62.32 / 62.33 62.32-0300 / 62.33-0300
2 CO (DPDT) 3 CO (3PDT)
2 NO (DPST-NO), ≥ 3 mm*
3 NO (3PST-NO), ≥3 mm*
16/30** 16/30**
250/400 250/400
4,000 4,000
750 750
0.8/— 0.8/1.5 0.8/— 0.8/1.5
16/0.6/0.4 16/1.1/0.7
1,000 (10/10) 1,000 (10/10)
AgCdO AgCdO
6 - 12 - 24 - 48 - 60 - 110 - 120 - 230 - 240 - 400
6 - 12 - 24 - 48 - 60 - 110 - 125 - 220
2.2/1.3 3/3
(0.8…1.1)U
N
(0.85…1.1)U
N
(0.8…1.1)U
N
(0.85…1.1)U
N
0.8 UN/0.6 U
N
0.8 UN/0.6 U
N
0.2 UN/0.1 U
N
0.2 UN/0.1 U
N
10 · 106/30 · 10
6
10 · 106/30 · 10
6
100 · 10
3
100 · 10
3
11/4 15/3
66
1,500 2,500
–40…+70 –40…+50
RT I RT I
• 2 & 3 pole changeover contact
• Plug-in / Faston 187
• 2 & 3 pole normally open contact
(≥ 3 mm contact gap)
• Plug-in / Faston 187
Contact specification
Contact configuration
Rated current/Maximum peak current A
Rated voltage/Maximum switching voltage V AC
Rated load AC1 VA
Rated load AC15 (230 V AC) VA
Motor rating (230/400 V AC) kW
Breaking capacity DC1: 30/110/220 V A
Minimum switching load mW (V/mA)
Standard contact material
Coil specification
Nominal voltage (U
N
) V AC (50/60 Hz)
V DC
Rated power AC/DC VA (50 Hz)/W
Operating range AC
DC
Holding voltage AC/DC
Must drop-out voltage AC/DC
Technical data
Mechanical life AC/DC cycles
Electrical life at rated load AC1 cycles
Operate/release time ms
Insulation between coil and contacts (1.2/50 µs)
kV
Dielectric strength between open contacts V AC
Ambient temperature range °C
Environmental protection
Approvals (according to type)
*
Distance between contacts ≥ 3 mm (EN 60730-1).
** With the AgSnO2 material the
maximum
peak
current is 120 A - 5 ms (NO contact).
F
OR UL RATINGS SEE:
“General technical information” page V
Features
Plug-in mount/Faston 187
16 A Power relay
• Plug-in (92 series sockets) or Faston 187
(4.8x0.5 mm) with optional mounting adaptors
• 2 & 3 Pole changeover contacts or NO
(≥ 3 mm contact gap)
• AC coils & DC coils
• UL Listing (certain relay/socket combinations)
• LED, mechanical indicator & test button options
• Reinforced insulation between coil and
contacts according to EN 60335-1, with
6 mm clearance & 8 mm creepage distance
• SELV coil-contact separator option
• Cadmium Free contact material options
• Sockets and accessories
• European Patent
2
62.33
62.33-0300
62.3x-030062.3x62.32
62.32-0300
62.32 62.33
62.32-0300 62.33-0300
62 Series - Power relays 16 A
