By Firstech, LLC.
www.compustar.com
USER’S GUIDE
One-Way AM Remote
R1600
Page 3
TABLE OF CONTENTS
Safety Information
Remote Button Functions
Remote Learn Routine
Reservation Mode
Valet Mode
Limited Lifetime Consumer Warranty
Page 4
Page 5
Page 5
Page 6
Page 7
Page 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Information
Please take these safety precautions into consideration under the following conditions :
Under normal circumstances, Reservation Mode is cancelled
when a door or hatchback opens. Please verify that the opening
of any door or hatchback cancels Reservation Mode. If any of the doors or hatchback
are not monitored by the Compustar because of improper installation or a faulty dome
light switch, do not use the the Compustar and take your vehicle immediately to the
dealer for repair. Do not set Reservation Mode if the window(s) are open or if there is
anyone inside the vehicle, this includes animals. Remote start installation in a manual
transmission vehicle with a convertible top is not recommended.
Page 4
Important!
1. Servicing the vehicle
When servicing your automobile (i.e. changing the oil, washing your car), the
Compustar system should be in Valet Mode. There is a safety shutdown switch under
the hood that deactivates the remote starter function if the hood is open.
However, if the switch has been damaged or the switch has been installed improperly,
the vehicle may start when the button is pressed for 2 seconds, even if the hood
is open.
2. Loaning your vehicle to others
Whenever you loan your vehicle to an individual who is not familiar with Compustar,
you may want to put the vehicle in Valet mode. This will prevent the borrower from
accidentally activating the Compustar auto-security system.
3. For manual transmission vehicles
If the Compustar is installed in a manual transmission vehicle, extra precautions are
required because the Compustar does not monitor the gear shifter :
Page 5
Remote Button Functions
1
2
3
5
6
7
8
9
10
11
12
13
14
Button Press Function
0.5 sec Horn - on/off
0.5 sec
Valet Mode - on/off
0.5 sec
Passive Locking - on/off
0.5 sec
0.5 sec
Timer Start Mode - on/off
Turbo Mode - on/off
2 sec
Programming Menu 1- Installer Only
2 sec
Programming Menu 2- Installer Only
Note :
" " Means, to press the button for 2 seconds.
"
()
" Means, to simultaneously press the buttons.
"
( )
" Means to simultaneously press the buttons for 2 seconds.
4
Lock
. If held for 3.5 seconds, it will panic the system.
0.5 sec
0.5 sec
0.5 sec
0.5 sec
Unlock
2 sec
Auto -start Function - on/off
Auxiliary Option 2
Auxiliary Option 1
2 sec
Trunk Release
3.5 sec
Panic, Press to shut off.
Remote Learn Routine
The Compustar system will allow up to three remotes to be programmed to one
vehicle. Please perform the following procedure to add or reprogram additional
remotes.
Page 6
Step2 :
Within a 7 second period after cycling the ignition for the 5
th
time,
Press the button for a 1/2 sec. The car parking lights will flash
once to confirm that the transmitter has been programmed.
You can continue programming the additional remotes. The parking
lights will flash two times when the programming mode has expired.
In order to auto-start your manual transmission vehicle, you must first set the CompuStar
system to Reservation Mode before leaving your vehicle. The purpose of Reservation
Mode is to leave the transmission gear in the neutral position when you leave your
vehicle. Reservation mode is intended for use on MANUAL TRANSMISSIONS ONLY
and NOT FOR AUTOMATIC TRANSMISSIONS. Reservation Mode must be engaged
each and every time you leave your manual transmission vehicle in order to auto-start it.
Note :
The system is not recommended for manual transmission vehicles with
removable or convertible tops.
Important Requirements to activate Reservation Mode
The transmission must be in the NEUTRAL position.
The vehicle windows must be rolled up.
Do not set the reservation mode with people in the vehicle.
Do not auto-start the vehicle with people inside it.
Activating Reservation Mode( MANUAL TRANSMISSION ONLY
)
Step1 :
After arriving at your destination, and BEFORE TURNING YOUR
ENGINE OFF, place the transmission in the Neutral position.
Step2 :
Activate the parking brake.
Step3 :
Remove your foot from the foot brake.
Step4 :
Remove the key from the ignition, and the engine will remain running.
Reservation Mode
(manual transmission only)
Page 7
1
2
3
4
5
6
7
Error Number
(# of times the car chirps & parking lights flash)
Error Reason
Engine On
Key On
Door Open
Trunk Open
Brake On
Hood Open
Reservation Off (Manual Transmission Only)
Diagnosing problems with Auto-Start
If there is a problem in auto-starting your vehicle,the the CompuStar system will
do one of two things; if it fails for any of the reasons listed in the table below, it will
flash the parkinglights three times then flash the error number. Otherwise, it will
attempt to start the vehicle three times. If, after three times, the vehicle will not
start or stay running, the the CompuStar system will shut down. In either case,
please see your istaller to resolve the situation.
Step5 :
Exit the vehicle and close the door within two minutes after activating
the parking brake. The engine will shut off and reservation mode for
the remote starter is now complete.
Valet Mode
While the vehicle is in valet mode, the only features that will function will be the keyless
entry and optional auxiliary functions.
In order to enter Valet mode, press the buttons simultaneously for a 1/2
second. In order to manually enter Valet Mode, insert your key into the ignition and turn
the ignition on and off
(between ACC and ON)
five times within 7 seconds
You can exit Valet Mode only by pressing buttons
simultaneously for 1/2 second..
Step1:
Activate Valet/ Programming mode by manually
turning the ignition on and off five times
(between Acc and
On)
with car key within a 7 second period.
The parking lights will flash once with successful completion of
this step.
