PREMIUM OUTDOOR GRILLS

RH PETERSON COMPANY | FIRE MAGIC PREMIUM OUTDOOR GRILLS COLLECTION CATALOG 2012

®

®

PREMIUM OUTDOOR GRILLS

W E L C O M E T O

®

From the moment you light a Fire Magic Premium Grill, you
know you’re on to something special. Under the gleaming
hood is a nely crafted, serious cooking machine designed
to ignite your outdoor cooking experience. ese all stainless
steel beauties boast ultra-durable cast stainless steel burners,
cooking grids of stainless steel and the highest BTUs to ensure
the most juicy, avorful grilled foods imaginable.

e most discerning grill enthusiasts nd that Fire Magic is
not just a grill, it’s a tradition – a tradition of inviting friends
and family to celebrate birthdays, holidays, anniversaries,
graduations and simple, casual get-togethers on a warm
summer day. Unwind on a lazy afternoon at the end of a
hectic week and enjoy a leisurely meal of grilled meats and
vegetables with guests. Savor the sunset with a thick steak
and a glass of cabernet or a juicy burger with grilled onions
and a refreshing soda.

Food has always been an integral part of our celebrations. At
Fire Magic we understand just how important good food is
and how the right preparation makes all the dierence. With
Fire Magic’s 5 Ways to Cook, you can grill, rotisserie cook,
infrared sear, smoke and even charcoal grill with no mess.

For this reason, we continue to concentrate on manufacturing
the best grill you can buy. Born a barbecue grill, the Fire Magic
line is engineered and manufactured right here in the USA.
Fire Magic Premium Grills and accessories have combined
remarkable craftsmanship and state-of-the-art technology to
set the industry standard for 75 years.

Ignite your outdoor cooking experience, invite friends and

family to celebrate, and let Fire Magic inspire you to create
new family traditions.

» Cast stainless steel “E” burners - guaranteed for life
» Most BTU’s & heat per sq. in. Heats fast-stays hot!
» Master Power Switch turns off electrical system

when not in use

» Recessed Quantum backburner for larger size

rotisserie cooking
» Built-in storage brackets for rotisserie spit rod
» Roller ball-bearings support rotisserie spit rod with

super-high-torque
motor & (2) 4 skewer meat holders with heavy

counter-balance
» 16-gauge stainless steel, avor grids are engineered

for durability and even heat distribution
» Heat zone separators isolate cooking zones so food
in each zone may be grilled at different temperatures
» Feather-Lite, easy-lift oven hood with spring assist
» Integral, and removable, oven warming rack for light

cooking or warming foods
» Customized stainless steel name plaque to

personalize your grill
» Built-in grill is eld convertible natural gas/propane
» Optional Magic View Window to check on food

without lifting hood
» Optional Infrared Burner
» Optional exclusive Motorized Hood
» Optional Remote Receiver (Model 3566) displays

temperature readings from up to 50 feet from the grill
» Meat Probe
» Easy to use Drip Collection System
» 12” Deep Fire Box

» FEATURE HIGHLIGHTS

ECHELON

diamond series

ECHELON

diamond series

ALL

STAINLESS

STEEL!

SAME

HEAT

LESS

GAS!

FIRE MAGIC INTRODUCES THE ALL NEW

QUANTUM BACK BURNER

BLUE BACKLIT KNOBS

MAGIC VIEW WINDOW HOT SURFACE IGNITION

HEAVY DUTY STAINLESS

STEEL COOKING GRIDS

CONTOURED FACE

MULTI-COLORED

BACKLIT THERMOMETER

WOODCHIP SMOKER DRAWERSLEEK LINES &

HALOGEN LIGHTS

EXCLUSIVE STAINLESS

STEEL “E” BURNERS

Models 790i-4E1N Shown

shown with 32814 Echelon Double Side Burner, 43830S Premium

Masonry Drawer, & DC790-CS-84C Pre-Fab Island

MODEL: E1060i-4E1N-W*

COOKING SURFACE 1056 sq. inches [48” x 22”]

BTU’s 115,000 Primary + (2) 11,000 Backburners

CUT-OUT 50” w x 231/2” d x 12” h

MODEL: E660i-4E1N*

COOKING SURFACE 660 sq. inches [30” x 22”]

BTU’s 78,000 Primary + 11,000 Backburner

CUT-OUT 311/4” w x 231/2” d x 12” h

MODEL: E790i-4E1N*

COOKING SURFACE 792 sq. inches [36” x 22”]

BTU’s 99,000 Primary + 13,000 Backburner

CUT-OUT 37” w x 231/2” d x 12” h

ECHELON

diamond series

ECHELON

diamond series

Built-In Grills

*All models available in natural gas or propane.

Model 1060s-4E1N-51-W Shown

MODEL: E1060s-4E1N-51-W*

COOKING SURFACE 1056 sq. inches [48” x 22”]

BTU’s

115,000 Primary + (2) 11,000 Backburners

+ 60,000 Power Burner

Model shown with Power Burner and optional Magic View Window. Same model

without the window is E1060s-4E1N-51

Also available with Double Side Burner or Single Side Burner options.

MODEL: E660s-4E1N-62*

COOKING SURFACE 660 sq. inches [30” x 22”]

BTU’s

78,000 Primary + 11,000 Backburner

+ 15,000 Single Side Burner

Model shown with a single side burner. Also available with a double side burner option.

MODEL: E790s-4E1N-71*

COOKING SURFACE 792 sq. inches [36” x 22”]

BTU’s

99,000 Primary + 13,000 Backburner

+ 30,000 Double Side Burner

Model shown with a double side burner. Also available with a single side burner option.

ECHELON

diamond series

ECHELON

diamond series

Stand-Alone Grills

*All models available in natural gas or propane.

AU R O R A

S E R I E S

AU R O R A

S E R I E S

» A grill of superior design and engineering--crafted

for cooking versatility, durability and longevity.

» 12 inches of rebox (top to bottom). Provides

most complete convection cooking

» Cast stainless steel “E” burners for consistent,

even heat distribution, guaranteed for life

(optional infrared burners are available)

» Electronic push-to-light spark ignition system

» Spring-assisted lid makes for feather-lite lifting.

» High BTU’s per sq. in.

» Sleek styling with seamless control panel

» Built-in digital thermometer with meat probe

» Optional recessed stainless steel rotisserie back

burner and heavy-duty rotisserie kit

» Built-in storage rack for rotisserie spit rod

» Built-in grill is convertible natural gas/propane --

No electricity needed

» Removable warming rack

» Easy to use Drip collection system

»

FEATURE HIGHLIGHTS

Model A790s-2E1N-62 Shown

MODEL: A540i-2E1N-62*

COOKING SURFACE 540 sq. inches [30” x 18”]

BTU’s 60,000 Primary + 19,000 B.B.

CUTOUT 32” w x 191/2” d x 12” h

MODEL: A660i-2E1N-62*

COOKING SURFACE 660 sq. inches [30” x 22”]

BTU’s 75,000 Primary + 19,000 B.B.

CUTOUT 32” w x 231/2” d x 12” h

MODEL: A530i-2E1N-62*

COOKING SURFACE 528 sq. inches [24” x 22”]

BTU’s 60,000 Primary + 16,000 B.B.

CUTOUT 251/2” w x 231/2” d x 12” h

MODEL: A430i-2E1N-62*

COOKING SURFACE 432 sq. inches [24” x 18”]

BTU’s 50,000 Primary + 16,000 B.B.

CUTOUT 251/2” w x 191/2” d x 12” h

MODEL: A790i-2E1N*

COOKING SURFACE 792 sq. inches [36” x 22”]

BTU’s 90,000 Primary + 23,000 B.B.

CUTOUT 373/4” w x 231/2” d x 12” h

AU R O R A

S E R I E S

AU R O R A

S E R I E S

MODEL: A830i-2E1N-CB*

COOKING SURFACE 828 sq. inches [24” x 18” + 22”x 18”]

BTU’s 50,000 Primary + 16,000 B.B. + 26,000 Charcoal Ignitor

CUTOUT 50” w x 191/2” d x 12” h

Built-In Grills

EXCLUSIVE TO FIRE MAGIC

®

FIRST EVER COMBINATION GAS

AND CHARCOAL GRILL!

*All models available in natural gas or propane. All models also available without backburner & rotisserie. Change the 6th digit to a “1”

Model A530s-2E1N-62 Shown

MODEL: A540s-2E1N-62*

COOKING SURFACE 540 sq. inches [30” x 18”]

BTU’s

60,000 Primary + 19,000 Backburner

+ 15,000 Single Side Burner

MODEL: A660s-2E1N-62*

COOKING SURFACE 660 sq. inches [30” x 22”]

BTU’s

75,000 Primary + 19,000 Backburner

+ 15,000 Single Side Burner

MODEL: A530s-2E1N-62*

COOKING SURFACE 528 sq. inches [24” x 22”]

BTU’s

60,000 Primary + 16,000 B.B.

+ 15,000 Single Side Burner

MODEL: A430s-2E1N-62*

COOKING SURFACE 432 sq. inches [24” x 18”]

BTU’s

50,000 Primary + 16,000 B.B.

+ 15,000 Single Side Burner

MODEL: A430s-2E1N-P6*

COOKING SURFACE 432 sq. inches [24” x 18”]

BTU’s

50,000 Primary + 16,000 B.B.

AU R O R A

S E R I E S

AU R O R A

S E R I E S

Stand-Alone Grills

*All models available in natural gas or propane. All models also available without backburner & rotisserie. Change the 6th digit to a “1”

MODEL: 5110-32

Optional stainless steel

LP tank shield

Legacy & Electric

c o l l e c t i o n

Model E250s-1Z1E-P6 Shown

P e r f e c t f o r b o a t s , c o n d o s , &

MODEL: 11-S1S1N-A

COOKING SURFACE 368 sq. inches [23” x 16”]

BTU’s 42,000

CUTOUT 321/4” w x 193/4” d 12” h

• HEAVY-DUTY STAINLESS STEEL CONSTRUCTION

• OPTIONAL INFRARED BURNER

AVAILABLE AS A CART, PATIO POST, OR IN-GROUND POST

MODEL: 34-S2S1N-A

COOKING SURFACE 540 sq. inches [30” x 18”]

BTU’s 64,000

CUTOUT 411/2” w x 201/2” d

MODEL: 3C-S1S1N-A (SHOWN)

COOKING SURFACE 368 sq. inches [23” x 16”]

BTU’s 42,000

CUTOUT 291/2” w x 161/2” d

MODEL: 31-S2S1N-A

COOKING SURFACE 368 sq. inches [23” x 16”]

BTU’s 42,000

CUTOUT 241/2” w x 191/2” d

• HEAVY-DUTY STAINLESS STEEL CONSTRUCTION

• REGAL 1 SIZE OFFERS OPTIONAL ROTISSERIE BACK

BURNER AND INFRARED BURNER OPTION

• DESIGNED TO DROP INTO THE TOP OF YOUR ISLAND

MODEL: E250s-1Z1E-P6

COOKING SURFACE 252 sq. inches [151/2 ” x 161/4”]

MODEL: E250t-1Z1E

COOKING SURFACE 252 sq. inches [151/2 ” x 161/4”]

a p a rt me nt b a lco n i es w h er e op e n
fl a m e c oo k in g is pr o h ib it ed

• Quality all-stainless steel construction, sleek contemporary styling

• High heat density- heats to more than 725˚F

• Large heating element for faster and hotter cooking

• Precision thermostatic control system with digital temperature read out

• Thermometer probe for accurate meat temperatures

• Available in table top and pedestal models

• Easy tilt up heating element for easy cleaning

• Easy grip cool-to-touch handle

• Easy removable inner liners for cleaning (dishwasher safe)

• Full width drip tray

• Stainless Steel cooking grids

• Operates on a 120V, 20 amp circuit

• Optional rotisserie kit

MODEL: 21-S1S1N-P6

PATIO POST

MODEL: 5110-32

Optional stainless steel

LP tank shield

Charcoal & Smoker

c o l l e c t i o n

Model 12-SC01C Shown

STAND ALONE

MODEL: 3324

COOKING SURFACE 540 sq. inches [30” x 18”]

CUTOUT

311/4” w x 211/4” d x 12” h

MODEL: 3329

COOKING SURFACE 368 sq. inches [23” x 16”]

CUTOUT

241/4” w x 191/4” d x 12” h

• DESIGNED TO DROP INTO THE TOP OF YOUR
ISLAND

• ADJUSTABLE CHARCOAL PAN FOR EASY COOKING

CONTROL

MODEL: 3339

COOKING SURFACE 368 sq. inches [23” x 16”]

CUTOUT

243/4” w x 173/4” d x 12” h

• CONSTRUCTED OF HEAVY-DUTY STEEL WITH

DURABLE POWDER COATED ENAMEL FINISH

• ADJUSTABLE CHARCOAL PAN FOR EASY COOKING

CONTROL

MODEL: 3334

COOKING SURFACE 540 sq. inches [30” x 18”]

CUTOUT

321/4” w x 193/4” d x 12” h

MODEL: 24s-SMB

COOKING SURFACE

1640 sq. inches

[ 5 Grids 171/2 ” x 183/4” each ]

•24s-SM MODEL WITHOUT BOTTOM STORAGE

DRAWER IS ALSO AVAILABLE

MODEL: 12-SC01C-A

COOKING SURFACE 432 sq. inches [24” x 18”]

CUTOUT

261/4” w x 193/4” d x 12” h

MODEL: 14-SC01C-A (SHOWN)

COOKING SURFACE 540 sq. inches [30” x 18”]

CUTOUT

321/4” w x 193/4”d x 12”h

MODEL: 22-SC01C-A

COOKING SURFACE 432 sq. inches [24” x 18”]

MODEL: 24-SC01C-61 (SHOWN)

COOKING SURFACE 540 sq. inches [30” x 18”]

MODEL: 22-SC01C-G6 IN-GROUND POST (SHOWN)

COOKING SURFACE 432 sq. inches [24” x 18”]

MODEL: 22-SC01C-P6 PATIO POST

COOKING SURFACE 432 sq. inches [24” x 18”]

MODEL: 24-SC01C-61

Built-In

MODEL: 14-SC01C-A

FIREMASTER

For a clas si c ro un de d oven hood cha ng e “S C” to “S1” in t he p art number

(ex. 24-S1 01 C- 61). Option not a va ilable on patio o r in-gro un d post models

LIFT-A-FIRE SLIDE-IN

*Co ok ing g ri ds an d ove ns (if de sired ) f or Fire maste r & L if t-A-F ire S li de- In must b e ord ere d sep ar ately.

GRILLING ACCESSORIES

Searing Station Model 3287-1Shown

ECHELON POWER BURNER

MODEL: 19-4B2N-0
CUTOUT: 19” w x 183/4” d x 12” h

The Echelon Power Burner is the largest,
most powerful side cooker available and
provides the high heat that’s perfect for
wok cooking or frying a turkey! Oering
a range of 3,000 to 60,000 BTU’s.
Available with porcelain cast iron or
stainless steel grids.

ECHELON DOUBLE
SEARING STATION
MODEL: 32884
CUTOUT: 19” w x 183/4” d x 12” h

With the Echelon Double Searing
Station, prepare restaurant-quality
steaks. When steaks are ash-cooked
at 1200°, juices are locked and meats
are tender and full of flavor. With 32,000
BTU’s.

ECHELON SINGLE
SEARING STATION
MODEL: 32874-1
CUTOUT: 14” w x 223/4” d x 12” h

Sear favorites such as ahi tuna
and marbled fillet mignon to
perfection. With 1200˚ of infrared
heat.

ECHELON DOUBLE
SIDE BURNER
MODEL: 32814
CUTOUT: 111/2” w x 223/4” d x 12” h

Enjoy precise ame control on each
burner to prepare side dishes and
sauces for your meal. Two (2) 15,000
BTU’s burners. Available with porcelain
cast or stainless steel grids.

ECHELON SINGLE
SIDE BURNER
MODEL: 32794-1
CUTOUT: 111/2” w x 14” d x 12” h

The Echelon Single Side Burner
features a 15,000 BTU’s ame burner,
precise ame control valve, and
stainless steel cover. Available with
porcelain cast grid.

POWER BURNER

MODEL: 19-S0B1N-0
CUTOUT: 19” w x 183/4” d x 12” h

The Aurora Power Burner is the largest,
most powerful side cooker available. It
provides a range of BTU’s from 3,000
to 60,000. Available with porcelain cast
iron or stainless steel grids.

SINGLE SIDE BURNER COUNTER TOP

CUTOUT: 83/4” w x 141/4” d

Drops into the top of island. Features include
15,000 BTU ’s sealed fla me burner, precise flame

control valve, and stainless steel cover.

DBL SEARING STATION

MODEL: 3288-1
CUTOUT: 19 w x 183/4 d x 12 h

With the Aurora Double Searing
Station steaks are ash-cooked at
1200°, juices are locked and meats are
tender and full of flavor. With 32,000
BTU’s, the double searing station is
a welcome companion to your Fire
Magic Aurora grill.

MODEL: 3280

SEARING STATION

MODEL: 3287-1
CUTOUT: 14” w x 223/4” d x 12” h

This single side burner flash cooks
at 1200˚ locking in juices for tender
meat and full flavor. Perfect for an
amazing seared steaks.

DOUBLE SIDE BURNER

MODEL: 3281
CUTOUT: 111/2” w x 223/4” d x 12” h

The Aurora Double side burner oers
precise ame control on each burner
to prepare side dishes and sauces
for your meal. Two (2) 15,000 BTU’s
burners. Available with porcelain cast
or stainless steel grids.

INFRARED COOKING SYSTEM

MODEL: 3049, 3050, 3051

The Fire Magic Infrared Cooking System is ideal
for searing steaks or when quick, high heat is
desired. 25,000 BTU’s with Natural or Propane
LP gas. Can be factory-installed or retrofitted.

SINGLE SIDE BURNER

MODEL: 3279-1
CUTOUT: 111/2” w x 14” d x 12” h

Features of this Aurora single side
burner include a 15,000 BTU’s ame
burner, precise ame control valve,
and stainless steel cover. Available
with porcelain cast grid.

Blender with hood Model 3284A Shown

BUILT-IN BEVERAGE CENTER BEVERAGE CENTER CART
MODEL: 1D-SSA MODEL: 2D-SSA
CUTOUT: 363/4” w x 231/2” d x 12” h

• Top storage shelf with rail • Halogen lights (requires 110V AC)

• Faucet & sink with drain • Covered heavy duty blender

• Removable bamboo cutting board • Insulated ice drawer with drain

• Storage drawer • 2 condiment holders

• Wine glass holder

ADDITIONAL STAND ALONE FEATURES:

• Waste basket & holder • Paper towel holder

• Stylish cart base • Insulated doors

• 110V AC receptable • 2 ice storage basins

• 2 large wine chillers • 2 towel racks

• Fold-down shelves

REFRIGERATOR
MODEL: 3590A
CUTOUT: 20” w x 211/4” d x 341/8” h

4.2 cubic foot. Interior light and, security
lock and key. Reversible door hinge and
lock. When used outdoors, it must be
installed in an enclosure.

BAR CADDY
MODEL: 1D-S0
CUTOUT: 141/4” w x 233/4” d x 12” h

Bar Caddy comes equipped with a towel
bar, bottle opener, sliding storage drawer,
two stainless steel bottle sleeves and
an installation hanger. Available with the
optional steam warming accessory.

PREMIUM REFRIGERATOR
MODEL: 3590DR
CUTOUT: 20” w x 211/4” d x 341/8” h

Fire Magic’s Premium Refrigerator
keeps beverages chilled to perfection.
Custom-designed door is fabricated with
a heavy-duty handle and radial corners
for an exclusive look. Handy lock keeps
contents safe. When used outdoors, it
must be installed in an enclosure.

BLENDER W/ HOOD
MODEL: 3284A
CUTOUT: 83/4” w x 141/4” d

Fire Magic’s Blender is the perfect
companion for any outdoor kitchen, bar
caddy or beverage center. The attractive
and sturdy stainless steel cover protects
the 675-watt motor from the elements.

COMPACT ICE MAKER
MODEL: 3592
CUTOUT: 151/2” w x 181/2” d x 251/2” h

Fire Magic’s new Ice Maker eliminates
trips inside to replenish your ice supply.
Door handle complements existing Fire
Magic doors.

LIGHTED BEV. CENTER TOP
MODEL: 1D-S-TOP

This stemware rack and light bar ts the
bill when island space is tight. Includes
transformer.

KEGERATOR
MODEL: 3591
CUTOUT: 241/2” w x 241/2” d x 37” h

Accommodates 60-litre beer kegs (CO₂
tank and hardware are included). LED
display, reversible door hinge, black/
chrome beer tower dispenser, drip tray
and optional swivel casters for portability
(Keg not included).

BAMBOO CUTTING BOARD
MODEL: 3582-1

This durable and functional Bamboo
Cutting Board is perfect for preparing
meats and vegetables for grilling. 12”x 14”.

SINK & FAUCET
MODEL: 3587 & 3588
CUTOUT: 14” w x 14” d

Adds convenience and functionality to
your outdoor kitchen, so clean-up can be
done grill side. Purchase separately or to­gether. Sink measures 15” x 15” x 6” and
requires a 17” clearance underneath.

CUT & CLEAN COMBO
MODEL: 53816
CUTOUT: 83/4” w x 4” d

Installed in a grill island counter top, this
cleverly designed accessory lets you slice
and dice on a Fire Magic bamboo cutting
board, then sweep debris right into the
Fire Magic trash receptacle or basic trash
can via a deep stainless steel trash chute.
Chute measures 143/4”.

GRIDDLE
MODEL: 3512A OR 3513A

WOK
MODEL: 3572

GRILL BRUSH
MODEL: 3576-1

FOUR-PIECE TOOL SET
MODEL: 3575

DISPOSABLE DRIP TRAY LINER
MODEL: 3557 (4-PACK)

Griddle available for the Fire Magic
double side burner as well as Echelon
and Aurora grills. Cook eggs, bacon,
and uy pancakes. Enjoy breakfast in
the great outdoors! Also great for fajitas!

CHARCOAL BASKET
MODEL: 3562-1 or 3562-2

Cooking with wood chunks or
charcoal is easier than ever. Basket
sits on top of the burner, gas burners
ignite the chunks or coals. Bottom
tray catches ashes for easy clean­up.

Hard-anodized stick-resistant lined
interior surface measures 14” in
diameter.

CHICKEN HOLDER
MODEL: 3617E

Enjoy a golden, succulent chicken
the quick and easy way!

The brass bristles on Fire Magic’s
Grill Brush make clean up fast and
easy. Includes one replacement brush
head. Replacement brush heads also
available.

FISH BASKET
MODEL: 3618

A versatile, stainless steel basket for
skewers, burgers, ribs or fish.

Includes a fork, spatula, knife and
tongs. Constructed of quality stainless
steel.

TURKEY FRYER KIT
MODEL: 3570

You’ll be amazed at how tender
a deep-fried turkey can be. Kit
includes pot, inner basket with
sturdy handle and thermometer
probe. Great as a crab or corn pot.

Custom-designed for Fire Magic grills
and sold in packs of 4, these convenient
disposable drip tray liners reduce the
risk of grease res.

TURKEY HOLDER
MODEL: 3615E

This sturdy holder is also perfect for
beef, pork and lamb roasts.

ECHELON DIAMOND
THERMOMETER RECEIVER
MODEL: 3566

Displays transmitted data from the
grill’s thermometer and will emit a
sound when the alarm goes off. Can
also be used as a timer.

STRAIGHT LINE GAS VALVE
MODEL: AV-30

Can be attached to gas line for
additional safety.

SAFETY TIMER
MODEL: 3090 (3 HOUR TIMER)
MODEL: 3092 (1 HOUR TIMER)

Fire Magic’s 3 Hour, and new 1
Hour, Safety Timers offers additional
safety and automatically shuts off
gas flow at pre-set times. Easy to
install. Great for apartment and
condominium use.

TRASH CONTAINER
MODEL: 53825-T

Constructed of stainless steel with a
hands-free foot lever, the door easily
slides open to reveal a 10.5 gallon
trash can. Fully enclosed.

PAPER TOWEL HOLDER
MODEL: 53812

Accepts and protects regular or
jumbo rolls. Premium 304 stainless
steel ensures a uniform look for all
Fire Magic built-in products.

PRE-FABRICATED ISLAND
MODEL: DC790-CS-84C

790 available in a beautiful stacked stone complete with Midnight Copper granite counter top

•

•

90” wide x 34” deep x 38 ½” high

•

Requires A790i or E790i grill, Double Side Burner 32814 and 3281, Front Access Drawer
43830-S, 33830-S, 43830-SW or 33830-SW. Side Panel Access Door 43920-SR/SL
or 33920-SR/SL

•

Sturdy interior stainless steel construction

•

Exterior faux stacked stone panels are made of magnesium oxide concrete

Model DC790-CS-84C

A L S O A V A I L A B L E

VENT HOOD FEATURES

• Available in 36”, 42” and 60” widths

• Powerful 1400 CFM dual fan specically designed
and engineered to quickly--and quietly--extract smoke,
heat and odors from the front and rear of the hood

• High quality brushed 304 stainless steel construction with
seamless edges

• Dual LED under mount lamps (three lamps on 60” unit)
provide generous light for evening grilling

• Blue bezel illuminated push buttons reveal lamps and fan
in the ON position at a glance

• Anodized aluminum lters remove easily and are
dishwasher safe

• Innovative low voltage operation

• Easy install mounting bracket included

• Indoor/Outdoor listed

• Available in a model with a 1000 CFM fan (36-VH-4)

VENT HOOD
MODEL: 36-VH-4
MODEL: 36-VH-3
MODEL: 42-VH-3
MODEL: 60-VH-3

ASSEMBLES

IN MINUTES!

PRE-FABRICATED ISLAND

Model DC430-CS-60C

MODEL: DC430-CS-60C

430 available in a beautiful stacked stone complete with Midnight Copper granite counter top

•

66” wide x 24” deep x 36 ½” high

•

Requires A430i Grill, 3280 Side Burner, Side Panel Access Door 43920-SR/SL or 33920-SR/SL

•

Sturdy interior construction
Exterior faux stacked stone panels are made of magnesium oxide concrete

•

•

DOORS & DRAWERS

MODEL: 53920-SL

MODEL: 43920-SL

Flush Mounted

MOUNTED DOORS AND DRAWERS (5 Series)

Featuring heavy-duty handles with cast stainless steel mounts, these doors and drawers are designed to close ush with the
frame with a strong magnetic latch. Premium Doors and Drawers are lled with polyurethane foam for insulation and a solid feel.
Available in a variation of door and drawer congurations and sizes. With so many options there is a combination available to
meet any outdoor kitchen storage need.

Premium

DOORS AND DRAWERS (4 Series)

Stylized with rounded edges to match the contours of your Fire Magic Grill, these doors and drawers feature heavy-duty handles
with cast stainless steel mounts and are mounted outside the frame. A strong magnetic latch ensures secure closure and
polyurethane foam gives a solid feel and insulation. Available in 17 door and 10 drawer congurations and sizes.

Select

DOORS AND DRAWERS (3 Series)

MODEL: 33920-SL

MODEL: 23920-SL

These doors and drawers feature outside mounting, double wall and square edge construction, a slim tubular stainless steel
handle and heavy-duty magnetic latch. Available in 16 door and 10 drawer congurations and styles.

Legacy

DOORS AND DRAWERS (2 Series)

Outside mounted with angled edges, the Legacy Doors and Drawers feature a slam latch for secure closure. Available in 12 door
and 4 drawer congurations and sizes. Select styles available with black powder-coated nish. The Legacy doors and drawers
are the most economical for builders and homeowners alike.

*AVAILABLE WITH

LEFT OR

RIGHT DOOR HINGE

DOUBLE DOORS WITH DUAL DRAWERS
MODEL: 53930S-22
CUT-OUT: 21” x 30 ½” x 20 ½”

Flush Mounted

• Sleek flush design

• Handles complement Echelon and Aurora series grills

• Double wall construction

• Insulated doors for solid sound and feel

• 304 Stainless Steel

• Cut-out is height x width x depth

SINGLE DOOR WITH DUAL DRAWERS*
MODEL: 53820-SR
CUT-OUT: 21” x 14 ½” x 20 ½”

DOUBLE ACCESS DOORS
MODEL: 53934S
CUT-OUT: 15” x 30”

DBL DOORS WITH TRASH
TRAY & DUAL DRAWERS

MODEL: 53930S-12
CUT-OUT: 21” x 30 ½” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 53920-SL
CUT-OUT: 21” x 14 ½”

DOUBLE ACCESS DOORS
MODEL: 53938S
CUT-OUT: 16” x 39”

ELECTRIC WARMING DRAWER
MODEL: 53830-SW
CUT-OUT: 14 ½” x 32 ¼” x 22”

SINGLE ACCESS DOORS*
MODEL: 53924-SL
CUT-OUT: 25” x 17 ½”

TRIPLE DRAWER
MODEL: 53803

CUT-OUT: 26 ¼” x 14 ½” x 20 ½”

SINGLE ACCESS DOORS*
MODEL: 53917-SR
CUT-OUT: 18” x 24 ½”

MASONRY DRAWER
MODEL: 53830-S
CUT-OUT: 14 ½” x 32 ¼” x 22”

SINGLE ACCESS DOORS*
MODEL: 53914-SR
CUT-OUT: 15” x 20 ½”

DOUBLE DRAWER
MODEL: 53802
CUT-OUT: 15 ¾” x 14 ½” x 20 ½”

Also available: (not shown)

MODEL: 53914-SL CUT-OUT: 15” x 20 ½”

MODEL: 53917-SL CUT-OUT: 18 ½” x 24 ½”

MODEL: 53924-SR CUT-OUT: 25” x 17 ½”

MODEL: 53820-SL CUT-OUT: 21” x 14 ½” x 20 ½”

MODEL: 53930S-12T CUT-OUT: 21” x 30 ½” x 20 ½”

MODEL: 53820-TSR or TSL CUT-OUT: 21” x 14 ½” x 20 ½”

DOUBLE ACCESS DOORS
MODEL: 53930S
CUT-OUT: 21” x 30”

SINGLE DRAWER
MODEL: 53801
CUT-OUT: 5 ¼” x 14 ½” x 20 ½”

Premium

• Sleek radius corners

*AVAILABLE WITH

LEFT OR

RIGHT DOOR HINGE

DOUBLE DOORS W/ TANK TRAY, LOUVERS, & DUAL DRAWERS
MODEL: 43930S-12T

CUT-OUT: 21” x 30 ½” x 20 ½”

• Handles complement Echelon and Aurora series grills

• Sturdy double wall construction

• Insulated doors for a solid sound and feel

• 304 Stainless Steel

• Cut-out is height x width x depth

SINGLE DOOR WITH DUAL DRAWERS*
MODEL: 43820-SL
CUT-OUT: 21” x 14 ½” x 20 ½”

DOUBLE DOORS WITH TRASH TRAY,
AND DUAL DRAWERS

MODEL: 43930S-12
CUT-OUT: 21” x 30 ½” x 20 ½”

DOUBLE DOORS WITH 2 DUAL DRAWERS
MODEL: 43930S-22
CUT-OUT: 21” x 30 ½” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 43920-SR
CUT-OUT: 21” x 14 ½”

DOUBLE ACCESS DOORS
MODEL: 43934S
CUT-OUT:15” x 30”

ELECTRIC WARMING DRAWER
MODEL: 43830-SW
CUT-OUT: 13” x 31” x 20 ½”

SINGLE ACCESS DOOR WITH TANK TRAY
AND LOUVERS*

MODEL: 43820-TSL
CUT-OUT: 21” x 14 ½” x 20 ½”

TRIPLE DRAWER
MODEL: 43803
CUT-OUT: 26 ¼” x 14 ½” x 20 ½”

MASONRY DRAWER
MODEL: 43830-S
CUT-OUT: 13” x 31” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 43917-SR
CUT-OUT: 18” x 24 ½”

DOUBLE DRAWER
MODEL: 43802
CUT-OUT: 15 ¾” x 14 ½” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 43914-SR
CUT-OUT: 15” x 20 ½”

DOUBLE ACCESS DOORS
MODEL: 43930S
CUT-OUT: 21” x 30”

SINGLE DRAWER
MODEL: 43801
CUT-OUT: 5 ¼” x 14 ½” x 20 ½”

Also available: (not shown)

MODEL: 43914-SL CUT-OUT: 15” x 20 ½”

MODEL: 43917-SL CUT-OUT: 18” x 24 ½”

MODEL: 43924-SR or SL CUT-OUT: 25” x 17 ½”

MODEL: 43920-SL CUT-OUT: 21” x 14 ½”

MODEL: 43820-TSR CUT-OUT: 21” x 14 ½” x 20 ½”

SINGLE DOOR WITH DUAL DRAWERS*
MODEL: 33820-SR
CUT-OUT: 21” x 14 ½” x 20 ½”

*AVAILABLE WITH

LEFT OR

RIGHT DOOR HINGE

Select

• Stainless steel tubular handles

• Double wall construction

• 304 Stainless Steel

• Cut-out is height x width x depth

TRIPLE DRAWER
MODEL: 33803
CUT-OUT: 26 ¼” x 14 ½” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 33914-SR
CUT-OUT: 15” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 33924-SR
CUT-OUT: 25” x 17”

ELECTRIC WARMING DRAWER
MODEL: 33830-SW
CUT-OUT: 13” x 31” x 20 ½”

DOUBLE DRAWER
MODEL: 33802
CUT-OUT: 15 ¾” x 14 ½” x 20 ½”

SINGLE ACCESS DOOR*
MODEL: 33920-SR
CUT-OUT: 21” x 14 ½”

SINGLE DRAWER
MODEL: 33801
CUT-OUT: 5 ¼” x 14 ½” x 20 ½”

DOUBLE ACCESS DOORS
MODEL: 33930S
CUT-OUT: 21” x 30”

MASONRY DRAWER
MODEL: 33830-S
CUT-OUT: 13” x 31” x 20 ½”

DOUBLE DOORS WITH 2 DUAL DRAWERS
MODEL: 33930S-22
CUT-OUT: 21” x 30 ½” x 20 ½”

MODEL: 33914-SL CUT-OUT: 15” x 20 ½”

MODEL: 33917-SL CUT-OUT: 18” x 24 ½”

MODEL: 33920-SL CUT-OUT: 21” x 14 ½”

SINGLE ACCESS DOOR*
MODEL: 33917-SR
CUT-OUT: 18” x 24 ½”

MODEL: 33820-SL CUT-OUT: 21” x 14 ½” x 20 ½”

MODEL: 33820-TSR CUT-OUT: 21” x 30 ½” x 20 ½”

MODEL: 33930S-12 CUT-OUT: 21” x 30 ½” x 20 ½”

DOUBLE DOORS WITH TANK TRAY,
LOUVERS, AND DUAL DRAWERS

MODEL: 33930S-12T
CUT-OUT: 21” x 30 ½” x 20 ½”

SINGLE ACCESS DOOR W/ TANK TRAY
AND LOUVERS*

MODEL: 33820-TSL
CUT-OUT: 21” x 14 ½” x 20 ½”

Also available: (not shown)

SINGLE DOOR WITH DUAL DRAWERS
MODEL: 23820-S
CUT-OUT: 20 ½” x 14 ½” x 20 ½”

Legacy

• Single wall construction with black latch handle

• Most economical door style

• Most doors are reversible for left or right access

• Single Access Doors also available in black powder coat finish

• 304 Stainless Steel

• Cut-out is height x width x depth

MASONRY DRAWER
MODEL: 23830-S
CUT-OUT: 13” x 31” x 20 ½”

SINGLE ACCESS DOOR
MODEL: 23917-S
CUT-OUT: 17 ½” x 24 ½”

SINGLE ACCESS DOOR
MODEL: 23920-S
CUT-OUT: 20 ½” x 14 ½”

DRAWER WITH PROPANE DOOR ASSY
MODEL: 25914-S
CUT-OUT: 27 ¾” x 14 ½” x 20 ½”

DOUBLE DOORS WITH DUAL DRAWERS
AND TRASH TRAY

MODEL: 23930S-12
CUT-OUT: 21” x 30 ½” x 20 ½”

SINGLE ACCESS DOOR WITH LOUVERS
MODEL: 23920-1-S
CUT-OUT: 20 ½” x 14 ½”

VENTING PANEL, LOUVERED
STAINLESS STEEL

MODEL: 5510-01
CUT-OUT: 3 ¾” x 12 ¾”

DOUBLE ACCESS DOOR
MODEL: 23930-S
CUT-OUT: 20 ½” x 30”

SINGLE ACCESS DOOR (RIGHT OR LEFT)
WITH TANK TRAY AND LOUVERS

MODEL: 23920-1T-S
CUT-OUT: 20 ½” x 14 ½” x 20 ½”

Also available: (not shown)

SINGLE ACCESS DOORS

MODEL: 23912-S CUT-OUT: 12 ½” x 18 ½”

MODEL: 23918-S CUT-OUT: 18 ½” x 12 ½”

MODEL: 23924-S CUT-OUT: 24 ½” x 17 ½”

MODEL: 23914-S CUT-OUT: 14 ½” x 20 ½”

14724 PROCTOR AVE. CITY OF INDUSTRY, CA 91746

FIRE MAGIC OUTDOOR GAS GRILL WARRANTY

®

WWW.RHPETERSON.COM

LI FETI ME WAR R ANT Y

FIRE MAGIC CAST STAINLESS STEEL BURNERS, STAINLESS STEEL ROD COOKING GRIDS, AND STAINLESS

STEEL HOUSINGS ARE WARRANTED FOR AS LONG AS YOU OWN YOUR FIRE MAGIC GRILL.

FI FTEE N YE AR WAR RANT Y

FIRE MAGIC BRASS BURNERS, BRASS VALVES, MANIFOLD ASSEMBLIES , AND BACKBURNER ASSEMBLIES (EXCEPT IGNITION SYSTEMS) ARE WARRANTED FOR FIFTEEN (15) YEARS.

TE N YE AR WAR R ANT Y

FIRE MAGIC ELECTRIC GRILLS, ELECTRIC GRILL STAINLESS STEEL COOKING GRIDS, AND ELECTRIC GRILL STAINLESS STEEL HOUSING ARE WARRANTED FOR TEN (10) YEARS.

FI VE Y EAR WA R RAN TY

INFRARED BURNERS, CHARCOAL STAINLESS STEEL GRILLS, AND SMOKERS (EXCEPT FOR THE CHARCOAL PAN

FIRE MAGIC SIDEBURNERS AND ALL OTHER FIRE MAGIC GRILL COMPONENTS (EXCEPT IGNITION SYSTEMS AND ELECTRICAL PARTS) ARE WARRANTED FOR THREE (3) YEARS.

FIRE MAGIC IGNITION SYSTEMS (EXCLUDING BATTERIES), ELECTRICAL COMPONENTS (INCLUDING LIGHTS AND THERMOMETER), CHARCOAL PAN AND ASH TRAY, AND GRILL ACCESSORIES

AND ASH TRAY) ARE WARRANTED FOR FIVE (5) YEARS

TH REE YEAR WA RRA NTY

ON E YE AR WAR R ANT Y

ARE WARRANTED FOR ONE (1) YEAR.

L-C1-04512
