INSTRUCTION MANUAL FOR
12 GAUGE OVER & UNDER
SHOTGUN
INSTRUCTION MANUAL
Thank you very much for your confidence in our products,
and thank you for purchasing our 12 gauge over & under
shotgun, Tiger head Brand.
Tiger Head Brand 12 gauge over & under shotgun is elegant in shape, the mechanical functions are reliable and
the firing accuracy is very good. It is easy to assemble,
disassemble, and maintain.
Our shotgun is manufactured by using high quality steels,
and the barrel is made from special gun barrel steel.
During production strict quality control is exercised and its
quality is ensured.
NOTE: Do not use steel shot in this
gun. The use of steel shot will damage the barrel and will
void the warranty.
12 Gauge Over & Under Shotgun
Main Technical Data
Item Model of 12 ga O&H Shotgun PH12-1
Gauge 12
Barrel length (in) 29½
Chamber length (in) 2¾
Choke over F
Choke Under M
Drop at comb (in) 1½
Drop at heel (in) 2½
2
Type of buttstock Common buttstock w/hard
plastic buttplate
Length of pull (in) 13¾
Engraving on receiver No
Lead Shot Only Yes
SAFETY FIRST
Firearms can be dangerous and can cause serious injury or
death. Proper and safe firearms handling is the responsibility
of anyone who touches or uses a firearm. Safety has to be
the primary consideration of anyone handling a firearm.
When purchasing a firearm, you assume responsibility for its
safe use, storage, and transportation. Particularly, it is critical
that firearms be kept from unauthorized use, and this includes
children. Your responsibility also includes, but is not limited to,
the need to protect yourself and others from injury resulting
from the misuse or abuse of a firearm.
Treat all firearms as if they were loaded.
Always be aware of where the muzzle is pointed.
Carry your firearm in a way that will preclude accidental
injury to yourself or others in the event you should
stumble, fall, or drop the firearm.
Before shooting, make certain the barrel has no
obstructions.
3
Do not allow the firearm or ammunition to be left
unattended. Secure both the firearm and ammunition
from access by unauthorized people, including children.
When shooting, always be certain that the area beyond
the target, including the backstop, is clear and safe.
Also make certain that shots fired present no safety
hazards for yourself or others.
Always use both ear and eye protection when shooting.
Always use factory loaded ammunition designed for
and intended to be used in the firearm you are shoot
ing. It must be the proper caliber and type for your
firearm.
Always understand the proper operation of your
firearm, and never allow the firearm to be used by any
one who does not understand how to use the firearm
properly and safely.
Never pass a firearm to another person unless the
action is open and the firearm is in an unloaded and
safe condition. Never put your finger into the trigger
guard until you are ready to shoot.
When not using the firearm, ensure that it is unloaded.
Store your firearm unloaded and in an area which is
secure from unauthorized access. Furthermore, store
4
12 Gauge Over & Under Shotgun
ammunition separately in an area secure from
unauthorized access.
SAFETY WARNING:
Discharging firearms in poorly ventilated areas, cleaning
firearms or handling ammunition may result in exposure to
lead and other substances known to cause birth defects,
reproductive harm and other serious physical injury. Have adequate ventilation at all times. Wash hands thoroughly after
exposure.
PARTS NOMENCLATURE
The parts nomenclature of the shotgun is as shown in
Fig 1.
1. Over Barrel
2. Under Barrel
3. Receiver
4. Top Lever
5. Safety Button
6. Buttstock
7. Forend
8. Latch
9. Hinge Pin
10. Hinge
11. Right Trigger
12. Left Trigger
5
12 Gauge Over & Under Shotgun
Figure 1:
AMMUNITION
Our over & under shotgun is 12 guage and the chamber
length is 70 mm (2 ¾ in). Use only good quality ammunition in this shotgun (lead shot only).
ASSEMBLY
Prior to assembly, move the top lever to the extreme right
hand position and release (this will cock the shotgun).
Check the gun again to ensure there is no dirt or burrs in
the fitting portions. Coat all metal surface with a good rust
preventative lubricant.
To assemble, ensure that the latch (8) is in the verticle
position (see Fig 2). Grasp the barrel with left hand and
hold receiver with right hand. Move top lever to extreme
right. Ensure that the extractor is fully forward. Slide the
barrel assembly into the receiver. Ensure that the pins on
the extractor fit into the grooves in the receiver. Close
6
1
2
3 4
5
6
7
8
9
10
11
12
12 Gauge Over & Under Shotgun
the action and push the latch fully forward. The shot gun
is now assembled.
7
Extractor
Lug
Hinge Slot
Fig.2 Disassembling Barrel from Receiver
Fig.3 Assembly of Shotgun
12 Gauge Over & Under Shotgun
LOADING & FIRING
When loading your shotgun the muzzle should be pointed
in a safe direction. Grasp the barrel with your left hand
and with the thumb of your right hand move the top lever
to the extreme right. Swing the barrel downward with your
left hand until it cannot be moved, thus the chamber is
opened, the safety button is returned to the safe position.
Check the bores of both barrels to make sure they are not
obstructed. Load shells into the chambers until the extractor catches the rims of shotshells. Hold the buttstock with
your right hand and grasp the barrel with your left hand.
Swing the barrel upward to close the gun. To fire, aim at
the target, push the safety button to the front position and
pull the trigger. The shotgun uses a double trigger to control the firing of shotshells in the over and under barrels
respectively. You can choose to fire the over or under barrel as desired. Pull the right trigger to fire the shell in the
under barrel. Pull the left trigger to fire the shell in the over
barrel. Never pull both triggers to fire the shells in both
barrels simultaneously, otherwise serious accidents may
occur.
8
12 Gauge Over & Under Shotgun
EXTRACTING EMPTY SHOTSHELL
Move the top lever to the right. Swing the barrel to the
loading position. The empty shells will be extracted out for
some length by the extractor, and then
you can take it out with your fingers.
DISASSEMBLY
This shotgun is built to very close tolerances. Use
extreme care when disassembling and re-assembling to
ensure that this shotgun is not damaged.
Before disassembling, ensure your shotgun is unloaded
and pointed in a safe direction. Move the barrel latch
downward to its rear most position. Move the top lever to
the extreme right to open the shotgun. Swing the barrel
down for approximately 15. Ensure the extractor is seated
forward fully. Pull the barrel upward with your left hand,
and press the buttstock downward with your right hand.
Exert force simultaneously with both your hands in opposite directions to release the barrel from the receiver as
shown in Fig 2.
9
12 Gauge Over & Under Shotgun
Figure #2
Figure #3
1.Latch
2. Slot
10
12 Gauge Over & Under Shotgun
MAINTENANCE
Maintenance is required for your shotgun after use or in
storage to prolong the service life of the gun.
After use, first swab the bores with an oil patch or brush
attached to the cleaning rod to remove powder residue
and other dirt. Coat the bores lightly with oil and solvent.
The cleaning rod and brush are shown in Fig 4.
Do not oil the buttstock and forend. The wood may
become deteriorated and deformed. Select the oil in
accordance with the surrounding temperature.
11
Figure #4
12 Gauge Over & Under Shotgun
Distributed by:
Century International Arms, Inc.
P.O. Box 714
St. Albans, Vermont 05478
Tel: 1-800-527-1252
WWW.CENTURYARMS.COM
HS-11998-12gauge
