Fisher-Price 78457 Instruction Sheet

®
Owner’s Manual with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 78457
Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver, Hammer, and Safety Scissors (tools not included).
Use only with a Power Wheels®6 Volt Battery with A-Style Connector and Built-in Thermal Fuse
and a Power Wheels®Super 6™Volt Charger (both included).
Sound Box requires three “AA” (LR6) alkaline batteries (not included) for operation.
Product features and decoration may vary from the picture above.
Ford, F-150 and associated trademarks used under license from Ford Motor Company.
Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of The Goodyear Tire & Rubber Company, used with permission.
Fisher Price, Power Wheels and Power Stick are U.S. trademarks of Mattel, Inc.
2
Table of Contents
Important Information
A Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
B Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
C Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
D Parts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
E Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
F Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
G Label Decoration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
H Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
I Battery Care and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
J Rules for Safe Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
K How to Operate Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
L Caring for Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
M Statement of Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
N Problems and Solutions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
O Authorized Service Centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
• Your new vehicle requires adult assembly. Please set aside at least 45 minutes for assembly.
• You must charge your battery for 18 - 30 hours before you use your vehicle for the first time. We recommend that you start charging your battery before beginning assembly. Please see Battery Charging begin­ning on page 7 for detailed instructions.
• Read this manual carefully for important safety informa­tion and operating instructions before using your vehicle. Keep the instructions for future reference as they contain important information.
• This vehicle is designed for use on grass, asphalt or other hard surfaces; on generally level terrain; by children 3 - 6 years of age.
• Make sure children know and follow these rules for safe driving and riding:
- always sit in the seat.
- always wear shoes.
- only one (1) rider at a time.
• This vehicle has an adjustable play seat belt. Please note that the adjustable seat belt is designed to be a play feature only and does not function as a protective safety restraint.
• To prevent damaging the motors and gears, teach your child to stop the vehicle before switching between forward and reverse. Do not tow anything behind the vehicle or overload it. Do not exceed the maximum weight capacity of 65 lb. (30 kg).
A
• If you have any questions about your Power Wheels
®
vehicle, please call our toll-free service lines at 1-800-348-0751 from 8 AM to 6 PM (EST) Monday through Friday. Trained customer service representatives are available to take your call in English or French. Habla Español? Si usted tiene alguna pregunta ó nece-sita asistencia llame gratis 1-800-348-0755 para los Estados Unidos. Tenemos representantes que hablan español para atender su llamada.
• For your convenience, Power Wheels®maintains an Authorized Service Center Network with more than 400 authorized service centers nationwide. Our author­ized service centers will repair or replace parts under warranty at no extra charge, and can perform non­warranty repairs for a minimal charge. Please see the Authorized Service Center list beginning on page 27 to find the authorized service center nearest you, or call 1-800-348-0751.
• Please complete and return the enclosed Registration Card today, or call 1-800-348-0751 to register your vehicle by phone.
Warnings and Cautions
B
3
CAUTION
• In the unassembled state, this package contains small parts. Adult assembly is required.
• Use the charger in dry locations only.
WARNING
Prevent Injuries and Deaths
• Direct Adult Supervision Required
• Keep Children Within Safe Riding Areas. These areas must be:
- away from swimming pools and other bodies of water to prevent drownings
- generally level to prevent tipovers
- away from steps, driveways, roads and alleys.
RIDING HAZARD
WARNING
• Battery can fall out and injure a child if vehicle tips over. Always use battery clamp.
PREVENT FIRE
- Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.
- Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury.
- Use of Power Wheels
®
components in products other than Power Wheels®vehicles
could cause overheating, fire or explosion.
• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury.
• Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery.
• Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.
• Read the safety instructions on the battery.
• Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part.
HOT motors. Handle carefully.
ELECTRICAL HAZARD
Parts
C
4
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store.
• Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
• Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant.
Dash Cover
Microphone
Grille
Steering Wheel Cap
Taillight Lens Set
(Left) (Right)
®
Super 6™ Volt Charger
6 Volt Battery
Seat Belt Strap - 2
Sport Bar Foot Set
(Left) (Right)
Sport Bar Bracket
Sport Bar Support - 2
Sound Box
Sport Bar
5
Parts
#8 x 1" Screw – 14
Knob
Part Not Shown: Label Sheet
Steering Column
All Shown Actual Size
Vehicle Body
Hood
Seat
T M
* Note: For your convenience, an extra
.354 cap nut has been included.
Steering Wheel
#6 x1/2" Screw – 2
Key
#6 x
3
/8" Screw – 2
Tailgate
.354 Cap Nut – 2*
#6 x 11/2" Screw – 2
KC™ Light Rack, Rear
Light Cover – 2
KC™ Light Rack, Front
T
M
®
Parts Diagram
1 Hood 2 Microphone 3 Steering Column 4 Steering Wheel 5 Steering Wheel Cap 6 Cap Nut – 2 7 Dash Cover 8 Knob
9 Key 10 Seat 11 Tailgate
12 Left Taillight 13 Right Taillight 14 Vehicle Body 15 Grille 16 6 Volt Battery 17 Sound Box 18 Sport Bar Foot - 2 19 Seat Belt Straps - 2 20 Super 6™Volt Charger 21 Sport Bar Bracket - 2 22 Sport Bat Support - 2
23 Sport Bar 24 KC™ Light Rack, Front 25 KC™ Light Rack, Rear 26 Light Cover - 2
Parts Not Shown:
Label Sheet #8 x 1" Screw - 14 #6 x 1/2" Screw - 2 #6 x 11/2" Screw - 2 #6 x 3/8" Screw - 2
Parts
2
4
5
6
1
16
17
10
11
12
13
7
9
8
15
6
3
14
D
18
22
19
20
21
23
24
25
26
6
Note: Some parts shown are assembled on both sides of the vehicle.
Battery Charging
E
Important Notes
Your new battery must be charged for at least
18 hours before you use it in your vehicle for the first time.
• You do not need to remove the battery from the vehicle to recharge it.
• The battery must be upright while charging.
• The charger is not a toy.
• Do not short circuit the battery.
• We recommend that you start charging your battery before beginning assembly of your vehicle.
• Before charging the battery, examine the battery case for cracks and other damage which may cause sulfuric acid (electrolyte) to leak during the charging process. If damage is detected, do not charge the battery or use it in your vehicle. Battery acid is very corrosive and can cause severe damage to surfaces it contacts.
• Do not charge the battery on a surface which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you charge your battery.
• Use only a Power Wheels Super 6 Volt charger with an A-style connector (120VAC 60 Hz 15W with an output of 6VDC 7.2W) to charge your 6 volt battery.
About Thermal Fuses
Your Power Wheels®battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting safety device which automatically “trips” and shuts down opera­tion of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once the fuse has “tripped”, it will automatically reset itself after approximately 25 seconds and allow the vehicle to resume normal operation. To avoid repeated automatic shutdowns, do not overload the vehicle by exceeding the 65 lb. (30 kg) maximum weight capacity or by towing anything behind the vehicle. Avoid severe driving conditions, such as driving up very steep hills or running into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors.
Make sure your child stops the vehicle before switching between forward and reverse.
If the thermal fuse continually trips under normal driving conditions, contact your local Power Wheels®Authorized Service Center. Please refer to the Authorized Service Center listing beginning on page 27 for the location of the Authorized Service Center nearest to you.
CAUTION
Use the charger in dry locations only.
WARNING
• Battery can fall out and injure a child if vehicle tips over. Always use battery clamp.
PREVENT FIRE
- Never modify the electrical system.
Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.
- Use of the wrong type battery or
charger could cause a fire or explo­sion resulting in serious injury.
- Use of Power Wheels
®
components
in products other than Power Wheels
®
vehicles could cause overheating, fire or explosion.
• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury.
• Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery.
• Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.
• Read the safety instructions on the battery.
• Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part.
ELECTRICAL HAZARD
7
®
W
A
R
N
I
N
G
P
R
E
V
E
N
T
F
I
R
E
D
o
n
o
t
b
y
p
a
s
s
a
P
o
w
e
r
W
h
e
e
l
U
s
e
o
n
l
y
a
R
e
d
P
o
w
e
r
W
h
e
e
l
s
N
e
v
e
r
m
o
d
i
f
y
t
h
e
e
l
e
c
t
r
i
c
a
l
P
R
E
V
E
N
T
F
I
R
E
D
o
n
o
t
b
y
p
a
s
s
a
P
o
w
e
r
W
h
e
e
l
U
s
e
o
n
l
y
a
R
e
d
P
o
w
e
r
W
h
e
e
l
s
N
e
v
e
r
m
o
d
i
f
y
t
h
e
e
l
e
c
t
r
i
c
a
l
A
v
e
r
t
i
s
s
e
m
e
n
t
A-Style Battery Connector
Battery Charging
8
1
2
• Plug the charger and battery connectors together. Push firmly to make sure the two connectors are completely joined.
• Plug the charger into a standard 120 volt wall outlet. Note: If power flow to the wall outlet is controlled by a
switch, make sure the switch is “ON”.
Before first time use, charge the battery for at least 18 hours. Never charge the battery longer than 30 hours.
Recharge the battery for at least 14 hours after each use of your vehicle. Do not charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the charger connector from the battery connector. Unplug the charger from the wall outlet. The battery is now charged and is ready to be installed in your vehicle. Please see "Battery Installation" on page 18 for detailed battery
Incorrect Correct
W
A
R
N
IN
G
P
R
E
V
E
N
T
F
I
R
E
D
o
n
o
t
b
y
p
a
s
s
a
P
o
w
e
r
W
h
e
e
l
U
s
e
o
n
l
y
a
R
e
d
P
o
w
e
r
W
h
e
e
l
s
N
e
v
e
r
m
o
d
i
f
y
t
h
e
e
l
e
c
t
r
i
c
a
l
PREVENT
FIRE
D
o
n
o
t
b
y
p
a
s
s
a
P
o
w
e
r
W
h
e
e
l
U
s
e
o
n
l
y
a
R
e
d
P
o
w
e
r
W
h
e
e
l
s
N
e
v
e
r
m
o
d
i
f
y
t
h
e
e
l
e
c
t
r
i
c
a
l
A
v
e
r
ti
s
s
e
m
en
t
A-Style Charger Connector
GAP
NO GAP
Assembly
F
9
Children can be harmed by small parts, sharp edges and sharp points in the vehi­cle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the bat­tery, or help in assembly of the vehicle.
WARNING
• Locate the sound box battery compartment.
• Loosen the screw in the battery compartment door with a Phillips screwdriver. The screw will remain in the door.
• Lift the battery compartment door open.
• Insert three LR6 “AA” alkaline batteries into the battery compartment as indicated on the battery compartment door.
• Close the battery compartment door.
• Tighten the screw with a Phillips screwdriver. Do not over-tighten.
• Place the sound box into the dash pocket in the vehicle body, speaker side down.
Battery Tips
• Do not mix old and new batteries.
• Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
• Remove batteries during long periods of non-use. Always remove exhausted batteries from the product. Battery leakage and corrosion can damage the product. Dispose of batteries properly.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to be recharged.
• Only batteries of the same or equivalent type as recom­mended in the battery installation instructions are to be used.
• If removeable rechargeable batteries are used, they are only to be charged under adult supervision.
• Rechargeable batteries are to be removed from the product before they are charged.
• Battery chargers used with the product must be exam­ined regularly for damage to the cord, plug enclosure and other parts. In the event that such damage is found, the product must not be used with the battery charger until the damage has been repaired.
+
-
Sound Box
Sound Box
Speaker Side
Dash Pocket
SHOWN ACTUAL SIZE
1.5 x 3
LR6 “AA”
1
Battery Compartment
Battery Compartment Door
2
• Insert the tabs on the top of the dash cover into the slots in the dash.
• Lower the bottom of the dash cover.
• Insert two #6 x 1/2" screws through the dash cover and into the dash.
• Tighten the screws with a Phillips screwdriver. Do not over-tighten.
Hint: Turn the key or the knob for sounds.To change the batteries in the sound box, simply remove the screws in the dash cover. Then, remove the dash cover to access the sound box. Please see assembly step 1, page 9 for battery information.
Tabs
Slots
Dash Cover
4
• Insert the end of the microphone cord through the hole in the right side of the dash.
• From the underside of the vehicle, bend the end of the microphone cord so that it forms a “T” under the dash.
• Gently pull on the microphone cord to make sure it is secure in the dash.
• Fit the tab on the back of the microphone into the slot in the dash to secure the microphone.
Steering Column
Slot
Front Axle
Hint: You may want the help of another person to complete assembly steps 6 through 9.
• Wipe the steering column with a paper towel to remove any excess lubricant.
• Carefully lift the front end of the vehicle.
• Insert the straight end of the steering column under the front axle, through the slot in the vehicle body and out through the large hole in the center of the dash.
“T” End
Hole
Microphone
Ta b
Slot
Bottom View
5
6
“T” End
• Position the dash cover as shown. Make sure the three tabs are upright.
• Fit the knob into the hole in the right side of the dash cover.
• Fit the key into the hole to the left of the knob.
• Insert a #6 x 3/8" screw into the back of the knob and into the back of the key.
• Tighten the screws with a Phillips screwdriver. Do not over-tighten.
Knob
Tabs
Key
Dash Cover
3
10
Assembly
Loading...
+ 22 hidden pages
