Fisher IM Supplement: Fisher DLC3100 Digital Level Controller-CSA Approvals Manuals & Guides

Quick Start Guide Supplement

D104232X012

DLC3100 Digital Valve Controller

June 2018

CSA (United States and Canada) Hazardous Area
Approvals

™

Fisher

FIELDVUE™ DLC3100 Digital Level

Controller

Hazardous Area Classifications and Special Instructions for “Safe
Use” and Installations in Hazardous Locations

Certain nameplates may carry more than one approval, and each approval may have unique installation/wiring
requirements and/or conditions of “safe use”. These special instructions for “safe use” are in addition to, and may
override, the standard installation procedures. Special instructions are listed by approval.

Note

This information supplements the nameplate markings affixed to the product and the DLC3100 quick start guide (D104214X012
available from your Emerson sales office

Always refer to the nameplate itself to identify the appropriate certification.

, Local Business Partner, or at www.Fisher.com.

),

WARNING

Failure to follow these conditions of “safe use” could result in personal injury or property damage from fire or explosion, or
area re‐classification.

Approval Information

Class/Division

Class I, Division 2 Groups A, B, C, D
Class II, Division 2 Groups E, F, G
Explosion-proof: Class I, Division 1 Groups B, C, D

Temperature Code: T5 (Tamb ≤ 80°C); T6 (Tamb ≤ 70°C)

Class II Division 1 Groups E, F, G
Class III

Temperature Code: T5 (Tamb ≤ 80°C); T6 (Tamb ≤ 54°C)

Intrinsically Safe
Class I, Division 1 Groups A, B, C, D
Class II, Division 1 Groups E, F, G

Install per drawing GG52544 (see figure 1, 2, and 3)

www.Fisher.com

DLC3100 Digital Valve Controller

June 2018

Quick Start Guide Supplement

Zone

Flameproof: AEx/Ex db IIB + H2 Gb
Type n: AEx/Ex nA IIC Gc
Dust by Enclosure: AEx/Ex tb IIIC Db

Temperature Code: T5 (Tamb ≤ 80°C); T6 (Tamb ≤ 70°C)

Intrinsically Safe
Gas: AEx/Ex ia IIC Ga
Dust: AEx/Ex ia IIIC Da

Install per drawing GG52544 (see figure 1, 2, and 3)

Special Conditions of Safe Use

Ambient temperature rating: -40°C ≤ Ta ≤ +80°C; -40°C ≤ Ta ≤ +54°C; -40°C ≤ Ta ≤ +70°C

Cautions/Warnings:

1. Substitution of components may impair intrinsic safety and suitability for class I, division 2.

2. To prevent ignition of explosive atmospheres, disconnect power before servicing.

3. In Explosion-proof/flameproof applications a seal shall be installed within 0 mm of the enclosure.

4. Do not open when an explosive atmosphere may be present.

5. Equipment may not be installed in atmospheres with Ketones and Esters.

D104232X012

Précautions/Avertissements:

1. Le remplacement de composants peut dégrader la sécurité intrinsèque et sa compatibilité pour la classe I,
division 2.

2. Pour empêcher l’inflammation d’atmosphères explosives déconnecter l’alimentation électrique avant toute
intervention.

3. Pour les applications antidéflagrantes un joint doit être installé à 0mm du boitier.

4. Ne pas ouvrir si l’atmosphère peut être explosive.

5. L’équipement ne peut pas être installé dans des atmosphères contenant des cétones et des esters.
