130
Pleated media panel filter
• Ecologically advanced filtration medium made
entirely from recycled materials.
• Media maximizing V-pleat design
• Expanded metal grid prevents media flutter
while in operation
• Diagonal and horizontal support members provide frame strength
• Filter media pack is sealed to eliminate air
bypass
• Average efficiency is 30-35% per ASHRAE
52.1-92
• Average arrestance is 93%•
• MERV Rating 8 per ASHRAE 52.2-99
Pre Pleat 40
MERV 8 Extended Surface Pleated Filters
The new MERV 8 Pre Pleat 40 filter features a filtering medium that is more efficient AND ecologically
friendly. Made entirely from recycled materials, this
medium achieves MERV 8 efficiency with low resistance to airflow. It is also unaffected by high humidity
and is hydrophobic (non-moisture absorbing.)
Pre Pleat 40 filters can upgrade existing flat panels as
well as MERV 6 & 7 pleated filters currently being
used with little increase in resistance. All PrePleat 40
filters are 30-35% efficient by ASHRAE 52.1-92 and
MERV 8 per ASHRAE 52.2-99.
These filters are suitable for variable air volume systems. Operating face velocity ranges are from 0 to
500 fpm for 1 in. and 2 in. filters, and from 0 to 625
fpm for 4 in. filters. Pre Pleat 40 filters are UL 900
Class 2 listed but are available with UL Class 1 listing.
Physical Data
Media: 100% Non-woven synthetic media manufac-
tured from recycled material
Media Support: Diamond-shaped expanded metal
Pleat Design: V Pleat
Frame: Moisture-resistant clay coated frame made
with recycled material
Size Range (micron) Initial Fractional
Efficiency (%)
0.35 1.0
0.475 3.0
0.625 9.6
0.85 23.3
1.15 33.8
1.45 42.3
1.9 51.7
2.6 63.4
3.5 71.5
4.75 74.9
6.25 78.3
8.5 83.0
131
1" Standard Model 40 Pleat
PA2832 80055.011010 10X10X1 STD CAP MODEL 40 PLEAT 12
PA2833 80055.011020 10X20X1 STD CAP MODEL 40 PLEAT 12
PA2834 80055.011220 12X20X1 STD CAP MODEL 40 PLEAT 12
PA2835 80055.011224 12X24X1 STD CAP MODEL 40 PLEAT 12
PA2836 80055.011420 14X20X1 STD CAP MODEL 40 PLEAT 12
PA2837 80055.011425 14X25X1 STD CAP MODEL 40 PLEAT 12
PA2838 80055.011520 15X20X1 STD CAP MODEL 40 PLEAT 12
PA2839 80055.011620 16X20X1 STD CAP MODEL 40 PLEAT 12
PA2840 80055.011625 16X25X1 STD CAP MODEL 40 PLEAT 12
PA2841 80055.011824 18X24X1 STD CAP MODEL 40 PLEAT 12
PA2842 80055.011825 18X25X1 STD CAP MODEL 40 PLEAT 12
PA2843 80055.012020 20X20X1 STD CAP MODEL 40 PLEAT 12
PA2844 80055.012024 20X24X1 STD CAP MODEL 40 PLEAT 12
PA2845 80055.012025 20X25X1 STD CAP MODEL 40 PLEAT 12
PA2846 80055.012030 20X30X1 STD CAP MODEL 40 PLEAT 12
PA2847 80055.012424 24X24X1 STD CAP MODEL 40 PLEAT 12
PA2848 80055.012525 25X25X1 STD CAP MODEL 40 PLEAT 12
2" Standard Model 40 Pleat
PA2438 80055.021020 10X20X2 STD CAP MODEL 40 PLEAT 12
PA2439 80055.021220 12X20X2 STD CAP MODEL 40 PLEAT 12
PA2440 80055.021224 12X24X2 STD CAP MODEL 40 PLEAT 12
PA2441 80055.021420 14X20X2 STD CAP MODEL 40 PLEAT 12
PA2442 80055.021425 14X25X2 STD CAP MODEL 40 PLEAT 12
PA2443 80055.021520 15X20X2 STD CAP MODEL 40 PLEAT 12
PA2444 80055.021620 16X20X2 STD CAP MODEL 40 PLEAT 12
PA2445 80055.021624 16X24X2 STD CAP MODEL 40 PLEAT 12
PA2446 80055.021625 16X25X2 STD CAP MODEL 40 PLEAT 12
PA2447 80055.021824 18X24X2 STD CAP MODEL 40 PLEAT 12
PA2448 80055.022020 20X20X2 STD CAP MODEL 40 PLEAT 12
PA2449 80055.022024 20X24X2 STD CAP MODEL 40 PLEAT 12
PA2450 80055.022025 20X25X2 STD CAP MODEL 40 PLEAT 12
PA2451 80055.022424 24X24X2 STD CAP MODEL 40 PLEAT 12
Pre Pleat 40
MERV 8 Extended Surface Pleated Filters
Item No. Model Description Qty/Case
132
PA2452 80055.022525 25X25X2 STD CAP MODEL 40 PLEAT 12
4" Standard Model 40 Pleat
PA2849 80055.041224 12X24X4 STD CAP MODEL 40 PLEAT 6
PA2850 80055.041620 16X20X4 STD CAP MODEL 40 PLEAT 6
PA2851 80055.041625 16X25X4 STD CAP MODEL 40 PLEAT 6
PA2852 80055.041824 18X24X4 STD CAP MODEL 40 PLEAT 6
PA2853 80055.042020 20X20X4 STD CAP MODEL 40 PLEAT 6
PA2854 80055.042024 20X24X4 STD CAP MODEL 40 PLEAT 6
PA2855 80055.042025 20X25X4 STD CAP MODEL 40 PLEAT 6
PA2856 80055.042424 24X24X4 STD CAP MODEL 40 PLEAT 6
PA2857 80055.042529 25X29X4 STD CAP MODEL 40 PLEAT 6
PA2858 80055.042830 28X30X4 STD CAP MODEL 40 PLEAT 6
1" Custom Model 40 Pleat
PA2859 80055.01199 0-199" 1" Custom Model 40 STD CAP. PLT 12
PA2860 80055.01299 200-299" 1" Custom Model 40 STD CAP. PLT 12
PA2861 80055.01399 300-399" 1" Custom Model 40 STD CAP. PLT 12
PA2862 80055.01499 400-499" 1" Custom Model 40 STD CAP. PLT 12
PA2863 80055.01599 500-599" 1" Custom Model 40 STD CAP. PLT 12
PA2864 80055.01699 600-699" 1" Custom Model 40 STD CAP. PLT 12
PA2865 80055.01750 700-750" 1" Custom Model 40 STD CAP. PLT 12
2" Custom Model 40 Pleat
PA2866 80055.02199 0-199" 2" Custom Model 40 STD CAP. PLT 12
PA2867 80055.02299 200-299" 2" Custom Model 40 STD CAP. PLT 12
PA2868 80055.02399 300-399" 2" Custom Model 40 STD CAP. PLT 12
PA2869 80055.02499 400-499" 2" Custom Model 40 STD CAP. PLT 12
PA2870 80055.02599 500-599" 2" Custom Model 40 STD CAP. PLT 12
PA2871 80055.02699 600-699" 2" Custom Model 40 STD CAP. PLT 12
PA2872 80055.02750 700-750" 2" Custom Model 40 STD CAP. PLT 12
4" Custom Model 40 Pleat
PA2873 80055.04199 0-199" 4" Custom Model 40 STD CAP. PLT 6
Item No. Model Description Qty/Case
Pre Pleat 40
MERV 8 Extended Surface Pleated Filters
133
PA2874 80055.04299 200-299" 4" Custom Model 40 STD CAP. PLT 6
PA2875 80055.04399 300-399" 4" Custom Model 40 STD CAP. PLT 6
PA2876 80055.04499 400-499" 4" Custom Model 40 STD CAP. PLT 6
PA2877 80055.04599 500-599" 4" Custom Model 40 STD CAP. PLT 6
PA2878 80055.04699 600-699" 4" Custom Model 40 STD CAP. PLT 6
PA2879 80055.04750 700-750" 4" Custom Model 40 STD CAP. PLT 6
1" Custom Model 40 Pleat Double
PA2880 80055D01399 180-399" 1" Custom STD CAP 40 DBL 12
PA2881 80055D01599 400-599" 1" Custom STD CAP 40 DBL 12
PA2882 80055D01799 600-799" 1" Custom STD CAP 40 DBL 12
PA2883 80055D01999 800-999" 1" Custom STD CAP 40 DBL 12
PA2884 80055D011199 1000-1199" 1" Custom STD CAP 40 DBL 12
PA2885 80055D011399 1200-1399" 1" Custom STD CAP 40 DBL 12
PA2886 80055D011500 1400-1500" 1" Custom STD CAP 40 DBL 12
2" Custom Model 40 Pleat Double
PA2887 80055D02399 180-399" 2" Custom STD CAP 40 DBL 12
PA2888 80055D02599 400-599" 2" Custom STD CAP 40 DBL 12
PA2889 80055D02799 600-799" 2" Custom STD CAP 40 DBL 12
PA2890 80055D02999 800-999" 2" Custom STD CAP 40 DBL 12
PA2891 80055D021199 1000-1199" 2" Custom STD CAP 40 DBL 12
PA2892 80055D021399 1200-1399" 2" Custom STD CAP 40 DBL 12
PA2893 80055D021500 1400-1500" 2" Custom STD CAP 40 DBL 12
4"Custom Model 40 Pleat Double
PA2894 80055D04399 180-399" 4" Custom STD CAP 40 DBL 6
PA2895 80055D04599 400-599" 4" Custom STD CAP 40 DBL 6
PA2896 80055D04799 600-799" 4" Custom STD CAP 40 DBL 6
PA2897 80055D04999 800-999" 4" Custom STD CAP 40 DBL 6
PA2898 80055D041199 1000-1199" 4" Custom STD CAP 40 DBL 6
PA2899 80055D041399 1200-1399" 4" Custom STD CAP 40 DBL 6
PA2900 80055D041500 1400-1500" 4" Custom STD CAP 40 DBL 6
Item No. Model Description Qty/Case
Pre Pleat 40
MERV 8 Extended Surface Pleated Filters
