finder 46.52, 46.61 User Manual
• 2 Pole CO, 8 A
• Plug-in/Solder terminals
2 CO (DPDT)
8/15
250/440
2,000
350
0.37
6/0.5/0.15
300 (5/5)
AgNi
1.2/0.5
(0.8...1.1)U
N
(0.73...1.1)U
N
0.8UN/0.4U
N
0.2UN/0.1U
N
10 · 10
6
100 · 10
3
10/3
6 (8 mm)
1,000
–40 ... +70
RT II
46.52
46 Series - Miniature industrial relays, 8 - 16 A
Contact specification
Contact configuration
Rated current/Maximum peak current A
Rated voltage/Maximum switching voltage V AC
Rated load AC1 VA
Rated load AC15 (230 V AC) VA
Single phase motor rating (230 V AC) kW
Breaking capacity DC1: 30/110/220 V A
Minimum switching load mW (V/mA)
Standard contact material
Coil specification
Nominal voltage (U
N
) V AC (50/60 Hz)
V DC
Rated power VA/W
Operating range AC
DC
Holding voltage AC/DC
Must drop-out voltage AC/DC
Technical data
Mechanical life AC/DC cycles
Electrical life at rated load AC1 cycles
Operate/release time ms
Insulation between coil and contacts (1.2/50 µs)
kV
Dielectric strength between open contacts
V AC
Ambient temperature range °C
Environmental protection
Approvals (according to type)
Features
1 & 2 Pole relay range
46.52 - 2 Pole 8 A
46.61 - 1 Pole 16 A
• Socket mount or direct connection via Faston
connectors
• AC coils & DC coils
• Available with: lockable test button,
mechanical indicator & LED indicator
• 8 mm, 6 kV (1.2/50 µs) isolation, coil-contacts
• Cadmium Free contacts
• 1 Pole CO, 16 A
• Plug-in/Faston 187
1 CO (SPDT)
16/25
250/440
4,000
750
0.55
12/0.5/0.15
300 (5/5)
AgNi
1.2/0.5
(0.8...1.1)U
N
(0.73...1.1)U
N
0.8UN/0.4U
N
0.2UN/0.1U
N
10 · 10
6
100 · 10
3
15/5
6 (8 mm)
1,000
–40 ... +70
RT II
46.61
12 - 24 - 48 - 110 - 120 - 230 - 240
12 - 24 - 48 - 110 - 125
1
46.52
46.61
FORUL H
ORSEPOWER ANDPILOTDUTY RATINGS
SEE“General technical information” page
V
29 12.4
20
2.5 0.5 2.5
29 12.4
20
4.75 0.5 4.75
32.86.5
32.8
6.5
8
3
2
12 11
A1
A2
222421
765
1
8.9
5
5
14.4
2.2
5
2
4
3
12
14
11
5.2
5.2
A1
A2
1
7.4
7.5
4.8 12.3
2
Example: 46 series Miniature industrial relay, 1 CO (SPDT), 24 V DC coil, lockable test button and mechanical indicator.
A: Contact material
0 = AgNi
4 = AgSnO
2
(46.61 only)
5 = AgNi + Au (5 µm)
B: Contact circuit
0 = CO (nPDT)
Series
Type
5 = Spade/blade solder terminal
(2.5x0.5)mm
6 = Spade/blade terminal
Faston 187 (4.8x0.5)mm
No. of poles
1 = 1 pole, 16 A
2 = 2 poles, 8 A
Coil version
9 = DC
8 = AC (50/60 Hz)
Coil voltage
See coil specifications
6 1 09
D: Special versions
0 = Standard
C: Options
2 = Mechanical indicator
4 = Lockable test button +
mechanical indicator
54 =Lockable test button + LED (AC) +
mechanical indicator
74 =Lockable test button + double LED
(DC non-polarized) + mechanical indicator
Ordering information
ABCD
... .
02446
46 Series - Miniature industrial relays, 8 - 16 A
0 4 0
Type Coil version A B C D
46.52 AC - DC 0 - 5 0 2 - 40
AC 0 - 5 0 54 /
DC 0 - 5 0 74 /
46.61 AC - DC 0 - 4 - 5 0 2 - 40
AC 0 - 4 - 5 0 54 /
DC 0 - 4 - 5 0 74 /
Selecting features and options: only combinations in the same row are possible.
Preferred selections for best avaliability are shown in bold.
Lockable test button and mechanical flag indicator
(0040, 0054, 0074)
The dual-purpose Finder test button can be used in two ways:
Case 1
) The plastic pip (located directly below the test button) remains intact. In this case, when
the test button is pushed, the contacts operate. When the test button is released the contacts return
to their former state.
Case 2) The plastic pip is broken-off (using an appropriate cutting tool). In this case, (in addition
to the above function), when the test button is pushed and rotated, the contacts are latched in
the operating state, and remain so until the test button is rotated back to its former position.
In both cases ensure that the test button actuation is swift and decisive.
1
8 A2
A2
5 1
A1
8
5
A1
C: Option 54
LED (AC)
C: Option 74
LED (DC, non-polarized)
Descriptions: Options
