Firegear OFP-L36TFS-N, OFP-L48TFS-N, OFP-L36TFS-P, OFP-L48TFS-P, OFP-L60TFS-N Installation And Operating Instructions Manual
...
Kalea Bay Outdoor Gas Fireplace
Installation and Operating Instructions
This is a Single-Sided replace with the option of
converting it into a See-Through replace.
MH# 60069
MODELS
Natural Gas Description Propane
OFP-L36TFS-N
OFP-L48TFS-N
OFP-L60TFS-N
OFP-L72TFS-N
36” Open Front/See-Through Fireplace
48” Open Front/See-Through Fireplace
60” Open Front/See-Through Fireplace
72” Open Front/See-Through Fireplace
OFP-L36TFS-P
OFP-L48TFS-P
OFP-L60TFS-P
OFP-L72TFS-P
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
INSTALLATION PRECAUTION:
This replace requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
CARBON MONOXIDE HAZZARD
DANGER
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed area can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open ame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or re department.
WARNING
Do not store our use gasoline or other
ammable vapors and liquids in the
vicinity of this or other appliances.
Any LP cylinder not connected for use
shall not be stored in the vicinity of this
or other appliances.
WARNING
Do not leave unattended during use.
Do not use for cooking.
Follow all gas leak procedures in this
manual prior to operation.
Improper installation, adjustment,
alteration, service or maintenance
can cause injury of property damage.
WARNING
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
WARNING
If the information in these instructions is not followed exactly, a re or explosion
may result causing property damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other ammable vapors and liquids in the vicinity
of this or other appliance.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 1
CERTIFICATION: The Kalea Bay Outdoor replaces are
tested and approved to ANSI Z21.97-2014, CSA 2.41-2014
standards by Underwriters Laboratories using listing
MH#60069. It should be installed by a qualied installer in
accordance with local and state building codes using
National Fuel Gas Code ANSI Z223.1/NFPA54 or current
CSA-B149.1 installation codes for Gas Burning Appliances
and Equipment in Canada.
DESCRIPTION: These Outdoor replace models come
pre-programmed and ready to operate with HI/LO
capibilitties once installation is complete. They use an
electronic ignition that runs off of (4) AA batteries or an
optional adapter (AF-4000ADP24). These are radiant
replaces only and do not have a fan option. Do not
burn real wood or other combustible materials in these
replaces. Use only approved glass media. Each model
is available for Natural or Propane gas and must be
ordered accordingly. They are not eld convertible. There
is no venting required for this replace. Provide adequate
clearances according to this manual and cross ventilation.
The burner assembly is removable for service. NEVER
obstruct the front opening(s) of the replace.
COMMONWEALTH OF MASSACHUSETTS
REQUIREMENTS
These appliances are approved for installation in the US
state of Massachusetts if the follow additional requirements
are met:
• Un-vented Room Heaters shall be installed in
accordance with 527 CMR 30.
• Installation and repair must be done by a plumber
or gas tter licensed in the Commonwealth of
Massachusetts.
• The exible gas line connector used shall not exceed
36-inches (92 centimeters) in length.
• The individual manual shut-off must be a T-handle type
valve.
• Unvented appliances may NOT be installed in bedrooms or bathrooms.
• A working smoke detector must be installed in the area
where vent-free appliances are installed.
Seller of of unvented Propane or Natural gas-red
supplemental room heaters shall provide to each purchaser
a copy of 527 CMR 30 upon sale of the unit.
NOTE: This replace comes with (4) metal standoffs
attached (at) secured to the top of the rebox. These
are to be used if combustible materials are being used as
part of the installation. If all non-combustible materials are
being used for the installation then the standoffs are not
required for installation.
SAFETY
1. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases.
2. Do not place Propane (LP) supply tanks inside any
structure. Locate propane tanks outdoors.
3. This replace is to be used only outdoors in a well
ventilated space and shall not be used in a building,
garage, or any other enclosed area.
4. Do not use this replace as a wood burning replace.
Use only high temperature media approved for use with
this replace.
5. Do not use this replace to cook or burn paper or other
objects.
6. Do not use if exposed to or under water. Immediately
call a qualied service technician to inspect the
replace and replace any part of the control system
and any gas control which has been under water.
7. Turn replace OFF and let cool before servicing. Only
a qualied service person should service and perform
service.
8. To prevent performance problems in Propane (LP)
replaces, do not use a Propane tank less than 100lbs.
capacity.
State of Massachusetts: The installation must be made
by a licensed plumber or gas tter in the Commonwealth
of Massachusetts.
Sellers of unvented Propane or Natural gas-red supplemental room heaters shall provide to each purchaser a
copy of 527 CMR 30 upon sale.
Vent-free gas products are prohibited for bedroom or
bathroom installation in the Commonwealth of
Massachusetts.
LOCAL CODES
Install and use replace with care. Follow all local codes.
In the absence of local codes, use the latest edition of the
National Fuel Gas Code ANSI Z223.1/ NFPA54.
Available from:
American National Standards Institute, Inc.
25 West 43rd Street, 4th oor
New York, NY 10036
National Fire Protection Association, Inc.
1 Batterymarch Park
Quincy, MA 02169-7471
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 2
Fuels used in gas red appliances, and the products of combustion such as fuels, contain
chemicals known to cause cancer, birth defects and/or other reproductive harm.
This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1
TABLE OF CONTENTS
Certication, Description & Safety Information 2
Installation Precautions 4-6
Framing, Gas Line & Cross Ventilation Requirements 5-6
Hard piping & High Elevation 6
Fireplace Specications 7
Single-Sided Fireplace Application 8
Dimensions; Combustible Clearances; Mantel Clearances 9
Framing with Metal or Wood Studs 10
See-Through Fireplace Application 11
Converting Fireplace to a See-Through Model 12
Dimensions; Combustible Clearances; Mantel Clearances 13
Framing with Metal or Wood Studs 14
Final Preparation 15-20
Installing Battery Pack & Transmitter Battery 15
Installing Pilot Covers in Burnerpan 16
Installation of Media in Burnerpan/Trough 17
Installation of Hoods and Windshield 18
Windshield Installation & Pilot Operation 19
Flame Height 20
Learning Additional Remote to Module (Receiver) 21
Operation 22
Lighting Instructions 22
Replacement Parts 23
Replacement Parts List 24-25
Fireplace Maintenance 25
Troubleshooting 26-28
Optional Accessories 29
All media (i.e. lava rock, lava stones, lava boulders and re glass) has the potential of thermal spalling. This is a process that may
occur when media is wet and moisture gets trapped inside of the material due to rapid temperature differences. When this
happens the media has the potential to crack or “pop” outside the replace. Heavy rains, high humidity and the presence of
moisture can contribute to this process.
ALWAYS USE CAUTION WHEN USING THE FIREPLACE
Extra caution should be taken when lighting a replace when heavy rains, high humidity and moisture are present. Light the
replace; leave the area allowing any moisture in the media to dissipate. We strongly recommend that during this drying out time
that you monitor the replace from a distance. This drying out period should be no less than 30 minutes. Continue monitoring the
ame from distance to ensure that all popping has ceased before fully enjoying the re.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 3
INSTALLATION PRECAUTIONS
1. These replaces are designed for outdoor use only. Not approved for any indoor use.
2. We recommend using ¾” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for proper
pipe sizing when exceeding 20-feet in length for replaces rated above 100,000 BTU.
3. Determine which replace you are preparing to install, single-sided or see-through. (Refer to page 8 or 11).
4. The Kalea Bay replace is not a “load bearing” replace. All nishing materials must be supported by the
surrounding structure and not rely on the replace itself.
5. Follow the local code requirements for the gas type being used. This replace should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fireplaces create high temperatures, it is very important to have any combustibles at a safe distance.
7. Normal operation of the replace is with a battery pack that is supplied with your system (Figs. 16-18 on page 15).
The battery pack has 12-feet of black sleeved wire that is to be passed through the junction box provided. This wire
should not be cut or spliced and the junction box can be placed in the facing of the vertical nish of the replace, if you
place the wire under ground you should install those wires into an approved protective conduit/sleeve material.
8. Fireplace should never be left unattended while in operation. It should always be a safe distance from all trees and
combustible landscape materials.
9. The replace must be installed on a at, level, stable, non-combustible surface. Exception: It is permissible to place
one layer of ½” cement board underneath the entire replace, then it may sit on a at, level, stable, combustible
surface. Drainage is critical to ensure that water does not damage gas valve and components. Never install the
replace system below grade.
10. CAUTION: A minimum of 18 square inches of cross ventilation (per side) is required to keep the inside of the
enclosure dry. Install the supplied VENT-KIT-6x12 approximately 3 to 4 inches from the oor centered on each end of
the replace (See Fig. 16, page 15).
11. Never ll the cavity under and around the valve box with any material, this is air space necessary for ventilation.
12. Only non-combustible materials (i.e. metal studs and cement board) should come in direct contact with any part
of the replace. Underneath area should be non-combustible or a at level combustible surface according to the
clearances specied in this manual. Bend out nailing anges on ends of replace and secure to metal studs.
13. This replace is designed to have glass media covering the burner trough, so the burnertubeis not visible. Media is
not provided. When purchasing media use minimum of ⅜” to ¾” diameter glass ll the burner trough. After the burner
is covered you are permitted to use a larger media on top to cover the remaining burnerpan. DO NOT COVER THE
IGNITION HOOD WITH ANY ROCK OR MEDIA. See Fig. 23 on page 17 for details.
14. Gas lines and ttings must be installed in to the non-combustible structure. All gas connections must be leak tested
before installation of the replace. Leak detection is required before regular use of the replace.
15. Do not use media that will absorb moisture over time and will not release this moisture quickly. Moisture can boil in
this media and can rapidly break apart and cause property damage or personal injury.
16. Never leave any other combustible material on top of the replace. This could cause unsafe operation of this system
and damage to the component that will not be covered under our warranty.
17. It is recommended to wear gloves when moving the replace into position and watch for sharp edges when handling
the replace.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 4
Inlet Gas Supply
Gas Shut-O
Firebox Area
Valve Box
INSTALLATION PRECAUTIONS
B
u
r
ner
Fireplace Side Wall
Pilot Cover
Remove Screw
B
u
r
n
er
p
a
n
CAUTION: BEFORE BEGINNING INSTALLATION CAREFULLY REMOVE THE
GLASS WINDSHIELDS, PARTS BOX AND ANY PACKING MATERIALS FROM
FIREPLACE AND SET ASIDE FOR LATER USE.
FRAMING: After framing is complete, slide the replace into position and secure it with the side nailing anges. Next
install cement board, securing it to the metal studs and replace. The framing provides for a ush t up to the opening of
the replace. DO NOT PROTRUDE INTO THE FIREPLACE OPENING WITH CEMENT BOARD.
GAS LINE: The gas line must have a predetermined location to enable it to be installed. Fig. 1 shows one example of an
inlet gas line with a gas shut off at the replace. This allows a technician to shut the inlet gas supply OFF and remove the
burner for servicing. It is imperative that the ex line from the gas shut-off be long enough to lift out burner pan
for service. Ensure you follow the local and state gas codes per your installation.
RECOMMENDATION: Once the gas line is established it is recommended to remove the burner pan from the rebox
until the replace is in the nal stages and ready for the burner installation. See Burnerpan Removal below.
IMPORTANT: It is permissible to reverse the burner pan in the eld to enable a closer gas line connection if necessary.
BURNERPAN REMOVAL
The burnerpan is secured in the replace with two screws. They are located at the outer edge of the burnerpan on each
corner (See Fig. 2). Remove both screws and lift the burnerpan out of the rebox for gas connection.
Fig.1 Close up view of inlet gas connection with
shut-off valve.
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE
Fireplaces are subjected to many outdoor elements such as
rain, snow, wind, heat or cold. A minimum of 18 square
inches of cross ventilation (2 sides) is required to keep
the components in good working order. Use Fig. 3 as a
guide.
Kalea Bay Outdoor Fireplace
Fig. 2 Removal of burnerpan screws.
Fig 3. Cross ventilation example providing minimum of 18-square
inches per side using Firegear VENT-KIT-6x12 provided.
REV. 1-5-17 Page 5
INSTALLATION PRECAUTIONS
WARNING: Proper clearances from combustible, construction materials must be maintained from all sides, top and
bottom of this appliance. See specications listed on pages 8-10 for a single-sided replace and pages 11-14 for a
see-through replace.
The replace must be installed on a at, level, stable, non-combustible surface. If one layer of ½” cement board is
installed underneath the entire replace, it may sit on a at, level, stable, combustible surface. Install replace according
to the clearances specied in this manual. NOTE: Do not place replace directly on grass, dirt, or rocks this may prevent
proper ventilation. Ensure proper water drainage is also incorporated under the replace enclosure.
IMPORTANT
Installation of Natural or LP gas should be done by a qualied installer, service agency or gas supplier.
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures equal to or less than ½ “psig (3.5kPa)
HARD PIPING TO Fireplace WITHOUT GAS PROXIMITY
NOTE: We recommend using ¾” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for
proper pipe sizing when exceeding 20-feet in length for replaces rated above 100,000 BTU.
1. Turn OFF gas supply system. NOTE: All gas connections (except for brass to brass) require the following. Clean pipe
threads using either a wire brush or steel wool. Apply pipe sealant to the ttings before making any connection. BE
CAREFUL! Ensure all gas connections are snug, but do not over tighten!
2. Extend the gas supply using minimum of ¾” black iron pipe or an approved exible gas line from existing house
supply. This can be accomplished by teeing off or tapping into a gas line connection. Install necessary pipe for the
distance required and then install a manual shut-off valve at the exterior house wall. If pipe is to pass through a
foundation or house wall, make sure to re-seal the area around the pipe with weather sealant.
3. The primary gas shut-off (supplied) will require a ½” male ared tting to enable connection of the stainless steel ex
gas line supplied with the replace (See Fig. 1 page 5).
HIGH ELEVATION INSTALLATION
This appliance is listed for elevations from 0 to 4500 feet in Canada and the U.S. If elevation exceeds 4500 feet it may
be necessary to decrease the input rating by changing the existing burner orice to a smaller size. Input should be
reduced 4% for each 1000 feet beyond the 4500 feet above sea level. Check with your local gas utility for assistance in
determining the proper orice in your location. In some cases the heating value may already be reduced and downsizing
the orice may not be necessary.
PAY CLOSE ATTENTION TO THE FOLLOWING PAGES. THIS FIREPLACE IS SHIPPED AS A
SINGLE-SIDED FIREPLACE, HOWEVER YOU HAVE THE OPTION TO CONVERT IT INTO A
SEE-THROUGH FIREPLACE. READ THE HEADERS CAREFULLY TO ENSURE YOU ARE
FOLLOWING THE CORRECT INSTALLATION.
UNLESS SPECIFIED, ALL OTHER PAGES ARE COMMON FOR BOTH FIREPLACES. REVIEW THE
INSTALLATION PRECAUTIONS BEFORE INSTALLING ANY OF THESE MODELS. IF YOU HAVE
ANY QUESTIONS PLEASE CALL OUR TECHNICAL SERVICE DEPARTMENT AT 1-855-498-8324.
The bottom support n seen in several gure drawings on pages 9 to 14 has pre-punched holes on inside edge to secure
n into place before attaching cement board.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 6
SPECIFICATIONS
NOTE: These replaces come shipped as Natural Gas or Propane Gas models only. There is no conversion kit
available. Ensure you order the specic model for your gas type.
IMPORTANT: It is permissible to reverse the burner pan in the eld to enable a closer gas line connection if necessary.
FRAMING FIREPLACE
Factory
Model:
OFP-L36TFS-N #42 31,000 18,500 #00 OFP-L36TFS-P #52 30,000 19,500 #55
OFP-L48TFS-N #35 43,500 24,500 #00 OFP-L48TFS-P #48 42,500 29,000 #47
OFP-L60TFS-N #31 50,000 36,000 #00 OFP-L60TFS-P #45 50,000 36,000 #37
OFP-L72TFS-N #29 65,000 42,000 #00 OFP-L72TFS-P #42 60,000 45,000 #00
Table 1. Fireplace dimensions and clearances.
Disclaimer: Btu listings are based on 7.0”WC for Natural Gas and 11.0”WC
for Liquid Propane (LP) at the inlet side of gas valve. Flex line size and
proper gas pipe sizing will also affect Btu’s. As a result your Btu’s may vary
slightly from Table 1 specications.
Orice
NG Btu’s
High
NG Btu’s
Low
Low
Rate
Screw
Model:
Factory
Orice
Pressure NG LP
Min. Inlet 5.0” WC 10.5” WC
Max. Inlet 10.5” WC 13.0” WC
Normal Inlet 7.0” WC 11.0” WC
Table 2 Gas Pressures
LP Btu’s
High
LP Btu’s
Low
Low
Rate
Screw
This replace ships from the factory as a single-sided replace with
the option of removing the back panels to convert it into a
see-through replace. Your specic application, single-sided or
see-through will determine how you install and frame this replace.
Carefully read through this manual to understand
Fig. 4 Metal standoffs come mounted in a at position on top of replace from the factory. These
standoffs are not required to be installed if using metal studs for framing. However if combustible wood
studs are installed they must be installed. See drawing above for installation - Remove from top of
replace, bend as shownd in “AFTER” drawing above. Secure into pre-punched holes in top of replace
with 2 screws on each side. Note: Requires (2) standoffs mounted at the front for a single sided replace
or (4) standoffs for a see-through replace installation.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 7
SINGLE-SIDED FIREPLACE
DIMENSIONS, FRAMING
AND CLEARANCES SECTION
This replace comes with several items prepackaged inside the replace
with a box labeled PARTS INSIDE DO NOT DISCARD.
Read the list below the contents:
(1) Transmitter
(1) Battery Pack
(4) AA Batteries
(1) 12-volt Battery
(1) Plastic Junction Box
(1) Cover Plate for Junction Box
(2) Stainless Steel Hoods
(2) Glass Clips
(2) Pilot Covers
(2) 6x12 Black Vents
(12) Black Screws, Nuts & Washers
(1) Installation Manual
(2) Glass Windshields (inside rebox)
NOTE: The Kalea Bay requires a specic amount of media (not supplied)
to cover the burner. See page 17, Table 9 for details.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 8
SINGLE-SIDED FIREPLACE DIMENSIONS & CLEARANCES
FRONT VIEW
TOP VIEW
END VIEW
E
E
C
6”
20”
F
D
A
B
G
Bottom Finish Fin
Hood
I
H
END VIEW
SIDEWALL
CEILING
FLOOR
11½”
END VIEW
12”
18”
TOP OF
FIREPLACE
6”
12”
Non-Combustible
Facing Material
Metal Stand-o
Combustible
Material
2 x 4’s
Combustible
Shelf
Ensure you follow the proper clearances during installation.
Model:
Natural Gas
(NG)
OFP-L36TFS-N OFP-L36TFS-P 40” 36” 37½” 16” 16” 11½” 8¾” 6” 42 ½”
OFP-L48TFS-N OFP-L48TFS-P 52” 48” 37½” 16” 16” 11½” 8¾” 6” 42 ½”
OFP-L60TFS-N OFP-L60TFS-P 64” 60” 37½” 16” 16” 11½” 8¾” 6” 42 ½”
OFP-L72TFS-N OFP-L72TFS-P 76” 72” 37½” 16” 16” 11½” 8¾” 6” 42 ½”
Model:
Propane Gas
(LP)
A
Overall
Length
B
Inside
Opening
C
Overall
Height
D
Opening
Height
E
Overall
Depth
F
Leg
Height
G
Valve
Box
Depth
H
Clearance
To
Combustile
Side Wall
Clearance
Combustible
Ceiling
Table 3 Fireplace dimensions and clearances.
I
To
Fig. 5 Fireplace dimensions; refer to Table 3.
Fig. 6 Single-sided replace clearance to
combustibles (See Table 3)
Kalea Bay Outdoor Fireplace
Fig. 7 Open front replace mantel clearances
REV. 1-5-17 Page 9
A
B
C
Metal Studs Metal Studs
Metal Studs
Metal Studs
*
Metal studs shown in gray.
Bottom Support Fin
Hood
SINGLE-SIDED FRAMING DIMENSIONS WITH METAL STUDS
Model:
Natural Gas (NG)
Model:
Propane Gas (LP)
OFP-L36TFS-N OFP-L36TFS-P
OFP-L48TFS-N OFP-L48TFS-P
OFP-L60TFS-N OFP-L60TFS-P
OFP-L72TFS-N OFP-L72TFS-P
Table 4 Fireplace framing dimensions.
A
Width
40 ½” 37 ¾” 16”
52 ½” 37¾” 16”
64 ½” 37 ¾” 16”
76 ½” 37 ¾” 16”
B
HeightCDepth
NOTE: The standoffs attached to the top of the
replace (secured at) are not required if using all
non-combustible nishing materials.
NOTE: The Kalea Bay
replace is not a
“load bearing” replace. All
nishing materials must be
supported by the surrounding
structure and not rely on the
replace itself.
Fig. 8 Framing dimensions using all non-combustible materials for single-sided replace; refer to Table 4.
SINGLE-SIDED FRAMING DIMENSIONS WITH WOOD STUDS
Model:
Natural Gas (NG)
OFP-L36TFS-N OFP-L36TFS-P
OFP-L48TFS-N OFP-L48TFS-P
OFP-L60TFS-N OFP-L60TFS-P
OFP-L72TFS-N OFP-L72TFS-P
Table 5 Fireplace framing dimensions.
C
Wood Studs
Standos
Wood Studs
Model:
Propane Gas (LP)
A
Width
52” 49½” 28”
64” 49½” 28”
76” 49½” 28”
88” 49½” 28”
B
HeightCDepth
A
Wood Studs Wood Studs
Standos
Wood Studs
B
Hood
Bottom Support Fin
The standoffs are required to be used when
framing with wood studs (See Fig. 4 page 7). The
clearances listed in Table 5 provide the necessary
12-inch clearance to combustibles from the top of
the rebox and 6-inch clearance to each side of the
replace.
NOTE: The Kalea Bay
replace is not a
*Wood studs shown in gray.
“load bearing” replace. All
nishing materials must be
supported by the surrounding
structure and not rely on the
replace itself.
Fig. 9 Framing dimensions using combustible materials for single-sided replace; refer to Table 5.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 10
SEE-THROUGH FIREPLACE
DIMENSIONS AND
CLEARANCES SECTION
This replace comes with several items prepackaged inside the replace
with a box labeled PARTS INSIDE DO NOT DISCARD.
Read the list below the contents:
(1) Transmitter
(1) Battery Pack
(4) AA Batteries
(1) 12-volt Battery
(1) Plastic Junction Box
(1) Cover Plate for Junction Box
(2) Stainless Steel Hoods
(2) Glass Clips
(2) Pilot Covers
(2) 6x12 Black Vents
(12) Black Screws, Nuts & Washers
(1) Installation Manual
(2) Glass Windshields (inside rebox)
NOTE: The Kalea Bay requires a specic amount of media (not supplied)
to cover the burner. See page 17, Table 9 for details.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 11
SEE-THROUGH FIREPLACE INSTALLATION ONLY
If you have determine to install the replace as a see-through model then you will need to remove the rear back panel to
convert it. Before removing the back panel be sure to remove the contents out of the rebox area.
Use the following steps:
Step 1: Look at the back side of the replace. Around the outer perimeter area of the frame or back wall are several
screws to remove (See the shaded area in Fig. 10). CAUTION: Watch for sharp edges. Note: The numbers of screws
to remove will vary with each replace model.
Step 2: The back panel will not be used again in the see-through application. Discard back panel and screws.
BACK VIEW REAR PANEL INSTALLED
Hood
Bottom Finish Fin
BACK VIEW REAR PANEL REMOVED
Fig. 10 Removing back wall to convert to see-through model.
NOTE: When converting to the see-through replace the windsheid clips will need to be installed. See gures 25 and 26
on pages 18 & 19. Two windshield clips are already be installed for a single-sided replace, the other two clips will need
to be installed for a see-through model. The clips will be packaged with the glass windshields. The retaining screws for
the clips are already installed in the replace. Simply remove the screws and reattach with the windshield clips in place
as shown in Fig 26. The see-through replace does require both windshields to be installed for proper operation.
The bottom support n (Fig. 10) has pre-punched holes on inside edge to secure n into place before attaching
cement board and the additional hood will need to be installed.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 12
SEE-THROUGH FIREPLACE DIMENSIONS & CLEARANCES ONLY
FRONT VIEW
TOP VIEW
END VIEW
E
E
C
6”
20”
F
D
A
B
G
Bottom Finish Fin
Hood
I
H
END VIEW
SIDEWALL
CEILING
FLOOR
11½”
This replace ships from the factory as a single sided replace but, by removing the back panels you can convert it
into a see-through replace. Your specic application, single sided verses see-through will determine your installation.
Ensure you follow the proper clearances during installation.
Model:
Natural Gas
(NG)
OFP-L36TFS-N OFP-L36TFS-P 40” 36” 37½” 16” 16” 11½” 8¾” 36” 42 ½”
OFP-L48TFS-N OFP-L48TFS-P 52” 48” 37½” 16” 16” 11½” 8¾” 36” 42 ½”
OFP-L60TFS-N OFP-L60TFS-P 64” 60” 37½” 16” 16” 11½” 8¾” 36” 42 ½”
OFP-L72TFS-N OFP-L72TFS-P 76” 72” 37½” 16” 16” 11½” 8¾” 36” 42 ½”
Model:
Propane Gas
(LP)
A
Overall
Length
B
Inside
Opening
C
Overall
Height
D
Opening
Height
E
Overall
Depth
F
Leg
Height
G
Valve
Box
Depth
H
Clearance
To
Combustile
Side Wall
Clearance
Combustible
Table 6 Fireplace dimensions and clearances.
I
To
Ceiling
Fig. 11 Fireplace dimensions; refer to Table 6
Fig. 12 See-through replace clearance to
combustibles (See Table 6)
Kalea Bay Outdoor Fireplace
Combustible Shelf
Combustible
material
Combustible Shelf
Non-combustible
facing material
Metal studs
Fig. 13 See-through replace mantel clearances
12”
6”
12”
2 x 4’s
6”
18” TYP.
12”
Metal
Stand-Offs
TOP OF
FIREPLACE
END VIEW
REV. 1-5-17 Page 13
A
B
C
Metal Studs Metal Studs
Metal Studs
Metal Studs
*
Metal studs shown in gray.
Bottom Support Fin
Hood
SEE-THROUGH FRAMING DIMENSIONS WITH METAL STUDS
Model:
Natural Gas (NG)
Model:
Propane Gas (LP)
OFP-L36TFS-N OFP-L36TFS-P
OFP-L48TFS-N OFP-L48TFS-P
OFP-L60TFS-N OFP-L60TFS-P
OFP-L72TFS-N OFP-L72TFS-P
Table 7 Fireplace framing dimensions.
A
Width
40 ½” 37 ¾” 16”
52 ½” 37¾” 16”
64 ½” 37 ¾” 16”
76 ½” 37 ¾” 16”
B
HeightCDepth
NOTE: The standoffs attached to the top of the
replace (secured at) are not required if using all
non-combustible nishing materials.
NOTE: The Kalea Bay
replace is not a
“load bearing” replace. All
nishing materials must be
supported by the surrounding
structure and not rely on the
replace itself.
Fig. 14 Framing dimensions using all non-combustible materials for single-sided replace; refer to Table 7.
SEE-THROUGH FRAMING DIMENSIONS WITH WOOD STUDS
Model:
Natural Gas (NG)
OFP-L36TFS-N OFP-L36TFS-P
OFP-L48TFS-N OFP-L48TFS-P
OFP-L60TFS-N OFP-L60TFS-P
OFP-L72TFS-N OFP-L72TFS-P
Table 8 Fireplace framing dimensions.
C
Wood Studs
Standos
Wood Studs
Model:
Propane Gas (LP)
A
Width
52” 49½” 28”
64” 49½” 28”
76” 49½” 28”
88” 49½” 28”
B
HeightCDepth
A
Wood Studs Wood Studs
Standos
Wood Studs
B
Hood
Bottom Support Fin
The standoffs are required to be used when
framing with wood studs (See Fig. 4 page 7). The
clearances listed in Table 5 provide the necessary
12-inch clearance to combustibles from the top of
the rebox and 6-inch clearance to each side of the
replace.
NOTE: The Kalea Bay
replace is not a
*Wood studs shown in gray.
“load bearing” replace. All
nishing materials must be
supported by the surrounding
structure and not rely on the
replace itself.
Fig. 15 Framing dimensions using combustible materials for single-sided replace; refer to Table 8.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 14
Requires 4-AA 1.5V
alkaline batteries
B
a
ttery cove
r slid
es on/off
La
tching
S
olenoid
D
C Moto
r Driv
e
Slide Switch
to Latching
Solenoid
Battery Pack
11½”
Battery
Pack
Vent
FINAL PREPARATION
INSTALLATION OF BATTERY PACK
1. The battery pack should be installed into the either end
of the replace no higher than 11 ½” from the bottom.
A plastic junction box is provided for the installation of
the battery pack (See Figs. 16-18). We recommend a
weather resistance cover to protect battery pack.
2. The wiring extending from the valve box is a 12-foot
special 4-pin connector that connects to the battery
pack and (2) two additional wires with ¼” female
connectors. A complete wiring diagram (Fig. 32) is
located on page 28.
3. Feed all wires into the plastic junction box and
connect special 4-pin plug into back of the battery
pack. Connect ¼” female spade connectors to
solenoid wires matching color, red-to-red and black-to black.
4. Install the (4) AA batteries in to the battery
compartment shown in Fig 17. Double check to ensure
the slide switch is in the Latching Solenoid position on
the battery pack. Then snap cover plate in place as
shown in Fig.18.
Fig.16 Battery pack location in end of replace.
Fig. 17 Slide switch on latching solenoid
5. Reinstall the battery pack into the plastic junction box, line up the two holes in the cover and install white screws
provided. Batteries can be changed or installed by removing the two screws that hold the cover plate battery pack
in place. Remove assembly, slide cover away from the cover plate and install the (4) four AA batteries.
6. Be sure the batteries are installed positive-to-positive and negative-to-negative. If one battery is installed wrong
the system will not operate.
7. Once the replace is installed into the enclosure, the burner and control system should be tested before the
media (rocks/glass) are installed.
INSTALLATION OF BATTERY INTO TRANSMITTER
You have one handheld transmitter and you will need to install the included (12-volt
battery) into the transmitter. On the backside of the transmitter, push the cover away from
the case. Place the battery into the compartment matching positive-to-positive and
negative-to-negative. To ensure the battery is properly installed push any button on the
transmitter and you will see a red LED light at the top of the transmitter glow. The red LED
light above the ON button will only be lit when button is pushed. See Fig. 19.
CAUTION: Handheld transmitter should not be left outside exposed to the elements when
replace is not in use.
Kalea Bay Outdoor Fireplace
Cover Plate
(Rear View)
Battery Pack
Fig. 18 Cover plate installation
12 V Battery
12 V
Fig. 19 Battery installation into remote control.
REV. 1-5-17 Page 15
FINAL PREPARATION
B
u
r
ner
Fireplace Side Wall
Pilot Cover
P
i
l
o
t
C
o
v
e
r
B
u
r
ner
Fireplace Side Wall
B
u
r
n
e
r
E
n
d
When the replace is framed into position and the gas line is run in place it is recommended to burn test the replace
before the nish work is complete. This will ensure proper operation and enables the installer to check for any gas leaks
at the replace.
NOTE: The pilot covers have a plastic lm that must be removed before installing.
Once the burner pan assembly secured into position, the pilot covers must be installed (one on each side). After you
have removed the plastic lm install the pilot covers into the open slot of the each burner end (spacers that center the
burner) with the with the open side of pilot cover facing toward the replace side wall (See Figures 20- 21). NOTE: Even
though there is no pilot on the opposite end the other pilot cover provides combustion air evenly to the burner for
operation.
REMOVE PLASTIC FILM
FROM PILOT COVER
Fig. 20 Installing pilot cover.
Kalea Bay Outdoor Fireplace
Fig. 21 Pilot cover installed.
REV. 1-5-17 Page 16
3/8” - 3/4”
Crushed Glass
Burner
Trough
Fig. 22 Installing media into the replace.
Additional Media Can
Cover Entire Floor
No Media on
Screen Hood
FINAL PREPARATION
Media (Firegear GR glass) is not supplied with the Kalea
Bay Fireplace however it is required to be installed in the
trough area of the burner and optional to ll the entire
burner area. This enables the homeowner to choose their
own color glass. Use the table below to determine the
amount of glass required for your model.
Model # Entire Burnerpan Trough Only
OFP-L36TFS
OFP-L48TFS
OFP-L60TFS
OFP-L72TFS
Table 9 Required media specications
(Entire burnerpan column includes ling the trough)
INSTALLING MEDIA
Install media (Firegear GR glass) into the burner pan.
Ensure the media used is minimum ⅜” to ¾” crushed
glass as a base.
Install the crushed glass into the burner trough (box
surrounding the burner tube). Fill the trough to the top
edge with your crushed glass. Media must stop at the
top edge of the trough. After lling the trough reinstall the
mesh hood overtop of the pilot area. NOTE: In some
cases you may have more media than needed for the
“trough only” applications, depending on the model.
Once the burner trough if lled the remaining inside oor
area of the replace can be covered with rock, matching
glass or Firegear GL glass to blend the entire rebox per
the shaded area in Fig. 23.
IMPORTANT: When lling the remaing re box with
media ensure no media falls down inside the pilot cover
area (Fig. 21, page 16). This is crucial to provide fresh
air to the pilot assembly and pilot covers (Figs. 20-21).
This provides even ow of combustion air on both sides
of the replace.
25# (5 bags) 4# (1 bag)
35# (7 bags) 5# (1 bag)
40# (8 bags) 6# (2 bags)
50# (10 bags) 7# (2 bags)
Fig. 23 Covering remain replace oor permitted
per shaded area.
Kalea Bay Outdoor Fireplace
Crushed Glass
Over Burner
REV. 1-5-17 Page 17
FINAL PREPARATION
GLASS WINDSHIELD
Glass Clips
CAUTION
HOT SURFACE
DO NOT TOUCH
INSTALLING HOOD(S)
The Kalea Bay replace requires hoods to be installed into the upper opening of the rebox. If you are installing a singlesided replace you only install one (1) hood. NOTE: If you are installing a see-through replace a hood is required on
both sides of the replace opening. All models require ve (5) screws to secure the hood to the replace except the
OFP-L72TFS, it uses seven (7) screws to secure the hood.
Fig. 24 shows hole location and installation process for hood installation. The protruding area of the hood is to be angled
downward for proper installation, see Hood Detail below.
Hood Screw Locations
FRONT VIEW
Fig. 24 Installing hood(s) on the replace.
SIDE VIEW
End View
(Deector Facing Downward)
Hood
Hood Detail
Fig. 25 Windshield clips location.
Kalea Bay Outdoor Fireplace
WARNING: During operation of the replace the
glass will get hot! Hot glass will cause burns.
DO NOT TOUCH glass until cooled.
NEVER allow children to touch the glass.
REV. 1-5-17 Page 18
FINAL PREPARATION
1
2
GLASS WINDSHIELD
GLASS WINDSHIELD
Side View
Installing Glass
Side View of
Installed Glass
BURNER PAN ASSEMBLY
WINDSHIELD INSTALLATION
The glass windshield(s) slide into the two clips on each end
of the replace and rest in position if installing for a
single-sided replace (See Fig. 25) for the location. If
you are installing a see-through replace, you will need to
install two additional glass clips (provided) into the opposite
side of the replace in the same location as the existing
clips. Use the two screws installed in the replace side wall
to secure the clips (glass holders). There are two glass
windshields provided to install on each side of the replace.
The glass will rest on the bottom tab of each windshield
clip.
CAUTION: THIS IS TEMPERED GLASS. DO NOT CHIP
GLASS. CHIPPED TEMPERED GLASS CAN BREAK
WITHOUT WARNING.
NOTE: If you are not using the extra windshield provided it
can be used as a replacement part.
INSTALLING WINDSHIELD INTO CLIPS
1. Carefully unpackage the windshield(s).
2. Using gloves carefully lift the windshield into the top
opening (above the clips) of the replace, supporting
the glass at the top and bottom as you handle it.
3. Carefully bring the bottom edge of the glass into the
top area of the windshield clip (See Fig. 26).
4. As the glass enters the clip the bottom edge of the
glass will rest in place on the bottom of the clip.
5. Center glass between clips after installation.
Fig. 26 Installing windshield into clips (glass holders).
PILOT OPERATION
The pilot assembly is located at the end of the burner hidden
underneath a pilot cover. Ensure the pilot ame is passing
through the ignition hole in the burner pan for proper ignition.
Use the Fig. 27 as a guide.
CAUTION: Ensure there is no media in the ignition hole area.
The burner tube gas ignites in this area to light the replace.
Media in this area could cause delayed ignition.
Pilot
(Hidden Underneath)
Ignition
Hole
Fig. 27 Proper pilot ame through ignition hole.
Burner
Tube
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 19
FINAL PREPARATION
FLAME HEIGHT
Proper ame height (Fig. 28) should be at the top edge of glass windshield (peaking above at times) while on HI setting.
The LO setting will be at least half of the height of HI or maybe lower. There will be a slight variance in ame height on
Natural gas verses LP gas models.
Fig. 28 Proper ame height.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 20
Learn Button
AUX
POWER
PEN
MODULE
INSIDE FIRE PIT
METAL BOX
Main Burner Orice
Access Screw
V
A
L
V
E
B
O
X
Pilot Tube
LEARNING ADDITIONAL REMOTES CONTROLS
LEARNING ADDITIONAL REMOTE TO THE MODULE
See www.regrearoutdoors.com for a video showing how
this can be accomplished.
The Kalea Bay replace comes standard with one
remote controlled transmitter. The handheld remote is
shipped with this system are already learned (programmed)
to the module inside the control box. Simply install the
batteries in the battery pack and remote control and press
the ON button of the remote control (See Fig. 19 pg. 15).
Additional transmitters can be learned to this electronic
module; up to a total of three Firegear Outdoors transmitters
are available. Contact Firegear Outdoors to discuss
additional transmitter options or see the accessory page of
this instruction manual.
Learning the new transmitters is simple, but will require
pressing the learn button on the module. You should learn
any new transmitters before the nal installation of the
replace. Follow the steps below:
1. Remove the access screw from the valve box
(See Fig. 29). The cover will slide down exposing
the gas valve and control module.
2. Find the black module attached to the inside of the
control box. Locate the “Learn Button” on the bottom
of the module.
3. Once the Learn button is located, press and release
the button once. You will hear a beep indicating that
the module is ready to receive a transmitter code
(See Fig. 30)
4. Take the transmitter and press the OFF button. You
will hear a series of rapid beeps indicating the
module has accepted the new code.
NOTE: A maximum of three (3) codes can be programmed
to the module. After a total of three (3) codes have been
programmed the memory is full and will not accept any
additional codes. To clear all codes, press and hold the
learn button for 10 seconds. The module will beep three
(3) times indicating the memory is clear of all codes. After
codes have been cleared see Step #3 above to re-learn
transmitter.
Fig. 29 Removing access screw from valve box.
Fig. 30 Learn button location.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 21
OPERATION
CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
SAFETY WARNINGS
1. Never leave the replace unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE ATTEMPTING TO LIGHT FIREPLACE
TURNING ON THE FIREPLACE
1. Ensure you have leak tested the replace before operating. Turn main gas supply ON.
2. Ensure batteries are installed in battery pack and switch is on Latching Solenoid.
3. Press the ON button on the transmitter. You will hear the ignitor probe will begin sparking
for up to 20 seconds and the replace will turn ON.
4. If the replace does not light the module will “beep” one time every second indicating an
ignition error. This is a hard lockout. If this occurs press the OFF button on the remote
control and repeat step 1-3.
5. If replace does not light after second try turn main gas OFF, wait 5 minutes and repeat
steps 1-3.
Fig. 31 Transmitter
NOTE: It may take several cycles of ON/OFF to purge the airow from the gas lines. The pilot ignition will turn OFF after
20 seconds if the burner does not light after which you will need to press transmitter OFF button then back ON to initiate
ignition again.
Flame height can be adjusted HI and LO. After the replace is operating press the handheld transmitter HI or LO.
The replace defaults to the HI setting when initially lighting the replace each time or if attempting to re-light but will
remember the last setting used and change back to that last setting in approximately 5 seconds after lighting.
O
N
O
F
F
H
I
L
O
W
TURNING OFF THE FIREPLACE
1. To turn OFF the replace press the OFF button on the transmitter. Fireplace will turn OFF.
2. After replace has completely cooled off install cover.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 22
Remote/Off
S
I
ADJ.
IPI
POWER
Learn
AUX
Latching Solenoid DC Moror Driv
Requires 4-AA 1.5V
alkaline batteries
Battery cover slides on/off
4
G
l
a
s
s
W
i
n
d
shi
e
l
d
P
i
l
o
t
C
o
v
e
r
KALEA BAY REPLACEMENT PARTS
1
2
3
6
5
9
12
OUT
PILOT ADJ
MAIN
PILOT
IN
Drawings Not to Scale
10
13
7
11
14
15
8
AA Batteries
AA Batteries
AA Batteries
O
F
H
I
L
O
W
AA Batteries
O
N
F
18
e
Slide
Switch
ON
OFF
Control Box
* Not all replacement parts are are depicted in the
drawings above but are listed on pages 24-25.
Kalea Bay Outdoor Fireplace
16
19
24
REV. 1-5-17 Page 23
KALEA BAY REPLACEMENT PARTS LIST
Item
1 36” Stainless Steel Burner Pan Assembly 1 KB36-73200
1 48” Stainless Steel Burner Pan Assembly 1 KB48-74200
1 60” Stainless Steel Burner Pan Assembly 1 KB60-75200
1 72” Stainless Steel Burner Pan Assembly 1 KB72-76200
2 36” Stainless Steel Burner Tube (1¼” diameter x 22 ¼” long) 1 KB36-73028
2 48” Stainless Steel Burner Tube (1¼” diameter x 34 ¼” long) 1 KB48-74028
2 60’ Stainless Steel Burner Tube (1¼” diameter x 46 ¼” long) 1 KB60-75028
2 72” Stainless Steel Burner Tube (1¼” diameter x 56 ¼” long) 1 KB72-76028
3 Bottom Support Fin - Steel Support at Bottom of 36” Fireplace KB36-73114
3 Bottom Support Fin - Steel Support at Bottom of 48” Fireplace KB48-74114
3 Bottom Support Fin - Steel Support at Bottom of 60” Fireplace KB60-75114
3 Bottom Support Fin - Steel Support at Bottom of 72” Fireplace KB72-76114
4 ½” MIP Lock Nut (Brass Mounting Nut) 1 105-8
5 7/8” Flat Washer/Spacer 2 ST3-113-1026
6 1/2” Flex Gas Line (46-inch Length) 1 T-200-9898-46
7 Air Shutter Orice NG (for 36” Natural Gas Models) 1 OAS-NG42
7 Air Shutter Orice NG (for 48” Natural Gas Models) 1 OAS-NG35
7 Air Shutter Orice NG (for 60” Natural Gas Models) 1 OAS-NG31
7 Air Shutter Orice NG (for 72” Natural Gas Models) 1 OAS-NG29
8 Air Shutter Orice LP (for 36” Propane Gas Models) 1 OAS-LP52
8 Air Shutter Orice LP (for 48” Propane Gas Models) 1 OAS-LP48
8 Air Shutter Orice LP (for 60” Propane Gas Models) 1 OAS-LP45
8 Air Shutter Orice LP (for 72” Propane Gas Models) 1 OAS-LP42
9 Electronic IPI Gas Valve with Solenoid 1 AF-4025DSILSS36
10 Pilot Assembly (comes as one complete assembly) 1 PILOTO-23300-206
11 Ignition Module 1 VCS-4000MODTC
12 Tempered Glass Windshield for 36” model (¼” x 8” x 35 ½”) 1 KB36-73120
12 Tempered Glass Windshield for 48” model (¼” x 8” x 47 ½”) 1 KB48-74120
12 Tempered Glass Windshield for 60” model (¼” x 8” x 59 ½”) 1 KB60-75120
12 Tempered Glass Windshield for 72” model (¼” x 8” x 71 ½”) 1 KB72-76120
13 Glass Holder (Windshield Clip) - Right Side 1 KBXX-76119
14 Glass Holder (Windshield Clip) - Left Side 1 KBXX-76124
15 AA Batteries 1.5 Volt (used in battery pack) 4 BATTAA
16 ON/OFF HI/LO Transmitter 1 RCAF-3TX
17 Transmitter Battery (not shown) 1 BATT12VOLT
18 Battery Pack (includes 12-foot 4-Pin, 4-wire harness, cover plate and
12-foot red & black 2-wire harness for solenoid)
19 Bottom End (Used to center burner pan into replace) 2 KBXX-76125
20 Gas Valve 8-Pin Wiring Harness (not shown) 1 AF-40008PIN12WH2
21 Plastic Electrical Gang Box with Tabs (not shown) 1 JUNCTIONBOX
22 ½” NPT Male to ½” Male Flare Fitting (not shown) 1 U1-8D-S
23 ¾” FIP to ½” Male Flare Fitting - burner to flex connector (not shown) 1 46-812
24 Pilot Cover (Sits inside bottom end, item #19) 2 KBXX-76207
Description
Qty.
1 AF-4000BP12
Part Number
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 24
KALEA BAY REPLACEMENT PARTS LIST
Item
25 ½” Coupling 304 Stainless Steel (not shown) 1 S499-8
26 ½” Pipe Nipple 2-inch Length Stainless Steel (not shown) 2 113SS4-D2
27 ½” Pipe Nipple 3-inch Length Stainless Steel (not shown) 1 113SS4-D3
28 ½” Cap 304 Stainless Steel (not shown) 1 S4104-8
29 ½” Tee 304 Stainless Steel (not shown) 1 S4311-8
30 Mesh Screen Cover (not shown) 1 ST3-100-1027
31 Manual Shut-off ½” OD Fare x ½” FIP (not shown) 1 01-487
32 36” Fireplace Hood (protrudes 1” from the top opening) (not shown) 1 KB36-73131
32 48” Fireplace Hood (protrudes 1” from the top opening) (not shown) 1 KB48-74131
32 60” Fireplace Hood (protrudes 1” from the top opening) (not shown) 1 KB60-75131
32 72” Fireplace Hood (protrudes 1” from the top opening) (not shown) 1 KB72-76131
Description
Qty.
Part Number
FIREPLACE MAINTENANCE
1. The replace should be inspected and cleaned before rst use at the beginning of each season by a qualied eld
service person.
2. Any component that is found faulty must be replaced with an approved component.
3. Any tampering or modifying with the replace is dangerous and voids all warranties.
4. During winter months in cold climates and various seasons operation the replace may be affected by weather
conditions. It is recommended to use a weather proof cover overtop for your replace to protect it from humid/rainy
weather conditions when not in use. Heavy rains/downpours could affect the replace operation if not covered; if this
occurs ensure you allow the replace time to dry out before attempting to operate. NOTE: If a combustible type cover
is used over the replace when not in use be sure to remove it before operation to prevent a severe safety hazard.
5. Carbon (soot) may build up on the metal interior during heavy use. Sooting may also occur periodically
under the pilot cover. CAUTION: Unsure replace is cool to touch and gas is turned OFF. To clean, mix several
drops of dishwashing liquid into a bucket of hot water. The dish soap assists in breaking up the soot and removing it
from the metal. 1. Dip a scrubbing sponge into the soapy water and wipe it back and forth over the soot deposits. This
breaks off the majority of the soot from the metallic surface. 2. Spray any remaining soot deposits with a combination
of warm water and white vinegar mixed in a spray bottle in a half-and-half solution. White vinegar is slightly acidic and
this helps break up the soot and cleans the metal effectively. 3. Run a nylon scrub brush against any stubborn soot to
remove it from the metal. Avoid using a metal scrub brush since this can result in scratching. 4. Buff the metal with a
damp rag to remove any remaining soap or vinegar and then dry it with a dry rag.
6. Over time stainless steel parts can discolor when heated, usually a golden or brown hue. This discoloration is normal
and does not affect the performance of the appliance.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 25
Symptom Remedy
Fireplace
Won’t Light
1. Bleed gas line.
2. Ensure all gas lines are turned ON.
3. Ensure there is not too much media overtop the burner, it can inhibit the
gas ow. Too little or no media can also contribute to non-lighting.
4. Check batteries in battery pack. Minimum total voltage to operate should be 5.3 volts.
TROUBLESHOOTING
TROUBLE SHOOTING
ADDITIONAL TROUBLE SHOOTING
No Spark to
Ignite
Continues to
Spark after
Lighting
Low Flame 1. Ensure the base media is at least 1-inch in diameter and top media is no more than 1-inch over
Water in my
Fireplace
Whistling Noises 1. Check media to ensure it is not too tightly packed around the burner tube.
Fireplace Won’t
Stay Lit
1. Visually look at ignitor for any physical damage.
2. Ensure batteries are not installed backwards in battery pack. Check min. voltage of 5.3 volts.
3. Ensure battery in transmitter is not installed backwards and at minimum voltage of 9.0 DCV.
1. Thermocouple out of alignment.
2. Check connection of thermocouple at “S” terminal on control module to ensure it is connected.
top of burner.
2. Ensure all shut-off valves and valve is fully open (See page 5, Fig. 1).
3. Check for spider webs inside burner orice.
1. Excess dust/sand material from media may be blocking the weep holes to relieve water. Remove
all media and unplug weep holes. Clean or install new media free of dust and dirt.
2. Ensure re pit enclosure has proper drainage for water and proper ventilation to dry out.
3. Recommend to purchase a cover/lid (if applicable) to keep excessive water out of the re pit.
2. Ensure a non-whistling ex connector is being used.
1. Check alignment of pilot ame through igntion hole on page 19, Fig. 27.
2. Thermocouple reading should be between 10-20mV. Test at the brass ground lead on gas valve
and the gold lead at “S” terminal on the control module. If no minimum millivolts are maintained
replace the TC.
3. Check continuity of thermocouple. Using a volt meter remove the TC test lead “S” from the
control module and the brass fork terminal from the gas valve. Test for continuity. If no continuity
then replace the TC.
4. Ensure thermocouple is clean and free of any debris. Excessive soot can be an issue.
Low Flame
Height
Sooting 1. Incorrect gas for the replace. Ensure rating label has proper model number for gas being used.
1. Wrong media installed into the burner trough.
2. Too much media installed overtop of the trough (See page 17 for details).
2. Too much media can cause sooting.
3. Wrong media being used. (See page 17 for details).
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 26
TROUBLESHOOTING - MODULE ERROR CODES
ERROR CODES
The VCS-4000MODTC control module has built-in error detection for several common operating fault conditions. When
the control module detects an error, it will emit a series of beeps. The beeping pattern will help to determine the cause of
the operating fault.
Ignition Safety (Protection for Ignition system):
Error Code: One beep every one second.
Description of Fault: Warn users if the pilot is not successfully ignited in 20 seconds.
How to Clear: Press OFF then ON buttons to re-attempt ignition.
What to Check:
1. Ensure gas supply is turned ON.
2. Ensure that the gas line is purged of air. Air is common in the gas line if the appliance has just been installed, has
been disconnected then re-connected to the gas line, or if the appliance has been unused for an extended period
of time.
3. Ensure there is no blockage in the gas line.
4. Ensure batteries in the battery pack are a minimum of 5.3 volts. If not, replace them.
5. Make sure that the ame is properly contacting the thermocouple on the pilot assembly and check for soot
build-up. Clean soot if present.
6. Ensure orange/white leads from module are plugged into the “PILOT” connection on the valve body.
7. Ensure green/white leads from module are plugged into the “MAIN” connection on the valve body.
8. Verify lead from pilot assembly is connected to the “I” terminal on the module.
9. Verify lead from thermocouple is connected to the “S” terminal on the module and thermocouple ground terminal
is connected to ground at the gas valve (See Fig. 32 on page 28).
10. Verify that the black ground lead from the module is connected to a proper ground on the appliance and check for
frayed or pinched wires on the sensor wire lead.
TROUBLE SHOOTING
Sensor Safety (Protection for Flame sensor):
Error Code: 4 Beeps every one second (Constant beeping)
Description of Fault: Warn users the ame sensor detects a ame already present when ignition sequence is initiated.
Also if thermocouple is not given enough time to cool off (30 seconds or more) before re-lighting appliance.
How to Clear: Press OFF then ON buttons to re-attempt normal ignition.
What to Check:
1. Allow thermocouple to cool off minimum of 30 seconds.
2. Check if ame is actually present when valve is turned OFF (if so, replace valve).
3. Check to ensure ground wire from thermocouple and module are connected to gas valve.
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 27
Thermal Safety (Overheat Protection):
OUT
PILOT ADJ
IN
MAIN
PILOT
Battery
Pack
Black (Ground)
Orange
Green
White
2-Brown
White
Black (-)
Red (+)
Black (4-Pin Connector)
Red
Red
Black
Black
Learn AUX
Remote/OFF
VCS-4000MODTC
Module
I
S
Ignitor
Sensor
Thermocouple Ground Wire
Pilot Assembly
Error Code: 4 Beeps every 2 seconds.
Description of Fault: Warn users that the modules internal temperature exceeds 170°F.
How to Clear: Module’s internal temperature must cool to below 160°F and then press ON button.
What to Check:
1. Ensure that there is proper ventilation to the control module.
2. Is module (inside valve box) located in unapproved location, too close to burner?
3. Move to cooler location.
Wireless Remote Transmitter Will Not Operate Appliance
1. Make sure that the transmitter is within the 25-foot operational range of the control module.
2. Ensure batteries in transmitter are fully charged and properly installed.
3. If using the battery pack, ensure batteries are fully charged and properly installed. Also, make sure the battery
pack’s 4-pin connector is securely connected to the battery pack and control module.
4. If using optional AC adapter, ensure that the AC adapter leads are securely attached to “POWER” connection on
the control module. Also, ensure that the AC adapter is connected to a live 120VAC power source.
5. Ensure “Remote/Off” switch on control module is set to “Remote”.
6. Ensure the control module has learned the transmitter’s security code (learning section page 21).
7. Make sure that the remote transmitter is not placed/mounted to a metal surface, which will reduce the operating
range.
8. Make sure that there is not a large metal obstruction between the remote transmitter and the control module.
Ignitor Sparks at Pilot Hood Frequently During Operation
1. The control module will generate a spark at the ignitor electrode to the pilot hood if the system is in the ON
position, but does not does not light; thermocouple may not be hot enough or generating enough millivolts.
2. Make sure that the tip of the thermocouple is clean. Soot buildup will insulate the thermocouple and will not allow
for proper ame sensing.
3. Make sure that wind does not blow the pilot ame out. The pilot hood and the media (rocks, glass, etc.) provides
shielding from the wind. Ensure that the pilot hood and media are properly positioned per the instructions. If wind
is too strong, and the pilot ame can not maintain contact the thermocouple properly, the appliance should not be
operated.
Flame Modulation Will Not Work or Works Backwards
1. Ensure that the black and red leads from the battery pack are securely connected to the red and black leads from
the Hi/Lo latching solenoid located on the valve body (red to red and black to black).
2. Verify that the selector switch on the battery pack is set to LATCHING SOLENOID only.
3. Check functionality with all transmitters to determine if there is an issue with the main control system or an
individual transmitter. If the issue is with an individual transmitter, make sure that the batteries in both the transmit
ter and battery pack are installed properly and fully charged.
Fig. 32 Wiring Diagram
Kalea Bay Outdoor Fireplace
REV. 1-5-17 Page 28
OPTIONAL ACCESSORIES
30 MIN
60 MIN
120 MIN
OFF
The following accessories are available from your local Firegear dealer/distributor.
Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing.
Firegear Outdoors Media
GR-Series (Reective Glass in several
colors)
MODEL: 1322-WT
Wireless wall switch with
ON/OFF/HI/LO
ON
OFF
HI
LO
Model: AF-4000ADP24 (80) optional
7.5VDC transformer (24” leads)
eliminates the use of battery power.
* Requires weather
proof box,
not provided.
MODEL: 1001D-A
Wireless wall switch with
ON/OFF ONLY
LP CONVERSION KIT
THERE IS NO LP CONVERSION KIT
AVAILABLE THESE MODELS. YOU
MUST ORDER THE FIREPLACE
DIRECT FROM THE FACTORY AS
PROPANE.
MODEL: TMR-AF1
4-Button Timer with
30/60/120/OFF Minutes
Home Automation System
Model: AF-4000HAT
Enables the replace to operate with a
home automation device.
FOR TECHNICAL SERVICE, CALL:
Kalea Bay Outdoor Fireplace
Twig Set
Model: 926-930
6 piece Beach Driftwood twisted twig
set.
NOTE: Logs cannot be placed overtop
of burner. They must be placed around
the burner.
(855) 498-8324
Firegear Outdoors
9230 Conservation Way
Fort Wayne, IN 46809
For Sales: (888) 672-8929
WEB SITE: www.regearoutdoors.com
REV. 1-5-17 Page 29
LIMITED WARRANTY
Skytech Products Group (Firegear Outdoors) hereby
warrants to the end user that products will be free from
material and workmanship defects that prevent safe and
correct operation of the product. The warranty
commences from date of sale to the end user for the
following period:
All approved returned defects must be conrmed by our
Technical Service Department. If the defect is conrmed
and we approve the claim, we will replace such parts
without charge. This warranty gives you specic legal
rights, and you may also have other rights, which vary
from state to state.
Consumer/Non-Commercial Applications
Stainless Steel Components 5-Years
Gas Valve, Spark Ignitor &
Electronic Parts
G90 Galvanized Pans 3-Years
Gas Logs 5-Years
Glass Windshield 1-Year
Glass Media 5-Years
Controls 5-Years
RTF Enclosure 5-Years
Lava Rock & Lava Stones No Warranty
2-Years
Commercial Applications
Stainless Steel Components 1-Year
Gas Valve, Spark Ignitor &
Electronic Parts
G90 Galvanized Pans 1-Year
Gas Logs 1-Year
Glass Windshield 1-Year
Glass Media 1-Year
Controls 1-Year
RTF Enclosure 1-Year
Lava Rock & Lava Stones No Warranty
1-Year
End User must provide a bill of sale, canceled check, or
payment record from the end user to verify
purchase date and to establish warranty period. This
Limited Warranty shall be valid and limited to the
original purchaser only.
WARNING: Any modication to the product will void the
warranty.
This Limited Warranty shall be limited to the repair and/
or replacement of parts that have proven to be defective
under normal use and service. Before
returning any parts, contact our Technical Service
Department for a Return Materials Authorization (RMA)
number. All warranty claims must be made by the OEM
/ Distributor / Dealer account on behalf of the end user.
You may contact Technical Service at (855) 498-8324.
Travel, diagnostic cost, service labor to repair the
defect and freight charges on warranty parts to and from
the factory will be responsibility of the owner. We will not
be responsible for labor charges and/or
damage incurred in installation, repair, and
replacement.
This Limited Warranty is voided if not assembled,
installed and operated as intended. This Limited
Warranty does not cover any defects due to accident,
abuse, misuse, alteration, misapplication, vandalism,
improper installation or improper maintenance or
service, removal from the original location or
re-installation into another location, or failure to
perform normal and routine maintenance.
Damage due to severe weather conditions such as hail,
hurricanes, earthquakes, tornadoes, discoloration due
to over-heating, exposure to chemicals (including salt),
either directly or in the atmosphere, or very high
humidity, is not covered by this Limited Warranty.
There are no other express warranties except as set
forth herein. For consumer applications, any
applicable implied warranties of merchantability and
tness are limited in duration to the period of coverage
of this Limited Warranty. Some states do not allow
limitation on how long an implied warranty lasts, so this
limitation may not apply to you.
For Commercial applications, the liability of
Firegear Outdoors is limited to the express terms of this
warranty. We expressly disclaim any and all implied
warranties, including any warranties of tness for a
particular purpose or merchantability.
We are not liable for any special, indirect or
consequential damages. Our maximum liability is
limited to the purchase price of the purchased products.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, so this limitation or
exclusions may not apply to you.
We do not authorize any person or company to
assume for it any other obligation or liability in
connection with the sale, installation, use, removal,
return, or replacement of its equipment; and no such
representations are binding. REV. 3-2-16
NOTES:
Having problems getting the replace to operate? Don’t leave the job site!
We want to help! Call 855.498.8324 for Technical Support
between the hours of 8:00AM to 5:00PM EST.
Text photos to 260.255.5750 or e-mail photos to support@skytechpg.com
BEFORE YOU CALL WE WILL NEED THIS INFORMATION
1. Model Number: ___________________________
2. Serial Number: ___________________________
3. How long is the gas line run? Nat Gas ____ LP Gas ____
4. What size is gas line? _____
5. Inlet Gas Pressure: _____WC
Manifold Gas Pressure: _____ WC
6. What type of media are you using? __________________
7. Review the troubleshooting section in the installation manual.
8. What are the symptoms? Please be prepared to explain.
9. Be prepared to send photos to us when on the phone.
10. Found missing or damaged parts? Let us know ASAP or send photos.
Fireplaces
FPSS 3-30-16
Loading...
