Instructions Flexopower Foldable Kit
SK120 12W/SK240 240W
Carefully follow the instructions below for successfully operating the Flexopower SK120 /240 4x4 kit.
The Flexopower SK120 / SK240 Solar Camping kit are based on foldable, glass free, flexible solar panel
technology and includes everything needed to charge/manage the batteries from the sun: solar panel,
solar regulator with a remote LCD display, cabling, connectors and user manual. Easy to install, plug and
play principle. The SK120 / SK240 4x4 kit are suitable for marine, desert and tropical environments.
1. Caution
Do not fold SK120 / SK240 solar panels other than in its default folding zones
Do not stand on SK120 / SK240 solar panels when folded up
Do not erect under or near power lines
Do not stand on, walk or drive over SK120 / SK240 solar panels
Do not tamper with cabling, equipment and connectors
Do not pull on lead cables
Always observe polarity: red/brown cable (+) positive; black/blue cable (-) negative
Always use with a solar regulator with correct capacity
The SK120 / SK240 kit as described here is suitable only for 12VDC systems. Please contact
Flexopower if you operate a 24, 36 or 48VDC system.
2. Complete kit consists of
Foldable
Panel
SK120 (120W)
SK240 (240W)
Foldable glass free solar panel with lead wire and
50A Anderson grey connector
1x 2x
Solar regulator
1x
14A, 12V
1x
14A, 12V
LCD remote display [V,A]
No No
Special ripcord twin core cable 4mm2
with 50
Amp Anderson grey connectors to connect panel
to regulator
1x 10m cable
2x 10m
cable
User Manual
1x 1x
Please note based on client feedback, no battery cable is included.
Page 2
SK120_SK240_manual_foldable_en_V1.docx
© Flexopower Desert Series. All rights reserved.
2
The power output of the Flexopower SK120 is suitable for smaller appliances and shorter stays in
camps without power. The power output of the Flexopower SK240 is suitable for 1-2 refrigerators and
longer stays in camps without power.
3. Assembly and disassembly (observe correct polarity: plus to plus, negative to negative)
3.1 Mount solar regulator with the remote LCD display in a suitable position as close as possible to
battery. Ensure solar regulator is protected from the elements, engine oil, engine heat etc.
3.2 Connect the solar regulator to the battery terminal at its battery symbol. Please note the
battery cable is not included in kit.
3.3 The solar regulator will now switch on.
3.4 Position SK120 / SK240 solar panel where it will have full day sun exposure. Temporarily leave
solar panel folded up until point 3.8. (eliminating the possibility of sparks when connecting the
solar panel to the solar regulator, i.e. no current flowing).
3.5 Connect SK120 / SK240 solar panel to the 10m cable via 50Amp Anderson grey connectors.
3.6 Connect the 10m cable to the solar regulator via 50Amp Anderson grey connectors.
3.7 The SK120 / SK240 ™ solar panel is now connected to the solar regulator and battery. Remove
Styrofoam and unfold the solar panel to full day sun exposure. The deep cycle battery is being
charged now.
3.8 Secure SK120 / SK240 through its eyelets if required.
3.9 The reverse order applies when disassembling. The solar regulator may be left permanently
connected to the battery terminals.
Optional
Permanently connect load (fridge, lights) to DC port of solar regulator. DC flows directly from
panel to load/consumer. Surplus DC power is stored in battery. Any balance will be supplied
from battery if DC output from panel is insufficient. Automatic switch during sun set and sun
rise.
Benefits:
eliminate 15% waste/loss of generated solar power in battery
reduced battery cycles and prolonged service life of battery
measure consumption of load (fridge, lights) in Amps via remote LCD display
Caution:
do not connect load exceeding 14A
do not connect AC inverter to DC port of solar regulator
Page 3
SK120_SK240_manual_foldable_en_V1.docx
© Flexopower Desert Series. All rights reserved.
3
4. Maintenance, transport and storage
Regularly wipe SK120 / SK240 solar panel with damp clean cloth
It is recommended to transport and store the SK120 / SK240 solar panels in a vertical position
with the Styrofoam inserted
Dry and wipe clean SK120 / SK240 solar panel for storage
Refer to solar regulator and remote LCD display manufacturer’s instructions
5. Warranty
5.1 The SK120 / SK240 solar panels are covered by a 2year manufacturing defect warranty.
5.2 Refer to solar regulator and LCD display manufacturer’s warranty.
5.3 All warranties and claims are null and void if the unit, connection and components have been
tampered with.
5.4 All warranties and claims are null and void if the unit, connection and components have been
operated beyond their limitations.
5.5 All warranties and claims are null and void in the event of reversed polarity.
5.6 All warranties and claims are null and void if cautions under 1) have not adhered to.
6. Features SK120 / SK240 4x4 kit
Foldable, flexible solar panel with eyelets on each side for proper securing
Expansion ready to conveniently add additional solar panels if needed
Easy to set up. Plug and play principle
More low light (overcast) and high temperature tolerant than glass solar panels
Delivers up to 20% more energy into the battery than glass solar panels-virtually unbreakable
Water, hail and dust proof
7. Specifications SK120 / SK240 Solar Panel Foldable Kit
IBS Order Number:
SK120 SK
240
Flexopower Name
Mojave 120
™ Mojave 240
™
Pmax, Power
120W
240W
Imp,
Current at max. Power
6.1A 12.2A
Vmp, Voltage at max. Power
19.1V
19.1V
Weight of panel
3.2 kg
2x 3.2 kg
Dimensions deployed L x W x H each
155x56x1cm
2 x 155x56x1cm
Dimensions folded
up
L x W x H each
56x44x2cm
2 x 56x44x2cm
Solarcontroller
ECOterm14
ECOterm14
Specification Solarcontroller Current/Tension/Waterproof
14A/12V/IP68
14A/12V/IP68
Max. operating temperature
85°C 85°C
Page 4
SK120_SK240_manual_foldable_en_V1.docx
© Flexopower Desert Series. All rights reserved.
4
8. Disclaimer
Flexopower (Pty) Ltd and IBS GmbH shall not be held liable for any loss or damage suffered
from the use of this system.
Flexopower (Pty) Ltd and IBS GmbH reserves the right to change the content of this manual
without prior notice.
SK120 /SK240
SK120 installed SK120 with integrated feet
Flexopower Energies (Pty) Ltd, Johannesburg, South Africa
IBS Inteligent Battery Systems GmbH, Seestrasse 24, CH-3600
Thun, Tel. 033 221 06 18
E-Mail: [email protected] Internet: www.ibs-tech.ch
