Fire Magic 1DSSD User Manual
BEVERAGE CENTER
Stand Alone Model # 2D-SSA, 2D-SSD
Built-In Model # 1D-SSA, 1D-SSD
INSTALLATION
INSTRUCTIONS & OWNER’S
MANUAL
INSTALLER: Leave these instructions with consumer.
CONSUMER: Retain for future reference.
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION OR USE.
2D-SSD shown
WARNING
This electrical appliance is equipped with a threepronged (grounding) plug for your protection against
shock hazard and should be plugged directly into
a properly grounded three-prong GFI protected
receptacle. Do not cut or remove the grounding prong
from the plug.
Do not operate any appliance with a damaged cord
or plug, after an appliance malfunction, or after the
appliance has been dropped or damaged. Return the
appliance to your dealer or authorized service facility for
inspection, repair, or electrical/mechanical adjustment.
ELECTRICAL GROUNDING
To protect from electrical shock, this appliance must
be grounded while in use.
Two-pronged outlets may be grounded by use of an adapter
as shown in Fig. 1-2. The grounding tab extending from
the adapter must be connected to a permanent ground.
If an extension cord is used, it must be a three-pronged
cord listed for outdoor use. These cords are identifi ed by
the marking: "Suitable for use with outdoor appliances;
store indoors while not in use." The cord must be rated
at or above the rating of this appliance as specifi ed on
the rating plate.
Grounding
plug
Metal mounting
Cover of grounded
Adapter
GFI receptacle
Test and reset
switches
Fig. 1-1 GFI receptacle
screw
outlet box
Grounding
means
Fig. 1-2 Grounding methods
ROBERT H. PETERSON CO. • 14724 East Proctor Avenue • City of Industry, CA 91746
REV 6 - 1301171200
1
L-C2-274
STAND ALONE REPLACEMENT PARTS LIST
Item Description Part No. Qty.
1. Sink
2. Faucet
3. Blender kit
4. Cutting board
5. Condiment holder with lid
6. Food/Beverage holder with lid
7. Waste water container
8. Overhead light lens*
Not shown
*
3587 1
3588 1
3284-1 1
1D-S-07 1
1D-S-08 2
2D-S-09 2
2D-S-13 1
24187-26 2
Item Description Part No. Qty.
9. Overhead light bulb*
10. Paper towel rack
11. GFI / receptacle & power supply
12. Waste basket
13.
Storage drawer (w/glides)
Diamond storage drawer (w/glides)
or
14.
Insulated ice drawer (w/glides)
Diamond insulated ice drawer (w/glides)
or
15. fold down shelf
16. Rigid shelf
24187-15 2
25387-11 1
24387-18 1
2D-S-14 1
1D-S-12
1D-SD-1211
1D-S-11
1D-SD-1111
24336-15 1
2D-S-16 1
16
6
13
2
3
6
Blender kit
(packed separately)
1
4
5
15
14
10
11
12
7
The beverage center is available in both built-in and stand alone models.
Built-in and stand alone models come with a sink, cutting board, blender, an equipment drawer, drawer-front bottle opener,
and a clean ice drawer. The unit is also topped with an upper shelf (optional on built-ins) with a lighted covering that sports a
wine glass rack and additional upper storage area.
Stand alone models come with shelves, a storage area containing two full-sized ice trays and two wine holders for cooling
beverages, a wheeled cart, side-folding paper-towel rack, and built-in transformer box.
REV 6 - 1301171200
2
2D-SSA shown
L-C2-274
BUILT-IN REPLACEMENT PARTS LIST
Item Description Part No. Qty.
1. Sink
2. Faucet
3. Blender kit
4. Cutting board
5. Condiment holder with lid
6. Electrical junction box
7. Overhead light lens (if equipped)*
8. Overhead light bulb (if equipped)*
9.
Storage drawer (w/glides)
Diamond storage drawer (w/glides)
or
10.
Insulated ice drawer (w/glides)
Diamond insulated ice drawer (w/glides)
or
Not shown
*
3587 1
3588 1
3284-1 1
1D-S-07 1
1D-S-08 2
24187-18 1
24187-26 2
24187-15 2
1D-S-12
1D-SD-1211
1D-S-11
1D-SD-1111
OPTIONAL
upper shelf
(non-retrofi ttable)
3
2
Blender kit
(packed separately)
1
4
5
Wire
9
connections:
(2) yellow - (2) black
(1) green - (1) green
10
6
1D-SSA shown
REV 6 - 1301171200
3
L-C2-274
6-1/2"
23-1/2"
12"
23 1/2"
Depth
Height
12"
Height
Depth
34"
Side view
Top view
Front view
36-3/4"
Width
INSTALLATION
BUILT-IN UNITS
Prepare a cut-out in the countertop as specifi ed in Table 1
and shown in Fig. 4-1. Note additional clearance required
to the rear for the blender cover to open fully.
Counter Cut-out Dimensions
Counter Opening Height* 12"
3
1
/4"
/2"
Counter Opening Width* 36Counter Opening Depth* 23-
Table 1
Install a listed, grounded 110-volt GFI receptacle beneath
the countertop within 5 feet of the blender base so that the
blender can be plugged into it. Install the electrical junction
box (see REPLACEMENT PARTS LIST) near the GFI
receptacle so that it can be plugged in the receptacle. The
wires from the box must be connected to the wires located
on the rear of the beverage center as follows:
• Connect the two yellow wires (junction box) to the two
black wires (beverage center).
• Connect the green wires (one found on both junction
box and beverage center).
WARNING
Have all electrical work
performed by a licensed
professional electrician.
Front
support
Fig. 4-1 Counter cut-out dimensions (built-in only)
The junction box must be put inside the enclosure before
the beverage center is installed.
After the enclosure cut-out and the electrical and plumbing
hookups are prepared, place the beverage center into the
cut-out. Keep all electrical wires from being pinched between
the beverage center and the enclosure.
The beverage center will rest on the countertop by its
stainless-steel hanger and on the front support shown in
Fig. 4-1 underneath the face.
Silicon sealant may be applied around the top edge of the
countertop cut-out to create a barrier between the housing
and countertop capable of keeping out fl uids. Do not use
silicon between the blender base and the stainless-steel
housing, as the base must be removable for cleaning and
maintenance.
STAND ALONE UNITS
Locate the unit on a fl at, level surface near desired electrical
and water lines. To lock a caster press down on the side of
the lever with the word "OFF" stamped on it until it stops and
does not turn (see Fig. 4-2). Repeat for all casters. For the
stand alone beverage center, plug the end of an extension
cord matching the requirements on the cover into the leftmost electrical receptacle on the right side.
Fig. 4-2
WARNING
Have all electrical work
performed by a licensed
professional electrician.
Caster in locked position (stand alone only)
REV 6 - 1301171200
4
L-C2-274
