User’s manual
FLIR T6xx series
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Important note
Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers.
Důležitá poznámka
Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se
jimi.
Vigtig meddelelse
Før du betjener enheden, skal du du læse, forstå og følge alle anvisninger, advarsler, sikkerhedsforanstaltninger og ansvarsfraskrivelser.
Wichtiger Hinweis
Bevor Sie das Gerät in Betrieb nehmen, lesen, verstehen und befolgen Sie unbedingt alle Anweisungen, Warnungen, Vorsichtshinweise
und Haftungsausschlüsse
Σημαντική σημείωση
Πριν από τη λειτουργία της συσκευής, πρέπει να διαβάσετε, να κατανοήσετε και να ακολουθήσετε όλες τις οδηγίες,
προειδοποιήσεις, προφυλάξεις και νομικές αποποιήσεις.
Nota importante
Antes de usar el dispositivo, debe leer, comprender y seguir toda la información sobre instrucciones, advertencias, precauciones y
renuncias de responsabilidad.
Tärkeä huomautus
Ennen laitteen käyttämistä on luettava ja ymmärrettävä kaikki ohjeet, vakavat varoitukset, varoitukset ja lakitiedotteet sekä noudatettava
niitä.
Remarque importante
Avant d'utiliser l'appareil, vous devez lire, comprendre et suivre l'ensemble des instructions, avertissements, mises en garde et clauses
légales de non-responsabilité.
Fontos megjegyzés
Az eszköz használata előtt figyelmesen olvassa el és tartsa be az összes utasítást, figyelmeztetést, óvintézkedést és jogi nyilatkozatot.
Nota importante
Prima di utilizzare il dispositivo, è importante leggere, capire e seguire tutte le istruzioni, avvertenze, precauzioni ed esclusioni di
responsabilità legali.
重要な注意
デバイスをご使用になる前に、あらゆる指示、警告、注意事項、および免責条項をお読み頂き、その内容を理解して従ってください。
중요한 참고 사항
장치를 작동하기 전에 반드시 다음의 사용 설명서와 경고, 주의사항, 법적 책임제한을 읽고 이해하며 따라야 합니다.
Viktig
Før du bruker enheten, må du lese, forstå og følge instruksjoner, advarsler og informasjon om ansvarsfraskrivelse.
Belangrijke opmerking
Zorg ervoor dat u, voordat u het apparaat gaat gebruiken, alle instructies, waarschuwingen en juridische informatie hebt doorgelezen en
begrepen, en dat u deze opvolgt en in acht neemt.
Ważna uwaga
Przed rozpoczęciem korzystania z urządzenia należy koniecznie zapoznać się z wszystkimi instrukcjami, ostrzeżeniami, przestrogami i
uwagami prawnymi. Należy zawsze postępować zgodnie z zaleceniami tam zawartymi.
Nota importante
Antes de utilizar o dispositivo, deverá proceder à leitura e compreensão de todos os avisos, precauções, instruções e isenções de
responsabilidade legal e assegurar-se do seu cumprimento.
Важное примечание
До того, как пользоваться устройством, вам необходимо прочитать и понять все предупреждения, предостережения и
юридические ограничения ответственности и следовать им.
Viktig information
Innan du använder enheten måste du läsa, förstå och följa alla anvisningar, varningar, försiktighetsåtgärder och ansvarsfriskrivningar.
Önemli not
Cihazı çalıştırmadan önce tüm talimatları, uyarıları, ikazları ve yasal açıklamaları okumalı, anlamalı ve bunlara uymalısınız.
重要注意事项
在操作设备之前，您必须阅读、理解并遵循所有说明、警告、注意事项和法律免责声明。
重要注意事項
操作裝置之前，您務必閱讀、了解並遵循所有說明、警告、注意事項與法律免責聲明。
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
User’s manual
FLIR T6xx series
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
v
Table of contents
1 Disclaimers ........................................................................................1
1.1 Legal disclaimer ......................................................................... 1
1.2 Usage statistics .......................................................................... 1
1.3 Changes to registry .....................................................................1
1.4 U.S. Government Regulations........................................................ 1
1.5 Copyright ..................................................................................1
1.6 Quality assurance .......................................................................1
1.7 Patents.....................................................................................1
1.8 EULA Terms ..............................................................................1
1.9 EULA Terms ..............................................................................2
2 Safety information ...............................................................................3
3 Notice to user .....................................................................................7
3.1 User-to-user forums ....................................................................7
3.2 Calibration................................................................................. 7
3.3 Accuracy .................................................................................. 7
3.4 Disposal of electronic waste ..........................................................7
3.5 Training ....................................................................................7
3.6 Documentation updates ............................................................... 8
3.7 Important note about this manual.................................................... 8
3.8 Note about authoritative versions.................................................... 8
4 Customer help ....................................................................................9
4.1 General ....................................................................................9
4.2 Submitting a question ..................................................................9
4.3 Downloads .............................................................................. 10
5 Quick start guide ............................................................................... 11
5.1 Procedure ............................................................................... 11
6 List of accessories and services ......................................................... 12
7 A note about ergonomics ................................................................... 14
7.1 General .................................................................................. 14
7.2 Figure .................................................................................... 14
8 Camera parts .................................................................................... 15
8.1 View from the right .................................................................... 15
8.1.1 Figure.......................................................................... 15
8.1.2 Explanation................................................................... 15
8.2 View from the left ...................................................................... 16
8.2.1 Figure.......................................................................... 16
8.2.2 Explanation................................................................... 16
8.3 View from the rear..................................................................... 17
8.3.1 Figure.......................................................................... 17
8.3.2 Explanation................................................................... 17
8.4 View from the bottom................................................................. 18
8.4.1 Figure.......................................................................... 18
8.4.2 Explanation................................................................... 18
8.5 Battery condition LED indicator .................................................... 19
8.5.1 Figure.......................................................................... 19
8.5.2 Explanation................................................................... 19
8.6 Power LED indicator.................................................................. 19
8.6.1 Figure.......................................................................... 19
8.6.2 Explanation................................................................... 19
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
vii
Table of contents
8.7 Laser pointer ........................................................................... 20
8.7.1 Figure.......................................................................... 20
8.7.2 Laser warning label......................................................... 20
8.7.3 Laser rules and regulations .............................................. 20
9 Screen elements ............................................................................... 21
9.1 Figure .................................................................................... 21
9.2 Explanation ............................................................................. 21
10 Navigating the menu system............................................................... 22
10.1 Figure .................................................................................... 22
10.2 Explanation ............................................................................. 22
11 Pairing Bluetooth devices................................................................... 23
11.1 General .................................................................................. 23
11.2 Procedure ............................................................................... 23
12 Configuring Wi-Fi .............................................................................. 24
12.1 General .................................................................................. 24
12.2 Setting up a peer-to-peer connection (most common use) ................. 24
12.3 Connecting the camera to a wireless local area network (less
13 Handling the camera .......................................................................... 26
13.1 Charging the battery.................................................................. 26
13.2 Turning on the camera ............................................................... 26
13.3 Turning off the camera ............................................................... 26
13.4 Adjusting the viewfinder’s dioptric correction ................................... 27
13.5 Adjusting the angle of the lens ..................................................... 28
13.6 Adjusting the infrared camera focus manually ................................. 28
13.7 Autofocusing the infrared camera ................................................. 29
13.8 Continuous autofocus ................................................................ 29
13.9 Operating the laser pointer.......................................................... 30
13.10 Using the digital zoom function .................................................... 31
13.11 Changing lenses....................................................................... 31
13.12 Calibrating the compass ............................................................. 33
common use) ........................................................................... 24
13.1.1 Using the power supply to charge the battery ....................... 26
13.1.2 Using the stand-alone battery charger to charge the
battery ......................................................................... 26
13.2.1 Procedure .................................................................... 26
13.3.1 Procedure .................................................................... 26
13.4.1 Figure.......................................................................... 27
13.4.2 Procedure .................................................................... 27
13.5.1 Figure.......................................................................... 28
13.6.1 Figure.......................................................................... 28
13.6.2 Procedure .................................................................... 28
13.7.1 Figure.......................................................................... 29
13.7.2 Procedure .................................................................... 29
13.8.1 General........................................................................ 29
13.8.2 Procedure .................................................................... 30
13.9.1 Figure.......................................................................... 30
13.9.2 Procedure .................................................................... 30
13.10.1 Figure.......................................................................... 31
13.10.2 Procedure .................................................................... 31
13.12.1 Procedure .................................................................... 33
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
viii
Table of contents
13.13 Changing the viewfinder eyecup................................................... 34
13.14 Using the camera lamp as a flash ................................................. 36
13.14.1 General........................................................................ 36
13.14.2 Procedure .................................................................... 36
14 Working with images.......................................................................... 37
14.1 Saving an image ....................................................................... 37
14.1.1 General........................................................................ 37
14.1.2 About UltraMax.............................................................. 37
14.1.3 Image capacity .............................................................. 37
14.1.4 Naming convention......................................................... 37
14.1.5 Procedure .................................................................... 37
14.2 Previewing an image ................................................................. 38
14.2.1 General........................................................................ 38
14.2.2 Procedure .................................................................... 38
14.3 Opening a saved image.............................................................. 38
14.3.1 General........................................................................ 38
14.3.2 Procedure .................................................................... 38
14.4 Editing a saved image................................................................ 38
14.4.1 General........................................................................ 38
14.4.2 Procedure .................................................................... 39
14.5 Adjusting an infrared image......................................................... 39
14.5.1 General........................................................................ 39
14.5.2 Example 1 .................................................................... 39
14.5.3 Example 2 .................................................................... 40
14.5.4 Procedure .................................................................... 40
14.6 Performing a non-uniformity correction (NUC) ................................. 41
14.6.1 What is a non-uniformity correction?................................... 41
14.6.2 When to perform a non-uniformity correction? ...................... 41
14.6.3 Procedure .................................................................... 41
14.7 Changing the temperature range .................................................. 41
14.7.1 General........................................................................ 41
14.7.2 Procedure .................................................................... 41
14.8 Hiding overlay graphics (programmable button) ............................... 41
14.8.1 General........................................................................ 41
14.8.2 Procedure .................................................................... 42
14.9 Changing the color palette .......................................................... 42
14.9.1 General........................................................................ 42
14.9.2 Procedure .................................................................... 42
14.10 Deleting an image ..................................................................... 42
14.10.1 General........................................................................ 42
14.10.2 Procedure .................................................................... 42
14.11 Deleting all images.................................................................... 43
14.11.1 General........................................................................ 43
14.11.2 Procedure .................................................................... 43
14.12 Creating a PDF report in the camera ............................................. 43
14.12.1 General........................................................................ 43
14.12.2 Naming convention......................................................... 43
14.12.3 Procedure .................................................................... 43
15 Working with image modes................................................................. 44
15.1 General .................................................................................. 44
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
ix
Table of contents
15.2 Image examples ....................................................................... 44
15.3 Selecting the image mode .......................................................... 45
16 Working with measurement tools ........................................................ 46
16.1 General .................................................................................. 46
16.2 Adding/removing measurement tools ............................................ 46
16.3 Working with user presets........................................................... 46
16.3.1 General........................................................................ 46
16.3.2 Procedure .................................................................... 46
16.4 Resizing or moving a measurement tool......................................... 47
16.4.1 General........................................................................ 47
16.4.2 Procedure .................................................................... 47
16.5 Changing object parameters ....................................................... 48
16.5.1 General........................................................................ 48
16.5.2 Types of parameters ....................................................... 48
16.5.3 Recommended values..................................................... 48
16.5.4 Procedure .................................................................... 49
16.5.5 Related topics ............................................................... 50
16.6 Displaying values in the result table and displaying a graph ................ 50
16.6.1 General........................................................................ 50
16.6.2 Procedure .................................................................... 50
16.7 Creating and setting up a difference calculation............................... 51
16.7.1 General........................................................................ 51
16.7.2 Procedure .................................................................... 51
16.8 Setting a measurement alarm ...................................................... 51
16.8.1 General........................................................................ 51
16.8.2 Types of alarm ............................................................... 52
16.8.3 Alarm signals ................................................................ 52
16.8.4 Procedure .................................................................... 52
17 Fetching data from external FLIR meters .............................................. 54
17.1 General .................................................................................. 54
17.2 Supported FLIR meters .............................................................. 54
17.3 Technical support for external meters ............................................ 54
17.4 Typical moisture measurement and documentation procedure ............ 54
17.4.1 General........................................................................ 54
17.4.2 Procedure .................................................................... 55
17.5 More information ...................................................................... 55
18 Working with color alarms and isotherms ............................................. 56
18.1 Color alarms ............................................................................ 56
18.1.1 General........................................................................ 56
18.1.2 Image examples ............................................................ 56
18.2 Setting up above, below, and interval alarms................................... 57
18.3 Building isotherms .................................................................... 58
18.3.1 About the Condensation alarm .......................................... 58
18.3.2 About the Insulation alarm ................................................ 58
18.3.3 Setting up condensation and insulation alarms ..................... 58
19 Annotating images ............................................................................ 59
19.1 General .................................................................................. 59
19.2 Adding a note .......................................................................... 59
19.2.1 General........................................................................ 59
19.2.2 Procedure .................................................................... 59
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
x
Table of contents
19.3 Adding a table .......................................................................... 60
19.3.1 General........................................................................ 60
19.3.2 Procedure .................................................................... 60
19.4 Adding a voice annotation........................................................... 60
19.4.1 General........................................................................ 60
19.4.2 Procedure .................................................................... 60
19.5 Adding a sketch........................................................................ 61
19.5.1 General........................................................................ 61
19.5.2 Procedure .................................................................... 61
20 Programming the camera (time lapse) ................................................. 62
20.1 General .................................................................................. 62
20.2 Procedure ............................................................................... 62
21 Recording video clips ........................................................................ 63
21.1 General .................................................................................. 63
21.2 Procedure ............................................................................... 63
22 Screening alarm ................................................................................ 64
22.1 General .................................................................................. 64
22.2 Procedure ............................................................................... 64
23 Changing settings ............................................................................. 65
23.1 General .................................................................................. 65
23.1.1 Define user presets ........................................................ 65
23.1.2 Save options ................................................................. 65
23.1.3 Programmable button...................................................... 65
23.1.4 Reset options ................................................................ 65
23.1.5 Device settings .............................................................. 65
23.2 Procedure ............................................................................... 66
24 Technical data................................................................................... 67
24.1 Online field-of-view calculator ...................................................... 68
24.2 Note about technical data ........................................................... 68
24.3 Note about authoritative versions.................................................. 68
24.4 FLIR T600 15° (incl. Wi-Fi and Ext. cal.) ......................................... 69
24.5 FLIR T600 15° (incl. Wi-Fi).......................................................... 75
24.6 FLIR T600 25° (incl. Wi-Fi and Ext. cal.) ......................................... 81
24.7 FLIR T600 25° (incl. Wi-Fi).......................................................... 87
24.8 FLIR T600 25° and 15° w/case..................................................... 93
24.9 FLIR T600 25° and 45° w/case..................................................... 99
24.10 FLIR T600 45° (incl. Wi-Fi and Ext. cal.) ....................................... 105
24.11 FLIR T600 45° (incl. Wi-Fi)........................................................ 111
24.12 FLIR T600bx 25° (incl. Wi-Fi and Ext. cal.).................................... 117
24.13 FLIR T600bx 25° (incl. Wi-Fi)..................................................... 123
24.14 FLIR T600bx 45° (incl. Wi-Fi and Ext. cal.).................................... 129
24.15 FLIR T600bx 45° (incl. Wi-Fi)..................................................... 135
24.16 FLIR T610 15° (incl. Wi-Fi)........................................................ 141
24.17 FLIR T610 25° (incl. Wi-Fi)........................................................ 147
24.18 FLIR T610 45° (incl. Wi-Fi)........................................................ 153
24.19 FLIR T620 15° (incl. Wi-Fi and Ext. cal.) ....................................... 159
24.20 FLIR T620 15° (incl. Wi-Fi)........................................................ 165
24.21 FLIR T620 25° (incl. Wi-Fi and Ext. cal.) ....................................... 171
24.22 FLIR T620 25° (incl. Wi-Fi)........................................................ 177
24.23 FLIR T620 25° and 15° (incl. Wi-Fi) ............................................. 183
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
xi
Table of contents
24.24 FLIR T620 25° and 45° (incl. Wi-Fi) ............................................. 189
24.25 FLIR T620 45° (incl. Wi-Fi and Ext. cal.) ....................................... 195
24.26 FLIR T620 45° (incl. Wi-Fi)........................................................ 201
24.27 FLIR T620bx 15° (incl. Wi-Fi and Ext. cal.).................................... 207
24.28 FLIR T620bx 15° (incl. Wi-Fi)..................................................... 213
24.29 FLIR T620bx 25° (incl. Wi-Fi and Ext. cal.).................................... 219
24.30 FLIR T620bx 25° (incl. Wi-Fi)..................................................... 225
24.31 FLIR T620bx 45° (incl. Wi-Fi and Ext. cal.).................................... 231
24.32 FLIR T620bx 45° (incl. Wi-Fi)..................................................... 237
24.33 FLIR T630 15° (incl. Wi-Fi)........................................................ 243
24.34 FLIR T630 25° (incl. Wi-Fi)........................................................ 249
24.35 FLIR T630 45° (incl. Wi-Fi)........................................................ 255
24.36 FLIR T630sc 15° (incl. Wi-Fi)..................................................... 261
24.37 FLIR T630sc 25° (incl. Wi-Fi)..................................................... 267
24.38 FLIR T630sc 25° and 45° w/case ............................................... 273
24.39 FLIR T630sc 45° (incl. Wi-Fi)..................................................... 279
24.40 FLIR T640 15° (incl. Wi-Fi and Ext. cal.) ....................................... 285
24.41 FLIR T640 15° (incl. Wi-Fi)........................................................ 292
24.42 FLIR T640 25° (incl. Wi-Fi and Ext. cal.) ....................................... 298
24.43 FLIR T640 25° (incl. Wi-Fi)........................................................ 305
24.44 FLIR T640 25° and 15° (incl. Wi-Fi) ............................................. 311
24.45 FLIR T640 25° and 45° (incl. Wi-Fi) ............................................. 318
24.46 FLIR T640 45° (incl. Wi-Fi and Ext. cal.) ....................................... 325
24.47 FLIR T640 45° (incl. Wi-Fi)........................................................ 332
24.48 FLIR T640bx 15° (incl. Wi-Fi and Ext. cal.).................................... 338
24.49 FLIR T640bx 15° (incl. Wi-Fi)..................................................... 345
24.50 FLIR T640bx 25° (incl. Wi-Fi and Ext. cal.).................................... 352
24.51 FLIR T640bx 25° (incl. Wi-Fi)..................................................... 359
24.52 FLIR T640bx 45° (incl. Wi-Fi and Ext. cal.).................................... 366
24.53 FLIR T640bx 45° (incl. Wi-Fi)..................................................... 373
24.54 FLIR T650sc 15° (incl. Wi-Fi)..................................................... 380
24.55 FLIR T650sc 25° (incl. Wi-Fi)..................................................... 387
24.56 FLIR T650sc 25° and 15° w/case ............................................... 394
24.57 FLIR T650sc 25° and 45° w/case ............................................... 401
24.58 FLIR T650sc 45° (incl. Wi-Fi)..................................................... 408
24.59 FLIR T660 15° (incl. Wi-Fi and Ext. cal.) ....................................... 415
24.60 FLIR T660 15° (incl. Wi-Fi)........................................................ 422
24.61 FLIR T660 25° (incl. Wi-Fi and Ext. cal.) ....................................... 429
24.62 FLIR T660 25° (incl. Wi-Fi)........................................................ 436
24.63 FLIR T660 25° and 15° w/case................................................... 443
24.64 FLIR T660 25° and 45° w/case................................................... 450
24.65 FLIR T660 45° (incl. Wi-Fi and Ext. cal.) ....................................... 457
24.66 FLIR T660 45° (incl. Wi-Fi)........................................................ 464
25 Mechanical drawings ....................................................................... 471
26 CE Declaration of conformity ............................................................ 481
27 Cleaning the camera ........................................................................ 483
27.1 Camera housing, cables, and other items..................................... 483
27.1.1 Liquids....................................................................... 483
27.1.2 Equipment.................................................................. 483
27.1.3 Procedure .................................................................. 483
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
xii
Table of contents
27.2 Infrared lens .......................................................................... 483
27.2.1 Liquids....................................................................... 483
27.2.2 Equipment.................................................................. 483
27.2.3 Procedure .................................................................. 483
27.3 Infrared detector ..................................................................... 484
27.3.1 General...................................................................... 484
27.3.2 Procedure .................................................................. 484
28 Application examples....................................................................... 485
28.1 Moisture & water damage ......................................................... 485
28.1.1 General...................................................................... 485
28.1.2 Figure........................................................................ 485
28.2 Faulty contact in socket ............................................................ 485
28.2.1 General...................................................................... 485
28.2.2 Figure........................................................................ 486
28.3 Oxidized socket...................................................................... 486
28.3.1 General...................................................................... 486
28.3.2 Figure........................................................................ 486
28.4 Insulation deficiencies.............................................................. 487
28.4.1 General...................................................................... 487
28.4.2 Figure........................................................................ 487
28.5 Draft .................................................................................... 488
28.5.1 General...................................................................... 488
28.5.2 Figure........................................................................ 488
29 About FLIR Systems ........................................................................ 490
29.1 More than just an infrared camera .............................................. 491
29.2 Sharing our knowledge ............................................................ 492
29.3 Supporting our customers......................................................... 492
30 Terms, laws, and definitions.............................................................. 493
31 Thermographic measurement techniques .......................................... 495
31.1 Introduction .......................................................................... 495
31.2 Emissivity.............................................................................. 495
31.2.1 Finding the emissivity of a sample.................................... 495
31.3 Reflected apparent temperature................................................. 499
31.4 Distance ............................................................................... 499
31.5 Relative humidity .................................................................... 499
31.6 Other parameters.................................................................... 499
32 History of infrared technology........................................................... 500
33 Theory of thermography................................................................... 503
33.1 Introduction ........................................................................... 503
33.2 The electromagnetic spectrum................................................... 503
33.3 Blackbody radiation................................................................. 504
33.3.1 Planck’s law ................................................................ 505
33.3.2 Wien’s displacement law................................................ 506
33.3.3 Stefan-Boltzmann's law ................................................. 507
33.3.4 Non-blackbody emitters ................................................. 508
33.4 Infrared semi-transparent materials............................................. 510
34 The measurement formula................................................................ 511
35 Emissivity tables ............................................................................. 515
35.1 References............................................................................ 515
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
xiii
Table of contents
35.2 Tables .................................................................................. 515
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
xiv
1
Disclaimers
1.1 Legal disclaimer
All products manufactured by FLIR Systems are warranted against defective
materials and workmanship for a period of one (1) year from the delivery date
of the original purchase, provided such products have been under normal storage, use and service, and in accordance with FLIR Systems instruction.
Uncooled handheld infrared cameras manufactured by FLIR Systems are warranted against defective materials and workmanship for a period oftwo (2)
years from the delivery date of the original purchase, provided such products
have been under normal storage, use and service, and in accordance with
FLIR Systems instruction, and provided that the camera has been registered
within 60 days of original purchase.
Detectors for uncooled handheld infrared cameras manufactured by FLIR Systems are warranted against defective materials and workmanship for a period
of ten (10) years from the delivery date of the original purchase, provided such
products have been under normal storage, use and service, and in accordance
with FLIR Systems instruction, and provided that the camera has been registered within 60 days of original purchase.
Products which are not manufactured by FLIR Systems but includedin systems delivered by FLIR Systems to the original purchaser, carry the warranty, if
any, of the particular supplier only. FLIR Systems has no responsibility whatsoever for such products.
The warranty extends only to the original purchaser and is not transferable. It
is not applicable to any product which has been subjected to misuse, neglect,
accident or abnormal conditions of operation. Expendable parts are excluded
from the warranty.
In the case of a defect in a product covered by thiswarranty the product must
not be further used in order to prevent additional damage. The purchaser shall
promptly report any defect to FLIR Systems or this warranty will not apply.
FLIR Systems will, at its option, repair or replace any such defective product
free of charge if, upon inspection, it proves to be defective in material or workmanship and provided that it is returned to FLIR Systems within the said oneyear period.
FLIR Systems has no other obligation or liability for defects than those set forth
above.
No other warranty is expressed or implied. FLIR Systems specifically disclaims
the implied warranties of merchantability and fitness for a particularpurpose.
FLIR Systems shall not be liable for any direct, indirect, special, incidental or
consequential loss or damage, whether based on contract, tort or any other legal theory.
This warranty shall begoverned by Swedish law.
Any dispute, controversy or claim arising out of or in connection with this war-
ranty, shall be finally settled by arbitration in accordance with the Rules of the
Arbitration Institute of the Stockholm Chamber of Commerce. The place of arbitration shall be Stockholm. The language to be used in the arbitral proceedings shall be English.
1.2 Usage statistics
FLIR Systems reserves the right to gather anonymous usage statistics to help
maintain and improve the quality of our software and services.
1.3 Changes to registry
The registry entry HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet
\Control\Lsa\LmCompatibilityLevel will be automatically changed to level 2 if
the FLIR Camera Monitor service detects a FLIR camera connected to the
computer with a USB cable. The modification will only be executed if the camera device implements a remote network service that supports network logons.
1.4 U.S. Government Regulations
This product may be subject to U.S. Export Regulations.
1.5 Copyright
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No parts of the software including source code may be reproduced, transmitted, transcribed or
translated into any language or computer language in any form or by any
means, electronic, magnetic, optical, manual or otherwise, without the prior
written permission of FLIR Systems.
The documentation must not, in whole or part, be copied, photocopied, reproduced, translated or transmitted to any electronic medium or machine readable form without prior consent, in writing, from FLIR Systems.
Names and marks appearing on the products herein are either registered
trademarks or trademarks of FLIR Systems and/or its subsidiaries. All other
trademarks, trade names or company names referenced herein are used for
identification only and are the property of their respective owners.
1.6 Quality assurance
The Quality Management System under which these products are developed
and manufactured has been certified in accordance with the ISO 9001
standard.
FLIR Systems is committed to a policy of continuous development; therefore
we reserve the right to make changes and improvements on any of the products without prior notice.
1.7 Patents
000439161; 000653423; 000726344; 000859020; 001707738; 001707746;
001707787; 001776519; 001954074; 002021543; 002021543-0002;
002058180; 002249953; 002531178; 002816785; 002816793; 011200326;
014347553; 057692; 061609; 07002405; 100414275; 101796816;
101796817; 101796818; 102334141; 1062100; 11063060001; 11517895;
1226865; 12300216; 12300224; 1285345; 1299699; 1325808; 1336775;
1391114; 1402918; 1404291; 1411581; 1415075; 1421497; 1458284;
1678485; 1732314; 17399650; 1880950; 1886650; 2007301511414;
2007303395047; 2008301285812; 2009301900619; 20100060357;
2010301761271; 2010301761303; 2010301761572; 2010305959313;
2011304423549; 2012304717443; 2012306207318; 2013302676195;
2015202354035; 2015304259171; 204465713; 204967995; 2106017;
2107799; 2115696; 2172004; 2315433; 2381417; 2794760001; 3006596;
3006597; 303330211; 4358936; 483782; 484155; 4889913; 4937897;
4995790001; 5177595; 540838; 579475; 584755; 599392; 60122153;
6020040116815; 602006006500.0; 6020080347796; 6020110003453;
615113; 615116; 664580; 664581; 665004; 665440; 67023029; 6707044;
677298; 68657; 69036179; 70022216; 70028915; 70028923; 70057990;
7034300; 710424; 7110035; 7154093; 7157705; 718801; 723605; 7237946;
7312822; 7332716; 7336823; 734803; 7544944; 7606484; 7634157;
7667198; 7809258; 7826736; 8018649; 8153971; 8212210; 8289372;
8340414; 8354639; 8384783; 8520970; 8565547; 8595689; 8599262;
8654239; 8680468; 8803093; 8823803; 8853631; 8933403; 9171361;
9191583; 9279728; 9280812; 9338352; 9423940; 9471970; 9595087;
D549758.
1.8 EULA Terms
• Youhave acquired a device (“INFRARED CAMERA”) that includes software licensed by FLIR Systems AB from Microsoft Licensing, GP or its affiliates (“MS”). Those installed software products of MS origin, as well as
associated media, printed materials, and “online” or electronic documentation (“SOFTWARE”) are protected by international intellectual property
laws and treaties. The SOFTWARE is licensed, not sold. All rights
reserved.
• IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT
(“EULA”), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLYCONTACT FLIR Systems AB FOR INSTRUCTIONS
ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE
OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON
THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT).
• GRANT OF SOFTWARE LICENSE. This EULA grants you the following
license:
◦ Youmay use the SOFTWARE only on theDEVICE.
◦ NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLER-
ANT.FLIR Systems AB HAS INDEPENDENTLY DETERMINED
HOW TO USE THESOFTWARE IN THE DEVICE, AND MS HAS
RELIED UPON FLIR Systems AB TO CONDUCT SUFFICIENT
TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE
FOR SUCH USE.
◦ NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is
provided “AS IS” and with all faults. THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE, ACCURACY,AND EFFORT (INCLUDING LACK OF NEGLIGENCE) IS WITH YOU.ALSO,
THERE IS NO WARRANTY AGAINST INTERFERENCE WITH
YOUR ENJOYMENT OF THE SOFTWARE OR AGAINST INFRINGEMENT.IF YOU HAVE RECEIVED ANY WARRANTIES RE-
GARDING THE DEVICE ORTHE SOFTWARE, THOSE
WARRANTIES DO NOT ORIGINATEFROM, ANDARE NOT
BINDING ON, MS.
◦ No Liability for Certain Damages. EXCEPT AS PROHIBITED BY
LAW,MS SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING
FROM OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY
EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. IN
NO EVENT SHALL MS BE LIABLE FOR ANY AMOUNT IN EXCESS OF U.S. TWO HUNDRED FIFTY DOLLARS (U.S.$250.00).
◦ Limitations on Reverse Engineering, Decompilation, and Dis-
assembly. Youmay not reverse engineer, decompile, or disassem-
ble the SOFTWARE, except and only to the extent that such activity
is expressly permitted by applicable law notwithstanding this
limitation.
◦ SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS.
Youmay permanently transfer rights under this EULA only as part of
a permanent sale or transfer of the Device, and only if the recipient
agrees to this EULA. If the SOFTWARE is an upgrade, any transfer
must also include all prior versions of the SOFTWARE.
◦ EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is
subject to U.S. export jurisdiction. You agree to comply with all applicable international and national laws that apply to the SOFTWARE,
including the U.S. Export Administration Regulations, as well as
end-user, end-use and destination restrictions issued by U.S. and
other governments.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
1
2
Safety information
WARNING
Applicability: Class B digital devices.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING
Applicability: Digital devices subject to 15.19/RSS-247.
NOTICE: This device complies with Part 15 of the FCC Rules and with RSS-247 of Industry Canada. Op-
eration is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired
operation.
WARNING
Applicability: Digital devices subject to 15.21.
NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems
may void the FCC authorization to operate this equipment.
WARNING
Applicability: Devices subject to RSS-102/47CFR2.1093.
This device has been tested and meets the FCC/ISED RF exposure guidelines, or the device is exempted
from SAR because of the low output power. Nevertheless, the device should be used in such a manner
that the potential for human contact during normal operation is minimized.
WARNING
Applicability: Cameras with one or more laser pointers.
Do not look directly into the laser beam. The laser beam can cause eye irritation.
WARNING
Applicability: Cameras with one or more batteries.
Do not disassemble or do a modification to the battery. The battery contains safety and protection devices
which, if damage occurs, can cause the battery to become hot, or cause an explosion or an ignition.
WARNING
Applicability: Cameras with one or more batteries.
If there is a leak from the battery and you get the fluid in your eyes, do not rub your eyes. Flush well with
water and immediately get medical care. The battery fluid can cause injury to your eyes if you do not do
this.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
3
2
Safety information
WARNING
Applicability: Cameras with one or more batteries.
Do not continue to charge the battery if it does not become charged in the specified charging time. If you
continue to charge the battery, it can become hot and cause an explosion or ignition. Injury to persons
can occur.
WARNING
Applicability: Cameras with one or more batteries.
Only use the correct equipment to remove the electrical power from the battery. If you do not use the correct equipment, you can decrease the performance or the life cycle of the battery. If you do not use the
correct equipment, an incorrect flow of current to the battery can occur. This can cause the battery to become hot, or cause an explosion. Injury to persons can occur.
WARNING
Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on containers before you use a liquid. The liquids can be dangerous. Injury to persons can occur.
CAUTION
Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example,
devices that cause laser radiation, or the sun. This can have an unwanted effect on the accuracy of the
camera. It can also cause damage to the detector in the camera.
CAUTION
Do not use the camera in temperatures more than +50°C (+122°F), unless other information is specified
in the user documentation or technical data. High temperatures can cause damage to the camera.
CAUTION
Applicability: Cameras with one or more laser pointers.
To prevent damage, put the protective cap on the laser pointer when you do not operate the laser pointer.
Damage to the laser pointer can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Do not attach the batteries directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a specific adapter to connect the batteries to a cigarette lighter socket. Damage to the batteries can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not connect the positive terminal and the negative terminal of the battery to each other with a metal
object (such as wire). Damage to the batteries can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not get water or salt water on the battery, or permit the battery to become wet. Damage to the batteries
can occur.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
4
2
Safety information
CAUTION
Applicability: Cameras with one or more batteries.
Do not make holes in the battery with objects. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not hit the battery with a hammer. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put your foot on the battery, hit it or cause shocks to it. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the batteries in or near a fire, or into direct sunlight. When the battery becomes hot, the built-in
safety equipment becomes energized and can stop the battery charging procedure. If the battery becomes hot, damage can occur to the safety equipment and this can cause more heat, damage or ignition
of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on a fire or increase the temperature of the battery with heat. Damage to the battery
and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not put the battery on or near fires, stoves, or other high-temperature locations. Damage to the battery
and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not solder directly onto the battery. Damage to the battery can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Do not use the battery if, when you use, charge, or put the battery in storage, there is an unusual smell
from the battery, the battery feels hot, changes color, changes shape, or is in an unusual condition. Speak
with your sales office if one or more of these problems occurs. Damage to the battery and injury to persons can occur.
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery charger when you charge the battery. Damage to the battery can occur if you
do not do this.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
5
2
Safety information
CAUTION
Applicability: Cameras with one or more batteries.
Only use a specified battery for the camera. Damage to the camera and the battery can occur if you do
not do this.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can charge the battery is 0°C to +45°C (+32°F to +113°F). If
you charge the battery at temperatures out of this range, it can cause the battery to become hot or to
break. It can also decrease the performance or the life cycle of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
The temperature range through which you can remove the electrical power from the battery is -15°C to
+50°C (+5°F to +122°F), unless other information is specified in the user documentation or technical data.
If you operate the battery out of this temperature range, it can decrease the performance or the life cycle
of the battery.
CAUTION
Applicability: Cameras with one or more batteries.
When the battery is worn, apply insulation to the terminals with adhesive tape or equivalent materials before you discard it. Damage to the battery and injury to persons can occur if you do not do this.
CAUTION
Applicability: Cameras with one or more batteries.
Remove any water or moisture on the battery before you install it. Damage to the battery can occur if you
do not do this.
CAUTION
Do not apply solvents or equivalent liquids to the camera, the cables, or other items. Damage to the battery and injury to persons can occur.
CAUTION
Be careful when you clean the infrared lens. The lens has an anti-reflective coating which is easily damaged. Damage to the infrared lens can occur.
CAUTION
Do not use too much force to clean the infrared lens. This can cause damage to the anti-reflective
coating.
Note The encapsulation rating is only applicable when all the openings on the camera
are sealed with their correct covers, hatches, or caps. This includes the compartments for
data storage, batteries, and connectors.
CAUTION
Applicability: Cameras with a viewfinder.
Make sure that the beams from the intensive energy sources do not go into the viewfinder. The beams
can cause damage to the camera. This includes the devices that emit laser radiation, or the sun.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
6
3
Notice to user
3.1 User-to-user forums
Exchange ideas, problems, and infrared solutions with fellow thermographers around the
world in our user-to-user forums. To go to the forums, visit:
3.2 Calibration
We recommend that you send in the camera for calibration once a year. Contact your local
sales office for instructions on where to send the camera.
3.3 Accuracy
For very accurate results, we recommend that you wait 5 minutes after you have started
the camera before measuring a temperature.
3.4 Disposal of electronic waste
Electrical and electronic equipment (EEE) contains materials, components and substances that may be hazardous and present a risk to human health and the environment when
waste electrical and electronic equipment (WEEE) is not handled correctly.
Equipment marked with the below crossed-out wheeled bin is electrical and electronic
equipment. The crossed-out wheeled bin symbol indicates that waste electrical and electronic equipment should not be discarded together with unseparated household waste,
but must be collected separately.
For this purpose all local authorities have established collection schemes under which residents can dispose waste electrical and electronic equipment at a recycling centre or other
collection points, or WEEE will be collected directly from households. More detailed information is available from the technical administration of the relevant local authority.
3.5 Training
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
7
4
Customer help
4.1 General
4.2 Submitting a question
To submit a question to the customer help team, you must be a registered user. It only
takes a few minutes to register online. If you only want to search the knowledgebase for
existing questions and answers, you do not need to be a registered user.
When you want to submit a question, make sure that you have the following information to
hand:
• The camera model
• The camera serial number
• The communication protocol, or method, between the camera and your device (for example, SD card reader, HDMI, Ethernet, USB, or FireWire)
• Device type (PC/Mac/iPhone/iPad/Android device, etc.)
• Version of any programs from FLIR Systems
• Full name, publication number, and revision number of the manual
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
9
4
Customer help
4.3 Downloads
On the customer help site you can also download the following, when applicable for the
product:
• Firmware updates for your infrared camera.
• Program updates for your PC/Mac software.
• Freeware and evaluation versions of PC/Mac software.
• User documentation for current, obsolete, and historical products.
• Mechanical drawings (in *.dxf and *.pdf format).
• Cad data models (in *.stp format).
• Application stories.
• Technical datasheets.
• Product catalogs.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
10
5
Quick start guide
5.1 Procedure
Follow this procedure:
1. Put a battery into the battery compartment.
2. Charge the battery for 4 hours before starting the camera for the first time.
3. Insert a memory card into the card slot.
4. Push the On/off button
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
11
6
List of accessories and services
Product name Part number
Battery charger, incl. power supply with multi plugs
T6xx
Bluetooth Headset T197771ACC
Calibration including General maintenance T6xx
series
Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft. T198509
Close-up IR lens, 1.5× (25 µm) with case
Close-up IR lens, 2.9× (50 µm) with case
Close-up IR lens, 5.8× (100 µm) with case
FLIR Reporter Professional (license only) T198586
FLIR ResearchIR 3 (license only) T198578
FLIR ResearchIR 3 Max (license only) T198574
FLIR ResearchIR Max + HSDR 4
FLIR ResearchIR Max 4 T198696
FLIR ResearchIR Standard 4
FLIR Tools T198584
FLIR Tools+ (license only) T198583
Hard transport case for T6xx series T198625ACC
HDMI type C to DVI cable 1.5 m T910930ACC
HDMI type C to HDMI type A cable 1.5 m T910891ACC
High temp option +300°C to 2000°C (+572°F to
3632°F) for FLIR A6xxsc and T6xx
IR lens, f=13.1 mm (45°) with case T197915
IR lens, f=24.6 mm (25°) with case T197922
IR lens, f=41.3 mm (15°) with case T197914
IR lens, f=6.5 mm (80°) with case T198065
IR lens, f=88.9 mm (7°) with case and support for
T6xx
IR Window 2 in 19250-100
IR Window 3 in. 19251-100
IR Window 4 in. 19252-100
Large eyecup T198497
Li-Ion Battery pack 3.7V 29Wh T198506
Memory card SDHC 4 GB T911230ACC
Neck strap T198499
One year extended warranty for T6xx series T199836
Pouch for FLIR T6xx and T4xx series T198495
Power supply, incl. multi plugs T910814
SS IR Window 2 in.
SS IR Window 3 in.
SS IR Window 4 in.
Tool belt T911093
T198126
T199838
T198066
T198059
T198060
T198697
T198731
T197896
T198166
19250-200
19251-200
19252-200
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
12
6
List of accessories and services
Product name Part number
Tripod Adapter T198498
USB cable Std A <-> Mini-B
1910423
Note FLIR Systems reserves the right to discontinue models, parts or accessories, and
other items, or to change specifications at any time without prior notice.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
13
7
A note about ergonomics
7.1 General
To prevent strain-related injuries, it is important that you hold the camera ergonomically
correct. This section gives advice and examples on how to hold the camera.
Note Please note the following:
• Always tilt the touch-screen LCD to suit your work position.
• When you hold the camera, make sure that you support the optics housing with your left
hand too. This decreases the strain on your right hand.
7.2 Figure
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
14
8
Camera parts
8.1 View from the right
8.1.1 Figure
8.1.2 Explanation
1. Knob to change the dioptric correction for the viewfinder.
Note This item is dependent on the camera model.
2. Hand strap.
3. Digital zoom button.
4. Autofocus button (push half-way down)/Save button (push fully down).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
15
8
Camera parts
8.2 View from the left
8.2.1 Figure
8.2.2 Explanation
1. Camera lamp.
2. Laser pointer.
Note The laser pointer may not be enabled in all markets.
3. Camera lamp.
4. Infrared lens.
5. Digital camera.
6. Focusing ring.
7. Button to operate the laser pointer.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
16
8
Camera parts
8.3 View from the rear
8.3.1 Figure
8.3.2 Explanation
1. Sensor that adjusts the touch-screen LCD intensity automatically.
2. Button to switch between touch-screen LCD mode and viewfinder mode.
Note This item is dependent on the camera model.
3. Viewfinder.
Note This item is dependent on the camera model.
4. Programmable button.
5. Joystick with push-button functionality.
6. Back button.
7. Camera lamp button.
8. Button to switch between automatic and manual image adjustment mode.
9. Image archive button.
10. Touch-screen LCD.
11. Power indicator.
12. On/off button.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
17
8
Camera parts
8.4 View from the bottom
8.4.1 Figure
8.4.2 Explanation
1. Memory card.
2. Indicator showing that the memory card is busy.
Note
• Do not eject the memory card when this LED is flashing.
• Do not connect the camera to a computer when this LED is flashing.
3. USB Mini-B cable (to connect the camera to a computer).
4. HDMI cable (for digital video output).
5. Battery condition LED indicator.
6. Power cable (to power the camera and charge the battery).
7. USB-A cable (to connect an external USB device to the camera).
8. Tripod mount. Requires an adapter (included).
9. Latch to release the battery.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
18
8
Camera parts
8.5 Battery condition LED indicator
8.5.1 Figure
8.5.2 Explanation
Type of signal Explanation
The green LED flashes twice per second. The battery is being charged.
The green LED glows continuously. The battery is fully charged.
8.6 Power LED indicator
8.6.1 Figure
8.6.2 Explanation
Type of signal Explanation
The LED is off. The camera is off.
The LED is blue. The camera is on.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
19
8
Camera parts
8.7 Laser pointer
8.7.1 Figure
Figure 8.1 This figure shows the difference in position between the laser pointer and the optical center of
the infrared lens.
WARNING
Do not look directly into the laser beam. The laser beam can cause eye irritation.
Note The symbol is displayed on the screen when the laser pointer is on.
Note The laser pointer is enabled by a setting. Select
Set up camera > Lamp & laser > Enable lamp & laser.
Note The laser pointer may not be enabled in all markets.
8.7.2 Laser warning label
A laser warning label with the following information is attached to the camera:
8.7.3 Laser rules and regulations
Wavelength: 635 nm. Maximum output power: 1 mW.
This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007.
(Settings) > Device settings >
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
20
9
Screen elements
9.1 Figure
9.2 Explanation
1. Measurement toolbar.
2. Measurement tool (e.g., spotmeter).
3. Zoom factor.
4. Result table.
5. Status icons.
6. Temperature scale.
7. Settings toolbar button.
8. Color toolbar button.
9. Measurement toolbar button.
10. Image mode toolbar button.
11. Measurement parameters toolbar button.
12. Recording mode toolbar button.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
21
10
Navigating the menu system
10.1 Figure
10.2 Explanation
The figure above shows the two ways to navigate the menu system in the camera:
• Using the index finger or a stylus pen specially designed for capacitive touch usage to
navigate the menu system (left).
• Using the joystick to navigate the menu system (right).
You can also use a combination of the two.
In this manual it is assumed that the joystick is used, but most tasks can also be carried
out using the index finger or a stylus pen.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
22
11
Pairing Bluetooth devices
11.1 General
Before you can use a Bluetooth device with the camera, you need to pair the devices.
11.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Bluetooth including METERLiNK and push the joystick.
6. If the Bluetooth check box is unchecked, push the joystick to activate Bluetooth.
Note You also need to activate Bluetooth connectivity on the external device.
7. Select Scan for Bluetooth devices and push the joystick.
8. Wait until a list of available devices is displayed. This will take about 15 seconds.
9. When a Bluetooth device is found, select the device to add it, and begin the pairing
procedure. The device is then ready to be used.
Note
• Only METERLiNK devices and Bluetooth-enabled headsets will appear in the list of
available devices.
• You can add several devices.
• You can remove a device by selecting the device and then selecting Unpair device.
• After adding a METERLiNK device, such as the FLIR MR77 or FLIR DM93, the result
from the meter will be visible in the result table and stored with the images. For more information, see section 17 Fetching data from external FLIR meters, page 54.
• After adding a Bluetooth-enabled headset, it is ready to be used for adding voice
annotations.
(Settings).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
23
12
Configuring Wi-Fi
12.1 General
Depending on your camera configuration, you can connect the camera to a wireless local
area network (WLAN) using Wi-Fi, or let the camera provide Wi-Fi access to another
device.
You can connect the camera in two different ways:
• Most common use: Setting up a peer-to-peer connection (also called an ad hoc or P2P
connection). This method is primarily used with other devices, e.g., an iPhone or iPad.
• Less common use: Connecting the camera to a WLAN.
12.2 Setting up a peer-to-peer connection (most
common use)
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Wi-Fi and push the joystick.
6. Select Share and push the joystick.
7. (Optional step.) To display and change the parameters, select Settings and push the
joystick.
• To change the channel (the channel that the camera is broadcasting on), select
Channel and push the joystick.
• To activate WEP (encryption algorithm), select WEP and push the joystick. This will
check the WEP check box.
• To change the WEP password, select Password and push the joystick.
Note These parameters are set for your camera’s network. They will be used by the
external device to connect that device to the network.
(Settings).
12.3 Connecting the camera to a wireless local area network (less common use)
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Wi-Fi and push the joystick.
6. Select Connect to network and push the joystick.
7. To display a list of the available networks, select Networks and push the joystick.
8. Select one of the available networks.
Password-protected networks are indicated with a padlock icon, and for these you will
need to enter a password.
(Settings).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
24
12
Configuring Wi-Fi
Note Some networks do not broadcast their existence. To connect to such a network,
select Settings from the Networks list and push the joystick. Then select Add network...
and set all parameters manually according to that network.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
25
13
Handling the camera
13.1 Charging the battery
Note You must charge the battery for 4 hours before you start using the camera for the
first time.
13.1.1 Using the power supply to charge the battery
13.1.1.1 Procedure
Follow this procedure:
1. Connect the power supply cable plug to the power connector on the camera.
2. Connect the power supply mains-electricity plug to a mains socket.
3. Disconnect the power supply cable plug when the green light of the battery condition
LED indicator is continuous.
13.1.2 Using the stand-alone battery charger to charge the battery
13.1.2.1 Explanation
Type of signal Explanation
The blue LED flashes. The battery is being charged.
The blue LED glows continuous. The battery is fully charged.
13.1.2.2 Procedure
Follow this procedure:
1. Put the battery in the battery charger.
2. Connect the power supply cable plug to the connector on the battery charger.
3. Connect the power supply mains-electricity plug to a mains socket.
4. Disconnect the power supply cable plug when the blue LED on the battery charger is
continuous.
13.2 Turning on the camera
13.2.1 Procedure
Follow this procedure:
1. To turn on the camera, push and release the
button.
13.3 Turning off the camera
13.3.1 Procedure
Follow this procedure:
1. To turn off the camera, push and hold the
button for more than 0.2 second.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
26
Handling the camera13
13.4 Adjusting the viewfinder’s dioptric
correction
13.4.1 Figure
CAUTION
Applicability: Cameras with a viewfinder.
Make sure that the beams from the intensive energy sources do not go into the viewfinder. The beams
can cause damage to the camera. This includes the devices that emit laser radiation, or the sun.
Note This item is dependent on the camera model.
13.4.2 Procedure
Follow this procedure:
1. To adjust the viewfinder’s dioptric correction, look at the displayed text or graphics on
the screen, and rotate the adjustment knob clockwise or counter-clockwise for best
sharpness.
Note
• Maximum dioptric correction: +2.
• Minimum dioptric correction: –2.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
27
Handling the camera13
13.5 Adjusting the angle of the lens
13.5.1 Figure
13.6 Adjusting the infrared camera focus
manually
13.6.1 Figure
13.6.2 Procedure
Follow this procedure:
1. Do one of the following:
• For far focus, rotate the focus ring clockwise (looking at the touch-screen LCD side).
• For near focus, rotate the focus ring counter-clockwise (looking at the touch-screen
LCD side).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
28
Handling the camera13
Note
• Do not touch the lens surface when you adjust the infrared camera focus manually. If
this happens, clean the lens according to the instructions in 27.2 Infrared lens, page
483.
• The focus ring can be rotated infinitely, but only a certain amount of rotation is needed
when focusing.
13.7 Autofocusing the infrared camera
13.7.1 Figure
13.7.2 Procedure
Follow this procedure:
1. To autofocus the camera when continuos autofocus is disabled, push the Autofocus/
Save button half-way down.
13.8 Continuous autofocus
13.8.1 General
The camera can be set up to perform continuous autofocusing.
Note
• In this mode, the digital camera is used, which means that continuous autofocus will
not work in darkness.
• When continuous autofocus is enabled, it is not possible to manually adjust the focus
by rotating the focus ring.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
29
Handling the camera13
13.8.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Set up camera and push the joystick.
6. Select Continuous autofocus. If the check box is unchecked, push the joystick to enable continuous autofocus.
7. Aim the camera toward the object of interest. The camera will now continuously
autofocus.
Note To pause continuous autofocusing, push the Autofocus/Save button half-way down.
(Settings).
13.9 Operating the laser pointer
Note The laser pointer is enabled by a setting. Select (Settings) > Device settings >
Set up camera > Lamp & laser > Enable lamp & laser.
13.9.1 Figure
13.9.2 Procedure
Follow this procedure:
1. To turn on the laser pointer, push and hold the laser button.
2. To turn off the laser pointer, release the laser button.
Note
• A warning indicator is displayed on the screen when the laser pointer is turned on.
• The position of the laser dot is indicated on the infrared image (depending on the cam-
era model).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
30
Handling the camera13
13.10 Using the digital zoom function
13.10.1 Figure
13.10.2 Procedure
Follow this procedure:
1. To zoom, push the zoom button left or right.
13.11 Changing lenses
Follow this procedure:
1. Take a firm grip around the outermost part of the lens.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
31
Handling the camera13
2. Rotate the lens 30° degrees counter-clockwise.
3. Carefully pull out the lens from the lens bayonet mount.
4. The infrared detector is now fully exposed. Do not touch this surface. If you see dust
on the detector, follow the instructions in 27.3 Infrared detector, page 484.
5. Note the index marks on the lens bayonet mount and on the lens.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
32
Handling the camera13
6. Align the lens correctly to the bayonet mount.
7. Carefully push the lens into position.
8. Rotate the lens 30° degrees clockwise.
13.12 Calibrating the compass
13.12.1 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select GPS & compass and push the joystick.
6. Select Compass. If the Compass check box is unchecked, push the joystick to enable
the compass.
(Settings).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
33
Handling the camera13
7. Select Calibrate compass and push the joystick. Follow the on-screen instructions.
Note You have to rotate the camera slowly.
13.13 Changing the viewfinder eyecup
CAUTION
Applicability: Cameras with a viewfinder.
Make sure that the beams from the intensive energy sources do not go into the viewfinder. The beams
can cause damage to the camera. This includes the devices that emit laser radiation, or the sun.
Note This item is dependent on the camera model.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
34
Handling the camera13
Follow this procedure:
1. Put your thumbs at the lower part of the eyecup. Push the eyecup horizontally, away
from the touch-screen LCD side, until the eyecup slides out from its mount.
Note To remove the eyecup, you must slide it out from its mount. Do not pull the eyecup straight up.
2. Note the grooves on the eyecup mount on the camera and on the new eyecup.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
35
Handling the camera13
3. Align the new eyecup with the eyecup mount on the camera.
4. Carefully slide the eyecup into position.
13.14 Using the camera lamp as a flash
13.14.1 General
The camera lamp can be used as a flash for the digital camera. When the flash function is
activated, the camera lamp will flash when an image is saved by pushing the Autofocus/
Save button fully down.
13.14.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Set up camera and push the joystick.
6. Select Lamp & laser and push the joystick.
7. Select Enable lamp & laser. If the check box is unchecked, push the joystick to enable
the camera lamp.
8. Select Use lamp as flash. If the check box is unchecked, push the joystick to activate
the flash function.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Settings).
36
14
Working with images
14.1 Saving an image
14.1.1 General
You can save images to a memory card.
The camera saves an image file including all thermal and visual information. This means
that you can open an image file at a later stage and, for example, select another image
mode, apply color alarms, and add measurement tools.
The image jpg file is fully radiometric and saved lossless, which enables full post-processing in FLIR Tools. There is also a regular jpg part (lossy) for convenient viewing in nonFLIR Systems software (Explorer).
14.1.2 About UltraMax
UltraMax is an image enhancement feature that increases the image resolution and lowers
the noise, making small objects easier to see and measure. An UltraMax image is twice as
wide and high as an ordinary image.
When an UltraMax image is captured by the camera, several ordinary images are saved in
the same file. Capturing all the images can take up to 1 second. To fully utilize UltraMax,
the images need to be slightly different, which can be accomplished by a slight movement
of the camera. You should hold the camera firmly in your hands (do not put it on a tripod),
which will make these images vary just a little during the capture. Correct focus, a highcontrast scene, and a non-moving target are other conditions that help to achieve a goodquality UltraMax image.
At the moment, only FLIR Tools has the ability to process UltraMax images. Other FLIR
software will treat the image as a regular image.
14.1.3 Image capacity
The capacity of a 4 GB memory card is theoretically 3600 images (with no annotations).
14.1.4 Naming convention
The naming convention for image files is FLIRxxxx.jpg, where xxxx is a unique counter.
14.1.5 Procedure
Follow this procedure:
1. To save an image, push the Autofocus/Save button fully down.
Note
• Depending on the settings in
◦ A preview image is displayed before the image is saved.
◦ An annotation tool or the annotation menu is displayed when the image has been
saved.
• To configure UltraMax, select
UltraMax.
• The camera can be configured to also save the visual image as a separate file. Select
(Settings) > Save options > Photo as separate JPEG = On.
(Settings) > Save options, the following may happen:
(Settings) > Save options > Image resolution =
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
37
Working with images14
14.2 Previewing an image
14.2.1 General
You can preview an image before you save it. This enables you to see if the image contains
the information you want before you save it. You can also adjust and edit the image.
Note The camera must be configured to display a preview image before saving. Select
(Settings) > Save options > Preview image before saving = On.
14.2.2 Procedure
Follow this procedure:
1. To preview an image, push the Autofocus/Save button fully down. This displays the
preview.
2. Manual image adjust mode is now active, and the status icon
age adjustment instructions, see 14.5 Adjusting an infrared image, page 39.
3. To edit the image, push the joystick. This displays a context menu. For editing instructions, see 14.4 Editing a saved image, page 38.
4. Do one of the following:
• To save the image, push the Autofocus/Save button fully down.
• To exit preview mode without saving, push the Back button
is displayed. For im-
.
14.3 Opening a saved image
14.3.1 General
When you save an image, the image file is stored on the memory card. To display the image again, open it from the image archive.
14.3.2 Procedure
Follow this procedure:
1. Push the Image archive button
2. Move the joystick up/down or left/right to select the image you want to view.
3. Push the joystick. This will display the image at full size.
4.
Do one or more of the following:
• To switch between an infrared image and a visual image, move the joystick up/down.
• To view the previous/next image, move the joystick left/right.
• To edit the image, add annotations, display information, or delete the image, push
the joystick. This displays a context menu.
.
• To return to the image archive overview, push the Back button
.
14.4 Editing a saved image
14.4.1 General
You can edit a saved image. You can also edit an image in preview mode.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
38
Working with images14
14.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick and select
3. Manual image adjust mode is now active, and the status icon
age adjustment instructions, see 14.5 Adjusting an infrared image, page 39.
4. Push the joystick. This displays a context menu.
• Select
• Select
• Select
• Select
• Select
• Select
(Cancel) to exit edit mode.
(Measurement parameters) to change the global parameters.
(Image mode) to change the image mode.
(Measurement) to add a measurement tool.
(Color) to change the color palette or set a color alarm.
(Save) to save and exit edit mode.
(Edit) from the menu.
is displayed. For im-
14.5 Adjusting an infrared image
14.5.1 General
An infrared image can be adjusted automatically or manually. When manual image adjust
mode is active, the status icon
is displayed.
• In live mode, push the button
modes. You can also switch between the modes by touching the temperature scale on
the screen.
• In preview/edit mode, manual image adjust mode is active.
14.5.2 Example 1
Here are two infrared images of a building. In the left image, which is auto-adjusted, the
large temperature span between the clear sky and the heated building makes a correct
analysis difficult. You can analyze the building in more detail if you change the temperature
scale to values close to the temperature of the building.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
to switch between automatic and manual image adjust
39
Working with images14
Automatic Manual
14.5.3 Example 2
Here are two infrared images of an isolator in a power line. To make it easier to analyze
the temperature variations in the isolator, the temperature scale in the right image has
been changed to values close to the temperature of the isolator.
Automatic Manual
14.5.4 Procedure
Follow this procedure:
1. In live mode, push the button
2. To change the temperature scale minimum and maximum limits simultaneously, move
the joystick up/down.
3. To change the temperature scale minimum or maximum limit, do the following:
• Move the joystick left/right to select (highlight) the maximum or minimum
temperature.
• Move the joystick up/down to change the value of the highlighted temperature.
4. (Optional step). In preview/edit mode, push the button
adjust sequence.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
to enter manual image adjust mode.
to perform a one-shot auto-
40
Working with images14
14.6 Performing a non-uniformity correction
(NUC)
14.6.1 What is a non-uniformity correction?
A non-uniformity correction is an image correction carried out by the camera software to
compensate for different sensitivities of detector elements and other optical and geometrical disturbances
14.6.2 When to perform a non-uniformity correction?
The non-uniformity correction process should be carried out whenever the output image
becomes spatially noisy. The output can become spatially noisy when the ambient temperature changes (such as from day to night operation, and vice versa).
14.6.3 Procedure
1
.
To perform a non-uniformity correction, push and hold the Image archive button
more than 2 seconds.
for
14.7 Changing the temperature range
14.7.1 General
You must change the temperature range according to the expected temperature of the object you are inspecting.
14.7.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Set up camera and push the joystick.
6. Select Camera temperature range and push the joystick.
7. Select the appropriate temperature range and push the joystick.
Note You can also assign the function Switch temperature range to the programmable
button. Select
(Settings) > Programmable button > Switch temperature range.
(Settings).
14.8 Hiding overlay graphics (programmable
button)
14.8.1 General
Overlay graphics provide information about an image, e.g., measurement functions and
parameters. You can choose to hide all overlay graphics.
1. Definition from the impending international adoption of DIN 54190-3 (Non-destructive testing – Thermographic
testing – Part 3: Terms and definitions).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
41
Working with images14
14.8.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Programmable button and push the joystick.
5. Select Hide graphics and push the joystick. You have now assigned this function to the
button
Note Other functions that can be associated with the programmable button include the
following:
• Hide graphics
• Calibrate
• Switch Thermal <> Digital camera
• Switch Thermal <> Thermal MSX
• Switch 1x zoom <> Max zoom
• Switch between two latest palettes
• Switch temperature range
• Continuous autofocus
. This is a programmable button, and you can assign other functions to it.
(Settings).
14.9 Changing the color palette
14.9.1 General
You can change the color palette that the camera uses to display different temperatures. A
different palette can make it easier to analyze an image.
14.9.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu.
4. Use the joystick to select a different palette.
5. Push the joystick.
(Color).
14.10 Deleting an image
14.10.1 General
You can delete an image from the memory card.
14.10.2 Procedure
Follow this procedure:
1. Push the Image archive button
2. Move the joystick up/down or left/right to select the image you want to delete.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
.
42
Working with images14
3. Push the joystick to display the image.
4. Push the joystick to display a menu.
5. On the menu, select
6. Push the joystick and confirm the choice.
Note Note that both images in the image file (thermal and visual) will be deleted.
(Delete).
14.11 Deleting all images
14.11.1 General
You can delete all images from the memory card.
14.11.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Reset options and push the joystick.
5. Select Delete all saved images... and confirm the choice.
(Settings).
14.12 Creating a PDF report in the camera
14.12.1 General
You can create a PDF report and save it to the memory card. You can then transfer the
PDF report to a computer, iPhone, or iPad using FLIR Tools, and send the report to a
customer.
14.12.2 Naming convention
The naming convention for report files is REPORTxxxx.jpg, where xxxx is a unique
counter.
14.12.3 Procedure
Follow this procedure:
1. Push the Image archive button
2. Move the joystick up/down or left/right to select an image.
3. Push the joystick to display the image.
4. Push the joystick to display a context menu.
5. Select
about the image.
6. Select Create report and push the joystick.
The created report will be available in the archive.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Information & reports) and push the joystick. This displays information
.
43
15
Working with image modes
15.1 General
The camera captures both thermal and visual images at the same time. By your choice of
image mode, you select which type of image to display on the screen.
The camera supports the following image modes:
• Thermal MSX (Multi Spectral Dynamic Imaging): The camera displays infrared images
where the edges of the objects are enhanced with visual image details.
• Thermal: A full infrared image is displayed.
• Picture in picture: An infrared image frame is displayed on top of the visual image.
• Digital camera: The visual image captured by the digital camera is displayed.
Note
• These image modes only work correctly for calibrated lenses. The lens that ships with
the camera is factory calibrated. To have a new lens calibrated, you must send in the
camera and the lens to your local service department.
• All thermal and visual information is stored when an image is saved. This means that
you can edit the image later, in the image archive or in FLIR Tools, and select any of the
image modes.
15.2 Image examples
This table explains the different types of image modes.
Image mode Image
Thermal
Thermal MSX
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
44
Working with image modes15
Image mode Image
Picture in picture
Digital camera
15.3 Selecting the image mode
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu.
4. Use the joystick to go to one of the image modes:
(Thermal MSX)
•
•
(Thermal)
(Picture in picture)
•
•
(Digital camera)
5. Push the joystick confirm.
6. If Picture in picture mode is selected, you can at this point move and resize the infrared
image frame using the touch screen.
(Image mode).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
45
16
Working with measurement tools
16.1 General
To measure a temperature, you can use one or more measurement tools, e.g., a spotmeter
or a box.
16.2 Adding/removing measurement tools
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu.
• Select
• Select
• Select
• Select
• Select
models.)
• Select (User preset 2) to add user preset 2. (Not available in all camera
models.)
4. Push the joystick. This displays the measurement tool or the group of preset tools on
the screen.
(No measurements) to remove all tools.
(Center spot) to add a center spot.
(Hot spot) to add a hot spot detection within a box area.
(Cold spot) to add a cold spot detection within a box area.
(User preset 1) to add user preset 1. (Not available in all camera
(Measurement).
16.3 Working with user presets
16.3.1 General
A user preset is a measurement tool, or a group of measurement tools, with predefined
characteristics.
16.3.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Select Define user presets and push the joystick.
5. Select Define preset 1 or Define preset 2 and push the joystick. This displays a context
menu.
6. Select
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Add measurement).
(Settings).
46
Working with measurement tools16
7. Push the joystick. This displays a submenu.
• Select
• Select
• Select
• Select
• Select
8. Push the joystick. This displays the measurement tool on the screen.
9. Push the joystick. This displays a context menu, where you can select one or more of
the following actions (depending on the type of tool):
• Remove the tool.
• Resize, move, center, and rotate the tool.
• Display maximum, minimum, and average values.
• Set alarms.
• Set local parameters.
• When completed, select
10. When all measurement tools have been added, select
(Add spot) to add a spot.
(Add box) to add a box.
(Add circle) to add a circle.
(Add line) to add a line.
(Add delta) to set up a differential calculation.
(Done).
(Save as preset).
16.4 Resizing or moving a measurement tool
16.4.1 General
You can resize and move a measurement tool.
16.4.2 Procedure
Note
• This procedure assumes that you have previously laid out a measurement tool or user
preset on the screen.
• You can also move and resize the measurement tool by touching the screen.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now displayed with one or more handles.
Spot measurement tool:
Area measurement tool:
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
47
Working with measurement tools16
2. Push the joystick—or touch and hold the tool. This displays a context menu.
• Select
• Select
3. Move the joystick up/down and left/right to resize or move the tool.
4. When completed, push the joystick and select
(Resize) to change the size of the tool.
(Move) to move the tool.
(Done).
16.5 Changing object parameters
16.5.1 General
For accurate measurements, you must set the object parameters.
16.5.2 Types of parameters
The camera can use these object parameters:
• External IR window compensation, i.e., the temperature of any protective windows, ex-
ternal lenses (e.g., the close-up lens), etc., that are set up between the camera and the
object of interest. If no protective window, protective shield, or external lens is used, this
value is irrelevant and should be left inactive.
• Object distance, i.e., the distance between the camera and the object of interest.
• Atmospheric temperature, i.e., the temperature of the air between the camera and the
object of interest.
• Relative humidity, i.e., the relative humidity of the air between the camera and the ob-
ject of interest.
• Reflected temperature, which is used when compensating for the radiation from the
surroundings reflected by the object into the camera. This property of the object is
called “reflectivity”.
• Emissivity, i.e., how much radiation an object emits, compared with the radiation of a
theoretical reference object at the same temperature (called a “blackbody”). The opposite of emissivity is reflectivity. The emissivity determines how much of the radiation
originates from the object as opposed to being reflected by it.
Note There is an Emissivity mode setting, which you can use to enter the emissivity
by material instead of by value. Select
> Emissivity mode > Select from materials table.
Of the object parameters, Emissivity is the most important parameter to set correctly. If the
Emissivity is set to a low value, the Reflected temperature also becomes important. The
parameters Object distance, Atmospheric temperature, and Relative humidity are relevant
for longer distances. The External IR window compensation must be activated if a protective window or external lens is used.
16.5.3 Recommended values
If you are unsure about the values, the following are recommended:
Object distance 1.0 m (3.3′)
Atmospheric temperature
Relative humidity 50%
Reflected temperature 20°C (69°F)
Emissivity 0.95
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Settings) > Device settings > Set up camera
20°C (69°F)
48
Working with measurement tools16
16.5.4 Procedure
You can set the object parameters globally. You can also change the Emissivity, Reflected
temperature, and Object distance parameters locally for a measurement tool.
Local parameters are normally only effective for a fixed setup, where each measurement
tool is set to a specific object of interest. In a general handheld application, the global parameters are usually sufficient.
Note Of the object parameters, Emissivity and Reflected temperature are the two most
important to set correctly in the camera.
16.5.4.1 Setting global parameters
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu. Use the joystick to select one or more of the
global object parameters:
•
(External IR window compensation)
•
(Object distance)
(Atmospheric temperature)
•
•
(Relative humidity)
(Reflected temperature)
•
•
(Emissivity)
4. Push the joystick to display a dialog box.
5. Use the joystick to change the parameter.
6. Push the joystick. This closes the dialog box.
16.5.4.2 Changing local parameters
You can change the local parameters for a measurement tool.
A P next to the measurement tool on the screen indicates that local parameters are acti-
vated for the tool.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now displayed with one or more handles.
2. Push the joystick—or touch and hold the tool. This displays a context menu.
(Measurement parameters).
3. Use the joystick to go to
4. Push the joystick.
5. Push the joystick to activate the use of local parameters.
tor) is displayed together with a submenu.
6. Use the joystick to select an object parameter.
7. Push the joystick to display a dialog box.
8. Use the joystick to change the parameter.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Use local parameters).
(icon with gray indicator) is displayed.
(icon with blue indica-
49
Working with measurement tools16
9. Push the joystick. This closes the dialog box.
10. When completed, push the joystick and select
16.5.5 Related topics
For in-depth information about parameters, and how to correctly set the emissivity and reflected apparent temperature, see section 31 Thermographic measurement techniques,
page 495.
(Done).
16.6 Displaying values in the result table and
displaying a graph
16.6.1 General
For the box, circle, and line tools, you can set the camera to display the maximum, minimum, and average values in the result table.
For the line tool, you can also display a graph.
16.6.2 Procedure
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now displayed with one or more handles.
2. Push the joystick—or touch and hold the tool. This displays a context menu.
3. Use the joystick to go to (depending on the tool)
or (Graph/Max/Min/Avg/Alarm).
4. Push the joystick. This displays a submenu.
, , or (Max/Min/Avg/Alarm)
• (Option available for the line tool.) Select
play a graph.
• Select
• Select
• Select
• (Optional step.) You can choose to show or hide the maximum and minimum
markers (the hot/cold spots). Select
to toggle:
◦ When
◦ When
5. When completed, move the joystick down to close the submenu.
6. Select
(Max) and push the joystick to display the maximum value.
(Min) and push the joystick to display the minimum value.
(Avg) and push the joystick to display the average value.
(icon with grey indicator) is displayed, the markers are hidden.
(icon with blue indicator) is displayed, the markers are shown.
(Done) and push the joystick.
(Graph) and push the joystick to dis-
(Max & min markers) and push the joystick
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
50
Working with measurement tools16
16.7 Creating and setting up a difference
calculation
16.7.1 General
A difference calculation gives the difference between the values of two known measurement results.
16.7.2 Procedure
Note
• You can set up a difference calculation when defining user presets, or when editing an
image in the archive.
• This procedure assumes that you have previously laid out at least one measurement
tool on the screen.
16.7.2.1 Procedure
Follow this procedure:
1. To set up a difference calculation, select
2. Push the joystick. This displays a dialog box where you can select the measurement
tools that you want to use in the difference calculation. You can also select a fixed-temperature reference.
3. Push the joystick. The result of the difference calculation is now displayed on the
screen.
(Add delta).
16.8 Setting a measurement alarm
16.8.1 General
You can make the camera trigger an alarm when certain measurement conditions are met.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
51
Working with measurement tools16
16.8.2 Types of alarm
You can choose between the following alarm types:
• Above: Triggers an alarm when the temperature is above the preset alarm temperature.
• Below: Triggers an alarm when the temperature is below the preset alarm temperature.
16.8.3 Alarm signals
When an alarm is set, the symbol
When an alarm is triggered, the value in the result table is displayed in red (above alarm)
or blue (below alarm) and the symbol
You can also set an audible alarm (there will be a “beep” when the alarm is triggered).
16.8.4 Procedure
There are different procedures for setting up an alarm for a spot, box, circle, or line and for
a difference calculation.
16.8.4.1 Setting up an alarm for a spot
Follow this procedure:
1. To select the spot, touch the tool on the screen. The tool is now displayed with a frame.
2. Push the joystick—or touch and hold the tool. This displays a context menu.
3. Use the joystick to go to
4. Push the joystick. This displays a dialog box where you can define the settings for the
alarm.
• Alarm condition: The condition that triggers the alarm. Applicable values are Above,
Below, or Off.
• Alarm limit: The temperature value that will be the critical condition when an alarm is
triggered or not.
• Alarm sound: Applicable values are Beep or No sound.
5. Push the joystick. This closes the dialog box.
is displayed in the result table.
(above alarm) or (below alarm) is blinking.
(Set alarm on spot).
6. Push the joystick and select
16.8.4.2 Setting up an alarm for a box, circle, or line
Note This procedure assumes that you have previously set the camera to display at least
one value (maximum, minimum, or average) in the result table.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now displayed with one or more handles.
2. Push the joystick—or touch and hold the tool. This displays a context menu.
3. Use the joystick to go to (depending on tool)
(Graph/Max/Min/Avg/Alarm).
4. Push the joystick. This displays a submenu.
5. Select
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Set alarm).
(Done).
, , or (Max/Min/Avg/Alarm) or
52
Working with measurement tools16
6. Push the joystick. This displays a dialog box where you can define the settings for the
alarm.
• Alarm condition: The condition that triggers the alarm. Applicable values are Above,
Below, or Off.
• Select measurement: Applicable settings are the values you have previously de-
fined (Max, Min, and/or Avg).
• Alarm limit: The temperature value that will be the critical condition when an alarm is
triggered or not.
• Alarm sound: Applicable values are Beep or No sound.
7. Push the joystick. This closes the dialog box.
8. Push the joystick and select
16.8.4.3 Setting up an alarm for a difference calculation
Note
• You can set up an alarm for a difference calculation when defining user presets, or
when editing an image in the archive.
• This procedure assumes that you have previously set up a difference calculation.
Follow this procedure:
1. Select
2. Select
3. Select Delta. This displays a context menu.
4. Use the joystick to go to
5. Push the joystick. This displays a dialog box where you can define the settings for the
alarm.
• Alarm condition: The condition that triggers the alarm. Applicable values are Above,
Below, or Off.
• Alarm limit: The temperature value that will be the critical condition when an alarm is
triggered or not.
• Alarm sound: Applicable values are Beep or No sound.
6. Push the joystick. This closes the dialog box.
(Add measurement). This displays a submenu.
(Select). This displays a dialog box.
(Done).
(Set alarm on delta).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
53
17
Fetching data from external FLIR meters
17.1 General
You can fetch data from an external FLIR meter and merge this data into the infrared
image.
When the camera is connected to a FLIR meter via Bluetooth, the measurement value
from the meter is displayed in the result table of the camera. The FLIR meter value is also
added to the information saved in the image file. In preview mode and when editing an image in the archive, you can add more than one value from the same FLIR meter.
Note
• Before you can use a FLIR meter with the camera, you need to pair the devices. For
more information, see 11 Pairing Bluetooth devices, page 23.
• To add more than one FLIR meter value when saving an image, preview mode must be
enabled. Select
In preview mode and when editing an image in the archive, you can do the following:
• Push the programmable button
meter.
• Push and hold the programmable button
image.
Note Any function assigned to the programmable button is temporarily disabled when in
preview mode or when editing an image in the archive.
(Settings) > Save options > Preview image before saving = On.
to add the value currently displayed by the FLIR
to remove all FLIR meter values from the
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
54
17
Fetching data from external FLIR meters
17.4.2 Procedure
Follow this procedure:
1. Use the infrared camera to identify any potential damp areas behind walls and ceilings.
2. Use the moisture meter to measure the moisture levels at various suspect locations
that may have been found.
3. When an area of particular interest is located, store the moisture reading in the moisture meter’s memory and identify the measurement area with a handprint or other thermal identifying marker.
4. Recall the reading from the meter memory. The moisture meter will now continuously
transmit this reading to the infrared camera.
5. Use the camera to take a thermal image of the area with the identifying marker. The
stored data from the moisture meter will also be saved on the image.
17.5 More information
For more information, see the users’ manuals that are shipped with the FLIR meters.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
55
18
Working with color alarms and isotherms
18.1 Color alarms
18.1.1 General
By using color alarms (isotherms), anomalies can easily be discovered in an infrared image. The isotherm command applies a contrasting color to all pixels with a temperature
above, below, or between the set temperature levels. The camera also features isotherm
types that are specific to the building trade: condensation and insulation alarms.
You can make the camera trigger the following types of color alarms:
• Above alarm: This will apply a contrasting color to all pixels with a temperature above
the specified temperature level.
• Below alarm: This will apply a contrasting color to all pixels with a temperature below
the specified temperature level.
• Interval alarm: This will apply a contrasting color to all pixels with a temperature be-
tween two specified temperature levels.
• Condensation alarm: Triggers when the camera detects a surface where the relative hu-
midity exceeds a preset value.
• Insulation alarm: Triggers when there is an insulation deficiency in a wall.
18.1.2 Image examples
This table explains the different color alarms (isotherms).
Color alarm
Above alarm
Below alarm
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
56
Working with color alarms and isotherms18
Color alarm
Interval alarm
Condensation alarm
Insulation alarm
18.2 Setting up above, below, and interval
alarms
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu. Use the joystick to select the type of alarm:
•
(Above alarm)
•
(Below alarm)
(Interval alarm)
•
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Color).
57
Working with color alarms and isotherms18
4. Push the joystick. The threshold temperature is displayed at the bottom of the screen.
5. To change the threshold temperature, do the following:
• For the Interval alarm, move the joystick left/right to select the low/high-temperature
value.
• Move the joystick up/down to change the threshold temperature.
18.3 Building isotherms
Note The Condensation and Insulation alarms are not supported by all camera models.
18.3.1 About the Condensation alarm
To detect areas with potential moisture problems, you can use the Condensation alarm.
You can set the relative humidity above which the isotherm will colorize the image.
18.3.2 About the Insulation alarm
The Insulation alarm can detect areas where there may be an insulation deficiency in the
building. It will trigger when the insulation level (which is called the thermal index in the
camera) falls below a preset value of the energy leakage through a wall.
Different building codes recommend different values for the insulation level, but typical values are 60–80% for new buildings. Refer to your national building code for
recommendations.
18.3.3 Setting up condensation and insulation alarms
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu. Use the joystick to select the type of alarm:
•
(Condensation alarm)
•
(Insulation alarm)
4. Push the joystick. This displays a dialog box where you can define the settings for the
alarm.
For the Condensation alarm, the following parameters can be set:
• Atmospheric temperature: The current atmospheric temperature.
• Relative humidity: The current relative humidity.
• Relative humidity limit: The relative humidity level at which you want the alarm to be
triggered. A relative humidity of 100% means that water vapor condenses from the
air as liquid water (= dewpoint). A relative humidity of about 70% or above can
cause mold.
For the Insulation alarm, the following parameters can be set:
• Indoor temperature: The current indoor temperature.
• Outdoor temperature: The current outdoor temperature.
• Thermal index: The insulation level, an integer between 0 and 100.
5. Push the joystick. This closes the dialog box.
(Color).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
58
19
Annotating images
19.1 General
You can save additional information together with an infrared image by using annotations.
Annotations make reporting and post-processing more efficient, by providing essential information about the image, e.g., conditions and information about where an image is taken.
Annotations are added to the image file, and can be viewed and edited in the image archive, and also when moving files from the camera to reporting software on the computer.
• You can set the camera to display annotation tools before an image is saved. Select
(Settings) > Save options > Add annotation after saving.
• You can also add annotations to a saved image in the image archive.
Note This section describes the procedures for adding annotations to a saved image in
the image archive. Adding annotations when saving an image works in a similar way.
19.2 Adding a note
19.2.1 General
A text note is grouped with the image file. Using this feature, you can annotate images by
entering free-form text.
19.2.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
4. Push the joystick. This displays a soft keyboard where you can enter the text you want
to save.
(Add note).
Note To select special characters, press and hold down the corresponding key on
the soft keyboard.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
59
Annotating images19
5. When completed, touch Done on the soft keyboard.
19.3 Adding a table
19.3.1 General
You can save a table with textual information to the image file. This feature is a very efficient way of recording information when you are inspecting a large number of similar objects. The idea behind using a table with textual information is to avoid filling out forms or
inspection protocols manually.
The camera has a number of default table templates. You can also import your own table
templates from FLIR Tools. The templates are stored on the memory card.
19.3.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
4. Select
5. This displays the default table template that ships with the camera.
Note You can select another template by first selecting
6. For each row in the table, do the following:
• Push the joystick. This displays the predefined values.
• Move the joystick up/down to select a predefined value. Push the joystick to confirm.
• Instead of selecting a predefined value, you can select the keyboard
other text.
7. When completed, select Save & Exit at the bottom of the table. Push the joystick to
confirm.
(Add table) and push the joystick.
(Add table contents) and push the joystick.
(Select default template).
and enter
19.4 Adding a voice annotation
19.4.1 General
A voice annotation is an audio recording that is saved to the infrared image file.
The voice annotation is recorded using a Bluetooth headset. The recording can be played
back in the camera, and in image analysis and reporting software from FLIR Systems.
19.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
4. To start a recording, select
5. To stop the recording, select
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
(Add voice annotation) and push the joystick.
(Record) and push the joystick.
(Stop) and push the joystick.
60
Annotating images19
6. To listen to the recording, select
7. To delete the recording, select
8. When completed, select
(Play) and push the joystick.
(Delete) and push the joystick.
(Done) and push the joystick.
19.5 Adding a sketch
19.5.1 General
You can add a freehand drawing to an image.
19.5.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
4. You are now in sketch mode. Draw the sketch by touching the screen.
5. Push the joystick. This displays a context menu. Do one or more of the following:
• To change the color of the sketch tools, select
lect the color and push the joystick.
• To erase, select (Eraser) and push the joystick. Erase parts of the sketch by
touching the screen.
(Add sketch) and push the joystick.
(Draw) and push the joystick. Se-
• To add an arrow, circle, or cross, select
Select the type of stamp and push the joystick. The stamp is displayed in the center
of the screen. You can move the stamp by touching the screen.
• To clear, select
• When the sketch is completed, select
(Clear all) and push the joystick.
(Stamp sketch) and push the joystick.
(Save) and push the joystick.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
61
20
Programming the camera (time lapse)
20.1 General
You can program the camera to save images periodically (time lapse).
20.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick. This displays a submenu.
4. Select
5. Push the joystick. This displays a dialog box, where you can set the save conditions:
• Save interval: Use the joystick to set the time interval between each saved image.
• Total number of images: Periodic saving will stop when the set number of images
have been saved.
6. Push the joystick. This closes the dialog box. The time interval is displayed at the top
of the screen.
7. To manually start or stop periodic saving, briefly push and release the Autofocus/Save
button.
(Time lapse).
(Recording mode).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
62
21
Recording video clips
21.1 General
You can record and save video clips to the memory card.
Note The camera can be configured to save video in *.mpg or *.csq format. Select
(Settings) > Save options > Video compression.
• Mpeg (*.mpg): Mpeg recordings cannot be edited after the file has been saved.
• Radiometric storage (*csq): A *.csq file supports full radiometry but is only supported
by FLIR Systems software. The file does not include any visual-image information.
21.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick. This displays a submenu.
4. Select
5. Do the following:
• To start a recording, push and release the Autofocus/Save button. A counter at the
top of the screen displays the duration of the recording.
• To stop a recording, push and release the Autofocus/Save button.
6. The recording is automatically saved to the image archive, where you can play or delete it.
(Video) and push the joystick.
(Recording mode).
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
63
22
Screening alarm
22.1 General
The screening alarm can be used, for example, at airports to detect passengers with elevated body temperatures, which may indicate the presence of a fever.
Activating the screening alarm will turn on a measurement box and screening data in the
result table.
The sampled average temperature.
The alarm temperature.
The measured temperature.
The alarm will trigger when the measurement box measures a temperature higher than the
alarm temperature. The alarm temperature is, in turn, the sum of a specified allowed deviation and a sampled average value.
22.2 Procedure
Follow this procedure:
1. Enable the screening mode by selecting
camera > Screening mode = On.
2. Push the joystick to display the menu system.
3. Use the joystick to go to
4. Push the joystick. This displays a submenu.
5. Select
6. Push the joystick. This displays a dialog box where you can define the settings for the
alarm.
• Allowed deviation: The allowed deviation from the sampled average.
• Alarm sound: Applicable values are Beep or No sound.
7. Push the joystick. This closes the dialog box.
8. Aim the camera toward a point of interest. The object should be within the frame of the
measurement box.
9. Push and hold the programmable button
10. Push the programmable button
11. Aim the camera toward more points of interest. Sample 10 times to build up a sample
base by pushing the programmable button
The alarm is now set up and ready to use. Occasionally record a few samples if the
alarm is used for a long time or if the conditions change.
Note
• The algorithm has a memory of the last 10 samples. It discriminates between the high-
est and lowest values, and calculates an average of the remaining values.
• Do not modify the measurement setup or activate another alarm because this will deac-
tivate the screening alarm.
(Screening).
(Recording mode).
to sample.
(Settings) > Device settings > Set up
to reset the sampled average.
.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
64
23
Changing settings
23.1 General
The Settings menu includes the following:
• Define user presets
• Save options
• Programmable button
• Reset options
• Device settings
23.1.1 Define user presets
• Define preset 1
• Define preset 2
23.1.2 Save options
• Preview image before saving
• Add annotation after saving
• Image resolution
• Video compression
• Photo as separate JPEG
23.1.3 Programmable button
• No action
• Hide graphics
• Calibrate
• Switch Thermal <> Digital camera
• Switch Thermal <> Thermal MSX
• Switch 1x zoom <> Max zoom
• Switch between two latest palettes
• Switch temperature range
• Continuous autofocus
23.1.4 Reset options
• Reset default camera mode...
• Reset device settings to factory default...
• Delete all saved images...
Note When an option is selected, a dialog box is displayed with more information. You
can choose to execute the reset/delete action or to cancel.
23.1.5 Device settings
• Set up camera
◦ Camera temperature range: The temperature range used for measuring objects. You
must change the temperature range according to the expected temperature of the
object you are inspecting.
◦ Auto orientation
◦ Continuous autofocus
◦ Display intensity
◦ Lamp & laser
◦ Viewfinder intensity
◦ HDMI
◦ Emissivity mode
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
65
23
Changing settings
• Wi-Fi: For more information, see 12 Configuring Wi-Fi, page 24.
• GPS & compass
• Bluetooth including METERLiNK: For more information, see 11 Pairing Bluetooth devi-
ces, page 23.
• Language, time & units
• Camera information: Information about the model, serial number, part number, and software versions. No changes can be made.
23.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display the Settings menu.
4. Use the joystick to select the setting you want to change.
5. To exit the Settings menu or a submenu, push the Back button
(Settings).
.
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
66
24
Technical data
Table of contents
24.1 Online field-of-view calculator............................................................. 68
24.2 Note about technical data ................................................................... 68
24.3 Note about authoritative versions........................................................ 68
24.4 FLIR T600 15° (incl. Wi-Fi and Ext. cal.) ................................................ 69
24.5 FLIR T600 15° (incl. Wi-Fi)................................................................... 75
24.6 FLIR T600 25° (incl. Wi-Fi and Ext. cal.) ................................................ 81
24.7 FLIR T600 25° (incl. Wi-Fi)................................................................... 87
24.8 FLIR T600 25° and 15° w/case ............................................................. 93
24.9 FLIR T600 25° and 45° w/case ............................................................. 99
24.10 FLIR T600 45° (incl. Wi-Fi and Ext. cal.) .............................................. 105
24.11 FLIR T600 45° (incl. Wi-Fi)................................................................. 111
24.12 FLIR T600bx 25° (incl. Wi-Fi and Ext. cal.) ........................................... 117
24.13 FLIR T600bx 25° (incl. Wi-Fi) ............................................................. 123
24.14 FLIR T600bx 45° (incl. Wi-Fi and Ext. cal.) ........................................... 129
24.15 FLIR T600bx 45° (incl. Wi-Fi) ............................................................. 135
24.16 FLIR T610 15° (incl. Wi-Fi)................................................................. 141
24.17 FLIR T610 25° (incl. Wi-Fi)................................................................. 147
24.18 FLIR T610 45° (incl. Wi-Fi)................................................................. 153
24.19 FLIR T620 15° (incl. Wi-Fi and Ext. cal.) .............................................. 159
24.20 FLIR T620 15° (incl. Wi-Fi)................................................................. 165
24.21 FLIR T620 25° (incl. Wi-Fi and Ext. cal.) .............................................. 171
24.22 FLIR T620 25° (incl. Wi-Fi)................................................................. 177
24.23 FLIR T620 25° and 15° (incl. Wi-Fi) ..................................................... 183
24.24 FLIR T620 25° and 45° (incl. Wi-Fi) ..................................................... 189
24.25 FLIR T620 45° (incl. Wi-Fi and Ext. cal.) .............................................. 195
24.26 FLIR T620 45° (incl. Wi-Fi)................................................................. 201
24.27 FLIR T620bx 15° (incl. Wi-Fi and Ext. cal.) ........................................... 207
24.28 FLIR T620bx 15° (incl. Wi-Fi) ............................................................. 213
24.29 FLIR T620bx 25° (incl. Wi-Fi and Ext. cal.) ........................................... 219
24.30 FLIR T620bx 25° (incl. Wi-Fi) ............................................................. 225
24.31 FLIR T620bx 45° (incl. Wi-Fi and Ext. cal.) ........................................... 231
24.32 FLIR T620bx 45° (incl. Wi-Fi) ............................................................. 237
24.33 FLIR T630 15° (incl. Wi-Fi)................................................................. 243
24.34 FLIR T630 25° (incl. Wi-Fi)................................................................. 249
24.35 FLIR T630 45° (incl. Wi-Fi)................................................................. 255
24.36 FLIR T630sc 15° (incl. Wi-Fi) ............................................................. 261
24.37 FLIR T630sc 25° (incl. Wi-Fi) ............................................................. 267
24.38 FLIR T630sc 25° and 45° w/case ........................................................ 273
24.39 FLIR T630sc 45° (incl. Wi-Fi) ............................................................. 279
24.40 FLIR T640 15° (incl. Wi-Fi and Ext. cal.) .............................................. 285
24.41 FLIR T640 15° (incl. Wi-Fi)................................................................. 292
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
67
Technical data24
24.4 FLIR T600 15° (incl. Wi-Fi and Ext. cal.)
P/N: 55903-1015
Rev.: 43545
General description
The FLIR T600 is designed for the expert requiring the highest performance and the latest technology
available. The camera combines excellent ergonomics and a walk-up-and-use interface with superior image quality of 480 × 360 pixel infrared resolution. The FLIR T600 is flexible and can meet your every need,
and has extensive communication options.
Benefits:
• Highest performance with the latest technology: The FLIR T600 is equipped with the innovative Multi
Spectral Dynamic Imaging (MSX) feature, which produces an image richer in detail than ever before.
• Ground-breaking efficiency: You can highlight objects of interest, on both the infrared and the visual
images, by sketching or adding predefined stamps directly onto the camera’s capacitive touch screen.
The user interface is intuitive and logical for effective operation. Auto-orientation allows you to tilt between landscape and portrait views.
• Extensive communication options: The Wi-Fi connectivity of the FLIR T600 allows you to connect to
smart phones or tables for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments to
the infrared image.
Imaging and optical data
IR resolution 480 × 360 pixels
UltraMax No
Thermal sensitivity/NETD <40 mK @ +30°C (+86°F)
Field of view (FOV)
Minimum focus distance 0.5 m (1.64 ft.)
Focal length 41 mm (1.63 in.)
Spatial resolution (IFOV) 0.55 mrad
Lens identification Automatic
F-number 1.0
Image frequency 30 Hz
Focus Automatic (one shot) or manual
Digital zoom 1–4× continuous
Digital image enhancement Adaptive digital noise reduction
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
Detector pitch 17 µm
Image presentation
Display Built-in touch screen, 4.3 in. wide screen LCD, 800
Display type Capacitive touch screen
Auto orientation Automatic landscape or portrait
15° × 11°
7.5–14 µm
× 480 pixels
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
69
Technical data24
Image presentation
Automatic image adjustment Continuous, histogram based
Manual image adjustment
Image presentation modes
Infrared image Full-color IR image
Visual image Full color visual image
Thermal MSX Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
Measurement
Object temperature range
Accuracy ±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
Linear based; possible to adjust level/span/max./
min.
• –40°C to +150°C (–40°F to +302°F)
• +100°C to +650°C (+212°F to +1202°F)
(77°F) nominal.
Measurement analysis
Spotmeter
Area 5 + 5 areas (boxes or circles) with max./min./aver-
Automatic hot/cold detection
Measurement presets No measurements, Center spot, Hot spot, Cold
User presets (in live images) The user can select and combine measurements
Difference temperature Delta temperature between measurement func-
Reference temperature Manually set using difference temperature
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0 or selected from materials
Emissivity table Emissivity table of predefined materials
Reflected apparent temperature correction Automatic, based on input of reflected temperature
External optics/windows correction Automatic, based on inputs of window transmis-
Measurement corrections Emissivity, reflected temperature, relative humidity,
Colors (palettes) Iron, Rainbow, Rainbow HC, White hot, Black hot,
10
age (in post-acquisition analysis)
Auto hot or cold spotmeter markers within area
spot, User preset 1, User preset 2
from any number of available spots/boxes/circles/
delta
tions or reference temperature
pheric temperature and relative humidity
list
sion and temperature
atmospheric temperature, object distance, external
IR window compensation
Arctic, Lava
Alarm
Color Alarm (isotherm) Above/below/interval
Measurement function alarm Audible/visual alarms (above/below) on any se-
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
lected measurement function
70
Technical data24
Set-up
Set-up commands Define user presets, Save options, Programmable
Service functions
Camera software update Use PC software FLIR Tools
Storage of images
Image storage Standard JPEG, including digital photo and meas-
Storage media Removable memory SD card
Image storage mode
Time lapse 15 seconds to 24 hours
File formats Standard JPEG, measurement data included
File formats, visual Standard JPEG, automatically associated with cor-
button, Reset options, Set up camera, Wi-Fi, Bluetooth, Language, Time & units, Camera
information
urement data, on memory card
• Simultaneous storage of thermal and digital
photo in same JPEG file.
• Optional to store digital photo as a separate
JPEG file.
responding thermal image
Image annotations (in still images)
Voice 60 seconds (via Bluetooth) stored with the image
Text Add table. Select between predefined templates or
Image description Add short note (stored in JPEG EXIF tag)
Sketch Draw on thermal/digital photo or add predefined
METERLiNK Wireless connection (Bluetooth) to:
Report generation
Video recording in camera
Non-radiometric IR video recording MPEG-4 to memory card
Visual video recording MPEG-4 to memory card
Video streaming
Radiometric IR video streaming
Non-radiometric IR video streaming
Visual video streaming
create your own in FLIR Tools
stamps
FLIR meters with METERLiNK
• Separate PC software with extensive report
generation
Full dynamic to PC using USB or to mobile devices
using Wi-Fi.
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
71
Technical data24
Digital camera
Built-in digital camera 5 Mpixels with LED light (photo as separate image)
Digital camera, FOV Adapts to the IR lens
Video lamp Built-in LED light
Laser pointer
Laser Activated by dedicated button
Laser alignment Position is automatic displayed on the IR image
Laser classification Class 2
Laser type Semiconductor AlGaInP diode laser, 1 mW, 635
Data communication interfaces
Interfaces USB-mini, USB-A, Bluetooth, Wi-Fi, Digital Video
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
nm (red)
Output
USB
USB
USB, standard USB 2.0 high speed
Video output
Video out Digital video output (DVI)
Video, connector type HDMI compatible
Radio
Wi-Fi
METERLiNK/Bluetooth Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery operating time > 2.5 hours at 25°C (+68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
Charging time
Charging temperature 0°C to +45°C (+32°F to +113°F)
External power operation AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / uncompressed colorized video
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
bay charger
2.5 h to 90 % capacity, charging status indicated
by LED's
vehicle (cable with standard plug, optional)
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
72
Technical data24
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
EMC
Radio spectrum
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety EN/UL/CSA/PSE 60950-1
to +40°C (+77°F to +104°F) / 2 cycles
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
• ICES-003
• ETSI EN 300 328
• FCC Part 15.247
• RSS-247 Issue 2
Physical data
Weight 1.3 kg (2.87 lb.)
Camera size, excl. lens (L × W × H) 143 × 195 × 95 mm (5.6 × 7.7 × 3.7 in.)
Tripod mounting UNC ¼"-20
Housing material Magnesium
Shipping information
Packaging, type Cardboard box
List of contents
Packaging, weight 6.6 kg (14.6 lb.)
Packaging, size 495 × 192 × 370 mm (19.49 × 7.56 × 14.57 in.)
EAN-13 7332558011867
UPC-12
Country of origin Sweden
• Infrared camera with lens
• Battery (2 ea.)
• Battery charger
• Bluetooth headset
• Calibration certificate
• Extended calibration certificate
• HDMI-DVI cable
• HDMI-HDMI cable
• Hard transport case
• Lens cap
• Memory card
• Neck strap
• Power supply, incl. multi-plugs
• Printed documentation
• Tripod adapter
• USB cable, Std A to Mini-B
845188012977
Supplies & accessories:
• T197914; IR lens, f=41.3 mm (15°) with case
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
73
Technical data24
• T197922; IR lens, f=24.6 mm (25°) with case
• T197915; IR lens, f=13.1 mm (45°) with case
• T198059; Close-up IR lens, 2.9× (50 µm) with case
• T198060; Close-up IR lens, 5.8× (100 µm) with case
• T198166; IR lens, f=88.9 mm (7°) with case and support for T6xx
• T198065; IR lens, f=6.5 mm (80°) with case
• T198066; Close-up IR lens, 1.5× (25 µm) with case
• T197896; High temperature option +300°C to 2000°C (+572°F to 3632°F)
• T910814; Power supply, incl. multi plugs
• T198126; Battery charger, incl. power supply with multi plugs T6xx
• T199406ACC; Battery Li-ion 3.7 V, 7.8 Ah, 29 Wh
• T911650ACC; Memory card SD Card 8 GB
• 1910423; USB cable Std A <-> Mini-B
• T198509; Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft.
• T910930ACC; HDMI type C to DVI cable 1.5 m
• T910891ACC; HDMI type C to HDMI type A cable 1.5 m
• T198625ACC; Hard transport case
• T198495; Pouch
• T198497; Large eyecup
• T198498; Tripod Adapter
• T198499; Neck strap
• T197771ACC; Bluetooth Headset
• T911093; Tool belt
• 19250-100; IR Window 2 in
• 19251-100; IR Window 3 in.
• 19252-100; IR Window 4 in.
• 19250-200; SS IR Window 2 in.
• 19251-200; SS IR Window 3 in.
• 19252-200; SS IR Window 4 in.
• T198496; Stylus pen
• T198586; FLIR Reporter Professional (license only)
• T198584; FLIR Tools
• T198583; FLIR Tools+ (download card incl. license key)
• DSW-10000; FLIR IR Camera Player
• APP-10002; FLIR Tools Mobile (Android Application)
• APP-10004; FLIR Tools (MacOS Application)
• T198697; FLIR ResearchIR Max + HSDR 4 (hardware sec. dev.)
• T199014; FLIR ResearchIR Max + HSDR 4 (printed license key)
• T199044; FLIR ResearchIR Max + HSDR 4 Upgrade (printed license key)
• T198696; FLIR ResearchIR Max 4 (hardware sec. dev.)
• T199013; FLIR ResearchIR Max 4 (printed license key)
• T199043; FLIR ResearchIR Max 4 Upgrade (printed license key)
• T198731; FLIR ResearchIR Standard 4 (hardware sec. dev.)
• T199012; FLIR ResearchIR Standard 4 (printed license key)
• T199042; FLIR ResearchIR Standard 4 Upgrade (printed license key)
• T199233; FLIR Atlas SDK for .NET
• T199234; FLIR Atlas SDK for MATLAB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
74
Technical data24
24.5 FLIR T600 15° (incl. Wi-Fi)
P/N: 55903-0922
Rev.: 43545
General description
The FLIR T600 is designed for the expert requiring the highest performance and the latest technology
available. The camera combines excellent ergonomics and a walk-up-and-use interface with superior image quality of 480 × 360 pixel infrared resolution. The FLIR T600 is flexible and can meet your every need,
and has extensive communication options.
Benefits:
• Highest performance with the latest technology: The FLIR T600 is equipped with the innovative Multi
Spectral Dynamic Imaging (MSX) feature, which produces an image richer in detail than ever before.
• Ground-breaking efficiency: You can highlight objects of interest, on both the infrared and the visual
images, by sketching or adding predefined stamps directly onto the camera’s capacitive touch screen.
The user interface is intuitive and logical for effective operation. Auto-orientation allows you to tilt between landscape and portrait views.
• Extensive communication options: The Wi-Fi connectivity of the FLIR T600 allows you to connect to
smart phones or tables for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments to
the infrared image.
Imaging and optical data
IR resolution 480 × 360 pixels
UltraMax No
Thermal sensitivity/NETD <40 mK @ +30°C (+86°F)
Field of view (FOV)
Minimum focus distance 0.5 m (1.64 ft.)
Focal length 41 mm (1.63 in.)
Spatial resolution (IFOV) 0.55 mrad
Lens identification Automatic
F-number 1.0
Image frequency 30 Hz
Focus Automatic (one shot) or manual
Digital zoom 1–4× continuous
Digital image enhancement Adaptive digital noise reduction
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
Detector pitch 17 µm
Image presentation
Display Built-in touch screen, 4.3 in. wide screen LCD, 800
Display type Capacitive touch screen
Auto orientation Automatic landscape or portrait
15° × 11°
7.5–14 µm
× 480 pixels
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
75
Technical data24
Image presentation
Automatic image adjustment Continuous, histogram based
Manual image adjustment
Image presentation modes
Infrared image Full-color IR image
Visual image Full color visual image
Thermal MSX Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
Measurement
Object temperature range
Accuracy ±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
Linear based; possible to adjust level/span/max./
min.
• –40°C to +150°C (–40°F to +302°F)
• +100°C to +650°C (+212°F to +1202°F)
(77°F) nominal.
Measurement analysis
Spotmeter
Area 5 + 5 areas (boxes or circles) with max./min./aver-
Automatic hot/cold detection
Measurement presets No measurements, Center spot, Hot spot, Cold
User presets (in live images) The user can select and combine measurements
Difference temperature Delta temperature between measurement func-
Reference temperature Manually set using difference temperature
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0 or selected from materials
Emissivity table Emissivity table of predefined materials
Reflected apparent temperature correction Automatic, based on input of reflected temperature
External optics/windows correction Automatic, based on inputs of window transmis-
Measurement corrections Emissivity, reflected temperature, relative humidity,
Colors (palettes) Iron, Rainbow, Rainbow HC, White hot, Black hot,
10
age (in post-acquisition analysis)
Auto hot or cold spotmeter markers within area
spot, User preset 1, User preset 2
from any number of available spots/boxes/circles/
delta
tions or reference temperature
pheric temperature and relative humidity
list
sion and temperature
atmospheric temperature, object distance, external
IR window compensation
Arctic, Lava
Alarm
Color Alarm (isotherm) Above/below/interval
Measurement function alarm Audible/visual alarms (above/below) on any se-
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
lected measurement function
76
Technical data24
Set-up
Set-up commands Define user presets, Save options, Programmable
Service functions
Camera software update Use PC software FLIR Tools
Storage of images
Image storage Standard JPEG, including digital photo and meas-
Storage media Removable memory SD card
Image storage mode
Time lapse 15 seconds to 24 hours
File formats Standard JPEG, measurement data included
File formats, visual Standard JPEG, automatically associated with cor-
button, Reset options, Set up camera, Wi-Fi, Bluetooth, Language, Time & units, Camera
information
urement data, on memory card
• Simultaneous storage of thermal and digital
photo in same JPEG file.
• Optional to store digital photo as a separate
JPEG file.
responding thermal image
Image annotations (in still images)
Voice 60 seconds (via Bluetooth) stored with the image
Text Add table. Select between predefined templates or
Image description Add short note (stored in JPEG EXIF tag)
Sketch Draw on thermal/digital photo or add predefined
METERLiNK Wireless connection (Bluetooth) to:
Report generation
Video recording in camera
Non-radiometric IR video recording MPEG-4 to memory card
Visual video recording MPEG-4 to memory card
Video streaming
Radiometric IR video streaming
Non-radiometric IR video streaming
Visual video streaming
create your own in FLIR Tools
stamps
FLIR meters with METERLiNK
• Separate PC software with extensive report
generation
Full dynamic to PC using USB or to mobile devices
using Wi-Fi.
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
77
Technical data24
Digital camera
Built-in digital camera 5 Mpixels with LED light (photo as separate image)
Digital camera, FOV Adapts to the IR lens
Video lamp Built-in LED light
Laser pointer
Laser Activated by dedicated button
Laser alignment Position is automatic displayed on the IR image
Laser classification Class 2
Laser type Semiconductor AlGaInP diode laser, 1 mW, 635
Data communication interfaces
Interfaces USB-mini, USB-A, Bluetooth, Wi-Fi, Digital Video
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
nm (red)
Output
USB
USB
USB, standard USB 2.0 high speed
Video output
Video out Digital video output (DVI)
Video, connector type HDMI compatible
Radio
Wi-Fi
METERLiNK/Bluetooth Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery operating time > 2.5 hours at 25°C (+68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
Charging time
Charging temperature 0°C to +45°C (+32°F to +113°F)
External power operation AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / uncompressed colorized video
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
bay charger
2.5 h to 90 % capacity, charging status indicated
by LED's
vehicle (cable with standard plug, optional)
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
78
Technical data24
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
EMC
Radio spectrum
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety EN/UL/CSA/PSE 60950-1
to +40°C (+77°F to +104°F) / 2 cycles
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
• ICES-003
• ETSI EN 300 328
• FCC Part 15.247
• RSS-247 Issue 2
Physical data
Weight 1.3 kg (2.87 lb.)
Camera size, excl. lens (L × W × H) 143 × 195 × 95 mm (5.6 × 7.7 × 3.7 in.)
Tripod mounting UNC ¼"-20
Housing material Magnesium
Shipping information
Packaging, type Cardboard box
List of contents
Packaging, weight 6.6 kg (14.6 lb.)
Packaging, size 495 × 192 × 370 mm (19.49 × 7.56 × 14.57 in.)
EAN-13 7332558006641
UPC-12
Country of origin Sweden
• Infrared camera with lens
• Battery (2 ea.)
• Battery charger
• Bluetooth headset
• Calibration certificate
• Printed documentation
• HDMI-DVI cable
• HDMI-HDMI cable
• Hard transport case
• Lens cap
• Memory card
• Neck strap
• Power supply, incl. multi-plugs
• Tripod adapter
• USB cable, Std A to Mini-B
845188006990
Supplies & accessories:
• T197914; IR lens, f=41.3 mm (15°) with case
• T197922; IR lens, f=24.6 mm (25°) with case
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
79
Technical data24
• T197915; IR lens, f=13.1 mm (45°) with case
• T198059; Close-up IR lens, 2.9× (50 µm) with case
• T198060; Close-up IR lens, 5.8× (100 µm) with case
• T198166; IR lens, f=88.9 mm (7°) with case and support for T6xx
• T198065; IR lens, f=6.5 mm (80°) with case
• T198066; Close-up IR lens, 1.5× (25 µm) with case
• T197896; High temperature option +300°C to 2000°C (+572°F to 3632°F)
• T910814; Power supply, incl. multi plugs
• T198126; Battery charger, incl. power supply with multi plugs T6xx
• T199406ACC; Battery Li-ion 3.7 V, 7.8 Ah, 29 Wh
• T911650ACC; Memory card SD Card 8 GB
• 1910423; USB cable Std A <-> Mini-B
• T198509; Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft.
• T910930ACC; HDMI type C to DVI cable 1.5 m
• T910891ACC; HDMI type C to HDMI type A cable 1.5 m
• T198625ACC; Hard transport case
• T198495; Pouch
• T198497; Large eyecup
• T198498; Tripod Adapter
• T198499; Neck strap
• T197771ACC; Bluetooth Headset
• T911093; Tool belt
• 19250-100; IR Window 2 in
• 19251-100; IR Window 3 in.
• 19252-100; IR Window 4 in.
• 19250-200; SS IR Window 2 in.
• 19251-200; SS IR Window 3 in.
• 19252-200; SS IR Window 4 in.
• T198496; Stylus pen
• T198586; FLIR Reporter Professional (license only)
• T198584; FLIR Tools
• T198583; FLIR Tools+ (download card incl. license key)
• DSW-10000; FLIR IR Camera Player
• APP-10002; FLIR Tools Mobile (Android Application)
• APP-10004; FLIR Tools (MacOS Application)
• T198697; FLIR ResearchIR Max + HSDR 4 (hardware sec. dev.)
• T199014; FLIR ResearchIR Max + HSDR 4 (printed license key)
• T199044; FLIR ResearchIR Max + HSDR 4 Upgrade (printed license key)
• T198696; FLIR ResearchIR Max 4 (hardware sec. dev.)
• T199013; FLIR ResearchIR Max 4 (printed license key)
• T199043; FLIR ResearchIR Max 4 Upgrade (printed license key)
• T198731; FLIR ResearchIR Standard 4 (hardware sec. dev.)
• T199012; FLIR ResearchIR Standard 4 (printed license key)
• T199042; FLIR ResearchIR Standard 4 Upgrade (printed license key)
• T199233; FLIR Atlas SDK for .NET
• T199234; FLIR Atlas SDK for MATLAB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
80
Technical data24
24.6 FLIR T600 25° (incl. Wi-Fi and Ext. cal.)
P/N: 55903-1016
Rev.: 43545
General description
The FLIR T600 is designed for the expert requiring the highest performance and the latest technology
available. The camera combines excellent ergonomics and a walk-up-and-use interface with superior image quality of 480 × 360 pixel infrared resolution. The FLIR T600 is flexible and can meet your every need,
and has extensive communication options.
Benefits:
• Highest performance with the latest technology: The FLIR T600 is equipped with the innovative Multi
Spectral Dynamic Imaging (MSX) feature, which produces an image richer in detail than ever before.
• Ground-breaking efficiency: You can highlight objects of interest, on both the infrared and the visual
images, by sketching or adding predefined stamps directly onto the camera’s capacitive touch screen.
The user interface is intuitive and logical for effective operation. Auto-orientation allows you to tilt between landscape and portrait views.
• Extensive communication options: The Wi-Fi connectivity of the FLIR T600 allows you to connect to
smart phones or tables for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments to
the infrared image.
Imaging and optical data
IR resolution 480 × 360 pixels
UltraMax No
Thermal sensitivity/NETD <40 mK @ +30°C (+86°F)
Field of view (FOV)
Minimum focus distance 0.25 m (0.82 ft.)
Focal length 25 mm (0.97 in.)
Spatial resolution (IFOV) 0.92 mrad
Lens identification Automatic
F-number 1.0
Image frequency 30 Hz
Focus Automatic (one shot) or manual
Digital zoom 1–4× continuous
Digital image enhancement Adaptive digital noise reduction
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
Detector pitch 17 µm
Image presentation
Display Built-in touch screen, 4.3 in. wide screen LCD, 800
Display type Capacitive touch screen
Auto orientation Automatic landscape or portrait
25° × 19°
7.5–14 µm
× 480 pixels
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
81
Technical data24
Image presentation
Automatic image adjustment Continuous, histogram based
Manual image adjustment
Image presentation modes
Infrared image Full-color IR image
Visual image Full color visual image
Thermal MSX Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
Measurement
Object temperature range
Accuracy ±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
Linear based; possible to adjust level/span/max./
min.
• –40°C to +150°C (–40°F to +302°F)
• +100°C to +650°C (+212°F to +1202°F)
(77°F) nominal.
Measurement analysis
Spotmeter
Area 5 + 5 areas (boxes or circles) with max./min./aver-
Automatic hot/cold detection
Measurement presets No measurements, Center spot, Hot spot, Cold
User presets (in live images) The user can select and combine measurements
Difference temperature Delta temperature between measurement func-
Reference temperature Manually set using difference temperature
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0 or selected from materials
Emissivity table Emissivity table of predefined materials
Reflected apparent temperature correction Automatic, based on input of reflected temperature
External optics/windows correction Automatic, based on inputs of window transmis-
Measurement corrections Emissivity, reflected temperature, relative humidity,
Colors (palettes) Iron, Rainbow, Rainbow HC, White hot, Black hot,
10
age (in post-acquisition analysis)
Auto hot or cold spotmeter markers within area
spot, User preset 1, User preset 2
from any number of available spots/boxes/circles/
delta
tions or reference temperature
pheric temperature and relative humidity
list
sion and temperature
atmospheric temperature, object distance, external
IR window compensation
Arctic, Lava
Alarm
Color Alarm (isotherm) Above/below/interval
Measurement function alarm Audible/visual alarms (above/below) on any se-
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
lected measurement function
82
Technical data24
Set-up
Set-up commands Define user presets, Save options, Programmable
Service functions
Camera software update Use PC software FLIR Tools
Storage of images
Image storage Standard JPEG, including digital photo and meas-
Storage media Removable memory SD card
Image storage mode
Time lapse 15 seconds to 24 hours
File formats Standard JPEG, measurement data included
File formats, visual Standard JPEG, automatically associated with cor-
button, Reset options, Set up camera, Wi-Fi, Bluetooth, Language, Time & units, Camera
information
urement data, on memory card
• Simultaneous storage of thermal and digital
photo in same JPEG file.
• Optional to store digital photo as a separate
JPEG file.
responding thermal image
Image annotations (in still images)
Voice 60 seconds (via Bluetooth) stored with the image
Text Add table. Select between predefined templates or
Image description Add short note (stored in JPEG EXIF tag)
Sketch Draw on thermal/digital photo or add predefined
METERLiNK Wireless connection (Bluetooth) to:
Report generation
Video recording in camera
Non-radiometric IR video recording MPEG-4 to memory card
Visual video recording MPEG-4 to memory card
Video streaming
Radiometric IR video streaming
Non-radiometric IR video streaming
Visual video streaming
create your own in FLIR Tools
stamps
FLIR meters with METERLiNK
• Separate PC software with extensive report
generation
Full dynamic to PC using USB or to mobile devices
using Wi-Fi.
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
83
Technical data24
Digital camera
Built-in digital camera 5 Mpixels with LED light (photo as separate image)
Digital camera, FOV Adapts to the IR lens
Video lamp Built-in LED light
Laser pointer
Laser Activated by dedicated button
Laser alignment Position is automatic displayed on the IR image
Laser classification Class 2
Laser type Semiconductor AlGaInP diode laser, 1 mW, 635
Data communication interfaces
Interfaces USB-mini, USB-A, Bluetooth, Wi-Fi, Digital Video
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
nm (red)
Output
USB
USB
USB, standard USB 2.0 high speed
Video output
Video out Digital video output (DVI)
Video, connector type HDMI compatible
Radio
Wi-Fi
METERLiNK/Bluetooth Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery operating time > 2.5 hours at 25°C (+68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
Charging time
Charging temperature 0°C to +45°C (+32°F to +113°F)
External power operation AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / uncompressed colorized video
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
bay charger
2.5 h to 90 % capacity, charging status indicated
by LED's
vehicle (cable with standard plug, optional)
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
84
Technical data24
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
EMC
Radio spectrum
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety EN/UL/CSA/PSE 60950-1
to +40°C (+77°F to +104°F) / 2 cycles
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
• ICES-003
• ETSI EN 300 328
• FCC Part 15.247
• RSS-247 Issue 2
Physical data
Weight 1.3 kg (2.87 lb.)
Camera size, excl. lens (L × W × H) 143 × 195 × 95 mm (5.6 × 7.7 × 3.7 in.)
Tripod mounting UNC ¼"-20
Housing material Magnesium
Shipping information
Packaging, type Cardboard box
List of contents
Packaging, weight 6.6 kg (14.6 lb.)
Packaging, size 495 × 192 × 370 mm (19.49 × 7.56 × 14.57 in.)
EAN-13 7332558011874
UPC-12
Country of origin Sweden
• Infrared camera with lens
• Battery (2 ea.)
• Battery charger
• Bluetooth headset
• Calibration certificate
• Extended calibration certificate
• HDMI-DVI cable
• HDMI-HDMI cable
• Hard transport case
• Lens cap
• Memory card
• Neck strap
• Power supply, incl. multi-plugs
• Printed documentation
• Tripod adapter
• USB cable, Std A to Mini-B
845188012984
Supplies & accessories:
• T197914; IR lens, f=41.3 mm (15°) with case
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
85
Technical data24
• T197922; IR lens, f=24.6 mm (25°) with case
• T197915; IR lens, f=13.1 mm (45°) with case
• T198059; Close-up IR lens, 2.9× (50 µm) with case
• T198060; Close-up IR lens, 5.8× (100 µm) with case
• T198166; IR lens, f=88.9 mm (7°) with case and support for T6xx
• T198065; IR lens, f=6.5 mm (80°) with case
• T198066; Close-up IR lens, 1.5× (25 µm) with case
• T197896; High temperature option +300°C to 2000°C (+572°F to 3632°F)
• T910814; Power supply, incl. multi plugs
• T198126; Battery charger, incl. power supply with multi plugs T6xx
• T199406ACC; Battery Li-ion 3.7 V, 7.8 Ah, 29 Wh
• T911650ACC; Memory card SD Card 8 GB
• 1910423; USB cable Std A <-> Mini-B
• T198509; Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft.
• T910930ACC; HDMI type C to DVI cable 1.5 m
• T910891ACC; HDMI type C to HDMI type A cable 1.5 m
• T198625ACC; Hard transport case
• T198495; Pouch
• T198497; Large eyecup
• T198498; Tripod Adapter
• T198499; Neck strap
• T197771ACC; Bluetooth Headset
• T911093; Tool belt
• 19250-100; IR Window 2 in
• 19251-100; IR Window 3 in.
• 19252-100; IR Window 4 in.
• 19250-200; SS IR Window 2 in.
• 19251-200; SS IR Window 3 in.
• 19252-200; SS IR Window 4 in.
• T198496; Stylus pen
• T198586; FLIR Reporter Professional (license only)
• T198584; FLIR Tools
• T198583; FLIR Tools+ (download card incl. license key)
• DSW-10000; FLIR IR Camera Player
• APP-10002; FLIR Tools Mobile (Android Application)
• APP-10004; FLIR Tools (MacOS Application)
• T198697; FLIR ResearchIR Max + HSDR 4 (hardware sec. dev.)
• T199014; FLIR ResearchIR Max + HSDR 4 (printed license key)
• T199044; FLIR ResearchIR Max + HSDR 4 Upgrade (printed license key)
• T198696; FLIR ResearchIR Max 4 (hardware sec. dev.)
• T199013; FLIR ResearchIR Max 4 (printed license key)
• T199043; FLIR ResearchIR Max 4 Upgrade (printed license key)
• T198731; FLIR ResearchIR Standard 4 (hardware sec. dev.)
• T199012; FLIR ResearchIR Standard 4 (printed license key)
• T199042; FLIR ResearchIR Standard 4 Upgrade (printed license key)
• T199233; FLIR Atlas SDK for .NET
• T199234; FLIR Atlas SDK for MATLAB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
86
Technical data24
24.7 FLIR T600 25° (incl. Wi-Fi)
P/N: 55903-1022
Rev.: 43545
General description
The FLIR T600 is designed for the expert requiring the highest performance and the latest technology
available. The camera combines excellent ergonomics and a walk-up-and-use interface with superior image quality of 480 × 360 pixel infrared resolution. The FLIR T600 is flexible and can meet your every need,
and has extensive communication options.
Benefits:
• Highest performance with the latest technology: The FLIR T600 is equipped with the innovative Multi
Spectral Dynamic Imaging (MSX) feature, which produces an image richer in detail than ever before.
• Ground-breaking efficiency: You can highlight objects of interest, on both the infrared and the visual
images, by sketching or adding predefined stamps directly onto the camera’s capacitive touch screen.
The user interface is intuitive and logical for effective operation. Auto-orientation allows you to tilt between landscape and portrait views.
• Extensive communication options: The Wi-Fi connectivity of the FLIR T600 allows you to connect to
smart phones or tables for the wireless transfer of images or the remote control of the camera. The
Bluetooth-based METERLiNK function transfers readings from external measurement instruments to
the infrared image.
Imaging and optical data
IR resolution 480 × 360 pixels
UltraMax No
Thermal sensitivity/NETD <40 mK @ +30°C (+86°F)
Field of view (FOV)
Minimum focus distance 0.25 m (0.82 ft.)
Focal length 25 mm (0.97 in.)
Spatial resolution (IFOV) 0.92 mrad
Lens identification Automatic
F-number 1.0
Image frequency 30 Hz
Focus Automatic (one shot) or manual
Digital zoom 1–4× continuous
Digital image enhancement Adaptive digital noise reduction
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
Detector pitch 17 µm
Image presentation
Display Built-in touch screen, 4.3 in. wide screen LCD, 800
Display type Capacitive touch screen
Auto orientation Automatic landscape or portrait
25° × 19°
7.5–14 µm
× 480 pixels
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
87
Technical data24
Image presentation
Automatic image adjustment Continuous, histogram based
Manual image adjustment
Image presentation modes
Infrared image Full-color IR image
Visual image Full color visual image
Thermal MSX Thermal image with enhanced detail presentation
Picture in Picture Resizable and movable IR area on visual image
Measurement
Object temperature range
Accuracy ±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
Linear based; possible to adjust level/span/max./
min.
• –40°C to +150°C (–40°F to +302°F)
• +100°C to +650°C (+212°F to +1202°F)
(77°F) nominal.
Measurement analysis
Spotmeter
Area 5 + 5 areas (boxes or circles) with max./min./aver-
Automatic hot/cold detection
Measurement presets No measurements, Center spot, Hot spot, Cold
User presets (in live images) The user can select and combine measurements
Difference temperature Delta temperature between measurement func-
Reference temperature Manually set using difference temperature
Atmospheric transmission correction Automatic, based on inputs for distance, atmos-
Optics transmission correction Automatic, based on signals from internal sensors
Emissivity correction Variable from 0.01 to 1.0 or selected from materials
Emissivity table Emissivity table of predefined materials
Reflected apparent temperature correction Automatic, based on input of reflected temperature
External optics/windows correction Automatic, based on inputs of window transmis-
Measurement corrections Emissivity, reflected temperature, relative humidity,
Colors (palettes) Iron, Rainbow, Rainbow HC, White hot, Black hot,
10
age (in post-acquisition analysis)
Auto hot or cold spotmeter markers within area
spot, User preset 1, User preset 2
from any number of available spots/boxes/circles/
delta
tions or reference temperature
pheric temperature and relative humidity
list
sion and temperature
atmospheric temperature, object distance, external
IR window compensation
Arctic, Lava
Alarm
Color Alarm (isotherm) Above/below/interval
Measurement function alarm Audible/visual alarms (above/below) on any se-
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
lected measurement function
88
Technical data24
Set-up
Set-up commands Define user presets, Save options, Programmable
Service functions
Camera software update Use PC software FLIR Tools
Storage of images
Image storage Standard JPEG, including digital photo and meas-
Storage media Removable memory SD card
Image storage mode
Time lapse 15 seconds to 24 hours
File formats Standard JPEG, measurement data included
File formats, visual Standard JPEG, automatically associated with cor-
button, Reset options, Set up camera, Wi-Fi, Bluetooth, Language, Time & units, Camera
information
urement data, on memory card
• Simultaneous storage of thermal and digital
photo in same JPEG file.
• Optional to store digital photo as a separate
JPEG file.
responding thermal image
Image annotations (in still images)
Voice 60 seconds (via Bluetooth) stored with the image
Text Add table. Select between predefined templates or
Image description Add short note (stored in JPEG EXIF tag)
Sketch Draw on thermal/digital photo or add predefined
METERLiNK Wireless connection (Bluetooth) to:
Report generation
Video recording in camera
Non-radiometric IR video recording MPEG-4 to memory card
Visual video recording MPEG-4 to memory card
Video streaming
Radiometric IR video streaming
Non-radiometric IR video streaming
Visual video streaming
create your own in FLIR Tools
stamps
FLIR meters with METERLiNK
• Separate PC software with extensive report
generation
Full dynamic to PC using USB or to mobile devices
using Wi-Fi.
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
• MPEG-4 using Wi-Fi
• Uncompressed colorized video using USB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
89
Technical data24
Digital camera
Built-in digital camera 5 Mpixels with LED light (photo as separate image)
Digital camera, FOV Adapts to the IR lens
Video lamp Built-in LED light
Laser pointer
Laser Activated by dedicated button
Laser alignment Position is automatic displayed on the IR image
Laser classification Class 2
Laser type Semiconductor AlGaInP diode laser, 1 mW, 635
Data communication interfaces
Interfaces USB-mini, USB-A, Bluetooth, Wi-Fi, Digital Video
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
nm (red)
Output
USB
USB
USB, standard USB 2.0 high speed
Video output
Video out Digital video output (DVI)
Video, connector type HDMI compatible
Radio
Wi-Fi
METERLiNK/Bluetooth Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery operating time > 2.5 hours at 25°C (+68°F) and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
Charging time
Charging temperature 0°C to +45°C (+32°F to +113°F)
External power operation AC adapter 90–260 VAC, 50/60 Hz or 12 V from a
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / uncompressed colorized video
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
bay charger
2.5 h to 90 % capacity, charging status indicated
by LED's
vehicle (cable with standard plug, optional)
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
90
Technical data24
Environmental data
Operating temperature range –15°C to +50°C (+5°F to +122°F)
Storage temperature range –40°C to +70°C (–40°F to +158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
EMC
Radio spectrum
Encapsulation IP 54 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Safety EN/UL/CSA/PSE 60950-1
to +40°C (+77°F to +104°F) / 2 cycles
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (Immunity)
• EN 61000-6-3 (Emission)
• FCC 47 CFR Part 15 Class B (Emission)
• ICES-003
• ETSI EN 300 328
• FCC Part 15.247
• RSS-247 Issue 2
Physical data
Weight 1.3 kg (2.87 lb.)
Camera size, excl. lens (L × W × H) 143 × 195 × 95 mm (5.6 × 7.7 × 3.7 in.)
Tripod mounting UNC ¼"-20
Housing material Magnesium
Shipping information
Packaging, type Cardboard box
List of contents
Packaging, weight 6.6 kg (14.6 lb.)
Packaging, size 495 × 192 × 370 mm (19.49 × 7.56 × 14.57 in.)
EAN-13 7332558006658
UPC-12
Country of origin Sweden
• Infrared camera with lens
• Battery (2 ea.)
• Battery charger
• Bluetooth headset
• Calibration certificate
• Printed documentation
• HDMI-DVI cable
• HDMI-HDMI cable
• Hard transport case
• Lens cap
• Memory card
• Neck strap
• Power supply, incl. multi-plugs
• Tripod adapter
• USB cable, Std A to Mini-B
845188007003
Supplies & accessories:
• T197914; IR lens, f=41.3 mm (15°) with case
• T197922; IR lens, f=24.6 mm (25°) with case
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
91
Technical data24
• T197915; IR lens, f=13.1 mm (45°) with case
• T198059; Close-up IR lens, 2.9× (50 µm) with case
• T198060; Close-up IR lens, 5.8× (100 µm) with case
• T198166; IR lens, f=88.9 mm (7°) with case and support for T6xx
• T198065; IR lens, f=6.5 mm (80°) with case
• T198066; Close-up IR lens, 1.5× (25 µm) with case
• T197896; High temperature option +300°C to 2000°C (+572°F to 3632°F)
• T910814; Power supply, incl. multi plugs
• T198126; Battery charger, incl. power supply with multi plugs T6xx
• T199406ACC; Battery Li-ion 3.7 V, 7.8 Ah, 29 Wh
• T911650ACC; Memory card SD Card 8 GB
• 1910423; USB cable Std A <-> Mini-B
• T198509; Cigarette lighter adapter kit, 12 VDC, 1.2 m/3.9 ft.
• T910930ACC; HDMI type C to DVI cable 1.5 m
• T910891ACC; HDMI type C to HDMI type A cable 1.5 m
• T198625ACC; Hard transport case
• T198495; Pouch
• T198497; Large eyecup
• T198498; Tripod Adapter
• T198499; Neck strap
• T197771ACC; Bluetooth Headset
• T911093; Tool belt
• 19250-100; IR Window 2 in
• 19251-100; IR Window 3 in.
• 19252-100; IR Window 4 in.
• 19250-200; SS IR Window 2 in.
• 19251-200; SS IR Window 3 in.
• 19252-200; SS IR Window 4 in.
• T198496; Stylus pen
• T198586; FLIR Reporter Professional (license only)
• T198584; FLIR Tools
• T198583; FLIR Tools+ (download card incl. license key)
• DSW-10000; FLIR IR Camera Player
• APP-10002; FLIR Tools Mobile (Android Application)
• APP-10004; FLIR Tools (MacOS Application)
• T198697; FLIR ResearchIR Max + HSDR 4 (hardware sec. dev.)
• T199014; FLIR ResearchIR Max + HSDR 4 (printed license key)
• T199044; FLIR ResearchIR Max + HSDR 4 Upgrade (printed license key)
• T198696; FLIR ResearchIR Max 4 (hardware sec. dev.)
• T199013; FLIR ResearchIR Max 4 (printed license key)
• T199043; FLIR ResearchIR Max 4 Upgrade (printed license key)
• T198731; FLIR ResearchIR Standard 4 (hardware sec. dev.)
• T199012; FLIR ResearchIR Standard 4 (printed license key)
• T199042; FLIR ResearchIR Standard 4 Upgrade (printed license key)
• T199233; FLIR Atlas SDK for .NET
• T199234; FLIR Atlas SDK for MATLAB
#T559880; r. AL/45866/45866; en-US
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
92
Loading...
