PROJECT NAME: _______________________________________
A
B
C
D
LOCATION: _____________________________________________
1890 Swarthmore Avenue, PO Box 2020, Lakewood, NJ 08701
Phone: 800-526-3694, 732-363-4700, Fax: 732-364-8110
www.amegard.com • www.componenthardware.com
BODY
BODY GASKET
LOCK WASHER
HEX NUT
REF: HOOD or DUCT
C
Ø
REF: TUBE/PIPE
COMPRESSION NUT
HOLE
B
A
SPECIFIER ITEM NO. ____________________QTY: _________
FLAME GARD PART NO. _____________________________________
Model No. Quick-Tite Fitting Hole Cut Out Size A B C
F15-250T 1/4” (6mm) Tube
F15-375T 3/8” (10mm) Tube
F15-500T250P
F15-625T375P
F15-500EMT 1/2” (13mm) EMT Conduit
F15-500P 1/2” (13mm) Pipe
F15-750P 3/4” (19mm) Pipe
F15-1000P 1” (25mm) Pipe
1/2” (13mm) Tube &
1/4” (6mm) Pipe
5/8” (16mm) Tube &
3/8” (10mm) Pipe
13/16” (21mm) to
7/8” (22mm)
1-3/16” (31mm) to
1-5/16” (33mm)
15/16” (24mm) to
1” (25mm)
1-3/16” (31mm) to
1-5/16” (33mm)
1-7/16” (37mm) to
1-9/16” (40mm)
1-11/16” (43mm) to
1-7/8” (48mm)
2-1/16” (53mm) to
2-1/2” (64mm)
2-5/8” (59mm) to
2-1/2” (64mm)
1.125
1.8
HEX
1.125
1.8
HEX
1.125
1.8
HEX
2.0 1.5 HEX .37
2.0 1.5 HEX .37
2.08 1.5 HEX .37
1.875
2.37
HEX
2.5 2.25 HEX .44
.31
.31
.31
.37
SEAL RING
BODY
BODY GASKET
LOCK WASHER
HEX NUT
Flame Gard is a registered trademarks of Component Hardware, registered in the US
Specications subject to change without notice © Component Hardware
C US
®
LISTED
3RS9
File No. MH19744
