CM6200 Starter System
Installation Manual
Firstech, LLC. 21911 68th Ave S. Kent, WA 98032
Phone. 888-820-3690 Fax. 206-957-3330
Please visit www.firstechonline.com for additional installation resources
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Table of Contents |
CM6200 |
|
|
|
|
Introduction |
4 |
|
Kit Contents |
4 |
|
Installation Basics |
5 |
|
Remote Programming Routine |
6 |
|
Placement and Use of Components |
7 |
|
Common Procedures |
8 |
|
Wiring Descriptions |
12 |
|
Option Programming Tables |
18 |
|
Option Menu Descriptions |
21 |
|
Special Option Groups 1 & 2 |
27 |
|
Option Programming |
28 |
|
Troubleshooting |
30 |
|
Frequently Asked Questions |
30 |
|
Technical Support Contacts |
33 |
|
Copyright 2009 Firstech, LLC. |
Page 2 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Copyright 2009 Firstech, LLC. |
Page 3 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Introduction |
CM6200 |
|
|
|
|
Thank you for purchasing this Firstech system for your vehicle. The following installation manual is intended for experienced and authorized Firstech technicians. We highly recommend that you contact your local Firstech dealer and seek professional installation. Call 888-820-3690 or visit our websites at www.compustar.com or www.firstechllc.com to locate your nearest dealer. If you need additional or replacement remotes and / or online support please visit www.firstechonline.com.
Caution: The Manufacturer’s warranty will be void if this product is installed by anyone other than an authorized Firstech dealer. Firstech provides installation support services to authorized dealers only.
This manual may change frequently. Please check www.firstechonline.com for updates.
Kit Contents |
CM6200 |
|
|
|
|
All Firstech FT-6200S CONT controllers include the following:
-CM6200 main control module
-Wiring diagram sheet
-Main ignition wiring harness with two external relays
-Wiring harnesses
-Hood pin
RF Kits with remote(s), Antenna, and Antenna Cable are not included with the FT-6200S CONT.
The following sensors are available but not included with every system:
-Firstech secure valet switch (FT-VALET GREY)
-Thermister temperature sensor (FT-TEMP SENSOR) (2 Way remote LCD systems only)
The remote(s) and antenna are modular and are not specific to the control modules. You have the ability to pair almost any Firstech remote(s) and antenna receiver to the CM6200. This includes all 4 and 6 pin antennas.
Any questions on contents please contact your distributor or us directly at 1.888.820.3690, Monday through
Friday, 8 AM to 5 PM Pacific Time.
Copyright 2009 Firstech, LLC. |
Page 4 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Installation Basics |
CM6200 |
|
|
|
|
If you are new to installing Firstech Series Remote Starts and / or Alarms, we highly recommended that you thoroughly review this manual to installing your first unit.
Key Points to Consider Before Installation:
You must code remotes to this system before anything will function. Program remotes by cycling the ignition
ON / OFF five times within 7 seconds and tap button 1 (0.5 second) on the first remote, and then tap button 1
(0.5 second) on the second remote.
Secure Valet:
This optional switch breaks the internal ignition connection to prevent the system from being put into valet when cycling the ignition ON / OFF five times.
Internal green loop must be cut for AUTOMATIC transmission vehicles.
By default, the units come in MANUAL transmission mode. You will need to cut the green loop inside the control module if you are installing the unit in a AUTOMATIC transmission.
Tach learning procedure:
Learn tach by: (1.) Starting the vehicle with the key, (2.) Press and hold the foot brake, then (3.) Hold the remote start button on the remote for 2.5 seconds - one chirp and parking light flash indicates that the vehicle tach signal has been successfully learned. Two chirps and two parking light flashes indicate that the control module failed to see a proper tachometer signal. (These units have the option for Tachless and 1.5 second assume cranking).
New Option Menus:
It is important to familiarize yourself with all the options as it will save time in most applications. For instance,
Option 1-04 controls the double pulse unlock feature on all CM6 series control modules.
Programmable Output Connectors (POC) Must have Option Programmer OP500
All control modules come with 9 programmable outputs that can be configured 19 different ways. It is important to familiarize yourself with the POCs as it will save time in most applications.
Internet updatable processors Visit www.firstechonline.com
All CM6 series units are equipped with some of the most powerful processors available today. This flexibility allows for on-demand internet updating capabilities in the event of a version update or change.
Copyright 2009 Firstech, LLC. |
Page 5 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Remote Programming Routine |
CM6200 |
|
|
|
|
IMPORTANT: Any and all remotes must be coded to the control module prior to performing any and all operations.
Remotes excluding 2WSSR-Pro
STEP 1: Activate programming mode by manually turning the vehicle’s key between the Ign On and Off (or the Acc & On positions) five times within 7 seconds. The vehicle’s parking lights will flash once with the successful completion of this step. (Note: this step also places the control module into Valet Mode)
STEP 2: Within a 2 second period after the 5th ignition cycle tap Button I on two way remotes or the Lock button on one-way remotes for 0.5 seconds. The parking lights will flash once to confirm the transmitter has been coded. Repeat for additional remotes, up to three.
Exiting Programming: Programming is a timed sequence. After 2 seconds the parking lights will flash twice signaling the end of programming mode.
Programming Multiple Remotes: After the confirmation flash given in STEP 2, code additional remotes by tapping Button I on two way remotes or the Lock button on one way remotes. The parking lights will flash once confirming each additional remote. All systems (except the PWSSR-Pro), can recognize up to three remotes.
Note: If you do not program any remotes and enter this sequence it will put the system into Valet Mode. Only the keyless entry will work in Valet Mode. To exit Valet Mode just program remote(s).
2WSSR-Pro
STEP 1: Remove the AA battery from the remote.
STEP 2: Activate programming mode by manually turning the vehicle’s key between the Ign On and Off (or the Acc & On positions) five times within 7 seconds. The vehicle’s parking lights will flash once with the successful completion of this step. (Note: this step also places the control module into Valet Mode)
STEP 3: Within a 2 second period after the 5th ignition cycle, insert the AA battery into the remote. The parking lights will flash once to confirm this step. If you have an additional 1 Way remote tap the Lock button after inserting the AA battery into the 2 Way remote.
STEP 4: Wait several seconds for the parking lights to flash twice and the remote LCD to receive a page back.
The transmitter has now been coded.
Programming Multiple Remotes: After the confirmation flash in step 3, program the optional 1 Way remote by tapping the Lock button for 0.5 seconds. The parking lights will flash once confirming that the 1 Way this remote has been learned. The 2WSSR-Pro can recognize (1) 2 Way remote and (1) 1 Way remote.
Copyright 2009 Firstech, LLC. |
Page 6 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Placement and Use of Components |
CM6200 |
|
|
|
|
IMPORTANT: The placement and use of components are critical to the performance of this system. Antenna and Cable
Firstech antennas are calibrated for horizontal installation at the top of the windshield. The cable that connects the antenna to the control module must be free from any pinches or kinks. Installing the antenna in areas other than the windshield may adversely affect the effective transmitting distance of the remotes.
Secure Valet Switch
The optional Secure Valet Switch prevents the alarm from being put into valet mode through cycling the ignition on/off five times. The Secure Valet Switch is more secure than traditional toggle / valet switches because it requires a two digit code. To program this feature you must perform the following procedures:
STEP 1: Turn on Option 3-10-III.
STEP 2: Turn ignition key to the “on” position.
STEP 3: Hold down the valet switch for 1.5 seconds. The LED on the valet switch will begin to flash rapidly with successful completion of this step.
STEP 4: Enter the first digit of the desired two-digit pass code by depressing the switch the number of times that coordinates with the desired first number. For example, to enter 3, depress the switch 3 times, then wait.
STEP 5: The LED will confirm the first number by flashing BLUE slowly. Once the LED begins to flash rapidly, enter your second number by repeating step 4.
STEP 6: Turn the ignition off - the Secure Valet Switch is now programmed. Follow steps 3 – 5 to enter your Secure Valet code.
**The first two digits of the RPS unlock/disarm pass code will be the default pass code for the Secure Valet
(you do not need to program them independently).
Thermister (Temperature Sensor)
Every 2 Way LCD Firstech RF kit includes an optional thermister, which must be plugged into the 2 pin port of the control module for use. This plug is blue on the CM6000. The use of the thermister allows the 2 Way remote to display the vehicle’s interior temperature on the remote LCD (liquid crystal display) as well as permitting the vehicle to start with timed Hot or Cold starting; see options 2-05, 2-07 and 2-08. IMPORTANT: New thermister plugs are blue 2 pin connectors on the CM6 series but old white plug thermistors will still work.
Hood Pin
The hood pin switch triggers the alarm in the event the hood is opened while the alarm is armed. The hood pin also doubles as an important safety feature that prevents the remote start from engaging while the hood is open.
Copyright 2009 Firstech, LLC. |
Page 7 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Common Procedures |
CM6200 |
|
|
Jumper Settings
Caution: Jumper settings affect the polarity and use of certain outputs. If these jumpers are used incorrectly, damage to the vehicle and /or control module may occur.
Jumper 1 (Door Trigger Polarity)
Determines the polarity of the door trigger input wire (red/white). In the default position the door trigger registers negative (-) triggers. To change to a positive (+) trigger, move the jumper.
Jumper 2 (Glow Plug or Key Sense Polarity)
Determines the polarity of the glow plug or key sense input wire (brown/white). In the default position it monitors a positive (+) glow plug input. To change to a negative (-) input move the jumper. To change from the glow plug to the key sense setting, you must change Option 4-09.
Jumper 3 (Parking Light to Trunk Output)
Determines the output type (not polarity) of the green/white wire on connector one (CN1). In the default position it provides a positive (+) parking light output. To change to a positive (+) trunk output move the jumper. A negative (-) parking light output is found on connector three (CN3) and a negative (-) trunk output is found on connector four (CN4).
Setting Auxiliary Outputs on Connector 2 - You Must Have the OP500 Option Programmer
To set auxiliary outputs on the control module you must change Programmable Output Connector wires (POCs). You must choose two odd pin wires on the black 18 pin connector that you are not using. For example we will use POC 8 and 9.
STEP 1: Plug in OP500 and use the Right or Left Arrow Button to scroll through the menu to POC 8 and POC 9 on LCD Line 1.
STEP 2: Use the Up or Down Arrow Button to change the lower number on LCD Line 2 to 10 – Auxiliary 1 or 11Auxiliary 2.
STEP 3: Scroll up the menu to Option 4-01 and 4-02 and set the options. Please see the Option Table for details.
STEP 4: The Pro control modules have a secure auxiliary option 4-05. This requires you to tap button 4 before you tap button 2 for
Aux 1 or button 3 for Aux 2. On 1-Way remotes you must hold the Trunk and Key/Start buttons for 2.5 seconds then tap the Trunk button for Aux 1 or the Key/Start button for Aux 2.
STEP 5: If you need to change the time settings of the outputs go to AU1 or AU2 on the OP500. LCD Line 2 is the timed output.
STEP 6: Hold the “W” Write button for 3 seconds to set all the options.
Tach Sensing
The default engine sensing mode is tach. In cold weather climates we recommend using an injector wire verses a coil wire for tachometer sense. There are new features that adjust tach reading methods on option 2-01. IMPORTANT: The remotes must be coded prior to setting up tach sensing. Firstech recommends using a digital multimeter to test for tach.
Copyright 2009 Firstech, LLC. |
Page 8 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
STEP 1: Start the vehicle with the key. Allow time for the engine to idle down.
STEP 2: Test wire and make connection. At idle the tach wire should test between 1 to 4 Volts AC. As the vehicle RPM’s increase the voltage on the meter will also increase. Always solder tach connections.
STEP 3: Learn tach. While the vehicle is at idle, hold the foot brake and press and hold the remote start button on the remote control for 2.5 seconds.
The parking lights will flash once and the siren |
Number of |
|
|
Parking Light |
Tach Error |
||
will chirp once to confirm a good tach signal. The |
|||
parking lights will flash two times and the siren |
Flashes |
|
|
1 |
Option 2-10 is not in default setting 1 |
||
will chirp two times to indicate the tach did not |
|||
learn. Two seconds following the two flashes, the |
2 |
Key is in the off position |
|
number of parking light flashes will indicate the |
3 |
Bad tach signal. Find a different wire. |
|
cause of the error: |
|
|
Alternator Sensing
Alternator sensing is an alternative method the remote start can utilize to determine if the engine is running.
This is different than the no tach sensing mode so a connection must be made. IMPORTANT: The remotes must be coded prior to setting up alternator sensing.
STEP 1: Change Option 2-10 to setting 2 - Alternator sensing.
STEP 2: Test wire and make connection. The stator wire is found at the vehicle’s alternator. Change your multimeter to DC voltage before testing for this wire.
A.At rest, with the ignition off, the stator wire should test 0V DC.
B.Turn the ignition to the run position. The stator wire should now test between 4 – 6V DC.
C.Start the vehicle with the key. The stator wire should now test between 12 – 14V DC at idle.
STEP 3: Process complete – no further programming is required.
No Tach Sensing – (Automatic Transmission Vehicles Only)
No tach sensing is an alternative engine sensing mode. No tach sensing does not require a connection to the vehicle other than the main ignition harness.
STEP 1: Change Option 2-10 to setting 3 – No tach sensing.
STEP 2: Process complete – there is no further programming required other than adjusting crank time when necessary (see below).
Adjusting Crank Time: To adjust minimum crank times, refer to Option 2-12. To help ensure successful starting, the system will automatically add additional crank time to the 2nd and 3rd start attempts. In addition, there is a built in “Smart Resting Mode”. Traditional tach sensing is still highly recommended for colder climates.
Copyright 2009 Firstech, LLC. |
Page 9 |
|
|
CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Timed Crank Setting – Automatic Transmission Only
Option 2-10 setting 4 provides a timed 1.5 second crank for the remote start sequence. This option just cranks the vehicle for 1.5 seconds and assumes remote start has completed. This option can be used for GM and other vehicles with built in anti-grind systems.
Green/White Loop
This loop wire determines the transmission setting. The default position (uncut loop) is for manual transmissions. When the loop is cut, the system will be ready for automatic transmissions. In the default (manual transmission) mode, the system must be set up in Reservation mode prior to the vehicle being able to remote start.
IMPORTANT: All warranties or claims are void if a controller with a cut loop is installed on a vehicle with a manual transmission.
Reservation Mode for Manual Transmissions
To remote start a manual transmission vehicle, the system must first be set up in reservation mode. Reservation mode is designed to prevent the vehicle from remote starting while the transmission is in gear.
Installation Requirements
1.The vehicle’s door triggers must be connected to the control module. Prior to making final connections, test the factory door triggers to ensure that they are functioning properly.
2.The vehicle’s emergency/parking brake wire must be connected to the control module. The proper vehicle wire usually provides a negative (-) trigger while the emergency / parking brake is set.
3.The vehicle’s clutch must be momentarily bypassed while the remote start cranks the engine. This momentary bypass simulates the clutch being depressed. For complete details on how to wire a momentary clutch bypass consult your CompuTech program or contact our technical support department by calling 888-820-3690.
IMPORTANT: Do not install a remote start in manual transmission vehicles with convertible / removable tops and in user’s vehicles that leave their windows down. Firstech nor their authorized dealers will assume responsibility for improper use or install.
Activating Reservation Mode
STEP 1: Start the vehicle with the key. Place the transmission in neutral, remove pressure from the pedal brake, and set the emergency/parking brake.
STEP 2: Remove the key from the vehicle’s ignition. The vehicles engine should remain running even after the key has been removed. If the vehicle does not remain running, check the emergency / parking brake connection.
STEP 3: Exit the vehicle and close the door. The vehicle’s engine should shut off upon closing the door. If the vehicle’s engine does not shut off, check the door trigger connection or wait for the factory dome-light to go out. The Firstech system is in reservation mode and the vehicle is ready to safely remote start.
Copyright 2009 Firstech, LLC. |
Page 10 |
|
|
