Page 1
T-SER IES
tHERMAL IMAGING CAMERAS FoR
PREDICtIVE MAINtENANCE
UNLEASH
THE
ULTIMATE
POWER OF
FLIR
Page 2
PRoDuCtIVItY booSt
T-SERIES
tHE
uLtIMAtE
tHERMAL
IMAGER
to KEEP EQuIPMENt
RuNNING RELIAbLY, You NEED
DEPENDAbLE tRoubLESHootING
tooLS tHAt CAN HELP You FIND
AND REPoRt PRobLEMS FASt.
tHAt’S WHY FLIR INFRARED
CAMERAS ARE INDISPENSAbLE.
tHEY LEt You SEE INVISIbLE
HEAt CAuSED bY ELECtRICAL
RESIStANCE, MECHANICAL
WEAR, AND otHER ISSuES EARLY
ENouGH to HELP You KEEP
tHINGS oPERAtING SAFELY
AND HEAD oFF EXPENSIVE
DoWNtIME. AND No otHER LINE
oF tHERMAL IMAGERS MAKES It
EASIER to CAPtuRE AND SHARE
FINDINGS tHAN t-SERIES.
• Touchscreen tools as intuitive as
a smartphone’s
• Simple buttons to access the
interface with gloved hands
• GPS & Compass embed pointing
direction and geo-location
• LEDs to light darker areas and a
laser pointer to mark locations
• Easy voice, text, and sketch
annotations, stored in
radiometric images
FASt CoMMuNICAtIoN
• FLIR Tools Mobile app links T-Series to smartphones & tablets for
immediate image analysis and sharing from the eld plus streaming
video and remote control for safer monitoring
• MeterLink® transmits FLIR T&M data to the camera, for instant
integration into images and reports
• FLIR Tools software for PC & Mac provides extra documentation
power and camera rmware updates
• Radiometric recording to memory card
oPtIMuM ERGoNoMICS
• Rotating optical block points 120° up and
down for easier aiming and viewing
• Auto Orientation switches onscreen
temperature data to portrait or landscape
• The fastest auto focus and manual control for
precision imaging
• T640 & T660 feature Continuous Auto Focus
for automatic clarity wherever you aim
Page 3
uLtIMAtE RESoLutIoN & SENSItIVItY
• Up to 640 x 480 native resolution
• Up to 1.2 MP thermal resolution with UltraMax™ – a 4x improvement
• MSX® Enhancement on live video, stored images, and UltraMax images
• Class-leading sensitivity of up to <0.02°C for outstanding image quality
• Temperature calibrations up to 2,000°C
VIEWFINDER FOR BRIGHT CONDITIONS
HELPFuL ACCESSoRIES
• A range of interchangeable
advanced optics
• Additional batteries
and chargers
• Spare cables and SD cards
• Camera pouches and
tripod adapters
• FLIR IR Windows
Page 4
T-SERIES
tHE uLtIMAtE
FEAtuRES
INtuItIVE
touCHSCREEN
Tap the screen or buttons to
quickly access temperature
measurement tools,
parameters, image modes,
and more.
T46 0
MEtERLINK
Automatically embed
readings from
MeterLink-enabled
test gear into thermal
images.
Joystick & large backlit
buttons for gloved
operation.
3.5“ bright touchscreen for
quick access to images,
camera tools, & analytics.
FLIR tooLS FoR
PC & MAC oS
Included software for indepth image analysis, report
generation, and more.
T640 view nder makes
surveys in the brightest
environments even
easier.
Large 4.3“ capacitive
touchscreen puts fast
tools at your ngertips.
T660
MEtERLINK
FLIR tooLS MobILE APP
Page 5
bRIGHt 3.5” touCHSCREEN
Auto FoCuS/IMAGE CAPtuRE
MANuAL FoCuS
LED LIGHt & LASER PoINtER
t420, t440 & t4 60
FLIR T420, T440, and T460 cameras deliver 76,800 pixels of vivid
thermal resolution, UltraMax image enhancement, advanced
interchangeable lenses to t the view and spot size you need, and more
productivity features than ever to help ease your demanding workload.
3.1 MP VISIbLE LIGHt CAMERA
Page 6
LARGE 4.3” CAPACItIVE
touCHSCREEN
VIEWFINDER oN t640 AND t660
Auto FoCuS/IMAGE
CAPtuRE
5 MP DIGItAL CAMERA
LED LAMPS & LASER PoINtER
MANuAL FoCuS
t600, t620, t640 & t660
The T600 produces crisp 480 x 360 thermal imagery, while T620, T6 40, and
T660 cameras offer the highest FLIR handheld IR precision at 640 x 480
resolution delivering 307,200 pixels, plus UltraMax image enhancement. The
greater the resolution, the easier it is to see, nd, and reliably measure heat
issues on smaller, distant components.
Page 7
T-SERIES
tHE
uLtIMAtE
RESoLutIoN
uLtRAMAX AND MSX CoMbINE to
tuRN t-SERIES CAMERAS INto
tHE MoSt PoWERFuL INFRARED
IMAGING AND NoN-CoNtACt
tEMPERAtuRE MEASuREMENt
tooLS oN tHE PLANEt, ALL IN A
CoMPACt, EASY-to-uSE DESIGN.
uLt R AMAX
FLIR’s new UltraMax is a unique image
processing technique that allows you to
generate reports with images that have
four times as many pixels, and 50% less
noise, so you’ll be able to zoom in on
smaller targets and measure them more
accurately than ever.
UNMAT CHED RE SOLUTIO N AND
MEASUREMENT PERFORMANCE
EVEN AT 8X ZOOM
WITHOUT MSX
MSX ENHANCEMENt
FLIR’s patented multi-spectral dynamic imaging (MSX) etches vital
image detail from the visible light image onto the thermal image
to help you see where problems are quickly and easily without
compromising any of your temperature measurement data.
WIT H MSX
Page 8
SPECIFICAtIoNS
Model T420 T440 T460 T600 T620 T640 T6 60
Thermal Resolution 76,8 00 (320 × 240) 172,80 0 (48 0 × 360 ) 307,200 (640 × 480)
Thermal Sensitivity <0.0 4°C @ 30 °C <0.03°C @ 30°C <0.0 4°C @ 30°C <0.03°C @ 30°C <0.02°C @ 30 °C
Accuracy +/-2° C (+/-3.6°F) or +/-2% of reading, whichever is greater, at 25°C (7 7°F) nominal +/-1°C (+/-1.8 °F) or +/-1% of reading for
Temperature Range -4° F to 1,202°F (-20 °C to 65 0°C)
Optional: to 2,192°F (1,200°C)
Measurement Modes 7 presets: center spot; hot spot (box max);
cold spot (box min); 3 spots; hot spot
- spot (box max + spot + delt a); hot spot -
temperature (box max + ref temp + delta);
no measurements
UltraMax • • • • • •
Radiometric Recording CSQ to memory card CSQ to memory card
User Presets • • • • • •
Frame Rate 60 Hz 30 Hz
Lens Choices 6°, 15° Tele, 45° & 90° Wide; Close up: 100 μm, 50 μm 25°, 7° & 15° Tele, 45° & 8 0° Wide; Close up: 100 μ m, 50 μm, 25 μm
Focus Manual & Automatic Manual & Automatic Manual, Automatic, and Continuous
Display Size 3.5” 4.3”
Touchscreen • • • Capacitive touch screen
V i e w n d e r • •
Built-in Visual Camera 3.1 MP 5 MP
Digital Zoom 4× 8× 4× 8×
Compass • • • • • •
GPS • • •
Sketch on IR/V isual Image Draw or add prede ned stamps Draw or add prede ned stamps
-4° F to 2,192°F (-20°C to 1,200°C) -4° F to 2,732°F (-20 °C to 1,50 0°C) -40°F to 1,20 2°F (-40°C to 650°C) -4 0°F to 1,202°F ( -4 0°C to 650°C)
6 presets: center spot; hot spot (box max); cold spot (b ox min); no measurements; 2
limited temperature range; ±2°C (±3.6°F)
or 2%, whichever is greater, at 25°C
(77°F ) nominal.
user presets
SEE FULL T-SERIES SPECIFICATIONS AT WWW.FLIR.COM/THERMOGRAPHY
FLIR 2-5-10 WARRANtY
All T-Series cameras are covered by our revolutionary
FLIR 2-5-10 Warranty when registered within 60 days of
purchase.
• 2 Years on Camera Parts & Labor
• 5 Years on Li-Ion Batteries
• 10 Years on the IR Detector
Only FLIR can provide peace of mind like this because
only FLIR makes all of the camera’s critical components
from the ground up.
Page 9
+/-2°C (+/- 3.6° F) or +/ -2% of reading , whichever is greater, at 25°C (77°F ) nominal +/-1°C (+/-1.8 °F) or +/-1% of reading for
-4 0°F to 3,632°F (- 40°C to 2,000°C)
Optional: to 3,632°F (2,000°C)
6 presets: center spot; hot spot (box max); cold spot (b ox min); no measurements; 2 user presets
limited temperature range; ±2°C (±3.6°F)
or 2%, whichever is greater, at 25°C
(77°F ) nominal.
SuPPoRt FRoM ItC
Expand your expertise, enhance your career, and get the most out
of your camera with valuable courses from the Infrared Training
Center. At ITC, you can get initial training and certi ed as a Level 1
Thermographer, or receive advanced training in specialized elds of
thermography. ITC training is a vital investment to help you get the
most out of your thermal camera.
