Finlux 55S6040-T User Manual

55S6040-T

colour television

owner’s manual

Contents

Package Contents .................................................. 3

Features ................................................................. 3

Introduction ............................................................. 4

Preparation ............................................................. 4

Safety Precautions ................................................. 4

Power Source ..................................................... 4

Power Cord ......................................................... 4

Moisture and Water ............................................ 4

Cleaning.............................................................. 4

Ventilation ........................................................... 4

Heat and Flames ................................................ 4

Lightning ............................................................. 4

Replacement Parts ............................................. 4

Servicing ............................................................. 4

Waste Disposal ................................................... 5

Instructions for waste disposal:........................... 5

Information for Users in European Union

Countries ............................................................ 5

Disconnecting the Device ................................... 5

Headphone Volume ............................................ 5

Installation........................................................... 5

LCD Screen ........................................................ 5

Warning .............................................................. 5

Environmental Information ..................................... 6

Repair Information .................................................. 6

Remote Control Handset ........................................ 6

Remote Control Buttons ......................................... 7

LED TV and Operating Buttons .............................. 8

Viewing the Connections - Back Connectors ......... 8

Viewing the Connections - Side Connectors .......... 9

Aerial Connection ................................................. 10

Power Connection ................................................ 10

Switching the TV On/Off ....................................... 10

To Switch the TV On ......................................... 10

To Switch the TV Off ......................................... 10

First Time Installation............................................ 10

Connecting to a DVD Player................................. 12

Connecting the LED TV to a PC ........................... 12

Side HDMI Connection (HDMI 4) ......................... 12

Using Side AV Connectors ................................... 13

Using Other Connectors ....................................... 13

USB Memory Connection ..................................... 13

Connecting to a Wired Network (optional) ............ 15

Connecting to a Wireless Network (Optional)....... 16

Input Selection ...................................................... 17

Basic Operations .................................................. 17

Operation with the Buttons on the TV ............... 17

Volume Setting .............................................. 17

Programme Selection ................................... 17

Viewing Main Menu ....................................... 17

AV Mode ....................................................... 17

Operation with the Remote Control .................. 17

Volume Setting .............................................. 17

Programme Selection (Previous or Next

Programme) .................................................. 17

Programme Selection (Direct Access) .......... 17

Viewing the Electronic Programme Guide (EPG) .... 17

EPG Timeline Menu .......................................... 17

EPG Programme Guide Menu .......................... 18

EPG Now and Next Menu................................. 18

Recording via EPG Screen ............................... 18

Programme Options.......................................... 18

Installation ............................................................ 19

Auto Channel Scan Menu Operation ................ 19

Manual Tuning ..................................................... 19

Analogue Fine Tune.......................................... 20

First Time Installation ........................................ 20

Clear Service List (*) ......................................... 20

Managing Stations: Channel List .......................... 20

Operating the Channel List ............................... 21

Moving a Channel ............................................. 21

Deleting a Channel ........................................... 21

Renaming a Channel ........................................ 21

Locking a Channel ............................................ 21

Managing Stations: Favourites ............................. 21

Button Functions ............................................... 21

Managing Stations: Sorting Channel List ............. 22

On-Screen Information ......................................... 22

Media Playback Using Media Browser ................. 22

Viewing Videos via USB .................................. 23

Viewing Photos via USB ................................... 23

Slideshow Options ............................................ 23

Playing Music via USB ..................................... 24

Media Browser Settings .................................... 24

Timeshift Recording ............................................. 25

Instant Recording ................................................. 25

Watching Recorded Programmes ....................... 26

Changing Image Size: Picture Formats ................ 26

Confi guring Picture Settings ................................. 27

Operating Picture Settings Menu Items ............ 27

Picture Settings Menu Items ............................. 27

PC Picture Settings........................................... 28

Confi guring Sound Settings .................................. 29

Operating Sound Settings Menu Items ............. 29

Sound Settings Menu Items.............................. 29

Confi guring Your TV’s Settings ............................. 29

Operating Settings Menu Items ........................ 29

Settings Menu Items ......................................... 29

Using a Conditional Access Module (not

supplied) ............................................................... 30

Viewing Conditional Access Menu (*) ............... 30

Confi guring Language Preferences ...................... 30

Parental Control.................................................... 31

Parental Settings Menu Operation (*) ............... 31

Timers ................................................................... 32

Setting Sleep Timer .......................................... 32

Setting Programme Timers ............................... 32

Adding a Timer .............................................. 32

Editing a Timer .............................................. 32

Deleting a Timer ............................................ 32

English - 1 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 101_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1 26.12.2011 13:52:0426.12.2011 13:52:04

Customer Helpline 0845 459 5282

Recording Confi guration ....................................... 32

Confi guring Date/Time Settings ............................ 33

Confi guring Source Settings ................................. 33

Confi guring IP Settings ......................................... 34

Wi-Fi Settings (Optional) ...................................... 34

Information ........................................................ 35

Delete Saved Wifi Profi les ................................ 35

Connecting to your Cell Phone via WiFi

(Optional) .......................................................... 35

Confi guring Other Settings ................................... 35

Operation .......................................................... 35

Other Features ..................................................... 36

Digital Teletext ...................................................... 37

Analogue Teletext ................................................. 37

Tips ....................................................................... 38

Appendix A: PC Input Typical Display Modes ....... 39

Appendix B: AV and HDMI Signal Compatibility

(Input Signal Types) .............................................. 40

Appendix C: Supported DVI Resolutions.............. 41

Appendix F: Supported File Formats for USB

Mode..................................................................... 41

Appendix D: Software Upgrade ............................ 42

Manual Software Update .................................. 42

Specifi cations ....................................................... 43

Digital Reception (DVB-T) .................................... 43

Digital Reception (DVB-T2) .................................. 43

Important Instruction ............................................. 44

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 201_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2 26.12.2011 13:52:0526.12.2011 13:52:05

English - 2 -

Package Contents

INTERNET

SCREEN

SUBTITLE

LANG

PRESETS

EPG

TEXT

FAV SLEEP

1

2

ABC DEF

4

5

GHI

JKL MNO

8

7

PQRS

TUV WXYZ

0

SOURCE

MENU

P +

P -

BACK

Y B TN 1M UTO Y B TN 2MUTOMULTIMEDIA

Remote

Control

Note: You should check the contents after opening
your purchase and make sure that every item is
included.

Batteries: 2 X AAA

3

6

9

SWAP

V +

-

V

EXIT

INFO

1 X Video & Audio

Connection Cable

LED TV

Instruction Book

Features

Remote controlled colour LED TV.•

Fully integrated Terrestrial digital TV (DVB-T •
MPEG2) (DVB-T MPEG4) DVB-T2.

• DVB-T2 compliant.

4 HDMI connectors.•

2 USB inputs.•

Programme recording.•

Programme timeshifting.•

10.000 programmes.•

On Screen Display (OSD) menu system.•

2 Scart sockets.•

Teletext, Fastext, TOP text.•

Headphone connection.•

Automatic programming system.•

Forward or backward manual tuning.•

Sleep timer / Child lock.•

Automatic sound mute when no transmission.•

NTSC playback. •

AVL (Automatic Volume Limiting).•

Auto power down.•

PLL (Frequency Search).•

PC input. •

Plug&Play for Windows 98, ME, 2000, XP, Vista, •
Windows 7.

Active Antenna Power.•

• Picture Off function.

100 Hz scanning frequency(Film Detection •
function).

The illustrations and the OSD in this operation •
manual are for explanation purposes and may vary
slightly from the actual operations.

Note: The HDMI connection between PC and TV
may cause radio interference in which case it is
recommended to use VGA (DSUB-15) connection.

English - 3 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 301_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3 26.12.2011 13:52:0526.12.2011 13:52:05

Customer Helpline 0845 459 5282

Introduction

Thank you for choosing this product. This manual will
guide you through the proper operation
of your TV. Before operating the TV, please
read this manual thoroughly.

Please keep this manual in a safe place
for future reference.

This device is intended to receive and
display TV programmes. The different
connection options make an additional expansion of
the reception and display sources possible (receiver,
DVD player, DVD recorder, VCR, PC etc.). This device
is only suitable for dry indoor use. This appliance is
intended solely for private domestic use and may not
be used for industrial and commercial purposes. We
exclude liability in principle, if the device is not used
as intended, or unauthorized modifi cations have been
made. To operate your LED TV in extreme ambient
conditions may cause damage to the device.

Preparation

For ventilation, leave a free space of at least 10 cm
all around the set. To prevent any fault and unsafe
situations, please do not place any objects on top
of the set.

Use this device in moderate climates.

Operating temperature: 0 0C to +40 0C

10 cm

10 cm

10 cm

Safety Precautions

Please read the following recommended safety
precautions carefully.

Power Source

The TV set should be operated only from a 220-240V
AC, 50 Hz outlet. Ensure that you select the correct
voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the
power cord or pinch the cord. Handle the power cord
by the plug. Do not unplug the appliance by pulling
from the power cord and never touch the power cord
with wet hands as this could cause a short circuit or
electric shock. Never make a knot in the cord or tie it
with other cords. The power cords should be placed in
such a way that they are not likely to be stepped on.

Customer Helpline 0845 459 5282

English - 4 -

A damaged power cord can cause fi re or give you an
electric shock. When it is damaged and needs to be
replaced, it should be done by qualifi ed personnel.

Moisture and Water

Do not use this device in a humid and
damp place (avoid the bathroom, the
sink in the kitchen, etc). Do not expose
this device to rain or water, as this may
be dangerous and do not place objects
fi lled with liquids, such as fl ower vases,
on top.

If any solid object or liquid falls into the cabinet, unplug
the TV and have it checked by qualifi ed personnel
before operating it any further.

Cleaning

Before cleaning, unplug the TV set from
the wall outlet. Do not use liquid or aerosol
cleaners. Use a soft, dry cloth.

Ventilation

The slots and openings on the TV set are intended for
ventilation and to ensure reliable operation. To prevent
overheating, these openings must not be blocked or
covered in anyway.

Heat and Flames

The set should not be placed near to
open fl ames and sources of intense heat
such as an electric heater. Ensure that no
open fl ame sources, such as candles, are
placed on top of the TV. Batteries should
not be exposed to excessive heat such as
sunshine, fi re or the like.

Lightning

In case of a storm and lightning or when
going on holiday, disconnect the power
cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specifi ed by the manufacturer or have the
same specifi cations as the original one. Unauthorized
substitutions may result in fi re, electrical shock or
other hazards.

Servicing

Please refer all servicing to qualified
personnel. Do not remove the cover
yourself as this may result in an electric
shock.

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 401_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 4 26.12.2011 13:52:0626.12.2011 13:52:06

Waste Disposal

Instructions for waste disposal:

Packaging and packaging aids are recyclable •
and should principally be recycled. Packaging
materials, such as a foil bag, must be kept away
from children.

Batteries, including those which are heavy metal-•
free, should not be disposed of with household
waste. Please dispose of used batteries in an
environmentally friendly manner. Find out about the
legal regulations which apply in your area.

Don’t try to recharge batteries, there is a danger of •
explosion. Replace batteries only with the same or
equivalent type.

The cold cathode fluorescent lamp in the LED •
PANEL contains a small amount of mercury; please
follow the local laws or regulations for disposal.

Information for Users in European Union
Countries

This symbol on the product or on its
packaging means that your electrical
device should be disposed at the end
of its service life separately from your
household wastes. There are separate
collection systems for recycling in EU.

For more information, please contact the
local authority or the dealer where you
purchased the product.

Disconnecting the Device

The mains plug is used to disconnect the TV set
from the mains and therefore it must remain readily
operable.

Headphone Volume

Excessive sound pressure from earphones
and headphones can cause hearing loss.

Installation

To prevent injury, this device must be securely
attached to the wall in accordance with the installation
instructions when mounted to the wall (if the option
is available).

LCD Screen

The LCD panel is a very high technology product

over 6 million thin fi lm transistors, giving you fi ne

with
picture details. Occasionally, a few non-active pixels
may appear on the screen as a fi xed blue, green or
red point. Please note that this does not affect the
performance of your product.

Warning

Do not leave your TV in standby or operating mode
when you leave your house.

Electrical device not in the hands of children

Never let children use electrical devices unsupervised.
Children cannot always recognize properly any
possible dangers. Batteries / accumulators can be
life threatening when swallowed. Store batteries out
of the reach of small children. In case of swallowing
a battery medical aid has to be sought immediately.
Also keep packaging away from children as there is
a danger of suffocation.

The Standby / On button does not fully switch off this
product. Moreover, the device continues to consume
power in standby mode. In order to separate the
device completely from mains, the mains plug has
to be pulled from the mains socket. Because of
that the device should be set up in a way, that an
unobstructed access to mains socket is guaranteed,
so that in case of emergency the mains plug can be
pulled immediately. During periods of prolonged non­use the TV should be disconnected from the main
power supply.

“HDMI, the HDMI logo and High-Definition •
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.”

The “HD TV 1080p” Logo is a trademark of EICTA.•

The DVB logo is the registered trademark of the •
Digital Video Broadcasting—DVB—project.

English - 5 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 501_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 5 26.12.2011 13:52:0626.12.2011 13:52:06

Customer Helpline 0845 459 5282

Environmental Information

This television is designed to consume less energy to save environment. You not only help to save the •
environment but you can also save money by reducing electricity bills thanks to the energy effi ciency features
of this TV. To reduce energy consumption, you should take the following steps:

You can use the Power Save Mode setting, located in the Picture Settings menu. If you set the Power •
Save Mode as Eco, the TV will switch to energy-saving mode and the luminance level of the TV set will
be decreased to the optimum level. Note that some picture settings will be unavailable when the TV is in
Power Save Mode.

If you set Power Save Mode as Picture off, a message will appear on the screen and backlight will be off •
within three seconds. Press any button on the remote controller to activate the picture again.

When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce •
energy consumption.

Disconnect power when going away for a prolonged period.•

It is highly recommended to activate Power Save Mode setting to reduce your annual power consumption•

Please help us to save the environment by following these steps.•

Repair Information

Please refer all servicing to qualifi ed personnel. Only qualifi ed personnel must repair the TV. Please contact
the dealer where you purchased this TV for further information.

Remote Control Handset

Remove the battery cover located on the back of the remote control by gently pulling backwards from the •
indicated part.

Insert two • AAA/R3 or equivalent type batteries inside. Observe the correct polarity (+/-) when inserting
batteries and replace the battery cover.

Note: Remove the batteries from the remote control when it will not be used for a long period. Otherwise it
can be damaged due to any leak from the batteries.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 601_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 6 26.12.2011 13:52:0626.12.2011 13:52:06

English - 6 -

Remote Control Buttons

No function1.

Play (in Media Browser mode) 2.

Programme recording3.

Fast rewind (in Media Browser mode)4.

No function5.

Mono/Stereo - Dual I-II / Current Language (*) / 6.
Play preview (in Media Browser mode)

Image size 7.

Teletext / Mix8.

Electronic Programme Guide9.

Numeric buttons10.

AV / Source11.

Menu on/off 12.

Programme Down - Page up / Programme Up - 13.
Page down

Back to previous menu 14.

Green button15.

Red button16.

Media Browser17.

My Button 1(**)18.

My Button 2(**)19.

Info / Reveal (in TXT mode)20.

Blue button21.

Yellow button22.

Exit (in DTV mode) / Return / Index page (in 23.
TXT mode)

OK / Select / Hold (in TXT mode) / Channel List24.

Volume up / down25.

Navigation buttons26.

Mute27.

Previous programme / Now (in EPG mode)28.

Sleep timer29.

Favourite mode selection30.

Picture mode selecion / Changes picture mode 31.
(in Media Browser video mode)

Subtitle on-off / TXT subtitle (analogue TV 32.
mode) / Subtitle (in Media Browser mode).

No function33.

Fast forward (in Media Browser mode)34.

Stop (in Media Browser mode)35.

Pause / Timeshift recording36.

Standby37.

Operation LED light38.

INTERNET

SCREEN

EPG

1

4

GHI

7

PQRS

SOURCE

MENU

P+

P-

BACK

ZOOM

SUBTITLE

LANG

TEXT

FAV SLEEP

2

ABC DEF

5

JKL MNO

8

TUV WXYZ

0

REPEAT

ROOT

YB T N1MUTO YBTN2MUTOMULTIMEDIA

PRESETS

3

6

9

SWAP

-V+V

EXIT

TITLE

INFO

(**)USING MY BUTTON 1&2

When on a desired source, channel or link, press
MY BUTTON 1 or 2 for fi ve seconds, until the “MY
BUTTON IS SET” message is displayed on the
screen. This confi rms that the selected MY BUTTON
is now associated with the selected function.

English - 7 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 701_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 7 26.12.2011 13:52:0726.12.2011 13:52:07

Customer Helpline 0845 459 5282

LED TV and Operating Buttons

FRONT and REAR VIEW Control buttons VIEW Control Buttons

Standby/On button1.

TV/AV button2.

Programme Up/Down buttons3.

Volume Up/Down buttons4.

Viewing the Connections - Back Connectors

12

Note: Press “
buttons at the same time to view
main menu.

1 3

” and

EXT 21. inputs or outputs for external devices.

EXT 12. inputs or outputs for external devices. Connect the SCART cable between SCART socket on the

TV and SCART socket on your external device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV
mode.
Note: SCART cable not supplied.

Component Video Inputs (YPbPr)3. are used for connecting component video.
You can connect the component video and audio sockets with a device that has component output.
Connect the component video cables between the COMPONENT VIDEO INPUTS on on the TV and
the component video outputs of your device. While connecting, be sure that the letters on your TV, “Y”,
“Pb”, “Pr” correspond with your device’s connectors.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 801_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 8 26.12.2011 13:52:0726.12.2011 13:52:07

English - 8 -

PC/YPbPr Audio Inputs4. are used for connecting audio signals of a PC or a device that connects to the

TV via YPbPr. Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output
of your PC to enable PC audio. Connect the audio cable between AUDIO INPUTS on the TV and audio
outputs of your device to enable component audio.

Subwoofer Out5. is for connecting an external, active subwoofer to the set to give a much deeper bass
effect. Use an appropriate RCA cable to connect the set to a subwoofer unit.

S/PDIF Digital Out6. outputs digital audio signals of the currently watched source.
Use a digital optic cable to transfer audio signals to a device that has S/PDIF input.

RF Input7. connects to an aerial or cable system.
Note that if you use a decoder or a media recorder, you should connect the aerial cable through the
device to the television with an appropriate antenna cable, as shown in the illustration in the following
pages.

HDMI 3: HDMI Input8.

HDMI 2: HDMI Input9.

HDMI 1: HDMI Input10.
HDMI Inputs are for connecting a device that has an HDMI socket. Your LED TV is capable of

displaying High Defi nition pictures from devices such as a High Defi nition Satellite Receiver or DVD
Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets
can accept either 720p or 1080p (optional) signals. No sound connection is needed for an HDMI to
HDMI connection.

PC Input11. is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC

Ethernet input (for service).12.

Viewing the Connections - Side Connectors

CI Slot is used for inserting a CI card. A CI card allows you to view all the channels 1.
that you subscribe to. For more information, see “Conditional Access” section.

USB Inputs. 2.

Note that programme recording feature is available via these USB inputs. You can
connect external hard disk drives to this input.

Side HDMI Input (HDMI 4) is for connecting a device that has an HDMI socket.3.

Headphone jack is used for connecting an external headphone to the system. 4.
Connect to the HEADPHONE jack to listen to the TV from headphones (optional).

Side audio-video connection5. input is used for connecting video and audio signals
of external devices. To make a video connection, you must use the supplied AV
connection cable for enabling connection. First, plug singular jack of the cable
to the TV’s Side AV socket. Afterwards, insert your video cable’s (not supplied)
connector into the YELLOW input (located on the plural side) of the supplied AV
connection cable. Colours of the connected jacks should match.

USB 1

HDMIUSB 2

To enable audio connection, you must use RED and WHITE inputs of the side AV
connection cable. Afterwards, insert your device’s audio cable’s connectors into
the RED and WHITE jack of the supplied side AV connection cable. Colours of the
connected jacks should match.

S-AV

Note: You should use audio inputs of side AV connection cable (RED & WHITE)
to enable sound connection when connecting a device to your TV by using PC or

COMPONENT VIDEO input.

English - 9 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 901_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 9 26.12.2011 13:52:0826.12.2011 13:52:08

Customer Helpline 0845 459 5282

Aerial Connection

• Connect the aerial TV plug to the AERIAL INPUT

socket located at the rear of the TV.

1 3

Power Connection

IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket.

After unpacking, allow the TV set to reach the •
ambient room temperature before you connect the
set to the mains.

Plug the power cable to the mains socket outlet.•

Switching the TV On/Off

To Switch the TV On

Connect the power cord to the 220-240V AC, 50 •
Hz socket.

Press STANDBY touch button. Then the standby •
LED lights up.

To switch on the TV from standby mode either:•

Press the “•
on the remote control.

Press the • -P/CH or P/CH+ touch button on the TV.
The TV will then switch on.

If you switch on your TV via standby button on the

Note:

remote control, the programme/source that you were watching
last will be reselected.

By either method the TV will switch on.

To Switch the TV Off

Press the “• ” button on the remote control or press
the STANDBY touch button on the TV, so the TV will
switch to standby mode.

To power down the TV completely, unplug the •
power cord from the mains socket.

Note: When the TV is switched to standby mode, the
standby LED can blink to indicate that features such
as Standby Search, Over Air Download or Timer is
active. The LED can also blink when you switch on
the TV from standby mode.

” button, P+ / P- or a numeric button

First Time Installation

IMPORTANT: Ensure that the aerial is connected
and a Common Interface module is not inserted
before switching on the TV for the first time
installation.

Do not insert a common interface module during the
search process.

When the TV is operated for the fi rst time, the •
installation wizard will guide you through the
process. First, the language selection screen will
be displayed:

Use “• ” or “ ” buttons to select your language
and press OK button to set selected language and
continue.

After selecting your language, you will be required •
to make the following settings: Country, Teletext

Language, Scan Encrypted and Active antenna
options.

Note:

Active antenna should normally be turned off for

most UK households.

By pressing “• ” or “ ” button, select the Country
you want to set and press “ ” button to highlight
Teletext Language option. Use “ ” or “ ” button
to select desired Teletext Language.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1001_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 10 26.12.2011 13:52:0926.12.2011 13:52:09

English - 10 -

Press “•

” button after setting Teletext Language
option. Scan Encrypted will be then highlighted. You
can set Scan Encrypted as Yes if you want to scan
coded stations. After selecting the Scan Encrypted,
select Active antenna feature by pressing “ ” or “
” button. Use “ ” or “ ” button to set active antenna
mode as on or off. If an active antenna is connected
to your TV, you can select this option as On (5V).
Antenna power should be Off when standard
antenna is used instead of the active antenna.

You can activate • Store mode option by using “
or “ ” button. If the Store mode is set to “enabled”,
Store mode option will be available in other settings
menu. If it is set to “disabled”, Store mode will not
be available after the First Time Installation.

Press • OK button on the remote control to continue
and the following message will be displayed on the
screen:

To continue please select YES and press OK. To
cancel operation, select NO and press OK.

The example below shows “UK” “England” “North
West” have been selected as the regional options,
after OK is pressed they can only be changed if
“First time installation” is repeated. Received regional
variations from the non selected region/transmitters
will be stored from preset 800.

”

After all the available stations have been stored a
channel list will be shown based on the broadcaster
LCN press OK to accept this channel order and start
viewing or use the Edit functions to change the order
or delete unwanted channels.

Press • OK button to quit channel list and watch TV.

Note: You can press “MENU” button to cancel.

IMPORTANT!

If you are located at a TV regional border or are able
to receive broadcasts from more than one transmitter
the “Choose Region” OSD will be displayed after the
digital channels have been scanned.

To prevent poor quality pictures or unwanted regional
variation from being stored in your main channel list
you MUST! select your preferred regional options for
each level where available, move the cursor to each
option and press the Left/right arrow keys to view the
available regions/transmitters.

English - 11 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1101_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 11 26.12.2011 13:52:0926.12.2011 13:52:09

Customer Helpline 0845 459 5282

Connecting to a DVD Player

If you want to connect a DVD player to your LED TV,
you can use various connections. DVD players may
have different connectors. Please refer to your DVD
player’s instruction book for additional information.
Power off both the TV and the device before making
any connections.

Note: Cables shown in the illustration are not
supplied.

If your DVD player has a HDMI socket, you can •
connect via HDMI. When you connect to the DVD
player as illustrated below, switch to HDMI source.
See, “Input Selection” section.

Use a component video cable to connect video •
input. For enabling audio, use a component audio
cable as illustrated below. When the connection is
made, switch to YPbPr source. See, “Input selection”
section.

You may also connect through the SCART 1 or •
SCART 2. Use a SCART cable as shown below.

Note: These three methods of connection perform the
same function but in different levels of quality. It is not
necessary to connect by all three methods.

Connecting the LED TV to a
PC

For displaying your computer’s screen image on your
LED TV, you can connect your computer to the TV
set. Power off both computer and television before
making any connections. Use 15-pin D-sub display
cable to connect a PC to the LED TV. When the
connection is made, switch to PC source. See “Input
selection”. Set the resolution that suits your viewing
requirements. Resolution information can be found in
the appendix parts.

1 3

Audio inputs of the TV

PC input of the TV

Scart sockets

Component

video

inputs

Component

audio
inputs

DVD Player

HDMI

inputs

PC audio cable

(not supplied)

Audio output of the PC

PC VGA cable
(not supplied)

Monitor output of the PC

Side HDMI Connection (HDMI 4)

The side HDMI is a convenient connection for external
HDMI devices, use an appropriate HDMI cable and
ensure both the TV and external device are switched
off before making the connection. Select HDMI 4 from
the Source list to access this input.

HDMI DEVICE SIDE VIEW

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1201_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 12 26.12.2011 13:52:1026.12.2011 13:52:10

English - 12 -

Using Side AV Connectors

You can connect a range of optional equipment to your
LED TV using side connectors of the TV.

For connecting a camcorder or camera , you should •
use AV socket (side). To do this, you must use the
supplied video/audio connection cable. First, plug
single jack of the cable to the TV’s AV I N socket
(side). Afterwards, insert your camera cable’s (not

supplied) connectors into the plural part of the video/
audio connection cable. Colours of the connected

jacks should match. See illustration below.

Afterwards, you should switch to • Side AV source. See
the section Input selection in the following sections
for more information.

To listen the TV sound from headphones, you •
should connect headphones to your TV by using the

HEADPHONE jack as illustrated above.

Using Other Connectors

You can connect a range of optional equipment
to your LED TV. Possible connections are shown
below. Note that cables shown in the illustration are
not supplied.

For connecting a to a device that has SPDIF support, •
use an appropriate SPDIF cable to enable sound
connection.

SIDE AV

AVConnection

Cable (supplied)

Headphone

External Speakers

A device that

supports

SPDIF signal.

AVCable

(not supplied)

Camera

USB Memory Connection

You can connect a USB hard disk drive or USB •
memory stick to your TV by using the USB inputs
of the TV. This feature allows you to play fi les stored
on a USB drive or record programmes.

2.5” and 3.5” inch (hdd with external power supply) •
external hard disk drives are supported.

To record a programme, you should fi rst connect a •
USB disk to your TV while the TV is switched off.
You should then switch on the TV to enable the
recording feature. Otherwise the recording feature
will not be available.

IMPORTANT !

You should back up your fi les before making any •
connections to the TV set in order to avoid any
possible data loss. Note that the manufacturer
will not be responsible for any file damage or
dataloss.

It is possible that certain types of USB devices (e.g. •
MP3 Players) or USB hard disk drives/memory sticks
may not be compatible with this TV.

IMPORTANT: The TV supports only FAT32 disk
formatting. NTFS format is not supported. If you
connect a USB disk with NTFS format, the TV will ask
you to format the content. See the section, “Format
Disk” in the following pages for more information on
disk formatting.

Note that ALL the data stored on the USB disk will
be lost and then the disk format will be converted to
FAT32 in such a case.

USB Disk Connection

• Plug your USB device to the USB input of the TV
while the TV is switched off.

Note: If you are going to connect a USB hard disk
drive to the TV set, USB connection cable used
between the disk drive and the TV should have a USB
logo and should be as short as possible.

Note: While formatting a USB hard disk that has 1TB
(Tera Byte) or more fi le capacity, you can experience
problems with the formatting process. In such a
case, you should format the disk with your personal
computer and the formatted disk type should be
FAT32.

SIDE VIEW USB MEMORY

English - 13 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1301_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 13 26.12.2011 13:52:1126.12.2011 13:52:11

Customer Helpline 0845 459 5282

CAUTION !

Quickly plugging and unplugging USB devices, •
is a very hazardous operation. Do not repeatedly
quickly plug and unplug the drive. This may cause
physical damage to the USB player or the USB
device itself.

Do not pull out USB device while playing or recording •
a fi le.

Programme Recording

To record a programme, you should fi rst connect a
USB disk to your TV while the TV is switched off.
You should then switch on the TV to enable recording
feature.

IMPORTANT: When using a new USB hard disk drive,
it is recommended that you fi rst format the disk using
your TV’s “Format Disk” option.

To use the recording function a USB 2.0 certifi ed •
device of at least 1GB should be used, If the
connected USB device is not USB 2.0 an error
message will be displayed.

Recorded programmes are saved onto the connected •
USB disk in .TS format (MPEG-2 transport stream).
If desirable, you can back up / copy these saved
recordings into a personal computer.

Note: It is possible that recorded broadcasts in
TS format may not be supported by your media
playback software. In such a case, you should install
an appropriate media playback software to your
computer.

An hour of the recordings stored occupies •
approximately 2 GB of space.

For more information on recording programmes, •
see sections “Instant Recording”, “Timeshifting”,
“Electronic Programme Guide”, “Recordings Library”
or “Recording Timers”.

Recorded programmes are stored in the following •
directory of the connected USB disk: \DVR\RECS.
All recordings are indicated with a number (such
as 4801-000.ts). A text (txt) fi le is created for each
recording. This text fi le includes information such as
broadcaster, programme, and recording time.

If the writing speed of the connected USB disk is •
not suffi cient, recording may fail and the timeshifting
feature may not be available.

Recordings of HD programmes can occupy more •
space on the USB disk depending on the broadcast’s
resolution. For this reason it is recommended
to use USB hard disk drives for recording HD
programmes.

Do not unplug the USB/HDD during the recording. •
This may harm the connected USB/HDD.

Only two partitions on a HDD unit can be •
supported.

Some stream packets may not be recorded because •
of signal problems, so sometimes video may freeze
during playback.

Record, Play, Pause, Display (for PlayListDialog) •
keys cannot be used when teletext is ON. If a
recording starts from timer when teletext is ON,
teletext is automatically turned off. Also teletext
usage is disabled when there is ongoing recording
or playback.

Note: If the recording time of an event is longer than
the memory capacity, the following message will
appear on the screen: “There is not enough space for
‘event’ but it will be recorded until the drive is full”.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1401_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 14 26.12.2011 13:52:1226.12.2011 13:52:12

English - 14 -

Connecting to a Wired Network (optional)

For connecting to a wired LAN network, you should perform the following steps:

Connect a broadband ISP connection ethernet cable to the ETHERNET INPUT of your modem.•

Ensure that Nero Media Home software is installed to your PC. (for DLNA function) •

Afterwards, you should connect your PC to the one of your modem’s LAN connectors (e.g. LAN 1) by using •
a proper LAN cable.

Use another LAN output of your modem (e.g. LAN 2) to enable the connection to your TV. You can add •
your TV to your LAN by connecting the LAN port at the rear of your TV to your modem’s LAN connector as

illustrated below.

Broadband ISP
Connection

PC with Nero
Media Home
software installed

Lan(Ethernet cable)

Rear of TV

You might be able to connect your TV to your LAN network depending on your network’s confi guration. In •
such a case, use an ethernet cable to connect your TV directly to the network wall outlet.

The modem port
on the wall

Rear of TV

English - 15 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1501_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 15 26.12.2011 13:52:1226.12.2011 13:52:12

Customer Helpline 0845 459 5282

Connecting to a Wireless Network (Optional)

IMPORTANT: “Veezy 100” USB dongle is required to use wireless network feature.

To use your TV with your wireless network, you need a “Veezy 100” Wireless USB dongle. To make your
modem’ s SSID visible, you should change your SSID settings via modem’s software. The TV cannot connect
to the networks with hidden SSID.

For connecting to a wireless LAN network, you should perform the following steps:

Connect broadband ISP connection ethernet cable to the ETHERNET INPUT of your modem.•

Ensure that Nero Media Home software is installed to your PC. (for DLNA function)•

Afterwards, you should connect wireless adaptor to one of the USB inputs of the TV.•

To confi gure wireless settings please refer Network Settings section in Settings menu.

Broadband ISP
Connection

PC with Nero
Media Home
software installed

USB Inputs (Side of the TV)

Wireless Lan
Adaptor

A Wireless-N router (IEEE 802.11a/b/g/n) with simultaneous 2.4 and 5 GHz bands designed to increase •
bandwidth. Optimized for smoother and faster HD video streaming, file transfers, and wireless gaming.

Use LAN connection for quicker file sharing between other devices like computers.•

The frequency and channel differ depending on the area.•

The transmission speed differs depending on the distance and number of obstructions between the •
transmission products, the configuration of these products, the radio wave conditions, the line traffic, and
the products that you use. The transmission may also be cut off or get disconnected depending on the radio
wave conditions DECT phones, or any other WiFi 11b appliances. The standard values of the transmission
speed are the theoretical maximum values for the wireless standards. They are not the actual speeds of
data transmission.

The location where the transmission is most effective differs depending on the usage environment.•

Wireless LAN adaptor should be connected directly to the TV’s USB port. USB hubs are not supported.•

To configure wireless settings please refer wifi section in Settings menu.•

It is recommended that you should use IEEE 802.11 a/b/g/n modem in order to avoid any possible problems •
while viewing HD videos.

Use the other usb input, if you experience problems with audio/video performance.•

You must change your modem’s SSID when there are any other modems around with the same SSID. You •
can encounter connection problems otherwise. Use wired connection instead if you experience problems
with wireless connection.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1601_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 16 26.12.2011 13:52:1226.12.2011 13:52:12

English - 16 -

Input Selection

Once you have connected external systems to
your TV, you can switch to different input sources.
Press the “SOURCE” button on your remote control
consecutively for directly changing sources.

You can operate your TV using both the remote control
and onset buttons.

Basic Operations

Operation with the Buttons on the TV

Volume Setting

Press “• ” button to decrease volume or
button to increase volume, so a volume level scale
(slider) will be displayed on the screen.

Programme Selection

Press “• P/CH +” button to select the next programme or
“P/CH -” button to select the previous programme.

Viewing Main Menu

Press the “• V+”/”V-” button at the same time to view
main menu. In the Main menu select the sub-menu
using “AV” button and set the sub-menu using “

” or “ ” buttons. To learn the usage of

the menus, refer to the menu system sections.

AV Mode

Press the “• AV” button in the control panel on the TV
to switch between AV modes.

Operation with the Remote Control

The remote control of your TV is designed to control •
all the functions of the model you selected. The
functions will be described in accordance with the
menu system of your TV.

Volume Setting

Press “• V ” button to increase the volume. Press “V

” button to decrease the volume. A volume level

scale (slider) will be displayed on the screen.

Programme Selection (Previous or Next
Programme)

Press “• CH ” button to select the previous
programme.

Press “• CH
programme.

” button to select the next

Programme Selection (Direct Access)

The side HDMI is convenient connection for external •
HDMI devices, use an appropriate HDMI cable and
ensure both the TV and external device are switched
off before making the connection. Select HDMI 4
from the Source list to access this input.

Note: If the background is transparent, on screen texts
will be slightly transparent as well.

Viewing the Electronic
Programme Guide (EPG)

You can view the Electronic Programme Guide (EPG)
to view information about available programmes. To
view the EPG menu please press EPG button on the
remote control.

Press “•
channels.

Press “•
programme list.

EPG• menu displays available information on all
channels.

Please note that event information is updated •
automatically. If there are no event information
data available for channels, EPG will be displayed
with blanks.

EPG Timeline Menu

Red button (Prev Day): Displays the programmes

of previous day.

Green button (Next day): Displays the programmes
of the next day.

”/“ ” buttons to navigate through

”/“ ” buttons to navigate through the

English - 17 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1701_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 17 26.12.2011 13:52:1226.12.2011 13:52:12

Customer Helpline 0845 459 5282

Yellow button (Zoom): Expands programme

information.

Blue button (Filter): Views fi ltering options.

INFO (Event Details): Displays the programmes in

detail.

Numeric buttons (Jump): Jumps to the preferred
channel directly via numeric buttons.

OK (Options): views/records or sets timer for future
programs.

Text (Search): Displays “Guide Search” menu.

SUBTTL: Press SUBTITLE button to view Select

Genre menu. Using this feature, you can search the
programme guide database in accordance with the
genre. Info available in the programme guide will
be searched and results matching your criteria will
be listed.

SWAP : Shows the current programme.

(RECORD): the TV will start to record the

selected progamme. You can press again to stop
the recording.

EPG Programme Guide Menu

Red button (Prev Time Slice): Displays the

programmes of previous time slice.

Green button (Next Time Slice): Displays the
programmes of the next time slice.

Yellow button (Prev Day): Displays the programmes
of previous day.

Blue button (Next day): Displays the programmes
of the next day.

Text button (Filter): Views fi ltering options.

Numeric buttons (Jump): Jumps to the preferred

channel directly via numeric buttons.

OK (Options): views/records or sets timer for future
programs.

INFO (Event Details): Displays the programmes in
detail.

(RECORD): the TV will start to record the

selected progamme. You can press again to stop
the recording.

EPG Now and Next Menu

OK (Options): views/records or sets timer for future

programs.

INFO (Event Details): Displays the programmes in
detail.

Green button: Programme schedule will be listed

Yellow button: Display EPG data in accordance with
timeline schedule

Blue button (Filter): Views fi ltering options.

(RECORD): the TV will start to record the
selected progamme. You can press again to stop
the recording.

Recording via EPG Screen

IMPORTANT: To record a programme, you should

fi rst connect a USB disk to your TV while the TV is
switched off. You should then switch on the TV to
enable recording feature. Otherwise, recording feature
will not be available.

(RECORD): the TV will start to record the
selected progamme. You can press again to stop
the recording.

Note: Switching to a different broadcast or source is
not available during the recording.

/ : Page left / Page right.

Programme Options

In EPG menu, press the OK button to enter the “Event
Options” menu.

Select Channel

In EPG menu, using this option, you can switch to the
selected channel.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1801_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 18 26.12.2011 13:52:1326.12.2011 13:52:13

English - 18 -

Record / Delete Record Timer

IMPORTANT: To record a programme, you should

fi rst connect a USB disk to your TV while the TV is
switched off. You should then switch on the TV to
enable the recording feature. Otherwise, the recording
feature will not be available.

After you have selected a programme in EPG menu, •
press the OK button and and Options screen will
be displayed. Select “Record” option and press the
OK button. After this operation, a recording becomes
set to the selected programme.

To cancel an already set recording, highlight that •
programme and press the OK button and select
the option “Delete Rec. Timer”. The recording will
be cancelled.

Note: You cannot switch to any other channel or
source while there is an active recording on the
current channel.

Set Timer / Delete Timer

After you have selected a programme in EPG menu,
press the OK button and and Options screen will
be displayed. Select “Set Timer on Event” option
and press OK button. You can set a timer for future
programmes.

To cancel an already set reminder, highlight that
programme and press the OK button. Then select
“Delete Timer” option. The timer will be cancelled.

Note: It is not possible to record or set timer for two or
more individual events at the same time interval.

Installation

HINT: Auto tuning feature will help you to retune the TV
set in order to store new services or stations.

Press “MENU” button on the remote control and
select Installation by using “
OK button and the following menu screen will be
displayed.

” or “ ” button. Press

Auto Channel Scan Menu Operation

Digital Aerial: Searches and stores aerial DVB
stations.

Analogue: Searches and stores analogue stations.

Digital & Analogue: Searches and stores both

analogue and aerial DVB stations.

After auto channel scan type is set and selected •
and confi rmed, installation process will start and
progress bar will move along. Press “MENU” button
to cancel process. In such a case, located channels
are not stored.

Manual Tuning

HINT: This feature can be used for direct broadcast
entry.

Select Manual Channel Scan from the Installation
menu by using “
options screen will be displayed.

Select the desired • Search Type using “

” button. Manual search options will change
accordingly. Use “ ”/“ ” button to highlight an item
and then press “ ” or “ ” button to set an option.
You can press “MENU” button to cancel.

Digital Manual Search

”/“ ” and OK buttons. Manual Scan

” or “

In manual channel scan, the number of the multiplex
or frequency are entered manually and only that
multiplex or frequency are searched for the channels.
After selecting search type as Digital, you can enter
the multiplex or frequency number using the numeric

Select Automatic Channel Scan (Retune) by using “
”/“ ” button and press OK button. Automatic Channel
Scan (Retune) options will be displayed. You can
select options by using “ ”/“ ” and OK buttons.

English - 19 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 1901_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 19 26.12.2011 13:52:1326.12.2011 13:52:13

buttons and press OK button to search.

Customer Helpline 0845 459 5282

Analogue Manual Search

Clear Service List (*)

(*) This setting is visible only when the Country option
is set to Denmark, Sweden, Norway or Finland.

Use this setting to clear channels stored. Press “
” or “ ” button to select Clear Service List and then
press OK. The following OSD will be displayed on
the screen:

After selecting search type as analogue, you can use
“ ”/“ ” button to highlight an item and then press “
” or “ ” button to set an option.

Enter the channel number or frequency using the
numeric buttons. You can then press OK button
to search. When the channel is located, any new
channels that are not on the list will be stored.

Analogue Fine Tune

Select • Analogue Fine Tune from the Installation
menu by using “ ” or “ ” and OK buttons.

Analogue Fine Tune screen will be displayed.
Analogue Fine Tune feature will not be available if

there are no analog channels, digital channels and
external sources d.

Press • OK button to proceed. Use “
to set Fine Tune. When fi nished, press OK button
again.

” or “ ” button

First Time Installation

If you want to delete all channels and settings please
select First Time Installation and press OK. The
TV’s memory will be deleted and installation progress
starts.

Select YES and press OK to continue or select NO
and press OK button to cancel.

Managing Stations: Channel List

The TV sorts all stored stations in the Channel List.
You can edit this channel list, set favourites or set
active stations to be listed by using the Channel List
options.

Press “• MENU” button to view main menu. Select
Channel List item by using “
OK to view menu contents.

Select Edit Channel List to manage all stored
channels. Use “ ” or “ ” and OK buttons to select
Edit Channel List.

” or “ ” button. Press

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2001_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 20 26.12.2011 13:52:1426.12.2011 13:52:14

English - 20 -

Operating the Channel List

Press “• ” or “ ” button to select the channel that
will be processed. Press “ ” or “ ” button to select
a function on Channel List menu.

Use • P+/P- buttons to move page up or down.

Press • BLUE button to view fi ltering options.

Press “• MENU” button to exit.

Moving a Channel

First select the desired channel. Select Move option •
in the channel list and press OK button.

Edit Number screen will be displayed. Enter the •
desired channel number by using the numeric
buttons on the remote control. If there is a previously
stored channel on that number, a warning screen
will be displayed. Select Yes if you want to move the
channel and press OK.

Press • OK button to process. Selected channel is
now moved.

Deleting a Channel

You can press GREEN button to tag/untag all
channels; YELLOW button to tag/untag channel.

Select the channel that you want to delete and select •
Delete option. Press OK button to continue.

A warning screen will appear. Select • YES to delete,
select No to cancel. Press OK button to continue.

Renaming a Channel

Select the channel that you want to rename and •
select Edit Name option. Press OK button to
continue.

Pressing “•
next character. Pressing “ ” or “ ” button toggles
the current character, i.e., ‘b’ character becomes ‘a’
by “ ” and ‘c’ by “ ”. Pressing the numeric buttons
‘0...9’ replaces the highlighted character with the
characters printed above the button one by one as
the button is pressed.

When fi nished, press • OK button to save. Press
“MENU” to cancel.

” or “ ” button moves to the previous/

Locking a Channel

You can press GREEN button to tag/untag all
channels; YELLOW button to tag/untag a single
channel.

Select the channel that you want to lock and select •
Lock option. Press OK button to continue.

You will be asked to enter parental control PIN. •
Default PIN is set as 0000. Enter the PIN number.

Press • OK button when the desired channel is
highlighted to lock/unlock the channel. Lock symbol
will be displayed next to the selected channel.

Managing Stations: Favourites

You can create a list of favourite programmes.

Press “• MENU” button to view main menu. Select
Channel List item by using “

OK to view menu contents.

Select • Favourites to manage favourite list. Use “
”/“ ” and OK buttons to select Favourites.

You can set various channels as favourites so that •
only the favourite channels are navigated.

Select a channel by using “• ” or “ ” button. Press
OK button to add selected channel to favourites list.
Press OK button again to remove.

Button Functions

OK• : Add/remove a station.

YELLOW• : Tag/untag a channel.

GREEN• : Tag/untag all channels.

BLUE• : Displays fi ltering options.

” or “ ” button. Press

English - 21 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2101_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 21 26.12.2011 13:52:1426.12.2011 13:52:14

Customer Helpline 0845 459 5282

Managing Stations: Sorting
Channel List

You can select broadcasts to be listed in the channel
list. To display specifi c types of broadcast, you should
use Active Channel List setting.

Select Active Channel List from the Channel list
menu by using “
to continue.

” or “ ” button. Press OK button

Media Playback Using Media
Browser

If the USB stick is not recognized after power off/on
or First Time Installation, fi rst, plug the USB device
out and power off/on the TV set. Plug the USB device
in again.

To display Media Browser window, press either
“MENU” button on the remote control and then select
Media Browser by pressing “
OK button to continue. Media Browser menu options
will be displayed.

Also, when you insert a USB device, the media
browser screen will be displayed automatically:

” or “ ” button. Press

You can select a broadcast type option from the list
by using “

” /“ ” and OK buttons.

On-Screen Information

You can press “INFO” button to display on-screen
information. Details of the station and current
programme will be displayed on the information
banner.

The information banner gives information on the
channel selected and the programmes on it. The name
of the channel is displayed, along with its channel
list number.

Hint: Not all channels broadcast the programme
data. If the name and time of the programme are not
available, then information banner will be displayed
with blanks.

If the selected channel is locked, you must enter the
correct four-digit numeric code to view the channel
(default code is 0000). “Enter PIN” will be displayed
on the screen in such a case:

Customer Helpline 0845 459 5282

English - 22 -

You can play music, picture and video fi les from the
connected USB memory stick. Use “ ” or “ ” button
to select Videos, Photos, Music or Settings.

When you have selected the desired media type
Videos, Photos or Music the USB device will be
scanned for all matching media, this may take several
minutes depending on the device size and number of
fi les contained within. During the scanning process
“Please wait…” will be displayed along with an
animated logo, please do not remove the USB device
during this time. The use of large USB storage devices
containing mixed media and many sub directories
levels may cause mis-operation of the media player
and the TV may require switching off to restore normal
operation.

You can connect two USB devices to your TV. If both
USB devices include music, picture or video fi les, USB
selection OSD will be displayed on the screen. The
fi rst USB device connected to the TV will be named
as USB Drive1.

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2201_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 22 26.12.2011 13:52:1426.12.2011 13:52:14

Select a device by using “ ” or “ ” button and press
OK.

Viewing Videos via USB

When you select Videos from the main options,
available video fi les will be fi ltered and listed on this
screen. You can use “ ” or “ ” button to select a video
fi le and press OK button to play a video. If you select
a subtitle fi le and press OK button, you can select or
deselect that subtitle fi le. The following menu will be
displayed while playing a video fi le:

Play ( button): Starts the video playback.

Stop (

Pause (

Rewind (

Forward ( button): Goes forward.

Subtitle/Audio (LANG. button): Sets subtitle/

Audio.

Yellow: Opens subtitle time correction menu

button): Stops the video playback.

button): Pause the video playback.

button): Goes backward.

Press RETURN button to switch back to previous
menu.

Viewing Photos via USB

When you select Photos from the main options,
available image fi les will be fi ltered and listed on this
screen.

Jump (Numeric buttons): Jump to selected fi le using
the numeric buttons.

OK: Views the selected picture in full screen.

Slideshow (

button): Starts the slideshow using

all images.

RED: Sorts fi les by date.

GREEN: Views images in thumbnails.

BLUE: Switch between music,photo,video and all

YELLOW: Change view style

Slideshow Options

Pause ( button) : Pauses the slideshow.

Continue (

Previous/Next (Left/Right buttons): Jumps to

previous or next fi le on slideshow.

button) : Continues the slideshow.

English - 23 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2301_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 23 26.12.2011 13:52:1526.12.2011 13:52:15

Customer Helpline 0845 459 5282

Rotate (Up/Down buttons): Rotates the image using

up/down buttons.

Loop/Shuffl e (GREEN button): Press once to disable
Loop. Press again to disable both Loop and Shuffl e.
Press once more to enable only Shuffl e. Press again
to enable all. You can follow the disabled functions
with the change of the icons.

BACK: Back to fi le list.

INFO: Displays help screen.

Playing Music via USB

When you select Music from the main options,
available audio fi les will be fi ltered and listed on this

screen.

0..9 (Jump): When you press a digit button displays
textual fi le search.

Play This (OK button) : Plays the selected fi le.

button) : Plays all media fi les starting with

Play (

the selected one.

Stop (

Pause (

Previous/Next (Left/Right buttons): Jumps to

previous or next fi le to play.

FAV: Sorts fi les by Title, Artist or Album.

INFO: Changes fi lter options.

Loop/Shuffl e (BLUE button): Press once to disable

Loop. Press again to disable both Loop and Shuffl e.
Press once more to enable only Shuffl e. Press again
to enable all. You can follow the disabled functions
with the change of the icons.

button): Stops playback.

button): Pauses the selected playback.

Media Browser Settings

You can set your Media Browser preferences by
using the Settings dialog. Press “ ” or “ ” button to
highlight an item and use “ ” or “ ” button to set.

View Style: Sets default browsing mode.

Slide Show Interval: Sets slide show interval time.

Show Subtitle: Sets subtitle enabling preference.

Subtitle Language: Sets supported subtitle

language.

Subtitle Position: Sets subtitle position as up or
down.

Subtitle Font Size: Sets subtitle font size (max.
54pt).

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2401_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 24 26.12.2011 13:52:1526.12.2011 13:52:15

English - 24 -

Timeshift Recording

IMPORTANT: To record a programme, you should
fi rst connect a USB disk to your TV while the TV is
switched off. You should then switch on the TV to
enable the recording feature. Otherwise, the recording
feature will not be available.

• Press
for switching to timeshifting mode.

• In timeshifting mode, the programme is paused and
simultaneously recorded to the connected USB disk
(*). Press
programme from the stopped moment.

• This playback is performed in x1 playback speed.
You will see the timeshift gap between the real and
the timeshifted programme in the info bar.

• Use
forward or backward on timeshift playback. When
the timeshift is reached, timeshifting mode will be
quitted and you will switch back to watching normal
broadcast.

• Press

(*) Continuous time shift recording’s duration depends
on your connected USB disk’s fi le size and defi ned
Max. Timeshift in the Recordings Confi guration menu.
See the section, “Recordings” for more information on
setting Max. Timeshift.

Note: Switching to a different broadcast or source;
and viewing the main menu are not available during
the timeshifting.

(PAUSE) button while watching a broadcast

(PLAY) button again to watch the paused

/ (PREVIOUS/NEXT) buttons to move

(STOP) button to quit timeshifting mode.

Instant Recording

IMPORTANT: To record a programme, you should

fi rst connect a USB disk to your TV while the TV is
switched off. You should then switch on the TV to
enable the recording feature. Otherwise, the recording
feature will not be available.

• Press
event instantly while watching a programme. The
following OSD appears on the screen:

• Record OSD will then be displayed for a short time
and the current event will be recorded.

• You can press
control again to record the next event on the EPG. In
this case, OSD will display the programmed events
for recording.

Press (STOP) button to cancel instant recording.
The following OSD will be displayed:

(RECORD) button to start recording an

(RECORD) button on the remote

Select Yes by using “ ” or “ ” / OK buttons to cancel
instant recording.

Note: Switching to a different broadcast or source;
and viewing Media Browser are not available during
the recording.

Note: If the recording time of the event is longer than
the memory capacity, following message will appear
on the screen: “There is not enough space for ‘event’
but it will be recorded until the drive is full”.

English - 25 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2501_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 25 26.12.2011 13:52:1526.12.2011 13:52:15

Customer Helpline 0845 459 5282

Watching Recorded
Programmes

In the main menu, use “ ” or “ ” buttons to select
Media Browser. Highlight Recordings Library item by
using “ ” or “ ” button and press OK button to enter.

Recordings Library will then be displayed.

IMPORTANT: To view recordings library, you should
fi rst connect a USB disk to your TV while the TV is
switched off. You should then switch on the TV to
enable the recording feature. Otherwise, the recording
feature will not be available.

Select a recorded item from the list (if previously
recorded) by using “ ” / “ ” button. Press OK button
to view Play Options. Select an option by using “ ”
/ “ ” or OK buttons.

Changing Image Size: Picture
Formats

Programmes can be watched in different picture •
formats, depending on the transmission received.

You can change the aspect ratio (image size) of •
the TV for viewing the picture in different zoom
modes.

Press “• SCREEN” button repeatedly to change
the image size. Available zoom modes are listed
below.

Auto

When AUTO is selected, the aspect ratio of the •
screen is adjusted by

the 8th pin of scart connector in scart mode•

the information provided by the HDMI source •
device in HDMI mode.

The format being displayed in AUTO mode is •
completely independent of WSS information which
could be included in the broadcast signal or the
signal from an external device.

16:9

This uniformly stretches the left and right sides of a
normal picture (4:3 aspect ratio) to fi ll the wide TV
screen.

Available playback options:

• Play from start: Plays the recording from the
beginning.

• Resume: Recommences the recordings.

• Play from offset: Specifi es a playing point.

Note: Viewing main menu and menu items will not be
available during the playback.

Press
to return to Recordings Library.

Slow Forward

If you press
recorded programmes, slow forward feature will be
available. You can use button to slow forward.
Pressing button consecutively will change slow
forwarding speed.

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2601_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 26 26.12.2011 13:52:1626.12.2011 13:52:16

(STOP) button to stop a playback and return

(PAUSE) button while watching

Customer Helpline 0845 459 5282

English - 26 -

For 16:9 aspect ratio pictures that have been •
squeezed into a normal picture (4:3 aspect ratio),
use the 16:9 mode to restore the picture to its
original shape.

Subtitle

This zooms up the wide picture (16:9 aspect ratio)
with subtitles to the full screen.

Note: You can shift the screen up or down by pressing
“ ” / “ ” buttons while picture zoom is selected as
Panoromic, 14:9 Zoom, Cinema or Subtitle.

14:9

This zooms up the wide picture (14:9 aspect ratio) to
the upper and lower limits of the screen.

14:9 Zoom

This option zooms to the 14:9 picture.

4:3

Use to view a normal picture (4:3 aspect ratio) as this
is its original size.

Panoramic

This stretches the left and right sides of a normal
picture (4:3 aspect ratio) to fi ll the screen, without
making the picture appear unnatural.

The top and bottom of the picture are slightly cut off.

Cinema

This zooms up the wide picture (16:9 aspect ratio) to
the full screen.

Confi guring Picture Settings

You can use different picture settings in detail.

Press “MENU” button and select the Picture icon
by using “
Picture Settings menu.

Operating Picture Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Use “•

Press “• MENU” button to exit.

Picture Settings Menu Items

Mode

For your viewing requirements, you can set the related
mode option. Picture mode can be set to one of these
options: Cinema, Dynamic and Natural.

Contrast: Sets the lightness and darkness values
of the screen.

Brightness: Sets the brightness value for the
screen.

Sharpness: Sets the sharpness value for the objects
displayed on the screen.

Colour: Sets the colour value, adjusting the colors.

Power Save Mode

Use “
Press “ ” or “ ” button to set Power Save Mode
as Eco, Picture Off and Disabled. See the section,
“Environmental Information” in this manual for further
information on Power Save Mode.

Backlight

This setting controls the backlight level and it can be
set to Low, Medium, High and Auto.

Noise Reduction

If the broadcast signal is weak and the picture is noisy,
use Noise Reduction setting to reduce the noise
amount. Noise Reduction can be set to one of these
options: Low, Medium, High or Off.

” or “ ” button. Press OK button to view

” or “ ” button to set an item.

” or “ ” button to select Power Save Mode.

English - 27 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2701_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 27 26.12.2011 13:52:1626.12.2011 13:52:16

Customer Helpline 0845 459 5282

Advanced Settings

Dynamic Contrast: You can change contrast rate by

using dynamic contrast function. Dynamic contrast
can be set to one of these options: Low, Medium,

High or Off

Colour Temp: Sets the desired colour tone.

Picture Zoom: Sets the picture size to Auto,16:9,

Subtitle,14:9, 14:9 Zoom, 4:3, Panoramic or
Cinema.

Movie Sense (Detection of movement): When the
movie Detection mode is active, the video parameters
of the television set will be optimized so that the
moving images acquire a better quality and a certain
visibility.

Using Detection movie mode

When the option Detection movie is regulated on
Weak, Average, High the demo option of the fi lm
detection mode is available. If the one of these options
is selected and you press the OK button, then the
demo mode starts. When the demo mode is active,
the screen divides itself in two sections, one displays
the activity of the Detection movie mode, the other
displaying the normal parameters of the TV screen.
To cancel, press the OK key again.

Note: Movement detection is equally effective for
broadcastings in 24 images per second.

Film mode: Films are recorded at a different number of
frames per second to normal television programmes.
Press “

” or “ ” button to select Film Mode. Press
“ ” or “ ”button to set this feature Auto or Off. Turn
this feature on when you are watching fi lms to see the
fast motion scenes clearly.

Skin Tone: Adjust the desired skin tone.

Colour Shift: Adjust the desired colour tone.

RGB Gain: You can confi gure the colour temperature

values using the RGB Gain feature.

Reset

Resets the picture settings to factory default
settings.

While in VGA (PC) mode, some items in Picture menu
will be unavailable. Instead, VGA mode settings will be
added to the Picture Settings while in PC mode.

PC Picture Settings

For adjusting PC picture items, do the following:

Press “
menu appears on the screen.

Contrast, Brightness, Colour, Colour Temp and
Picture Zoom and other settings in this menu are

identical to settings defi ned in TV picture menu under
“Main Menu System”.

Sound, Settings and Source settings are identical to
the settings explained in main menu system.

PC Position: Select this to display PC position menu
items.

Autoposition: Automatically optimizes the display.
Press OK to optimize.

H Position: This item shifts the image horizontally to
right hand side or left hand side of the screen.

V Position: This item shifts the image vertically
towards the top or bottom of the screen.

Dot Clock: Dot Clock adjustments correct the
interference that appear as vertical banding in
dot intensive presentations like spreadsheets or
paragraphs or text in smaller fonts.

Phase: Depending on the resolution and scan
frequency that you input to the TV set, you may see
a hazy or noisy picture on the screen. In such a case
you can use this item to get a clear picture by trial
and error method.

” or “ ” button to select Picture icon. Picture

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2801_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 28 26.12.2011 13:52:1726.12.2011 13:52:17

English - 28 -

Confi guring Sound Settings

Sound settings can be confi gured according to your
personal preferences.

Press “MENU” button and select the Sound icon by
using “
Sound Settings menu.

” or “ ” button. Press OK button to view

In Equalizer menu, the preset can be changed to
Music, Movie, Speech, Flat, Classic and User.
Press the “MENU” button to return to the previous
menu.

Note: Equalizer menu settings can be changed
manually only when the Equalizer Mode is in User.

Balance: This setting is used for emphasizing left or
right speaker balance.

Headphone: Sets headphone volume.

Sound Mode: You can select Mono, Stereo, Dual I

or Dual II mode, only if the selected channel supports
that mode.

AVL : Automatic Volume Limiting (AVL) function sets the
sound to obtain fi xed output level between programmes
(For instance, volume level of advertisements tend to
be louder than programmes).

Digital Out: Sets digital out audio type.

Confi guring Your TV’s Settings

Detailed settings can be configured to suit your
personal preferences.

Press “MENU” button and select Settings icon by
using “
Settings menu.

” or “ ” button. Press OK button to view

Operating Sound Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

” or “ ” button to set an item.

Use “•

Press “• MENU” button to exit.

Sound Settings Menu Items

Volume: Adjusts volume level.

Equalizer: Press OK button to view equalizer sub-

menu.

Operating Settings Menu Items

Press “• ” or “ ” button to highlight a menu item.

Press • OK button to select an item.

Press “• MENU” button to exit.

Settings Menu Items

Conditional Access: Controls conditional access

modules when available.

Language: Confi gures language settings.

Parental: Confi gures parental settings.

English - 29 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 2901_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 29 26.12.2011 13:52:1726.12.2011 13:52:17

Customer Helpline 0845 459 5282

Timers: Sets timers for selected programmes.

Date/Time: Sets date and time.

Sources: Enables or disables selected source

options.

Network Settings: Displays Network Settings
screen.

Other Settings: Displays other setting options of
the TV set.

Using a Conditional Access
Module (not supplied)

IMPORTANT: Insert or remove the CI module only
when the TV is SWITCHED OFF.

In order to watch certain digital channels, a •
conditional access module (CAM) can be necessary.
This module must be inserted in the CI slot of your
TV.

Obtain the Conditional Access Module (CAM) and •
the viewing card by subscribing to a pay channel
company, then insert those to the TV using the
following procedure.

Insert the CAM and then the viewing card to the •
slot that is located in the terminal cover at the rear
side of the TV.

The CAM should be correctly inserted, it is •
impossible to insert fully if reversed. The CAM or
the TV terminal may be damaged if the CAM is
forcefully inserted.

Connect the TV to the mains supply, switch on
and then wait for few moments until the card is
activated.

When no module is inserted, “• No Common
Interface module detected” message appears on
the screen.

Refer to the module instruction manual for details •
of the settings.

Viewing Conditional Access Menu (*)

(*) These menu settings may change depending on
the service provider.

Press “MENU” button and select the icon by using “

” or “ ” button. Press OK button to view Settings

menu. Use “ ” or “ ” button to highlight Conditional

Access and press OK to view menu items.

Confi guring Language
Preferences

You can operate the TV’s language settings using
this menu.

Press “MENU” button and select the Settings icon
by using “
Settings menu. Use “ ” or “ ” button to highlight
Language and press OK to continue:

Use “ ” or “ ” button to set an item. Settings are
stored automatically.

Menu: displays the system language.

Preferred

These settings will be used if available. Otherwise the
current settings will be used.

Audio• : Sets the preferred audio language.

Subtitle• : Sets the subtitle language. Selected

language will be seen in subtitles.

Teletext• : Sets teletext language.

Guide• : Sets the preferred Guide language.

Current (*)

(*) These settings can be changed if only the
broadcaster supports. Otherwise, settings will not be
available to be changed.

Audio• : Changes the audio language for the current
channel.

Subtitle• : Sets the subtitle language for the current
channel.

” or “ ” button. Press OK button to view

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3001_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 30 26.12.2011 13:52:1726.12.2011 13:52:17

English - 30 -

Note: If the Country option is set to Denmark, Sweden,

Norway or Finland, the Language Settings menu will
function as described below:

Language Settings

In the Settings menu, highlight the Language Settings
item by pressing “ ” or “ ” buttons. Press OK and
Language Settings submenu will be displayed on
the screen:

” or “ ” buttons to highlight the menu item

Use “
that will be adjusted and then press “ ” or “ ” button
to set.

Notes:

System Language determines the on-screen menu •
language.

Audio Language is used for selecting the soundtrack •
of a channels.

Primary settings are the first priority when multiple •
choices are available on a broadcast. Secondary
settings are the alternatives when the first options
are not available.

Parental Control

To prohibit viewing of certain programmes, channels
and menus can be locked by using the parental
control system.

This function enables or disables the menu protection
system and allows the PIN code to be changed.

Press “MENU” button and select the Settings by using
“

” or “ ” button. Press OK button to view Settings
menu. Use “ ” or “ ” button to highlight Parental
and press OK to continue:

To display parental lock menu options, PIN number
should be entered. Factory default PIN number is

0000. After coding the correct PIN number, parental
settings menu will be displayed:

Parental Settings Menu Operation (*)

Select an item by using “•

” or “ ” button to set an item.

Use “•

Press• OK button to view more options.

(*) If you set Country option as UK in the fi rst time
installation, Maturity Lock and Child Lock options
will not be visible. This setting is available only for
EU countries.

English - 31 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3101_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 31 26.12.2011 13:52:1826.12.2011 13:52:18

” or “ ” button.

Customer Helpline 0845 459 5282

Menu Lock: Menu lock setting enables or disables

the menu access. You can disable access to the
installation menu or the whole menu system.

Maturity Lock(optional): When set, this option gets
the maturity information from the broadcast and if
this maturity level is disabled, disables access to the
broadcast.

Child Lock: When Child Lock is set, the TV can only
be controlled by the remote control. In this case the
control panel buttons will not work, except for the
Standby/On button. When Child Lock is activated
you are able to switch the TV into Standby mode with
the Standby/On button. To switch the TV on again,
you need the remote control. Hence, if one of those
buttons is pressed, Child Lock Is On will be displayed
on the screen when the menu screen is not visible.

Set PIN: Defi nes a new PIN number. Use numeric
buttons to enter a new pin number. You will need
to code your new PIN a second time for verifi cation
purposes.

IMPORTANT: The factory default PIN number is 0000,
if you change the PIN number make sure you write it
down and keep it safe.

Timers

To view Timers menu, press MENU button and select
Settings icon by using “ ” or “ ” button. Press OK
button to view Settings menu. Use “ ” or “ ” button
to highlight Timers and press OK to continue:

Setting Sleep Timer

This setting is used for setting the TV to turn off after
a certain time.

Highlight Sleep Timer by using “•

” or “ ” button to set. The timer can be

Use “•
programmed between Off and 2.00 hours (120
minutes) in steps of 30 minutes.

Setting Programme Timers

You can set programme timers for a particular
programme using this feature.

Press “
timer function buttons will be displayed on the
screen.

” button to set timers on an event. Programme

Adding a Timer

Press • YELLOW button on the remote control to
add a timer.

Network Type: This feature is unavailable to be set.

Timer Type: You can select timer type as Record

or Timer.

Channel: Changes channel by using “

Timer Type: This feature is unavailable to be set.

Date: Enter a date using the numeric buttons.

” or “ ” button.

” or “ ”.

Start: Enter a starting time using the numeric
buttons.

End: Enter an ending time using the numeric
buttons.

Duration: Displays duration between the starting and
ending time.

Repeat: Sets a timer to be repeated as Once, Daily or
Weekly. Use “

Change/Delete: Sets the change/delete permission.

Playback: Sets the playback permission and parental

settings.

Press • GREEN button to save the timer. Press RED
button to cancel.

” or “ ” buttons to select an option.

Editing a Timer

Select the timer you want to edit by pressing “• ”
or “ ” button.

Press • GREEN button. Edit Timer menu screen will
be displayed.

When fi nished with editing, press • GREEN button to
save. You can press “MENU” button to cancel.

Deleting a Timer

Select the timer you want to delete by pressing “•
” or “ ” button.

Press • RED button.

Select • YES by using “
timer. Select NO to cancel.

” or “ ” buttons to delete the

Recording Confi guration

Select Recording Confi guration item in the Settings
menu to confi gure recording settings. The following
menu is displayed for recording confi guration.

The following options are available for adjustments:

Start Early (*)

You set recording timer’s starting time to start earlier
by using this setting.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3201_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 32 26.12.2011 13:52:1826.12.2011 13:52:18

English - 32 -

(*) Available only for EU country options.

End Late (*)

You set recording timer’s starting time to start later
by using this setting.

(*) Available only for EU country options.

Max Timeshift

This setting allows you to set the maximum time
allowed for timeshifting. Duration options are
approximate and can change accordingly, depending
on the broadcast received. When the Max Timeshift
time is reached, auto play will proceed.

Format Disk

IMPORTANT: Note that ALL the data stored on the
USB disk will be lost and then the disk format will be
converted to FAT32 if you activate this feature.

If you want to delete all fi les on the connected USB •
hard disk drive or memory stick, you can use Format
Disk option.

Also, if your USB disk malfunctions, you can try •
formatting the USB disk. In most cases formatting
the USB disk will restore normal operation; however,
ALL the data stored on the USB disk will be lost in
such a case.

Press • OK button while the Format Disk option is
highlighted. A menu will appear on the screen,
requiring you to enter a pin number. If you have not
changed the pin number, the factory default is 0000.
After you enter the pin, a pop-up menu appears on
the screen to ensure that the hard disk should be
formatted, select “YES” and press OK to format
the hard disk. Select “NO” and press OK to cancel.
Ensure you back up important recordings before you
format the USB disk unit.

Hard Disk Info

To view the details about the USB disk, highlight Hard
Disk Info by using “
disk information will be displayed:

” or “ ” key and press OK. USB

Confi guring Date/Time Settings

Select Date/Time in the Settings menu to confi gure
Date/Time settings. Press OK button.

Use “• ” or “ ” buttons to highlight Date/Time.

Date, Time, Time Settings Mode and Time Zone
Setting will be available.

Use “

” or “ ” buttons to highlight the Time Settings
Mode. Time Settings Mode is set using “ ” or “ ”
buttons. It can be set to AUTO or MANUAL.

When AUTO is selected, Date/Time and Time Zone
options will not be available to be set. If MANUAL
option is selected as the Time Zone can be altered:

• By pressing “

” or “ ” buttons to change the Time Zone

Use “
between GMT-12 or GMT+12. Date/Time on the top
of the menu list will then change according to the
selected Time Zone.

Changes are automatically stored. Press “• MENU”
to exit.

” or “ ” buttons select Time Zone.

Confi guring Source Settings

You can enable or disable selected source options.
The TV will not switch to the disabled source options
when “SOURCE” button is pressed.

Select • Sources in the Settings menu and press
OK button.

Press“•

Use “•
selected source. Changes are automatically
stored.

” or “ ” buttons to select a source.

” or “ ” button to enable or disable the

English - 33 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3301_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 33 26.12.2011 13:52:1826.12.2011 13:52:18

Customer Helpline 0845 459 5282

Confi guring IP Settings

Using IP Settings window you can set IP address and
DNS servers of the TV set. IP address can be either
static or dynamic. Static means that the address that
you know is given by the service supervisor. Also
Subnet mask, Default Gateway and DNS Server’s IP
addresses should be set correctly.

If the IP address is not known or if a specifi c IP is
not used, you can select the Confi guration Status
as Dynamic.

With this selection, all settings are taken from service
supervisor and addresses are displayed on this
menu.

IP address and DNS Server settings’ can be edited
if Static is selected. If Dynamic is selected, these will
not be available.

To set an IP address please press RED and to change
DNS servers please press YELLOW button.

To save and exit all settings, press BLUE button.

This menu is functional if an Internet connection is
present and if the ethernet cable is plugged.

If a connection problem occurs or the TV does not
connect to the Internet, menu screen will be displayed
as above and all address lines will be blank.

To disable the connection, please select confi guration
status as disabled.

Wi-Fi Settings (Optional)

Wi-Fi feature can be used for a wireless network
connection (optional). The feature is used for
infrastructure purposes only, such as connecting to
the web, hbb sites and connecting with DLNA servers
(optional). Select Wireless Device option to switch to
Wireless Settings from Network Settings window.

Press GREEN button to switch to advanced mode
and then press OK button to edit settings.

To enable Wi-Fi feature, profi les should be confi gured
properly. Please plug in the Wi-Fi dongle to one of the
USB ports (IMPORTANT: “Veezy 100” USB dongle is
required to use wireless network feature. To use your
TV with your wireless network, you need a “Veezy
100” Wireless USB dongle.).

Press YELLOW button to scan wireless network
from network settings menu. Afterwards available
network list will be displayed. Please select your
desired network from the list. If the selected network
is protected with a password, please enter the correct
key by using the virtual keyboard. You can use this
keyboard via navigation buttons (Left/Right/Up/Down)
and OK button on the remote control. Wait until the
IP the address is shown on the screen.

This means that the connection is now established.
To disconnect from a wireless network, you should
highlight Confi guration Status and press OK.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3401_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 34 26.12.2011 13:52:1926.12.2011 13:52:19

English - 34 -

You can navigate between menu tabs by pressing left/
right buttons. The help bar on the bottom of the dialog
shows features that you may use. Press BLUE button
to check your internet connection speed.

You can check the signal strenght by using the network
settings menu for the wireless device mode.

Information

Configuration Status: Displays wi-fi status as

connected or not connected.

IP Address: Displays the current IP address.

Network Name: Connected networks’ name will be

displayed.

Delete Saved Wifi Profi les

Saved profi les will be deleted if you press red button
while wireless device selection osd is on the screen.

Connecting to your Cell Phone via WiFi
(Optional)

If your cell phone has WiFi feature, you can connect •
your cell phone to your TV by using WiFi connection
via a router, in order to play content from your phone.
For this, your cell phone must have an appropriate
sharing software.

Connect to your router following the steps stated •
above in the Wireless Connection section.

Afterwards, engage your cell phone with the router •
and then activate sharing software on your cell
phone. Then, select fi les that you would like to share
with your TV.

If the connection is established correctly, you should •
now access the shared fi les of your cell phone via
the Media Browser of your TV.

Enter Media Browser menu and playback device •
selection OSD will be displayed. Select your cell
phone’s ident and press OK to continue.

Note: This feature may not be supported by some
cell phones.

English - 35 -

Confi guring Other Settings

To view general confi guration preferences, select
Other Settings in the Settings menu and press OK
button.

Operation

Press “• ” or “ ” buttons to select an item.

” or “ ” button to set an option.

Use “•

Press• OK button to view a sub-menu.

Menu Timeout: Changes timeout duration for menu
screens.

Active Antenna: This feature enables or disables
the use of active antennas. When antenna power
option is set as On, +5V will be transmitted to the
antenna output.

IMPORTANT: Antenna power should be Off when
standard antenna is used instead of the active
antenna.

Scan Encrypted: When this setting is on, search
process will locate the encrypted channels as well. If
it is set as Off, encrypted channels will not be located
in automatic search or manual search.

Blue Background: Activates or deactivates blue
background system when the signal is weak or
absent.

Software Upgrade: To ensure that your TV always
has the most update information, you can use this
setting. In order for the proper operation, please
ensure that the TV is set to standby mode.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3501_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 35 26.12.2011 13:52:1926.12.2011 13:52:19

You can enable or disable automatic upgrade by
setting Automatic Scanning option.

You can manually search for new software by
selecting Scan for upgrade.

Hard of Hearing: If the broadcaster enables any
special signal concerning the audio, you can set this
setting as On to receive such signals.

Audio Description: Audio description refers to
an additional narration track for blind and visually
impaired viewers of visual media, including television
and movies. The description narrator talks through
the presentation, describing what is happening on the
screen during the natural pauses in the audio (and
sometimes during dialogue, if deemed necessary).
You can use this feature, only if the broadcaster
supports that additional narration track.

Auto TV Off: You can set the timeout value of auto off
feature. After the timeout value is reached and the TV
is not operated for selected time, the TV will go off.

Standby Search (optional): Use “
to select Standby Search and then press “ ” or “

” button to set this setting as On or Off. If you
change Standby Search to Off, this function will be
unavailable.To use Standby Search please make sure
that you select Standby Search as On.

To deactivate this feature, please set to “disabled”.
While Store mode is enabled,Backlight will be set
to maximum automatically. Auto TV off function will
be invisible.

” or “ ” button

Other Features

Displaying TV Information: Programme Number,

Programme Name, Sound Indicator, time, teletext,
channel type and resolution information is displayed
on the screen when a new programme is entered or
“INFO” button is pressed.

Mute Function: Press “
Mute indicator will be displayed in the upper side of
the screen. To cancel mute, there are two alternatives;
the fi rst one is pressing the “
one is increasing the volume level.

Picture Mode Selection: By pressing PRESETS
button, you can change Picture Mode settings in
accordance with your viewing requirements. Available
options are Dynamic, Natural, Cinema and Game.

Displaying Subtitles: You can enable subtitles by
pressing the SUBTITLE button of the remote control.
Press SUBTITLE button again to disable subtitle
function.

If “Subtitle” is On, pressing the “TEXT” button causes
the following warning message to be displayed on the
screen (** for UK only)

” button to disable sound.

” button and the second

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3601_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 36 26.12.2011 13:52:1926.12.2011 13:52:19

English - 36 -

Digital Teletext

• Press the “ ” button.

The digital teletext information appears.•

Operate it with the coloured buttons, cursor buttons •
and OK button.

The operation method may differ depending on the
contents of the digital teletext.

Follow the instructions displayed on digital teletext
screen.

When Press “• OK” button or similar message appears
on the screen, press the OK button.

When the “•
television broadcasting.

With digital broadcasting (DVB), in addition to digital •
teletext broadcasting together with the normal
broadcasting, there are also channels with just digital
teletext broadcasting.

The aspect ratio (picture shape) when watching •
a channel with just digital teletext broadcasting is
the same as the aspect ratio of the picture viewed
previously.

When you press the “• ” button again, the digital
teletext screen will be displayed.

” button is pressed, the TV returns to

Analogue Teletext

The teletext system transmits information such as
news, sports and weather on your TV. Note that if the
signal degrades, for example in poor/adverse weather
conditions, some text errors may occur or the teletext
mode may be aborted.

Teletext function buttons are listed below:

“TEXT” Teletext / Mix : Activates teletext mode when

pressed once. Press again to place the teletext screen
over the programme (mix). Pressing again will quit
the teletext mode.

“RETURN” Index: Selects the teletext index page.

“INFO”Reveal: Shows hidden information (e.g.

solutions of games).

“OK” Hold: Holds a text page when convenient. Press
again to resume.

”/“ ” Subcode Pages: Selects subcode pages if

“
available when the teletext is activated.

P+ / P- and numbers (0-9): Press to select a page.

Note: Most TV stations use code 100 for their index
pages.

Coloured Buttons (RED/GREEN/YELLOW/
BLUE)

Your TV supports both FASTEXT and TOP text
systems. When these systems are available, the
pages are divided into groups or topics. When
FASTEXT system is available, sections in a teletext
page will become colour-coded and can be selected
by pressing the coloured buttons. Press a coloured
button that corresponds to with your needs. The
coloured writings will appear, showing you which
coloured buttons to use when TOP text transmission
is present. Pressing “ ” or “ ” commands will request
the next or previous page respec tively.

English - 37 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3701_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 37 26.12.2011 13:52:1926.12.2011 13:52:19

Customer Helpline 0845 459 5282

Tips

Screen Care: Clean the screen with a dry, soft cloth.

Do not use abrasive solvents as they may damage the
coating layer of the TV screen. For your safety, unplug
the mains plug when cleaning the set. When moving
the TV, hold it properly from the bottom part.

Image Persistence: Please note that ghosting may
occur while displaying a persistent image. LED TVs’
image persistence may disappear after a short time.
Try turning off the TV for a while.

To avoid this, do not leave the screen in still picture
for extended periods.

No Power: If your TV system has no power, please
check the main power cable and connection to the
mains socket outlet.

Poor Picture: Have you selected the correct TV
system? Is your TV set or house aerial located too
close to a non-earthed audio equipment or neon
lights, etc.? Mountains or high buildings can cause
double pictures or ghost images. Sometimes you can
improve the picture quality by changing the direction
of the aerial. Is the picture or teletext unrecognisable?
Check if you have entered the correct frequency.
Please retune the channels. The picture quality may
degrade when two peripherals are connected to the
TV at the same time. In such a case, disconnect one
of the peripherals.

No Picture: Is the aerial connected properly? Are the
plugs connected tightly to the aerial socket? Is the
aerial cable damaged? Are suitable plugs used to
connect the aerial? If you are in doubt, consult your
dealer. No Picture means that your TV is not receiving
a transmission. Have you selected the correct button
on the remote control? Try once more. Also make sure
the correct input source has been selected.

Sound: You can not hear any sound. Did you perhaps
mute the sound, pressing the
coming from only one of the speakers? Is the balance
set to one extreme? See Sound Menu.

Remote Control: Your TV no longer responds to the
remote control. Perhaps the batteries are exhausted.
If so you can still use the local buttons on the TV.

Input Sources: If you cannot select an input source,
it is possible that no device is connected. Check
the AV cables and connections if you have tried to
connect a device/

Recording Unavailable: To record a programme, you
should fi rst connect a USB disk to your TV while the
TV is switched off. You should then switch on the TV to
enable recording feature. Otherwise, recording feature
will not be available. If you cannot perform recording,
try switching off the TV and then re-inserting the USB
device while the TV is switched off.

button? Sound is

USB Is too Slow: If “USB is too slow” message is
displayed on the screen while starting a recording,
try restarting the recording. If you still get the same
error, it is possible that your USB disk does not meet
the speed requirements. Try connecting another
USB disk.

Picture Breakup: If whilst watching DTV you
experience picture or sound disruptions then please
retune your TV using “First Time Installation” and
make sure you select the correct region/transmitter
when prompted by the “Choose Region” on screen
message. Please note regional selection can only be
made if “First time Installation” is used.

TV Switches Randomly to Stand-By: The TV by
default will switch back to standby after 4 hours if the
TV remote is not used, this is most likely to occur if you
are you are using an external set-top box as a signal
source or you are out of the TV room. This power
saving feature can be switched off or the activation
time extended or reduced via the menu “Settings->
Other Settings -> Auto TV OFF”. The TV will also
return to stand-by if the aerial signal is lost for more
than 5 minutes.

Dark Picture: When the TV is fi rst switched on the
back lights brightness is reduced, this is normal
operation and the brightness will increase to the
running level within a few minutes. Please note when
“Backlight” is set to “Auto” the backlight brightness will
change with picture content.

Wireless Network Not Available: Ensure that the
firewalls of your network allows the TV wireless
connection. Winstron DNUB-236 USB wifi dongle
should be plugged properly (if available). If the
wireless network does not function properly, try
using the wired network in your home. Refer to the
Wired Connection section for more information on
the process.

If the Net TV does not function, check the modem
(router) fi rst. If the router does not have a problem,
check the internet connection of your modem.

Connection is Slow: See the instruction book
of your wireless modem to get information on the
internal service area, connection speed, signal quality
and other settings. You need to have a high speed
connection for your modem.

Distruption during playback or slow reactions:

You could try the following in such a case: Keep
at least three meters distance from microwave ovens,
mobile telephones, bluetooth devices or any other
Wi-Fi compatible devices. Try changing the active
channel on the WLAN router.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3801_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 38 26.12.2011 13:52:2026.12.2011 13:52:20

English - 38 -

Appendix A: PC Input Typical Display Modes

The display has a maximum resolution of 1920 x 1200. The following table is an illustration of some of the
typical video display modes.

Your TV may not support different resolutions. Supported resolution modes are listed below.

If you switch your PC to an unsupported mode, a warning OSD sho
seconds to change back to your last setting.

Different graphics card and drivers allow for variable resolution support.

For the most compatible settings, we recommend you download the latest drivers for your graphics card. For
more information, contact your PC manufacturer.

uld appear on the screen giving you 15

Index Resolution

1 640x480p - VGA 59

2 640x480p - VGA 72

3 640x480p - VGA 75

4 640x480p - VGA 85

5 800x600p - SVGA 56

6 800x600p - SVGA 60

7 800x600p - SVGA 72

8 800x600p - SVGA 75

9 800x600p - SVGA 85

10 1024x768p - XGA 60

11 1024x768p - XGA 60

12 1024x768p - XGA 66

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

1024x768p - XGA 70

1024x768p - XGA 75

1024x768p - XGA 84

1152x864p 75

1280x1024p - SXGA 75

1280x1024p - SXGA 85

1280x1024p - SXGA 60

1280x768p - WXGA 59

1280x768p - WXGA 59

1280x768p - WXGA 74

1280x768p - WXGA 84

1280x960 - WXGA 60

1280x960p - WXGA 85

1360x768p - WXGA 60

1360x768p - WXGA 60

1400x1050p - SXGA+ 74

1600x1200p - UXGA 60

1920x1080p 59

Frequency

(Hz)

English - 39 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 3901_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 39 26.12.2011 13:52:2026.12.2011 13:52:20

Customer Helpline 0845 459 5282

Appendix B: AV and HDMI Signal Compatibility (Input Signal Types)

Source Supported Signals Available

PAL 50/60 O

EXT-1

EXT-2

FAV

(SIDE AV)

YPbPr

HDMI1

HDMI2

HDMI3

HDMI4

NTSC 60 O

RGB 50 O

RGB 60 O

PAL 50/60 O

NTSC 60 O

RGB 50 X

RGB 60 X

PAL 50/60 O

NTSC 60 O

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

480I 60Hz O

480P 60Hz O

576I 50Hz O

576P 50Hz O

720P 50Hz O

720P 60Hz O

1080I 50Hz O

1080I 60Hz O

1080P 50Hz O

1080P 60Hz O

1080P 24Hz O

(X: Not Available, O: Available)

In some cases a signal on the LED TV may not be displayed properly. The problem may be an inconsistency with standards
from the source equipment (DVD, Set-top box, etc. ). If you do experience such a problem please contact your dealer and
also the manufacturer of the source equipment.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 4001_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 40 26.12.2011 13:52:2026.12.2011 13:52:20

English - 40 -

Appendix C: Supported DVI Resolutions

When connecting devices to your TV’s connectors by using DVI converter cables (not supplied), you can refer
to the following resolution information.

24Hz 25Hz 30Hz 50Hz 60Hz

480i

480p

576i

576p

720p

1080i

1080p

;

;

;;

;;

;;;; ;

;

;

Appendix F: Supported File Formats for USB Mode

Supported Players

Player Stream Video Decoder (MSVD) Audio Decoder (MSAD)

Audio MP3 None MP3

Audio WAV/AIFF None-- LPCM

Windows Media

(optional)

MPEG1 Program

Stream

WMA / ASF VC1 WMA

MPEG-1 MPEG1 MP3, AC-3 and PCM

MPEG2 Program

Stream

MPEG4

MPEG-2 MPEG2 MP3, AC-3 and PCM

MPEG-4/H264 in

MP4 container

H264 and MPEG4 AAC

AVI XVID MPEG4vbn MP3, AC-3 and PCM

MKV MKV H264 and VC-1 MP3-AC-3,AAC

English - 41 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 4101_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 41 26.12.2011 13:52:2026.12.2011 13:52:20

Customer Helpline 0845 459 5282

Appendix D: Software Upgrade

• Your TV is capable of fi nding and updating new software upgrades over broadcast channels.

• For broadcast channels search, theTV looks at the available channels stored in your settings. So before the
software upgrade search, it is advised to auto search and update all available channels.

1) Software upgrade search via user interface

• It is possible to manually check if there is a new software upgrade for your TV set.

• Simply navigate on your main menu. Choose Settings and select Other Settings menu. In Other Settings
navigate to the Software Upgrade item and press OK button to open Upgrade Options menu.

• In Upgrade Options menu select Scan for upgrade and press OK button.

• If a new upgrade is found, it starts to download the upgrade. A progress bar indicates the remaining download
progress. When the download completes with success a message is displayed for reboot to activate new
software. Press OK to continue with the reboot operation.

2) Background search and upgrade mode

• While TV is connected to Internet, in the background it searches for critical software upgrades. If a critical
software upgrade is found it downloads the upgrade silently. When the download completes with success a
message is

displayed for reboot operation to activate new software. Press OK to continue with the reboot operation.

3) 3.AM search and upgrade mode

• If Automatic scanning in Upgrade Options menu is enabled, the TV wakes up at 03:00 and searches
broadcast channels for new software upgrade. If new software is found and downloaded successfully, with
next power up TV opens with new software version.

Note on reboot operation: Reboot is the last step in software upgrade operation if download of new software
is fi nished successfully. During reboot TV makes fi nal initializations. In the reboot sequence the panel power
is closed and front led indicates the activity with blinking. Around 5 minutes later TV restarts with new software
activated.

• If your TV fails to restart in 10 minutes, unplug the power for 10 minutes and re-plug again. The TV should
open with the new software safely. If you still can not get TV working, please kindly repeat unplug and plug
sequence a few more times. If your set still can not operate, please call the service personnel to fi x the
problem for you.

Caution: While led is blinking during reboot do not unplug your TV’s power. Doing this may cause
your TV not to re-open again and can only be fi xed by service personnel.

Manual Software Update

Ensure that the ethernet cable is connected to your TV.

Menu -> Settings -> IP Settings -> Confi guration Status -> Connected

Go to Settings tab from the main menu and select Other Settings. Highlight Software Upgrade and press OK.
Select Scan for Upgrade and press OK button.

An OSD screen including the progress bar will be visible under the “Software upgrade” title.

A warning screen will be displayed on the screen, stating that the TV will be rebooted. Press OK button to
fi nalize upgrade process and reboot TV.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 4201_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 42 26.12.2011 13:52:2026.12.2011 13:52:20

English - 42 -

Specifi cations

TV BROADCASTING

PAL/SECAM B/G D/K K’ I/I’ L/L’

RECEIVING CHANNELS

VHF (BAND I/III)

UHF (BAND U)

HYPERBAND

NUMBER OF PRESET CHANNELS

10.000

CHANNEL INDICATOR

On Screen Display

RF AERIAL INPUT

75 Ohm (unbalanced)

OPERATING VOLTAGE

220-240V AC, 50 Hz.

AUDIO OUTPUT POWER (W

2 x 12

POWER CONSUMPTION (W)

165 W (max)

PANEL

55” (140 cm) wide screen

DIMENSIONS (mm)

DxLxH (With foot): 330 x 1307 x 819,5

Weight (Kg): 31,5

DxLxH (Without foot): 39,9 x 1307 x 778,5

Weight (Kg): 26,8

) (10% THD)

RMS.

Digital Reception (DVB-T)

Transmission Standards:

DVB-T, MPEG2,DVB-T, MPEG4 HD

i. DEMODULATION

-Symbol rate: COFDM with 2K/8K FFT mode.•

-Modulation: 16-QAM - 64-QAM FEC for all DVB •
modes (automatically found)

MHEG-5 ENGINE compliant with ISO/IEC 13522-5 •
UK engine Profi le (UK only)

Object carousel support compliant with ISO/IEC •
135818-6 and UK DTT profi le(UK only)

Frequency range: 474-850 MHz for UK models•

ii. VIDEO

-H.264 (MPEG-4 part 10) main and high profi le level •

4.1/MPEG-2 MP@HL video decoder.

-HD display multi format capable (1080i, 720p, •
576p)

-CVBS analogue output.(In HD channels, this will •
not be available

iii. AUDIO

-MPEG-1 layer I/II, MPEG-2 layer II, AAC, HEAAC, •
AC3, E-AC3

-Sampling frequencies supported are 32, 44.1 & •
48 kHz

Digital Reception (DVB-T2)

Demodulation

-QPSK, 16QAM, 64QAM, 256QAM with 1k, 2k, 4k,•

8k, 16k, 32k FFT mode•

Frequency Band

- UHF/ VHF•

Channel BW

- 8 MHz /7MHz•

Profi les

- MPEG-4 H.264/AVC HP@L 4.0, MP@L 4.0 (HD)•

- H.264/AVC MP@L 3 .2, HP@L 3 .2 (SD)•

- MPEG-2 MP@HL, MP@ML (SD)•

English - 43 -

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 4301_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 43 26.12.2011 13:52:2026.12.2011 13:52:20

Customer Helpline 0845 459 5282

Important Instruction

For your own safety read following instruction carefully before attempting to connect this unit to the mains
supply.

MAINS (AC) OPERATION

The wires in the mains lead are coloured in accordance with the following code :

GREEN

&

FUSE

YELLOW

(Earth)

(if there is earth cable)

BROWN

BLUE

(Live)

(Neutral)

IMPORTANT

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal which is marked with
the letter E, or by the earth symbol, or coloured green or green and yellow.

The wire which is coloured blue or black must be connected to the terminal which is marked with the
letter N or coloured Black.

The wire which is coloured brown or red must be connected to the terminal which is marked with the
letter L or coloured Red.

For continued protection against risk of fi re, replace only with same type and rating of fuse (ASTA
approved 5A 250VAC fuse).

CAUTION

TO PREVENT ELECTRIC SHOCK DISCONNECT FROM THE MAINS BEFORE REMOVING
COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

SAFETY PRECAUTION

THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO NOT
ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE.

Customer Helpline 0845 459 5282

01_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 4401_[GB]_MB70_5112UK_IDTV_T2_100Hz_55990LED_GOLD11_10077108_50209161.indd 44 26.12.2011 13:52:2126.12.2011 13:52:21

English - 44 -

www.finluxdirect.com

Customer helpline: 0845 459 5282

50209161
