Product may differ slightly from that shown
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precau tions should
always be followed. These ins t ructions should be saved for futur e
reference:
• Read and familiarise yourself with all operating instructions before using
this Kettle.
• Before plugging your kettle into the mains, visually check that the kettle is
intact and has not suffered any t ra nsit damage.
• Check that the voltage indicated on the data plate corresponds with that of
the local network before connecting the appliance to t he mains power
supply.
• Do not immerse the appliance, base or its cord in water or any other
liquids.
• Close supervision is required when using this appliance near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by children unless they
are older than 8 and supervised. Keep the appliance and its cord out of the
reach of children aged less than 8 years.
• Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children shall not play with the appliance.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains
supply.
• Always use this appliance on a solid, level, non-f l ammable surface.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has been used,
before it is cleaned and whilst being repaired.
• If the supply cord is damaged, it must be replaced by the manufacturer,
service agent or similarly qualified person in order to avoid a hazard
.
• Do not operate this appliance after a malfunction or after being dropped or
damaged in any way.
• Do not allow the mains cable to hang over sharp edges or come in contact
with hot surfaces.
• Do not run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or high pressure
containers.
• This appliance is intended for household use only and should not be used
for industrial purposes.
• Do not use any accessories or attachments with this appliance other than
those supplied or recommended by supplier – only used the stand provided
with this kettl e.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance and/or
electric shock may occur.
• Ensure appliance is situated in an open area, do not allow it to come in
contact with cupboards, curtains, wall coverings, clothing or other
flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• Do not cover this appliance.
• Never place this appliance on an electric, gas, or any other type of hob.
WARNING: Do not open the lid while the water is boiling. Never
•
fill the kettle more than its capacity, if the kettle is overf illed, boiling
water may be ejected – ensure the water level is between the min and
max marks.
• Always close the lid dur ing use.
CAUTION: The outside surface of the kettle will get hot during
•
use.
• Ensure the kettle is switched off before removing it from the base.
Description of parts
Before the first time you use your kettle
• Please read these operating instructions thoroughly and keep them in
a safe place for future reference.
• Remove all packaging materials and discard responsibly.
• Before using th e kettle for the first time, fill to the max mark and allow
it to boil.
• Pour away the boiled water and then repeat the process. If a slight
taste or odour remains repeat the above process once more.
• Do not immerse the kettle or its base in water.
Instructions for use
• Place the ket tl e base on a flat, level, non-flammable surface
• Pull the lid off and fill the kettle wi t h water to the desired level ensuring that
it is above the MIN mark and below the MAX mark.
• Replace the lid on the kettle by pushing it closed and place it onto the base.
• Insert the mains plug (with dry hands) into the mains socket and switch on
if applicable.
• Push down the power on/off switch which will illuminate the Power Indicator
Light and the water will begin to boil.
• At the end of the boiling cycle the power on/off switch will automatically
switch off.
• Wait until the water has finished boiling before removing it from the base
unit.
• Ensure the lid is correctly closed before pouring boiling water – beware of
scalding.
Cleaning your kettle
• Do not clean your kettle in a dishwasher.
• Always disconnect the kettle from the mains power s upply before
cleaning.
• Wipe clean the outside of the kettle with a soft damp cloth. Never
clean any part of the kettle with harsh or abrasive cleaners.
• Do not submerge any part of the base, mains cable or kettle in water
or any other liquids.
Decalcification of your kettle
• The frequency of the decalcification depends on the hardness of the
water in your area and how often the appliance is used
• If the kettle switches off before it boils or has a white deposit building
up inside then it probably needs to be decalcified.
• Do not use vinegar but a commercially availabl e dec alcification agent;
carefully follow the quantities recommended in the instructions of the
agent.
Fitting a new plug
Waste electrical products should not be disposed of with household
recycle where facilities exist. Check with your Local
Connect
Ensure the outer sheath of the
Europasonic (UK) Ltd
Connect
Connect
The mains lead must be connected as shown below. The wires are
coloured with the following code - Brown wire = Live (L), Blue wire =
Neutral (N), Green & Yellow = Earth (E).
Green &
Yellow to
Earth (E
)
Brown to
Live (L)
Blue to
Neutral
(N)
mains lead is securely held by the
cable clamp
• The Blue wire must be connected to the terminal marked N or
coloured Black.
• The Brown wire must be connected to the terminal marked L or
coloured Red.
• The Green & Yellow wire must be connected to the terminal marked E
or coloured Green.
• Check that there are no cut or stray strands of wire inside the plug.
• Use a 13 Amp BS 1362 fuse, only use BSI or ASTA approved fuses.
• If you are in any way unsure which plug or fuse to use, always refer to
a qualified electrician.
• After replacing or changing a fuse on a moulded plug, the cover must
be refitted to the plug; the appliance must not be used without a fuse
cover.
Technical Data
Voltage : 220-240V AC 50/60Hz
Rated power : 1850 - 2200 W
Capacity : 1700ml
Model Number : SDA1193
waste. Please
Authority or retailer for recycling advice.
Manchester M3 1JS
www.europasonic.com
