SPECIFICATIONS
VERTICAL LETTER FILES
FIREPROOF INSULATION is 100% gypsum, reinforced by a 1” by 2” lattice made
of 14-gauge galvanized welded steel wire, providing complete peace of mind
from fi re, impact, or explosion.
FIELD REPLACEABLE STEEL PANELS can easily be replaced in the event that any
Filing
Arrangement:
LETTER FILING
FRONT TO BACK
panel is damaged.
FINISH is an environmentally-friendly electrostatic powder coating applied to
all sides, including bottom. The fi nish is scratch-resistant, providing a lifetime
quality appearance. Standard colors available include: parchment, tan,
taupe, brown, black, sand, champagne, platinum, and pewter.
DRAWER BODIES are built with high sides for use with hanging folders – no
additional frames are needed. Each fi le includes 1 follower block per drawer.
DRAWER SUSPENSIONS are maintenance free.
DRAWER LOCKS are UL
®
-listed Medeco high-security key locks.
DRAWER PULLS are surface mounted to allow for extra insulation inside the
drawer heads.
INSULATION BETWEEN ALL DRAWERS makes each drawer a separate insulated
container.
WATER RESISTANCE means fi les are designed to prevent water damage resulting from
sprinklers and fi re hoses.
2-POSITION DRAWER CATCH allows access to certain drawers while others remain locked.
DRAWER HEADS are formed of welded steel and fi lled with fi reproof insulation, and are fi eld
replaceable.
UNDERWRITERS LABORATORIES
®
(UL®) FIRE & IMPACT RATING on all fi le cabinets. These models
carry the 1-Hour Class 350 Fire with Impact UL label. Tests include 1 hour exterior fi re
exposure at 1700°F, a 2000°F explosion test, and a 30 foot drop to test impact integrity.
OPTIONAL UPGRADES are available to enhance your fi le’s appearance or functionality.
Upgrades available include custom color fi nishes, standard lock options, casters, and interior
options such as document inserts, trays, and inner drawers.
FIREKING’S LIMITED LIFETIME WARRANTY on all mechanical or operable parts. Associated labor
costs will be paid by FireKing for two years from the date of purchase. If your FireKing fi le
sustains any damage while protecting documents from a fi re, FireKing will replace the fi le free
of charge. For more details visit www.fi reking.com.
SIDE VIEW:
60 7/8” OVERALL DEPTH
WITH DRAWER EXTENDED
33 1/8”
WITH HANDLE
31 9/16” CHASSIS
FILING
DEPTH 26”
MODEL 2-1831-C:
348 lbs (avg. ship wt.)
FILING WIDTH
12 3/16”
27 3/4”
CHASSIS
HEIGHT
17 3/4”
CHASSIS WIDTH
Dimensions
±1/16 inch
101 Security Pkwy • New Albany IN 47150
MODEL 3-1831-C:
476 lbs (avg. ship wt.)
FILING WIDTH
12 3/16”
10 3/8”
FILING
HEIGHT
40 1/4”
CHASSIS
HEIGHT
17 3/4”
CHASSIS WIDTH
FireKing Security Group
800.457.2424 / 812.948.8400
www.fi reking.com
10 3/8”
FILING
HEIGHT
MODEL 4-1831-C:
603 lbs (avg. ship wt.)
FILING WIDTH
12 3/16”
10 3/8”
FILING
HEIGHT
52 3/4”
CHASSIS
HEIGHT
17 3/4”
CHASSIS WIDTH
