G0602 Retrofit Kit

Table of Contents

THANK YOU ............................................................................................................................................................... 2

PRODUCT SUPPORT .................................................................................................................................................... 2

SAFETY AND USAGE GUIDELINES ............................................................................................................................... 3

SHIPMENT DETAILS .................................................................................................................................................... 4

INSTALLATION ................................................................................................... ERROR! BOOKMARK NOT DEFINED.

MOTOR MOUNTING TO BRACKETS - ALL KITS: .......................................................................................................... 6

Z AXIS- ALL KITS: .............................................................................................. ERROR! BOOKMARK NOT DEFINED.

ACME KIT X & Y AXES: ..................................................................................... ERROR! BOOKMARK NOT DEFINED.

BALL SCREW KIT X & Y: .................................................................................... ERROR! BOOKMARK NOT DEFINED.

CLEANING / MAINTENANCE ..................................................................................................................................... 10

REVISION HISTORY ............................................................................................ ERROR! BOOKMARK NOT DEFINED.

FlashCut CNC Universal Retrofit Kit 2

Thank You

Thank you for purchasing the FlashCut™ CNC Universal Series Retrofit Kit. It is
powered by our own intuitive, powerful CNC control system for Windows 7,
Vista, and XP. No system is easier to set up and use than FlashCut CNC. With
intuitive controls and real time graphics, it lets you make parts quickly and
accurately on your machine tool.

We are dedicated to the excellence and ongoing enhancement of all FlashCut
CNC products. Feel free to call us with any comments or questions.

Product Support

We are committed to the full support of FlashCut CNC products. We have many
resources devoted to helping you resolve your problems quickly. Please use these
resources in the following order:

1. Web Site: www.FlashCutCNC.com

Our website has product specifications, documentation, and a dedicated
support section containing Troubleshooting Guides and FAQ’s.

2. Dealer Support:

If you purchased FlashCut CNC from a dealer or other machine tool
manufacturer, please contact them as they will have the best knowledge
of your complete system.

3. E-mail: [e-mail]

E-mail is the most organized way to convey your issues to our support
staff. In your e-mail, please state your problem completely. Include
your FlashCut version, the processor and speed of your computer, your
version of Windows and your signal generator serial number. Attach
your setup file (usually found in a folder named c:\FlashCut data) and,
when appropriate, the G-Code file with which you are having problems.

4. Phone/Fax Support

In addition to e-mail support, you may call one of our telephone support
numbers. We will normally respond to your call within 24 hours.

Phone: [phone] (9:00 AM-5:00 PM, CST, M-F)
Fax: [phone]

FlashCut CNC Universal Retrofit Kit 3

Safety and Usage Guidelines

When running an automated machine tool, safety is of utmost importance. For
proper and safe use of the FlashCut CNC program and your CNC machine, the
following safety guidelines must be followed:

1. Never let the machine tool run unattended.

2. Require any person in the same room as a running machine tool to wear safety

goggles, and to stay a safe distance from the machine.

3. Allow only trained operators to run the machine tool. Any operator must have:

Knowledge of machine tool operation.
Knowledge of personal computer operation.
Knowledge of Microsoft Windows.
Good common sense.

4. Place safety guards around the machine to prevent injury from flying objects. It

is highly recommended that you build a safety shield around the entire tool
envelope. If your machine came with a safety hood, ensure that the hood is
closed at all times. The machine or spindle should never be on while the hood is
open.

5. Never place any part of your body within the tool envelope while the machine is

online, since unexpected machine movement can occur at any time.

6. Always keep the tool envelope tidy and free of any loose objects. Clean the

machine regularly and remove chips and dust deposits.

7. Be alert for computer crashes at all times.

8. The machine must not be operated in combustible atmosphere.

9. Ensure sufficient ventilation for dust or gas resulting from cutting your parts.

10. Do not use alcohol as coolant (danger of explosion!).
FlashCut CNC, Inc. is not responsible for the safe installation and use of this product.

You and only you are responsible for the safety of yourself and others during the
operation of your CNC machine tool. FlashCut CNC supplies this product but has no
control over how it is installed or used. Always be careful!

FlashCut CNC, Inc., or its affiliates are not responsible for damage to any equipment
or work piece resulting from use of this product. If you do not understand and agree
with all of the above, do not use this product.

IF YOU DO NOT UNDERSTAND AND AGREE WITH ALL OF THE ABOVE,
DO NOT USE THIS PRODUCT.
