Page 1
PROJECT NAME: _______________________________________
LOCATION: _____________________________________________
1890 Swarthmore Avenue, PO Box 2020, Lakewood, NJ 08701
Phone: 800-526-3694, 732-363-4700, Fax: 732-364-8110
www.amegard.com • www.componenthardware.com
SPECIFIER ITEM NO. ____________________QTY: _________
FLAME GARD PART NO. _____________________________________
Model
FG51-1016
FG51-1020
FG51-1216
FG51-1220
FG51-1616
FG51-1620
FG51-1625
FG51-2016
FG51-2020
FG51-2025
FG51-2516
FG51-2520
Nominal Size
H x W
10" x 16"
(254mm x 406mm)
10" x 20"
(254mm x 508mm)
12" x 16"
(305mm x 406mm)
12" x 20"
(305mm x 508mm)
16" x 16"
(406mm x 406mm)
16" x 20"
(406mm x 508mm)
16" x 25"
(406mm x 635mm)
20" x 16"
(508mm x 406mm)
20" x 20"
(508mm x 508mm)
20" x 25"
(508mm x 635mm)
25" x 16"
(635mm x 406mm)
25" x 20"
(635mm x 508mm)
Actual Dim.’s
H x W x D
9-5/8" x 15-3/4" x 1-3/4"
9-5/8" x 19-5/8" x 1-3/4"
11-5/8" x 15-3/4" x 1-3/4"
11-5/8" x 19-5/8" x 1-3/4"
15-3/4" x 15-3/4" x 1-3/4"
15-3/4" x 19-5/8" x 1-3/4"
15-3/4" x 24-5/8" x 1-3/4"
19-5/8" x 15-3/4" x 1-3/4"
19-5/8" x 19-5/8" x 1-3/4"
19-5/8" x 24-5/8" x 1-3/4"
24-5/8" x 15-3/4" x 1-3/4"
24-5/8" x 19-5/8" x 1-3/4"
Wt. Per
Filter
2.6 lbs
(1.2 kg)
3.2 lbs
(1.5 kg)
3.0 lbs
(1.4 kg)
3.6 lbs
(1.7 kg)
3.8 lbs
(1.8 kg)
4.5 lbs
(2.1 kg)
5.6 lbs
(2.6 kg)
4.6 lbs
(2.1 kg)
5.5 lbs
(2.5 kg)
6.7 lbs
(3.1 kg)
5.7 lbs
(2.6 kg)
6.8 lbs
(3.1 kg)
Case
Qty.
10
10
10
10
10
10
10
10
10
10
10
10
Flame Gard is a registered trademarks of Component Hardware, registered in the US
Specications subject to change without notice © Component Hardware
C US
®
LISTED
File No. R10173
NFPA #96
