High Denition DVB-T Receiver
User Manual
Model Number: DK-5203
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
Contents
What Your 1 Year Warranty Means............................................................................. 03
General Information and Safety Instructions...................................................... 04
Assembly and Parts List................................................................................................... 05
Instructions.............................................................................................................................. 06
Hardware Driver Installation................................................................. ................. 06
Software Installation.................................................... ............................................... 08
Total Media User Manual.......................................................................................... 11
Hardware Installation.................................................... ............................................. 12
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
02
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
03
What Your 1 Year Warranty Means
Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly. In
the event of product failure within its intended use over the course of the
rst 1 year after the date of purchase, we will rectify the problem as quickly
as possible once it has been brought to our attention. In the unlikely event
of such an occurrence, or if you require any information about the product
please contact us via our after sales support services, details of which can
be found in this manual and on the product itself.
General Information and Safety Instructions
Quick Installation Guide
Special Notes
1. This device requires Microsoft Windows™ XP, Vista or 2000/SP4, as
well as Microsoft DirectX™ 9.01a or above. Before driver and software
installation, download DirectX™ 9.01a from Microsoft website www.
microsoft.com (if not already installed).
2. The power consumption of a USB port is limited; therefore, please
disconnect all other USB devices when using your USB Digital TV
device (DTV). If the “USB Device Not Recognized” error message pops
up while connecting the USB DTV device, please disconnect all USB
devices and try to reconnect.
3. Please note that each USB port has a unique ID; therefore, when the
USB DTV device is connected to a USB port, which has never been
connected with this device before, the system will promptly re-install
the driver. Please follow the procedures of Driver Installation to install
the drivers properly (after installation as below). This is particularly
obvious when using a USB Hub.
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
04
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
05
Assembly and Parts List
• Tevion USB DVB-T Tuner
• DVB-T Antenna
• Remote Control
• Software CD with Manual
Instructions
Hardware Driver Installation
1. Insert the software CD into the CD-ROM drive.
2. The CD ROM will automatically enable the Autorun program.
3. Please click “Driver Installation” to install the driver for the USB DTV
receiver. (If the installation does not automatically start, please go to
the directory of “E:\Driver\Driver” and execute “setup.exe” to install the
driver - if E:\ is your CD Rom drive).
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
06
4. Click "Next"
5. Click “Finish” to complete the driver install.
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
07
Software Installation
1. Click the “Arcsoft Total Media” option on the Autorun page to install
Total Media software. (If the installation does not automatically start,
please go to the directory of “E:\TotalMedia 3” and execute “setup.exe”
to install the software - if E:\ is your CD Rom drive).
2. Please choose appropriate language.
3. Click “Next”
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
08
4. Click “Yes”
5. Put in Name, Company Name and Licence Key (from White CD-cover)
and Click “Next”
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
09
7. Click “Next
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
10
6. Click “Next
7. Click “Finish” to nish the software installation
Total Media User Manual
1. Double click the “Manual” option on the Autorun page. It will
automatically open the “Manual” folder.
2. Please choose your favorite language for the operational reference.
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
11
Hardware Installation
1. Please connect antenna rst.
Note: The antenna supplied is intended for use in strong signal areas,
preferably for outdoors. For indoor use or for weak signal areas, it is
recommended that the receiver be connected to an external TV antenna.
2. Take the USB connector of the device and connect it directly into any
available USB port of the computer.
After Sales Support TEL: 1300 558 702 WEB: www.unisupport.net
12
