ZoneFlex H510
Multiservice 802.11ac Wave 2 Wired/Wireless Wall Switch
DATA SHEET
HIGH PERFORMANCE 802.11AC WAVE 2 INTEGRATED WIRED/
WIRELESS WALL SWITCH
The ZoneFlex™ H510 is the industry’s rst Wave 2 802.11ac wired and wireless wall
switch using Ruckus’ patented BeamFlex+ adaptive antenna technology to deliver
high-speed 802.11ac Wi-Fi in an ultra-sleek, low-prole design that can be discretely
installed over a standard electrical junction box. Ideal for oering converged services
in hotel guest rooms, student residences, and multi-dwelling units, the ZoneFlex
H510 provides an easy way to oer multiple connections in a single room without
multiple cables.
BENEFITS
WAVE 2 MU-MIMO
Network performance improved by transmitting to multiple
clients at the same instant.
CONVERGED IP SERVICES
Multiple SSIDs, port-based VLANs and four Gigabit Ethernet
access ports make the ZoneFlex H510 ideal
for supporting concurrent IP-based services such as VoIP,
IPTV, high-speed Internet access and in-room device
connectivity — both wired and wireless
ADDITIVE PERFORMANCE WITH
BEAMFLEX+
BeamFlex+ adaptive antennas improve Wi-Fi signal quality by
adapting to device location and orientation, which is ideal for
better performance on handheld mobile devices
MODULAR SUPPORT
The H510 has been designed to accommodate snap-on
modules for a variety of applications including connectivity
beyond Wi-Fi
STANDALONE OR CENTRALLY MANAGED
The ZoneFlex H510 can be deployed in standalone mode or
centrally managed by the Ruckus ZoneDirector, SmartZone,
or Ruckus FlexMaster systems
The ZoneFlex H510 supports Multi-User MIMO (MU-MIMO) as a Wave 2 solution
and can increase network throughput by transmitting to two Wave 2 clients at
the same instant in time. This ecient utilization of the Wi-Fi channel boosts
performance for Wave 2 clients but also frees up airtime for all clients, which means
even non-Wave 2 clients see a performance benet.
The “mobile device ready” ZoneFlex H510 with BeamFlex+ adapts in real time
to client device location and physical orientation, delivering consistent Wi-Fi
performance. The BeamFlex+ adaptive antenna system of the ZoneFlex H510 is
optimized to deliver best-in-class Wi-Fi coverage and performance in hotel guest
rooms and MDU residences.
Equipped with four Ethernet ports for in-room access, the ZoneFlex H510 can be
used to connect a range of wired network devices such as IPTV set top boxes, IP
telephones, or networked minibars while simultaneously providing dual band 802.11ac
wireless LAN coverage. An IEEE 802.3af-compliant Power-over-Ethernet (PoE)
port on the H510 allows devices such as IP telephones to be powered directly from
the wall switch. The H510 itself may be powered via standard PoE or a DC
power adapter.
The ZoneFlex H510 oers maximum exibility and future-proofed utility. It is
designed to securely support future add-on radio modules for wireless connectivity
beyond best-in-class Wi-Fi. The cable pathways at the rear, support legacy cabling
such as RG6 or CAT3/CAT5. Existing services such as video and voice over Ethernet
can co-exist within the same junction box, reducing both installation time and
construction costs. The H510 can be deployed as a standalone device or centrally
managed by SmartZone, ZoneDirector, or FlexMaster management platforms.
FLEXIBLE DEPLOYMENT OPTIONS
The ZoneFlex H510 requires a single cable drop and operates
under standard 802.3af PoE, reducing cabling, switch ports
and power sourcing equipment
SLEEK, INCONSPICUOUS COMPACT FORM
FACTOR FOR BEST AESTHETICS
Installs into any standard electrical outlet box creating a low
prole, secure design and front port access which eliminates
unsightly cabling and disruptive furniture placement
INTEGRATED POE SUPPORT ELIMINATES
MORE WIRES
POE out to power devices such as IP-based VoIP phones
eliminates the need for more power cords and clutter
© 2016 RUCKUS WIRELESS, INC. COMPANY PROPRIETARY INFORMATION
ZoneFlex H510
29 mm
Multiservice 802.11ac Wave 2 Wired/Wireless Wall Switch
FEATURES
Integrated dual radio 2x2 802.11ac Wav 2 Wi-Fi AP and Ethernet wall switch
•
supporting Multi-User MIMO (MU-MIMO)
Ruckus patented BeamFlex+ adaptive antennas optimized for in-room perfor-
•
mance and mobile clients
Matched Band Coverage ensures similar Wi-Fi coverage for both 2.4 and 5 GHz
•
client devices
Modular options for add-on radios
145 mm
90 mm
•
Powered by either PoE or 48VDC
•
Supplies PoE power for in-room devices such as VoIP phones
•
SmartCast QoS
•
Multiple BSSIDs per radio with unique QoS and security policies
•
WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
•
802.1X support for RADIUS and Active Directory*
•
Dynamic PSK*
•
Application recognition and control*
•
Mounts over a standard US and EU single gang wall jack
•
RJ-45 for uplink Ethernet port
•
Cable channel for preserving legacy infrastructure (e.g. PBX phones)
•
SmartMesh Networking*
•
* with management
DATASHEET
DATA SHEET
© 2016 RUCKUS WIRELESS, INC. COMPANY PROPRIETARY INFORMATION
ZoneFlex H510
Multiservice 802.11ac Wave 2 Wired/Wireless Wall Switch
CONVERGED WIRED AND WIRELESS SERVICES
DATASHEET
DATA SHEET
Laptop
VoIP Phone
IPTV
SmartPhone
In-room IP device
(eg. minibar)
Printer
© 2016 RUCKUS WIRELESS, INC. COMPANY PROPRIETARY INFORMATION
TITLE GOES HERE
ZoneFlex H510
SUB-TITLE GOES HERE
Multiservice 802.11ac Wave 2 Wired/Wireless Wall Switch
DATASHEET
CASE STUDY
DATA SHEET
PHYSICAL CHARACTERISTICS
Power
Physical Size
Weight
Physical Ports
Mounting Options
Environmental
Conditions
Power Draw
POE 802.3af/802.3at
•
48VDC input
•
90 mm x 145 mm x 29 mm
•
230 g
•
292 g with bracket
•
4 10/100/1000 Mbps Base-T 802.3, 802.3u, RJ-45
•
Ethernet access ports.
1 10/100/1000 Mpbs Base-T 802.3, 802.3u,
•
802.3ab, 802.3af (802.3at class 4) PoE input, RJ-45
USB 2.0
•
Electrical wallbox; Standard US and EU single gang
•
wall jack
Optional bracket for oset & wall mount
•
Operating Temperature:
•
32°F (0°C) - 104°F (40°C)
Operating Humidity: 15% - 95%
•
non-condensing
Idle: 6.5 W
•
Typical: 7.3 W
•
Peak, no PoE out load: 9.2W
•
Max load on PoE out:
4W with 802.3af for PoE
•
12.95W with 802.3at PoE in
•
RF
Minimum Rx Sensitivity
Beamex* Sinr Tx Gain
Beamex* Sinr Rx Gain
Interference Mitigation
* BeamFlex gains are statistical system level eects translated to enhanced SINR based on
observations over time in real-world conditions with multiple APs and many clients
Up to -99dBm
•
2dB
•
3-5dB (PD-MRC)
•
5dB
•
PERFORMANCE AND CAPACITY
Concurrent users
Voice Calls
BSSID
100
•
30
•
8 BSSIDs per radio
•
MULTIMEDIA AND QUALITY OF SERVICE
802.11e/WMM
Software Queues
Trac Classication
Rate Limiting
Supported
•
Per trac type (4), per client
•
Automatic, heuristics and TOS based or
•
VLAN-dened
Dynamic, per-user or per-WLAN
•
NETWORK ARCHITECTURE
IP
VLANs
IPv4, IPv6, dual-stack
•
802.1Q (1 per BSSID or dynamic, per user
•
based on RADIUS)
Port-based
•
NETWORK ARCHITECTURE
802.1X For Ethernet
Ports
Authenticator
•
Supplicant
•
MANAGEMENT
Deployment Options
Conguration
Standalone (individually managed)
•
Managed by ZoneDirector
•
Managed by SmartZone
•
Managed by FlexMaster
•
Web User Interface (HTTP/S)
•
CLI (Telnet/SSH), SNMP v1, 2, 3
•
WI-FI
Standards
Mimo Conguration
Supported
Data Rates
Rf Power Output*
(Aggregate)
Channelization
Frequency Band
Operating
Channels
Wireless
Security
* Maximum power varies by country
**See price list for latest country certications
IEEE 802.11a/b/g/n/ac
•
2 x 2 : 2 SU-MIMO
•
2 x 2 : 2 MU-MIMO
•
802.11n/ac: 6.5Mbps – 173.4Mbps (20MHz)
•
13.5Mbps – 400Mbps (40MHz)
•
29.3Mbps – 867Mbps (80MHz)
•
802.11a: 54, 48, 36, 24, 18, 12, 9 and 6Mbps
•
802.11b: 11, 5.5, 2 and 1 Mbps
•
802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
•
2.4 GHz: 18dBm
•
5.0 GHz: 22dBm
•
20MHz, 40MHz, 80MHz
•
IEEE 802.11 b/g/n: 2.4 – 2.484 GHz
•
IEEE 802.11a/ac: 5.15 – 5.25 GHz; 5.25 – 5.35 GHz;
•
5.47 – 5.725 GHz; 5.725 – 5.85 GHz
2.4GHz : 1-13
•
5GHz : 36-64, 100-140, 149-165
•
Channel availability is country dependent according to
•
the local regulations
WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i
•
Authentication via 802.1X with ZoneDirector, local
•
authentication database, support for RADIUS, LDAP,
and Active Directory
PRODUCT ORDERING INFORMATION
MODEL DESCRIPTION
ZoneFlex H510 Wi-Fi Wall Switch
901-H510-XX00
Optional Accessories
902-0170-XX0
902-0162-XX00
902-0126-0000
Dual band Wave 2 802.11ac Wi-Fi Wall Switch
Power Supply (Qty. 1)
•
PoE injector (Qty. 1)
•
Optional Surface-mount bracket
•
