Finlux 47F9076-T User Manual
Contents
Safety Information .......................................... 2
Getting Started ....................................................... 3
Notications & Features & Accessories .................. 3
Remote Control - 1 ................................................ 6
Connections............................................................ 7
First Time Installation - USB Connections .............. 8
TV Menu Features and Functions .........................11
General TV Operation .......................................... 14
Using DLNA Network Service ............................... 19
iPlayer Application ................................................ 21
Internet Browser ................................................... 22
Getting Started with Skype ................................... 23
Software Upgrade................................................. 28
Troubleshooting & Tips ......................................... 28
Appendix A: Nero MediaHome Installation ........... 28
PC Input Typical Display Modes .......................... 30
AV and HDMI Signal Compatibility ....................... 30
Supported File Formats for USB Mode ................ 31
Important Instruction ............................................. 32
English - 1 -
Safety Information
If there is lightning or storms, or if the TV is not
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO
To operate your TV in extreme ambient conditions
may cause damage of the device.
NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Note : Follow the on screen instructions for operating the
related features.
going to be used for a while (e.g. if going away
on holiday), disconnect the TV set from the
mains. The mains plug is used to disconnect
TV set from the mains and therefore it must
remain readily operable.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
IMPORTANT - Please read these instructions fully before installing or operating
WARNING: Never let people (including
children) with reduced physical, sensory or
mental capabilities or lack of experience and / or
knowledge use electrical devices unsupervised.
• For ventilation purposes, leave a free space of at
least 10 cm all around the set.
•Do not block ventilation holes.
•Do not place the TV on sloping or unstable surfaces,
the TV may tip over.
• Use this device in moderate climates.
• The power cord plug should be easily accessible. Do
not place the TV, furniture, etc. on the power cord.
A damaged power cord/plug can cause re or give
you an electric shock. Handle the power cord by the
plug, do not unplug the TV by pulling the power cord.
Never touch the power cord/plug with wet hands
as this could cause a short circuit or electric shock.
Never make a knot in the power cord or tie it with
other cords. When damaged it must be replaced,
this should only be done by qualied personnel.
•Do not use this TV in a humid or damp place. Do
not expose the TV to liquids. If any liquid falls into
the cabinet unplug the TV and have it checked by
qualied personnel before operating it any further.
•Do not expose the TV to direct sunlight or other
heat sources.
• The TV should not be placed near to open ames or
sources of intense heat such as an electric heater.
• Excessive sound pressure from
earphones and headphones can cause
hearing loss.
• Ensure that no open ame sources, such
as lit candles, are placed on top of the TV.
• To prevent injury, this TV must be securely
attached to the wall in accordance with
the installation instructions (if the option
is available).
• Occasionally, a few non-active pixels may appear
on the screen as a xed blue, green or red point.
Please note that this does not affect the performance
of your product. Take care not to scratch the screen
with ngernails or other hard objects.
• Before cleaning, unplug the TV from the wall socket.
Only use a soft, dry cloth while cleaning.
Warning
Risk of electric shock
Caution
Important
Notice
Serious injury or death risk
Dangerous voltage risk
Injury or property damage risk
Operating the system correctly
Additional notes marked
English - 2 -
Getting Started
Notications&Features&Accessories
Environmental Information
This television is designed to consume less energy
to help save the environment. To reduce energy
consumption, you should take the following steps:
You can use the Power Save Mode setting, located
in the Picture menu. If you set the Power Save Mode
as Eco, the TV will switch to energy-saving mode
and the luminance level of TV set will be decreased
to the optimum level. Note that some picture settings
will be unavailable to be changed when the TV is in
Power Save Mode.
If Picture Off is selected, “Screen will be off in
15 seconds.” message will be displayed. Select
PROCEED and press OK to continue. The screen
will be off immediately.
When the TV is not in use, please switch off or
disconnect the TV from the mains plug. This will also
reduce energy consumption.
StandbyNotications
1) If the TV does not receive any input signal (e.g.
from an aerial or HDMI source) for 5 minutes, the TV
will go into standby. When you next switch-on, the
following message will be displayed: “Standby Cause
No Signal”. Press OK to continue.
2) If the TV has been left on and not been operated
for a while, the TV will go into standby. When you next
switch-on, the following message will be displayed.
“Standby Cause No Operation” Press OK to
continue.
Features
• 3D Viewing: This product supports the viewing
of 3D content from devices such as a High
Denition Satellite Receiver or Blu-ray Player via
HDMI, PC,YPBPR, USB inputs or via an available
broadcast.
• Remote controlled colour LED TV.
• Fully integrated digital/cable TV (DVB-T2/C)
• DVB T2.
• HDMI inputs are for connecting a device that has
a HDMI socket.
• USB input.
• Programme recording.
• Programme timeshifting.
• OSD menu system.
• Scart socket for external devices (such as DVD
Players, PVR, video games, etc.)
• Stereo sound system.
• Teletext.
English - 3 -
• Headphone connection.
• Automatic programming system.
• Manual tuning.
• Automatic power down after up to six hours.
• Sleep timer.
• Child lock.
• Automatic sound mute when no transmission.
• NTSC playback.
• AVL (Automatic Volume Limiting).
• PLL (Frequency Search).
• PC input.
• Plug&Play for Windows 98, ME, 2000, XP, Vista,
Windows 7.
• Game Mode (Optional).
• Ethernet (LAN) for Internet connectivity and service
• 802.11n WIFI Support via USB dongle (Optional).
• DLNA.
Accessories Included
Remote Control
Batteries: 2 x AAA
Instruction Book
Quick Start Guide
Side AV Connection Cable
3D Glasses x8
Nero Media Home CD
Mini scart adapter cable
TV Control Buttons & Operation
1. Standby On/Off button
2. TV/AV button
3. Programme Up/Down buttons
4. Volume Up/Down buttons
Operation with the Buttons on the TV
Press button to decrease volume or
button to increase volume. Press P/CH + button to
select the next programme or P/CH - button to select
the previous programme.
Press the or button at the same
time to view main menu. In the Main menu select
sub-menu using TV/AV button and set the sub-
menu using or buttons. To see
what options are available via the menu, refer
to the menu system section of this manual.
Press the TV/AV button in the control panel on
the TV to switch between AV modes.
Note: Function indications of the buttons will
be displayed on the screen when pressed.
Inserting the Batteries into the Remote
Lift the cover on the back of the remote upward
gently. Install two AAA batteries. Make sure to
match the + and - ends of the batteries in the
battery compartment (observe the correct polarity)
Replace the cover.
Connect Power
IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz socket. After unpacking, allow
the TV set to reach the ambient room temperature
before you connect the set to the mains. Plug the
power cable to the mains socket outlet.
Antenna/Cable Connection
Connect the aerial or cable TV plug to AERIAL INPUT
(ANT-TV) socket located on the rear bottom side of
the TV.
Notication
Manufactured under license from Dolby Laboratories.
TRADEMARK ACKNOWLEDGMENT
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
“HDMI, the HDMI logo and High-Denition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.”
“DLNA, the DLNA Logo and DLNA CERTIFIED are
trademarks, service marks, or certication marks of
the Digital Living Network Alliance.”
“YouTube and the YouTube logo are trademarks of
Google Inc.”
Information for Users on Disposal of Old
Equipment and Batteries
[European Union only]
These symbols indicate that equipment with these
symbols should not be disposed of as general
household waste. If you want to dispose of the
product or battery, please consider the collection
systems or facilities for appropriate recycling.
Notice: The sign Pb below the symbol for batteries indicates
that this battery contains lead.
Battery
Products
English - 4 -
Specication
TV Broadcasting PAL B/G D/K K
Receiving Channels VHF (BAND I/III) - UHF
Number of Preset
Channels
Channel Indicator On Screen Display
RF Aerial Input 75 Ohm (unbalanced)
Operating Voltage 220-240V AC, 50Hz.
Audio German + Nicam Stereo
Audio Output Power
(WRMS.) (10% THD)
Power Consumption 110 W
TV Dimensions
DxLxH (with foot)
TV Dimensions
DxLxH (without
foot)
Display 47”
Operation
temperature and
operation humidity:
(BAND U) - HYPERBAND
1.000
2x10W
220x1064x684
41x1064x616
0ºC up to 40ºC, 85%
humidity max
Teletext
Press “ ” button to enter. Press again to activate
mix mode. Press once more to exit. Follow the
instructions displayed on digital teletext screen.
Digital Teletext (for UK only)
Press“ ” button to view digital teletext information.
Operate it with the coloured buttons, cursor buttons
and the OK button. The operation method may differ
depending on the contents of the digital teletext.
Follow the instructions displayed on the digital teletext
screen. When the “ ” button is pressed again, the
TV returns to television broadcast.
English - 5 -
Getting Started
Remote Control - 1
NOTE: The Remote Control range is approximately 7m
/ 23ft.
Using My button 1 (*)
This button’s main function is to run Youtube link.
However, if you want to change this function, you can
press MY BUTTON 1 for ve seconds when on a desired
source, channel or link, until the “MY BUTTON IS SET”
message is displayed on the screen. This conrms that
the selected MY BUTTON is now associated with the
selected function. Note that if you perform rst time
installation, MY BUTTON 1 will return to its default
function.
Using My Button 2 (**)
Press MY BUTTON 2 for ve seconds when on a
desired source, channel or link, until the “MY BUTTON
IS SET” message is displayed on the screen. This
confirms that the selected MY BUTTON is now
associated with the selected function.
English - 6 -
1. Source
2. Sleep Timer
3. Internet Portal
4. Play ( in media browser mode )
5. Programme recording
6. Rapid reverse
7. Mono/Stereo - Dual I-II / Current language (in
DVB channels)
8. Green button
9. Red button
10. Numeric buttons
11. Channel List/TV source
12. Menu
13. Volume up / down
14. Back (Return) / Index (in TXT mode)
15. Favourite channel list
16. Expand (in TXT mode) / Screen size
17. My button 1 / Youtube (*)
18. My button 2 (**)
19. Teletext / Mix
20. Electronic programme guide
21. Mute
22. Info / Reveal (in TXT mode)
23. Exit (return)
24. Ok / Select / Hold (in TXT mode)
25. Programme up - Page down / Programme down
- Page up
26. Navigation buttons
27. Quick menu
28. Previous programme
29. Blue button
30. Yellow button
31. Subtitle on / off
32. Rapid advance
33. Stop ( in media browser mode )
34. Pause (in media browser mode) / Timeshift
recording
35. Media browser
36. Picture mode selection / Changes picture mode
(in media browser video mode)
37. Standby button
38. Function LED
Getting Started
Connections
Connector Type Cables Device
Scart
Connection
(back)
Mini Scart
Connection
(rear bottom)
VGA
Connection
(back)
PC/YPbPr
Audio
Connection
(back)
HDMI
Connection
(bottom&side)
S/PDIF
(Optical Out)
Connection
(bottom)
Side AV
(Audio/Video)
Connection
(side)
Headphone
Connection
(side)
Mini Scart adapter
cable (supplied)
Side Audio
YPbPr or PC Connection Cable
(not supplied)
Side AV
Connection Cable
(supplied)
NOTE: When connecting
a device via the YPbPr or
Side AV input, you must
use a connection cables
to enable connection. See
the illustrations above. |
To enable PC audio, you
will need to use the SIDE
AV CONNECTION cable’s
WHITE & RED inputs. | If an
external device is connected
via the SCART socket, the TV
will automatically switch to AV
mode.| When receiving DTV
channels (Mpeg4 H.264) or
while in Media Browser mode,
output will not be available
via the scart socket. | When
using the wall mounting kit
(optional), we recommend
that you plug all your cables
into the back of the TV before
mounting on the wall. | Insert
or remove the CI module only
when the TV is SWITCHED
OFF. You should refer to the
module instruction manual
for details of the settings.
| Each USB input of your TV
supports devices up to 500mA.
Connecting devices that have
current value above 500mA may
damage your TV.
YPbPr Video
Connection
(side)
USB
Connection
(side)
CI
Connection
(side)
Subwoofer
Connection
(back)
YPbPr Connection
Cable(not supplied)
English - 7 -
CAM
module
Getting Started
First Time Installation - USB Connections
Switching On/Off
To Switch the TV On
Connect the power cord to the 220-240V AC, 50 Hz.
To switch on the TV from standby mode either:
Press the “ ” button, P+ / P- or a numeric button on
the remote control.
To Switch the TV Off
Press the “ ” button on the remote control or press the
“ ” touch button on the TV. The TV will now switch to
standby mode.
To power down the TV completely, unplug the
power cord from the mains socket.
Note: When the TV is switched to standby mode, the standby
LED can blink to indicate that features such as Standby Search,
Over Air Download or Timer is active. The LED can also blink
when you switch on the TV from standby mode.
First Time Installation
When turned on for the first time, the language
selection screen is displayed. Select the desired
language and press OK.
The First Time Installation (FTI) screen will be
displayed next. Set your preferences using the
navigation buttons and when nished, press OK to
continue.
You can activate Store mode option to be available
in “Other settings” menu and your TV’s settings will
be optimized for best display quality. A conrmation
screen will be displayed. Select YES to proceed.
If Home Mode is selected, Store mode will not be
available after the First Time Installation. Press OK
button to continue.
Aerial Installation
If you select AERIAL option from the Search Type
screen, the television will search for digital terrestrial
TV broadcasts.
NOTE: You can press MENU button to cancel.
After all the available stations are stored, the Channel
List will be displayed on the screen. If you like how the
channels are sorted according to the LCN (*), please
select “Yes” and than press OK.
Press MENU button to quit channel list and watch TV.
(*) LCN is the Logical Channel Number system that
organizes available broadcasts in accordance with a
recognizable channel sequence (if available).
Cable Installation
If you select CABLE option and press OK button on
the remote control a conrmation message will be
displayed. To continue, select YES and press OK. To
cancel operation, select NO and press OK. You can
select frequency ranges from this screen.
Enter the frequency range manually by using the
numeric buttons.
Note: Searching duration will change depending on
the selected search step.
Media Playback via USB Input
You can connect a 2.5” and 3.5” inch (hdd with
external power supply) external hard disk drives or
USB memory stick to your TV by using the USB inputs
of the TV.
IMPORTANT! Back up your files before making
any connections to the TV. The Manufacturer
will not be responsible for any file damage or
data loss. Certain types of USB devices (e.g.
MP3 Players) or USB hard disk drives/memory
sticks may not be compatible with this TV. The
TV supports FAT32 and NTFS disk formatting
but recording will not be available with NTFS
formatted disks.
While formatting a USB hard disk that has
1TB (Tera Byte) or more file capacity, you can
experience problems with the formatting process.
Quickly plugging and unplugging USB devices,
is a very hazardous operation. This may cause
physical damage to the USB player and the USB
device itself. Do not pull out the USB module while
playing a le.
You can use USB hubs with your TV’s USB inputs.
External power supplied USB hubs are recommended
in such a case.
It is recommended to use the TV’s USB input(s)
directly, if you are going to connect a USB hard disk.
English - 8 -
Recording a Programme
IMPORTANT: When using a new USB hard disk drive,
it is recommended that you rst format the disk using
your TV’s “Format Disk” option.
Note: To record a programme, you should rst connect
a USB disk to your TV while the TV is switched off.
You should then switch on the TV to enable the
recording feature.
To use the recording function, you need to connect
a USB disk or an external hard disk drive to the TV
and the connected USB disk should have at least 1
GB capacity and should have 2.0 speed compatibility.
If the connected USB device does not support 2.0
speed, an error message will be displayed.
Note: Recorded programmes are saved into the
connected USB disk. If desired, you can store/copy
recordings onto a computer; however, these les will
not be available to be played on a computer. You can
play the recordings only via your TV.
Note: Lip Sync delay may occur during the timeshifting.
Radio record is supported. The TV can record
programmes up to ten hours.
Recorded programmes are split into 4GB partitions.
If the writing speed of the connected USB disk is not
sufcient, the recording may fail and the timeshifting
feature may not be available.
It is recommended to use USB hard disk drive to
recording HD programmes.
Do not plug out the USB/HDD during a recording. This
may harm the connected USB/HDD.
Multipartition support is available. A maximum of two
different partitions are supported. The rst partition of
the USB disk is used for PVR ready features. It also
must be formatted as the primary partition to be used
for the PVR ready features.
Some stream packets may not be recorded because of
signal problems, so sometimes the video may freeze
during playback.
Record, Play, Pause, Display (for PlayListDialog) keys
can not be used when teletext is ON. If a recording
starts from the timer when teletext is ON, teletext
is automatically turned off. Also teletext usage is
disabled when there is an ongoing recording or
playback.
Timeshift Recording
Press (PAUSE) button while watching a broadcast
to activate timeshifting mode.In timeshifting mode, the
programme is paused and simultaneously recorded
to the connected USB disk. Press (PLAY) button
again to resume the paused programme from where
you stopped. Press the STOP button to stop timeshift
recording and return to the live broadcast.
Note: Timeshift cannot be used while in radio mode.
Note: You cannot use the timeshift fast reverse feature
before advancing the playback with the fast forward
option.
Instant Recording
Press (RECORD) button to start recording an
event instantly while watching a programme. You can
press (RECORD) button on the remote control
again to record the next event on the EPG. In this
case, an OSD will be displayed, indicating the
programmed events for recording. Press (STOP)
button to cancel instant recording.
Note: You can not switch broadcasts or view the Media Browser
during the recording mode. While recording a programme or
during the timeshifting, a warning message appears on the
screen if your USB device speed is not sufcent.
Watching Recorded Programmes
Select the Recordings Library from the Media
Browser menu. Select a recorded item from the list (if
previously recorded). Press the OK button to view the
Play Options. Select an option then press OK button.
Note: Viewing main menu and menu items will not be available
during the playback.
Press the (STOP) button to stop a playback and
return to the Recordings Library.
Slow Forward
If you press the (PAUSE) button while watching
recorded programmes, the slow forward feature will be
available. You can use the button to slow forward.
Pressing the button consecutively will change slow
forwarding speed.
RecordingConguration
Select the Recording Conguration item in the
Settings menu to congure the recording settings.
Format Disk: You can use the Format Disk feature
for formatting the connected USB disk. Your pin is
required to use the Format Disk feature (default pin
is 0000).
IMPORTANT: Note that ALL the data stored on the
USB disk will be lost and the disk format will be
converted to FAT32 if you activate this feature. If
your USB disk malfunctions, you can try formatting
the USB disk. In most cases formatting the USB disk
will restore normal operation; however, ALL the data
stored on the USB disk will be lost in such a case.
Note: If “USB is too slow” message is displayed on
the screen while starting a recording, try restarting the
recording. If you still get the same error, it is possible that
your USB disk does not meet the speed requirements. Try
connecting another USB disk.
English - 9 -
Media Browser Menu
You can play photo, music, and movie les stored
on a USB disk by connecting it to your TV. Connect
a USB disk to one of the USB inputs located on
the side of the TV. Pressing the MENU button while
in the Media Browser mode will access the Picture,
Sound and Settings menu options. Pressing the
MENU button again will exit from this screen. You
can set your Media Browser preferences by using
the Settings Menu.
Loop/Shufe Mode Operation
Start playback with and
activate
Start playback with
activate
Start playback with
and activate
OK and
TV plays next file and
loop the list.
The same file will
be played in a loop
(repeat).
OK/
The file will be
played in a shuffle.
Quick Menu
The Quick Settings menu allows you to access
some options quickly. This menu includes Power
Save Mode, 3D Mode, Virtual 3D, Picture Mode,
Equalizer Settings, Favourites, Sleep Timer,
FollowMe TV (Optional) and Information booklet
options. Press Q.MENU button on the remote control
to view the quick menu. See the following chapters
for details of the listed features.
FollowMe TV (Optional)
With your tablet you can stream the current
broadcast from your smart TV using the FollowMe
TV feature. Install the appropriate application to
your tablet PC. Start the application.
For further information on using this feature refer to
the instructions of the application you use.
E-Manual (Optional)
You can nd instructions for your TV’s features in
the E-Manual.
To use E-Manual, press to the Info button while
main menu is displayed on the screen.
By using the navigation buttons select a desired
category. Every category includes a different topics.
Select a topic and press OK to read instructions.
To close the E-Manual screen press the Exit button.
Note: The contents of the E-Manual may vary
according to model.
English - 10 -
Loading...
