FIRE MAGIC® BRINGS OUT
THE BEST IN YOUR GRILLING
Family owned and crafted in America, Fire Magic® is the name trusted by true grilling enthusiasts
for over 80 years. With an extensive product line, versatile cooking options, enhanced durability
and superior design innovations, Fire Magic® is the nest performing grill on the market and a
shining centerpiece for a lifetime of special moments shared with family and friends.
2
BEAUTIFULLY DESIGNED.
BULLET PROOF TOUGH.
BUILT WITH PASSION.
OWNED WITH PRIDE.
Fire Magic® grills are made by people who demand the
best, for people who demand the best. Every Fire Magic®
grill is manufactured in our U.S. production facility and
held to the strictest quality standards and the highest
performance metrics. Using state-of-the-art technology,
guided by the watchful eye and careful hand of master
craftsmen, and backed by the industry’s best warranty, our
grills are an investment to be enjoyed for years to come.
Constructed entirely of the nest quality, heavy-gauge
304 stainless steel with unsurpassed attention to the
most precise detail in design and construction, Fire
Magic® grills are the most elegant and durable barbecue
grills available. They are engineered to perform at the
highest temperature for the longest time of any outdoor
barbecue grill. Our exclusive advanced heat distribution
system, searing options, smoking capability, rotisserie,
and charcoal grilling features allow you to grill any meal
imaginable with ease and exceptional results. Fire Magic
will keep you grilling and the neighbors talking for years
to come.
Diamond Sear
large cooking surface
Diamond Sear Cooking Grids *
• Diamond Sear cooking grids promote more optimal heat
transfer to food. With more surface area, similar to a
griddle, their shape with angled sides improves the flow
of heat to the cooking surface.
Advanced Heat
Distribution System
• Diamond Sear cooking grids are easier to cook on as
foods release from the surface more easily with less
sticking.
• Diamond Sear cooking grids have more contact surface
than round grids. This provides more points of contact
that help to sear your meat better and faster.
• More eicient heat transfer and quicker cooking result in
less use of gas.
*
U.S. Patent No.: D857,453 & D862,984
Flavor Grids
• Heavy gauge stainless steel flavor grids
minimize flare ups, provide quick and even heat
distribution, and flavor food by vaporizing juices.
• Designed to provide distributed heat to the
cooking grids; they don’t retain or block heat
from rising.
• Easy to clean and maintain.
• Simple to remove when rotisserie cooking (for
largest rotisserie area).
Largest Cooking Area
Fire Magic® grills provide more cooking area than other
grills and more BTU’s per square inch of cooking surface.
Cast Stainless Steel “E” Burners
• 1/4" thick cast stainless steel burners weighing up to
12 lbs. each.
• Precision porting – cast to be evenly spaced on each
burner.
• An internal baling system and carry over slots
designed for ease of lighting, and balancing flame
and heat; to provide well distributed heat, on high or
low in each burner.
Echelon Diamond Series
When only the best will do, our top of the line Fire Magic® Echelon Diamond combines
the ultimate in performance, beauty, and innovation. With sleek lines, a unique contoured
face, state-of-the-art features such as hot surface ignition, blue back-lit knobs, and an
optional Magic View Window, Echelon Diamond denes luxury in grilling.
6
FEATURE HIGHLIGHTS
Seamless, 90° hood w/ Spring Assist
High Eiciency, Quantum Backburner
with Rotisserie Kit
Diamond Sear Cooking Grids
Angled Interior Halogen Lights
Dual Position Warming Rack
Hot Surface Ignition
Zone Flavor Grids
Cast Stainless Steel BurnersCharcoal / Smoker Basket Large Drip Tray w/ Aluminum Liner Meat Probe with Storage BoxDigital Thermometer
Contoured Face w/ Back-Lit Knobs
7
Echelon Diamond Series | Feature Highlights
Diamond Sear
Cooking Grills *
All 304 stainless steel cooking
grids provide more optimal cooking
surface for even heat and great
searing.
*
U.S. Patent No.: D857,453 & D862,984
Zone Flavor Grids
16-gauge stainless steel flavor
grids are engineered for durability,
even heat distribution, and reduced
flare-ups.
Cast Stainless Steel
Burners
1/4” thick cast stainless steel “E”
burners for consistent, even heat
and a lifetime of durability.
Digital Thermometer
Illuminated chromed digital
thermometer with meat probe,
timer, and alarm settings for
precise grilling.
Echelon grills are also available
with Analog Thermometer on the
hood (measures up to 1000°).
Angled Interior
Halogen Lights
12 Volt angled halogen lights make
evening grilling a breeze.
8
Hot Surface Ignition
Hot surface electronic ignition
provides reliable lighting for every
meal. Requires 120 Volt AC power
supply.
Echelon Diamond Series | Feature Highlights
Contoured Face
w/ Back-lit Knobs
Smooth, seamless lines with
polished highlights that feature
back-lit knobs (at 41°) with comfort
touch grips and flame icons for
convenience.
Adjustable, Dual
Position Warming Rack
Dual position stainless steel
warming rack for easier use and
storage.
Charcoal / Smoker
Basket
Included with all Echelon Diamond
Grills. Great tool for charcoal
grilling and smoking.
Quantum Backburner
w/ Rotisserie Kit
Recessed Quantum Backburner made
of stainless steel foam; it uses less
BTU’s to generate even, eicient high
heat for rotisserie cooking. Includes
complete rotisserie kit with super
heavy duty motor, stainless steel spit
rod, counter-balance, meat prongs,
and polished stainless steel cover.
Large Drip Tray
Large capacity drip tray with ball
bearing glides for smooth open
and close.
Meat Probe With
Storage Box
Meat probe included with all
Echelon digital grills and features a
braided stainless steel sleeve and
decorative wood box.
9
Echelon Diamond Series | E1060i Built-In Grill
Echelon E1060i, 48” Built-In Grill
E1060i-8E1N*-W (optional Magic View Window shown)
KEY FEATURES
• Heavy duty, patented Diamond Sear cooking grids
• Cast stainless steel “E” burners
• Heavy gauge stainless steel dual position, adjustable warming rack
• Heavy gauge all stainless steel Zone Flavor Grids
• Push-to-Light Hot Surface Electric Ignition system w/ flash tubes
• Angled halogen 12 Volt internal oven lamps
• Contoured control panel w/ bright polished trim & polished, back-lit knobs
• Digital chrome meat & grill thermometer in control panel or angled analog
thermometer in lid measuring up to 1000º F
• Seamless double wall 90º hood with feather-lite easy Lift Lid
• Recessed high eiciency stainless steel foam rotisserie Quantum Backburner
*All models available in natural gas or propane (for propane, change N to P in the model number).
10
KEY FEATURES (continued)
• Charcoal/Smoker Basket included with all Echelon grills
• Optional infrared sear burner
• Optional Magic View Window in lid
• Custom personalized name plate
SPECIFICATIONS
• Primary cooking surface: 48” x 22” (1,056 sq. in.)
• Warming rack surface: 48” x 8” (344 sq. in.)
• Main burners: 112,000 BTU’s
• Backburners: 22,000 BTU’s (11,000 x 2)
• Cut-out dimensions: 50”w x 23½”d x 11½”h
Optional Magic View
Window
Optional
Infrared Burner
on the left side
E1060i-8E1N
w/ Digital Thermometer
E1060i-8E1N-W
w/ Digital Thermometer & Magic View Window
E1060i-8EAN
w/ Analog Thermometer
E1060i-8EAN-W
w/ Analog Thermometer & Magic View Window
Echelon Diamond Series | E1060s Portable Grills
Echelon E1060s, 48” Portable Grill
E1060s-8E1N*-62-W (optional Magic View Window shown)
In addition to the features listed on page 10,
• Primary cooking surface: 48” x 22” (1,056 sq. in.)
• Warming rack surface: 48” x 8” (344 sq. in.)
• Main burners: 112,000 BTU’s
• Backburners: 22,000 BTU’s (11,000 x 2)
• Single Side Burner: 15,000 BTU’s
Single Side Burner
Flush mounted on left side shelf with 15,000 BTU’s
burner and stainless steel grate.
Echelon E1060s, 48” Portable Grill
E1060s-8E1N*-51-W (optional Magic View Window shown)
• Primary cooking surface: 48” x 22” (1,056 sq. in.)
• Warming rack surface: 48” x 8” (344 sq. in.)
• Main burners: 112,000 BTU’s
• Backburners: 22,000 BTU’s (11,000 x 2)
• Power Burner: 60,000 BTU’s
*All models available in natural gas or propane (for propane, change N to P in the model number).
Power Burner
60,000 BTU’s Power Burner with lid mounted on
the left side.
11
11
Echelon Diamond Series | E790i Built-In Grill
Optional Magic View
Window
E790i-8E1N
w/ Digital Thermometer
Echelon E790i, 36” Built-In Grill
E790i-8E1N*-W (optional Magic View Window shown)
KEY FEATURES
• Heavy duty, patented Diamond Sear cooking grids
• Cast stainless steel “E” burners
• Heavy gauge stainless steel dual position, adjustable warming rack
• Heavy gauge all stainless steel Zone Flavor Grids
• Push-to-Light Hot Surface Electric Ignition system w/ flash tubes
• Angled halogen 12 Volt internal oven lamps
• Contoured control panel w/ bright polished trim & polished, back-lit knobs
• Digital chrome meat & grill thermometer in control panel or angled analog
thermometer in lid measuring up to 1000º F
• Seamless double wall 90º hood with feather-lite easy Lift Lid
• Recessed high eiciency stainless steel foam rotisserie Quantum Backburner
*All models available in natural gas or propane (for propane, change N to P in the model number).
12
Optional Infrared Burner
on the left side
KEY FEATURES (continued)
• Charcoal/Smoker Basket included with all Echelon grills
• Optional infrared sear burner
• Optional Magic View Window in lid
• Custom personalized name plate
SPECIFICATIONS
• Primary cooking surface: 36” x 22” (792 sq. in.)
• Warming rack surface: 36” x 8” (288 sq. in.)
• Main burners: 90,000 BTU’s
• Backburner: 13,000 BTU’s
• Cut-out dimensions: 37”w x 23½”d x 11½”h
w/ Digital Thermometer & Magic View Window
E790i-8E1N-W
E790i-8EAN
w/ Analog Thermometer
E790i-8EAN-W
w/ Analog Thermometer & Magic View Window
Echelon Diamond Series | E790s Portable Grills
Echelon E790s, 36” Portable Grill
E790s-8EAN*-62-W (optional Magic View Window shown)
• Primary cooking surface: 36” x 22” (792 sq. in.)
• Warming rack surface: 36” x 8” (288 sq. in.)
• Main burners: 90,000 BTU’s
• Backburner: 13,000 BTU’s
• Side Burner: 15,000 BTU’s
Single Side Burner
Flush mounted on left side shelf with 15,000 BTU’s
burner and stainless steel grate.
Echelon E790s, 36” Portable Grill
E790s-8E1N*-71
• Primary cooking surface: 36” x 22” (792 sq. in.)
• Warming rack surface: 36” x 8” (288 sq. in.)
• Main burners: 90,000 BTU’s
• Backburner 13,000 BTU’s
• Double Side Burner: 30,000 BTU’s (15,000 x 2)
*All models available in natural gas or propane (for propane, change N to P in the model number).
Double Side Burner
The Double side burner oers precise flame
control on each burner to prepare side dishes
and sauces for your meal (Two [2] 15,000 BTU’s
burners). Includes stainless steel grids as well as
removable stainless steel cover.
13
13
Echelon Diamond Series | E660i Built-In Grill
E660i-8E1N
w/ Digital Thermometer
Optional Magic View
Window
Echelon E660i, 30” Built-In Grill
E660i-8E1N*-W (optional Magic View Window shown)
KEY FEATURES
• Heavy duty, patented Diamond Sear cooking grids
• Cast stainless steel “E” burners
• Heavy gauge stainless steel dual position, adjustable warming rack
• Heavy gauge all stainless steel Zone Flavor Grids
• Push-to-Light Hot Surface Electric Ignition system w/ flash tubes
• Angled halogen 12 Volt internal oven lamps
• Contoured control panel w/ bright polished trim & polished, back-lit knobs
• Digital chrome meat & grill thermometer in control panel or angled analog
thermometer in lid measuring up to 1000º F
• Seamless double wall 90º hood with feather-lite easy Lift Lid
• Recessed high eiciency stainless steel foam rotisserie Quantum Backburner
*All models available in natural gas or propane (for propane, change N to P in the model number).
14
Optional Infrared Burner
on the left side
KEY FEATURES (continued)
• Charcoal/Smoker Basket included with all Echelon grills
• Optional infrared sear burner
• Optional Magic View Window in lid
• Custom personalized name plate
SPECIFICATIONS
• Primary cooking surface: 30” x 22” (660 sq. in.)
• Warming rack surface: 30” x 8” (288 sq. in.)
• Main burners: 75,000 BTU’s
• Backburner: 11,000 BTU’s
• Cut-out dimensions: 31¼”w x 23½”d x 11½”h
w/ Digital Thermometer & Magic View Window
E660i-8E1N-W
E660i-8EAN
w/ Digital Thermometer
E660i-8EAN-W
w/ Digital Thermometer & Magic View Window
Echelon Diamond Series | E660s Portable Grill
Echelon E660s, 30” Portable Grill
E660s-8E1N*-62-W (optional Magic View Window shown)
• Primary cooking surface: 30” x 22” (660 sq. in.)
• Warming rack surface: 30” x 8” (288 sq. in.)
• Main burners: 75,000 BTU’s
• Backburner: 11,000 BTU’s
• Side Burner: 15,000 BTU’s
Single Side Burner
Flush mounted on left side shelf with 15,000 BTU’s
burner and stainless steel grate.
*All models available in natural gas or propane (for propane, change N to P in the model number).
15
15
16
Echelon Black Diamond Series
The Black Diamond Edition Grill combines all the same features as the top of the line
Echelon Diamond wrapped in a porcelain-coated nish with stainless steel accents. A
unique and stylish design, the Black Diamond Edition grill fuses performance, beauty
and innovation to deliver the very best in outdoor cooking.
Echelon Black Diamond Series | H790i Built-In Grill
Black Diamond H790i, 36” Built-In Grill
H790i-8E1N*-W (includes Magic View Window)
KEY FEATURES
• Heavy duty Diamond Sear cooking grids
• Cast stainless steel “E” burners
• Heavy gauge stainless steel dual position, adjustable warming rack
• Heavy gauge all stainless steel Zone Flavor Grids
• Push-to-light Hot Surface Electric Ignition system w/ flash tubes
• Angled halogen 12 Volt internal oven lamps
• Porcelain coated finish w/ satin stainless steel trim accents & satin, back-lit knobs
• Digital chrome meat & grill thermometer in control panel
• Seamless double wall 90º hood with feather-lite easy lift lid
• Recessed high eiciency stainless steel foam rotisserie Quantum Backburner
• Charcoal/Smoker Basket included
Optional Infrared Burner
on the left side
KEY FEATURES (continued)
• Optional Infrared Sear Burner
• Includes Magic View Window in lid
• Custom personalized name plate
SPECIFICATIONS
• Primary cooking surface: 36” x 22” (792 sq. in.)
• Warming rack surface: 36” x 8” (288 sq. in.)
• Main burners: 90,000 BTU’s
• Backburner: 13,000 BTU’s
• Cut-out dimensions: 37”w x 23½”d x 11½”h
Black Porcelain Coated Finish with
Satin Stainless Steel Accents
Magic View Window included
Satin Stainless Steel, Back-Lit Knobs
*All models available in natural gas or propane (for propane, change N to P in the model number).
17
17
Echelon Black Diamond Series | Matching Accessories
Black Diamond Power Burner
19-H5B1N*-0 (with stainless steel grids)
• Burner: 60,000 BTU’s
• Cut-out Dimensions: 19”w x 18¾”d x 11½”h
• Power Burner includes black protective lid.
• Available with porcelain cast iron or stainless steel grids.
Black Diamond Trash Cabinet
53820HTSC
Black Diamond Double Side Burner
32815H* (with stainless steel grids)
• Burners: 30,000 BTU’s (15,000 x 2)
• Cut-out Dimensions: 11½”w x 22¾”d x 11½”h
• Double Side Burner includes black protective lid.
Black Diamond Double Drawer
53802HSC
Black Diamond Refrigerator
3598H-DR (-DL)
• Cut-out Dimensions: 20”w x 21¼”d x 34⅛”h
• Features Black Diamond Edition accents.
• 4.0 cubic feet of space
• Interior light and security lock & key.
• When used outdoors, it must be installed in an enclosure.
Black Diamond Door w/ Tank Tray & Louvers
53820HSC-TL (-TR)
• Cut-out Dimensions: 21”h x 14½”w x 19¼”d
• Includes two 3.25 gallon trash bins (1 black, 1 blue).
• Features Soft-Close mechanism.
18
• Cut-out: 16”h x 14½”w x 20½"d
• Black Diamond Edition double drawer.
• Features Soft-Close mechanism.
• Cut-out: 21”h x 14½”w x 20½"d
• Features Soft-Close mechanism.
Loading...
