Owner’s Manual:
FDX 2.0 - 003
CAUTION!
READ ALL INSTRUCTIONS.
TAKE THE TIME TO READ THE SAFETY TIPS
AND MAINTENANCE SECTIONS. NO EXERCISE
EQUIPMENT IS SAFE UNLESS YOU LEARN HOW
TO SAFELY OPERATE THE EQUIPMENT.
REGULAR MAINTENANCE IS VERY
IMPORTANT!
THIS PRODUCT HAS MOVING PARTS. TAKE ALL
PRECAUTIONS WHEN CHILDREN, PETS AND
OTHER OBJECTS NEEDING CARE ARE IN THE
AREA OF THIS PRODUCT. USE RESPONSIBLY,
MACHINE CAN TIP, ITEMS CAN GET CAUGHT IN
THE PEDALS. TAKE EXTRA CARE WHEN
FOLDING, TRANSPORTING, UNFOLDING AND
MAKING ANY ADJUSTMENTS TO PRODUCT.
WHEN USING DESK AREA TO PLACE ITEMS ON
– ALWAYS USE SAFETY STRAP TO HOLD ITEM
DOWN. IF YOU DO NOT HAVE A STRAP.
CONTACT US. WE CAN HELP.
WE WANT YOU TO SAFELY USE THIS
PRODUCT. PLEASE DO NOT HESITATE TO
EMAIL, CALL OR TEXT IF YOU HAVE ANY
QUESTIONS.
EMAIL: CUSTOMERSERVICE @FITDESK.NET
PHONE: 615-669-9004
Assembly Instructions
Operations Manual
Where Productivity and Health Converge
If you need to return:
PLEASE CONTACT US FOR REPACKAGING
INSTRUCTIONS
OR
FOR ASSEMBLY INSTRUCTIONS,
MISSING PARTS, OR FOR HELP WITH A
QUESTION at :
Customerservice@fitdesk.net
Also we have a detailed FAQ section at our website
www.FitDesk.net
Or call Monday to Friday 9am to 5pm CST
615-669-9004
For fastest possible service please have:
- Model # (refer to this manual)
- Serial # (located on stabilizer bar sticker)
Technical Specs
Table of Contents
Technical Specifications
Recommended User Height Range = 4’10” to 6’5” (147cm to 199cm)
Recommended Max User Weight = 300lbs (136kgs)
Weight of Bike: 47lbs
Foot Print in OPEN position = 16” wide X 26” long X 45” high
Table of Contents
[] Precautions
[] Parts and Maintenance
[] Get to know your FitDesk 2.0
[] Assembly Instructions
[] Meter Instructions
[] Contact Information
Safety
Precautions
Precautions…Please read before assembly or operations
1. Read the entire manual before assembling and using the equipment. Safe use can only
be achieved if the equipment is assembled, maintained and used properly. All users of the
equipment must be informed of all warnings and precautions.
2. Before starting or using this equipment including massage roller you should consult your
doctor to determine if you have any health conditions that could create a risk to your health
and safety, or prevent you from using the equipment properly. Before using massage roller
it is your responsibility to learn if use of this can cause or aggravate conditions regarding
your health. Your doctor's advice is essential if you are taking any medication.
3. Be aware of your body's signals. Incorrect or excessive exercise can damage your health.
Stop exercising if you experience any of the following symptoms: Pain, tightness in your
chest, irregular heartbeat, extreme shortness of breath, feeling light headed, dizzy or
nauseous. If you do experience any of these conditions or any other signs that concern you,
Please consult your doctor before continuing with your exercise program.
4. Fingers can get pinched when picking up the bike. Lift by seat and handlebar only.
5. The frame must be in the closed and locked position prior to transport. Frame locks in
closed position.
6. Read and follow the warning stickers on the FitDesk®.
7. Warm-up stretching is recommended before exercise. ALWAYS USE GOOD POSTURE
8. Make sure your all devices are tightly secured to the desk top by the strap provided. Keep
wires from getting tangled while pedaling.
9. Mount and dismount carefully.
- Extreme movements CAN TIP MACHINE
- INJURY AND EQUIPMENT DAMAGE CAN OCCUR
- Do not use while standing on pedals
10. Keep pets and young children away from the equipment.
11. Use the equipment on a solid, level surface with a protective cover for your floor or
carpet. The equipment should have at least one yard of free space all around it.
Precautions
Please read this section
Safety Precautions
Continued
Precautions…Please read before assembly or operations
12. Inspect and tighten all parts often. Replace any worn parts immediately. The safety level
of the equipment can only be maintained if it is regularly examined for damage and/or wear
and tear.
13. Always use the equipment as indicated. If you find any defective components while
assembling or checking the equipment, or if you hear any unusual noises coming from the
equipment during use, stop immediately. Do not use the equipment until the problem has
been rectified.
14. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may
get caught in the equipment or clothing that may restrict or prevent movement.
15. Do not exceed maximum recommended user weight of :300lbs, 136 kg
Recommended for ages 13+
16. The equipment is suitable for home and office use only. Do not use in commercial or
rental settings. This item was not intended or designed for use in commercial or public
places.
17. Keep wires from getting tangled in pedals. Suggestion is to wrap computer-charging
wires over meter holder to keep away from pedals and in center of desk, NOT on side.
18. Do not stand while pedaling.
For light use only
19. SADDLE COMFORT We here at Revo Innovations LLC love cycling and try to ride
everyday. But we do remember how painful it was to “adjust” to cycling saddles. There is no
“magic” way to ease the discomfort caused when spending time on a saddle. The good
news is it can be a “one time” event. As a safety precaution we recommend you consult with
a doctor if you feel pain or are concerned about issues that are outside the explanation here
about saddle comfort. We recommend these tips to help make adjusting easier.
- Wear padded cycling shorts
- When you feel pain exit cycle and walk around for a few minutes before getting back on
- Use padded saddle cover (we like the sheepskin type)
- Try different saddles (we have adapter available for lowest possible costs) with free return
shipping.
20. Resistance Bands: Do not use when person is in area. Never let go of handles while
stretching. Do not stretch too far. Replace when you see any signs of wear. Do not take off
of bike to use. Do not allow children to play with them. Do not twist while using.
08
01
59
93
66
72
67
62
45
14
23
49
10
28
13
18
43
43
20
05
55
02
49
102
03
95
95
25
07
86
05
39
40
79
79
69
99
16
88
88
06
53
54
06
06
06
06
21
21
70
100
27
61
61
61
61
61
48
48
25
11
15
15
15
12
12
22
22
11
11
11
15
19
19
41
42
98
24
46
46
46
46
47
47
52
64
64
60
60
60
60
94
94
94
09
26
97
51
50
50
104
44
44
37
38
106R
106L
71
32
33
65
65
77
78
76
76
76
107
04
07
10
17
26
26
29
30
31
35
34
40
36
39
39
56
57
58
58
63
63
68
07
74
73
75
79
80
82
81
83
84
84
85
85
87
90
89
89
91
91
91
85
85
92
101
105
74
103
96-1
108
16
40
39
15
15
50
91
91
91
91
91
96
96-1
96-2
96-2
109
Parts and
Maintenance Tips
TIP:
• Check Pedal tightness with 15mm wrench WHEN NEW THEN AFTER 30 miles. KEEP
VERY TIGHT. IF you hear a “click” noise when pedaling the pedals are loose. Retighten
and install THREAD LOCK TO PEDAL THREADS.
• Tighten Crank Arms with 14mm socket after initial 100 miles use.
• Check Crank Arm and Pedal tightness every 300 miles
• Check Base Stabilizers for tightness every 300 miles
• FitDesk® uses a low maintenance twin belt drive mechanism and rarely ever needs
adjusting. However if belt slipping is noticed remove gearbox covers, loosen Idle wheel
nuts (21) and tighten adjuster nuts (22) till slipping stops. Re-tighten and Re-assemble
• Check frame, seat mount, handlebar mounting areas for wear. Do not use if any sign of
frame cracking. Contact us here at Revo Innovations LLC.
Complete Exploded View
Precautions…Please read before assembly or operations
Get to know your
New FitDesk® 2.0
Seat Back for multi-position
use
Resistance Bands provides
convenient and effective
upper body exercise
Easy and safe folding frame
design
Sliding Desk for comfortable
daily use
Resistance knob
adjusts pedal tension
with plenty of room
to grow into
Cycle computer
tracks Time, Speed,
Distance, Calories
and Total miles
PRESS MODE
BUTTON AT
VERY BOTTOM
This model FitDesk® uses a Quick release frame unlock
design.
As a safety precaution please use the technique shown
here to Open and Close
To Open: pull pin on frame support while placing foot
on base. Then release
To Close:
1. Remove any items on desk and in drawer.
2. Pull pin and close frame by lifting on bottom of
saddle and desk. Frame is locked when PULL
PIN clicks in.
Under desk storage
drawer.
FRAME UNLOCK
OPERATION
SEE OUR COMPLETE LINE
OF ACCESSORIES TO
CUSTOMIZE YOUR NEW
FITDESK® AT
www.fitdesk.net
TIP: Make Pedals EXTRA Tight during Assembly. Use
thread lock on pedal threads during assembly
SADDLE
DESK
METER
SADDLE
BACK
ASSEMBLY
MAIN FRAME
METER
HOLDER
RESISTANCE
BAND
HOLDER
SADDLE POST
REAR
STABILIZER
FRONT
STABILIZER
DESK FRAME
SUPPORT
DESK STRAP
SADDLE
HEIGHT
RESISTANCE BANDS
PEDALS
MASSAGE BAR
SADDLE
HEIGHT
ADJUSTER
KNOB
ASSEMBLY
TOOLS
DESK DRAWER
Parts List
Get Started Assembling
Your New Exercise Bike
Assembly Instructions
Step #1 Install Stabilizers
Remove Main Frame (01) and all components and place on a clean durable surface. Note: most
mounting hardware is pre-installed for easy matching during assembly. Tools are provided
• Unlock Main Frame (01) to “Open” position by pulling Frame Lock Pin (55) while pushing
lightly with foot on stabilizer, then release.
• Install front (59) and rear (62) stabilizers to Main Frame (01) with hex cap nuts (61) and
curved washer (06), tighten securely. Rear Stabilizer has transport wheels.
STEP#1
STEP#2
MOUNTING HARDWARE IS LOCATED
ON PARTS THEY ARE TO BE
INSTALLED ON FOR EASY IDENTITY
Step #2 Install Pedals
• Note:Left Pedal installs counter clockwise. Install by rotating to LEFT. Use
care that Pedal Shaft is Perpendicular to Crank Shaft.Use5/8” or 15mm wrench
or supplied wrench to tighten. Check pedals often for tightness when new.
• Note: Crank arms should be checked for tightness using 14mm socket after
first couple hours of use.
Important!
Make
Pedals
Extra
Tight !
Note: Pedals must be made extra tight. USE 5/8” or 15mm Wrench
TIP: Tap end of wrench with Hammer till EXTRA Tight. Use thread lock on pedal
threads.
104
102
05
07
101
68
70
69
72
67
66
Get to know your
New Exercise Bike
Assembly Instructions
Continued
STEP#5 Install Resistance Bands
• Clip Resistance Band Holder to Seat Back Tube here –
• Place one RB Handle through opening here:
• Place Tube in metal loop
• Hang handles on Resistance Band Holder
Step#3 Install Saddle Tube and Saddle
• Install Saddle Tube Adjuster Knob (104)
• Assemble Saddle (98) to Seat Tube (66) using Nut (100) and Washer (99)
• Note: FitDesk® is supplied with optional saddle height extender (71) for increased
leg extension if needed. Recommended for use if taller than 5’9” / 175cm
• Height is adjusted using Knob (104). You do not have to remove to adjust. Loosen and
Pull – retighten.
STEP#4 Install Saddle Back
• Mount Saddle Back
Assembly (67) to
Saddle Post (66) with
Carriage Bolt (68),
Nuts (70), Washers
(69)
• Choose High or Low
Position and Mount
Saddle Back Cushion
(101) to Saddle Back
(72) using bolt (05)
and washer (07).
97
105
91
92
05
07
06
85
80
85
Get to know your
New Exercise Bike
Assembly Instructions
Continued
STEP#7 Install Desk Assembly to bike frame
• Locate and remove 2 handlebar mounting bolts
(05) with washers (07,06) in bike main frame.
• Place Desk over bike main frame and install the 2
bolts with washers in to threaded holes as shown
to right.
• Tighten with 5mm hex wrench to a snug fit. Do
NOT over tighten
• Connect Meter wire (92) to wire from frame
STEP#9 Assemble Massage Bar Arm Rests
• Bolt Massage Bar (80) to Desk using Knob Bolts (85)
• Massage Bar (80) can be set in 3 positions above Horizontal. Choose a desired height.
Align each Support Arm in same position on each side. Tighten Knob Bolt (85)
3 position armrest height adjustment
STEP#6 Install Meter Holder to bottom of desk
• Slide Meter Holder (105) and meter wire
through opening in top center
• Install and tighten 2 screws (91) through
Meter Holder (105)
• Slide Meter (97) on to Meter Holder (105) and
plug meter wire in to back of meter
STEP#8 Install Drawer to Desk
• Align and Slide Drawer Assembly to
Desk Rails located on bottom of
Desk.
• Push through to rider side
104
89
85
Adjust To Fit
STEP#9 Adjust for comfort
• Massage Bar has 3 positions for supporting arms while in use. Remove knob (85) and lift or
lower to best position. Re-install and Tighten Knob
• Desk and ride position can be adjusted by loosening Knobs (89) located on underside of Desk.
Slide to comfortable position and Tighten Knobs.
• Saddle Height can be adjusted for comfortable use while pedaling. Loosen Knob (104), Pull
to release pin, adjust to height, release and tighten Knob.
Loosen knobs (89) to slide desk.
Raise or Lower Massage Bar with
Knob (85)
Easy adjust seat height
knob
Loosen, pull, adjust, retighten
Use upright or semi-recumbent
Thread Hold Down Strap Through Openings in Desk and
around device. Wrap Thru “D” rings and pull tight
Saddle Back can be
set lower or high by
choosing mounting
hole.
Adjust Saddle
Back Tilt Forward
or Backward Here
Use 5mm Hex Key
Hold Down Strap
104
Resistance Bands
Resistance Band Use
Instructions
Handle rest on Hanger Under Saddle
Your FitDesk® is supplied with a Premium Latex Resistance Band. Having this proven fitness staple
near you throughout the day is a great option for more exercise. Here we want you to take a look at
ways you can use your FitDesk® Resistance Bands and also show you how to maintain them for
maximum safety.
Never stretch the tube more than 2 times its
length.
Never use bands with people near you so if
you loose grip of band you will hit them or
yourself. Do not direct resistance band too
close to your face. Always inspect the tube,
handle and locking device before use. Look for
cracks, cuts, wear marks. Handles must be
checked they are free of cracks and all
components are secure. Use caution to assure
the tube is passing only through “Loop” in
frame support tube. Do not use bands in a
“sawing” motion through frame loop. Take
care of bands to assure they are safe before
each use.. Contact us for replacements. Use
caution when reaching under saddle to mount
handles on hanger. Stop pedaling, drop
handles on floor and dismount and put handles
on. Do not pedal bike and do arm exercises at
the same time. Use caution not to get the
resistance bands caught in the pedal arms.
Fitness training can result in serious injury or
death if not done safely and properly. Risk can
be reduced if take common safety measures to
avoid injuring yourself or others. Over
stretching the bands can cause damage to band
which may result in the band breaking
unexpectedly. These bands are for light use.
How to use the FitDesk® Resistance
Bands:
- Stop pedaling
- Reach under saddle and grab hold of
both handles.
- Raise 1 arm at a time while holding
the other arm in position.
- Repeat the other side.
Warning
Meter
Instructions
Performance Monitor Operation Manual and Troubleshooting
Specifications:
Speed = Miles per hour
Distance = Mi
Calories = Kcal
Odometer = Mi
OPERATION PROCEDURES:
1. AUTO ON/OFF
◆ The system turns on when any key is pressed or when it senses input from the
speed sensor.
2. RESET
The unit can be reset by pressing the RESET key. Make sure NOT in SCAN
MODE. Each field resets independent from each other.
3. MODE – tap twice to take out of SCAN MODE.
To choose a function, press the MODE key when the pointer is on the function
you want. It will begin blinking. Press MODE key in lower area of button.
FUNCTIONS:
1. TIME: Press the MODE key until the pointer is on TIME. The time of the
workout will be displayed.
2. SPEED: Press the MODE key until the pointer advances to SPEED. The
current speed will be shown.
3. DISTANCE: Press the MODE key until the pointer advances to DISTANCE.
The distance of each workout will be displayed.
4. CALORIE: Press the MODE key until the pointer advances to CALORIE. The
calories burned will be displayed.
5. ODOMETER Press the MODE key until the pointer advances to ODOMETER.
The total accumulated distance will be displayed.
SCAN: Automatically display changes every 4 seconds.
Trouble Shooting
BATTERY: If there are problems with the display try reinstalling the battery.
Connection: If no reading when pedaling disconnect, clean and reconnect link.
Button Functions:
Mode: (Select/Reset) Press BELOW THE
PRINTING “MODE”
Clear (Reset)
Set: Toggles data
Where%Productivity%and%Health%Converge%
%
Tell others how we are doing. Your Review pays for donations of FitDesk’s at
schools across the nation. For every 10 reviews we donate 1 FitDesk to a school in
USA…
Please take a moment to help this cause.
http://www.amazon.com/fitdesk
or
www.fitdesk.net/review
Here is a quick scan code for fastest way to leave a review
Now you can turn your computer time in to the healthiest part of your day. See our
complete line of products designed to merge your productive time with your health
goals.
See our latest products and accessories at
Our website:
www.fitdesk.net
Email: customerservice@fitdesk.net
Loading...
