Model SDA1029
Stainless Steel Pyramid Kettle
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before
using this Kettle.
• Before plugging your kettle into the mains, visually check that the
kettle is intact and has not suffered any transit damage.
• Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the mains
power supply.
• Do not immerse the appliance, base or its cord in water or any other
liquids.
• Close supervision is required when using this appliance near children.
• Never leave this appliance within reach of children.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains
supply.
• Always use this appliance on a solid, level, non-flammable surface.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has been
used, before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place user at serious risk.
• Do not operate this appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
• Regular, periodic checks should be carried out on the mains cable to
ensure no damage is evident. Should there be any signs of damage
the appliance should not be used.
• Do not allow the mains cable to hang over sharp edges or come in
contact with hot surfaces.
• Do not run the mains cable under carpets, rugs, etc.
• Allow the unit to cool before storage.
• Never place the appliance near to flammable material or high
pressure containers.
• This appliance is intended for household use only and should not be
used for industrial purposes.
• Do not use any accessories or attachments with this appliance other
than those supplied or recommended by supplier.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance
and/or electric shock may occur.
• Ensure appliance is situated in an open area, do not allow it to come
in contact with cupboards, curtains, wall coverings, clothing or other
flammable materials.
• Unplug after each use. Grasp the plug, not the cord.
• Do not cover this appliance.
• Never place this appliance on an electric, gas, or any other type of
hob.
• WARNING: Do not remove lid while the water is boiling.
• Never fill the kettle more than its capacity – ensure the water level is
between the min and max marks.
• Always fit the lid during use and do not remove the lid whilst the water
is boiling.
• CAUTION: The outside surface of the kettle will get hot
during use.
• Ensure the kettle is switch off before removing it from the base.
Description of parts
Lid knob
Filter (Inside Kettle)
Spout
Body
Base
Handle
Removable Lid
Water Level Scale
Power on/off Switch
Power Indicator Light
Before the first time you use your kettle
Please read these operating instructions thoroughly and keep them in
a safe place for future reference.
Before using the kettle for the first time fill to the max mark and allow
to boil. Pour away the boiled water and then repeat the process. If a
slight taste or odour remains repeat the above process once more.
Instructions for use
• Place the kettle on a flat level surface
• Fill the kettle with water to the desired level ensuring that it is above
the MIN mark and below the MAX mark.
• Place the lid on the kettle and place it onto the base.
• Insert the mains plug (with dry hands) into the mains socket.
• Push down the power on/off switch, the indicator light on the bottom
edge of the kettle will illuminate and the water will begin to boil.
• At the end of the boiling cycle the power on/off switch will
automatically switch off and the light will go out.
• Wait until the water has finished boiling before removing it from the
base unit.
• Ensure the lid is correctly fitted before pouring boiling water – beware
of scalding.
Cleaning your kettle
• Do not clean your kettle in a dishwasher.
• Always disconnect the kettle from the mains power supply before
cleaning.
• Wipe clean the outside of the kettle with a soft damp cloth. Never
clean any part of the kettle with harsh or abrasive cleaners.
• Do not submerge any part of the base, mains cable or kettle in water
or any other liquids.
Decalcification of your kettle
• The frequency of the decalcification depends on the hardness of the
water in your area and how often the appliance is used
• If the kettle switches off before it boils or has a white deposit building
up inside then it probably needs to be decalcified.
• Do not use vinegar but a commercially available decalcification agent;
carefully follow the quantities recommended in the instructions of the
agent.
Technical Data
Voltage : 220-240V ~ 50Hz
Rated power : 1850-2200 W
Capacity : 1700ml
Fitting a new plug
If for any reason you need to fit a new plug, the flexible mains lead
must be connected as shown below. The wires in the mains lead fitted
to this appliance are coloured in accordance with the following code:
Brown wire = Live (L)
Blue wire = Neutral (N)
Green & Yellow = Earth (E)
!
If colours of the wires in the mains lead of this appliance do not
correspond with the coloured marking identifying the terminals in your
plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Black. The wire which is
coloured Brown must be connected to the terminal which is marked
with the letter L or coloured Red. The wire which is coloured Green &
Yellow must be connected to the terminal which is marked with the
letter E or coloured Green.
Before refitting the plug cover check that there are no cut or stray
strands of wire inside the plug. Use a 13 Amp BS 1362 fuse, only BSI
or ASTA approved fuses should be used. If you are in any way unsure
which plug or fuse to use, always refer to a qualified electrician.
Connect Green
& Yellow to
Earth (E)
Connect
Brown to
Live (L)
Connect
Blue to
Neutral (N)
Note: After replacing or changing a fuse on a moulded plug which has
a fuse cover, the cover must be refitted to the plug, the appliance
must not be used without a fuse cover.
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.
!
Europasonic (UK) Ltd
Manchester M3 1JS
www.europasonic.com
