OPERATION AND PARTS MANUAL
DRUM PUMP MOTORS
Models: M3 M5 M3T M3X M5T M5X M6 M6X M7T M7X M10X M15-M40 M58P M59P
![](/html/80/8079/80791861279c3e44cb1b915cc041f7c014c5c607018cec0d2a3448732c8d48ce/bg2.png)
EU Declaration of Conformity
Finish Thompson Inc. hereby declares that the following electrical equipment fully complies
with the applicable health and safety requirements as specified be the EC Directives listed.
The product may not be taken into service until it has been established that the driven Drum
and Container Pump complies with the provisions of all relevant EC Directives. The complete
product complies with the provisions of the EC Directive on machinery safety provided
pumps manufactured by Finish Thompson Inc. are used.
This declaration is valid provided that the devices are fully assembled and no modifications
are made to these devices.
M3V-UK M5 M5T M5V M5X M13 M54
M56 M59P M59H S2 S3
Type of Device:
Electric Motors for Driving Drum
and Container Pumps
Models:
EC Directives:
Low Voltage Equipment (2006/95/EC)
Electromagnetic Compatibility (2004/108/EC)
Applied Harmonized Standards:
EN 60335-1 EN 60335-2-41
EN 55014-1 EN 55014-2
EN 60529
Manufacturer:
Finish Thompson Inc.
921 Greengarden Road
Erie, Pennsylvania 16501-1591 U.S.A
Signed,
President
January 7, 2013
2
_
![](/html/80/8079/80791861279c3e44cb1b915cc041f7c014c5c607018cec0d2a3448732c8d48ce/bg3.png)
EC DECLARATION OF CONFORMITY
Finish Thompson Inc. hereby declares that the following machines fully comply with the applicable
health and safety requirements as specied by the EC Directives listed. This declaration is valid
provided that the devices are fully assembled and no modications are made to these machines.
Type of Device:
Pump Motor
Pump Motor Models:
M10X
EC Directives:
Equipment and protective systems intended for use in potentially
explosive atmospheres (94/9/EC)
EC-Type Examination:
Physical T echnical Testing Institute 1026
Ostrava-Radvanice
FTZU 08 ATEX 0083X
Product Quality Assurance Notication:
Physical T echnical Testing Institute 1026
Ostrava-Radanice
FTZU 08 ATEX Q 003
Applicable Harmonized Standards:
EN 60079-0:2012
EN 60079-1:2007
Signed,
Casey D. Bowes
CEO and President
July 3, 2013
3
![](/html/80/8079/80791861279c3e44cb1b915cc041f7c014c5c607018cec0d2a3448732c8d48ce/bg4.png)
EU Declaration of Conformity
Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the
applicable health and safety requirements as specified be the EC Directives listed.
The product may not be taken into service until it has been established that the driven Drum
and Container pump complies with the provisions of all relevant EC Directives. The complete
product complies with the provisions of the EC Directive on machinery safety provided
pumps manufactured by Finish Thompson Inc. are used.
This declaration is valid provided that the devices are fully assembled and no modifications
are made to these devices.
Type of Device:
Air Motors for Driving Drum
and Container Pumps
Models:
M6 M6X M18 M19 M20 M57
M65 M66 S4
EC Directives:
Machinery Safety (2006/42/EC)
Applied Harmonized Standards:
EN ISO 12100 Part 1
EN ISO 12100 Part 2
EN 983
Manufacturer:
Finish Thompson Inc.
921 Greengarden Road
Erie, Pennsylvania 16501-1591 U.S.A
Signed,
_
President
January 7, 2013
Person(s) Authorized to Compile Technical File: Michael Smith Engineers Limited
Telephone: 01483 771871
GU21 6PH, UK
4
Oaks Road, Woking, Surrey
![](/html/80/8079/80791861279c3e44cb1b915cc041f7c014c5c607018cec0d2a3448732c8d48ce/bg5.png)
TABLE OF CONTENTS
TABLA DE CONTENIDO
Introduction ........................................................ 6
Warranty and Return Policy ............................... 6
Safety Precautions .............................................. 7
Maintenance Precautions ................................... 7
Installation .......................................................... 8
M3 & M5 Models .............................................. 9
Assembly Drawing and Parts List
M3T & M5T Models ........................................ 10
Assembly Drawing and Parts List
M7T Models ......................................................11
Assembly Drawing and Parts List
M6 Model......................................................... 12
Assembly Drawing and Parts List
M6X Model ...................................................... 13
Assembly Drawing and Parts List
M3X, M5X, M7X & M10X Models ................ 14
Introducción ....................................................... 6
Garantía y Póliza de Devolución ....................... 6
Precauciones de Seguridad ................................ 7
Precauciones de Mantenimiento ........................ 7
Instalación .......................................................... 8
Modelos M3& M5 ............................................. 9
Dibujo de Armadura y Lista de Partes
Modelos M3T & M5T ...................................... 10
Dibujo de Armadura y Lista de Partes
Modelos M7T ....................................................11
Dibujo de Armadura y Lista de Partes
Modelo M6....................................................... 12
Dibujo de Armadura y Lista de Partes
Modelo M6X .................................................... 13
Dibujo de Armadura y Lista de Partes
Modelos M3X, M5X, M7X & M10X .............. 14
BT Models ....................................................... 14
Assembly Drawing and Parts List
M58P-M59P Models ........................................ 15
Assembly Drawing and Parts List
Static Protection Kit ......................................... 16
Modelo BT ....................................................... 14
Dibujo de Armadura y Lista de Partes
Modelos M58P, M59P ...................................... 15
Dibujo de Armadura y Lista de Partes
Guias para el Equipo de Protección Estático ... 17
5
![](/html/80/8079/80791861279c3e44cb1b915cc041f7c014c5c607018cec0d2a3448732c8d48ce/bg6.png)
INTRODUCTION
INTRODUCCIÓN
FTI has been an international designer and manufacturer of drum
pumps and mixers for over twenty years. We make drum pump
selection easy with our complete line of interchangeable motors
and tubes. When properly installed and operated, your Finish
Thompson drum pump or mixer will provide long, trouble free
service.
FTI ha sido diseñador y fabricante internacional de bombas de
tambor y mezcladoras por más de veinte años. Hacemos selección
de bombas de tambor fácil con nuestra línea completa de motores
y tubos intercambiables. Cuando se instala y se maneja correcta-
mente, su bomba de tambor o mezcladora Finish Thompson le
dará servicio por un largo tiempo y sin problemas.
WARRANTY GARANTÍA
Finish Thompson, Inc (manufacturer) warrants this product to
be free of defects in materials and workmanship for a period of
one year from date of purchase by original purchaser. If a warranted defect, which is determined by manufacturer’s inspection,
occurs within this period, it will be repaired or replaced at the
manufacturer’s option, provided (1) the product is submitted with
proof of purchase date and (2) transportation charges are prepaid
to the manufacturer. Liability under this warranty is expressly
limited to repairing or replacing the product or parts thereof and
is in lieu of any other warranties, either expressed or implied.
This warranty does apply only to normal wear of the product or
components. This warranty does not apply to products or parts
broken due to, in whole or in part, accident, overload, abuse,
chemical attack, tampering, or alteration. The manufacturer accepts no responsibility for product damage or personal injuries
sustained when the product is modied in any way. If this warranty
does not apply, the purchaser shall bear all cost for labor, material
and transportation.
Manufacturer shall not be liable for incidental or consequential
damages including, but not limited to process down time, transportation costs, costs associated with replacement or substitution
products, labor costs, product installation or removal costs, or loss
of prot. In any and all events, manufacturer’s liability shall not
exceed the purchase price of the product and/or accessories.
Finish Thompson, Inc (el fabricante) garantiza este producto contra
todo defecto de materiales y mano de obra durante un periodo de un
año des de la fecha de adquisición por parte del comprador original.
Si, dentro de este periodo, se detecta algún defecto cubierto por la
garantía mediante una inspección del fabricante, éste se encargará de
corregirlo, mediante reparación o sustitución, a su elección, siempre
y cuando: (1) el producto le sea devuelto con algún comprobante de
la fecha de compra y (2) a portes pagados. La responsabilidad de
esta garantía se limita expresamente a la reparación o sustitución
del producto o de partes del mismo, y sustituye a cualquier otra
garantía expresa o implícita. Esta garantía sólo se aplica al desgaste
del producto o de sus componentes derivado del uso normal. No es
aplicable a productos o piezas cuya rotura se deba, en todo o en parte,
a accidentes, sobrecargas, abusos, agresión química, manipulación
o alteración. El fabricante declina toda responsabilidad por daños
en el producto o lesiones personales que se produzcan después de
modicar el producto en cualquier forma. Si el comprador no hace
valer esta garantía, deberá asumir todos los gastos de mano de obra,
material y transporte.
El fabricante no es responsable de los daños consecutivos o re-
sultantes incluidos, aunque sin limitación, los relacionados con
la parada de procesos, costes de transporte, costes asociados a la
sustitución de productos, costes de mano de obra, costes de retirada
o instalación de productos, o perdida de benecios. En cualquier
caso, la responsabilidad del fabricante no sobrepasará el precio
de compra del producto y/o los accesorios.
RETURN POLICY
Should you have any problems with this product, please contact
the distributor in your area. The distributor will then determine
if a return to the factory is necessary and will contact the factory
for a return authorization number.
Call our toll free Technical Service Hot Line, 1-800-888-3743,
if you have any questions regarding product operation or
repair.
PÓLIZA DE DEVOLUCIÓN
Si usted tiene cualquier problema con este producto, por favor
póngase en contacto con el distribuidor en su area. Entonces el
determinará si una devolución a la fábrica es necesaria y se pondrá
en contacto con la fábrica para obtener un número de autorización
de devolución.
Llame nuestro servicio técnico al numero 814-455-4478 si tiene
pregunts de operación o reparación.
