6. Go to the following website to download FLIR Tools/Tools+
http://support.flir.com/tools
7. Install FLIR Tools/Tools+ on your computer.
8. Start FLIR Tools/Tools+.
9. Connect the camera to your computer, using the USB cable.
10. Import the images into FLIR Tools/Tools+.
1
:
1. For online documentation about FLIR Tools/Tools+, go to http://support.flir.com/resources/f22s/. FLIR Tools+ is
licensed software.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
10
7

Description

7.1 View from the front

7.1.1 Figure

7.1.2 Explanation

1. LCD display.
2. Infrared camera lens.
3. Archive button. Function:
• Push to open the image archive.
4. Back/Cancel button. Function:
• Push to go back into the menu system.
• Push to cancel a choice.
5. Navigation pad. Function:
• Push left/right or up/down to navigate in menus, submenus, and dialog boxes.
• Push the center to confirm.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
11
7
Description
6. Save button. Function:
• Push to save an image.
7. Fine-adjustment knob.

7.2 View from the rear

7.2.1 Figure

7.2.2 Explanation

1. USB connector.
2. On/off button. Function:
• Push the On/off button to turn on the camera.
• Push and hold the On/off button for less than 5 seconds to put the camera into
standby mode. The camera then automatically turns off after 48 hours.
• Push and hold the On/off button for more than 10 seconds to turn off the camera.
3. Stand mount knob.
4. Supporting ring knob.
5. Ground stud.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
12
7
Description

7.3 USB connector

The purpose of this USB connector is the following:
• Charging the battery using the FLIR power supply.
• Charging the battery using a USB cable connected to a computer.
Note Charging the camera using a USB cable connected to a computer takes consid- erably longer than using the FLIR power supply.
• Moving images from the camera to a computer for further analysis in FLIR Tools/Tools+.
Note Install FLIR Tools/Tools+ on your computer before you move the images.

7.4 Screen elements

7.4.1 Figure

7.4.2 Explanation

1. Main menu toolbar.
2. Submenu toolbar.
3. Spotmeter.
4. Result table.
5. Status icons.
6. Temperature scale.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
13
8

Handling the camera unit

8.1 Charging the battery

WARNING
Make sure that you install the socket-outlet near the equipment and that it is easy to get access to.

8.1.1 Charging the battery using the FLIR power supply

Follow this procedure:
1. Connect the power supply to a mains socket.
2. Connect the power supply cable to the USB connector on the camera unit.
3. It is good practice to disconnect the power supply from the mains socket when the bat­tery is fully charged.
Note The charging time for a fully depleted battery is 2 hours.

8.1.2 Charging the battery using a USB cable connected to a computer

Follow this procedure:
1. Connect the camera unit to a computer using a USB cable.
Note
• To charge the camera, the computer must be turned on.
• Charging the camera using a USB cable connected to a computer takes considerably
longer than using the FLIR power supply.

8.2 Turning on and turning off the camera

• Push the On/off button to turn on the camera.
• Push and hold the On/off button for less than 5 seconds to put the camera in standby
mode. The camera then automatically turns off after 48 hours.
• Push and hold the On/off button for more than 10 seconds to turn off the camera.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
14
Handling the camera unit8

8.3 Adjusting the position of the camera unit

8.3.1 Figure

8.3.2 Explanation

1. Fine-adjustment knob.
2. Stand mount knob.
3. Supporting ring knob.

8.3.3 Procedure

Note Do not touch the lens surface. If this happens, clean the lens according to the in-
structions in 12.2 Infrared lens, page 36. Follow this procedure:
1. For fine adjustments, turn the fine-adjustment knob.
2. For coarse adjustments, do the following:
2.1. Loosen the stand mount knob and move the stand mount to the desired posi-
tion. Tighten the stand mount knob.
2.2. Loosen the supporting ring knob and move the supporting ring near the stand
mount. Tighten the supporting ring knob.
8.4 Removing the stand mount from the camera
unit
Note Do not touch the lens surface. If this happens, clean the lens according to the in-
structions in 12.2 Infrared lens, page 36.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
15
Handling the camera unit8

8.4.1 Procedure

Follow this procedure:
1. Turn and remove the top of the stand.
2. Loosen the stand mount knob and remove the camera unit from the stand.
3. Turn the fine-adjustment knob counter-clockwise until you can see a screw. Remove the screw.
4. Turn the fine-adjustment knob clockwise until you can see a screw on the other side. Remove the screw.
5. Remove the stand mount from the camera unit.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
16
Handling the camera unit8
6. Remove the two screws that hold the bracket to the camera unit.
7. Remove the two screws that hold the bracket to the camera unit.
8. Remove the bracket from the camera unit.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
17
9

Operation

9.1 Saving an image

9.1.1 General

You can save multiple images to the internal camera memory.

9.1.2 Image capacity

Approximately 1500 images can be saved to the internal camera memory.

9.1.3 Naming convention

The naming convention for images is FLIRxxxx.jpg, where xxxx is a unique counter.

9.1.4 Procedure

Follow this procedure:
1. To save an image, push the Save button.

9.2 Recalling an image

9.2.1 General

When you save an image, it is stored in the internal camera memory. To display the image again, you can recall it from the internal camera memory.

9.2.2 Procedure

Follow this procedure:
1. Push the Archive button.
2. Push the navigation pad left/right or up/down to select the image you want to view.
3. Push the center of the navigation pad. This displays the selected image.
4. Do one or more of the following:
• To view the image in full screen, display image information, or delete the image,
push the center of the navigation pad. This displays a toolbar.
• To view the previous/next image, push the navigation pad left/right.
5. To return to live mode, push the Back button repeatedly or push the Archive button.

9.3 Deleting an image

9.3.1 General

You can delete one or more images from the internal camera memory.

9.3.2 Procedure

Follow this procedure:
1. Push the Archive button.
2. Push the navigation pad left/right or up/down to select the image you want to delete.
3. Push the center of the navigation pad. This displays the selected image.
4. Push the center of the navigation pad. This displays a toolbar.
5. On the toolbar, select Delete delete the image or to cancel the delete action.
. This displays a dialog box where you can choose to
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
18
9
Operation

9.4 Deleting all images

9.4.1 General

You can delete all images from the internal camera memory.

9.4.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Settings
3. In the dialog box, select Device settings. This displays a dialog box.
4. In the dialog box, select Reset options. This displays a dialog box.
5. In the dialog box, select Delete all saved images. This displays a dialog box where you can choose to permanently delete all the saved images or to cancel the delete action.
. This displays a dialog box.

9.5 Measuring a temperature using a spotmeter

9.5.1 General

You can measure a temperature using a spotmeter. This will display the temperature at the position of the spotmeter on the screen.

9.5.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Measurement
3. On the toolbar, select Center spot The temperature at the position of the spotmeter will now be displayed in the top left corner of the screen.
. This displays a toolbar.
.
9.6 Measuring the hottest temperature within an
area

9.6.1 General

You can measure the hottest temperature within an area. This displays a moving spot­meter that indicates the hottest temperature.

9.6.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Measurement
3. On the toolbar, select Hot spot
. This displays a toolbar.
.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
19
9
Operation
9.7 Measuring the coldest temperature within
an area

9.7.1 General

You can measure the coldest temperature within an area. This displays a moving spot­meter that indicates the coldest temperature.

9.7.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Measurement
3. On the toolbar, select Cold spot
. This displays a toolbar.
.

9.8 Hiding measurement tools

9.8.1 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Measurement
3. On the toolbar, select No measurements
. This displays a toolbar.
.

9.9 Changing the color palette

9.9.1 General

You can change the color palette that the camera uses to display different temperatures. A different palette can make it easier to analyze an image.

9.9.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Color
3. On the toolbar, select a new color palette.
. This displays a toolbar.

9.10 Working with color alarms

9.10.1 General

By using color alarms (isotherms), anomalies can easily be discovered in an infrared im­age. The isotherm command applies a contrasting color to all pixels with a temperature above or below the specified temperature level.

9.10.2 Image examples

This table explains the different color alarms (isotherms).
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
20
9
Operation
Color alarm
Below alarm
Above alarm

9.10.3 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Color
3. On the toolbar, select the type of alarm:
• Below alarm
• Above alarm
4. Push the center of the navigation pad. The threshold temperature is displayed at the top of the screen.
5. To change the threshold temperature, push the navigation pad up/down.
.
.
. This displays a toolbar.

9.11 Changing the temperature scale mode

9.11.1 General

The camera can, depending on the camera model, operate in different temperature scale modes:
• Auto mode: In this mode, the camera is continuously auto-adjusted for the best image
brightness and contrast.
• Manual mode: This mode allows manual adjustments of the temperature span and the
temperature level.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
21
9
Operation

9.11.2 When to use Manual mode

Here are two infrared images of a PCB board. To make it easier to analyze the tempera­ture variations in the component in the upper left corner, the temperature scale in the right image has been changed to values close to the temperature of the component.
Automatic Manual

9.11.3 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Temperature scale
3. On the toolbar, select one of the following:
• Auto
• Manual
4. To change the temperature span and the temperature level in Manual mode, do the following:
• Push the navigation pad left/right to select (highlight) the maximum and/or minimum
temperature.
• Push the navigation pad up/down to change the value of the highlighted
temperature.
.
.
. This displays a toolbar.
9.12 Setting the emissivity as a surface
property

9.12.1 General

To measure temperatures accurately, the camera must know what kind of surface you are measuring. You can choose between the following surface properties:
• Matt.
• Semi-matt.
• Semi-glossy.
For more information about emissivity, see section 15 Thermographic measurement tech- niques, page 43.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
22
9
Operation

9.12.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Settings
3. In the dialog box, select Measurement parameters. This displays a dialog box.
4. In the dialog box, select Emissivity. This displays a dialog box.
5. In the dialog box, select one of the following:
• Matt.
• Semi-matt.
• Semi-glossy.
. This displays a dialog box.

9.13 Setting the emissivity as a custom material

9.13.1 General

Instead of specifying a surface property as matt, semi-matt or semi-glossy, you can specify a custom material from a list of materials.
For more information about emissivity, see section 15 Thermographic measurement tech- niques, page 43.

9.13.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Settings
3. In the dialog box, select Measurement parameters. This displays a dialog box.
4. In the dialog box, select Emissivity. This displays a dialog box.
5. In the dialog box, select Custom material. This displays a list of materials with known emissivities.
6. In the list, select the material.
. This displays a dialog box.

9.14 Changing the emissivity as a custom value

9.14.1 General

For very precise measurements, you may need to set the emissivity, instead of selecting a surface property or a custom material. You also need to understand how emissivity and re­flectivity affect measurements, rather than just simply selecting a surface property.
Emissivity is a property that indicates how much radiation originates from an object as op­posed to being reflected by it. A lower value indicates that a larger proportion is being re­flected, while a high value indicates that a lower proportion is being reflected.
Polished stainless steel, for example, has an emissivity of 0.14, while a structured PVC floor typically has an emissivity of 0.93.
For more information about emissivity, see section 15 Thermographic measurement tech- niques, page 43.

9.14.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
23
9
Operation
2. On the toolbar, select Settings
3. In the dialog box, select Measurement parameters. This displays a dialog box.
4. In the dialog box, select Emissivity. This displays a dialog box.
5. In the dialog box, select Custom value. This displays a dialog box where you can set a custom value.
. This displays a dialog box.
9.15 Changing the reflected apparent
temperature

9.15.1 General

This parameter is used to compensate for the radiation reflected by the object. If the emis­sivity is low and the object temperature significantly different from that of the reflected tem­perature, it will be important to set and compensate for the reflected apparent temperature correctly.
For more information about reflected apparent temperature, see section 15 Thermo- graphic measurement techniques, page 43.

9.15.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Settings
3. In the dialog box, select Measurement parameters. This displays a dialog box.
4. In the dialog box, select Reflected apparent temperature. This displays a dialog box where you can set a value.
. This displays a dialog box.
9.16 Performing a non-uniformity correction
(NUC)

9.16.1 General

When the thermal camera displays Calibrating... it is performing what in thermography is called a ”non-uniformity correction” (NUC). An NUC is an image correction carried out by
the camera software to compensate for different sensitivities of detector elements and oth­er optical and geometrical disturbances bration, page 55.
An NUC is performed automatically, for example at start-up or when the environment tem­perature changes.
You can also perform an NUC manually. This is useful when you have to perform a critical measurement with as little image disturbance as possible.

9.16.2 Procedure

Follow this procedure:
1. To perform a manual NUC, push and hold down the Archive button for more than 2 seconds.
2. Definition from the European standard EN 16714-3:2016, Non-destructive Testing—Thermographic Testing—
Part 3: Terms and Definitions.
2
. For more information, see section 17 About cali-
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
24
9
Operation

9.17 Changing the settings

9.17.1 General

You can change a variety of settings for the camera. The Settings menu includes the following:
• Measurement parameters.
• Device settings.
9.17.1.1 Measurement parameters
• Emissivity: Default value: 0.95.
• Reflected temperature: Default value: 20°C (69°F).
• Distance: Default value: 1.0 m (3.3 ft.).
Note During normal operation there is typically no need to change the default measure­ment parameters. For very accurate measurements, you may need to set the Emissivity and/or the Reflected temperature. For more information, see sections 9.12 Setting the
emissivity as a surface property, 9.13 Setting the emissivity as a custom material, 9.14 Changing the emissivity as a custom value, and 9.15 Changing the reflected apparent temperature.
9.17.1.2 Device settings
• Language, time & units:
◦ Language. ◦ Temperature unit. ◦ Distance unit. ◦ Date & time. ◦ Date & time format.
• Reset options:
◦ Reset default camera mode. ◦ Reset device settings to factory default. ◦ Delete all saved images.
• Auto power off.
• Display intensity.
• Camera information: This menu command displays various items of information about
the camera, such as the model, serial number, and software version.

9.17.2 Procedure

Follow this procedure:
1. Push the center of the navigation pad. This displays a toolbar.
2. On the toolbar, select Settings
3. In the dialog box, select the setting that you want to change and use the navigation pad to display additional dialog boxes.
. This displays a dialog box.

9.18 Updating the camera

9.18.1 General

To take advantage of our latest camera firmware, it is important that you keep your camera updated. You update your camera using FLIR Tools/Tools+.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
25
9
Operation

9.18.2 Procedure

Follow this procedure:
1. Start FLIR Tools/Tools+.
2. Start the camera.
3. Connect the camera to the computer using the USB cable.
4. On the Help menu in FLIR Tools/Tools+, click Check for updates.
5. Follow the on-screen instructions.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
26
10

Technical data

10.1 Online field-of-view calculator

Please visit http://support.flir.com and click the photo of the camera series for field-of-view
tables for all lens–camera combinations.

10.2 Note about technical data

FLIR Systems reserves the right to change specifications at any time without prior notice. Please check http://support.flir.com for latest changes.

10.3 Note about authoritative versions

The authoritative version of this publication is English. In the event of divergences due to translation errors, the English text has precedence.
Any late changes are first implemented in English.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
27
Technical data10

10.4 FLIR ETS320

P/N: 63950-1001 Rev.: 41898
General description
The FLIR ETS320 is FLIR’s first electronic test bench camera, designed for a quick temperature check of PCB boards and electronic devices. The FLIR ETS320 is sensitive enough to detect subtle temperature difference with an accuracy of ±3°C, so you can quickly find hot spots and potential points of failure. The 320 × 240 pixel infrared detector offers more than 76 000 points of temperature measurement, eliminating the guesswork of legacy measurement tools. Designed specifically for bench-top work, the battery-pow­ered FLIR ETS 320 connects to your PC for immediate analysis and sharing of thermal data.
Benefits:
• Reduces test times: Quickly identify hot spots, thermal gradients, and potential points of failure.
• Improves product design: Know where and when to add fans and heatsinks, and ensure products are operating within specification for their maximum lifetime.
• Saves money: Improve rapid prototyping and reduce product development cycles.
• Optimizes lab time: Battery powered and hands-free, and offers complete measurement and analysis in the camera.
Key features:
• >76 000 points of non-contact temperature measurement at the push of a button.
• 320 × 240 pixel detector provides crisp thermal imagery.
• Time versus temperature measurement with FLIR Tools+.
• Small-component measurement, down to 170 µm per pixel spot size.
• Lens offers a 45° thermal view of the target for the quick detection of hot spots.
• Records radiometric imagery in standard JPEG format for easier sharing.
• ±3% accuracy promotes quality assurance and factory acceptance of PCBs.
• Quickly mounts on the supplied stand for immediate use.
• Crisp 3 in. LCD display provides immediate thermal feedback.
• World-class software provided for advanced measurement corrections/capabilities.
Imaging and optical data
IR resolution 320 × 240 pixels
Thermal sensitivity/NETD <0.06°C (0.11°F)/<60 mK
Field of view (FOV)
Fixed focus distance Spatial resolution (IFOV)
F-number 1.5 Image frequency 9 Hz
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
Image presentation
Display 3.0 in. 320 × 240 color LCD
Image adjustment
45° × 34°
70 mm ± 10 mm
2.6 mrad
7.5–13 µm
Automatic/manual
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
28
Technical data10
Measurement
Object temperature range –20°C to +250°C (–4°F to +482°F)
Accuracy
Measurement analysis
Spotmeter Center spot
Area Emissivity correction Variable from 0.1 to 1.0
Emissivity table Emissivity table of predefined materials
Reflected apparent temperature correction Automatic, based on input of reflected temperature
Set-up
Color palettes
Set-up commands Local adaptation of units, language, date and time
±3°C (±5.4°F) or ±3% of reading, whichever great­est, for ambient temperature 10°C to 35°C (+50°F to 95°F) and object temperature above +0°C (+32° F)
Box with maximum/minimum
Black and white, iron, and rainbow
formats
Video streaming
Radiometric IR video streaming Full dynamic to PC (FLIR Tools/Tools+) using USB
Non-radiometric IR video streaming
Storage of images
File formats Standard JPEG, 14-bit measurement data
Data communication interfaces
Interfaces USB Micro: Data transfer to and from PC and Mac
Power system
Battery type Rechargeable Li ion battery
Battery voltage 3.7 V
Battery operating time
Charging system
Charging time 2.5 hours to 90% capacity
Power management Automatic shut-down
AC operation AC adapter, 90–260 V AC input, 5 V DC output to
Environmental data
Operating temperature range 10–40°C (50–104°F)
Storage temperature range –40 to +70°C (–40 to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity
Encapsulation
Uncompressed colorized video using USB
included
devices
Approximately 4 hours at 25°C (77°F) ambient temperature and typical use
Battery is charged inside the unit
camera
IP 40 (IEC 60529)
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
29
Technical data10
Directives and regulations
Directives and regulations
Physical data
System weight, incl. battery 1.8 kg (4.0 lb.)
System size (L × W × H) 220 mm × 150 mm × 300 mm (8.7 in. × 5.9 in. ×
Color
Shipping information
Packaging, type Cardboard box
List of contents
Packaging, weight 2.9 kg (6.4 lb.)
Packaging, size (L × W × H) 290 mm × 170 mm × 378 mm (11.4 in. × 6.7 in. ×
EAN-13 4743254002913 UPC-12 Country of origin Designed & Engineered by FLIR Systems, Sweden.
• Battery Directive 2006/66/EC
• EMC Directive 2014/30/EU
• FCC 47 CFR Part 15 Class B Subpart B
• REACH Regulation EC 1907/2006
• RoHS2 Directive 2011/65/EC
• WEEE Directive 2012/19/EC
11.8 in.)
Black and gray
• FLIR Tools+
• Infrared camera unit
• Power supply
• Printed documentation
• USB cable
14.9 in.)
845188014186
Assembled in Taiwan.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
30
0,06in
1,5mm
(ESD discharge plate)
4,39in
111,6mm
11,81in
300mm
0,38in
9,7mm
1,83in
46,4mm
2,48in
63mm
0,84in
21,3mm
5,91in
150mm
8,66in
220mm
0,31in
R8mm
1,97in
R50mm
4,43in
112,5mm
Optical Center
2,95in
75mm
1,58in
40,2mm
6,94in
176,2mm
2,17in
55,2mm
0,36in
9,2mm
1,57in
40mm
Optical Center
3,98in
101,2mm
Front View
Top View
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
1(4)
T130266
Basic Dimension ETS 320
TMHA
2017-03-01
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
A
1:2
Scale
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
2,56in
±0,39
65mm
±10
( 0 - 6,9 in)
Max object height 0 - 176mm
0,87in
22mm
1,23in
31,15mm
2,56in
±0,39
65mm
±10
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
2(4)
T130266
Basic Dimension ETS 320
TMHA
2017-03-01
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
A
1:2
Scale
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
A
0,94in
24mm
0,83in
21mm
DETAIL A
SCALE 1 : 1
Total adjustment length (locked): 45mm (1,77 in)
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
3(4)
T130266
Basic Dimension ETS 320
TMHA
2017-03-01
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
A
1:2
Scale
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Sheet
Drawing No.
Size
Check
Drawn by
Denomination
A3
4(4)
T130266
Basic Dimension ETS 320
TMHA
2017-03-01
R&D Instruments
Modified
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
F
G
H
1 32 54
C
F
B
D
G
E
A
6
Rev
A
1:2
Scale
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
12

Cleaning the camera

12.1 Camera housing, cables, and other items

12.1.1 Liquids

Use one of these liquids:
• Warm water
• A weak detergent solution

12.1.2 Equipment

A soft cloth

12.1.3 Procedure

Follow this procedure:
1. Soak the cloth in the liquid.
2. Twist the cloth to remove excess liquid.
3. Clean the part with the cloth.
CAUTION
Do not apply solvents or similar liquids to the camera, the cables, or other items. This can cause damage.

12.2 Infrared lens

12.2.1 Liquids

Use one of these liquids:
• A commercial lens cleaning liquid with more than 30% isopropyl alcohol.
• 96% ethyl alcohol (C

12.2.2 Equipment

Cotton wool
CAUTION
If you use a lens cleaning cloth it must be dry. Do not use a lens cleaning cloth with the liquids that are giv­en in section 12.2.1 above. These liquids can cause material on the lens cleaning cloth to become loose. This material can have an unwanted effect on the surface of the lens.

12.2.3 Procedure

Follow this procedure:
1. Soak the cotton wool in the liquid.
2. Twist the cotton wool to remove excess liquid.
3. Clean the lens one time only and discard the cotton wool.
2H5
OH).
WARNING
Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on con­tainers before you use a liquid: the liquids can be dangerous.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
36
12
Cleaning the camera
CAUTION
• Be careful when you clean the infrared lens. The lens has a delicate anti-reflective coating.
• Do not clean the infrared lens too vigorously. This can damage the anti-reflective coating.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
37
13

About FLIR Systems

FLIR Systems was established in 1978 to pioneer the development of high-performance infrared imaging systems, and is the world leader in the design, manufacture, and market­ing of thermal imaging systems for a wide variety of commercial, industrial, and govern­ment applications. Today, FLIR Systems embraces five major companies with outstanding achievements in infrared technology since 1958—the Swedish AGEMA Infrared Systems (formerly AGA Infrared Systems), the three United States companies Indigo Systems, FSI, and Inframetrics, and the French company Cedip.
Since 2007, FLIR Systems has acquired several companies with world-leading expertise in sensor technologies:
• Extech Instruments (2007)
• Ifara Tecnologías (2008)
• Salvador Imaging (2009)
• OmniTech Partners (2009)
• Directed Perception (2009)
• Raymarine (2010)
• ICx Technologies (2010)
• TackTick Marine Digital Instruments (2011)
• Aerius Photonics (2011)
• Lorex Technology (2012)
• Traficon (2012)
• MARSS (2013)
• DigitalOptics micro-optics business (2013)
• DVTEL (2015)
• Point Grey Research (2016)
• Prox Dynamics (2016)
Figure 13.1 Patent documents from the early 1960s
FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
38
13
About FLIR Systems
manufacturing plant in Tallinn, Estonia. Direct sales offices in Belgium, Brazil, China, France, Germany, Great Britain, Hong Kong, Italy, Japan, Korea, Sweden, and the USA— together with a worldwide network of agents and distributors—support our international customer base.
FLIR Systems is at the forefront of innovation in the infrared camera industry. We antici­pate market demand by constantly improving our existing cameras and developing new ones. The company has set milestones in product design and development such as the in­troduction of the first battery-operated portable camera for industrial inspections, and the first uncooled infrared camera, to mention just two innovations.
Figure 13.2 1969: Thermovision Model 661. The camera weighed approximately 25 kg (55 lb.), the oscilloscope 20 kg (44 lb.), and the tripod 15 kg (33 lb.). The operator also needed a 220 VAC gen­erator set, and a 10 L (2.6 US gallon) jar with liquid nitrogen. To the left of the oscilloscope the Polaroid attachment (6 kg/13 lb.) can be seen.
Figure 13.3 2015: FLIR One, an accessory to iPhone and Android mobile phones. Weight: 90 g (3.2 oz.).
FLIR Systems manufactures all vital mechanical and electronic components of the camera systems itself. From detector design and manufacturing, to lenses and system electronics, to final testing and calibration, all production steps are carried out and supervised by our own engineers. The in-depth expertise of these infrared specialists ensures the accuracy and reliability of all vital components that are assembled into your infrared camera.

13.1 More than just an infrared camera

At FLIR Systems we recognize that our job is to go beyond just producing the best infrared camera systems. We are committed to enabling all users of our infrared camera systems to work more productively by providing them with the most powerful camera–software combination. Especially tailored software for predictive maintenance, R & D, and process monitoring is developed in-house. Most software is available in a wide variety of languages.
We support all our infrared cameras with a wide variety of accessories to adapt your equip­ment to the most demanding infrared applications.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
39
13
About FLIR Systems

13.2 Sharing our knowledge

Although our cameras are designed to be very user-friendly, there is a lot more to thermog­raphy than just knowing how to handle a camera. Therefore, FLIR Systems has founded the Infrared Training Center (ITC), a separate business unit, that provides certified training courses. Attending one of the ITC courses will give you a truly hands-on learning experience.
The staff of the ITC are also there to provide you with any application support you may need in putting infrared theory into practice.

13.3 Supporting our customers

FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equip­ment and expertise to solve it within the shortest possible time. Therefore, there is no need to send your camera to the other side of the world or to talk to someone who does not speak your language.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
40
14

Terms, laws, and definitions

Term Definition
Absorption and emission
Apparent temperature uncompensated reading from an infrared instrument, contain-
Color palette assigns different colors to indicate specific levels of apparent
Conduction direct transfer of thermal energy from molecule to molecule,
Convection heat transfer mode where a fluid is brought into motion, either
Diagnostics examination of symptoms and syndromes to determine the
Direction of heat transfer
Emissivity ratio of the power radiated by real bodies to the power that is
Energy conservation
Exitant radiation radiation that leaves the surface of an object, regardless of its
Heat thermal energy that is transferred between two objects (sys-
Heat transfer rate
Incident radiation radiation that strikes an object from its surroundings
IR thermography process of acquisition and analysis of thermal information
Isotherm replaces certain colors in the scale with a contrasting color. It
3
6
9
10
The capacity or ability of an object to absorb incident radiated energy is always the same as the capacity to emit its own en­ergy as radiation
ing all radiation incident on the instrument, regardless of its
4
sources
temperature. Palettes can provide high or low contrast, de­pending on the colors used in them
caused by collisions between the molecules
by gravity or another force, thereby transferring heat from one place to another
nature of faults or failures Heat will spontaneously flow from hotter to colder, thereby
transferring thermal energy from one place to another
radiated by a blackbody at the same temperature and at the same wavelength
The sum of the total energy contents in a closed system is constant
original sources
tems) due to their difference in temperature
The heat transfer rate under steady state conditions is directly proportional to the thermal conductivity of the object, the cross-sectional area of the object through which the heat flows, and the temperature difference between the two ends of the object. It is inversely proportional to the length, or thick­ness, of the object
from non-contact thermal imaging devices
marks an interval of equal apparent temperature
5
7
8
11
12
3. Kirchhoff’s law of thermal radiation.
4. Based on ISO 18434-1:2008 (en).
5. Based on ISO 13372:2004 (en).
6. 2nd law of thermodynamics.
7. This is a consequence of the 2nd law of thermodynamics, the law itself is more complicated.
8. Based on ISO 16714-3:2016 (en).
9. 1st law of thermodynamics.
10.Fourier’s law.
11.This is the one-dimensional form of Fourier’s law, valid for steady-state conditions.
12.Based on ISO 18434-1:2008 (en)
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
41
14
Terms, laws, and definitions
Term Definition
Qualitative thermography thermography that relies on the analysis of thermal patterns to
Quantitative thermography
Radiative heat transfer Heat transfer by the emission and absorption of thermal
Reflected apparent temperature apparent temperature of the environment that is reflected by
Spatial resolution ability of an IR camera to resolve small objects or details
Temperature measure of the average kinetic energy of the molecules and
Thermal energy total kinetic energy of the molecules that make up the object
Thermal gradient gradual change in temperature over distance
Thermal tuning process of putting the colors of the image on the object of
reveal the existence of and to locate the position of anomalies
13
thermography that uses temperature measurement to deter­mine the seriousness of an anomaly, in order to establish re­pair priorities
13
radiation
the target into the IR camera
14
atoms that make up the substance
14
analysis, in order to maximize contrast
15
13.Based on ISO 10878-2013 (en).
14.Based on ISO 16714-3:2016 (en).
15.Thermal energy is part of the internal energy of an object.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
42
15

Thermographic measurement techniques

15.1 Introduction

An infrared camera measures and images the emitted infrared radiation from an object. The fact that radiation is a function of object surface temperature makes it possible for the camera to calculate and display this temperature.
However, the radiation measured by the camera does not only depend on the temperature of the object but is also a function of the emissivity. Radiation also originates from the sur­roundings and is reflected in the object. The radiation from the object and the reflected ra­diation will also be influenced by the absorption of the atmosphere.
To measure temperature accurately, it is therefore necessary to compensate for the effects of a number of different radiation sources. This is done on-line automatically by the cam­era. The following object parameters must, however, be supplied for the camera:
• The emissivity of the object
• The reflected apparent temperature
• The distance between the object and the camera
• The relative humidity
• Temperature of the atmosphere

15.2 Emissivity

The most important object parameter to set correctly is the emissivity which, in short, is a measure of how much radiation is emitted from the object, compared to that from a perfect blackbody of the same temperature.
Normally, object materials and surface treatments exhibit emissivity ranging from approxi­mately 0.1 to 0.95. A highly polished (mirror) surface falls below 0.1, while an oxidized or painted surface has a higher emissivity. Oil-based paint, regardless of color in the visible spectrum, has an emissivity over 0.9 in the infrared. Human skin exhibits an emissivity
0.97 to 0.98. Non-oxidized metals represent an extreme case of perfect opacity and high reflexivity,
which does not vary greatly with wavelength. Consequently, the emissivity of metals is low – only increasing with temperature. For non-metals, emissivity tends to be high, and de­creases with temperature.

15.2.1 Finding the emissivity of a sample

15.2.1.1 Step 1: Determining reflected apparent temperature
Use one of the following two methods to determine reflected apparent temperature:
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
43
Thermographic measurement techniques15
15.2.1.1.1 Method 1: Direct method Follow this procedure:
1. Look for possible reflection sources, considering that the incident angle = reflection an­gle (a = b).
Figure 15.1 1 = Reflection source
2. If the reflection source is a spot source, modify the source by obstructing it using a piece if cardboard.
Figure 15.2 1 = Reflection source
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
44
Thermographic measurement techniques15
3. Measure the radiation intensity (= apparent temperature) from the reflection source us­ing the following settings:
• Emissivity: 1.0
• D
: 0
obj
You can measure the radiation intensity using one of the following two methods:
Figure 15.3 1 = Reflection source Figure 15.4 1 = Reflection source
You can not use a thermocouple to measure reflected apparent temperature, because a thermocouple measures temperature, but apparent temperatrure is radiation intensity.
15.2.1.1.2 Method 2: Reflector method
Follow this procedure:
1. Crumble up a large piece of aluminum foil.
2. Uncrumble the aluminum foil and attach it to a piece of cardboard of the same size.
3. Put the piece of cardboard in front of the object you want to measure. Make sure that the side with aluminum foil points to the camera.
4. Set the emissivity to 1.0.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
45
Thermographic measurement techniques15
5. Measure the apparent temperature of the aluminum foil and write it down. The foil is considered a perfect reflector, so its apparent temperature equals the reflected appa­rent temperature from the surroundings.
Figure 15.5 Measuring the apparent temperature of the aluminum foil.
15.2.1.2 Step 2: Determining the emissivity
Follow this procedure:
1. Select a place to put the sample.
2. Determine and set reflected apparent temperature according to the previous procedure.
3. Put a piece of electrical tape with known high emissivity on the sample.
4. Heat the sample at least 20 K above room temperature. Heating must be reasonably even.
5. Focus and auto-adjust the camera, and freeze the image.
6. Adjust Level and Span for best image brightness and contrast.
7. Set emissivity to that of the tape (usually 0.97).
8. Measure the temperature of the tape using one of the following measurement functions:
• Isotherm (helps you to determine both the temperature and how evenly you have
heated the sample)
• Spot (simpler)
• Box Avg (good for surfaces with varying emissivity).
9. Write down the temperature.
10. Move your measurement function to the sample surface.
11. Change the emissivity setting until you read the same temperature as your previous measurement.
12. Write down the emissivity.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
46
Thermographic measurement techniques15
Note
• Avoid forced convection
• Look for a thermally stable surrounding that will not generate spot reflections
• Use high quality tape that you know is not transparent, and has a high emissivity you
are certain of
• This method assumes that the temperature of your tape and the sample surface are the
same. If they are not, your emissivity measurement will be wrong.

15.3 Reflected apparent temperature

This parameter is used to compensate for the radiation reflected in the object. If the emis­sivity is low and the object temperature relatively far from that of the reflected it will be im­portant to set and compensate for the reflected apparent temperature correctly.

15.4 Distance

The distance is the distance between the object and the front lens of the camera. This pa­rameter is used to compensate for the following two facts:
• That radiation from the target is absorbed by the atmosphere between the object and
the camera.
• That radiation from the atmosphere itself is detected by the camera.

15.5 Relative humidity

The camera can also compensate for the fact that the transmittance is also dependent on the relative humidity of the atmosphere. To do this set the relative humidity to the correct value. For short distances and normal humidity the relative humidity can normally be left at a default value of 50%.

15.6 Other parameters

In addition, some cameras and analysis programs from FLIR Systems allow you to com­pensate for the following parameters:
• Atmospheric temperature – i.e. the temperature of the atmosphere between the camera
and the target
• External optics temperature – i.e. the temperature of any external lenses or windows
used in front of the camera
• External optics transmittance – i.e. the transmission of any external lenses or windows
used in front of the camera
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
47
16

The secret to a good thermal image

16.1 Introduction

The use of thermal cameras has spread to many professional environments in recent years. They are easy to handle, and thermal images are quick to take. Images can also be attached to reports easily, e.g., for an inspection of an electrical installation or building as evidence of work carried out or of any faults or deviations identified. However, people often forget that an image to be used as evidence or even proof before the courts must meet certain requirements: this is not achieved with a quick snapshot. So, what characterizes a really good thermal image?

16.2 Background

During the practical exercises in our thermography training classes we notice, time and time again, how difficult some participants find choosing the optimal camera settings for different tasks. Not everyone has a background in, for example, amateur photography (more on the difference between thermography and photography in the next section), and to take a good and meaningful thermal image you need some knowledge of photography, including its practical application. For this reason, it is hardly surprising that thermogra­phers, particularly those without training, repeatedly produce reports with thermal images that are devoid of meaning or even support the wrong conclusions and are fit only for the waste bin. Unfortunately, such reports are found not only in companies in which thermog­raphy is more of an added bonus but also in businesses where these reports may be part of a critical process monitoring or maintenance program. There are two main reasons for this: either the users don't know what a good thermal image is or how to take one, or—for whatever reason—the job is not being done properly.

16.3 A good image

As thermography and photography are related, it makes sense to take a look at what is im­portant to professional photographers. How do they characterize a good image? Three as­pects can be pointed out as the most important:
1. An image has to touch the observer in some way. That means it needs to be unusual, striking, or unique, and has to arouse interest and, depending on the genre, emotion.
2. The composition and balance must be in harmony; the image detail and content must go together aesthetically.
3. The lighting must be interesting, such as back lighting or side lighting that casts dra­matic shadows, or evening light or other pleasing illumination—whatever fits the overall effect that the photographer wants.
To what extent can these concepts be applied to thermography? With thermography, the motif should also be interesting. In other words, our aim is to de-
pict an object or its condition. Emotions are not required—facts have priority in thermal im­ages (assuming they are not an art project!). In everyday working life, it is important to illustrate thermal patterns clearly and to facilitate temperature measurements.
The thermal image must also have suitable image detail and display the object at an ap­propriate size and position.
Without external illumination, neither visual sight nor photography is possible because what we see with our eyes or capture with a camera is reflected light. In thermography, the camera records both emitted and reflected radiation. Therefore, the relationship and inten­sity of the infrared radiation, both emitted by the object and by the surrounding environ­ment, are important. Brightness and contrast in the image are then adjusted by changing the displayed temperature interval.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
48
The secret to a good thermal image16
The comparison between photography and thermography can be summarized in a table using a few keywords:
Photography Thermography
Interesting motif The object to be examined
“Tells a story” “Presents facts”
Aesthetically pleasing
Emotive
Image detail Image detail
Focus Focus Lighting Emission and reflection
Brightness Brightness
Contrast Contrast
Clear heat patterns
Objective
As with photography, in thermography there are countless possibilities for editing images —provided they are saved as radiometric images. However, not all settings can be changed, and not all image errors can be corrected.

16.4 The three unchangeables—the basis for a good image

16.4.1 Focus

A professional thermal image is always focused and sharp, and the object and heat pat­tern must be clear and easy to recognize.
Figure 16.1 Only hazy “patches of heat” can be seen in the unfocused image (left). The focused image (right) clearly shows which object is being observed and where the object is warm.
A blurred image not only comes across as unprofessional and makes it harder to identify the object and any faults (see Figure 16.1) but can also lead to measurement errors (see Figure 16.2), which are more serious the smaller the measurement object. Even if all other parameters are set correctly, the measurement values from an unfocused thermal image are highly likely to be incorrect.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
49
The secret to a good thermal image16
Figure 16.2 Focused thermal image (left) with a maximum temperature of T
unfocused thermal image (right) with a maximum temperature of T
= 73.7°C (164.7°F).
max
= 89.7°C (193.5°F) and an
max
Of course, the size of the detector matrix also plays a role in image quality. Images taken by cameras with small detectors (i.e., with fewer pixels) are more blurred or “grainier” and give the impression that they are not focused (see Figure 16.3). It should also be noted that not every camera can be focused, and in this case the only means of focusing the camera is by changing the distance from the object.
Figure 16.3 The same radiator from the same distance with the same settings, taken by three different ther­mal cameras: FLIR C2 (left), FLIR T440 (middle), and FLIR T640 (right).

16.4.2 Temperature range

For hand-held uncooled microbolometer cameras, the “exposure” is essentially preset by the image frame rate. This means that it is not possible to choose for how long—and there­fore how much—radiation hits the camera detector. For this reason, an appropriate tem­perature range must be selected that matches the amount of incident radiation. If a temperature range is selected that is too low, the image will be oversaturated, as objects with higher temperatures emit more infrared radiation than colder objects. If you select a temperature range that is too high, the thermal image will be “underexposed,” as can be seen in Figure 16.4.
Figure 16.4 Images from a FLIR T440 with temperature ranges of –20 to +120°C, (left, –4 to +248°F), 0 to +650°C (middle, +32 to +1202°F) and +250 to +1200°C (right, +482 to +2192°F). All other settings are unchanged.
To take an image or temperature measurement, the lowest possible temperature range available on the camera should be selected. However, it must also include the highest temperature in the image (see Figure 16.5).
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
50
The secret to a good thermal image16
Figure 16.5 An image of the same object taken with different temperature ranges: –20 to 120°C (left, –4 to
+248°F) and 0 to 650°C (right, +32 to +1202°F). The temperature in the left image is displayed with a warn­ing sign (a red circle with a white cross) because the measured values are outside the calibrated range.
Depending on the camera model and configuration options, overdriven and underdriven areas can be displayed in a contrasting color.

16.4.3 Image detail and distance from the object

Illumination in photography corresponds in thermography to the interplay of radiation from the object and reflected radiation from the surrounding environment. The latter is un­wanted because interfering—or, at the very least, spot—reflections need to be avoided. This is achieved by choosing a suitable position from where to take images. It is also ad­visable to select a position from which the object of interest can be seen clearly and is not hidden. This may seem obvious but in the building sector, for example, it is common to find reports in which pipes or windows to be investigated are hidden behind sofas, indoor plants or curtains. Figure 16.6 illustrates this situation—which occurs all too regularly.
Figure 16.6 “Thermographic inspection” of an inaccessible object.
It is also important that the object under investigation, or its areas of interest, take up the whole thermal image. This is particularly true when measuring the temperature of small objects. The spot tool must be completely filled by the object to enable correct tempera­ture measurements. Since the field of view and therefore the spot size are determined by both the distance to the object and the camera’s optics, in such situations the distance to the object must either be reduced (get closer!) or a telephoto lens must be used (see Fig­ure 16.7).
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
51
The secret to a good thermal image16
Figure 16.7 Supply and return lines from radiators in an open-plan office. The left image was taken from a
distance of 1 m: the measurement spot is filled and the temperature measurement is correct. The right im­age was taken from a distance of 3 m: the measurement spot is not completely filled and the measured tem­perature values are incorrect (31.4 and 24.4°C (88.5 and 75.9°F) instead of 33.2 and 25.9°C (91.8 and 78.6° F)).

16.5 The changeables—image optimization and temperature measurement

16.5.1 Level and span

After choosing the appropriate temperature range, you can adjust the contrast and bright­ness of the thermal image by changing the temperature intervals displayed. In manual mode, the false colors available in the palette can be assigned to the temperatures of the object of interest. This process is often referred to as “thermal tuning.” In automatic mode, the camera selects the coldest and warmest apparent temperatures in the image as the upper and lower limits of the temperature interval currently displayed.
A good or problem-specific scaling of the thermal image is an important step in the inter­pretation of the image, and is, unfortunately, often underestimated (see Figure 16.8).
Figure 16.8 A thermal image in automatic mode (left) and in manual model (right). The adjusted tempera­ture interval increases the contrast in the image and makes the faults clear.

16.5.2 Palettes and isotherms

Palettes represent intervals with the same apparent temperatures using different sets of colors. In other words, they translate specific radiation intensities into colors that are spe­cific to a particular palette. Frequently used palettes include the gray, iron, and rainbow pa­lettes (see Figure 16.9). Gray tones are particularly suited to resolving small geometric details but are less suited to displaying small differences in temperature. The iron palette is very intuitive and also easy to understand for those without much experience in ther­mography. It offers a good balance between geometric and thermal resolution. The rain­bow palette is more colorful and alternates between light and dark colors. This results in
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
52
The secret to a good thermal image16
greater contrast, but this can lead to a noisy image for objects with different surfaces or many temperatures.
Figure 16.9 Gray, iron, and rainbow palettes (left to right).
The isotherm is a measuring function that displays a given interval of the same apparent temperature or radiation intensity in a color that is different from the palette. It allows you to emphasize temperature patterns in the image (see Figure 16.10).
Figure 16.10 Foundation wall: connection between the old (left in image) and the new (right in image) parts of the building. The isotherm highlights an area of air leakage.

16.5.3 Object parameters

As we have seen, the appearance of thermal images is dependent on the thermographer’s technique and choice of settings, and the look of saved radiometric images can be altered by editing. However, it is also possible to change the settings that are relevant for the cal­culation of temperatures. In practice, this means that the emissivity and reflected apparent temperature can be altered retrospectively. If you notice that these parameters have been set incorrectly or want to add more measurement spots, the temperature measurement values will be calculated or recalculated according to the changes (see Figure 16.11).
Figure 16.11 Change in emissivity for a saved image. The maximum temperature is 65.0°C (149°F) for ε =
0.95 in the left image and 77.3°C (171.1°F) for ε = 0.7 in the right image.

16.6 Taking images—practical tips

The following list includes some practical tips. However, note that this is not a comprehen­sive description of the thermal imaging procedure.
• Ensure that the camera is saving radiometric images.
• Choose an appropriate position from which to take images:
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
53
The secret to a good thermal image16
◦ Observe the radiative situation. ◦ Check that the object is clearly visible and displayed at an appropriate size and
position.
• If you change the emissivity, monitor the temperature range and make sure that it re-
mains appropriate.
• Focus.
• Use a tripod to minimize camera shake.
• Carry out thermal tuning.
• Take note of the object description, object size, actual distance, environmental condi-
tions, and operating conditions.
It is easier to edit the thermal image when it is saved or “frozen” (in “Preview”). Also, since you don't have to do everything on site, you can leave dangerous zones immediately after taking the image. If possible, take a few more images than you need—including from dif­ferent angles. This is preferable to taking too few! You can then choose the best image afterwards, at leisure.

16.7 Conclusion

Taking a good thermal image does not require any magic tricks—solid craft and sound work is all that is required. Many of the points mentioned may seem trivial and “old news,” particularly to amateur photographers. Of course, the equipment plays a role easier to en­sure sharp images. Better, i.e. high-definition, cameras allow the fast localization of even small anomalies, and without focusing capabilities it is always difficult to capture a sharp image. However, high-end cameras are no guarantee of good images if used incorrectly. The basis for good, professional work is education and training in thermography, exchange of knowledge with other thermographers, and, of course, practical experience.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
54
17

About calibration

17.1 Introduction

Calibration of a thermal camera is a prerequisite for temperature measurement. The cali­bration provides the relationship between the input signal and the physical quantity that the user wants to measure. However, despite its widespread and frequent use, the term “calibration” is often misunderstood and misused. Local and national differences as well as translation-related issues create additional confusion.
Unclear terminology can lead to difficulties in communication and erroneous translations, and subsequently to incorrect measurements due to misunderstandings and, in the worst case, even to lawsuits.

17.2 Definition—what is calibration?

The International Bureau of Weights and Measures16defines calibration17in the following way:
an operation that, under specified conditions, in a first step, establishes a relation between the quantity values with measurement uncertainties provided by measurement standards and corresponding indications with associated measurement uncertainties and, in a sec­ond step, uses this information to establish a relation for obtaining a measurement result from an indication.
The calibration itself may be expressed in different formats: this can be a statement, cali­bration function, calibration diagram
Often, the first step alone in the above definition is perceived and referred to as being “cal­ibration.” However, this is not (always) sufficient.
Considering the calibration procedure of a thermal camera, the first step establishes the relation between emitted radiation (the quantity value) and the electrical output signal (the indication). This first step of the calibration procedure consists of obtaining a homogene­ous (or uniform) response when the camera is placed in front of an extended source of radiation.
As we know the temperature of the reference source emitting the radiation, in the second step the obtained output signal (the indication) can be related to the reference source’s temperature (measurement result). The second step includes drift measurement and compensation.
To be correct, calibration of a thermal camera is, strictly, not expressed through tempera­ture. Thermal cameras are sensitive to infrared radiation: therefore, at first you obtain a ra­diance correspondence, then a relationship between radiance and temperature. For bolometer cameras used by non-R&D customers, radiance is not expressed: only the tem­perature is provided.
18
, calibration curve19, or calibration table.

17.3 Camera calibration at FLIR Systems

Without calibration, an infrared camera would not be able to measure either radiance or temperature. At FLIR Systems, the calibration of uncooled microbolometer cameras with a
16.http://www.bipm.org/en/about-us/ [Retrieved 2017-01-31.]
17.http://jcgm.bipm.org/vim/en/2.39.html [Retrieved 2017-01-31.]
18.http://jcgm.bipm.org/vim/en/4.30.html [Retrieved 2017-01-31.]
19.http://jcgm.bipm.org/vim/en/4.31.html [Retrieved 2017-01-31.]
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
55
About calibration17
measurement capability is carried out during both production and service. Cooled cam­eras with photon detectors are often calibrated by the user with special software. With this type of software, in theory, common handheld uncooled thermal cameras could be cali­brated by the user too. However, as this software is not suitable for reporting purposes, most users do not have it. Non-measuring devices that are used for imaging only do not need temperature calibration. Sometimes this is also reflected in camera terminology when talking about infrared or thermal imaging cameras compared with thermography cameras, where the latter are the measuring devices.
The calibration information, no matter if the calibration is done by FLIR Systems or the user, is stored in calibration curves, which are expressed by mathematical functions. As radiation intensity changes with both temperature and the distance between the object and the camera, different curves are generated for different temperature ranges and ex­changeable lenses.
17.4 The differences between a calibration
performed by a user and that performed directly at FLIR Systems
First, the reference sources that FLIR Systems uses are themselves calibrated and trace­able. This means, at each FLIR Systems site performing calibration, that the sources are controlled by an independent national authority. The camera calibration certificate is con­firmation of this. It is proof that not only has the calibration been performed by FLIR Sys­tems but that it has also been carried out using calibrated references. Some users own or have access to accredited reference sources, but they are very few in number.
Second, there is a technical difference. When performing a user calibration, the result is often (but not always) not drift compensated. This means that the values do not take into account a possible change in the camera’s output when the camera’s internal temperature varies. This yields a larger uncertainty. Drift compensation uses data obtained in climate­controlled chambers. All FLIR Systems cameras are drift compensated when they are first delivered to the customer and when they are recalibrated by FLIR Systems service departments.

17.5 Calibration, verification and adjustment

A common misconception is to confuse calibration with verification or adjustment. Indeed, calibration is a prerequisite for verification, which provides confirmation that specified re­quirements are met. Verification provides objective evidence that a given item fulfills speci­fied requirements. To obtain the verification, defined temperatures (emitted radiation) of calibrated and traceable reference sources are measured. The measurement results, in­cluding the deviation, are noted in a table. The verification certificate states that these measurement results meet specified requirements. Sometimes, companies or organiza­tions offer and market this verification certificate as a “calibration certificate.”
Proper verification—and by extension calibration and/or recalibration—can only be achieved when a validated protocol is respected. The process is more than placing the camera in front of blackbodies and checking if the camera output (as temperature, for in­stance) corresponds to the original calibration table. It is often forgotten that a camera is not sensitive to temperature but to radiation. Furthermore, a camera is an imaging system, not just a single sensor. Consequently, if the optical configuration allowing the camera to “collect” radiance is poor or misaligned, then the “verification” (or calibration or recalibra­tion) is worthless.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
56
About calibration17
For instance, one has to ensure that the distance between the blackbody and the camera as well as the diameter of the blackbody cavity are chosen so as to reduce stray radiation and the size-of-source effect.
To summarize: a validated protocol must comply with the physical laws for radiance, and not only those for temperature.
Calibration is also a prerequisite for adjustment, which is the set of operations carried out on a measuring system such that the system provides prescribed indications correspond­ing to given values of quantities to be measured, typically obtained from measurement standards. Simplified, adjustment is a manipulation that results in instruments that meas­ure correctly within their specifications. In everyday language, the term “calibration” is widely used instead of “adjustment” for measuring devices.

17.6 Non-uniformity correction

When the thermal camera displays ”Calibrating…” it is adjusting for the deviation in re­sponse of each individual detector element (pixel). In thermography, this is called a ”non­uniformity correction” (NUC). It is an offset update, and the gain remains unchanged.
The European standard EN 16714-3, Non-destructive Testing—Thermographic Testing— Part 3: Terms and Definitions, defines an NUC as “Image correction carried out by the camera software to compensate for different sensitivities of detector elements and other optical and geometrical disturbances.”
During the NUC (the offset update), a shutter (internal flag) is placed in the optical path, and all the detector elements are exposed to the same amount of radiation originating from the shutter. Therefore, in an ideal situation, they should all give the same output sig­nal. However, each individual element has its own response, so the output is not uniform. This deviation from the ideal result is calculated and used to mathematically perform an image correction, which is essentially a correction of the displayed radiation signal. Some cameras do not have an internal flag. In this case, the offset update must be performed manually using special software and an external uniform source of radiation.
An NUC is performed, for example, at start-up, when changing a measurement range, or when the environment temperature changes. Some cameras also allow the user to trigger it manually. This is useful when you have to perform a critical measurement with as little image disturbance as possible.
17.7 Thermal image adjustment (thermal
tuning)
Some people use the term “image calibration” when adjusting the thermal contrast and brightness in the image to enhance specific details. During this operation, the temperature interval is set in such a way that all available colors are used to show only (or mainly) the temperatures in the region of interest. The correct term for this manipulation is “thermal im­age adjustment” or “thermal tuning”, or, in some languages, “thermal image optimization.” You must be in manual mode to undertake this, otherwise the camera will set the lower and upper limits of the displayed temperature interval automatically to the coldest and hot­test temperatures in the scene.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
57
18

History of infrared technology

Before the year 1800, the existence of the infrared portion of the electromagnetic spectrum wasn't even suspected. The original significance of the infrared spectrum, or simply ‘the in­frared’ as it is often called, as a form of heat radiation is perhaps less obvious today than it was at the time of its discovery by Herschel in 1800.
Figure 18.1 Sir William Herschel (1738–1822)
The discovery was made accidentally during the search for a new optical material. Sir Wil­liam Herschel – Royal Astronomer to King George III of England, and already famous for his discovery of the planet Uranus – was searching for an optical filter material to reduce the brightness of the sun’s image in telescopes during solar observations. While testing different samples of colored glass which gave similar reductions in brightness he was in­trigued to find that some of the samples passed very little of the sun’s heat, while others passed so much heat that he risked eye damage after only a few seconds’ observation.
Herschel was soon convinced of the necessity of setting up a systematic experiment, with the objective of finding a single material that would give the desired reduction in brightness as well as the maximum reduction in heat. He began the experiment by actually repeating Newton’s prism experiment, but looking for the heating effect rather than the visual distri­bution of intensity in the spectrum. He first blackened the bulb of a sensitive mercury-in­glass thermometer with ink, and with this as his radiation detector he proceeded to test the heating effect of the various colors of the spectrum formed on the top of a table by passing sunlight through a glass prism. Other thermometers, placed outside the sun’s rays, served as controls.
As the blackened thermometer was moved slowly along the colors of the spectrum, the temperature readings showed a steady increase from the violet end to the red end. This was not entirely unexpected, since the Italian researcher, Landriani, in a similar experiment in 1777 had observed much the same effect. It was Herschel, however, who was the first to recognize that there must be a point where the heating effect reaches a maximum, and that measurements confined to the visible portion of the spectrum failed to locate this point.
Figure 18.2 Marsilio Landriani (1746–1815)
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
58
18
History of infrared technology
Moving the thermometer into the dark region beyond the red end of the spectrum, Her­schel confirmed that the heating continued to increase. The maximum point, when he found it, lay well beyond the red end – in what is known today as the ‘infrared wavelengths’.
When Herschel revealed his discovery, he referred to this new portion of the electromag­netic spectrum as the ‘thermometrical spectrum’. The radiation itself he sometimes re­ferred to as ‘dark heat’, or simply ‘the invisible rays’. Ironically, and contrary to popular opinion, it wasn't Herschel who originated the term ‘infrared’. The word only began to ap­pear in print around 75 years later, and it is still unclear who should receive credit as the originator.
Herschel’s use of glass in the prism of his original experiment led to some early controver­sies with his contemporaries about the actual existence of the infrared wavelengths. Differ­ent investigators, in attempting to confirm his work, used various types of glass indiscriminately, having different transparencies in the infrared. Through his later experi­ments, Herschel was aware of the limited transparency of glass to the newly-discovered thermal radiation, and he was forced to conclude that optics for the infrared would prob­ably be doomed to the use of reflective elements exclusively (i.e. plane and curved mir­rors). Fortunately, this proved to be true only until 1830, when the Italian investigator, Melloni, made his great discovery that naturally occurring rock salt (NaCl) – which was available in large enough natural crystals to be made into lenses and prisms – is remark­ably transparent to the infrared. The result was that rock salt became the principal infrared optical material, and remained so for the next hundred years, until the art of synthetic crys­tal growing was mastered in the 1930’s.
Figure 18.3 Macedonio Melloni (1798–1854)
Thermometers, as radiation detectors, remained unchallenged until 1829, the year Nobili invented the thermocouple. (Herschel’s own thermometer could be read to 0.2 °C (0.036 ° F), and later models were able to be read to 0.05 °C (0.09 °F)). Then a breakthrough oc­curred; Melloni connected a number of thermocouples in series to form the first thermopile. The new device was at least 40 times as sensitive as the best thermometer of the day for detecting heat radiation – capable of detecting the heat from a person standing three me­ters away.
The first so-called ‘heat-picture’ became possible in 1840, the result of work by Sir John Herschel, son of the discoverer of the infrared and a famous astronomer in his own right. Based upon the differential evaporation of a thin film of oil when exposed to a heat pattern focused upon it, the thermal image could be seen by reflected light where the interference effects of the oil film made the image visible to the eye. Sir John also managed to obtain a primitive record of the thermal image on paper, which he called a ‘thermograph’.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
59
18
History of infrared technology
Figure 18.4 Samuel P. Langley (1834–1906)
The improvement of infrared-detector sensitivity progressed slowly. Another major break­through, made by Langley in 1880, was the invention of the bolometer. This consisted of a thin blackened strip of platinum connected in one arm of a Wheatstone bridge circuit upon which the infrared radiation was focused and to which a sensitive galvanometer re­sponded. This instrument is said to have been able to detect the heat from a cow at a dis­tance of 400 meters.
An English scientist, Sir James Dewar, first introduced the use of liquefied gases as cool­ing agents (such as liquid nitrogen with a temperature of –196°C (–320.8°F)) in low tem­perature research. In 1892 he invented a unique vacuum insulating container in which it is possible to store liquefied gases for entire days. The common ‘thermos bottle’, used for storing hot and cold drinks, is based upon his invention.
Between the years 1900 and 1920, the inventors of the world ‘discovered’ the infrared. Many patents were issued for devices to detect personnel, artillery, aircraft, ships – and even icebergs. The first operating systems, in the modern sense, began to be developed during the 1914–18 war, when both sides had research programs devoted to the military exploitation of the infrared. These programs included experimental systems for enemy in­trusion/detection, remote temperature sensing, secure communications, and ‘flying torpe­do’ guidance. An infrared search system tested during this period was able to detect an approaching airplane at a distance of 1.5 km (0.94 miles), or a person more than 300 me­ters (984 ft.) away.
The most sensitive systems up to this time were all based upon variations of the bolometer idea, but the period between the two wars saw the development of two revolutionary new infrared detectors: the image converter and the photon detector. At first, the image con­verter received the greatest attention by the military, because it enabled an observer for the first time in history to literally ‘see in the dark’. However, the sensitivity of the image converter was limited to the near infrared wavelengths, and the most interesting military targets (i.e. enemy soldiers) had to be illuminated by infrared search beams. Since this in­volved the risk of giving away the observer’s position to a similarly-equipped enemy ob­server, it is understandable that military interest in the image converter eventually faded.
The tactical military disadvantages of so-called 'active’ (i.e. search beam-equipped) ther­mal imaging systems provided impetus following the 1939–45 war for extensive secret military infrared-research programs into the possibilities of developing ‘passive’ (no search beam) systems around the extremely sensitive photon detector. During this period, military secrecy regulations completely prevented disclosure of the status of infrared-imaging technology. This secrecy only began to be lifted in the middle of the 1950’s, and from that time adequate thermal-imaging devices finally began to be available to civilian science and industry.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
60
19

Theory of thermography

19.1 Introduction

The subjects of infrared radiation and the related technique of thermography are still new to many who will use an infrared camera. In this section the theory behind thermography will be given.

19.2 The electromagnetic spectrum

The electromagnetic spectrum is divided arbitrarily into a number of wavelength regions, called bands, distinguished by the methods used to produce and detect the radiation. There is no fundamental difference between radiation in the different bands of the electro­magnetic spectrum. They are all governed by the same laws and the only differences are those due to differences in wavelength.
Figure 19.1 The electromagnetic spectrum. 1: X-ray; 2: UV; 3: Visible; 4: IR; 5: Microwaves; 6: Radiowaves.
Thermography makes use of the infrared spectral band. At the short-wavelength end the boundary lies at the limit of visual perception, in the deep red. At the long-wavelength end it merges with the microwave radio wavelengths, in the millimeter range.
The infrared band is often further subdivided into four smaller bands, the boundaries of which are also arbitrarily chosen. They include: the near infrared (0.75–3 μm), the middle infrared (3–6 μm), the far infrared (6–15 μm) and the extreme infrared (15–100 μm). Although the wavelengths are given in μm (micrometers), other units are often still used to measure wavelength in this spectral region, e.g. nanometer (nm) and Ångström (Å).
The relationships between the different wavelength measurements is:
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
61
19
Theory of thermography

19.3 Blackbody radiation

A blackbody is defined as an object which absorbs all radiation that impinges on it at any wavelength. The apparent misnomer black relating to an object emitting radiation is ex­plained by Kirchhoff’s Law (after Gustav Robert Kirchhoff, 1824–1887), which states that a body capable of absorbing all radiation at any wavelength is equally capable in the emis­sion of radiation.
Figure 19.2 Gustav Robert Kirchhoff (1824–1887)
The construction of a blackbody source is, in principle, very simple. The radiation charac­teristics of an aperture in an isotherm cavity made of an opaque absorbing material repre­sents almost exactly the properties of a blackbody. A practical application of the principle to the construction of a perfect absorber of radiation consists of a box that is light tight ex­cept for an aperture in one of the sides. Any radiation which then enters the hole is scat­tered and absorbed by repeated reflections so only an infinitesimal fraction can possibly escape. The blackness which is obtained at the aperture is nearly equal to a blackbody and almost perfect for all wavelengths.
By providing such an isothermal cavity with a suitable heater it becomes what is termed a cavity radiator. An isothermal cavity heated to a uniform temperature generates blackbody radiation, the characteristics of which are determined solely by the temperature of the cav­ity. Such cavity radiators are commonly used as sources of radiation in temperature refer­ence standards in the laboratory for calibrating thermographic instruments, such as a FLIR Systems camera for example.
If the temperature of blackbody radiation increases to more than 525°C (977°F), the source begins to be visible so that it appears to the eye no longer black. This is the incipi­ent red heat temperature of the radiator, which then becomes orange or yellow as the tem­perature increases further. In fact, the definition of the so-called color temperature of an object is the temperature to which a blackbody would have to be heated to have the same appearance.
Now consider three expressions that describe the radiation emitted from a blackbody.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
62
19
Theory of thermography

19.3.1 Planck’s law

Figure 19.3 Max Planck (1858–1947)
Max Planck (1858–1947) was able to describe the spectral distribution of the radiation from a blackbody by means of the following formula:
where:
W
λb
c
h Planck’s constant = 6.6 × 10 k Boltzmann’s constant = 1.4 × 10 T Absolute temperature (K) of a blackbody.
λ Wavelength (μm).
Blackbody spectral radiant emittance at wavelength λ.
Velocity of light = 3 × 10
8
m/s
-34
Joule sec.
-23
Joule/K.
Note The factor 10-6is used since spectral emittance in the curves is expressed in Watt/
2
m
, μm.
Planck’s formula, when plotted graphically for various temperatures, produces a family of curves. Following any particular Planck curve, the spectral emittance is zero at λ = 0, then increases rapidly to a maximum at a wavelength λ
and after passing it approaches zero
max
again at very long wavelengths. The higher the temperature, the shorter the wavelength at which maximum occurs.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
63
19
Theory of thermography
Figure 19.4 Blackbody spectral radiant emittance according to Planck’s law, plotted for various absolute
temperatures. 1: Spectral radiant emittance (W/cm
2
× 103(μm)); 2: Wavelength (μm)

19.3.2 Wien’s displacement law

By differentiating Planck’s formula with respect to λ, and finding the maximum, we have:
This is Wien’s formula (after Wilhelm Wien, 1864–1928), which expresses mathematically the common observation that colors vary from red to orange or yellow as the temperature of a thermal radiator increases. The wavelength of the color is the same as the wavelength calculated for λ
. A good approximation of the value of λ
max
for a given blackbody tem-
max
perature is obtained by applying the rule-of-thumb 3 000/T μm. Thus, a very hot star such as Sirius (11 000 K), emitting bluish-white light, radiates with the peak of spectral radiant emittance occurring within the invisible ultraviolet spectrum, at wavelength 0.27 μm.
Figure 19.5 Wilhelm Wien (1864–1928)
The sun (approx. 6 000 K) emits yellow light, peaking at about 0.5 μm in the middle of the visible light spectrum.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
64
19
Theory of thermography
At room temperature (300 K) the peak of radiant emittance lies at 9.7 μm, in the far infra­red, while at the temperature of liquid nitrogen (77 K) the maximum of the almost insignifi­cant amount of radiant emittance occurs at 38 μm, in the extreme infrared wavelengths.
Figure 19.6 Planckian curves plotted on semi-log scales from 100 K to 1000 K. The dotted line represents the locus of maximum radiant emittance at each temperature as described by Wien's displacement law. 1: Spectral radiant emittance (W/cm
2
(μm)); 2: Wavelength (μm).

19.3.3 Stefan-Boltzmann's law

By integrating Planck’s formula from λ = 0 to λ = ∞, we obtain the total radiant emittance (W
) of a blackbody:
b
This is the Stefan-Boltzmann formula (after Josef Stefan, 1835–1893, and Ludwig Boltz- mann, 1844–1906), which states that the total emissive power of a blackbody is propor­tional to the fourth power of its absolute temperature. Graphically, W
represents the area
b
below the Planck curve for a particular temperature. It can be shown that the radiant emit­tance in the interval λ = 0 to λ
is only 25% of the total, which represents about the
max
amount of the sun’s radiation which lies inside the visible light spectrum.
Figure 19.7 Josef Stefan (1835–1893), and Ludwig Boltzmann (1844–1906)
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
65
19
Theory of thermography
Using the Stefan-Boltzmann formula to calculate the power radiated by the human body, at a temperature of 300 K and an external surface area of approx. 2 m
2
, we obtain 1 kW. This power loss could not be sustained if it were not for the compensating absorption of ra­diation from surrounding surfaces, at room temperatures which do not vary too drastically from the temperature of the body – or, of course, the addition of clothing.

19.3.4 Non-blackbody emitters

So far, only blackbody radiators and blackbody radiation have been discussed. However, real objects almost never comply with these laws over an extended wavelength region – although they may approach the blackbody behavior in certain spectral intervals. For ex­ample, a certain type of white paint may appear perfectly white in the visible light spec­trum, but becomes distinctly gray at about 2 μm, and beyond 3 μm it is almost black.
There are three processes which can occur that prevent a real object from acting like a blackbody: a fraction of the incident radiation α may be absorbed, a fraction ρ may be re­flected, and a fraction τ may be transmitted. Since all of these factors are more or less wavelength dependent, the subscript λ is used to imply the spectral dependence of their definitions. Thus:
• The spectral absorptance α
= the ratio of the spectral radiant power absorbed by an ob-
λ
ject to that incident upon it.
• The spectral reflectance ρ
= the ratio of the spectral radiant power reflected by an ob-
λ
ject to that incident upon it.
• The spectral transmittance τ
= the ratio of the spectral radiant power transmitted
λ
through an object to that incident upon it.
The sum of these three factors must always add up to the whole at any wavelength, so we have the relation:
For opaque materials τλ= 0 and the relation simplifies to:
Another factor, called the emissivity, is required to describe the fraction ε of the radiant emittance of a blackbody produced by an object at a specific temperature. Thus, we have the definition:
The spectral emissivity ε
= the ratio of the spectral radiant power from an object to that
λ
from a blackbody at the same temperature and wavelength. Expressed mathematically, this can be written as the ratio of the spectral emittance of the
object to that of a blackbody as follows:
Generally speaking, there are three types of radiation source, distinguished by the ways in which the spectral emittance of each varies with wavelength.
• A blackbody, for which ε
• A graybody, for which ε
= ε = 1
λ
= ε = constant less than 1
λ
• A selective radiator, for which ε varies with wavelength According to Kirchhoff’s law, for any material the spectral emissivity and spectral absorp-
tance of a body are equal at any specified temperature and wavelength. That is:
From this we obtain, for an opaque material (since αλ+ ρλ= 1):
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
66
19
Theory of thermography
For highly polished materials ελapproaches zero, so that for a perfectly reflecting material (i.e. a perfect mirror) we have:
For a graybody radiator, the Stefan-Boltzmann formula becomes:
This states that the total emissive power of a graybody is the same as a blackbody at the same temperature reduced in proportion to the value of ε from the graybody.
Figure 19.8 Spectral radiant emittance of three types of radiators. 1: Spectral radiant emittance; 2: Wave­length; 3: Blackbody; 4: Selective radiator; 5: Graybody.
Figure 19.9 Spectral emissivity of three types of radiators. 1: Spectral emissivity; 2: Wavelength; 3: Black­body; 4: Graybody; 5: Selective radiator.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
67
19
Theory of thermography

19.4 Infrared semi-transparent materials

Consider now a non-metallic, semi-transparent body – let us say, in the form of a thick flat plate of plastic material. When the plate is heated, radiation generated within its volume must work its way toward the surfaces through the material in which it is partially absorbed. Moreover, when it arrives at the surface, some of it is reflected back into the interior. The back-reflected radiation is again partially absorbed, but some of it arrives at the other sur­face, through which most of it escapes; part of it is reflected back again. Although the pro­gressive reflections become weaker and weaker they must all be added up when the total emittance of the plate is sought. When the resulting geometrical series is summed, the ef­fective emissivity of a semi-transparent plate is obtained as:
When the plate becomes opaque this formula is reduced to the single formula:
This last relation is a particularly convenient one, because it is often easier to measure re­flectance than to measure emissivity directly.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
68
20

The measurement formula

As already mentioned, when viewing an object, the camera receives radiation not only from the object itself. It also collects radiation from the surroundings reflected via the ob­ject surface. Both these radiation contributions become attenuated to some extent by the atmosphere in the measurement path. To this comes a third radiation contribution from the atmosphere itself.
This description of the measurement situation, as illustrated in the figure below, is so far a fairly true description of the real conditions. What has been neglected could for instance be sun light scattering in the atmosphere or stray radiation from intense radiation sources outside the field of view. Such disturbances are difficult to quantify, however, in most cases they are fortunately small enough to be neglected. In case they are not negligible, the measurement configuration is likely to be such that the risk for disturbance is obvious, at least to a trained operator. It is then his responsibility to modify the measurement situation to avoid the disturbance e.g. by changing the viewing direction, shielding off intense radia­tion sources etc.
Accepting the description above, we can use the figure below to derive a formula for the calculation of the object temperature from the calibrated camera output.
Figure 20.1 A schematic representation of the general thermographic measurement situation.1: Surround­ings; 2: Object; 3: Atmosphere; 4: Camera
Assume that the received radiation power W from a blackbody source of temperature T
on short distance generates a camera output signal U
source
the power input (power linear camera). We can then write (Equation 1):
or, with simplified notation:
where C is a constant. Should the source be a graybody with emittance ε, the received radiation would conse-
quently be εW We are now ready to write the three collected radiation power terms:
1. Emission from the object = ετW
transmittance of the atmosphere. The object temperature is T
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
source
.
, where ε is the emittance of the object and τ is the
obj
that is proportional to
source
.
obj
69
20
The measurement formula
2. Reflected emission from ambient sources = (1 – ε)τW
tance of the object. The ambient sources have the temperature T It has here been assumed that the temperature T
, where (1 – ε) is the reflec-
refl
.
refl
is the same for all emitting surfaces
refl
within the halfsphere seen from a point on the object surface. This is of course some­times a simplification of the true situation. It is, however, a necessary simplification in order to derive a workable formula, and T
can – at least theoretically – be given a val-
refl
ue that represents an efficient temperature of a complex surrounding. Note also that we have assumed that the emittance for the surroundings = 1. This is
correct in accordance with Kirchhoff’s law: All radiation impinging on the surrounding surfaces will eventually be absorbed by the same surfaces. Thus the emittance = 1. (Note though that the latest discussion requires the complete sphere around the object to be considered.)
3. Emission from the atmosphere = (1 – τ)τW
mosphere. The temperature of the atmosphere is T
, where (1 – τ) is the emittance of the at-
atm
atm
.
The total received radiation power can now be written (Equation 2):
We multiply each term by the constant C of Equation 1 and replace the CW products by the corresponding U according to the same equation, and get (Equation 3):
Solve Equation 3 for U
(Equation 4):
obj
This is the general measurement formula used in all the FLIR Systems thermographic equipment. The voltages of the formula are:
Table 20.1 Voltages
U
obj
U
tot
U
refl
U
atm
Calculated camera output voltage for a blackbody of temperature T i.e. a voltage that can be directly converted into true requested object temperature.
Measured camera output voltage for the actual case.
Theoretical camera output voltage for a blackbody of temperature T
according to the calibration.
refl
Theoretical camera output voltage for a blackbody of temperature
according to the calibration.
T
atm
obj
The operator has to supply a number of parameter values for the calculation:
• the object emittance ε,
• the relative humidity,
• T
atm
• object distance (D
obj
)
• the (effective) temperature of the object surroundings, or the reflected ambient temper-
ature T
• the temperature of the atmosphere T
refl
, and
atm
This task could sometimes be a heavy burden for the operator since there are normally no easy ways to find accurate values of emittance and atmospheric transmittance for the
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
70
20
The measurement formula
actual case. The two temperatures are normally less of a problem provided the surround­ings do not contain large and intense radiation sources.
A natural question in this connection is: How important is it to know the right values of these parameters? It could though be of interest to get a feeling for this problem already here by looking into some different measurement cases and compare the relative magni­tudes of the three radiation terms. This will give indications about when it is important to use correct values of which parameters.
The figures below illustrates the relative magnitudes of the three radiation contributions for three different object temperatures, two emittances, and two spectral ranges: SW and LW. Remaining parameters have the following fixed values:
• τ = 0.88
• T
= +20°C (+68°F)
refl
• T
= +20°C (+68°F)
atm
It is obvious that measurement of low object temperatures are more critical than measur­ing high temperatures since the ‘disturbing’ radiation sources are relatively much stronger in the first case. Should also the object emittance be low, the situation would be still more difficult.
We have finally to answer a question about the importance of being allowed to use the cal­ibration curve above the highest calibration point, what we call extrapolation. Imagine that we in a certain case measure U
= 4.5 volts. The highest calibration point for the camera
tot
was in the order of 4.1 volts, a value unknown to the operator. Thus, even if the object hap­pened to be a blackbody, i.e. U
obj
= U
, we are actually performing extrapolation of the
tot
calibration curve when converting 4.5 volts into temperature. Let us now assume that the object is not black, it has an emittance of 0.75, and the trans-
mittance is 0.92. We also assume that the two second terms of Equation 4 amount to 0.5 volts together. Computation of U
by means of Equation 4 then results in U
obj
= 4.5 / 0.75
obj
/ 0.92 – 0.5 = 6.0. This is a rather extreme extrapolation, particularly when considering that the video amplifier might limit the output to 5 volts! Note, though, that the application of the calibration curve is a theoretical procedure where no electronic or other limitations exist. We trust that if there had been no signal limitations in the camera, and if it had been cali­brated far beyond 5 volts, the resulting curve would have been very much the same as our real curve extrapolated beyond 4.1 volts, provided the calibration algorithm is based on ra­diation physics, like the FLIR Systems algorithm. Of course there must be a limit to such extrapolations.
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
71
20
The measurement formula
Figure 20.2 Relative magnitudes of radiation sources under varying measurement conditions (SW camera).
1: Object temperature; 2: Emittance; Obj: Object radiation; Refl: Reflected radiation; Atm: atmosphere radia­tion. Fixed parameters: τ = 0.88; T
Figure 20.3 Relative magnitudes of radiation sources under varying measurement conditions (LW camera). 1: Object temperature; 2: Emittance; Obj: Object radiation; Refl: Reflected radiation; Atm: atmosphere radia­tion. Fixed parameters: τ = 0.88; T
= 20°C (+68°F); T
refl
= 20°C (+68°F); T
refl
= 20°C (+68°F).
atm
= 20°C (+68°F).
atm
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
72
21

Emissivity tables

This section presents a compilation of emissivity data from the infrared literature and measurements made by FLIR Systems.

21.1 References

1. Mikaél A. Bramson: Infrared Radiation, A Handbook for Applications, Plenum press, N.
Y.
2. William L. Wolfe, George J. Zissis: The Infrared Handbook, Office of Naval Research,
Department of Navy, Washington, D.C.
3. Madding, R. P.: Thermographic Instruments and systems. Madison, Wisconsin: Univer-
sity of Wisconsin – Extension, Department of Engineering and Applied Science.
4. William L. Wolfe: Handbook of Military Infrared Technology, Office of Naval Research,
Department of Navy, Washington, D.C.
5. Jones, Smith, Probert: External thermography of buildings..., Proc. of the Society of
Photo-Optical Instrumentation Engineers, vol.110, Industrial and Civil Applications of Infrared Technology, June 1977 London.
6. Paljak, Pettersson: Thermography of Buildings, Swedish Building Research Institute,
Stockholm 1972.
7. Vlcek, J: Determination of emissivity with imaging radiometers and some emissivities
at λ = 5 µm. Photogrammetric Engineering and Remote Sensing.
8. Kern: Evaluation of infrared emission of clouds and ground as measured by weather
satellites, Defence Documentation Center, AD 617 417.
9. Öhman, Claes: Emittansmätningar med AGEMA E-Box. Teknisk rapport, AGEMA
1999. (Emittance measurements using AGEMA E-Box. Technical report, AGEMA
1999.)
10. Matteï, S., Tang-Kwor, E: Emissivity measurements for Nextel Velvet coating 811-21
between –36°C AND 82°C.
11. Lohrengel & Todtenhaupt (1996)
12. ITC Technical publication 32.
13. ITC Technical publication 29.
14. Schuster, Norbert and Kolobrodov, Valentin G. Infrarotthermographie. Berlin: Wiley-
VCH, 2000.
Note The emissivity values in the table below are recorded using a shortwave (SW) cam­era. The values should be regarded as recommendations only and used with caution.

21.2 Tables

Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference
1 2 3 4 5 6
3M type 35 Vinyl electrical
3M type 88 Black vinyl electri-
3M type 88 Black vinyl electri-
3M type Super 33 +
Aluminum anodized sheet 100 T 0.55 2
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
tape (several colors)
cal tape
cal tape
Black vinyl electri­cal tape
< 80 LW ≈ 0.96 13
< 105 LW ≈ 0.96 13
< 105 MW < 0.96 13
< 80 LW ≈ 0.96 13
73
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Aluminum anodized, black,
Aluminum anodized, black,
Aluminum anodized, light
Aluminum anodized, light
Aluminum as received, plate 100 T 0.09 4
Aluminum as received, sheet 100 T 0.09 2
Aluminum cast, blast
Aluminum cast, blast
Aluminum dipped in HNO
Aluminum foil
Aluminum foil
Aluminum oxidized, strongly 50–500 T 0.2–0.3 1
Aluminum polished 50–100 T 0.04–0.06 1
Aluminum polished plate 100 T 0.05 4
Aluminum polished, sheet 100 T 0.05 2
Aluminum rough surface
Aluminum roughened 27 10 µm 0.18 3
Aluminum roughened 27 3 µm 0.28 3
Aluminum sheet, 4 samples
Aluminum sheet, 4 samples
Aluminum vacuum deposited 20 T 0.04 2
Aluminum weathered,
Aluminum bronze 20 T 0.60 1 Aluminum
hydroxide
Aluminum oxide activated, powder T 0.46 1
Aluminum oxide pure, powder
Asbestos board 20 T 0.96 1 Asbestos fabric T 0.78 1 Asbestos floor tile Asbestos
dull
dull
gray, dull
gray, dull
cleaned
cleaned
plate
differently scratched
differently scratched
heavily
powder T 0.28 1
(alumina)
paper 40–400 T 0.93–0.95 1
70
70 LW 0.95 9
70
70 LW 0.97 9
70
70 LW 0.46 9
100 T 0.05 4
,
3
27 10 µm 0.04 3
27 3 µm 0.09 3
20–50 T 0.06–0.07 1
70
70 LW 0.03–0.06 9
17
35
SW
SW
SW
SW
SW
T 0.16 1
SW
0.67 9
0.61 9
0.47 9
0.05–0.08 9
0.83–0.94 5
0.94 7
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
74
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Asbestos powder T 0.40–0.60 1
Asbestos slate 20 T 0.96 1 Asphalt paving 4 LLW 0.967 8
Brass dull, tarnished 20–350 T 0.22 1
Brass oxidized 100 T 0.61 2 Brass oxidized 70 Brass oxidized 70 LW 0.03–0.07 9 Brass oxidized at 600°C Brass polished 200 T 0.03 1
Brass polished, highly 100 T 0.03 2
Brass rubbed with 80-
Brass sheet, rolled 20 T 0.06 1
Brass sheet, worked
Brick alumina 17 Brick Brick Dinas silica,
Brick Dinas silica,
Brick Dinas silica, un-
Brick firebrick Brick fireclay
Brick fireclay
Brick fireclay
Brick
Brick
Brick red, common 20 T 0.93 2
Brick red, rough 20 T 0.88–0.93 1
Brick refractory,
Brick refractory,
Brick refractory, strongly
Brick refractory, weakly
Brick
Brick sillimanite, 33%
grit emery
with emery
common 17
glazed, rough
refractory
glazed, rough
masonry 35
masonry, plastered
corundum
magnesite
radiating
radiating
silica, 95% SiO
SiO
, 64% Al2O
2
200–600 T 0.59–0.61 1
20 T 0.20 2
20 T 0.2 1
1100 T 0.85 1
1000 T 0.66 1
1000 T 0.80 1
17 1000 T 0.75 1
1200 T 0.59 1
20 T 0.85 1
20 T 0.94 1
1000 T 0.46 1
1000–1300 T 0.38 1
500–1000 T 0.8–0.9 1
500–1000 T 0.65–0.75 1
1230 T 0.66 1
2
1500 T 0.29 1
3
SW
SW SW
SW
SW
0.04–0.09 9
0.68 5
0.86–0.81 5
0.68 5
0.94 7
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
75
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Brick waterproof
Bronze phosphor bronze 70
Bronze phosphor bronze 70 LW 0.06 9
Bronze polished 50 T 0.1 1
Bronze porous, rough 50–150 T 0.55 1
Bronze powder T 0.76–0.80 1
Carbon Carbon
Carbon graphite powder T 0.97 1
Carbon graphite, filed
Carbon lampblack 20–400 T 0.95–0.97 1
Chipboard
Chromium
Chromium polished 500–1000 T 0.28–0.38 1
Clay fired
Cloth Concrete Concrete dry 36 SW
Concrete rough 17 SW
Concrete
Copper
Copper electrolytic, care-
Copper
Copper
Copper
Copper oxidized to
Copper
Copper
Copper
Copper
Copper
Copper polished,
Copper pure, carefully
Copper
candle soot 20 T 0.95 2 charcoal powder T 0.96 1
surface
untreated 20
polished 50 T 0.10 1
black 20 T 0.98 1
walkway
commercial, burnished
fully polished
electrolytic, polished
molten 1100–1300 T 0.13–0.15 1
oxidized 50 T 0.6–0.7 1
blackness oxidized, black 27 T 0.78 4
oxidized, heavily 20 T 0.78 2
polished 50–100 T 0.02 1
polished 100 T 0.03 2
polished, commercial
mechanical
prepared surface
scraped 27 T 0.07 4
17
20 T 0.98 2
70 T 0.91 1
20 T 0.92 2
5
20 T 0.07 1
80 T 0.018 1
–34 T 0.006 4
27 T 0.03 4
22 T 0.015 4
22 T 0.008 4
SW
SW
SW
LLW 0.974 8
T 0.88 1
0.87 5
0.08 9
0.90 6
0.95 7
0.97 5
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
76
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Copper dioxide
Copper oxide
Ebonite T 0.89 1 Emery
Enamel 20 T 0.9 1 Enamel lacquer 20 T 0.85–0.95 1
Fiber board hard, untreated 20
Fiber board masonite 70 Fiber board masonite 70 LW 0.88 9 Fiber board particle board 70
Fiber board particle board 70 LW 0.89 9
Fiber board porous, untreated 20
Glass pane (float glass)
Gold
Gold polished, carefully
Gold
Granite
Granite rough 21 LLW 0.879 8
Granite rough, 4 different
Granite rough, 4 different
Gypsum
Ice: See Water Iron and steel cold rolled 70 Iron and steel cold rolled 70 LW 0.09 9 Iron and steel covered with red
Iron and steel electrolytic 100 T 0.05 4
Iron and steel electrolytic 22 T 0.05 4
Iron and steel electrolytic 260 T 0.07 4
Iron and steel electrolytic, care-
Iron and steel freshly worked
Iron and steel ground sheet 950–1100 T 0.55–0.61 1
Iron and steel heavily rusted
Iron and steel hot rolled 130 T 0.60 1 Iron and steel hot rolled 20 T 0.77 1 Iron and steel oxidized 100 T 0.74 4
powder T 0.84 1
red, powder T 0.70 1
coarse 80 T 0.85 1
SW
SW
SW
SW
non-coated 20 LW 0.97 14
polished 130 T 0.018 1
200–600 T 0.02–0.03 1
polished, highly 100 T 0.02 2
polished 20 LLW 0.849 8
samples
70
70 LW 0.77–0.87 9
samples
20 T 0.8–0.9 1
20 T 0.61–0.85 1
rust
175–225 T 0.05–0.06 1
fully polished
20 T 0.24 1
with emery
20 T 0.69 2
sheet
SW
SW
0.85 6
0.75 9
0.77 9
0.85 6
0.95–0.97 9
0.20 9
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
77
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Iron and steel oxidized 100 T 0.74 1 Iron and steel oxidized 1227 T 0.89 4 Iron and steel oxidized 125–525 T 0.78–0.82 1 Iron and steel oxidized 200 T 0.79 2 Iron and steel oxidized 200–600 T 0.80 1 Iron and steel oxidized strongly 50 T 0.88 1
Iron and steel oxidized strongly 500 T 0.98 1
Iron and steel polished 100 T 0.07 2
Iron and steel polished 400–1000 T 0.14–0.38 1
Iron and steel polished sheet 750–1050 T 0.52–0.56 1
Iron and steel rolled sheet 50 T 0.56 1 Iron and steel rolled, freshly
Iron and steel rough, plane
Iron and steel rusted red, sheet 22 T 0.69 4
Iron and steel rusted, heavily 17
Iron and steel rusty, red 20 T 0.69 1
Iron and steel shiny oxide layer,
Iron and steel shiny, etched 150 T 0.16 1
Iron and steel wrought, carefully
Iron galvanized heavily oxidized 70
Iron galvanized heavily oxidized 70 LW 0.85 9
Iron galvanized sheet 92 T 0.07 4
Iron galvanized sheet, burnished 30 T 0.23 1
Iron galvanized sheet, oxidized 20 T 0.28 1
Iron tinned sheet 24 T 0.064 4 Iron, cast casting 50 T 0.81 1
Iron, cast ingots 1000 T 0.95 1
Iron, cast liquid 1300 T 0.28 1
Iron, cast machined 800–1000 T 0.60–0.70 1
Iron, cast oxidized 100 T 0.64 2
Iron, cast oxidized 260 T 0.66 4
Iron, cast oxidized 38 T 0.63 4
Iron, cast oxidized 538 T 0.76 4
Iron, cast
Iron, cast polished 200 T 0.21 1
Iron, cast polished 38 T 0.21 4
Iron, cast polished 40 T 0.21 2
surface
sheet,
polished
oxidized at 600°C
20 T 0.24 1
50 T 0.95–0.98 1
SW
20 T 0.82 1
40–250 T 0.28 1
SW
200–600 T 0.64–0.78 1
0.96 5
0.64 9
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
78
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Iron, cast unworked 900–1100 T 0.87–0.95 1
Krylon Ultra-flat black 1602
Krylon Ultra-flat black 1602
Lacquer 3 colors sprayed
Lacquer 3 colors sprayed
Lacquer Aluminum on
Lacquer bakelite 80 T 0.83 1
Lacquer black, dull 40–100 T 0.96–0.98 1
Lacquer black, matte 100 T 0.97 2
Lacquer black, shiny,
Lacquer heat–resistant 100 T 0.92 1
Lacquer white 100 T 0.92 2
Lacquer white 40–100 T 0.8–0.95 1
Lead Lead oxidized, gray 20 T 0.28 1
Lead oxidized, gray 22 T 0.28 4
Lead shiny 250 T 0.08 1
Lead unoxidized,
Lead red 100 T 0.93 4 Lead red, powder 100 T 0.93 1
Leather tanned T 0.75–0.80 1 Lime T 0.3–0.4 1 Magnesium 22 T 0.07 4
Magnesium 260 T 0.13 4
Magnesium 538 T 0.18 4
Magnesium polished 20 T 0.07 2
Magnesium powder
Molybdenum 1500–2200 T 0.19–0.26 1
Molybdenum 600–1000 T 0.08–0.13 1
Molybdenum filament
Mortar 17 Mortar dry 36
Nextel Velvet 811­21 Black
Flat black Room tempera-
Flat black Room tempera-
on Aluminum
on Aluminum
rough surface
sprayed on iron
oxidized at 200°C
polished
Flat black –60–150 LW > 0.97 10 and
ture up to 175
ture up to 175
70
70 LW 0.92–0.94 9
20 T 0.4 1
20 T 0.87 1
200 T 0.63 1
100 T 0.05 4
700–2500 T 0.1–0.3 1
LW ≈ 0.96 12
MW ≈ 0.97 12
SW
T 0.86 1
SW SW
0.50–0.53 9
0.87 5
0.94 7
11
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
79
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Nichrome rolled 700 T 0.25 1 Nichrome sandblasted 700 T 0.70 1 Nichrome wire, clean 50 T 0.65 1
Nichrome wire, clean 500–1000 T 0.71–0.79 1
Nichrome wire, oxidized 50–500 T 0.95–0.98 1
Nickel bright matte 122 T 0.041 4
Nickel commercially
Nickel commercially
Nickel electrolytic 22 T 0.04 4
Nickel electrolytic 260 T 0.07 4
Nickel electrolytic 38 T 0.06 4
Nickel electrolytic 538 T 0.10 4
Nickel electroplated on
Nickel electroplated on
Nickel electroplated on
Nickel electroplated,
Nickel oxidized 1227 T 0.85 4 Nickel oxidized 200 T 0.37 2 Nickel oxidized 227 T 0.37 4 Nickel oxidized at 600°C Nickel polished 122 T 0.045 4
Nickel wire 200–1000 T 0.1–0.2 1 Nickel oxide 1000–1250 T 0.75–0.86 1 Nickel oxide 500–650 T 0.52–0.59 1 Oil, lubricating 0.025 mm film
Oil, lubricating 0.050 mm film
Oil, lubricating 0.125 mm film
Oil, lubricating film on Ni base: Ni
Oil, lubricating
Paint 8 different colors
Paint 8 different colors
Paint Aluminum, various
Paint cadmium yellow T 0.28–0.33 1
pure, polished
pure, polished
iron, polished
iron, unpolished
iron, unpolished
polished
base only
thick coating 20 T 0.82 2
and qualities
and qualities
ages
100 T 0.045 1
200–400 T 0.07–0.09 1
22 T 0.045 4
20 T 0.11–0.40 1
22 T 0.11 4
20 T 0.05 2
200–600 T 0.37–0.48 1
20 T 0.27 2
20 T 0.46 2
20 T 0.72 2
20 T 0.05 2
70
70 LW 0.92–0.94 9
50–100 T 0.27–0.67 1
SW
0.88–0.96 9
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
80
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Paint chrome green T 0.65–0.70 1
Paint cobalt blue T 0.7–0.8 1 Paint oil 17 Paint oil based, average
Paint oil, black flat
Paint oil, black gloss 20
Paint oil, gray flat
Paint oil, gray gloss 20
Paint oil, various colors 100 T 0.92–0.96 1
Paint plastic, black 20
Paint plastic, white 20
Paper 4 different colors
Paper 4 different colors
Paper black T 0.90 1
Paper black, dull T 0.94 1
Paper black, dull 70
Paper black, dull 70 LW 0.89 9
Paper blue, dark T 0.84 1
Paper coated with black
Paper
Paper red T 0.76 1
Paper white 20 T 0.7–0.9 1
Paper white bond 20 T 0.93 2
Paper white, 3 different
Paper white, 3 different
Paper yellow T 0.72 1
Plaster 17 Plaster plasterboard,
Plaster rough coat 20 T 0.91 2
Plastic glass fibre lami-
Plastic glass fibre lami-
Plastic polyurethane iso-
of 16 colors
lacquer
green
glosses
glosses
untreated
nate (printed circ. board)
nate (printed circ. board)
lation board
100 T 0.94 2
20
20
70
70 LW 0.92–0.94 9
70
70 LW 0.88–0.90 9
20
70
70 LW 0.91 9
70 LW 0.55 9
SW
SW
SW
SW
SW
SW
SW
SW
SW
T 0.93 1
T 0.85 1
SW
SW SW
SW
0.87 5
0.94 6
0.92 6
0.97 6
0.96 6
0.95 6
0.84 6
0.68–0.74 9
0.86 9
0.76–0.78 9
0.86 5
0.90 6
0.94 9
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
81
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Plastic polyurethane iso-
Plastic PVC, plastic floor,
Plastic PVC, plastic floor,
Platinum 100 T 0.05 4 Platinum 1000–1500 T 0.14–0.18 1 Platinum 1094 T 0.18 4 Platinum 17 T 0.016 4 Platinum 22 T 0.03 4 Platinum 260 T 0.06 4 Platinum 538 T 0.10 4 Platinum pure, polished 200–600 T 0.05–0.10 1
Platinum ribbon 900–1100 T 0.12–0.17 1 Platinum wire 1400 T 0.18 1 Platinum wire 500–1000 T 0.10–0.16 1 Platinum wire 50–200 T 0.06–0.07 1 Porcelain glazed 20 T 0.92 1
Porcelain white, shiny T 0.70–0.75 1
Rubber hard 20 T 0.95 1 Rubber soft, gray, rough
Sand Sand Sandstone polished 19 LLW 0.909 8
Sandstone
Silver
Silver pure, polished 200–600 T 0.02–0.03 1
Skin Slag
Slag
Slag boiler 200–500 T 0.89–0.78 1
Slag boiler 600–1200 T 0.76–0.70 1
Snow: See Water Soil
Soil saturated with
Stainless steel
Stainless steel Stainless steel Stainless steel sheet, polished 70 SW
lation board
dull, structured
dull, structured
rough 19 LLW 0.935 8
polished 100 T 0.03 2
human 32 T 0.98 2 boiler 0–100 T 0.97–0.93 1
boiler 1400–1800 T 0.69–0.67 1
dry 20 T 0.92 2
water alloy, 8% Ni, 18%
Cr rolled 700 T 0.45 1 sandblasted 700 T 0.70 1
70
70
70 LW 0.93 9
20 T 0.95 1
20 T 0.90 2
20 T 0.95 2
500 T 0.35 1
SW
SW
T 0.60 1
0.29 9
0.94 9
0.18 9
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
82
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Stainless steel
Stainless steel sheet, untreated,
Stainless steel
Stainless steel type 18-8, buffed
Stainless steel type 18-8, oxi-
Stucco rough, lime 10–90 T 0.91 1
Styrofoam insulation 37 SW
Tar T 0.79–0.84 1 Tar
Tile glazed 17
Tin burnished 20–50 T 0.04–0.06 1 Tin tin–plated sheet
Titanium oxidized at 540°C Titanium Titanium oxidized at 540°C Titanium polished 1000 T 0.36 1
Titanium polished 200 T 0.15 1
Titanium polished 500 T 0.20 1
Tungsten 1500–2200 T 0.24–0.31 1
Tungsten 200 T 0.05 1
Tungsten 600–1000 T 0.1–0.16 1
Tungsten filament
Varnish flat Varnish on oak parquet
Varnish on oak parquet
Wallpaper slight pattern, light
Wallpaper slight pattern, red 20
Water distilled 20 T 0.96 2 Water frost crystals
Water ice, covered with
Water ice, smooth 0 T 0.97 1
Water ice, smooth –10 T 0.96 2
Water layer >0.1 mm
sheet, polished 70 LW 0.14 9
somewhat scratched
sheet, untreated, somewhat scratched
dized at 800°C
paper 20 T 0.91–0.93 1
iron
oxidized at 540°C
floor
floor
gray
heavy frost
thick
70
70 LW 0.28 9
20 T 0.16 2
60 T 0.85 2
100 T 0.07 2
1000 T 0.60 1 200 T 0.40 1 500 T 0.50 1
3300 T 0.39 1
20 70
70 LW 0.90–0.93 9
20
–10 T 0.98 2
0 T 0.98 1
0–100 T 0.95–0.98 1
SW
SW
SW SW
SW
SW
0.30 9
0.60 7
0.94 5
0.93 6
0.90 9
0.85 6
0.90 6
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
83
Emissivity tables21
Table 21.1 T: Total spectrum; SW: 2–5 µm; LW: 8–14 µm, LLW: 6.5–20 µm; 1: Material; 2: Specification; 3:
Temperature in °C; 4: Spectrum; 5: Emissivity: 6:Reference (continued)
1 2 3 4 5 6
Water Water Wood 17 Wood 19 LLW 0.962 8 Wood ground T 0.5–0.7 1
Wood pine, 4 different
Wood pine, 4 different
Wood planed 20 T 0.8–0.9 1
Wood planed oak 20 T 0.90 2
Wood planed oak 70
Wood planed oak 70 LW 0.88 9
Wood plywood, smooth,
Wood plywood,
Wood white, damp 20 T 0.7–0.8 1
Zinc oxidized at 400°C Zinc oxidized surface Zinc polished 200–300 T 0.04–0.05 1
Zinc sheet 50 T 0.20 1
snow snow –10 T 0.85 2
70
samples
70 LW 0.81–0.89 9
samples
36
dry
20
untreated
400 T 0.11 1 1000–1200 T 0.50–0.60 1
T 0.8 1
SW
SW
SW
SW
SW
0.98 5
0.67–0.75 9
0.77 9
0.82 7
0.83 6
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
84
A note on the technical production of this publication
This publication was produced using XML — the eXtensible Markup Language. For more information about XML, please visit http://www.w3.org/XML/
A note on the typeface used in this publication
This publication was typeset using Linotype Helvetica™ World. Helvetica™ was designed by Max Miedinger (1910–1980)
LOEF (List Of Effective Files)
T501250.xml; en-US; AA; 41997; 2017-04-10 T505552.xml; en-US; 9599; 2013-11-05 T505469.xml; en-US; 39689; 2017-01-25 T505013.xml; en-US; 39689; 2017-01-25 T506128.xml; en-US; 40817; 2017-03-02 T505470.xml; en-US; 39513; 2017-01-18 T505007.xml; en-US; 39512; 2017-01-18 T506125.xml; en-US; 40753; 2017-03-02 T505000.xml; en-US; 39687; 2017-01-25 T506155.xml; en-US; 41087; 2017-03-09 T506051.xml; en-US; 40460; 2017-02-20 T505005.xml; en-US; 41563; 2017-03-23 T505001.xml; en-US; 41563; 2017-03-23 T505006.xml; en-US; 41563; 2017-03-23 T505002.xml; en-US; 39512; 2017-01-18
#T810252; r. AA/41997/41997; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
86
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
