Instruction Manual Supplement

D104192X012

i2P-100 Transducer - CSA

July 2018

CSA Hazardous Area Approvals

™

Fisher

Hazardous Area Classifications and Special Instructions for “Safe Use” and
Installation in Hazardous Locations

Certain nameplates may carry more than one approval, and each approval may have unique installation/wiring
requirements and/or conditions of “safe use”. These special instructions for “safe use” are in addition to, and may
override, the standard installation procedures. Special instructions are listed by approval.

Note

This information supplements the nameplate markings affixed to the product and the i2P-100 instruction manual
(D103198X012

Always refer to the nameplate itself to identify the appropriate certification.

i2P-100 Electro‐Pneumatic Transducer

), available from your Emerson sales office or Local Business Partner, or at www.Fisher.com.

WARNING

Failure to follow these conditions of “safe use” could result in personal injury or property damage from fire or explosion,
and area re‐classification.

Intrinsically Safe, Explosion-proof, Type n, Dust‐Ignition proof

No special conditions of safe use.

Refer to table 1 for approval information.

Table 1. Approval Information

Certification Body Certification Obtained Entity Rating Temperature Code

CSA

Intrinsically Safe
Ex ia IIC T3/T4/T5 per drawing GE07471, Ga (see figure 1)
Ex ia Intrinsically Safe
Class I, II, III Division 1 GP A,B,C,D,E,F,G per drawing GE07471 (see
figure 1)

Explosion-proof
Ex d IIC T5/T6, Gb
Class I, Division 1 GP, A,B,C,D T5

Type n
Ex nC IIC T5/T6, Gc

Class I, Division 2, GP A,B,C,D T5
Class II, Division 1, GP E,F,G T5
Class II, Division 2 GP F,G T5
Class III

Vmax = 30 VDC
Imax = 100 mA
Pi = 1.0 W
Ci = 0 uF
Li = 0 uH

- - -

- - -

- - - T5 (Tamb ≤ 85°C)

T3 (Tamb ≤ 85°C)
T4 (Tamb ≤ 81°C)
T5 (Tamb ≤ 46°C)

T5 (Tamb ≤ 85°C)
T6 (Tamb ≤ 75°C)

T5 (Tamb ≤ 85°C)
T6 (Tamb ≤ 75°C)

www.Fisher.com

i2P-100 Transducer - CSA

July 2018

Figure 1. CSA Loop Schematic (Drawing GE07471)

Instruction Manual Supplement

D104192X012

CSA ENTITY INSTALLATION DRAWING

HAZARDOUS LOCATION
CLASS I, GROUPS A,B,C,D
CLASS II, GROUPS E,F,G
CLASS III

FISHER TYPE: i2P-100

Vmax = 30 Vdc
Imax = 100 mA
Ci = 0 nF
Li = 0 mH
Pi = 1.0 W

WARNING:

THE APPARATUS ENCLOSURE CONTAINS ALUMINUM AND
IS CONSIDERED TO CONSTITUTE A POTENTIAL RISK OF
IGNTION BY IMPACT OR FRICTION. AVOID IMPACT AND
FRICTION DURING INSTALLATION AND USE TO PREVENT
RISK OF IGNITION.

NOTES:

1. BARRIERS MUST BE CSA CERTIFIED WITH ENTITY PARAMETERS
 AND ARE TO BE INSTALLED IN ACCORDANCE WITH THE
 MANUFACTURERS I.S. INSTALLATION INSTRUCTIONS.

2. EQUIPMENT SHALL BE INSTALLED IN ACCORDANCE WITH
 THE CANADIAN ELECTRICAL CODE, PART I.

3. FOR ENTITY INSTALLATION: Vmax > Voc, Imax > Isc,
 Ci + Ccable < Ca, Li + Ccable < La.

GE07471_B

NON-HAZARDOUS LOCATION

CSA APPROVED BARRIER
