Flaming River C-10 User Manual

Index
For safety disconnect battery cables and ensure that vehicle is properly supported by jack stands.
NOTE:

Before paint or powder coating of the rack and pinion cradle system we recommend that you pre-fit the system to ensure proper
fit.

Installation hardware and inventory PG 2
Electrical System Verification PG 3

(Only if using a Flaming River Column)
Removal of Factory Steering Shaft PG 3
Removal of Factory Steering Column PG 4

(Only if using a Flaming River Column)
Steering Box & Linkage Removal PG 4-5
Installation of Flaming River Column (For kits including new Column)

Hoses (FR1610) Pump Mounting Bracket (FR1611) is sold sep arately and is not included in this kit.

Installation of New Flaming River Tilt Column PG 6

Electrical System Notes PG 7

Installation of Rack and Cradle PG 8-9
Universal Joint and Steering Shaft Installation PG 10-11

Steering

Wheel Installation PG 12

Power Steering Pump Installation PG 13
Bleeding the power Steering System PG 13-14

Torque Specs PG 14

WARRANTY DISCLAIMER: Flaming River

Flaming River® warrants its products to be free from defects in material and workmanship for a period of one (1) year
after the date of purchase, except that: All steering columns are warranted for a period of three (3) years from the date of
purchase. Flaming River’s® warranty liability is limited to the replacement of defective products. Flaming River® is not
liable for any labor costs associated with any warranty claim, or for any incidental or consequential damages. Improper
installation, abuse, racing, and/or modification of the products voids this warranty. No warranty of merchantability or
fitness for a particular purpose is made by Flaming River® with respect to any of its products. Warnings and
Recommendations It is the customer’s responsibility to determine the suitability of a given Flaming River® product for the
customer’s uses. Likewise, it is the customer’s responsibility to install a Flaming River® product. Contact the vehicle
manufacturer whenever installing a switch to confirm the appropriateness of using such a switch and the recommended
placement of the switch on the vehicle. Use qualified chassis specialists for the installation of all steering rel ated
components. Be aware that the installation of certain Flaming River® products may adversely impact a manufacturer’ s
warranty with respect to certain vehicles and other manufactured goods. Flaming River will rep air or replace any product
found to be defective in material or workmanship. Improper installation, abuse, racing and/or modification VOID
WARRANTY. Flaming River® is not responsible for any labor costs associated with any warranty.

’s® Limited Warranty

1

Power Steering Rack and Pinion Cradle Kit

73-87 C-10 Truck

04/22/10

Installation Kit Hardware Package

QTY Part Number Description

1 100436 C-10 Rack and Cradle Assembly
1 BK10200 Support Bearing Bracket
1 FR1810 Support Bearing
3 7/16"-14x1" 7/16" Driver's Side Mounting Bolts
6 7/16" Flat Wa shers 7/16" Driver's Side Washers
3 7/16" Lock Washers 7/16" Driver's Side Lock Washers
3 7/16"-1 4 Lock Nuts 7/16" Lock Nuts
2 3/8"-16x1" 3/8" Passenger Side Mounting Bolts
4 3/8" Flat Washers 3/8" Pasenger Side Washers
2 3/8" Lock Washers 3/8" Passenger Side Lock Washers
2 3/8"-16 Lock Nuts 3/8" Lock Nuts
1 FR1789P FRPOWER x 3/4"DD Universal Joint
1 FR1920 3/4"DDx3/4"DD Chrome Moly Universal Joint
1 FR1934 3/4"DDx1"DD Chrome Moly Universal Joint
1 FR1850 18" DD Steering Shaft
1 FR30006 or FR30006SS Floorshift Tilt Key Column (Floor Shift Kit)

1 FR30106 or FR30106SS

Column Shift Tilt Key Column (Column Shift

Kit)

1 FR20114 OEM Column Mount
1 FR1614 Power Steering Reservior
1 FRPMPSB-V Power Steering Pump with V-Belt Pulley

2

Power Steering Rack and Pinion Cradle Kit

73-87 C-10 Truck

04/22/10

If using a Flaming River Steering Column it is recommended that before any disassem bly you should first verify the wiring for
your turn signals and ignition switch to ensue proper operation.

Color Verification to be completed before disassembly

Before disconnecting the turn signal and the ignition connectors verify the wiring color to ensure proper operation. The colors
listed with the ignition switch diagram below are from a stock wiring system. Wire colors may change due to the use of
aftermarket wiring harnesses and wiring modifications. The use of a wiring diagram is recommended.

 Brake Light Switch :
 RR Turn Signal :
 LR Turn Signal :
 Turn Signal Power :
 Hazard Power :
 RF Turn Signal :
 LF Turn Signal :
 Horn :

Original Steering Shaft Removal

1) Remove the pinch bolt that retains the steering coupler to the steering column and the bolt that retains the rag joint to
the steering box. Collapse shaft and remove it from the car.

3

Power Steering Rack and Pinion Cradle Kit

73-87 C-10 Truck

04/22/10

Original Column Removal

Only perform these steps if using a new Flaming River Steering Col umn

1) Disconnect the column wiring connectors.

2) Remove the bolts that hold the column floor mount to the firewall.

3) Support the column and remove the bolts that retain the under dash mounting clamp.

4) Remove the factory steering column from the vehicle.

Steering Box and Linkage Removal

Before beginning you must first measure the width of your front end from LEFT outer tie rod end zerk to the RIGHT outer tie rod
end zerk to determine the overall width of your front end. Write dimension here for further reference

1) Remove the pitman arm nut and then the pitman arm from the steering box using a pitman arm puller.

4

Power Steering Rack and Pinion Cradle Kit

73-87 C-10 Truck

04/22/10
