Page 1
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Fisher™ D3 Control Valve with Gen 2 easy-Drive
Electric Actuator
Contents
Introduction 1.................................
Scope of Manual 1.............................
Description 3.................................
Specifications 3...............................
Educational Services 3.........................
Installation 3..................................
Special Instructions for “Safe Use” and Installations
in Hazardous Locations 4.....................
Startup Overview 5............................
Default Input Signals 10........................
Configuration 10..............................
Input Configuration 10.....................
Changing the Inputs from Default Settings 10..
Modbus Setup 10.............................
Connecting using the Fisher easy-Drive
configuration software 11................
Initial Setup 11............................
Calibration Instructions 12..................
Licensing 15..............................
Startup 17................................
Troubleshooting 18.............................
Setting the Valve Flow Adjuster 19................
Maintenance 20................................
Valve Plug and Seat Ring Maintenance 22.........
Packing Maintenance 24........................
Parts Ordering 26...............................
Figure 1. Fisher D3 Control Valve with Gen 2
easy-Drive Electric Actuator
W9797-7
Parts Kits 26...................................
Parts List 26...................................
Appendix A - Modbus 29.........................
Appendix B - Certificate of Conformance 34.........
™
Introduction
Scope of Manual
This instruction manual provides installation, maintenance, and parts information for the Fisher D3 control valve with
Gen 2 easy-Drive electric actuator. For Gen 1 electric actuators, use Fisher D3 with easy-Drive Instruction Manual,
(D103460X012
(D104551X012
www.Fisher.com
). If the actuator has a RPU-100 installed refer to easy-Drive RPU-100 Instruction Manual,
).
Do not install, operate, or maintain a D3 valve with Gen 2 easy-Drive electric actuator without being fully
trained and qualified in valve, actuator, and accessory installation, operation, and maintenance. To avoid
personal injury or property damage, it is important to carefully read, understand, and follow all the
contents of this manual, including all safety cautions and warnings. If you have any questions about
these instructions, contact your Emerson sales office
before proceeding.
Page 2
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Table 1. Specifications
Instruction Manual
D104161X012
Valve Body Sizes, End Connection Styles, and Port
Diameters
VALVE
SIZE, NPS
X = Available construction.
Maximum Inlet Pressures and Temperatures
VALVE BODY SIZE
Maximum Shutoff Pressure Drops
Port Size,
mm (inch)
Flow Up 155 (2250) 105 (1518) 75 (1089)
Flow Down 155 (2250) 155 (2250) 130 (1889)
(1)
PORT
DIAMETER,
(INCHES)
1 0.375, 0.75, 1 X X
2 0.375, 0.75, 1 X X
MAXIMUM INLET
NPS 1 NPT
CL900
NPS 2 NPT
CL900
NPS 1 RF
CL600
NPS 2 RF
CL600
MAXIMUM nP BAR (PSI) PER PORT SIZE
9.5 (0.375) 19.1 (0.75) 25.4 (1.00)
THREADED
CL900 CL600
PRESSURE
bar (psig) _C (_F)
155 (2250) -46 to 93 (-50 to 200)
150 (2185) 93 to 149 (200 to 300)
155 (2250) -46 to 93 (-50 to 200)
150 (2185) 93 to 149 (200 to 300)
103 (1500) -46 to 93 (-50 to 200)
100 (1455) 93 to 149 (200 to 300)
103 (1500) -46 to 93 (-50 to 200)
100 (1455) 93 to 149 (200 to 300)
RAISED FACE
(RF) FLANGED
TEMPERATURE RANGE
(1)
(1)
Shutoff Classification per ANSI/FCI 70‐2
and IEC 60534‐4
Class IV
Flow Characteristic / Valve Plug Style
Equal percentage / Micro‐Form Valve Plug
Available Actuator Configurations
On/off (snap acting)
Positioning (flow or pressure control)
Power Requirements
11 - 30 VDC, minimum 4 amp power supply required
(fuse to 5 amps)
Maximum Current Draw
4 amps
Idle Current Draw
15 mA at 24 VDC, 25 mA at 12 VDC
Conduit Connections
Two 3/4 NPT connections
Stroke Length
FloPro controlled between 10 mm (0.4 inch) and
15 mm (0.6 inch)
Nominal Stroke Speed
(2)
3.9 mm/s (0.15 inch/s) at 24 VDC
2.2 mm/s (0.09 inch/s) at 12 VDC
Hazardous Area Approvals
CSA (C/US): ExplosionProof Class I, Division 1,
Groups C and D, T6, Ex db IIA T6, Class I, Zone 1,
AEx db IIA T6
ATEX Flameproof - Gas:
II 2 G, Ex db IIA T6 Gb
IECEx Flameproof - Gas: Ex db IIA T6 Gb
Maximum Travel
15 mm (0.6 inch)
Material Temperature Capabilities
Valve Body Assembly:
(1)
Enclosure Rating
Type 4X and IP66
Duty Cycle
50% maximum
Standard Bonnet O-Ring: -40 to 135°C (-40 to 275°F)
Electric Actuator Assembly: -20 to 70°C
(-4 to 158°F), < 90% non-condensing humidity
Flow Direction
Flow up (standard), Flow down (optional)
1. The pressure or temperature limits in the referenced tables and any applicable ASME code limitations should not be exceeded.
2. 10% variation can be expected, based on temperature and pressure of application.
2
Enclosure Material
Cast aluminum alloy with powder coat paint
Approximate Weight:
18 - 27 kg (39 - 60 lbs), depending upon construction
Page 3
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Description
The Fisher D3 with easyDrive electric actuator technology (figure 1) is a globe valve with electric actuator specifically
designed for upstream, low power applications. The easyDrive operates with 12 or 24 VDC in either on/off or
Positioning configurations.
The on/off configuration has 2 different states; opened or closed, which are ideal for dump or snap acting applications.
The Positioning configuration extends the functionality to intermediate positions for flow and pressure control
applications.
Specifications
Table 1 lists specifications for the D3 control valve. Some of the specifications for a given control valve as it originally
comes from the factory are stamped on a nameplate located on the lower actuator housing.
Educational Services
For information on available courses for the Fisher D3 control valve with Gen 2 easy-Drive electric actuator, as well as a
variety of other products, contact:
Emerson Automation Solutions
Educational Services - Registration
Phone: 1-641-754-3771 or 1-800-338-8158
E-mail: education@emerson.com
emerson.com/fishervalvetraining
Installation
WARNING
Always wear protective gloves, clothing, and eyewear when performing any installation operations to avoid personal
injury.
To avoid personal injury or property damage caused by bursting of pressure‐retaining parts or by uncontrolled process
fluid, be certain the service conditions do not exceed the limits shown on the valve nameplate and in table 1. Use
pressure‐relieving devices required by government or accepted industry codes and good engineering practices.
Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance section in this
instruction manual.
WARNING
For explosionproof applications, ensure the actuator cover is properly bolted before applying power to the actuator.
Personal injury or property damage may result from fire or explosion if power is applied to the actuator with the cover
removed in a hazardous area.
For explosion‐proof applications, install rigid metal conduit and a conduit seal no more than 457 mm (18 inches) from the
actuator. Personal injury or property damage may result from explosion if the seal is not installed.
Select wiring and/or cable glands that are rated for the environment of use (such as hazardous area, ingress protection, and
temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property damage
from fire or explosion.
3
Page 4
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area approval.
Failure to follow the local, regional, and national codes could result in personal injury or property damage from fire or
explosion.
Instruction Manual
D104161X012
CAUTION
When ordered, the valve configuration and construction materials were selected to meet particular pressure, temperature,
pressure drop, and controlled fluid conditions. Responsibility for the safety of process media and compatibility of valve
materials with process media rests solely with the purchaser and end‐user. Since some body/trim material combinations
are limited in their pressure drop and temperature ranges, do not apply any other conditions to the valve without first
contacting your Emerson Automation Solutions sales office.
To avoid product damage, inspect the valve before installation for any damage or any foreign material that may have
collected in the valve body. Also remove any pipe scale, welding slag, or other foreign material from the pipeline.
1. Before installing the control valve assembly, inspect it for any damage and for any foreign material that may have
collected in the valve body.
2. Clean out all pipelines to remove scale, welding slag, and other foreign materials.
3. The control valve assembly may be installed in any orientation, but normally the actuator is vertical above the valve.
Install the valve so the flow direction arrow on the side of the valve indicates the direction of the process flow.
4. Install the valve following local and national piping codes when they apply to the application. For screwed
connections, treat the external pipe threads with a good grade pipe compound. For flanged connections, use
suitable gaskets between valve and pipeline flanges.
5. If continuous operation is required during inspection or maintenance, install a three‐valve bypass around the
control valve assembly.
Special Instructions for “Safe Use” and Installations in Hazardous Locations
ATEX/IECEx
WARNING
To avoid static discharge from the enclosure, do not rub or clean the enclosure with solvents. To do so could result in an
explosion. Clean with a mild detergent and water only.
The enclosure is nonconducting and may generate an ignitioncapable level of electrostatic charges under certain extreme
conditions. The user should ensure that the equipment is not installed in a location where it may be subjected to external
conditions (such as highpressure steam) which might cause a buildup of electrostatic charges on nonconducting surfaces.
Additionally, cleaning of the equipment shall only be done with a damp cloth.
To avoid damage to the enclosure, when screws are fully tightened into blind holes in enclosure walls, with no washer
fitted, at least one full thread shall remain free at the base of the hole.
4
Page 5
Instruction Manual
D104161X012
Startup Overview
Figure 2. Flowchart
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
PREPARE PER INSTRUCTIONS
IN INSTALLATION SECTION
ON/OFF
WIRE PER DIAGRAM FOR L2e
YES
FIRST TIME USING
Modbus?
NO
POSITIONING OR
ON/OFF?
ARE YOU USING
Modbus?
POSITIONING
WIRE PER DIAGRAM FOR 4-20 mA
NO
YES
CONNECT USB-TO-Modbus CONVERTER
TO INTERNET CONNECTED COMPUTER
FOLLOW DRIVER INSTALLATION
INSTRUCTIONS FOR YOUR DEVICE
INSTALL easy-Drive CONFIGURATION OR
Modbus MASTER SOFTWARE
CONNECT VIA Modbus TO VALVE AND
MONITOR DESIRED REGISTERS
UNIT IS READY FOR OPERATION
5
Page 6
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 3. Fisher D3 Valve with Gen 2 easy-Drive Actuator Wiring Diagram
Instruction Manual
D104161X012
CONTROLLER
POWER AND
CONTROL TERMINAL
MOTOR / GEARBOX ASSY
(GE84238)
GE47302-7
FIELD WIRING CONNECTIONS
TOP VIEW CONTROLLER
Power Requirements
Ensure a stable DC power source is available, maintaining less than 5% ripple and sufficiently surge protected for the
application. A 4 amp (minimum) power supply is required.
Wiring Instructions
1. Observe local wiring requirements for hazardous location usage.
2. Conduit seals within 450 mm (18 inches) of the enclosure port are required for explosionproof installation.
3. 18 AWG (0.52 mm
2
) to 12 AWG (3.31 mm2) wire size required.
4. Fuse system to 5A.
5. Connect enclosure and analog signal shields.
6. Ensure power is turned off before connecting the wires.
Power
1. Connect 12 or 24 VDC reference to: –
2. Connect 12 or 24 VDC positive to: +
3. Be sure to tighten terminals sufficiently to ensure solid mechanical connection.
6
Page 7
Instruction Manual
D104161X012
Figure 4. Wiring - Analog Input
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 5. Wiring - L2e
7
Page 8
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 6. Wiring - Single Dry Contact
Instruction Manual
D104161X012
Figure 7. Wiring - Modbus Input
8
Page 9
Instruction Manual
D104161X012
Figure 8. Wiring - Auxiliary Digital I/O set to input (40080=0)
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 9. Wiring - Auxiliary Digital I/O set to output (40080=1)
10 V, 25 mA max
9
Page 10
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Instruction Manual
D104161X012
Default Input Signals
The D3 with easyDrive comes from the factory calibrated and ready for use with the following default input signals
shown in table 2.
Table 2. D3 easy-Drive Default Input Signals
CONFIGURATION ON/OFF POSITIONING
Input Signal L2e (dual dry contact) 4-20 mA
If the input signal of the application matches table 2, proceed to the Wiring Instructions section. If the input signal of
the application does not match table 2, proceed to the Configuration section.
Configuration
Input Configuration
There are two functional configurations available for the easyDrive electric actuator: On/Off and Positioning. It is
possible to change an actuator from On/Off to Positioning after it has been delivered from the factory using a
positioning license key. See licensing section.
All available input signals are shown in table 3.
Table 3. All Available Input Signals
CONFIGURATION ON/OFF POSITIONING
Control Source Modbus Local Modbus Local
Input Signal Modbus
L2e Dual Dry Contact
(default)
Single Dry Contact Modbus 4-20 mA (default)
If you are using the default inputs signals, and the valve has not been disassembled or adjusted in any way, there is no
need to recalibrate the assembly. You can proceed directly to Startup (page 17).
Changing the Inputs from Default Settings
All configuration within the valve is done by setting values in Modbus registers. This can be done using any Modbus
master (flow computer, PLC, PC). Configuration software, providing a visual interface to the registers, is available
through your Emerson sales office
.
Modbus setup
Use of a serial or USB to RS-485 device is required to connect to the actuator. Refer to manufacturer's requirements for
installation. The D3 with easyDrive electric actuator Modbus factory defaults are Address 1, 9600 baud, even parity, 1
stop bit, MSB.
When a connection has been achieved, the actuator may be configured to accept the input signal over the Modbus
link (ignoring the physical inputs) and the Modbus settings may be changed to accommodate the network to which it
is attached. Other changes to functionality are possible, such as:
D Low level cutoff: 40054 (default is 5%)
D Position upon loss of signal: 40053 (default is 0%)
See Appendix A for a full map of Modbus registers and their functions.
10
Page 11
Instruction Manual
D104161X012
Figure 10. Fisher easy-Drive Configuration Software
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Connecting using the Fisher easyDrive configuration software
The Fisher easyDrive configuration software allows configuration and diagnosing of the Fisher easyDrive electric
actuator with a graphical interface. Connect a PC to the actuator using a USB or serial device to Modbus RTU converter
using the wiring instructions above. The USB or serial device will be visible in the drop menu under Serial Port Settings.
Baud rate and parity should be set to the Modbus settings of the actuator. Default actuator settings are address 1,
9600 baud, even parity, 1 stop bit, MSB. Press the AUTO button in the upper left corner to connect to the valve.
Use the Fisher easyDrive configuration software (figure 10) to make the desired changes, or register values may be
changed to allow different functionality.
Note
If an actuator is on/off, a Modbus command of 0499 in register 40001 will cause the valve to close fully, while a value of 5001000
will cause the valve to open fully. The command register has one implied decimal point.
Initial Setup
The control method selection determines what control signal to which the valve will respond. Only the control signal
selected will result in movement of the valve; all others will be ignored. The control methods available are dependent
upon the licensing tier purchased with the valve. The functions for each tier are shown below.
D On/Off Tier
11
Page 12
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Instruction Manual
D104161X012
D Dual Contact On/Off
D Single Contact On/Off
D Modbus On/Off
D Positioning Tier - License required (see Licensing section)
D Dual Contact On/Off
D Single Contact On/Off
D Modbus On/Off
D Modbus Positioning
D 4-20mA Positioning
D 4-20mA Level
When using the easy-Drive Configuration Tool, clicking on the “Control Method” box will create a drop menu as
shown. Select the desired control source; the selection will turn yellow. A box with Pending Changes will appear
showing all changers. Press “APPLY” and the valve will immediately respond to that signal only.
Figure 11.
Calibration Instructions
WARNING
To avoid personal injury or property damage, be aware that the valve will open fully and then close fully during the
calibration cycle.
12
Page 13
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
If an easy-Drive valve has been shipped from the Fisher factory, it is not necessary to perform a span calibration. If,
however, the valve has a new controller board or maintenance has been performed on the valve, such as trim
replacement, it will be necessary to perform a span calibration. A span calibration is accomplished by the following
method:
1. Ensure the process and valve are in a safe state – the valve may move during this operation
2. Press the CALIBRATE SPAN button to initiate the span calibration. The software will show a progress bar during the
calibration and display Valve Span Calibrated when complete.
Analog Input Calibration
For valves using 4-20 mA as a control source, several options are available to customize control of the actuator. Use a
4-20 mA signal generator to provide the desired signal. It is possible to calibrate the 4-20 mA signal in reverse acting or
split-ranging with the method below with at least 4 mA of signal difference between the close and open values. The
example shows a valve being changed from normal to reverse acting during the calibration process.
1. With the Control Method set to 4-20mA Positioning or 4-20mA Level, enter the Calibration screen and the
4-20mA Signal Calibration window will be visible.
2. Click the CALIBRATE CLOSE & OPEN VALUES button. A separate window will open to guide through the process.
3. Set the 4-20 mA signal to the desired value for when the valve is to be closed.
4. Enter this value into the Calibrated mA Signal text box and press Next
Figure 12.
5. Set the 4-20 mA signal to the desired value for when the valve is to be open.
6. Enter this value into the Calibrated mA Signal text box and press Next
13
Page 14
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 13.
Instruction Manual
D104161X012
7. If the Close and Open values are as expected, press Confirm to accept these values. If not, press Cancel to restart
the process.
Note
Note 1: The value of the 4-20 mA signal must have at least 4 mA difference between the close and open signals. A differential less
than that amount will cause the actuator to reject the calibration and use the previous values.
Note 2: Should the entered values vary more than 10% from the expected 4-20 mA values; the actuator will accept the calibration
and a Notification displaying “Questionable Analog Calibration” will result.
Figure 14.
Calibration with the use of Modbus
1. After the unit has been properly wired and fused per instructions in the Wiring section of this instruction manual,
turn power to the unit on.
2. Calibrate using Modbus:
a. Send position command of 0% to actuator to prevent unexpected motion. Valve will move to commanded
position following the calibration procedure.
14
Page 15
Instruction Manual
D104161X012
b. Send a value of 1 to register 40043. Valve plug will move to fully open position and then to fully closed. The valve
plug will then return to the commanded position.
If a Modbus connection is not available, and recalibration is desired, use the appropriate calibration method as
determined by the control method of your valve.
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Calibration without the use of Modbus
1. Turn power to the actuator off.
2. Wait for 10 seconds to ensure all circuits have discharged.
3. Return power to the actuator and use the appropriate calibration method for your control signal. Calibration
sequence must be done within 15 seconds of power being switched on.
4. For positioning operation using 4-20 mA:
a. Apply a 4 mA signal between pins 4-20 mA - and 4-20 mA +. If Span is currently uncalibrated, valve plug will not
move at this time.
b. Apply a 20 mA signal between pins 4-20 mA - and 4-20 mA +. If Span is currently uncalibrated, valve plug will not
move at this time.
c. Apply a 4 mA signal between pins 4-20 mA - and 4-20 mA +; valve plug will move to the upper stop, immediately
followed by moving to the lower, closed position.
d. If calibration of the analog input is desired to improve positional accuracy, an optional operation is listed on
page 13 titled Analog Input Calibration.
5. For On/Off operation using dual-input dry contact:
a. Close the contact to create a short between pins COMMON and CLOSE. If Span is currently uncalibrated, valve
plug will not move at this time.
b. Close the contact to create a short between pins COMMON and OPEN. If Span is currently uncalibrated, valve
plug will not move at this time.
c. Close the contact to create a short between pins COMMON and CLOSE; valve plug will move to the upper, open
position and then to the lower, closed position.
6. For On/Off operation using single dry contact:
a. Open the contact to create an open circuit between pins COMMON and OPEN. If Span is currently uncalibrated,
valve plug will not move at this time.
b. Close the contact to create a short between pins COMMON and OPEN. If Span is currently uncalibrated, valve
plug will not move at this time.
c. Open the contact to create an open circuit between pins COMMON and OPEN; valve plug will move to the upper,
open position and then to the lower, closed position.
7. The unit is now calibrated.
Licensing
The Gen 2 easy-Drive actuator has two differing modes of operation: On/Off and Positioning. The On/Off mode is
intended for snap-acting applications where the valve is either fully open or fully closed. In this mode, the valve plug
cannot remain at any intermediate position; it will move to a fully closed or fully open position only. For applications
that require the actuator to control over the full range of motion, it is necessary to have a Positioning license installed.
A positioning license will allow access to 4-20mA positioning, 4-20mA level control and Modbus positioning.
15
Page 16
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Instruction Manual
D104161X012
Positioning licenses can be purchased with the actuator and installed at the factory or can be installed at a later date by
use of a license key on a USB license dongle. Installation of the license can be completed using the configuration
software.
1. Insert the USB license dongle into the computer connected to the Gen 2 easy-Drive actuator.
Figure 15.
2. Click the button labelled MANAGE LICENSES on the left side of the configuration software screen.
Figure 16.
3. The license control screen will open, showing all licenses installed on the USB and the actuator.
Figure 17.
16
Page 17
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
4. After verifying the presence of the desired license on the USB license dongle, click the button labelled ‘easy-Drive’
under Move To, and the license will be transferred to the valve as shown below
Figure 18.
5. It is also possible to transfer licenses from one USB license dongle to another. Place two dongles into the computer
with the configuration software. Type in the number of licenses to move and click USB 2 to move the licenses.
Start Up
WARNING
To avoid personal injury or property damage, be aware that the valve will move and respond to an input signal during start
up.
1. Before turning on power to the unit, be sure that a closed signal is being commanded to the unit.
D DryContact: contact is open.
D L2e (Dual Dry Contact): Contact closed across pins COMMON and CLOSE.
D Analog Input: signal = 4 mA.
D Modbus: position demand = 0.
2. Turn on power to the unit.
3. Apply a change in position demand to ensure unit responds properly.
D DryContact:
D Closed contact between pins COMMON and OPEN will open the valve.
D Dual contact / L2e only: Closed contact between pins COMMON and OPEN will open the valve. Closed contact
between pins COMMON and CLOSE will close the valve.
D Analog Input: valve will respond to proportional demand.
17
Page 18
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
D Modbus: valve will respond to positional demand in register 40001. 0 = fully closed and 1000 = fully open.
4. If the valve does not respond as expected, proceed to Troubleshooting guide on page 18.
5. Check conduit ports.
D Conduit seal must be in place within 450 mm (18 inches) of the enclosure.
D Unused conduit ports must be sealed with an explosionproof port plug.
6. Replace the cover and tighten all 8 bolts to 20 NSm (15 ftSlbs).
Instruction Manual
D104161X012
Troubleshooting
1. Unit does not move.
a. Verify that 12VDC to 24VDC is present on the power terminals as shown on the cover. Green heartbeat LED will
pulse near Modbus terminals when power is present.
b. Verify that all wires are firmly attached on both ends.
c. Verify that wires are connected to the correct terminals - see Wiring in the manual.
d. Verify mode of operation (on/off or positioning) matches control signal.
e. Verify mode of control (local or Modbus) matches control signal.
2. Unit does not respond to 420 mA signal
a. Verify that 12VDC to 24VDC is present on the power terminals as shown on the cover.
b. Verify that the 420 mA signal is wired correctly and that the terminals are firmly on the wires.
c. Verify mode of operation matches control signal (local control: 40067=0, positioning: 40065=1).
d. Check the value of the analog input in register 40026 to determine if it is 0 or greater.
i. If register 40026 shows 0, the 4-20 mA may be wired backwards. Swap wire and attempt again.
3. Diagnostics show a Motor Stall - Travel Deviation Fault.
a. The easyDrive electric actuator is designed to operate in a manner consistent with a pneumatic actuator. This
means that if the valve plug can not move to its commanded position, the actuator will stop, without damage,
and issue a Motor Stall - Travel Deviation Fault warning. When the command signal changes outside of the
deadband (Modbus register 40036), it will attempt to move again. Recalibrate the actuator span per instructions
in the Startup section of this manual.
4. Position on D3 is not accurate (proportional positioning units only).
a. If the position of a D3 is too high (i.e. 50% is much higher than 50% on the bonnet), check the valve type. If valve
type is D4, change to D3, cycle power, and recalibrate.
b. If the local analog input is being used (420 mA or 15 V), the analog inputs of the actuator may be calibrated to
match the input signal.
i. Command 0% (4 mA or 1 V).
18
Page 19
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
ii. Using a Modbus link, send a 1 to register 40004 or use the Fisher easyDrive configuration software by clicking
the button “Analog Cal at 0%”.
iii. Command 100% (20 mA or 5 V).
iv. Using a Modbus link, send a 1 to register 40005 or use the Fisher easyDrive configuration software by clicking
the button “Analog Cal at 100%”.
Figure 19. Adjusts to Vary Flow Capacity (Shown with Valve Plug in Seated Position)
April 2022
100%
50%
CLOSED
STEM CONNECTOR
INDICATES TRAVEL
USE 5/32 INCH
ALLEN KEY
FULL CAPACITY SETTING (FACTORY SET)
15 mm (0.6 INCH) TRAVEL
NOTE: USE THE WIDELY-SPACED TRAVEL INDICATORS,
AS SHOWN ON THE LEFT PORTION OF THIS VIEW.
REDUCED CAPACITY SETTING
10 mm (0.4 INCH) TRAVEL
NOTE: USE THE CLOSELY-SPACED TRAVEL INDICATORS,
AS SHOWN ON THE RIGHT PORTION OF THIS VIEW.
100%
50%
CLOSED
STEM CONNECTOR
INDICATES TRAVEL
Setting the Valve Flow Adjuster
The flow setting may only be adjusted if the 0.375 and 0.75 inch port sizes are installed and only when using the on/off
version.
When shipped from the factory, the actuator has the flow adjuster set at the maximum flow rate position for the given
port size.
1. Ensure the valve plug is in the seated position.
2. To change the valve flow rate, loosen the flow adjuster socket head cap screws (key 15) with a 5/32 inch Allen key,
and reposition the flow adjuster halves (key 13 and 14) to the desired flow rate position. See figure 19 for flow rate
settings.
3. Retighten the socket head screws (key 15) to 3 NSm (26 lbfSin).
4. Follow instructions for recalibration on page 10.
19
Page 20
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Instruction Manual
D104161X012
Maintenance
Refer to figure 22.
Valve parts are subject to normal wear and must be inspected and replaced as necessary. The frequency of inspection
and maintenance depends on the severity of the service conditions.
WARNING
Avoid personal injury from sudden release of process pressure or bursting of parts. Before performing any maintenance
operations:
D Do not remove the actuator from the valve while the valve is still pressurized.
D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal
injury.
D Disconnect any operating lines providing electric power, or a control signal to the actuator. Be sure the actuator cannot
suddenly open or close the valve.
D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure
on both sides of the valve. Drain the process media from both sides of the valve.
D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.
D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the
pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings.
D Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.
WARNING
For explosionproof applications, ensure the actuator cover is properly bolted before applying power to the actuator.
Personal injury or property damage may result from fire or explosion if power is applied to the actuator with the cover
removed in a hazardous area.
Do not remove the actuator cover for 10 minutes after power is disconnected if the UPS option is installed.
For explosion‐proof applications, install rigid metal conduit and a conduit seal no more than 457 mm (18 inches) from the
transducer. Personal injury or property damage may result from explosion if the seal is not installed.
Select wiring and/or cable glands that are rated for the environment of use (such as hazardous area, ingress protection, and
temperature). Failure to use properly rated wiring and/or cable glands can result in personal injury or property damage
from fire or explosion.
Wiring connections must be in accordance with local, regional, and national codes for any given hazardous area approval.
Failure to follow the local, regional, and national codes could result in personal injury or property damage from fire or
explosion.
20
Page 21
Instruction Manual
D104161X012
Figure 20. Packing and Belleville Spring Stacking Order
10
11
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
7
FEMALE PACKING ADAPTOR
12
LUBRICATE WITH 3 mm (1/8 INCH
BEAD) OF SUPPLIED HIGH
PERFORMANCE FLUORINATED
GREASE (KEY 44)
PACKING RING
12
10
LUBRICATE WITH 3 mm (1/8
9
INCH BEAD) OF SUPPLIED HIGH
PERFORMANCE FLUORINATED
GREASE
MALE PACKING ADAPTOR
8
16
LUBRICATION LOCATIONS
ON PACKING
43
3
21
Page 22
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 21. Packing and Belleville Spring Stacking Order
Instruction Manual
D104161X012
UNTIGHTENED,
NOTE THE GAP
PACKING RETAINER
(KEY 8)
BELLEVILLE SPRINGS FULLY ENCLOSED BY
THE PACKING RETAINER
VALVE PLUG, BELLEVILLE SPRINGS, AND PACKING RETAINER CORRECTLY
Valve Plug and Seat Ring Maintenance
Trim Disassembly
Key numbers are referenced in figures 20, 22, and 23.
FULLY TIGHTENED,
NO GAP
INSTALLED AND TIGHTENED
1. Isolate the control valve from the line pressure, release pressure from both sides of the valve body (key 1), and drain
the process media from both sides of the valve.
CAUTION
The following steps are intended to prevent damage to the valve plug (key 3) and seat ring (key 2) during the removal of the
bonnet and actuator.
For ON/OFF Actuators
2. Command the valve open.
3. Place an open end wrench or a similar obstruction about 6 mm (1/4 inch) thick under the FloPro.
4. Command the valve closed.
For Positioning Actuators
5. Command the valve to anywhere between 10% and 20% travel.
6. Isolate power and signal.
22
Page 23
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
7. Break the bonnet nut (key 5) loose with a hammer. Continue turning the bonnet nut by using a hammer or a large
adjustable wrench, tightened around one ear of the bonnet nut. If the bonnet (key 7) is stuck in the valve, continue
to unscrew the bonnet nut. The bonnet nut will contact the spring pins (or pipe plugs) (key 6, figure 22) and jack the
bonnet out of the valve. Carefully lift the actuator assembly from the valve body.
WARNING
The spring pins/pipe plugs (key 6) must always be in place during valve operation. They provide a safeguard against injury
when the unit is being disassembled.
8. Completely remove the packing retainer (key 8) using a 1‐1/8 inch wrench.
9. Remove the valve plug by driving out the pin (key 43) and unscrewing the valve plug from the stem. Do not remove
the Belleville springs (key 9) from the stem, in order to retain the Belleville stacking orientation as shown in figure
20.
10. Use a 1‐3/16 inch socket wrench to loosen and remove the seat ring (key 2).
CAUTION
Inspect the seat ring and valve body interior for wear, erosion, or damage in the following steps.
11. Inspect the seat ring for wear or damage. If the seating surface has been damaged, discard the seat ring.
12. Visually inspect the valve body interior below the seat ring for erosion or damage. Replace the valve body if
necessary.
WARNING
Be careful to avoid damaging the seating surface on the valve plug or seat ring as damage in these areas will allow excessive
leakage at shutoff. Avoid damaging the highly polished valve stem surface. A damaged valve stem could cut the packing
and allow process fluid to leak to the atmosphere.
Cover the opening in the valve body to prevent foreign material from getting into the valve body cavity.
Trim Assembly
1. Ensure the threads of the valve stem (key 16) and valve plug (key 3) are clean and free of debris.
2. Make sure the Belleville springs (key 9) are properly installed on the valve stem, as shown in figure 21.
3. Install the valve plug on the stem and insert a new pin (key 43).
4. Lubricate the threads of the packing retainer with anti‐seize and install into the bonnet using a 1‐1/8 inch wrench.
Make sure the Belleville springs (key 9) are completely enclosed by the packing retainer as shown in figure 21.
5. Torque the packing retainer to 81 NSm (60 lbfSft). The packing retainer has been installed correctly when a
metal‐to‐metal contact has been made between the packing retainer end and the bonnet (key 7). The packing
retainer threads should be completely enclosed by the bonnet (see figure 21).
6. Thoroughly clean the seat ring (key 2) threads and the mating threads in the valve body (key 1).
7. Apply anti‐seize lubricant to the threads of the seat ring and its mating threads in the valve body.
8. Screw the seat ring into the valve body. Use a 1‐3/16 inch socket wrench to tighten the seat ring to 170 NSm
(125 lbfSft). Remove all excess lubricant after tightening.
9. Lubricate the bonnet O‐ring (key 4) with lithium grease and install on the bonnet.
23
Page 24
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
10. Apply anti‐seize lubricant to the threads on the valve body and bonnet nut (key 5) and the contact surfaces of the
bonnet and bonnet nut flange. Install the bonnet and actuator assembly onto the valve body. Tighten the bonnet
nut until the nut stops turning. A few hammer blows will be required to ensure that the assembly is tight.
Instruction Manual
D104161X012
Packing Maintenance
WARNING
Observe the warning at the start of the Maintenance section.
Key numbers are referenced in figure 20.
The valve stem packing can only be serviced by removing the bonnet from the valve body.
Packing Disassembly
1. Disassemble the valve per steps 1 ‐ 9 in the Trim Disassembly section of the Valve Plug and Seat Ring Maintenance
section of this manual.
2. Remove the five Belleville springs (key 9), lower packing spacer (key 12), packing set (key 11), and two
anti‐extrusion washers (key 10) from the bonnet (key 7) using a formed wire hook.
3. Clean and inspect the packing box wall to ensure that the packing surfaces are not damaged. If the surface
condition is damaged and cannot be improved by light sanding, replace the bonnet.
4. Inspect the valve stem (key 16) and valve plug (key 3) for scratches or wear and replace if necessary.
Packing Assembly
The following steps define the proper procedure for installing the packing in a D3 valve. Improper packing assembly
can lead to poor valve performance. The proper packing arrangement is shown in figures 20 and 21.
1. Ensure the upper packing spacer (key 12) is installed.
2. Use the lower packing spacer (key 12) and a tube to push the upper anti‐extrusion washer (key 10) into place. Using
the lower packing spacer in this manner will ensure the upper anti‐extrusion washer is fully seated and flat when
installed in the packing bore.
3. Remove the lower packing spacer from the packing bore.
CAUTION
All D3 packing kits include a single use packet of high performance fluorinated grease. This is the only acceptable D3
packing lubricant.
Note
In the following procedure, carefully install each packing ring individually over the valve stem and push completely into the packing
box with a non‐marring tube. A 12‐inch length of 1/2 inch PVC pipe works well for this. It is recommended that the lubricated
packing rings be installed individually rather than pushed in as a set.
4. Apply a 3 mm (1/8 inch) bead of the supplied high performance fluorinated grease (key 44) around the groove of
the female packing adaptor as shown in figure 20 and install over the valve stem (key 16).
5. Apply a 3 mm (1/8 inch) bead of the supplied high performance fluorinated grease (key 44) around the groove of
the packing ring as shown in figure 20 and install over the valve stem.
24
Page 25
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
6. Install the male packing adaptor, lower anti‐extrusion washer (key 10), and lower packing spacer over the valve
stem as shown in figure 20.
7. Firmly press all packing parts into the packing bore with a tube.
8. Install the five Belleville springs (key 9) over the valve stem as shown in figure 20.
9. Install the valve plug (key 3) on the stem and insert a new groove pin (key 43).
10. Lubricate the threads of the packing retainer with anti‐seize and install into the bonnet using a 1‐1/8 inch wrench.
Make sure the Belleville springs are completely enclosed by the packing retainer as shown in figure 21.
11. Torque the packing retainer to 68 NSm (50 lbfSft). The packing retainer has been installed correctly when a
metal‐to‐metal contact has been made between the packing retainer end and the bonnet (key 7). The packing
retainer threads should be completely enclosed by the bonnet.
12. Apply anti‐seize lubricant to the threads on the valve body and bonnet nut (key 5) and the contact surfaces of the
bonnet and bonnet nut flange. Install the bonnet and actuator assembly onto the valve body. Tighten the bonnet
nut until the nut stops turning. A few hammer blows will be required to ensure that the assembly is tight.
Stem Replacement
CAUTION
If the valve stem is replaced, the packing will also need to be replaced, since the threads on the valve stem may damage the
packing when the valve stem is removed.
1. Follow the Trim Disassembly procedures, steps 1-8 on page 22 of this manual.
2. Ensure power and signal have been isolated from the actuator. Open the explosion-proof enclosure (keys 60 and
61), using a 13 mm wrench.
3. Remove the FloPro (keys 13, 14, and 15), using a 5/32 inch hex head wrench.
4. Remove the stem nut (key 27), using an 11/16 inch wrench, noting the position of the FloPro relative to the bonnet
markings.
5. Use a rubber mallet to gently drive the stem downward through the bottom of the actuator housing and remove
the stem.
6. Ensure the packing as been removed, using procedures in the Packing Disassembly on page 24 of this manual.
7. Replace the stem by gently pushing the stem up through the actuator.
8. Replace the packing and plug, using the procedures in the Packing Assembly on page 24 of this manual.
9. Install the FloPro at the same position it was removed from in step 4. Tighten the hex socket head cap screws
to 3 N•m (26 lbf•in).
10. Tighten the stem nut (key 27) to 39 N•m (29 lbf•ft) using an 11/16 inch wrench. Be sure the FloPro is not allowed
to rotate when tightening the stem nut.
11. Apply anti‐seize lubricant to the threads on the valve body and bonnet nut (key 5) and the contact surfaces of the
bonnet and bonnet nut flange. Install the bonnet and actuator assembly onto the valve body. Tighten the bonnet
nut until the nut stops turning. A few hammer blows will be required to ensure that the assembly is tight.
25
Page 26
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Instruction Manual
D104161X012
Parts Ordering
Each D3 control valve is assigned a serial number, which can be found on the nameplate. Refer to the number when
contacting your Emerson sales office
for assistance or when ordering replacement parts.
WARNING
Use only genuine Fisher replacement parts. Components that are not supplied by Emerson should not, under any
circumstances, be used in any Fisher valve, because they may void your warranty, might adversely affect the performance
of the valve, and could cause personal injury and property damage.
Parts Kits
Port Diameter (inches) 0.375 0.75 1
Trim Kits
Packing Kit (Contains keys 4, 10, 11, 43, and 44) RD3PACKX012
Valve Stem (Key 16) GE48049X012
Board Replacement Kit (On/Off is default) GE83055X012
Board Replacement Kit + Positioning License Dongle GE83126X012
Motor/Gearbox Assembly GE84237X012
Motor/Gearbox/Board Assembly (On/Off is default) GE84238X012
Motor/Gearbox/Board Assembly + Positioning License Dongle GE89047X012
Replacement Kit - Belleville Springs GE78843X012
Positioning License Dongle (1 License) GE83574X012
Positioning License Dongle (5 License) GE83574X022
Standard trim kit (Contains keys 2, 3, 4, and 43) RD3STDX0012 RD3STDX0022 RD3STDX0032
Carbide trim kit (Contains keys 2, 3, 4, and 43) RD3CARBX042 RD3CARBX052 RD3CARBX062
Parts List
Note
Recommended spare parts are included in the Parts Kits shown at the
top of this page. Contact your Emerson sales office for Part Ordering
information.
Key Description
1 Valve Body
2* Seat Ring
3* Valve Plug
4* Bonnet O‐ring
5 Bonnet Nut
6 Spring Pin (or alternate pipe plug) (2 req'd)
7 Bonnet
8 Packing Retainer
9 Belleville Springs (5 req'd)
10* Anti‐Extrusion Washer (2 req'd)
11* Packing Set
26
Key Description
12 Packing Spacer
13 FloPro Half
14 FloPro Half
15 Hex Socket Head Cap Screw (2 req'd)
16* Stem
18* O-ring
20 Locknut
25* Stem O-ring
27 Stem Nut
34 Valve Nameplate
41 Drive Screw (2 req'd)
43* Groove Pin
44* High Performance Fluorinated Grease Packing Lubricant
58 Enclosure O-ring
59 Motor/gearbox/controller assembly
60 Upper Enclosure
61 Lower Enclosure
62 Motor Cap Screws (4 req'd)
63 Motor Cap Screw Washers (4 req'd)
64 Enclosure Cap Screws (8 req'd)
65 Enclosure Cap Screw Retaining Washers (8 req'd)
66 Ground Screw
68 Certification Nameplate
69 easy-Drive Label
*Recommended spare parts
Page 27
Instruction Manual
D104161X012
Figure 22. D3 Valve Assembly
64
13 mm
60
62
65
63
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
13 mm
11/16 INCH
58
27
59
1-1/2 INCH
20
61
27
Page 28
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Figure 23. D3 Valve Assembly - Cross Sectional View
Instruction Manual
D104161X012
APPLY LUBRICANT
GE49376-B
28
Page 29
Instruction Manual
D104161X012
Appendix A - Modbus
A.1 Register Summary
Table 4. Gen 2 easy-Drive Actuator Modbus Map
(1)
Type
uint16
uint16 Digital output 40002 0 R/W 0,1
uint16 Reset error codes 40003 0 R/W 0,1
uint16 RESERVED 40004
uint16 RESERVED 40005
uint16 RESERVED 40006
uint16 RESERVED 40007
uint16 RESERVED 40008
Modbus position command
Name MB Register Default R/W Values Notes
(100=10.0%)
40001 0 R/W 0-1000
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Modbus command value with one implied decimal
place (1000=100.0%). R/W at all times but only used in
Modbus control mode. In on/off mode 0-499 will result
in a move to 0% and 500-1000 will result in a move to
100%.
0=no voltage supplied to terminals,
1=voltage supplied to terminals (Only used when
output setup is set for Remote controlled)
Value of 1 will clear faults. Will automatically set back
to 0.
uint16 RESERVED 40009
Present position of the actuator relative to span with 1
uint16 Actual position (100=10.0%) 40010 0 R 0-1000
uint16
uint16 Diagnostic Flags 40012 0 R 0-65535 Bit flags - see chart
uint16 Digital status 40013 0 R 0 - 1
uint32 Total Running Time (min) 40014, 40015 0 R 4294967296
uint32 Total Open Time (min) 40016, 40017 0 R 4294967296
uint32 Total Closed Time (min) 40018, 40019 0 R 4294967296
uint32 Number of Closed (Cycle count) 40020, 40021 0 R 4294967296
uint32 Number of Power Cycles 40022, 40023 0 R 4294967296
uint32 Number of Movements 40024, 40025 0 R 4294967296
uint16 Analog input control value 40026 0 R 0-2400
uint16 Incoming voltage 40027 0 R 0-350
uint16 Latch Open State 40028 0 R 0 - 1 Normally open latch state
Commanded position
(100=10.0%)
40011 0 R 0-1000
-Continued-
implied decimal place (1000=100.0%). Valid for all
control modes.
Present position command of the actuator relative to
span (1000=100.0%). Valid for all control modes.
0=no connection between terminals, 1=connection
between terminals (Status of digital input or output)
Total number of minutes the actuator has been
powered on since time has been reset
Total number of minutes the actuator has been at
100% of travel since time has been reset
Total number of minutes the actuator has been at 0%
of travel since time has been reset
Total number of close cycles the actuator has
performed since reset. One open/close cycle counts as
1.
Total number of times the actuator has been powered
on.
Total number of movements the actuator has
performed. Move must be at least 5% of rated travel for
cycle to increment.
Value of the analog signal in mA with 2 implied
decimals. In analog control mode, this is the command
value and is subject to the analog settings in registers
40046 to 40059. Always active but a slower refresh
rate when unit is not in analog control mode.
Diagnostic register - value of incoming voltage with 1
implied decimal.
29
Page 30
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Table 4. Gen 2 easy-Drive Actuator Modbus Map (cont.)
Type Name MB Register Default R/W Values Notes
uint16 Latch Close State 40029 0 R 0 - 1 Normally closed latch state
uint16 RESERVED 40030
uint16 RESERVED 40031
uint16 RESERVED 40032
uint16 RESERVED 40033
uint16 RESERVED 40034
uint16 RESERVED 40035
uint16 RESERVED 40036
uint16 RESERVED 40037
uint16 RESERVED 40038
uint16 RESERVED 40039
uint16 Test Register - 16 bit 40040 45964 R 45964
uint32 Test Register - 32 bit 40041, 40042 3,012,341,331 R 3,012,341,331
uint16 Span calibration 40043 0 R/W 0,1
uint16 RESERVED 40044
Fixed register to test correct reading of 16 bit registers
- Hex=B38C, Binary=1011001110001100
Fixed register to test correct reading of 32 bit registers
- Hex=B38C AE53, Binary=1011001110001100
1010111001010011
Value of 1 will initiate span calibration. Will
automatically set back to 0.
Instruction Manual
D104161X012
uint16 RESERVED 40045
uint16 RESERVED 40046
uint16 RESERVED 40047
uint16 RESERVED 40048
uint16 RESERVED 40049
uint16
uint16 Modbus timeout (s) 40051 60 R/W 0-65535
uint16 Dual contact timeout (s) 40052 60 R/W 0-3600
Loss of signal position
(100=10.0%)
40050 0 R/W 0-1001
-Continued-
Position to which valve plug will be driven upon loss of
signal. Loss of signal is based upon the active control
mode. 0-1000=0-100.0% with 1 implied decimal point.
In on/off mode 0-499 will result in movement to 0%
while 500-1000 will result in movement to 100%. A
value of 1001 in any control mode is the setting for
"lock-in-last".
Time without a valid Modbus message is seen (to any
address) before "loss of signal" motion is engaged
when in Modbus control mode. Only active in Modbus
control mode. 0=disabled
Time without a digital signal being low (contact made)
from either digital input as viewed by voltage level on
the digital input terminals. If neither contact has been
made (pulled input low) within the timeout period, the
valve plug will be moved to the loss-of-signal position.
Only active in the local, on-off, dual contact mode.
0=disabled.
30
Page 31
Instruction Manual
D3 Valve with Gen 2 easy-Drive Actuator
D104161X012
Table 4. Gen 2 easy-Drive Actuator Modbus Map (cont.)
Type Name MB Register Default R/W Values Notes
Minimum percentage signal change to elicit a
movement response based upon end position of last
movement. For example, if the previous command
uint16 Deadband (10=1.0%) 40053 5 R/W 0-250
uint16
uint16
uint16
uint16 Analog Close Value 40057 40 R 31 - 220
uint16 Analog Open Value 40058 200 R 31 - 220
uint16 Number of retries 40059 2 R/W 0-4
uint16 RESERVED 40060
Low travel cutoff position
(100=10.0%)
Analog on/off close position
(100=10.0%)
Analog on/off open position
(100-10.0%)
40054 50 R/W 0-999
40055 400 R/W 0-999
40056 500 R/W 1-1000
resulted in the actuator moving to 31.2% of travel and
deadband is set to 100 (10.0%), setpoint must
command valve to 21.2% or 41.2% before valve will
move to new position. Default is set set to minimize
signal dithering.
Analog input command, in percent with one implied
decimal (50=5.0%), below this value will result in the
valve plug moving to the closed position. Active in
both local and Modbus control modes.
When the valve is in 4-20 mA on/off mode, this value is
the point at which the valve will close. It must be set to
a smaller value than the analog on/off open position.
Percentage position value with one implied decimal
(400=40.0%).
When the valve is in 4-20 mA on/off mode, this value is
the point at which the valve will open. It must be set to
a larger value than the analog on/off close position.
Percentage position value with one implied decimal
(500=50.0%).
The analog value, in mA with one implied decimal
(40=4.0 mA), that defines the closed position
The analog value , in mA with one implied decimal
(200=20.0 mA), that defines the open position
When the valve plug encounters an obstruction, how
many attempts will it make to move past that point,
assuming no change in the command signal within the
deadband range.
April 2022
uint16 RESERVED 40061
uint16 RESERVED 40062
uint16 RESERVED 40063
uint16 RESERVED 40064
uint16 RESERVED 40065
uint16 RESERVED 40066
0=Dual Contact On/Off 1=Single Contact On/Off,
uint16 Control Source 40067 0 R/W 0-5
uint16 Valve Type 40068 1 R/W 1-10 1=D3, 2=D4
uint16 RESERVED 40069
uint16 RESERVED 40070
uint16 RESERVED 40071
uint16 RESERVED 40072
uint16 RESERVED 40073
uint16 Modbus address 40074 1 R/W 1-247 Slave Address of the actuator
uint16 Baud Rate 40075 5 R/W 4,5,6,7
uint16 Parity 40076 0 R/W 0,1,2 0=Even, 1=Odd, 2=None
uint16 Modbus stop bits 40077 1 R/W 0,1,2
uint16 MSB/LSB 40078 0 R/W 0,1 0=MSB (Big Endian), 1=LSB (Little Endian)
-Continued-
2=Modbus On/Off, 3=Modbus Positioning, 4=4-20
Positioning, 5=4-20 Level
4=4800 baud, 5=9600 baud (default), 6=19200 baud,
7=38400 baud
1 stop bit is the standard with even and odd parity
while 2 stop bits is the standard for none.
31
Page 32
D3 Valve with Gen 2 easy-Drive Actuator
Instruction Manual
April 2022
Table 4. Gen 2 easy-Drive Actuator Modbus Map (cont.)
Type Name MB Register Default R/W Values Notes
uint16 RESERVED 40079
uint16 Digital I/O selection 40080 1 R/W 0,1
uint16 Digital I/O output setup 40081 0 R/W 0,1,2,3
uint16 Digital I/O input setup 40082 0 R/W 0,1
uint16 RESERVED 40083
uint16 RESERVED 40084
uint16 RESERVED 40085
uint16 RESERVED 40086
uint16 RESERVED 40087
uint16 RESERVED 40088
uint16 RESERVED 40089
uint16 RESERVED 40090
uint16 RESERVED 40091
uint16 RESERVED 40092
uint16 RESERVED 40093
uint32 Device Tag 40094-40113 "easyDrive2" R/W
uint32 Valve serial number 40114, 40115 0 R/W*
uint32 Motor serial number 40116, 40117 0 R/W*
uint32 Motor revision 40118, 40119 0 R/W*
uint32 PCB serial number 40120, 40121 0 R/W*
uint16 PCB revision 40122, 40123 0 R/W*
uint16 Flash Firmware major revision 40124 0 R 0-65535 From flash firmware when compiled
uint16 Flash Firmware minor revision 40125 0 R 0-65535 From flash firmware when compiled
uint16 Flash Firmware mod revision 40126 0 R 0-65535 From flash firmware when compiled
uint16 Flash Firmware build revision 40127 0 R 0-65535 From flash firmware when compiled
uint16 Boot Firmware major revision 40128 0 R 0-65535 From boot firmware when compiled
uint16 Boot Firmware minor revision 40129 0 R 0-65535 From boot firmware when compiled
uint16 Boot Firmware mod revision 40130 0 R 0-65535 From boot firmware when compiled
uint16 Boot Firmware build revision 40131 0 R 0-65535 From boot firmware when compiled
uint32 PCB test date 40132, 40133
uint32 Motor test date 40134, 40135 0 R/W*
uint32 System completion date 40136, 40137 0 R/W*
1. uint is defined as unsigned integer
uint16 – unsigned 16 bit variable, can take value 0-65535.
uint32 – unsigned 32 bit variable, can take value 0-4294967295.
(Reserved) – registers used for development use only.
0 R/W*
0 - 255 per
character
0-4,294,967,296Valve assembly serial number assigned at Fisher
0-4,294,967,2
0-4,294,967,2
0-4,294,967,2
0-4,294,967,2
0-4,294,967,
296
0-4,294,967,296Seconds since January 1, 2000, Motor Supplier Test
0-4,294,967,296Seconds since January 1, 2000, Final Assembly Test
† - 32bit register contains data that spans two registers – reads and write of data needs
to be performed within the same Modbus command function to ensure coherency of
data.
0=9 V sinking digital input, 1=25 mA at 10 V digital
output
Valid only when Digital I/O selection is set to Output
(1) - 0=In position, 1=Fully closed, 2=Fully open, 3 =
Remote controlled (driven by Digital Output register)
Valid only when Digital I/O selection is set to Input (0) 0=Reference only (status appears in 40013 and does
nothing else), 1=Override (status appears in 40013 and
valve plug is moved to safe position noted in register
40050)
Device Tag (20 character UTF8 string)
assembly plant
Motor/gearbox serial number
96
Motor/gearbox revision
96
PCB serial number
96
PCB revision
96
Seconds since January 1, 2000, Board Supplier
Functional Test Date
Date
Date
D104161X012
32
Page 33
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Table 5. Diagnostic Fault Flags
Hex Value Bit Mask Description Value Bit Definition
0x8000 1000 0000 0000 0000
0x8000 1000 0000 0000 0000
0x4000 0100 0000 0000 0000 Motor Assembly Stall - Travel Deviation 16384 14
0x2000 0010 0000 0000 0000 Discrete Input override mode active 8192 13
0x1000 0001 0000 0000 0000 System or Watchdog fault 4096 12
0x0800 0000 1000 0000 0000
0x0400 0000 0100 0000 0000
0x0200 0000 0010 0000 0000 Analog Input span calibration not in legal range 512 9
0x0100 0000 0001 0000 0000 256 8
0x0080 0000 0000 1000 0000 Valve was shutdown while moving 128 7
0x0040 0000 0000 0100 0000 Valve span calibrated (informational) 64 6 Span has been calibrated and actuator is ready.
0x0020 0000 0000 0010 0000 Valve position controller active (informational) 32 5 Actuator is active and ready.
0x0010 0000 0000 0001 0000 Loss of signal active 16 4
0x0008 0000 0000 0000 1000 8 3
0x0004 0000 0000 0000 0100
0x0002 0000 0000 0000 0010
0x0001 0000 0000 0000 0001
Fault in N.V. Memory – system has restored
default settings
Fault in N.V. Memory – system has restored
default settings
Analog Input calibration value not in expected
range
Valve travel distance calibration not in legal
range
Modbus command has been sent (starts a
calibrated system)
Analog input initialized (system has seen input
>3 mA/1 V)
Start delay active (within 15 second calibration
window)
32768 15
32768 15
2048 11
1024 10
4 2 The actuator is successfully moving the valve.
2 1 4-20 mA analog input has a valid signal present
1 0
A memory fault has occurred and the actuator
has been restored to factory defaults. Contact
your Emerson sales office
A memory fault has occurred and the actuator
has been restored to factory defaults. Contact
your Emerson sales office.
The actuator is unable to move to the
commanded position and has stopped. Follow
troubleshooting guide in Help section to remedy.
The digital input has detected a closed contact
and the actuator has moved to its safe position.
Check switch input device status.
The actuator has experienced a fatal error and
shut down. Contact your Emerson sales office.
The analog values entered do not match the
analog signal level. Check analog signal value and
value entered.
The valve travel distance is outside the
acceptable range. Confirm valve type and that no
obstructions are present.
The analog values for open and close are less
than 4 mA and previous values have been
maintained. Calibrate analog input with
differential >4 mA.
Actuator was powered down during a move and
actual position may vary from commanded.
Recalibrate the valve span.
Control signal not present. Signal is <3 mA,
timeout period exceeded (40051 or 40052).
Span calibration using physical inputs allowed
during startup
.
33
Page 34
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Appendix B - Certificate of Conformance
Instruction Manual
D104161X012
34
Page 35
Instruction Manual
D104161X012
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
35
Page 36
D3 Valve with Gen 2 easy-Drive Actuator
April 2022
Instruction Manual
D104161X012
Neither Emerson, Emerson Automation Solutions, nor any of their affiliated entities assumes responsibility for the selection, use or maintenance
of any product. Responsibility for proper selection, use, and maintenance of any product remains solely with the purchaser and end user.
Fisher and easy-Drive are marks owned by one of the companies in the Emerson Automation Solutions business unit of Emerson Electric Co. Emerson
Automation Solutions, Emerson, and the Emerson logo are trademarks and service marks of Emerson Electric Co. All other marks are the property of their
respective owners.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not
to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are
governed by our terms and conditions, which are available upon request. We reserve the right to modify or improve the designs or specifications of such
products at any time without notice.
Emerson Automation Solutions
Marshalltown, Iowa 50158 USA
Sorocaba, 18087 Brazil
Cernay, 68700 France
Dubai, United Arab Emirates
Singapore 128461 Singapore
www.Fisher.com
36
E 2016, 2022 Fisher Controls International LLC. All rights reserved.
Loading...
