Thermal imaging camera
Bench Test Thermal Kits
IR Camera, Optics and Software for
- Entry Level R&D
- Industrial Labs
- Education
- PCB and Circuit-Board Analysis
Find Quality Products Online at: sales@GlobalTestSupply.com
Edition : April 2014
www.GlobalTestSupply.com
FLIR Bench Test Thermal Kit Camera
No one can afford costly product recalls and do-overs caused by inadequate
temperature measurement devices. So FLIR developed an innovative alternative that
you can’t afford to pass up.
Throw out the rat’s nest of thermocouples, the painstaking IR thermometer guns, and all the questionable results
that go with them. Know exactly where to measure, trust your findings every time, and become far more productive
with the FLIR Bench Test Thermal Kits.
Thermocouples are limited to a best guess of where the right measurement points might be and often create
undesirable heat sinks that alter a target’s thermal properties. A spot pyrometer isn’t ver y ef fective either. Like a
thermocouple, it only measures one point at a time. Worse, it merely senses the average temperature of an area,
and the farther away from the objec t, the greater the discrepancy.
But with the thermal imaging camera in a FLIR Bench Test Thermal Kit, you can detect thousands of measurement
point s in each thermal image and get reliable data in seconds. Together with the kit’s lens choices and advanced IR
analysis software for use in Industrial and R&D labs, FLIR now offers the most dependable thermal imaging solution
to help paint the complete picture and get it right the first time.
Features
Thermal images making the difference
Eliminate risky guesswork with instant
non-contact readings that deliver up to
327,680 repeatable, accurate temperature
measurements in each thermographic image.
Spot-on Detection
FLIR’s high accuracy of up to ±2% (or ±2°C) of
reading with down to <0.045°C sensitivity lets
you see the fine thermal variations necessary
for critical documentation.
Optics Options
View an entire printed circuit board from a
distance or tighten in to a 50 µm spot size with
additional close focus lens for example. (valid for
T420 model).
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Portable & Easy-to-Operate
Compact at less than 1 kg for E40 and
T420, and less than 300 gram for A35 and
A65 models, the camera takes up
little bench space and can be easily moved to
other test stations.
On-Camera Measurement Analysis
Spot and area measurement tools are built into
the touchscreen of both the T420 and E40
camera’s providing quick temperature analysis
on live thermal imagery or recorded snapshots.
Movie Recording & Data Logging
Stream to a PC via USB from an E40 or T420,
or over Gigabit Ethernet from an A35, A65 to
display, record, and fur ther analyse images.
Chart time vs. temperature for spot and area
measurements with the kit’s real-time IR
analysis software ResearchIR.
Complete value packs!
FLIR A65/35 Bench Test Thermal Kit Camera
• A65 or A35 thermal camera
• Manual focus 48° on A35 and 45º on A65
• ResearchIR: Real-time image/data logging and plot ting sof tware
• Camera tripod adapter for locked-down targeting
• PoE injector (Power over ethernet)
FULL PRODUCT
WARRANTY*
* After product registration on www.flir.com
DETECTOR
WARRANTY*
FLIR A35 Benc h Test Ther mal Ki t camer a: 63209- 0102
FLIR A65 Benc h Test Ther mal Ki t camer a: 62513-0102
FLIR E40 Bench Test Thermal Kit Camera
• E40 thermal camera
• 19,200 pixels/spots per image
• 25° and 45° lens in the package
• Measurements down to 200µm with 45° lens
• ResearchIR: Real-time image/data logging and plot ting sof tware
• Possible to attach to a tripod.
FULL PRODUCT
WARRANTY*
* After product registration on www.flir.com
FLIR E40 Ben ch Test The rmal
Kit c amera: 6 4501-0103
DETECTOR
WARRANTY*
FLIR T420 Bench Test Thermal Kit Camera
• T420 thermal camera
• 76,800 pixels/spots per image
• 25° and 45° lens in the package
• Remote and auto focus
• Optional close-up lenses for measurement
at 50μm and 100μm exist
• ResearchIR: Real-time image/data logging
and plotting software
• Possible to attach to a tripod
FULL PRODUCT
WARRANTY*
Find Quality Products Online at: sales@GlobalTestSupply.com
* After product registration on www.flir.com
DETECTOR
WARRANTY*
www.GlobalTestSupply.com
FLIR T420 Bench Test T herm al Kit C amera: 62103-1205
R&D - Science Software
Turning tools into solutions
At FLIR, we recognise that our job is to go beyond just producing the best possible
thermal imaging camera systems. We are committed to enabling all users of our
thermal imaging camera systems to work more efficiently and productively by providing them with the most professional camera-software combination.
FLIR ResearchIR
FLIR ResearchIR is aimed at R&D-Science users of thermal imaging cameras with a cooled or uncooled detector.
FLIR ResearchIR takes the most out of your thermal imaging camera and allows high speed recording and advanced
thermal pattern analysis.
FLIR ResearchIR key features:
• View, record and store images at high speed
• Post-processing of fast thermal events
• Generate time-temperature plots from live images
or recorded sequences
•
Advanced Start/Stop recording conditions
• Unlimited number of analysis functions
(Spot, Line, Area)
ResearchIR is the perfect tool for industrial R&D labs.
•
File organizer
• Zoom & Pan allows a closer look
• Multiple user-configurable tabs for live images, recorded
images or plot
Specifications A35 A65 E40 T420
Resolution 320 x 256 640 x 512 160 x 120 320 x 240
Sensitivity/NETD <0.05°C @ +30°C /50 mK <0.05°C @ +30°C /50 mK <0.07°C @ +30°C / 70 mK <0.0 45° C
Accuracy ±5°C or ±5% of reading ±5°C or ±5% of reading ±2°C or ±2% of reading ±2°C or ±2% of reading
Temperature Range -25°C t o +135°C
-40°C to +550°C
Built-In Digital Camera NA NA 3 .1 M p i x e l 3 .1 M p i x e l
On-Camera Analysis NA NA Cent er spot
Digital Data Streaming t o PC Gigabit Ethernet Gigabit Ethernet via USB via USB
ResearchIR Software Included Yes Yes Yes Yes
-25°C t o 135°C -20°C to 120°C
0°C to 650°C
Hot spot
Cold spot
3 spot s
Difference temperature
(two versions)
-20°C to 650°C
Cent er spot
Hot spot
Cold spot
3 spot s
Difference temperature
(two versions)
