Instruction Manual

D103793X012

585CLS Actuator

April 2018

Fisher™ 585CLS Long Stroke Piston Actuator

Contents

Introduction 1.................................

Safety Instructions 1............................

Specifications 2................................

Inspection and Maintenance Schedules 2...........

Parts Ordering 2................................

Installation 3..................................

Operation 3...................................

Maintenance 3.................................

Latest Published Instruction Manual 5..............

Introduction

The product covered in this document is Inactive. This document, which includes the latest published version of the
instruction manual, is made available to provide updates of newer safety procedures. Be sure to follow the safety
procedures in this supplement as well as the specific instructions in the included instruction manual.

Part numbers in the included instruction manual should not be relied on to order replacement parts. For replacement
parts, contact your Emerson sales office

For more than 20 years, Fisher products have been manufactured with asbestos‐free components. The included
manual might mention asbestos containing parts. Since 1988, any gasket or packing which may have contained some
asbestos, has been replaced by a suitable non‐asbestos material. Replacement parts in other materials are available
from your sales office.

or Local Business Partner.

Safety Instructions

Please read these safety warnings, cautions, and instructions carefully before using the product.

These instructions cannot cover every installation and situation. Do not install, operate, or maintain this product
without being fully trained and qualified in valve, actuator and accessory installation, operation and maintenance. To

avoid personal injury or property damage it is important to carefully read, understand, and follow all of the contents of
this manual, including all safety cautions and warnings. If you have any questions about these instructions, contact

your Emerson sales office or Local Business Partner before proceeding.

www.Fisher.com

585CLS Actuator

April 2018

Instruction Manual

D103793X012

Specifications

This product was intended for a specific range of service conditions‐‐pressure, pressure drop, process and ambient
temperature, temperature variations, process fluid, and possibly other specifications. Do not expose the product to
service conditions or variables other than those for which the product was intended. If you are not sure what these
conditions or variables are, contact your Emerson sales office
product serial number and all other pertinent information that you have available.

or Local Business Partner for assistance. Provide the

Inspection and Maintenance Schedules

All products must be inspected periodically and maintained as needed. The schedule for inspection can only be
determined based on the severity of your service conditions. Your installation might also be subject to inspection
schedules set by applicable governmental codes and regulations, industry standards, company standards, or plant
standards.

In order to avoid increasing dust explosion risk, periodically clean dust deposits from all equipment.

When equipment is installed in a hazardous area location (potentially explosive atmosphere), prevent sparks by proper
tool selection and avoiding other types of impact energy. Control Valve surface temperature is dependent upon
process operating conditions.

WARNING

Control valve surface temperature is dependent upon process operating conditions. Personal injury or property damage,
caused by fire or explosion, can result if the valve body surface temperature exceeds the acceptable temperature for the
hazardous area classification. To avoid an increase of instrumentation and/or accessory surface temperature due to process
operating conditions, ensure adequate ventilation, shielding, or insulation of control valve components installed in a
potentially hazardous or explosive atmosphere.

Parts Ordering

Whenever ordering parts for older products, always specify the serial number of the product and provide all other
pertinent information that you can, such as product size, part material, age of the product, and general service
conditions. If you have modified the product since it was originally purchased, include that information with your
request.

WARNING

Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Automation Solutions should
not, under any circumstances, be used in any Fisher product, because they may void your warranty, might adversely affect
the performance of the product, and could cause personal injury and property damage.

2

Instruction Manual

D103793X012

585CLS Actuator

April 2018

Installation

These safety instructions are limited to pneumatic actuators which are operating using air or nitrogen (inert gas). If the
application requires use of a flammable or hazardous gas, you must contact your Emerson sales office
Business Partner for assistance.

WARNING

To avoid personal injury and property damage caused by bursting of parts and to avoid parts damage, malfunction of
control valve, or loss of control of the process caused by excessive pressure, do not exceed the maximum pressures or
temperatures for this actuator, as given in the applicable product literature or on the nameplate. Use pressure‐limiting or
pressure‐relieving devices to prevent the actuator pressure from exceeding specified limits. If you cannot determine the
limits for this product, contact your Emerson Automation Solutions sales office before proceeding.

D To avoid personal injury, always wear protective gloves, clothing, and eyewear when performing any installation

operations.

D Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

D If hoisting the actuator, use a nylon sling to protect the surfaces. Carefully position the sling to prevent damage to the

actuator tubing and any accessories. Also, take care to prevent people from being injured in case the hoist or rigging
might slip. Be sure to use adequately sized hoists and chains or slings to handle the assembly.

D If installing into an existing application, also refer to the WARNING in the Maintenance section.

or Local

Operation

WARNING

When moving the actuator stem or shaft with loading pressure applied, use caution to keep hands and tools out of the
actuator travel path. Personal injury and property damage is possible if something is caught between the actuator stem
and other control valve assembly parts.

Maintenance

WARNING

Avoid personal injury or property damage from sudden release of process pressure or uncontrolled movement of parts.
Before performing any maintenance operations:

D Do not remove the actuator while the valve is pressurized.

D Always wear protective gloves, clothing, and eyewear.

D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the

actuator cannot suddenly open or close the valve.

3

585CLS Actuator

April 2018

Instruction Manual

D103793X012

D Vent any pneumatic pressure from the actuator and relieve any actuator spring pre‐compression.

D Use lock‐out procedures to be sure that the above measures stay in effect while you work on the equipment.

D To avoid personal injury due to the sudden uncontrolled movement of parts, do not loosen the stem connector cap

screws when the stem connector has spring force applied to it.

D Never apply pressure to a partially assembled actuator unless all pressure‐retaining parts have been installed properly.

D Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

Neither Emerson, Emerson Automation Solutions, nor any of their affiliated entities assumes responsibility for the selection, use or maintenance
of any product. Responsibility for proper selection, use, and maintenance of any product remains solely with the purchaser and end user.

Fisher is a mark owned by one of the companies in the Emerson Automation Solutions business unit of Emerson Electric Co. Emerson Automation Solutions,
Emerson, and the Emerson logo are trademarks and service marks of Emerson Electric Co. All other marks are the property of their respective owners.

The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not
to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are
governed by our terms and conditions, which are available upon request. We reserve the right to modify or improve the designs or specifications of such
products at any time without notice.

Emerson Automation Solutions

Marshalltown, Iowa 50158 USA
Sorocaba, 18087 Brazil
Cernay, 68700 France
Dubai, United Arab Emirates
Singapore 128461 Singapore

www.Fisher.com

4

E 2018 Fisher Controls International LLC. All rights reserved.

Instruction Manual

D103793X012

585CLS Actuator

Fisherr 585CLS Long Stroke Piston Actuator

October 2013

Contents

Introduction 1.................................

Scope of Manual 1.............................

Description 1.................................

Specifications 2...............................

Educational Services 2.........................

Principle of Operation 2.........................

Installation 4..................................

Bypass Assembly 5............................

Three-Way Valve Applications Note 6.............

Actuator Mounting 6............................

Handwheels 6.................................

Maintenance 7.................................

Non-Handwheel Construction 7.................

Handwheel Construction 8.....................

Stem Connection Procedure 9...................

Parts Ordering 9................................

Parts List 10...................................

Introduction

Figure 1. Fisher 585CLS Piston Actuator

W2795-1

Scope of Manual

This instruction manual provides information on installation, maintenance, and parts ordering for the Fisher 585CLS
Long Stroke piston actuator. Refer to separate instruction manuals for information about other equipment and
accessories used with these actuators.

Do not install, operate, or maintain a 585CLS actuator without being fully trained and qualified in valve, actuator, and
accessory installation, operation, and maintenance. To avoid personal injury or property damage, it is important to
carefully read, understand, and follow all the contents of this manual, including all safety cautions and warnings. If you
have any questions about these instructions, contact your Emerson Process Management sales office before
proceeding.

Description

585CLS piston actuators are available with travel capabilities exceeding 203 mm (8 inches) up through 610 mm (24
inches). This actuator is available with a manual handwheel, which can be used to open, close, or position the valve.
The manual handwheel may also be used as a stop to limit the upward travel of the valve plug.

The 585CLS actuator typically is equipped with either a FIELDVUE™ DVC6200 digital valve controller or 3600
positioner for throttling service. For on-off service, the actuator cylinder is loaded and unloaded through the operation
of a solenoid valve, pneumatic switch, or similar equipment.

www.Fisher.com

585CLS Actuator

October 2013

Instruction Manual

D103793X012

Specifications

Specifications for 585CLS piston actuators are given in table 1. Some individual actuators come from the factory with
specifications stamped on a nameplate attached to the yoke.

Educational Services

For information on available courses for Fisher 585CLS pistonactuators,aswellasavariety of other products, contact:

Emerson Process Management
Educational Services, Registration
P.O. Box 190; 301 S. 1
Marshalltown, IA 50158-2823
Phone: [phone] or
Phone: [phone]
FAX: [phone]
e-mail: [e-mail]

st

Ave.

Principle of Operation

The 585CLS piston actuator uses a piston that moves inside the actuator cylinder.

From an equilibrium state, the actuator reacts to a force unbalance that is created by increasing supply pressure on
onesideofthepiston,anddecreasingitontheother.Thismoves the piston up or down, and results in a repositioning
of the valve control element.

For more detailed information on the 3610 positioner and DVC6200 digital valve controllers, refer to the Principle of
Operation section in the 3610 and DVC6200 Instruction Manuals.

2

Instruction Manual

D103793X012

Table 1. 585CLS Specifications (Fabricated Yoke Actuators)

Operating Pressure

Minimum Recommended: For v alves with low thrust
requirements--2.4 bar (35 psig); for all other
valves--3.4 bar (50 psig)
Maximum Allowable: 127 mm (5-inch) to 305 mm
(12-inch) diameter cylinders--17.2 bar (250 psig)
unless limited by maximum allowable supply pressure
of positioner or switching devices; 356 mm (14-inch)
diameter cylinder--13.8 bar (200 psig) unless limited
by maximum allowable supply pressure of positioner
or switching device

(1)

585CLS Actuator

October 2013

Piston Diameters and Areas

See table 3

Yoke Boss and Valve Stem Diameters

See table 2

Pressure Connections

Standard is 1/4 NPT. For larger sizes, consult your
Emerson Process Management sales office

Travel Information

Construction Materials

All Types: 229 mm (9 inches) through 610 mm (24
inches) in 25 mm (1-inch) increments as shown in
figure 3
Travel Ratio for Handwheel Construction: 10
complete revolutions of the wheel moves the stem
25 mm (1 inch)

Thrust Information

See table 3

Operative Ambient Temperature

(1)

Standard:

-23 to 74_C(-10to165_F)
Optional:

Low Temperature: -46 to 66_C(-50to150_F)
High Temperature: -23 to 121_C(-10to250_F)

1. The pressure/temperature limits in this manualand any applicable standard or code limitation for valve should not be exceeded.

Cylinder Body: 127 mm through 356 mm
(5-inch through 14-inch)

Piston Rod

Yoke Structural steel

Stem Connector Stainless steel

Piston Aluminum

Bolting and fasteners NCF

O-rings Nitrile

Options

J Fisher 377 trip valves to fail actuator up, down, or

lock in last position,
side-mounted handwheel

Table2.YokeBossandValveStemDiameters

ACTUATOR SIZE

All

1. Heavy actuatorto bonnet bolting.

YOKE BOSS DIAMETER VALVE STEM DIAMETER

mm Inches mm Inches

127
178

5H

(1)

7

Part Material

Steel, chrome
plated

Steel, chrome
plated

J Limit switches, J Integral

25.4 or 31.8

50.8

1or1-1/4

2

3

585CLS Actuator

October 2013

Instruction Manual

D103793X012

Table 3. Thrust

PISTON

DIAMETER

mm mm mm

127
152 182 5030 7560 10100 12600 15100 17600 18900
203 323 8940 13400 17900 22400 26800 31300 33500
254 507 14000 21000 27900 34900 41900 48900 52500
305 730 20100 30200 40300 50300 60500 70300 75600
356 993 27400 41100 54700 68500 82300 96100 103000
127
152 167 4580 6890 9210 11500 13800 16100 17300
203 309 8500 12800 17000 21300 25500 29800 31900
254 491 13600 20300 27100 33900 40700 47600 50700
203
254 475
305 698 19300 28900 38500 48000 57800 67200 72100
356 961 26500 39800 52900 66300 79600 93000 99600

PISTON

DIAMETER

Inches Inches Inches

5
6 28.3 1130 1700 2260 2830 3390 3960 4240

8 50.3 2010 3020 4020 5030 6030 7040 7540
10 78.5 3140 4710 6280 7850 9420 11000 11800
12 113.1 4520 6790 9050 11300 13600 15800 17000
14 153.9 6160 9240 12300 15400 18500 21600 23100

5

6 25.9 1030 1550 2070 2590 3100 3620 3880

8 47.9 1910 2870 3830 4790 5740 6700 7180
10 76.1 3050 4570 6090 7610 9140 10700 11400

8
10 73.6
12 108.2 4330 6490 8660 10800 13000 15100 16200
14 149.0 5960 8940 11900 14900 17900 20900 22400

1. For operating pressures above10.3 bar (150 psig), consult your Emerson Process Management salesoffice.

2. For travels greater than 406 mm (16 inches) with 10.3to 17.3 bar (150 to 250 psig) operating pressure.

3. For travels greater than 406mm (16 inches).

STROKE

Push ---

Pull 44.5

Pull 63.5

STROKE

Push ---

Pull 1.75

Pull 2.5

PISTON

ROD
SIZE

PISTON

ROD
SIZE

PISTON

AREA

2

127 3500 5250 6980 8720 10500 12200 13100

111 3060 4580 6140 7650 9210 10700 11500

(2)

293

(3)

PISTON

AREA

19.6 786 1180 1570 1960 2360 2750 2950

17.2 689 1030 1380 1720 2070 2410 2580

(2)

45.4

(3)

2.8 4.1 5.5 6.9 8.3 9.7 10.3

8050 12100 16100 20200 24200 28200 30200

13100 19700 26200 32700 39300 45800 48900

40 60 80 100 120 140 150

2

1810 2720 3630 4540 5440 6350 6800
2950 4420 5890 7360 8840 10300 11000

TOTAL THRUST

Operating Pressure, bar

Force, Newtons

Operating Pressure, psig

Force, Pounds

(1)

Installation

WARNING

To avoid personal injury or property damage caused by cylinder fracture as a result of piston impact, install the stem
connector securely before supplying pressure to the positioner. Use only a regulator-controlled air supply to move the
actuator piston so that you can install the stem connector. Do not use the positioner to move the actuator piston before
installing the stem connector.

Always wear protective gloves, clothing, and eyewear when performing any installation operations to avoid personal
injury.

To avoid personal injury or property damage caused by bursting of pressure-retaining parts, be certain the cylinder
pressure or other pressure ratings do not exceed the limits listed in table 1. Use pressure-limiting or pressure-relieving
devices to prevent cylinder pressure or other pressure ratings from exceeding these limits.

4

Instruction Manual

D103793X012

Check with your process or safety engineer for any additional measures that must be taken to protect against process
media.

If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance sections in this
instruction manual.

585CLS Actuator

October 2013

When an actuator and valve are shipped together as a control valve assembly, the actuator is normally mounted on the
valve. Follow the valve instructions when installing the control valve in the pipeline. If the actuator is shipped
separately or if it is necessary to mount the actuator on the valve, perform the Actuator Mounting procedures in this
instruction manual corresponding to your actuator size. For information on mounting valve positioners, refer to the
3610 or DVC6200 instruction manuals for details.

If a 585CLS actuator is being installed without a positioner, the cylinder loading pressures should be supplied through
a 4-way solenoid valve or a switching valve.

The supply pressure medium should be clean, dry filtered air. If the supply source is capable of exceeding the
maximum actuator operating pressure or positioner supply pressure, appropriate steps must be taken during
installation to protect the positioner and all connected equipment against overpressure.

WARNING

Dropping the actuator and any attached accessories and/or valve may cause personal injury and/or equipment damage. For
all mounting procedures use an adequately sized chain, sling, hoist, or crane to handle the actuator and any attached
accessories and/or valve. Use caution during lifting and handling to prevent slippage, swinging, faulty equipment
connections, or sudden shock loads.

CAUTION

To avoid damage to actuator parts and difficult operation of actuator handwheels, open the bypass valve before using a
handwheel.

If manual operation is required, the actuator should be equipped with a manual handwheel. To manually move the
piston rod with the handwheel, first open the bypass needle valve (key 54, figure 2), place the handwheel indicator in
the neutral position, and insert the locking pin in the sleeve assembly. Then turn the handwheel in the selected
direction as indicated on the wheel.

The control valve should be located where it will be accessible for servicing. Room should be left above and below the
control valve to permit removal of the actuator and valve plug.

Bypass Assembly

The bypass is furnished as shown in figure 2 only when a handwheel actuator is specified. The bypass allows the
pressure to equalize on either side of the piston, so that the manual actuator can be used to position the valve.

Flow through the bypass tubing is controlled by an angle needle valve (key 54, figure 2), which is operated manually.
This valve should be closed when air pressure is being used to operate the valve.

5

585CLS Actuator

October 2013

Instruction Manual

D103793X012

Three-Way Valve Applications Note

WARNING

To avoid loss of control of process fluid and subsequent personal injury or property damage caused by bursting of
pressure-retaining parts, be sure the cylinder pressure does not exceed 80 psig in high cycle-rate, fast stroking speed,
three-way valve applications.

In three-way valve applications where the actuator fully strokes at a frequency of once per minute or faster, and the
stroking speed is rapid (less than 0.5 seconds per stroke), there is a possibility that the stem can fracture at the plug if
the actuator cylinder pressure is greater than 80 psig. This can cause loss of control of process fluid and further
damage to the actuator. Consideration should be given to the use of high-strength, fatigue-resistant stem materials in
these applications.

Actuator Mounting

The following procedure describes how to mount a 585CLS actuator on a push-down-to-close valve so that the piston
stem to valve plug stem connection allows full travel and proper shutoff. Key numbers referenced in the following
steps are shown in figures 2 and 3.

If you purchase a 585CLS actuator for field installation on a control valve, mount the actuator on the valve and secure it
to the bonnet with the eight bonnet-to-actuator bolts. The stem connection should then be made up to clamp the
actuator stem and valve plug stem together to provide proper valve travel.

CAUTION

To avoid damaging the seating surfaces, do not rotate the valve plug while it is seated. Avoid damage to the valve plug
stem by careful use of tools during travel adjustments.

1. With the valve assembled and actuator mounted, make sure the valve plug is in the closed position. Then turn the
two stem locknuts (key 23) all the way onto the stem thread.

2. Starting with the cylinder fully retracted, manually or with air pressure extend the piston rod extension the specified
valve travel.

3. Attach the stem connector (key 22), clamping the pistonrodextensiontothevalvestem.Besureyoualsoattach
the feedback arm (key 4) and travel indicator (key 3).

4. Cycle the actuator to check availability of desired total travel and that the valve plug seats before the cylinder
reaches the end of its stroke. You can make minor travel adjustments, if necessary, by loosening the stem
connector slightly, tightening the locknuts together, and (with the valve plug off the seat) screwing the stem either
into or out of the stem connector by means of a wrench on the locknuts.

5. If the total travel is adequate, tighten the stem connector (key 22) securely, lock the stem locknuts (key 23) against
the connector, and adjust the indicator scale (key 7) on the yoke (key 1) to show valve plug position.

6. Provide a gauge, if necessary, to measure the pressure to the actuator. Make a final adjustment on the positioner to
set the starting point of valve travel and to obtain full travel for the given instrument range.

Handwheels

Key numbers referenced in the following steps are shown in figures 2 and 3.

6

Instruction Manual

D103793X012

585CLS Actuator

October 2013

With the pointer (key 42) in the neutral position, automatic operation is possible throughout full travel. The locking
pin (key 10) should be left out during automatic operation, and the needle valve (key 54) must be closed.

For manual operation, the locking pin (key 10) must be inserted into the hole in the sleeve assembly before you open
the needle valve (key 54). Rotation of the handwheel (key 32) in either direction causes the valve stem to move
because of the pinned connection between the piston rod extension and sleeve. There is a directional arrow and the
word “OPEN” cast on the handwheel to indicate the rotation required to open the valve. To shift from manual to
automatic operation, return the handwheel pointer (key 42) to the neutral position, close the needle valve (key 54),
andremovethetaperedpin(key10).

The handwheel assembly can provide a travel stop to restrict upward travel of the valve plug. When you set the travel
stop, the tapered pin (key 10) should be left out. As an example, consider the control valve with a push-down-to-close
valve plug action. To restrict full opening, turn the handwheel (key 32) to lower the sleeve assembly (key 9). In normal
operation, as the valve opens, the stem connector (key 22) contacts the lower part of the sleeve before full valve travel
is reached. You can note the amount of restriction on the travel scale (key 7).

Note

If an emergency arises, you can close the valve (push-down-to-close) quickly without inserting the pin into the sleeve assembly.
First, turn the handwheel to move the sleeve against the stem connector (key 22), then open the needle valve and turn the
handwheel to force the valve plug closed.

Maintenance

Instructions are given below for complete disassembly of the actuator. When inspection or repair is necessary,
disassemble the actuator only as far as is required to accomplish the job.

WARNING

Avoid personal injury from sudden release of process pressure or uncontrolled process fluid. Before starting disassembly:

D Do not remove the actuator from the valve while the valve is still pressurized.

D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations to avoid personal

injury.

D Disconnect any operating lines providing air pressure to the actuator. Be sure the actuator cannot suddenly open or

close the valve.

D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure

on both sides of the valve. Drain the process media from both sides of the valve.

D Vent the power actuator loading pressure.

D Use lock-out procedures to be sure that the above measures stay in effect while you work on the equipment.

D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the

pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings, or when
loosening the packing box pipe plug.

D Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

Non-Handwheel Construction

Key numbers used below are shown in the figure 3 assembly drawing.

7

585CLS Actuator

October 2013

Instruction Manual

D103793X012

1. Disconnect the cylinder tubing from the cylinder (key 11) and positioner.

2. Break the stem connection by loosening the two locknuts (key 23) and removing the four cap screws from the stem
connector.

Note

Refer to the appropriate instruction manual for any maintenance or adjustments that need to be made on the positioner.

3. You can remove the cylinder (key 11) by unscrewing the four cap screws (key 14) that fasten it to the yoke (key 1).

Note

Refer to the manufacturer's instruction manual for disassembly, maintenance and parts ordering instructions for the cylinder.

4. Reassemble the actuator in the reverse order of the above instructions. Refer to the section Stem Connection
Procedure to properly attach the valve stem to the cylinder rod extension.

Handwheel Construction

Key numbers used below are shown in the figure 2 assembly drawing.

1. Disconnect the cylinder tubing (key 47) from the cylinder (key 11) and positioner.

2. Disengage the locking pin (key 10), if necessary. Then break the stem connection by loosening the two locknuts
(key 23) and removing four cap screws from the stem connector (key 22).

Note

Refer to the appropriate instruction manual for any maintenance or adjustments that need to be made on the positioner.

3. Unscrew the four cap screws (key 14) that fasten the cylinder (key 11) to the handwheel extension (key 8). Then
pull the cylinder, piston, and piston rod extension out of the sleeve (key 9).

4. Unscrew the piston rod extension from the cylinder piston rod using a wrench on the cylinder piston rod flats to
keep the two from turning together.

Note

Refer to the manufacturer's instruction manual for disassembly, maintenance and parts ordering instructions for the cylinder.

5. To continue disassembly, remove the six cap screws (key 13) in order to take off the handwheel extension. Be
careful not to lose the key (key 28).

6. Loosen the set screws (key 36) in the gear case (key 18) and handwheel cap (key 35). Unscrew the handwheel cap
and remove the handwheel (key 32).

7. Unscrew the worm retainers (keys 29 and 30) and rotate the worm shaft (key 31) to remove it from the gear case.

8. Unscrew the cap screws (key 44) and remove the gear case.

8

Instruction Manual

D103793X012

9. One thrust bearing (key 20) is now exposed. To expose the other thrust bearing, unscrew the gear (key 19) from the
sleeve (key 9).

Note

The bearing retainer (key 21) sits on top of six set screws (key 27). If the gear case is just going to be repacked and no parts are
changed which would change the free play in the bearings, you do not need to make any adjustment with the set screws.

10. Upon reassembly, pack the bearings (keys 20 and 40) with lithium grease. Also apply lithium grease to the surfaces
ofthesleeveandthebearingsurfacesofthewormshaft.Usethe zerk fitting for periodic lubrication after assembly.

11. Reassemble in the reverse order of the above steps observing the following points:
a. Line up the key (key 28) with the slot in the sleeve.

b. After the unit is reassembled, adjust the set screws (key27), if necessary, to eliminate free play in the bearings.

Lockthesetscrewsinplacewiththehexnuts(key41).

Note

Over-tightening the set screws will make handwheel operation difficult.

585CLS Actuator

October 2013

Stem Connection Procedure

Thefollowingprocedureisforapush-down-to-closevalve.Theobjectiveofthisprocedureisthatthestemconnection
must be made so that the valve strokes from full open to closed before the actuator reaches full stroke.

CAUTION

To avoid damaging the seating surfaces, do not rotate the valve plug while it is seated. Avoid damage to the valve plug
stem by careful use of tools during travel adjustments.

1. With the valve assembled and actuator mounted, make sure the valve plug is in the closed position. Then turn the
two stem locknuts (key 23) all the way onto the stem thread.

2. Starting with the cylinder fully retracted, manually or with air pressure extend the piston rod extension the specified
valve travel.

3. Attach the stem connector (key 22), clamping the pistonrodextensiontothevalvestem.Besureyoualsoattach
the feedback arm and travel indicator (key 3).

4. Cycle the actuator to check availability of desired total travel and that the valve plug seats before the cylinder
reaches the end of its stroke. You can make minor travel adjustments, if necessary, by loosening the stem
connector (key 22) slightly, tightening the locknuts (key 23) together, and (with the valve plug off the seat)
screwing the stem either into or out of the stem connector (key 22) by means of a wrench on the locknuts.

5. If the total travel is adequate, tighten the stem connector (key 22) securely, lock the stem locknuts (key 23) against
the connector, and adjust the indicator scale (key 7) on the yoke to show valve plug position.

6. Provide a gauge, if necessary, to measure the pressure to the actuator. Make a final adjustment on the positioner to
set the starting point of valve travel and to obtain full travel for the given instrument range.

Parts Ordering

When corresponding with your Emerson Process Management sales office about this equipment, refer to the serial
number found on the actuator nameplate (key 21). Also, specify the complete 11-character part number from the
following Parts List when ordering replacement parts.

9

585CLS Actuator

October 2013

Instruction Manual

D103793X012

WARNING

Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Process Management should
not, under any circumstances, be used in any Fisher valve, because they may void your warranty, might adversely affect the
performance of the valve, and could cause personal injury and property damage.

Parts List

Note

Part numbers are shown for recommendedspares only. For part
numbers not shown, contact your Emerson Process Management sales
office.

In the listing below, some parts are related to a 6-inch wide channel yoke leg or an 8-inch wide channel yoke leg. This
refers to the size of the vertical channel iron member of the yoke. This is not to be confused with a 5H or 7-inch
diameter yoke boss, which refers to the actuator-to-valve mounting design.

Some parts are also related to the piston rod or piston rod extension diameter. This measurement should be taken
above the stem connector where the rod is full diameter.

Key Description

1Yoke
2 Cable Protector, galvanized steel
3TravelIndicator,SST
4 Feedback Arm, pl steel
4 Anti-Rotator, steel
5MachineScrew,steelpl
6 Washer, steel pl
7 Travel Scale, aluminum
8 Handwheel Extension

9 Sleeve Assembly
10 Locking Pin, 416 SST
11 Air Cylinder

Refer to the nameplateattached to the cylinder. Order all

replacement parts for the cylinder from the cylinder
manufacturer. Also, if the handwheel is specified,
order its replacement parts from the cylinder manufacturer.
When corresponding with the cylinder manufacturer,
include the cylinder serial number, model number, and all

other pertinent nameplate information.
12 Pipe Plug, steel
13 Cap Screw, plated steel
14 Cap Screw, plated steel
15 Bushing
16 Nameplate, SST
17 DriveScrew, SST
18 Gear Case, cast iron
19 WormGear, bronze
20 Bearing
21 Bearing Retainer, steel
22 StemConnector, 410 SST
23 HexNut, platedsteel

Key Description

24 Handwheel Indicator, SST
25 Chain,SST
26 Drive Screw, plated steel
27 Set Screw, steel
28 Key, steel
29 Front Worm Retainer, steel
30 Back Worm Retainer, steel
31 Worm Shaft, steel
32 Handwheel, cast iron
33 Handgrip,steel
34 Handgripbolt, steel
35 Handwheel Cap, cast iron
36 Set Screw, steel
37 ZerkFitting
38 Ball, alloy steel
39 Spring, phosphor bronze
40 Ball Bearing
41 Hex Nut, plated steel
42 Pointer, SST
43 Conduit Clamp
44 Cap Screw, plated steel
45 MachineScrew, plated steel
46 MachineScrew, plated steel
47 Tubing,copper (specifylength)
49 Connector, brass
50 Elbow,brass
51 Positioner
52 MachineScrew, SST
53 Lock Washer, SST
54 Needle Valve
55 Pipe Nipple, steel
56 Pipe Tee, steel

10

Instruction Manual

D103793X012

Figure 2. Fisher 585CLS Actuator

B

B

585CLS Actuator

October 2013

VIEW B-B

AA

BACK VIEW

LP

SECTION A-A

LP-LUBRIPLATE NO. 130AA
PACK PARTS 20 AND 40 WITH MULTIPURPOSE GREASE

52A7782-A

LP

LP

11

585CLS Actuator

October 2013

Figure 3. Fisher 585CLS Actuator

Instruction Manual

D103793X012

52A7783-A

Neither Emerson, Emerson Process Management, nor any of their affiliated entities assumes responsibility for the selection, use or maintenance
of any product. Responsibility for properselection, use, and maintenance of any product remainssolely with the purchaser and end user.

Fisher, FIELDVUE, and TopWorx are marks owned by one of the companies in the Emerson Process Management business unit of Emerson Electric Co.
Emerson Process Management, Emerson, and the Emerson logo are trademarks and service marks of Emerson Electric Co. All other marks are the property
of their respective owners.

The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they arenot
to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are
governed by our terms and conditions,which are available upon request. We reserve the right to modify or improve the designs or specifications of such
products at any time without notice.

Emerson Process Management
Marshalltown, Iowa 50158 USA
Sorocaba, 18087 Brazil
Chatham, Kent ME4 4QZ UK
Dubai, United Arab Emirates
Singapore 128461 Singapore

www.Fisher.com

12

E 2013 Fisher Controls International LLC. Allrights reserved.
