USER MANUAL
FLIR
LS-X/R
Thermal Monocular
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FLIR
LS-X/R
USER MANUAL
© 2019 FLIR Systems, Inc. All rights reserved
worldwide. No parts of this manual, in whole or
in part, may be copied, photocopied, translated,
or transmitted by any electronic medium or in
machine-readable form without the prior written
permission of FLIR Systems, Inc.
Names and marks appearing on the products
herein are either registered trademarks or
trademarks of FLIR Outdoor & Tactical Systems
and/or its subsidiaries. All other trademarks,
trade names, or company names referenced
herein are used for identification only and are
the property of their respective owners.
This product is protected by patents, design
patents, patents pending, or design patents
pending.
If you have questions that are not covered in
this manual, or need service, contact FLIR OTS
customer support for additional information prior
to returning a camera.
This documentation is subject to change without
notice.
Proper Disposal of Electrical
and Electronic Equipment
(EEE)
The European Union (EU) has enacted Waste
Electrical and Electronic Equipment Directive
2002/96/EC (WEEE), which aims
to prevent EEE waste from arising;
to encourage reuse, recycling,
and recovery of EEE waste; and to
promote environmental responsibility.
In accordance with these regulations,
all EEE products labeled with the “crossed out
wheeled bin” either on the product itself or in
the product literature must not be disposed
of in regular rubbish bins, mixed with regular
household or other commercial waste, or by
other regular municipal waste collection means.
Instead, and in order to prevent possible harm
to the environment or human health, all EEE
products (including any cables that came with
the product) should be responsibly discarded or
recycled.
To identify a responsible disposal method
where you live, please contact your local waste
collection or recycling service, your original
place of purchase or product supplier, or the
responsible government authority in your area.
Business users should contact their supplier or
refer to their purchase contract.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Important Instructions
and Notices to the User:
Modification of this device without the express
authorization of FLIR Systems, Inc. may void
the user’s authority under FCC rules to operate
this device.
Note 1: This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that the interference will not occur in
a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the
equipment and receiver
• Connect the equipment into an outlet on a
circuit different from that of the receiver
• Consult the dealer or an experienced radio/
television technician for help.
Industry Canada Notice:
This Class B digital apparatus complies with
Canadian ICES-003.
3
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FLIR
LS-X/R
USER MANUAL
CONTENT
Page
1. Introduction 5
2. Getting Started 7
3. Operating the System 9
4. Symbology 13
5. Maintenance 14
6. Warranty 14
7. Specifications 15
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SECTION 1. INTRODUCTION
1.1 SCOPE
This manual covers the FLIR LS-X/R Series and
all applicable components. It is recommended
that you read and understand this manual to
optimize the monocular’s operation.
1.2 INTRODUCTION
FLIR’s LS-X/R Series thermal handheld
monoculars give hikers, law enforcement
professionals and first responders the ability to
see clearly in total darkness, providing a wealth
of information during any nighttime mission.
1.3 FEATURES
• Rugged design – built to withstand the
demands of outdoor use.
• Microbolometer sensor for excellent image
quality and clarity
• Palm-sized portability and lightweight – only
12 ounces
• Red laser pointer
• Battery charging via USB cable
• USB/Video adapter cable for video out
• Rechargeable internal li-ion battery – provides
up to 5 hours of camera operation on a single
chargege
1.4 REGISTER YOUR LS-X/R
In order to validate the warranty on your product,
FLIRl Systems Inc. must register the product on
5
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FLIR
LS-X/R
USER MANUAL
1.5 INFRARED THERMAL
VISION VERSUS IMAGE
INTENSIFIED NIGHT VISION
The FLIR LS-X/R makes images from heat, not
light, a feat impossible for the naked eye or
image intensified (I2) night vision devices. This
allows you to see clearly without any visible
light. People, animals, and objects all generate
or reflect heat and are clearly seen by the FLIR
LS-X/R in even the most adverse conditions.
FLIR LS-X/R ENABLES THE
OUTDOOR ENTHUSIAST TO:
• See animals and difficult terrain in reduced
visibility or total darkness
• See through smoke, dust, and light fog
• See camouflage and foliage in any lighting
conditions
• See more – and see farther – than with lowlight night vision goggles
1.6 DETECTION,
RECOGNITION,
IDENTIFICATION
DETECTION
I see something.
IMAGE INTENSIFIED I
THERMAL IMAGING
RECOGNITION
It’s a four-legged animal.
2
IDENTIFICATION
I can tell it is an Elk.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SECTION 2. GETTING STARTED
2.1 UNPACKING AND
INSPECTING
The FLIR LS-X/R Series monocular is available
with the features, options, and accessories
described in this manual. Refer to the packing
list enclosed with your product to determine the
actual contents of your product package.
In addition to the product the following items are
included in the product package:
• FCC Declaration of Conformity
• CE Declaration of Conformity
Molle-Compatible
Belt Holster
Quick Start Guide
Lens Cap
USB to RCA Cable
(320 & 640 models only)
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Wrist Strap
USB Cable
USB Power Adapter
7
FLIR
LS-X/R
USER MANUAL
2.2 CHARGING THE SYSTEM
To assure proper charging, LS-X/R Series
monoculars should be turned OFF throughout
the charging cycle. Charging MUST only be done
when the camera temperature is from 0 to 40°C
(32 to 104°F), or battery damage may occur.
The monocular battery should be fully charged
prior to use. To charge the monocular, lift the
cover from the USB port, plug in the USB cable
provided with the monocular, and plug other
cable end into a USB power source.
USB Port
Charging Indicator
• When charging the charging indicator will be
lit orange.
• When fully charged, the charging indicator
will light solid green. The initial charge time
is approximately 5 hours.
2.3 BATTERY
Your LS-X/R Series monocular is equipped
with a sophisticated power system that uses a
rechargeable internal Li-Ion battery.
BATTER Y S TATUS INDICATOR
While the monocular
is ON, a battery status
indicator is always
shown in the corner
of the display image.
This indicator provides
an estimation of the
remaining battery
charge.
BATTER Y S AFE TY INFORMATION
The LS-X/R Series monocular is a sealed unit
with sensitive electronics and contains no userserviceable parts. Service or repair
is to be performed only by the manufacturer. The
monocular must never be opened or modified
by the user. The monocular contains no user
serviceable components. The battery used in
this device may present a risk of fire or chemical
burn if mistreated. Do not disassemble the
monocular, store above 60°C, or incinerate. The
battery is replaceable only in the factory. Return
the product to the manufacturer for
battery replacement.
Full Charge
Half Charge
Plugged In
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SECTION 3. OPERATING THE SYSTEM
3.1 SYSTEM CONTROLS AND BUTTONS
Power
Display Brightness
Task Light On/Off
Zoom
Charging
Indicator
Eyepiece
Laser Pointer
Mini-USB/Charging/Analog
video out
3.1.1 DIOPTER ADJUSTMENT
While looking through the eyepiece, adjust the
position of the diopter lever to optimize the
sharpness of the image in the viewfinder.
3.1.2 POWER BUTTON
The Power Button performs the
following functions:
SYSTEM STATE SHORT PRESS LONG PRESS
System OFF Turns Power ON N/A
System ON Access User
Menu
Turns Power
OFF
Palette Selection
Adjustable Diopter
3.1.3 DISPLAY BRIGHTNESS
BUTTON
Use this button to cycle through the
five levels of display brightness.
Each press of the button advances
to the next level of brightness.
When the highest brightness level is reached,
subsequent button presses advance to the
next lower brightness levels. When the lowest
brightness level is reached, subsequent button
presses advance to the next higher brightness
level. One of the following icons is displayed
for approximately 3 seconds after the button is
pressed indicating the current brightness level:
Dim Bright
SYSTEM STATE SHORT PRESS LONG PRESS
System OFF Flashes LED Task
System ON Changes Current
light
Display Brightness
Turn on LED
Task Light
N/A
9
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FLIR
LS-X/R
USER MANUAL
3.1.4 COLOR PALETTES
Use this button to toggle between
the available color palettes. Please
see the following images for
examples of LS-X/R’s color palettes.
WHITE HOT
Most commonly used palette. Hot objects
appear white. Good for scenes with either high
or low contrast.
BLACK HOT
Hot objects appear black. Scenes appear more
lifelike than White-Hot, especially at night.
INSTALERT™ LEVEL 2
The hottest 10% of things in the image are
colored and everything else is greyscale.
INSTALERT™ LEVEL 3
The hottest 15% of things in the image are
colored and everything else is greyscale.
INSTALERT™ LEVEL 1
The hottest 5% of things in the image are
colored and everything else is greyscale.
INSTALERT™ LEVEL 4
The hottest 20% of things in the image are
colored and everything else is greyscale.
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
3.1.5 ZOOM BUTTON
Use this button to switch the monocular
between no zoom (full resolution), 2X and 4X
(LS-X), and 2X, 4X, and 8X (LS-XR). The central
part of the image is magnified by the zoom level
selected.
When zoom has been selected, the icon appears
continuously in the display. See user menu
section for additional details
3.2 USING USB/ANALOG
VIDEO ADAPTER CABLE
To obtain analog video out, insert the adapter
cable into the USB connector. The monocular
will detect the adapter cable and provide the
video stream. Use an RCA cable to connect to a
monitor or a video recorder.
USB to RCA Video Cable
3.3 LS-X/R POWER
MANAGEMENT
Your LS-X/R Series monocular is equipped with
a power management system that provides up
to five hours of continuous operation. When left
in the Off state the battery will hold a charge
for up to two months. To use the product it is
important to understand the basic power states
of the product.
• When the monocular is turned on from the
Off state, it takes about five seconds to
become operational. During the boot up
process, the FLIR splash screen is shown.
Pressing the Power button will toggle the
monocular between On and Off.
• The camera shuts down after about five
minutes if no buttons are pushed.
SYSTEM
STAT E
OFF
ON
HOW DO YOU KNOW?
The display is off and the Task
Light comes on when the
Brightness button is pressed.
The display is on and the LED
Task Light is disabled. If the
image appears blank, make sure
the lens cover is removed.
Customer Supplied RCA Cable
When using the USB/Analog Video Adapter
cable to record video or supply video to a remote
monitor, it may be useful to turn off the Auto
Power Off feature of the monocular. Set the
video format using the LS-X/R/LS-X/LS-XR End
User Tool.
3.4 AUTO POWER OFF
OPERATION
Auto Power Off is a feature of the LS-X/R Series
monocular that helps to guard against draining
the battery prematurely by inadvertently leaving
the camera on.
Auto Shutdown turns the camera off if the
following conditions are met:
• The product is On
• No buttons have been pressed for five
minutes
Once these conditions are met, you will see the
following message in the display: “Auto Power
Off 30s.” After counting down for 30 seconds,
the monocular will shutdown.
Press any button during this countdown to
terminate Auto Power Off and resume normal
operation.
11
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FLIR
LS-X/R
USER MANUAL
3.5 AUTO FFC /
CALIBRATION
By design, the camera will periodically initiate
a Flat Field Correction (FFC) cycle, also known
as a Non-Uniformity Correction (NUC). A shutter
activates inside the camera and provides a
target of uniform temperature, allowing the
camera to correct for ambient temperature
changes and provide the best possible image.
Just prior to the FFC, a small green square will
appear in the upper left corner of the screen for
two seconds. When the FFC occurs, the video
image temporarily freezes.
3.6 LS-X/R/L S-X/LS-XR
END USER TOOL
The SCOUT III/LS-X/LS-XR end user tool is a
graphical user interface (GUI) that is used with
the following FLIR handheld thermal imaging
monoculars:
• SCOUT III Series
• LS-X/R Series
To get detailed information,software downloads,
or product support for your LS-X or LS-XR visit
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SECTION 4. SYMBOLOGY
The LS-X/R user interface has a clear and simple on-screen symbology that allows the user to easily
navigate through the settings, and optimize the image quality based on certain variables. From the
zoom function to palette choice the symbology on-screen matches the button symbology so the user
becomes instantly familiar with how to manipulate and operate all of LS-X/R’s functions.
See the reference points below to get a solid understanding of the onscreen functionality.
The brightness indicator
appears on screen when
adjusting the brightness
level of the LCD screen.
The battery symbol clearly
displays the battery status.
The magnifying glass
clearly indicates the
zoom functionality of the
LS-X/R and the 2X inside
the symbol indicates the
magnification.
This symbol clearly identifies
the current palette being
used. In this example,
InstAlert level 1 is displayed
(I1).
13
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
FLIR
LS-X/R
USER MANUAL
SECTION 5. MAINTENANCE
5.1 SOFTWARE UPDATE
Software updates for your LS-X/R can be
found at:
5.2 BATTERY SERVICE AND
REPLACEMENT
If the battery will not hold a charge and requires
replacement, please contact FLIR Systems for
details on returning the unit for service.
For instructions on charging the battery refer to
Section 2.3 Charging the system.
5.3 CLEANING THE LS-X/R
Wipe the housing with a damp cloth, as needed.
Use a high quality lens wipe to remove dirt or
smudges from the lens and display window.
Do not use abrasives or solvents to clean the
housing, lens, or display window.
5.4 CAUTIONS
• Do not disassemble the monocular enclosure.
Disassembly can cause permanent damage.
The battery is not user-replaceable
• Do not point the monocular at high-intensity
radiation sources, such as the sun, lasers, or
arc welders
• Do not leave fingerprints on the monocular’s
infrared optics. Clean only with low pressure
fresh water and a lens cloth
• All service must be provided by the
manufacturer
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
SECTION 7. SPECIFICATIONS
LS-X
LS-XR
LS-X
LS-XR
SENSOR SPECIFICATIONS
Detector Type 336 × 256 VOx
Video Refresh Rate 60Hz NTSC 30Hz NTSC
Field of View (H x V) 17° × 13° 18° × 14°
Focal Length 19mm Fixed Focus 35mm Fixed Focus
Start up < 1.5 seconds
Image Processing FLIR Proprietary Digital Detail Enhancement™
Microbolometer
640 × 512 VOx
Microbolometer
USER INTERFACE
Zoom Button 2X Zoom 2X, 4X Zoom
Video D etection Palettes User Selectable: Black Hot, White Hot, InstAler t™ and Graded Fire
Brightness Multiple Brightness Levels
Laser Pointer LED (operational when imager power off )
SYSTEM SPECIFICATIONS
Display
Video Output NTSC / PAL composite video NTSC composite video
POWER
Batte ry Ty pe Internal Li-Ion Cell
Batter y Life (Operating) >5 hours, Auto-off after 5 minutes of non- use
Battery Power 3.7 V 240 0mAh
ENVIRONMENTAL
Rating IP-67, Submersible
Operating Temp. -4° F to 122°F (-20°C to 50°C)
Storage Temp. -4 0°F to 140°F (-4 0°C to 60 °C)
PHYSICAL
Weight (incl. lens) 12 oz (340 g)
Size (L × W × H) 6.70” x 2.31”x 2.44”
Color (housing) Black
Countr y Of Origin USA
RANGE PERFORMANCE
Detect Man (1.8 m × 0.5 m) 600 yd (550m) 1200yd (1140m)
PACKAGES INCLUDE
Handheld Thermal Monocular, USB Power Ad apter/Charger, Wrist Strap, Custom Video Out Cable,
USB Cable, Quick Star t Guide, Molle Bag
15
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Loading...
