EN280 Manual
®
Package Includes:
Bluetooth Stereo Speaker - EN280 x 1
MicroUSB Cable x 1
AUX Cable x 1
User Manual x 1
Page 2
Important:
Features & Functions:
Keep the speaker away from flinty environment:
damp, dusty, reeky and so on.
Keep the speaker away from water and other
liquid. If it occurs, please use a soft cloth to dry it.
Don’t use water or chemical liquid to clean it, please
use a soft cloth to clean the surface of the speakers.
Keep this product away from high temperature,
baking or drying is not allowed
Be sure the voltage for power ≤ 5V
Keep this product away from hit of large external
force.
Keep the speaker away from strong magnetic.
Don’t open and repair the speaker by yourself.
Bluetooth
Bluetooth transmission up to 10 metres range
2.0 Channel design with stereo sound
High quality sound with powerful bass
Mondrian style classic design
Bulit-in microphone for incoming calls
Press “Pause/Play” to answer or hang up the phone
Built-in battery: 1200mAh
Able to play music continuously up to 8 hours
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
1
Page 3
Product Structure
ON
OFF
AUX Line in
microUSB Port
Power ON / OFF
2
1
3
Volume - / Previous Song
Play / Pause / Answer Phone
Volume + / Next Song
5
4
6
2
Page 4
Bluetooth Mode
Function Key:
Press one time, next song /
Long press, increase volume
Press one time, preview song /
Long press, decrease volume
Pause / Play
Normal Bluetooth Connecting
1.
2.
3.
Turn on the Bluetooth speaker
Use your music device to search the Bluetooth
Speaker Bluetooth - Speaker Name: “FC-EN280”
Pair the speaker with your music device
Once the Bluetooth speaker is successfully connected,
you can play music and control your music devices
through the function keys on the speaker.
Bluetooth answer phone calls
Decrease the volume
Touch for answering the call /
Touch for ending the call
Increase the volume
During playing music with your mobile phone, when a call
comes, speaker will stop playing music.
When talking ends, the speaker will be back to the former
working task
33
Page 5
AUX Mode
Charging
No matter power is on or off, you can charge the
speaker by
1. Connecting with PC via USB cable provided
2. Using the wall adaptor DC 5V / 500mAh
Red light turns on: Charging
Red light turns off: Fully charged
Charging the speaker
Power on the speaker and plug in the AUX line in
cable, the speaker will automatically switch to AUX
mode.
After the AUX cable is unplugged, the speaker will turn
to Bluetooth mode.
In AUX mode, function key is invalid.
Switch to AUX mode
LED indicator:
ON
OFF
14
Page 6
Specifications
Categories Items
Description
Bluetooth
Audio
Standard
Profile
Speaker Unit
Rated Power
Response Frequency
S/N
RATED IMP
Frequency
Connection
Range
THD
Bluetooth 4.0
HSP/HFP, A2DP, AVRCP
40mm
3W + 3W
120Hz~18KHz
≥96 dB
4 Ω
2.4-2.48 GHz
By hand
Up to 10m
≤1% (1Khz/1W)
Type
Battery Capacity
Charging Voltage
AUX input
DC-IN Input
Gift box Size
Speaker Size
Speaker Weight
Power
Input
Dimensions
Li-Ion battery
1200mAh
DC 5V
3.5mm AUX
microUSB
173 x 78 x 101 mm
156 x 54 x 61 mm
355 grams
15
Page 7
First Champion Technology Limited
First Champion and the First Champion logo are
trademarks of First Champion Technology Limited,
registered in Hong Kong and other countries. The
Bluetooth word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by First Champion Technology Limited is
under license. All other brand names or trade names
mentioned above are for identification purposes only
and may be trademarks of their respective owner(s).
©2014 First Champion Technology Limited. All rights
reserved.
Unit 1810, 18/F, Nan Fung Commercial
Centre,No.19 Lam Lok Street, Kowloon
Bay, Hong Kong.
Tel: (852) 3118 4962
Email: [email protected]
www.firstchampion.hk
Page 8
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provi de rea sonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, whi ch can be determin ed by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by First
Champion T echnology Limited
may void the FCC authorization to operate this device.
Note: The manufacturer is not responsible for any radio or tv interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
