ADVANCED CLEANING APPLIANCES
™
®
DustTamer
ULTRA D4500
®
INDEX
2
IMPORTANT SAFEGUARDS 4
ABOUT YOUR DUSTTAMER ULTRA
®
6
DUSTTAMER ULTRA®DESCRIPTION 7
BATTERY CHARGING PROCEDURE 8
2-STAGE HEPA FILTRATION 10
LAMBSWOOL DUSTER 11
DUSTING 11
CLEANING LAMBSWOOL DUSTER WITH VACUUM CHAMBER 12
LAMBSWOOL DUSTER STORAGE 14
MAINTENANCE 15
Emptying/Cleaning the Dust Drawer
Cleaning/Replacing the HEPA Filter
Cleaning the DustTamer Ultra®
BATTERY REMOVAL/DISPOSAL 18
ACCESSORIES 19
WARRANTY Back Cover
PG
3
Congratulations!
You now own a top-quality
FilterStream
®
DustTamer Ultra
®
Vacuum Powered Duster.
To ensure maximum satisfaction,
please take a few moments to
review the following important
information before using this item.
Thank You!
IMPORTANT SAFEGUARDS
4
When using electrical appliances,
always follow basic precautions,
including the following:
PLEASE READ ALL
INSTRUCTIONS CAREFULLY
BEFORE USING THIS
APPLIANCE
WARNING:
To reduce the risk of fire,
electrical shock or injury:
• Close supervision is necessary
when any appliance is used
by or near children. Do not
allow this appliance to be
used as a toy.
• Do not use without the Dust
Drawer and HEPA filter in
place. Replace a damaged
filter promptly.
• To protect against risk of
electrical shock: (i) do not put
vacuum chamber or charger in
water or other liquid, and (ii)
do not insert a wet duster into
the vacuum chamber
• Do not put anything that is
burning or smoking, such as
cigarettes, matches, or hot
ashes into the vacuum chamber.
• Avoid putting hard, sharp
objects in the vacuum chamber.
They may damage the vacuum
chamber and the filters.
• Do not use this product to pick
up toxic substances,
flammable or combustible
liquids such as gasoline or
operate in the presence of
explosive or flammable fumes.
Do not immerse the vacuum
chamber in any liquid.
• Do not operate in the
presence of explosives and/or
flammable fumes or liquids.
• Do not unplug the charger by
pulling on the cord. Never
carry the charger or vacuum
chamber by the cord or yank
to disconnect from an outlet;
instead, grasp the charger
and pull to disconnect. Do not
pull cord around sharp edges
or corners.
• Do not allow the cord to hang
over the edge of a table or
counter or touch hot surfaces.
The vacuum chamber should
be placed away from sinks and
hot surfaces.
• The use of an extension cord
is not recommended. Only
plug the charger into a
standard electrical outlet
(120V/60 Hz).
• Use only the charger supplied
with this unit to recharge the
vacuum chamber.
5
• Do not attempt to use the
charger with any other product.
• Never handle the plug or vacuum
chamber with wet hands.
• Do not operate with a
damaged cord or charger.
If the vacuum chamber has
been dropped into water or
if it malfunctions, return the
unit to the store where it
was purchased.
• Unplug the charger from
outlet before any routine
cleaning or maintenance of the
vacuum chamber.
• Do not put any object into
openings. Do not use with any
opening blocked; keep free of
dust, lint, hair, or anything that
may reduce airflow.
• Do not use on or near hot
surfaces.
• Use extra care when cleaning
on stairs.
• This vacuum chamber is
intended for household use
only and not for commercial or
industrial use.
• Use only as described in this
manual. Use only
FilterStream
®
DustTamer
®
accessories and filters.
• The vacuum chamber should
be unplugged before turning
on the unit.
• This product contains nickel
cadmium (Ni-cad) batteries.
Do not incinerate the batteries
as they will explode at high
temperatures. Always dispose
of the batteries in accordance
with your state’s laws. Please
call 1-800-822-8837 for
disposal instructions and drop
off locations in your area.
• Leaks from a battery cell can
occur under extreme
conditions. If the battery
liquid gets on skin: (i) wash
immediately with water. If it
gets in your eyes,
immediately flush your eyes
with a mild solution of baking
soda and water and seek
medical attention.
SAVE THESE
INSTRUCTIONS
ABOUT YOUR DUSTTAMER ULTRA
®
6
The revolutionary DustTamer
Ultra
®
, the world’s first dusting
appliance, makes dusting faster,
easier and cleaner!
With DustTamer Ultra
®
, there’s
no more brushing of allergy
causing dust back and forth and
into the air, and no more wasted
time with slow, messy dusting
cloths.
To use, you simply dust your
home with the professional
quality Australian lambswool
duster and conveniently suction
off the dust on-the-spot with
the cordless, rechargeable
vacuum chamber!
To ensure that only clean, dust
and allergen free air re-enters
your home, DustTamer Ultra
®
utilizes a 2-stage HEPA filtration
system that captures 99.97% of
dust and allergens.
Your DustTamer Ultra
®
D4500
comes complete with a handy 22"
duster, a Dust Drawer containing
a washable/reusable Stainless
Steel Pre-Filter and a certified
HEPA filter.
Please follow this manual for the
proper set-up, use, and care of this
revolutionary cleaning product.
Your DustTamer Ultra
®
Vacuum
Powered Duster contains the
following parts:
Vacuum Chamber Housing
AC Adapter
Lambswool Duster (22”)
Duster Hanging Hook
Dust Agitation/Suction Vents
Dust View Window
Dust Drawer with Stainless
Steel Pre-Filter Screen
HEPA Filter
On/Off Switch
Carrying Handle
Battery Compartment
(located on bottom of unit)
Motor and Fan
Air Exhaust
AC Adapter Jack
(located at the bottom
rear of unit)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
7
DUSTTAMER ULTRA®DESCRIPTION
1
2
3
4
5
12
13
14
6
7
8
9
10
11
8
7
BATTERY CHARGING PROCEDURE
8
Your DustTamer Ultra®uses a
cordless, rechargeable Vacuum
Chamber to suction dust off your
DustTamer
®
Duster. When fully
charged, your Vacuum Chamber
will have enough power to clean
your Duster dozens of times.
To charge your DustTamer
Ultra
®
, please do the following:
1. Remove the supplied AC
Adapter from the Carton and
connect it to the AC Adapter
Jack located at the rear bottom
of the Vacuum Chamber and
plug the AC Adapter into a wall
outlet. (See figure 1)
1Fig.
9
Important: Before first use,
charge your DustTamer Ultra
®
for at least 24 hours.
Note 1: To maintain a charge,
keep the AC Adapter and
Vacuum Chamber plugged into
a standard wall outlet at all
times. When charging, the AC
Adapter may be warm to the
touch. This is normal.
The Vacuum Chamber can be
left in one location during
dusting, (bringing the Duster
back to it for cleaning) or you
can carry the Vacuum
Chamber with you from room
to room for extra convenience.
(See figure 2)
Note 2: As with many
rechargeable products, we
recommend that the AC
Adapter not be plugged into
the wall outlet when the unit is
in use (i.e. while cleaning the
Duster with suction action).
2Fig.
2-STAGE FILTRATION SYSTEM
10
Traditional dusting tools push
allergy causing dust from one
spot to another or into the air.
With its 2-stage HEPA filtration
system, DustTamer Ultra
®
overcomes this problem.
(See figure 3)
Stage 1: A reusable, washable
Dust Drawer containing a
Stainless Steel Pre-Filter
Screen traps larger dust
particles for clean and
easy removal when full
(see “Maintenance”
section of this manual for
emptying instructions).
Stage 2: An included
FilterStream
®
certified
HEPA Filter captures
99.97% of microscopic
dust particles, pollen,
bacteria and other
allergens down to 0.3
microns in size.
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
1
2
3
Fig.
11
Your DustTamer Ultra®includes a
professional quality 100%
Lambswool Duster made in
Australia.
Lambswool dusters are the choice
of cleaning professionals because
they are:
Fast - the large head covers large
areas quickly
Superior at Dust Pick Up -
lambswool has natural dust
grabbing fibers, electrostatic
action and lanolin oil that attracts
and holds dust like a magnet
Incredibly Soft & Versatile -
won’t scratch delicate items; great
for small figurines or large tables
Reusable - saves time and money!
LAMBSWOOL DUSTER • DUSTING
DUSTING
The included Lambswool Duster
is ideal for cleaning any areas
where dust accumulates:
• Venetian blinds
• lamps
• louvered doors
• fine furniture
• collectibles
• televisions/stereo equipment
• plant leaves
• computer monitors/keyboards
• automobile dashboards
For helpful dusting & cleaning
tips, see our handy DustTamer
®
Cleaning Tips booklet included
with your DustTamer Ultra
®
.
To clean your Lambswool Duster
in the Vacuum Chamber, simply
follow these steps:
a. Press and hold the unit’s
on/off switch to start the
suction action. (see figure 4)
b. Insert the lambswool duster
into the vacuum chamber and
slowly
move the duster in an
up and down twisting motion
several times. (see Figure 5)
c. The combination of the Dust
Agitation/Suction Vents with
the up and down twisting
motion will most effectively
remove dust from the
Lambswool Duster. Hold the
on/off switch to maintain the
suction. Release to turn the
unit off.
During the above cleaning
cycle, dust and allergens are
being suctioned away and
captured in the Dust Drawer’s
Stainless Steel Pre-Filter Screen
and the HEPA Filter (see figure
6). Only clean, allergen free air is
recirculated into your home.
Your Lambswool Duster is now
clean and ready to dust another
room in your house.
CLEANING LAMBSWOOL DUSTER WITH VACUUM CHAMBER
12
1. Your DustTamer Ultra
®
Vacuum Chamber can be
conveniently carried from
room to room operating on
battery power.
2. The number of times you
clean your Lambswool Duster
in the Vacuum Chamber will
be determined by the amount
of dust you pick up. Rooms
with heavy dust accumulation
may require several cleanings,
whereas small rooms or quick
touch-up dusting may only
require one cleaning.
Your DustTamer Ultra® is
designed to clean everyday
household dust, not thick,
decades old dust found in
attics, garages, warehouses, etc.
Note: To keep your Lambswool
Duster free of dust and allergens,
we recommend periodic cleaning
of your Lambswool Duster in
the Vacuum Chamber, even if
dust isn’t visible on the
Lambswool Duster.
13
4
5
Fig.
Fig.
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
▼
1
2
6
Fig.
LAMBSWOOL DUSTER STORAGE
14
Your Lambswool Duster can be
stored inside the Vacuum
Chamber or hung from a hook,
nail, etc. with the built-in
hanging hook.
(See Figures 7 & 8)
7
8
Fig.
Fig.
Duster
Stored
Separately
Duster
Stored
Inside
Vacuum
Chamber
15
Dust, dirt and debris suctioned
off by your Vacuum Chamber will
collect in the Dust Drawer’s
Stainless Steel Pre-Filter Screen
and HEPA Filter. To empty/clean
these parts, please follow these
steps:
1.Remove the Dust Drawer
Holding the Vacuum Chamber
Housing with one hand use the
other hand to pull the Dust
Drawer from the unit.
(see figure 9)
2.Cleaning the Dust Drawer
The Dust Drawer with Stainless
Steel Pre-Filter Screen can be
cleaned by emptying the dust
in the trash, or preferably, in
the sink under running water
(see figure 10) to ensure that
dust particles are not
reintroduced to the household.
Thouroughy dry the Dust
Drawer and the Pre-Filter
Screen after cleaning to
prevent moisture from getting
on the HEPA filter.
MAINTENANCE
9
Fig.
10
Fig.
MAINTENANCE
16
3.Cleaning HEPA Filter
To remove the HEPA Filter
from the Vacuum Chamber
Housing, insert your thumb
and middle finger into the
opening where the Dust
Drawer was located and lift the
HEPA filter out. Use your
finger to lightly clean the
paper surface of the HEPA
Filter, clearing off any dirt,
dust, and hair. You can also
gently tap the HEPA Filter on
the edge of the garbage can
or sink face down for
additional cleaning.
(see figure 11)
Note: Do not wash the HEPA
filter. Water will permanently
damage the filter.
11
Fig.
4.Cleaning Vacuum Chamber
Cleaning Interior: Remove any
dust that may build up inside
the Vacuum Chamber with a dry
cloth.
Cleaning Exterior: Clean the
Vacuum Chamber’s exterior
with a damp cloth
Warning: Never immerse the
Vacuum Chamber in water
This may damage the electrical
contacts and circuitry inside
the unit.
17
Note: Make sure that all parts
are dry before putting them
back together.
4. After cleaning, insert the
HEPA Filter and Dust Drawer
back into the Vacuum Chamber
Housing. (see figure 12)
Insert the Dust Drawer into the
Vacuum Chamber Housing until
the Dust Drawer is securely
seated in the unit.
(see figure 13)
12
Fig.
13
Fig.
BATTERY REMOVAL/DISPOSAL
18
Your DustTamer Ultra® Vacuum
Chamber uses 6 nickel cadmium
(Ni-Cad) batteries which are
factory installed in the Battery
Compartment located at the
bottom of the unit. When the
battery life has been exceeded,
the batteries should be removed
from the Vacuum Chamber and
recycled in accordance with
state, and/or national laws.
To remove/replace the Battery
Pack, follow these steps:
a. Open the Battery
Compartment by unscrewing
the two screws on the bottom
of the unit which hold the
battery compartment door in
place. (see figure 14)
b. The battery pack is removed
and detached from the unit
by unplugging the wire
connectors.
c. Attach the new battery packs’
connector to the Vacuum
Chamber connector and
place the new pack into the
Battery Compartment.
d. Close the Battery
Compartment by screwing
the two screws back on the
bottom of the unit.
e. Recycle according to State,
and/or National Laws. Please
call 1-800-822-8837 for
disposal instructions and drop
off locations in your area.
f. A new battery pack, which
contains fresh batteries, can
be ordered from the
FilterStream Customer
Service Center at
800-211-9607.
Note: Please call
1-800-822-8837
for disposal
instructions and
drop off locations in your area.
The batteries must not be
incinerated or composted.
14
Fig.
19
Handy Duster Accessories:
A variety of 100% Lambswool Dusters are available to make your
dusting chores easier:
Standard 22” DustTamer® Duster (Model# D-100)
Extendable 31” DustTamer® Duster (Model# EX-100)
Bendable & Extendable 33” DustTamer® Duster (Model# B-100)
Mini 10” DustTamer® Duster (Model# M-100)
All of these Duster accessories are available from FilterStream at
1-800-211-9607 or by mailing the enclosed order form to FilterStream
with payment.
Replacement Filters and Battery Packs:
Replacement Filters and Battery Packs are available from FilterStream
at 1-800-211-9607. Please reference the following numbers:
FilterStream® HEPA Filter (Model # H-100)
[Fits all DirtTamer Cordless Hand Vacs & DustTamer Vacuum
Powered Dusters]
DustTamer® Dust Drawer Containing Stainless Steel
Pre-Filter (Model #DD-100)
DustTamer® Battery Pack (Model # RBP-200)
Please visit us at www.filterstream.com for more information.
ACCESSORIES
FilterStream Company warrants that this product is free from defects in
materials or workmanship for a period on two (2) years from the date
of original purchase.
It the product fails to operate in accordance with the manufacturer’s
specifications, simply return the product to the retail location where
you purchased it (or send it postage prepaid to the address below)
within two (2) years of the date of purchase. Proof of date of purchase
is required.
Upon receipt, FilterStream Company will, at its option, repair or
replace the product at no charge to you.
This warranty does not cover damage resulting from accident, misuse
or abuse, lack of reasonable care, the affixing of any attachment not
provided with the product, or loss of parts, or subjecting the product to
anything but the specified voltage or batteries.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS
OR IMPLIED. ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO TWO (2)
YEARS FROM THE DATE OF ORIGINAL PURCHASE. IN NO EVENT
WILL FILTERSTREAM COMPANY BE RESPONSIBLE FOR INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT.
Some states do no allow limitation on how long an implied warranty
last and/or the exclusion or limitation of incidental or consequential
damages, so the above limitation may not apply to you. This warranty
gives you specific rights which vary from state to state.
To speak with a FilterStream representative, please call:
1-800-685-0710
Artwork#: 03-A200-01
FilterStream Company Service Center
P.O. Box 481, Westwood, MA, USA 02090-0481
TWO YEAR LIMITED WARRANTY
Loading...
