WINK HUB V2 QUICK START GUIDE

Flextronics America LLC

3300 Holcomb Bridge Road, Suite 290

Norcross, Georgia 30092

www.flextronics.com Part Number: 08-00014-01 Rev. 1.0

08-00015-01 Rev. 1.0 Wink Hub V2 Quick Start Guide

2 of 7

Rev.

Author

Change Description

Date

Status

1.0

Initial Draft

08/31/2016

Unreleased

Revision History

Table 1 Revision History

CONTENTS

1. WARNINGS AND CAUTIONS .......................................................................................................................... 3

1.1. GENERAL WARNINGS AND CAUTIONS ....................................................................................................................... 3

1.2. RADIO COMPLIANCE AND INTERFERENCE................................................................................................................... 3

1.3. RSS-GEN: .......................................................................................................................................................... 4

1.4. RF EXPOSURE ........................................................................................................ ERROR! BOOKMARK NOT DEFINED.

2. BASIC OPERATION ........................................................................................................................................ 5

2.1. CONNECTION PORTS ............................................................................................................................................. 5

2.2. PLACEMENT ........................................................................................................................................................ 6

2.3. CONNECTING POWER TO YOUR HUB V2 ................................................................................................................... 6

2.4. CONNECTING THE HUB TO THE NETWORK ................................................................................................................. 6

2.5. PROVISIONING YOUR UNIT ..................................................................................................................................... 6

Flextronics – Confidential. Further distribution prohibited without prior written consent from Flextronics. © 2012

08-00015-01 Rev. 1.0 Wink Hub V2 Quick Start Guide

3 of 7

1. WARNINGS AND CAUTIONS

1.1 GENERAL WARNINGS AND CAUTIONS

READ ALL OF THE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR OPERATING THIS PRODUCT.

This manual provides information on the installation and operation of the Wink Home Automation
Gateway Version 2. For proper operation it is important to follow these instructions.

1.2 RADIO COMPLIANCE AND INTERFERENCE

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION

Warning: Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.
—Consult the dealer or an experienced radio/TV technician for help.

Flextronics – Confidential. Further distribution prohibited without prior written consent from Flextronics. © 2012
