BlueTone™ BTHF205 User Manual
Bluetooth Handsfree User Manual
Model：BlueTone™ BTHF205
. 1
BlueTone™ BTHF205 User Manual
Declaration:
Without written permission from original manufacturer, reprodu ction, transfer, distribution or storage of
part or all of the contents in this document in any form is prohibited.
The company reserves rights to make any changes and improvements to the product described in this
document without p rior notice.
Notice ：
Please make sure your mobile phone supports Bluetooth profiles and network operator supports the
functions described in this manual, otherwise the relative functions cannot b e realized on this Handsfree
device.
Safety
Use the charger that comes with package.
Caution, risk of explosion if battery is replaced by an incorrect type.
Check the laws and regulations on the use of mobile phones and handsfree equipment in the areas where you
drive. Always give full attention to driving and pull off the road and park before making or answering a call if
driving conditions require.
Do not allow children to play with your Bluetooth Handsfree Speaker since it contains small parts that could
become detached and create a choking hazard.
This device contains a Li-polymer battery. Please keep it away from fire anytime (including discarding the
device) or the battery may explode.
The Handsfree Speaker, especially the embedded battery must be properly disposed or may be recycled,
contacts your local recycling centers for disposal methods.
. 2
BlueTone™ BTHF205 User Manual
Certification and Safety Approvals
This product has been tested and found to comply with Bluetooth BQB requirements, part 15 of FCC rules,
R&TTE Directive（99/5/EC） or CE marked requirements.
Warning：Users should not make changes or modify the device in any way. Changes or modifications
without expressly approved by the party responsible for compliance could void the user’s authority to
operate the device.
This device complies with part 15 of th e FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interf eren ce, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been t ested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to p rovid e reasonab le protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and u s ed in accordance with the instructions, may cau se harmful interference to
radio communications. However, there is no guaran tee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning t h e equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenn a.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which th e receiver is conn ected.
-Consult the dealer or an experienced rad i o/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
RF exposure warning：
This equipment must be installed and operated in accord ance with provided instructions and the antenna(s)
used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction with any other antenna or tran smit ter. End-users
and installers must be provide with antenna installation instructions and transmitter operating conditions
for satisfying RF exposure compliance.
CE command：
EN 301 489-17 v1.2.1: 2002
ETSI EN 300 328 v1.6.1:2004
IEC 60950-1:2001 / EN 60950-1:2001
. 3
BlueTone™ BTHF205 User Manual
Contents：
1. INTRODUCTION.................................................................................................................................5
1.1 BLUETOOTH TECHNOLOGY ..................................................................................................................5
1.2 BLUETOOTH HANDSFREE SPEAKER......................................................................................................5
1.3 P
RODUCT FEATURES
1.4 PACKAGE CONTENTS............................................................................................................................6
1.5 OVERVIEW ...........................................................................................................................................6
2. USING YOUR HANDSFREE..............................................................................................................7
2.1 BATTERY CHARGING AND USAGE ........................................................................................................7
2.1.1 Battery Charging .........................................................................................................................7
2.1.2 Battery Information .....................................................................................................................7
2.2 MOUNTING YOUR HANDSFREE .............................................................................................................8
2.3 TURN ON/OFF HANDSFREE ..................................................................................................................9
2.4 PAIRING/CONNECTING YOUR HANDSFREE WITH BLUETOOTH EQUIPMENT ..........................................9
2.4.1 Pairing your Handsfree with Bluetooth handset..........................................................................9
2.4.2 Erase all Paired Records............................................................................................................10
2.4.3 Connecting/Disconnecting your Handsfree with Bluetooth Equipment ....................................10
2.5 C
ALL FUNCTIONS
2.5.1 Basic Call Operations ................................................................................................................10
2.5.2 Call Mute...................................................................................................................................11
2.5.3 Transferring Calls to/from your Handset...................................................................................11
2.5.4 Voice Dialing.............................................................................................................................11
2.5.5 Advanced Call Functions...........................................................................................................11
2.6 AV FUNCTIONS..................................................................................................................................11
2.6.1 Using Handset AV Function......................................................................................................12
2.6.2 AV Operations...........................................................................................................................12
2.7 VOLUME ADJUSTMENT.......................................................................................................................12
2.8 PAIRING/CONNECTING YOUR HANDSFREE WITH OTHER BLUETOOTH EQUIPMENT ............................12
2.8.1 Pairing Handsfree with Other Bluetooth Equipment.................................................................12
2.8.2 Connecting your Handsfree with USB Dongle..........................................................................12
............................................................................................................................5
...............................................................................................................................10
3. UPGRADE SOFTWARE ...................................................................................................................14
4. QUICK USER GUIDE........................................................................................................................15
4.1 LED INDICATOR PATTERNS ...............................................................................................................15
4.2 QUICK USER GUIDE............................................................................................................................15
5. MAINTENANCE................................................................................................................................19
6. IMPORTANT MESSAGES AND FREQUENTLY ASKED QUESTIONS...................................20
. 4
BlueTone™ BTHF205 User Manual
1. Introduction
1.1 Bluetooth Technology
Bluetooth is an internationally standardized technology supporting short distance wireless communications. Any
two Bluetooth-compatible equipments, such as mobile phone, PDA、PC, headset, mouse, keyboards, printer, etc.
can wirelessly communicate with each other via Bluetooth connection. To ensure worldwide compatibility,
Bluetooth operates on the globally available ISM (Industrial Scientific and Medical) frequency band. Within 2.4
GHz and 2.48 GHz, Bluetooth transmits data up to either 10 meters (CLASS II mode) or 100 meters (CLASS I
mode) using 79 frequency hopping channels.
Though line-of-sight is not required, Bluetooth connections could be subject to interferences from obstructions such
as walls, human bodies, and other electronic devices. In addition, due to variations on product implementation, it is
likely that Bluetooth equipments from different manufactures have interoperability issues. In that case, you may
consult with manufactures to check product compatibility.
Note that, there could be some restrictions imposing on using Bluetooth devices in some countries. Please check
with your local authorities.
1.2 Bluetooth Handsfree Speaker
This Bluetooth handsfree speaker is a specially designed BlueTone™ series product allowing car drivers to make
and receive calls without holding a mobile phone. It provides a clean wireless audio connection with your
Bluetooth mobile phone and PDA.
In addition to vehicle environment applications, this portable equipment, supported by an internal rechargeable Li-
ion battery, can also be used in office environment as normal handsfree equipment to make/receive/conference
phone calls. It can also be placed beside a Bluetooth-enabled PC to make voice calls over the Internet.
1.3 Product Features
Bluetooth v 1.2 compliant, interference-tolerable with WLAN devices
Class II, operating range up to 10 meters
Data rate up to 723 Kbps
Compatible with most Bluetooth-enabled devices such as cellular phones, PDAs, and computers for voice
communication and music playing
Support up to 8 handset pairing information
Best-in-class voice quality ensured by cutting-edge noise suppression and echo cancellation techniques
Voice dialing and user friendly operation keys ideal for car drivers to make/receive calls
Support call waiting and conference functions
Support end-user software self-upgradeable to improve future handset compatibility
Voice security ensured by using 128-bit encryption
Audio output up to 120 dB
Better portability with internal rechargeable Lithium Polymer battery
. 5
BlueTone™ BTHF205 User Manual
Low power consumption, up to 9 hours continuous talk time and 25 days standby time with the internal battery
Easy-to-mount with magnetic mounting design and Sun visor clip
Robust performance, fast connection, accurate and sensible search of devices in range
Stylish, portable, lightweight, mini-sized, suitable for vehicle and office environment
1.4 Package Contents
BlueTone™ BTHF205
Sun-visor Clip
Vent Mounting Clip
12/24V Car Charger Set（or Traveling Charger Set，Optional）
User Manual
1.5 Overview
1
2
6
7
5
4
Figure 1 Overview
1
1
1
1
1
8
3
1. Speaker：Voice/AV music delivery.
2. Red/Blue LED：Indicate device status.
3. Button
4. Button
：Switch the device on/off.
： Answer/end call, connect/disconnect, transfer a call between handsfree and phone.
5. Button ╋：Volume up, last number redial, call mute.
6. Button ━：Volume down, erase all paired records, reject call, voice dialing, call mute.
7. Microphone：Voice pick-up
8. Charging Port
. 6
：Connect to the travel (or car) charger to charge the battery of device
