44.52 44.62
1
2 CO (DPDT) 2 CO (DPDT)
6/10 10/20
250/400 250/400
1,500 2,500
250 500
0.185 0.37
6/0.3/0.13 10/0.3/0.13
300 (5/5) 300 (5/5)
AgNi AgNi
——
6 - 9 - 12 - 14 - 24 - 28 - 48 - 60 - 110 - 125
—/0.65/0.5 —/0.65/0.5
——
(0.73…1.5)U
N
/(0.73…1.7)UN(0.73…1.5)UN/(0.8…1.7)U
N
—/0.4 U
N
—/0.4 U
N
—/0.1 U
N
—/0.1 U
N
—/20 · 10
6
—/20 · 10
6
150 · 10
3
100 · 10
3
8/5 - (12/5 sensitive) 8/5 - (12/5 sensitive)
6 (8 mm) 6 (8 mm)
1,000 1,000
–40…+85 –40…+85
RT II RT II
Contact specification
Contact configuration
Rated current/Maximum peak current A
Rated voltage/Maximum switching voltage V AC
Rated load AC1 VA
Rated load AC15 (230 V AC) VA
Single phase motor rating (230 V AC) kW
Breaking capacity DC1: 30/110/220 V A
Minimum switching load mW (V/mA)
Standard contact material
Coil specification
Nominal voltage (U
N
) V AC (50/60 Hz)
V DC
Rated power AC/DC/sens. DC VA (50 Hz)/W/W
Operating range AC
DC/sens. DC
Holding voltage AC/DC
Must drop-out voltage AC/DC
Technical data
Mechanical life AC/DC cycles
Electrical life at rated load AC1 cycles
Operate/release time ms
Insulation between coil and contacts (1.2/50 µs)
kV
Dielectric strength between open contacts V AC
Ambient temperature range °C
Environmental protection
Approvals (according to type)
Copper side view Copper side view
Features
2 Pole relay range
44.52 - 2 Pole 6 A (5 mm pin pitch)
44.62 - 2 Pole 10 A (5 mm pin pitch)
PCB mount - direct or via PCB socket
35 mm rail mount - via screw and screwless sockets
• High physical separation between adjacent
contacts
• DC coils (Standard or sensitive)
• Cadmium Free contact materials
• 8 mm, 6 kV (1.2/50 µs) isolation, coil-contacts
• UL Listing (certain relay/socket combinations)
• Flux proof: RT II
• 95 series sockets
• Coil EMC suppression
• Timer accessories 86 series
• 2 Pole, 6 A
• 5 mm contact pin pitch
• PCB or 95 series sockets
• 2 Pole, 10 A
• 5 mm contact pin pitch
• PCB or 95 series sockets
FOR UL HORSEPOWER AND PILOT DUTY RATINGS
SEE “General technical information” page V
44 Series - Miniature PCB relays 6 - 10 A
29
12.4
25
0.4 1
5
Page 2
Example: 44 series PCB relay, 2 CO (DPDT) 10 A contacts, 24 V DC coil.
A: Contact material
0 = Standard AgNi
4 = AgSnO
2
for 44.62 only
5 = AgNi + Au (5 µm)
for 44.52 only
B: Contact circuit
0 = CO (DPDT)
Series
Typ e
5 = PCB - 5 mm pinning
6 = PCB - 5 mm pinning
No. of poles
2 = 2 pole for
44.52, 6 A
44.62, 10 A
Coil version
7 = Sensitive DC
9 = DC
Coil voltage
See coil specifications
D: Special versions
0 = Flux proof (RT II)
C: Options
0 = None
ABCD
2
44 Series - Miniature PCB relays 6 - 10 A
Technical data
Ordering information
6 2 09
... .
02444 0
0
0
Type Coil version A B C D
44.52 DC - sens. DC 0 - 5 00 0
44.62 DC - sens. DC 0 - 4 00 0
Selecting features and options: only combinations in the same row are possible.
Preferred selections for best availability are shown in bold.
Insulation according to EN 61810-1
Nominal voltage of supply system V AC 230/400
Rated insulation voltage V AC 250 400
Pollution degree 3 2
Insulation between coil and contact set
Type of Insulation Reinforced (8 mm)
Overvoltage category III
Rated impulse voltage kV (1.2/50 µs) 6
Dielectric strength V AC 4,000
Insulation between adjacent contacts
Type of insulation Basic
Overvoltage category III
Rated impulse voltage kV (1.2/50 µs) 4
Dielectric strength V AC 2,500
Insulation between open contacts
Type of disconnection Micro-disconnection
Dielectric strength V AC/kV (1.2/50 µs) 1,000/1.5
Conducted disturbance immunity
Burst (5...50)ns, 5 kHz, on A1 - A2 EN 61000-4-4 level 4 (4 kV)
Surge (1.2/50 µs) on A1 - A2 (differential mode) EN 61000-4-5 level 3 (2 kV)
Other data
Bounce time: NO/NC ms 4/4
Vibration resistance (5…55)Hz: NO/NC g 15/12
Shock resistance g 16
Power lost to the environment without contact current W 0.6
with rated current W 1.2 (44.52) 2.7 (44.62)
Recommended distance between relays mounted on PCB mm ≥ 5
Page 3
3
44 Series - Miniature PCB relays 6 - 10 A
Nominal Coil Operating range Resistance Rated coil
voltage code
consumption
U
N
U
min
U
max
R I at U
N
VVVΩ mA
6 9.006 4.4 9 55 109
9 9.009 6.6 13.5 125 72
12 9.012 8.8 18 220 55
14 9.014 10.2 21 300 47
24 9.024 17.5 36 900 27
28 9.028 20.5 42 1,200 23
48 9.048 35 72 3,500 14
60 9.060 43.8 90 5,500 11
110 9.110 80.3 165 18,000 6.2
125 9.125 91.2 188 23,500 5.3
DC coil data - 0.65 W standard
Nominal Coil Operating range Resistance Rated coil
voltage code
consumption
U
N
U
min
*U
max
R I at U
N
VVVΩ mA
6 7.006 4.4 10.2 75 80
9 7.009 6.6 15.3 160 56
12 7.012 8.8 20.4 300 40
14 7.014 10.2 23.8 400 35
24 7.024 17.5 40.8 1,200 20
28 7.028 20.5 47.6 1,600 17.5
48 7.048 35 81.6 4,800 10
60 7.060 43.8 102 7,200 8.4
110 7.110 80.3 187 23,500 4.7
125 7.125 100 219 32,000 3.9
DC coil data - 0.5 W sensitive
*U
min
= 0.8 UNfor 44.62
Coil specifications
Contact specification
Cycles
F 44 - Electrical life (AC) v contact current
• When switching a resistive load (DC1) having voltage and current
values under the curve, an electrical life of ≥ 100·103can be expected.
• In the case of DC13 loads, the connection of a diode in parallel with
the load will permit a similar electrical life as for a DC1 load.
Note: the release time for the load will be increased.
H 44 - Maximum DC1 breaking capacity
DC breaking current (A)
DC voltage (V)
1 - Max. permitted coil voltage.
2 - Min. pick-up voltage with coil at ambient temperature.
R 44 - DC coil operating range v ambient temperature
Standard coil
R 44 - DC coil operating range v ambient temperature
Sensitive coil
1 - Max. permitted coil voltage.
2 - Min. pick-up voltage with coil at ambient temperature.
Resistive load - cosϕ = 1
Inductive load - cosϕ = 0.4
limit for 44.52
2 contacts in series
single contact
44.62 current limit
44.52 current limit
