Fisher-Price N9628 Instruction Sheet
®
®
®
PHYSICAL LEARNING ARCADE SYSTEM
Get up. Get smart. Get going!
It’s a stationary bike, a learning center, and an arcade game
system – all rolled into one! Smart Cycle® plugs right into
your TV, ready to take kids on learning adventures like no
other. As they pedal, favorite character friends guide them
through learning discoveries, games, and even exciting races.
And now they can do it all with Rumble Action -cool vibrations
that add an extra dimension of fun!
Drive
Pedal, steer and learn at your own pace –
visit Math Mountain, Shape Lake,
Number Fields,Letter Creek and other
stops along the way.
Learn
Stop and rest, but don’t stop
learning! Use the joystick to reinforce important learning skills with
plenty of games and activities – with
different levels for growing kids.
Race
Put the pedal to the metal as you
race with cars on-screen, against
the clock, or with another player!
2
Parts
ed
e
(Wide)
Frame with Console
and Plug-and-Play Cord
Assembly Tool
Front Base
(Wide)
Seat
2 P
2 Pedals
(Left and Right)
Adult assembly is required. Tools needed for assembly:
Phillips screwdriver (not included) and assembly tool (included).
Back Base
ack Bas
(Narrow)
Learning Adventure Game Cartridge
with Key Ring
Handlebar
1
/2" Screws – 4
#10 x 1
(Use in Assembly steps 2 and 3.)
Shown Actual Size
Note: Tighten and loosen all screws with a Phillips screwdriver. Do not over-tighten screws.
#8 x 1" Screws – 6
(Use in Assembly steps 5 and 9.)
3
S
Seat Peg
•
yc
•
Seat
eat
Assembly
Front Base
(Wide)
1
• Turn to remove the seat peg from
Turn to re
the frame.
• Insert the seat into the slot in the frame.
• Replace the seat peg and turn to secure.
Hint: You can adjust the seat height (higher
or lower) for your child's comfort. Simply
remove the seat peg and lift or lower the
seat. Replace the seat peg to secure the seat.
4
2
• Turn the cycle upside down.
Turn the c
• Identify the front base (wide) and the rear
base (narrow).
• Fit the front base (wide) into the groove
in the front of the frame.
Hint: The front base is designed to fi t easily
into the groove in the frame. If it does not
fi t, turn the base around so that it curves
away from the seat.
• Insert two #10 x 11/2" long screws
through the tube in the front base
and tighten.
Rear Base
b
•
in
(Narrow)
Assembly
Console
3
• Fit the rear base (narrow) into the groove
• Fit the rear
in the rear of the frame.
Hint: The rear base is designed to fi t easily
into the groove in the frame. If it does not
fi t, turn the base around so that it curves
away from the seat.
• Insert two #10 x 11/2" long screws
through the tube in the rear base
and tighten.
• Set the cycle upright.
4
• While tucking the wires into the frame, fi t
While tuck
the console into the frame.
5
Assembly
connect the connector on the handlebar into
!
• Plug the h
an
5
• Align the screw holes in the frame and
• Align the sc
console. Insert four #8 x 1" screws
through the frame and into the console.
• Tighten the screws.
IMPORTANT! For proper function, you must
connect the connector on the handlebar into
the socket in the console!
the socket in the console
Handlebar
Connector
Socket
6
6
• Plug the handlebar connector into the
socket in the console.
Hint: The connector will only fi t one way
into the socket. If it does not seem to fi t,
turn it around and try again!
Assembly
t
•
ha
•
t
Tab
Post
7
• Place the handlebar, at an angle, onto the
Place the
top of the post.
• Push to insert the tab on the back of the
handlebar into the slot in the console.
s
8
• Next, push the handlebar forward and
Next,
down in place.
sh
7
Assembly
#
9
• Insert two #8 x 1" screws into the handle-
• Insert two
bar and tighten.
Hint: If the screws cannot be tightened, you
have not assembled the handlebar properly.
Remove the handlebar and refer back to
Assembly steps 7 and 8.
10
• Check to be sure the handlebar is secured
• Check to be
on the console by pulling it up. If you can
remove it, you have not assembled it
properly. Please refer back to assembly
steps 6-9.
8
Assembly
TIGHTEN LEFT PEDAL
• Fit the asse
m
COCO
• Locate the l
e
IMPORTANT! Just like a real bicycle, Smart Cycle pedals are not interchangeable (there is
a left threaded pedal and a right threaded pedal). It's important to assemble the right pedal
on the right side of your Smart Cycle, and the left pedal on the left side. To help you, we’ve
stamped and labeled each pedal and pedal axle with an "R" for the right side and an "L"
for the left side. To tighten the pedals, you'll need to turn the left pedal counter-clockwise
(which is different from how you would normally tighten) and the right pedal clockwise.
Be sure to tighten both pedals fi rmly with the enclosed assembly.
Left Pedal
Axle (L)
11
• Locate the left pedal marked with an
L on the outside end.
• Now, fi nd the left pedal axle marked with
an L.
• Fit the threaded end of the left pedal into
the hole in the left pedal axle.
• Hand-tighten the left pedal by turning
it counter-clockwise.
9
Left Pedal (L)
Assembly Tool
TIGHTEN LEFT PEDAL
COUNTER-CLOCKWISE
12
• Fit the assembly tool to the end of the
left pedal. Turn it counter-clockwise to
fully tighten.
Hint: You will not be able to tighten the
pedal if you have tried to attach the right
pedal to the left pedal axle. Remove the
pedal and be sure you are attaching the left
pedal to the left pedal axle. Be sure to match
the letter L on each part.
