Fisher-Price G2580, H4793 Instruction Sheet

Page 1

Owner's Manual

with Assembly Instructions

For Models: G2580, H4793

In an effort to provide the best products possible, we periodically make product modifications. Actual products may not be identical to items pictured above.

Please read this manual and save it with your original sales receipt.

Tools needed for assembly: Phillips screwdriver, Slotted screwdriver and Hammer.

Use only with a Power Wheels®6 Volt (4.0 Amp/Hr.) Battery and a

Power Wheels®6™Volt (4.0 Amp/Hr.) Charger (both included).

Page 2

Table of Contents

Important Information

•Your new vehicle requires adult assembly. Please set aside at least 30 minutes for assembly.

•You must charge your battery for 18 - 30 hours before you use your vehicle for the first time.We recommend that you start charging your battery before beginning assembly. Please see Battery Charging beginning on page 6 for detailed instructions.

• Read this manual carefully for important safety information and operating instructions before using your vehicle. Keep this manual for future reference as it contains important information.

• This vehicle is designed for use on grass, asphalt or other hard surfaces; on generally level terrain; by children 1 to 3 years of age.

• Make sure children know and follow these rules for safe driving and riding:

- always sit in the seat.

- always wear shoes.

- only one (1) rider at a time.

• This vehicle has adjustable play seat belts. Please note that the adjustable seat belts are designed to be a play feature only and do not function as protective safety restraints.

• Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price®will not be responsible for damage to the floor if the vehicle is used indoors.

•To prevent damaging the motors and gears, teach your child to stop the vehicle before switching between forward and reverse. Do not tow anything behind the vehicle or overload it. Do not exceed the maximum weight capacity of 40 lbs (18 kg).

• If you have any questions about your Power Wheels

vehicle, please call our toll-free service lines at 1-800-348-0751 from 8 AM to 6 PM (EST) Monday through Friday. Trained customer service representatives are available to take your call in English or French. Habla Español? Si usted tiene alguna pregunta ó necesita asistencia llame gratis 1-800-348-0755 para los Estados Unidos. Tenemos representantes que hablan español para atender su llamada.

•For your convenience, Power Wheels®maintains an independently owned and operated Authorized Service Center Network with more than 400 authorized service centers nationwide. The authorized service centers will repair or replace parts under warranty at no extra charge, and can perform non-warranty repairs for a minimal charge. To find the authorized service center nearest to you, visit us on-line at www.powerwheels.com or call 1-800-348-0751.

• If you would like to register your vehicle, please visit us on-line at www.powerwheels.com.

A Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

B Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

C Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

D Parts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

E Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

F Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

G Label Decoration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

H Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

I Battery Care and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

J Caring For Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

K Rules For Safe Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

L How to Operate Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

M Problems and Solutions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

N Statement of Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Page 3

Warnings and Cautions

CAUTION

• In the unassembled state, this package contains small parts. Adult assembly is required.

• Use the charger in dry locations only.

WARNING

• Prevent Injuries and Deaths

• Direct Adult Supervision Required

• Keep Children Within Safe Riding Areas. These areas must be:

- away from swimming pools and other bodies of water to prevent drownings

- generally level to prevent tipovers

- away from steps and steep inclines, cars, roads and alleys.

RIDING HAZARD

WARNING

• Battery can fall out and injure a child if vehicle tips over. Always use battery clamp.

• PREVENT FIRE

- Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.

- Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury.

- Use of Power Wheels

components in products other than Power Wheels®vehicles

could cause overheating, fire or explosion.

• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury.

•Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery.

•Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.

• Read the safety instructions on the battery.

• Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part.

• HOT motors. Handle carefully.

ELECTRICAL HAZARD

Page 4

Both Shown Actual Size

Not Shown: Label Sheet, Cap Nut Assembly Tool

.354 Cap Nut – 2

0,9 cm

#8 x 1" Screw - 2

* For your convenience, extra fasteners are included!

Seat

Parts

• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store.

• Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.

•Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant.

Steering Wheel Cap

Handle

Seat Belts

Cap Nut Cover

Vehicle

Steering Column

Steering Wheel Turn Signal 6 Volt Charger

6 Volt Battery

Key

Dash

Page 5

Parts Diagram

1. Steering Wheel Cap

2. .354 Cap Nut - 2

3. Steering Wheel

4. Tu rn Signal

5. Dash

6. Steering Column

7. Battery Clamp

8. 6 Volt Battery

9. Seat Belt - 2

10. Seat

11. Handle

12. Vehicle

13. Cap Nut Cover

14. 6 Volt Charger

15. Key

Not Shown

Label Sheet #8 x 1" Screw - 2

Page 6

Battery Charging

About Thermal Fuses

Your Power Wheels®battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting safety device which automatically “trips” and shuts down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once the fuse has “tripped”, it will automatically reset itself after approximately 25 seconds and allow the vehicle to resume normal operation. To avoid repeated automatic shutdowns, do not overload the vehicle by exceeding the 40 lbs (18 kg) maximum weight capacity or by towing anything behind the vehicle. Avoid severe driving conditions, such as driving up very steep hills or running into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors. Make sure your child stops the vehicle before switching between forward and reverse.

If a thermal fuse in a battery continually trips under normal driving conditions, please contact your local Power Wheels Authorized Service Center. For the location nearest to you, please visit us on line at www.powerwheels.com or call 1-800-348-0751.

CAUTION

Use the charger in dry locations only.

WARNING

• Battery can fall out and injure a child if vehicle tips over. Always use battery clamp.

• PREVENT FIRE

- Never modify the electrical system.

Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.

- Use of the wrong type battery or

charger could cause a fire or explosion resulting in serious injury.

- Use of Power Wheels

components

in products other than Power Wheels

vehicles could cause overheating, fire or explosion.

• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury.

•Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery.

•Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.

• Read the safety instructions on the battery.

ELECTRICAL HAZARD

Important Notes

•Your new battery must be charged for at least 18 hours before you use it in your vehicle for the first time.

•We recommend that you start charging your battery before beginning assembly of your new vehicle.

•The battery must be upright while charging.

• The charger is not a toy.

• Do not short circuit the battery.

•You do not need to remove the battery from your vehicle to recharge it.

• Before charging the battery, examine the battery case for cracks and other damage which may cause sulfuric acid (electrolyte) to leak during the charging process. If damage is detected, do not charge the battery or use it in your vehicle. Battery acid is very corrosive and can cause severe damage to surfaces it contacts.

• Do not charge the battery on a surface (such as kitchen counter tops) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you charge your battery.

• Use only a Power Wheels®6™Volt (4.0 Amp/Hr.) charger (120 VAC, 60 Hz, 6W with an output of 6 VDC, 2.4W) to charge your 6 volt (4.0 Amp/Hr.) battery.

• If your battery is old and will not accept a charge, do not leave it in the vehicle. Always remove a dead battery from the vehicle.

Page 7

A-Style Battery Connector

Battery Charging

• Plug the battery connector into the charger connector. Push firmly to make sure the two connectors are completely joined.

• Plug the charger into a standard 120 volt wall outlet.

Note: If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”.

• Before first time use, charge the battery for at least 18 hours. Never charge the battery longer than 30 hours.

• Recharge the battery for at least 14 hours after each use of your vehicle. Do not charge the battery longer than 30 hours.

• Once the battery is charged, disconnect the charger connector from the battery connector. Unplug the charger from the wall outlet. The battery is now charged and is ready to be installed in your vehicle. Please see “Battery Installation” on page 13 for detailed battery installation instructions.

A-Style Charger Connector

Assembly

Children can be harmed by small parts,

sharp edges and sharp points in the

vehicle’s unassembled state, or by

electrical items. Care should be taken in

unpacking and assembly of the vehicle.

Children should not handle parts,

including the battery, or help in

assembly of the vehicle.

WARNING

•Insert and “snap” the key into the dash.

Page 8

• Locate the wire connector inside the front end of

the vehicle.

• While feeding the wire connector through the hole in

the dash, fit the tabs on the dash onto the front end of the vehicle.

Assembly

• Insert two #8 x 1" screws straight into the dash, as shown. Tighten the screws.

Hint: If the screw holes in the dash do not align with the vehicle body, place a finger in the steering wheel opening in the dash. Pull the dash toward the back of the vehicle to secure it.

#8 x 1" Screw

Pull

Dash

Page 9

• Fit the end of the steering column through the hole in the steering linkage.

• Fit a cap nut on the end of the steering column.

•Tap the cap nut with a hammer to secure it to the end of the steering column.

Hint: You may need the help of another adult to hold the steering column in place while you tap the cap nut.

Assembly

End of Steering Column

Cap Nut Cover

• “Snap” the cap nut cover over the cap nut and into the steering linkage.

•Turn the vehicle upright.

.354 Cap Nut

Cap Nut

•Turn the vehicle over.

•Fit the straight end of the steering column down through the hole in the dash.

Steering Column

Bottom View

Steering Wheel

Wire with Connector

Tu rn Signal

•Position the turn signal with the hollow side down.

• Fit the wire with connector on the end of the steering wheel through the center of the turn signal.

• Fit the turn signal onto the steering wheel.

Page 10

Assembly

• “Snap” the steering wheel cap into the center of the steering wheel.

Steering Wheel Cap

•Plug the motor harness connector from the vehicle body into the steering wheel connector.

• While carefully feeding the wire down into the dash, fit the steering wheel onto the end of the steering column.

• Fit the remaining .345 cap nut onto the end of the steering column.

•Tap the cap nut with a hammer to secure it to the end of the steering column.

End of Steering Column

.354 Cap Nut

Cap Nut

Page 11

Handle

Latch

Ta b

• Make sure the front wheels are not turned.

• Locate the latch on the back end of the vehicle.

• Press the tab and slide the latch to open.

•Insert the handle, as shown, and release the tab. Note: Be sure the end of the handle is clean and free from

debris before inserting. IMPORTANT! If the latch closes, the handle is properly

inserted. If it does not, remove the handle and repeat this step.

Ta b

• Using a slotted screwdriver, turn both lock fasteners

turn to the locked position .

• First, “snap” the front of the seat to the vehicle .

•Next, “snap” the four tabs near the back of the seat

into the matching slots in the vehicle .

LOCKED

UNLOCKED

Assembly

•Position the two seat belts so that the fasteners face each other, as shown.

•Insert the T-loop end of each seat belt through the slot in each side of the seat.

• Pull up on the seat belts to secure them to the seat.

T-Loops

Seat Belt Fasteners





Page 12

11 5

Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind:

•Wash your hands before applying the labels.

• Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.

• Place the labels exactly as shown in the illustrations.

•For best results, avoid repositioning a label once it has been applied to the vehicle.

• After applying a label, rub the label firmly with a clean, dry cloth to make sure the label is adhered to your vehicle. Start at the center of a label, and smooth towards the outer edges to remove air bubbles.

Label Decoration

Page 13

• Remove the #8-18 x 7/8" screw from the battery clamp. Lift to remove the battery clamp from the vehicle.

• Place the Power Wheels®6 Volt (4.0 Amp/Hr.) battery in the battery compartment. Make sure the battery connector extends toward the rear of the vehicle.

• Replace the battery clamp over the battery. Insert the #8-18 x 7/8" screw through the battery clamp and into the vehicle. Tighten the screw.

IMPORTANT! Use only a Power Wheels®6 volt (4.0 Amp/Hr.) battery. Use of any other battery can damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels®6 volt (4.0 Amp/Hr.) charger before operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the vehicle. Never charge the battery longer than 30 hours. Failure to follow these instructions may damage your battery and will void your warranty.

• Locate the lock fasteners on the front edge of the seat.

• Using a slotted screwdriver, turn both lock fasteners

turn to the unlocked position .

•Grasp under the front of the seat and lift firmly to remove it.

Battery Installation

LOCKED

UNLOCKED

Battery Connector

Battery Clamp

• Plug the battery connector into the motor harness connector. Note: If the battery connector will not plug into the motor

harness connector, turn it over and try again! Do not force the battery connector into the motor harness connector.

• Re-assemble the seat to the vehicle. Using a slotted screwdiver, turn the lock fastener

turn to the locked

position .

IMPORTANT! Always remember to keep the lock fasteners locked at all times to prevent children from accessing the battery.

Page 14

If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal.

If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.

If acid is internally ingested, give water, milk of magnesia or egg whites immediately. Never give emetics or induce vomiting. Call a physician.

• Charge a new battery for at least 18 hours before first use. Never charge the battery longer than 30 hours. Overcharging or undercharging the battery may shorten battery life and decrease vehicle running time.

• After the first charge, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Charge the battery after each use, regardless of how long the vehicle was used.

•The battery must be upright while charging.

• Do not allow the battery to run down completely before charging.

• Charge the battery before storing the vehicle.

• Charge the battery at least once per month, even if the vehicle has not been used.

•Leaving the battery in a discharged condition will ruin it.

• Always remove an exhausted battery from the vehicle. Battery leakage and corrosion can damage the vehicle.

• Do not store the battery on a surface (such as kitchen countertops) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you store the battery.

• Do not store the battery in temperatures above 75° F or below -10° F.

• Use only a Power Wheels

6 volt battery. Remember to charge the new battery for at least 18 hours before first use.

• Prevent the battery from moving freely inside the battery compartment. Always use the battery clamp to secure the battery in the battery compartment.

• Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage is detected, do not use the charger or the battery until you have replaced the worn or damaged part.

Care Disposal

Battery Care and Disposal

Caring For Your Vehicle

• Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces.

• During snowy or rainy weather, the vehicle should be stored inside or under a protective cover. Remember to charge the battery at least once per month while your vehicle is not in regular use.

•Avoid operating the vehicle in wet or snowy conditions, and do not spray the vehicle with a hose. Do not wash the vehicle with soap and water. Water or moisture in the motors or electrical switches can cause them to corrode, and could cause switch or motor failure.

•Avoid operating the vehicle on sand, loose dirt or gravel. Sand, loose dirt or gravel in the motors or electrical switches can cause them to jam, and could cause switch or motor failure.

• The vehicle can be wiped down with a soft, dry cloth. For a shiny finish, you can wipe plastic parts with a non-wax furniture polish applied to a soft-cloth. Do not use automotive wax. Do not use soap and water or spray the vehicle with a hose.

•To ensure that your vehicle stays in good operating order, we recommend that you periodically have your vehicle checked by a Power Wheels®authorized service center. For the location of the authorized service center nearest you, please visit us on-line at www.powerwheels.com or call 1-800-348-0751.

Battery Care and Disposal

•Your Power Wheels®battery is a sealed lead-acid battery. It must be recycled or disposed of in an environmentally sound manner.

• Do not dispose of a lead-acid battery in a fire. The battery may explode or leak.

• Do not dispose of a lead-acid battery in your regular, household trash. The incineration, landfilling or mixing of sealed lead-acid batteries with household trash is prohibited by law in most areas.

• Return exhausted batteries to federal or state approved lead-acid battery recycler, such as a Power Wheels

authorized service center or a local seller of automotive batteries. For the authorized service center location nearest to you, please call 1-800-348-0751. Contact your local waste management officials for other information regarding the environmentally sound collection, recycling and disposal of lead-acid batteries. If you live in the State of Florida or the State of Minnesota, it is prohibited by law for anyone to throw away lead-acid batteries in the municipal waste stream.

Page 15

Rules for Safe Driving

Teach Safety Rules to Children

While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills are still very immature. Unsupervised driving by children can lead to serious injury. Before children use this vehicle, an adult should carefully evaluate the driving area as well as the children’s skill level and ability to drive this vehicle safely. Children are not always able to recognize or anticipate hazards, even when they have been taught about them. THERE IS NO

ACCEPTABLE SUBSTITUTE FOR DIRECT ADULT SUPERVISION.

Teach appropriate safety rules to your child before allowing operation of this vehicle. These rules should also be reviewed with neighborhood children or other playmates who want to drive this vehicle.

Riding Rules

Make sure children know and follow these rules for

safe driving:

1. Always sit on the seat.

2. Always wear shoes.

3. Only 1 (one) rider at a time. A child who is not sitting on

the seat or who is standing on the vehicle could fall off, cause a tip-over or block the driver’s view. A child could be seriously injured.

4. Do not allow any child to drive the vehicle in the street or near moving (motorized) vehicles.

5. Do not allow any child to drive near bodies of water (such as pools or creeks), obstructions (such as furniture, low tree limbs or play equipment), or drop-offs (such as stairs or decks).

6. Do not allow any child to drive the vehicle in the dark. A child could encounter unexpected obstacles and have an accident. Operate the vehicle only in the daytime or a well-lit area.

7. Do not allow your child to drive on sloped or inclined surfaces. Restrict your child’s driving to generally

level ground ONLY!

8. Do not allow your child to drive down or across a

steep slope.

- The vehicle may gain unsafe speed, even if the

button is released to stop.

- The vehicle may tilt and tip over.

- The wheels could lose traction, causing the vehicle

to slip.

9. Do not allow your child to drive up steep inclines. The motor may stop and the vehicle could roll backwards at an unsafe speed.

10. Never put anything near any moving parts. Rotating parts such as motors, gear boxes and wheels can snag fingers, hair, etc., causing serious injury. Do not allow operation of the vehicle when it is on its side or in an upside-down position.

11. Do not operate the vehicle near flammable vapors (gasoline, paint thinner, acetone, liquid wax, etc.). The vehicle’s electrical switches, like most electrical switches, emit an internal spark when first turned on or turned off. The presence of flammable liquids or vapors could cause an explosion or a fire. Keep all flammable products in tightly sealed containers and away from the vehicle.

12. Do not allow a child to operate the vehicle without direct adult supervision. To prevent unsupervised use of the vehicle, disconnect the motor harness from the battery when the vehicle is not in use.

WARNING

Prevent Injuries and Deaths

• Direct Adult Supervision Required.

•Keep Children Within Safe Riding Areas These areas must be:

- away from swimming pools and other bodies of water to prevent drownings.

- generally level to prevent tipovers.

- away from steps, steep inclines, cars, roads and alleys.

RIDING HAZARD

Page 16

• Press the drive button on the steering wheel. The vehicle drives forward at a maximum speed of 2 mph.

• Help your child practice steering to learn how far and how quickly to turn the steering wheel when driving.

•To stop, release the drive button.

• Make sure your child is comfortable with steering the vehicle and automatically knows how to stop.

Stage 1 - Parent Assisted

Drive Button

Drive

Button

PRESS

Stage 2 - Child Driver

IMPORTANT! use the vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher Price®will not be responsible for damage to the floor if the vehicle is used indoors.

How to Operate Your Vehicle

Handle

Latch

Ta b

• Make sure the front wheels are not turned.

• Locate the latch next to the steering handle.

• Press the tab and slide the latch open.

•Lift and remove the handle from the vehicle, and release the tab.

• Store the handle in a safe, clean place for future use.

Note: Be sure the end of the handle is clean and free from debris before reinserting.

• Make sure the handle is installed (see Assembly step 15).

•Grasp the handle and press the drive button. The vehicle drives forward at a maximum of 2 mph.

• Swing the handle to the left or right to steer the vehicle.

•To stop, release the drive button.

Hint: Your child can also press the drive button on the steering wheel while you steer with the handle.

Page 17

Problem Possible Cause Solution

Vehicle does not run Undercharged battery Charge the battery. A new battery should have been charged

for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours.

Check all connectors. Make sure the battery connector is tightly plugged into the charger connector, and that the charger is plugged into the wall.

Make sure power flow to the wall outlet is “ON”.

Charger is not working There is no sure way to tell if your charger is working unless

you have a volt meter. If you suspect there is a problem with your charger, contact your local Power Wheels®authorized service center. They can test your charger for you.

Tr ipped thermal fuse The built-in thermal fuse in the battery may "trip" and shut

down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. The fuse will automatically reset itself after approximately 25 seconds, allowing the vehicle to resume normal operation. To avoid repeated automatic shutdowns, do not overload the vehicle by exceeding the 40 lb. (18 kg) maximum weight capacity or by towing anything behind the vehicle. Do not drive up hills or run into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors. If a thermal fuse continually trips, contact your local Power Wheels®authorized service center.

Loose wire or loose connectors Check all wires and connectors. Make sure the battery

connector is tightly plugged into the motor harness connector, and that there are no loose wires around the motors.

Dead battery If your battery is old or if you have not followed Battery Care

instructions, your battery may be dead. If you are unsure whether or not the battery is dead, you can have it tested at your local Power Wheels®authorized service center.

Electrical switch damage The electrical switches can become corroded due to exposure

to water or moisture, or can jam due to loose dirt, sand or gravel. Contact your local Power Wheels®authorized service center for diagnosis and repair.

Motor damage Contact your local Power Wheels®authorized service center for

diagnosis and repair.

Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the battery suddenly stopped connector is tightly plugged into the motor harness connector,

and that there are no loose wires around the motors.

Tr ipped thermal fuse The built-in thermal fuse in the battery may "trip" and shut

Problems and Solutions Guide

IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions

Guide below. If you still experience a problem, please contact Power Wheels®Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels®authorized service center. For the location nearest to you, please visit us on-line at www.powerwheels.com or call 1-800-348-0751.

Page 18

Problem Possible Cause Solution

Short run time (Less than Undercharged battery Charge the battery. A new battery should have been charged 1 - 3 hours per charge) for at least 18 hours before using the vehicle for the first time.

After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours.

Check all wires and connectors. Make sure the battery connector is tightly plugged into the charger connector, and that the charger is plugged into the wall.

Make sure power flow to the wall outlet is “ON”.

Overcharged battery Do not charge the battery longer than 30 hours. If you suspect

that your battery is damaged as a result of overcharging, contact your local Power Wheels®authorized service center. They can test your battery for you.

Battery is old and will not Even with proper care, a rechargeable battery does not last accept full charge forever. Average battery life is 1 to 3 years depending

on vehicle use and use conditions. Do not substitute parts.

Tr ipped thermal fuse The built-in thermal fuse in the battery may "trip" and shut

Vehicle runs sluggishly Undercharged battery Charge the battery. A new battey should have been charged

for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours.

Check all connectors. Make sure the battery connector is tightly plugged into the charger connector, and that the charger is plugged into the wall.

Make sure power flow to the wall outlet is “ON”.

Battery needs charging Be sure to charge the battery after each use.

Battery is old and will not accept Even with proper care, a rechargeable battery does not last full charge forever. Average battery life is 1 to 3 years depending on

the vehicle use and use conditions. Replace the battery with a Power Wheels®6 volt battery. Do not substitute parts.

Vehicle is overloaded Make sure you do not overload the vehicle by allowing more

than one rider at one time, by exceeding the 40 lb. maximum weight capacity, or by towing objects behind the vehicle. If the vehicle is overloaded, the built-in thermal fuse in the battery may “trip” and automatically shut down operation of the vehicle for approximately 25 seconds. Reduce the load on the vehicle to prevent repeated automatic shutdowns.

Driving conditions are too stressful Use only on generally level ground.

Sometimes the vehicle doesn’t Loose wire or connector Check all wires around the motors and all connectors to make run, but other times it does sure they are tight.

Motor or electrical switch damage Contact your local Power Wheels®authorized service

center for diagnosis and repair.

Problems and Solutions Guide

Page 19

When the drive button is pressed, Loose wire or connector Check all wires around the motors and all connectors the vehicle won’t run without to make sure they are tight. a push

“Dead Spot” on motor Contact your local Power Wheels®authorized service

center for diagnosis and repair.

Loud clacking or grinding Broken gears Contact your local Power Wheels®authorized service noise from a motor-gearbox center for diagnosis and repair.

Charger gets warm during use It is normal for some chargers to get No action required.

warm during use and is not reason for concern. Some chargers do not If your charger does not get warm during get warm during use. use, it does not mean that it is not working properly.

Battery makes a sizzling or It is normal for some batteries to No action required. gurgling noise when charging make noise and swell slightly while

charging and is not reason for If your battery does not make noise or swell slightly concern. Some batteries do not during charging, it does not mean that it is make noise or swell while charging. not accepting the charge.

Problems and Solutions Guide

If, after reviewing the Problems and Solutions Guide, the vehicle still fails to operate, please contact Power Wheels

Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels®authorized service center. For the location nearest to you, please visit us on-line at www.powerwheels.com or call 1-800-348-0751.

Hint: For faster service when calling Consumer Relations, completely charge the battery before calling and have the following available by the phone:

•vehicle,

•vehicle model number (see sticker in battery compartment),

•vehicle production run number (see sticker in battery compartment),

•a Phillips screwdriver and a slotted screwdriver.

Problem Possible Cause Solution

*One year limited warranty from the date of purchase on the Power Wheels®vehicle. Six month limited warranty on the 6 volt battery.

For the original purchaser, this one year limited warranty covers the Power Wheels®ride-on vehicle (purchased from Power Wheels®) against defects in materials and workmanship. The six month limited warranty applies only to the 6 volt battery included by Power Wheels®with the original purchase of the vehicle.

This warranty covers normal use and does not cover the Power Wheels®vehicle or battery if damaged by unreasonable use, neglect, accident, abuse, misuse, improper service or other causes not arising out of defects in materials or workmanship. Evidence of any attempt at consumer repair will void this warranty. THIS WARRANTY DOES NOT COVER, AND IS INTENDED TO EXCLUDE, ANY LIABILITY ON THE PART OF POWER WHEELS®, WHETHER UNDER THIS WARRANTY OR IMPLIED BY LAW FOR ANY INDIRECT OR CONSEQUENTIAL DAMAGES FOR BREACH OF WARRANTY. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION SO THIS LIMITATION MAY NOT APPLY TO YOU.

Should you need service or assistance with your vehicle during the warranty period, do not return the vehicle to the store. Power Wheels

has provided nationwide network of authorized service centers. For the location of the authorized service center nearest you, please visit us on-line at www.powerwheels.com or call 1-800-348-0751.Power Wheels®is continually expanding our Authorized Service Center Network. If there is not an authorized service center in your area, please call Consumer Relations for information, 1-800-348-0751.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.

PLEASE SAVE YOUR ORIGINAL SALES RECEIPT.

Statement of Limited Warranty

Page 20

PRINTED IN MEXICO G2580pr-0920

Fisher-Price, Power Wheels, Power Wheels by Fisher-Price and Power Lock are U.S. trademarks of Mattel, Inc.

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A.

If you are missing parts or need assistance,

please call us toll-free:

Power Wheels®Consumer Relations

1-800-348-0751

8 AM - 6 PM EST, Monday through Friday.

Over 400

Authorized Service Centers!

Visit us on-line at

www.powerwheels.com for

the location nearest you.

Or contact your local, independently owned and operated

Power Wheels®Authorized Service Center.

For the location nearest you,

visit us on-line at www.powerwheels.com.

IMPORTANT!

DO NOT Return your

Vehicle to the Store!

DO NOT use this vehicle

for the first time until you have

charged the battery for 18 hours.

Remember to…

✔

Charge the battery immediately after each use.

✔

Charge the battery once a month during storage, even if the vehicle has not been used.

Failure to follow these instructions will permanently damage your battery and void your warranty. Please refer to the Battery Care Section in this manual for more information. For high speed operation, please refer to the How to Operate Your Vehicle Section in this manual for more information.

Fisher-Price G2580, H4793 Instruction Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual
