UAS THERMAL
IMAGING KITS
Featuring DJI M200 Series and Zenmuse XT2 Thermal Imagers
MORE ACCESSIBLE THAN EVER BEFORE
By combining the ight stability, gimbal technology, mobile app integration, and image transmission of the powerful DJI M200, M210,
and M210RTK with the industry-leading thermal imaging technology of FLIR, these packages offer you the ultimate solution for reliable,
rapidly-deployable aerial thermal imaging. The M210 and M210RTK kits let you deploy two imagers below the aircraft so you can y
thermal and visible cameras at the same time, or single upward-facing gimbal, and the upgraded Cendence control unit.
WITHOUT FLIR MSX WITH FLIR MSX*
Zenmuse XT2
FLIR M200 XT2
336-9 mm
M200 airframe, XT2 IR camera,
336 × 256 9 mm IR and 12 MP
visual, 7.8” CrystalSky display,
2 TB50 batteries
Applications: Fire, SAR,
basic structural inspections
FLIR M200 XT2 R
640-13 mm or 640-19 mm
M200 airframe, XT2 IR camera,
640 × 512 (13 or 19 mm) IR and 12
MP visual, 7.8” Cr ystalSky display,
2 TB50 batteries
Applications: Fire, SAR,
building, roong inspection
All Models Compatible with:
www.ir.com/dronesense
FLIR M210 XT2 R
640-13 mm or 640-19 mm
M210 airframe, XT2 IR camera,
640 × 512 (13 or 19 mm) IR and 12
MP visual, Cendence RC,
7.8” CrystalSky display, 2 TB50
and 2 TB55 bat teries
Single-, dual-, or top-mount
thermal/visible gimbal mounts
Dual camera operation
Applications: building/roong,
utility, solar inspection
FLIR M210RTK XT2 R
640-13 mm or 640-19 mm
M210RTK* airframe, X T2 IR camera, 640
× 512 (13 or 19 mm) IR and 12 MP visual,
Cendence RC, 7.8” CrystalSky diplay,
2 TB50 and 2 TB55 batteries
Single-, dual-, or top-mount
thermal/visible gimbal mounts
Dual camera operation
Applications: Areas where GPS may be
obscured or additional GPS accuracy is
required
*The built-in RTK unit on the M210 RTK
model enables the drone to hover
with centimeter-level accuracy due to
the improved GPS data, making slight
interferences to the transmission
system potentially less dangerous.
All FLIR UAS Thermal Imaging Kits Include:
®
Zenmuse XT2 thermal camera with MSX
*
7.8” CrystalSky display
FLIR Tools+ imaging software
Key Stats for Controlled Operation
7 km
Operating
Range
* FLIR MSX® Multi-Spectral Dynamic Imaging embosses visible image edge details
onto thermal images to enhance perspective and safety
38 min
Max Flight
Time
IP43
Ingress
Protection
2 kg
Max Payload
Capacity
SPECIFICATIONS
AVAILABLE KITS
Aircraft Model
Included Tablet Interface
RC Unit- 1 Included
Aircraft Battery
Gimbal Mount (IR & Visual)
Compatible Cameras
Zenmuse XT2 Camera
Frame Rate
Thermal Imager
IR Sensitivity
Scene Range (High Gain)
Scene Range (Low Gain)
Thermal Photo/Video Format
Visual Camera
Visual Photo/Video
File Storage
Weight (Gimbal)
FLIR M200 XT2 R 336-9 mm
1
DJI M200
1
DJI CrystalSky display 7.85”
DJI GL6D10A
Qty 2 TB50 (4280 mAh)
Single downward
Zenmuse XT2 (included)
Zenmuse X5S (optional)*
Zenmuse X30 (optional)*
XT2 336 × 256 – 9 mm FOV 35° × 27°
30 Hz or 9 Hz (region-dependent)
Uncooled VOx microbolometer, 7.5 – 13.5 µm
<50 mK at f/1.0
-25°C to 100°C (-13°F to 212°F)
-40°C to 550°C (-40°F to 1022°F)
JPEG, TIFF, R-JPEG/8-bit
MOV, MP4/14-BIT
TIFF sequence, SEQ
12 MP, 1/1.7” CMOS, FOV 57.12° × 42.44°
4K Ultra HD: 3840 × 210, 29.97p
FHD: 1920 × 1080, 29.97p
JPEG/MOV, MP4
Micro SD, max. capacity: 128 GB. UHS-3
required. SanDisk Extreme 16/32 GB UHS-3
micro-SDHC or SanDisk Extreme 16/128 GB
UHS-3 microSDXC recommended
588 g (20.7 oz)
FLIR M200 XT2 R
Choice of 640-13 mm or 640-19 mm
DJI M200
DJI CrystalSky display 7.85”
DJI GL6D10A
Qty 2 TB50 (4280 mAh)
Single downward
Zenmuse XT2 (included)
Zenmuse X5S (optional)*
Zenmuse X30 (optional)*
XT2 640 x 512 13mm FOV 45° x 37° Or
XT2 640 x 512 19mm FOV 32° x 26°
30 Hz or 9 Hz (region-dependent)
Uncooled VOx microbolometer, 7.5 – 13.5 µm
<50 mK at f/1.1
-25°C to 135°C (-13°F to 275°F)
-40°C to 550°C (-40°F to 1022°F)
JPEG, TIFF, R-JPEG/8-bit
MOV, MP4/14-BIT
TIFF sequence, SEQ
12 MP, 1/1.7” CMOS, FOV 57.12° × 42.44°
4K Ultra HD: 3840 × 210, 29.97p
FHD: 1920 × 1080, 29.97p
JPEG/MOV, MP4
Micro SD, max. capacity: 128 GB. UHS-3
required. SanDisk Extreme 16/32 GB UHS-3
micro-SDHC or SanDisk Extreme 16/128 GB
UHS-3 microSDXC recommended
588 g (20.7 oz)
FLIR M210 XT2 R
Choice of 640-13 mm or 640-19 mm
1
DJI M210
DJI CrystalSky display 7.85”
DJI Cendence RC
Qty 2 TB50 (4280 mAh) & Qty 2 TB55 (7660 mAh)
Single downward, Dual downward, Single upward
Zenmuse XT2 (included)
Zenmuse X5S (optional)*
Zenmuse X30 (optional)*
XT2 640 x 512 13mm FOV 45° x 37° Or
XT2 640 x 512 19mm FOV 32° x 26°
30 Hz or 9 Hz (region-dependent)
Uncooled VOx microbolometer, 7.5 – 13.5 µm
<50 mK at f/1.0
-25°C to 135°C (-13°F to 275°F)
-40°C to 550°C (-40°F to 1022°F)
JPEG, TIFF, R-JPEG/8-bit
MOV, MP4/14-BIT
TIFF sequence, SEQ
12 MP, 1/1.7” CMOS, FOV 57.12° × 42.44°
4K Ultra HD: 3840 × 210, 29.97p
FHD: 1920 × 1080, 29.97p
JPEG/MOV, MP4
Micro SD, max. capacity: 128 GB. UHS-3 required.
SanDisk Extreme 16/32 GB UHS-3 micro-SDHC or
SanDisk Extreme 16/128 GB UHS-3 microSDXC
recommended
588 g (20.7 oz)
FLIR M210 RTK XT2 R
Choice of 640-13 mm or 640-19 mm
DJI M210RTK
1
DJI CrystalSky display 7.85”
DJI Cendence RC
Qty 2 TB50 (4280 mAh) & Qty 2 TB55 (7660 mAh)
Single downward, Dual downward, Single upward
Zenmuse XT2 (included)
Zenmuse X5S (optional)*
Zenmuse X30 (optional)*
XT2 640 x 512 13mm FOV 45° x 37° Or
XT2 640 x 512 19mm FOV 32° x 26°
30 Hz or 9 Hz (region-dependent)
Uncooled VOx microbolometer, 7.5 – 13.5 µm
<50 mK at f/1.0
-25°C to 135°C (-13°F to 275°F)
-40°C to 550°C (-40°F to 1022°F)
JPEG, TIFF, R-JPEG/8-bit
MOV, MP4/14-BIT
TIFF sequence, SEQ
12 MP, 1/1.7” CMOS, FOV 57.12° × 42.44°
4K Ultra HD: 3840 × 210, 29.97p
FHD: 1920 × 1080, 29.97p
JPEG/MOV, MP4
Micro SD, max. capacity: 128 GB. UHS-3 required.
SanDisk Extreme 16/32 GB UHS-3 micro-SDHC or
SanDisk Extreme 16/128 GB UHS-3 microSDXC
recommended
588 g (20.7oz)
Software
FLIR Tools+
Notes:
FLIR Tools+ included with all FLIR Kits to manage and
analyze IR images
U.S. MARKETS
Please note operation of the Small Unmanned Aerial Systems sold by FLIR Systems into U.S. markets in most all cases constitutes commercial use and
requires the appropriate FAA registrations which may include a pilot’s license requirement. Registrations or certications are not conveyed with a camera
purchase and must be obtained by the buyer. Operator training is strongly recommended.
Equipment described herein may require US Government authorization for export purposes. Diversion contrary to US law is prohibited. Imagery for
illustration purposes only. Specications are subject to change without notice. ©2018 FLIR Systems, Inc. All rights reserved. 18-2413 – Updated11/14/18
1. Full airframe details can be found at http://www.dji.com/matrice-200-series/info#specs and are subject to change by DJI
*Contact your FLIR dealer for pricing on optional accessories such as the Z30, X5S, additional batteries, or remote control units.
