Wall canopy

Installation instructions

HC60PCIX2 & HC90PCIX2 models

and User guide

NZ AU

Contents

1

Safety and warnings

2

Installation instructions

3

Getting started quickly

8

Cleaning and maintenance

9

Manufacturer’s warranty

11

Customer care

12

Important!

SAVE THESE INSTRUCTIONS

The models shown in this User Guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please visit our local website listed on the back cover or contact your local Fisher & Paykel dealer.

2 Safety and warnings

Important!

Please read the entire set of instructions before installing the wall canopy.

This wall canopy is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they do not play with the wall canopy. There must be adequate ventilation of the room when the wall canopy is used at the same time

as appliances burning gas or other fuels. (A partial vacuum in the room could result in too high a concentration of gas in the air).

You must read the details concerning the method and frequency of cleaning. There is a fire risk if cleaning is not carried out in accordance with the instructions. Do not flambé under the wall canopy.

Exhaust air must not be discharged into an existing flue that is used for exhausting fumes from appliances burning gas or other fuels.

The minimum distance between the cooktop surface and the filters of the wall canopy shall be 600 mm, or 650 mm if installed over a gas cooktop.

Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air is fulfilled.

If the supply cord of this equipment is damaged it must only be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard.

Always switch the power off prior to installation, servicing or cleaning the wall canopy. Never use the wall canopy without the filters in place.

A power outlet should be within 750 mm of the motor assembly and can be either on the wall, behind the chimney or in the ceiling.

To comply with electrical safety regulations, this canopy must be plugged into a socket near the appliance. The socket must be accessible, or have an accessible isolating switch, to enable the end user to isolate the canopy from the power for the purpose of internal cleaning or maintenance. Ducting accessories are not supplied. All ducting must comply with local requirements and building codes.

WARNING!

Electrical Shock Hazard

All electrical work must be done in accordance with local and/or national electrical codes as applicable. For safety, this product must be earthed. If you are unfamiliar with methods of installing electrical wiring, employ the services of a qualified electrician. Turn off power at service entrance before installing wiring or servicing this product.



WARNING!



Weight Hazard



The wall canopy is heavy. Please ensure adequate care is taken when installing

(HC60)

the wall canopy to prevent personal injury. The wall canopy must be installed

onto a solid wall, stud, beam or truss. Weight of the product is 8.8 kg/10.7 kg.

(HC90)

Contents of packaging

1 x wall canopy

2 x chimney flues with bracket

1 x installation instructions

2 x aluminium mesh filters (HC60PCIX2)

3 x aluminium mesh filters (HC90PCIX2)

2 x butterfly flaps

4 x small screws, to secure chimney flue

5 x 8 x 1½” wood screws

1 x washer (5 mm inner diameter)

Typical equipment required:

Electric drill

Screwdriver

Duct tape

Jig saw

Ladder

Ducting

Tape measure

Drill bits

Spirit level

Installation instructions

3

Fig.1 Wall canopy

Accessories

Accessory

Part Number

Chimney ext (740 mm) SS

791989

Light bulb

SES 230V/Max 25W

Charcoal filter (HC60)

790681

Replacement aluminium filter (HC60)

790682

Charcoal filter (HC90)

790683

Replacement aluminium filter (HC90)

790684
