FileMaker® 9
ODBC and JDBC Guide
© 2004-2007 FileMaker, Inc. All Rights Reserved.
FileMaker, Inc.
5201 Patrick Henry Drive
Santa Clara, California 95054
FileMaker is a trademark of FileMaker, Inc., registered in the
U.S. and other countries, and ScriptMaker and the file folder logo
are trademarks of FileMaker, Inc. All other trademarks are the
property of their respective owners.
FileMaker documentation is copyrighted. You are not authorized
to make additional copies or distribute this documentation
without written permission from FileMaker. You may use this
documentation solely with a valid licensed copy of FileMaker
software.
All persons and companies listed in the examples are purely
fictitious and any resemblance to existing persons and companies
is purely coincidental. Credits are listed in the
Acknowledgements documents provided with this software.
Mention of third-party products is for informational purposes
only and constitutes neither an endorsement nor a
recommendation. FileMaker, Inc. assumes no responsibility with
regard to the performance of these products.
For more information, visit our website at www.filemaker.com.
Edition: 01
Contents
Chapter 1
Introduction 7
About this guide 7
Using a FileMaker database as a data source 7
Accessing a hosted FileMaker Pro database 8
Limitations with third-party tools 8
Networking requirements 8
Updating files from previous versions 9
Installing current drivers 9
Chapter 2
Installing FileMaker ODBC and JDBC client drivers 11
Abiding by the license agreement 11
Hardware and software requirements 11
ODBC client driver requirements (Windows) 11
ODBC client driver requirements (Mac OS) 11
JDBC client driver requirements 12
Networking requirements 12
ODBC client driver installation (Windows) 12
ODBC client driver installation (Mac OS) 13
JDBC client driver installation (Windows and Mac OS) 13
Configuring client drivers 14
Where to go from here 14
Chapter 3
Using ODBC to share FileMaker data 15
About ODBC 15
Using the ODBC client driver 16
Overview of accessing a FileMaker database file 16
Accessing a FileMaker database file from a Windows application 17
Specifying ODBC client driver properties for a FileMaker DSN (Windows) 17
Verifying access via ODBC (Windows) 18
Accessing a FileMaker database file from a Mac OS application 19
Configuring the ODBC client driver (Mac OS) 19
Specifying ODBC client driver properties for a FileMaker DSN (Mac OS) 19
4 FileMaker ODBC and JDBC Guide
Chapter 4
Using JDBC to share FileMaker data 21
About JDBC 21
Using the JDBC client driver 21
About the JDBC client driver 22
Using a JDBC URL to connect to your database 22
Specifying driver properties in the URL subname 24
Verifying access via JDBC 25
Chapter 5
Supported standards 27
Support for Unicode characters 27
SQL statements 27
SELECT statement 27
SQL clauses 28
FROM clause 29
WHERE clause 29
GROUP BY clause 29
HAVING clause 30
UNION operator 30
ORDER BY clause 30
FOR UPDATE clause 31
DELETE statement 33
INSERT statement 33
UPDATE statement 34
CREATE TABLE statement 35
ALTER TABLE statement 35
CREATE INDEX statement 36
DROP INDEX statement 36
SQL aggregate functions 36
SQL expressions 37
Field names 37
Constants and literals 37
Exponential/scientific notation 38
Numeric operators 38
Character operators 38
Date operators 39
Relational operators 39
Logical operators 40
Functions 41
Operator precedence 43
ODBC Catalog functions 43
JDBC Meta Data functions 44
Reserved SQL keywords 44
| Contents 5
Appendix A
Mapping FileMaker fields to ODBC data types 47
Appendix B
Mapping FileMaker fields to JDBC data types 49
Appendix C
ODBC and JDBC error messages 51
ODBC error messages 51
ODBC driver error messages 51
ODBC Driver Manager error messages 51
SequeLink Client error messages 51
SequeLink Server error messages 52
Data source error messages 52
JDBC error messages 52
JDBC driver error messages 52
SequeLink Server error messages 52
Data source error messages 53
Index 55
6 FileMaker ODBC and JDBC Guide
Chapter 1
Introduction
This guide explains concepts and details to help you share FileMaker® data with other applications using
ODBC (Open Database Connectivity) and JDBC (Java Database Connectivity). This guide also documents
how the ODBC and JDBC client drivers, when used with FileMaker
support the industry standards for ODBC, JDBC, and SQL (Structured Query Language).
You can use FileMaker Pro, FileMaker Pro Advanced, or FileMaker Server Advanced to create and test your
database solution. You can then share your FileMaker database solution as a data source with ODBC- and
JDBC-compliant applications. You must install the FileMaker ODBC and JDBC drivers on the machine
where your third-party application is installed.
Important This guide describes using FileMaker software as a data source. For step-by-step information on
using FileMaker
The following table gives an overview of how to use ODBC and JDBC with FileMaker software.
What do you want to do? How do you do it? See
Use FileMaker Pro as a data source/share
FileMaker Pro data
Pro as an ODBC client application, see FileMaker Pro Help.
1. SQL queries
2. JDBC
Pro and FileMaker Server Advanced,
This guide
Use FileMaker Pro as an ODBC client/
access ODBC data
1. Interactively via the relationships graph
2. One-time, static via ODBC import or File
menu > Open. Also, the Import Records script
step and the Execute SQL script step
FileMaker Pro Help
About this guide
1 For information on using ODBC and JDBC with previous versions of FileMaker Pro, see
www.filemaker.com/downloads.
1 This guide assumes that you are familiar with the basics of using ODBC and JDBC, and constructing
SQL queries. Refer to a third-party book for more information on these topics.
1 This guide uses “FileMaker Pro” to refer to both FileMaker Pro and FileMaker Pro Advanced, unless
describing specific FileMaker Pro Advanced features.
Note You can download PDFs of FileMaker documentation from www.filemaker.com/downloads. Any
updates to this document are also available from the website.
Using a FileMaker database as a data source
ODBC and JDBC are application programming interfaces (APIs). These APIs give client applications a
common language for interacting with a variety of data sources and database services, including
FileMaker
Pro and FileMaker Server Advanced.
All applications that support ODBC and JDBC recognize a basic subset of SQL statements. Working with
SQL, you can use other applications (like spreadsheets, word processors, and reporting tools) to view,
analyze, and modify FileMaker data.
8 FileMaker ODBC and JDBC Guide
SQL is passed through the ODBC and JDBC interfaces to the FileMaker host of the data source, performing
queries such as
making updates such as the creation of a new record with
last_name) VALUES ('Jane','Smith')
SELECT first_name, last_name FROM customers WHERE city='Paris' and
INSERT INTO customers (first_name,
.
Accessing a hosted FileMaker Pro database
With either FileMaker Server Advanced or FileMaker Pro, you can host a FileMaker database file as a data
source, sharing your data with other applications using ODBC and JDBC. The following table describes
what each FileMaker product allows.
This FileMaker product Allows
FileMaker Server Advanced Up to 50 connections and supports local access (same computer) and remote
access (both for middleware such as web servers, and for remote client access
from desktop productivity applications).
FileMaker Pro Up to five connections and supports local access (same computer) only.
The ODBC and JDBC plug-in components you need for sharing your data with other applications is
installed with FileMaker
Server Advanced and FileMaker Pro.
To access a hosted FileMaker database file, you need to install the corresponding ODBC or JDBC client
driver. Install the client driver on the machine on which the third-party application is installed. See
“Installing FileMaker ODBC and JDBC client drivers” for information on installing the driver files needed
for accessing a FileMaker data source.
If your FileMaker database solution uses more than one FileMaker database file, all of the database files
must be on the same computer.
Chapter 5, “Supported standards,” describes the SQL statements that the ODBC and JDBC client drivers
support when used with FileMaker Pro and FileMaker Server Advanced.
Important If you disable ODBC/JDBC sharing after it's already been on, a data source hosted by
FileMaker
administrator doesn’t have the capability to alert ODBC and JDBC client applications about the data
source’s availability (the administrator can communicate only with FileMaker database file clients). No
errors are reported, and the client application should notify users that the data source is not available and
transactions cannot be completed. If a client application attempts to connect to an unavailable FileMaker
database file, a message explains that the connection failed.
Server Advanced or FileMaker Pro immediately becomes unavailable. The database
chapter 2,
Limitations with third-party tools
1 Microsoft Query Wizard: In a FileMaker data source, you cannot access table or column names that use
High ASCII or double-byte characters. Instead, use Microsoft Query and manually enter the characters,
enclosed in double quotation marks.
1 Microsoft Access: In a FileMaker data source, you cannot access table or column names that use High
ASCII or double-byte characters.
Networking requirements
You need a TCP/IP network when using FileMaker Server Advanced to host a FileMaker database file as a
data source over a network. FileMaker
Pro supports local access (same computer) only.
Chapter 1 | Introduction 9
Updating files from previous versions
If you used LDAC (Local Data Access Companion) or RDAC (Remote Data Access Companion) in versions
prior to FileMaker Server 5.5 to share a database file, you’ll need to make two changes. First, you need to
set up users to belong to an account that has the extended privilege of Access via ODBC/JDBC (as part of the
account’s privilege set).
See FileMaker Pro Help for information about sharing via ODBC/JDBC and setting up accounts and
privilege sets.
Installing current drivers
If you installed a driver from versions prior to FileMaker Server 9 Advanced or FileMaker Pro 9, you must
uninstall the earlier driver and install the driver for version 9. For more information, see
“Installing FileMaker ODBC and JDBC client drivers.”
Note You have to create a DSN for each FileMaker database file you want to access as a data source. If you
have previously set up access through one DSN that allows tables to be spread among several FileMaker
database files, you’ll need to consolidate those tables into a single database file (or create several DSNs).
chapter 2,
10 FileMaker ODBC and JDBC Guide
Chapter 2
Installing FileMaker ODBC
and
These instructions help you install the drivers needed to access a FileMaker data source from third-party and
custom applications via ODBC (Open Database Connectivity) and JDBC (Java Database Connectivity). The
client drivers are available through a separate installation on your FileMaker CD or electronic download in
the folder \xDBC.The latest versions of the client drivers are also available from
www.filemaker.com/support/technologies.
If you’ll be hosting a FileMaker database file using FileMaker Server Advanced, make the client drivers
available to remote users.
After installing the client driver you need, you can configure the driver to access a FileMaker data source
and construct SQL (Structured Query Language) queries to interact with the data.
JDBC client drivers
Abiding by the license agreement
The ODBC and JDBC client drivers are the driver portions of the FileMaker software that allow third-party
applications or custom applications to access FileMaker files as ODBC or JDBC data sources.
Hardware and software requirements
To install and use the ODBC and JDBC client drivers, you need the following minimum equipment and
software:
ODBC client driver requirements (Windows)
1 Pentium 300 MHz or faster
1 64 MB total RAM for Windows 2000, 128 MB total RAM for Windows XP
1 Microsoft Data Access Components (MDAC) 2.8 SP1
1 Windows MDAC 6.0 for Vista
ODBC client driver requirements (Mac OS)
1 Apple G3 or faster (no G3 upgrade cards)
1 128 MB total RAM
1 Mac OS X version 10.3.9 or 10.4 (the software may also work with later versions certified by FileMaker)
12 FileMaker ODBC and JDBC Guide
JDBC client driver requirements
Applications using Require
JDBC 1.22 API JDK 1.2 compatible Java Virtual Machine (JVM)
JDBC 2.0 Core API JDK 1.3 compatible JVM
JDBC 2.0 Optional Package JDK 1.3 compatible JVM
Also, the following APIs are required and are supplied with SequeLink
Java client:
1 JDBC 2.0 Optional Package
1 JNDI 1.2
1 JTA 1.0.1
JCA API JDK 1.3
JDBC 3.0 API JDK 1.4 or 1.5
To find which version of Java you’re running, open a command window (Windows) or Terminal window
OS) and type java -version.
(Mac
Networking requirements
If you’ll be accessing a FileMaker data source hosted on another computer, you’ll need network access via
TCP/IP.
ODBC client driver installation (Windows)
If you have previously installed the ODBC client driver for Windows, uninstall it with Add or Remove
Programs before installing an updated version.
To install the ODBC client driver:
You need MDAC 2.8 SP1 (available from www.microsoft.com) to install the ODBC client driver.
1. In the folder \xDBC\ODBC Client Driver Installer, double-click setup.
The DataDirect SequeLink for ODBC 5.5 - InstallShield Wizard appears.
2. Install the ODBC client driver by following the on-screen instructions.
The Data Source SyncTool, Data Source SyncTool Administrator, and SequeLink Online Books are not
chosen as part of the default installation; you do not need them to use the ODBC client driver.
By default, the ODBC client driver will be installed in this folder:
C:\Program
3. When the installation is complete, click Finish.
The ODBC client driver, DataDirect 32-BIT SequeLink 5.5, is now available for you to configure for
accessing a FileMaker data source.
Files\DataDirect\slodbc55. Choose another drive or another folder if you wish.
Note If you have any trouble installing directly, install the driver instead through Add or Remove
Programs in Windows (choose Start menu
> Control Panel > Add or Remove Programs).
Chapter 2 | Installing FileMaker ODBC and JDBC client drivers 13
ODBC client driver installation (Mac OS)
If you have previously installed the ODBC client driver for Mac OS, uninstall it before installing an updated
version.
To install the ODBC client driver:
From the folder /xDBC/ODBC Client Driver Installer, copy the file SequeLink.bundle to either your System
or User library. If you don’t have an /ODBC folder, create one manually:
Library
System /Library/ODBC /Library/ODBC/SequeLink.bundle/Contents/MacOS/ivslk20.dylib
User /Users/<user>/Library/ODBC /Users/<user>/Library/ODBC/SequeLink.bundle/Contents/MacOS/
This client driver has been tested with ODBC Administrator 1.0.1 (available with Mac OS 10.4).
Important Use the ODBC Administrator bundled with the ODBC driver manager software recommended
for your client application.
Copy SequeLink.bundle
to this folder: Use this driver path during configuration:
ivslk20.dylib
JDBC client driver installation (Windows and Mac OS)
The installation program and the JDBC client driver work on both Windows and Mac OS. You must have
write access to the folder where you’re installing the JDBC client driver. By default, the folder that contains
the installation program is the installation folder.
If you have previously installed the JDBC client driver, uninstall it before installing an updated version.
To install the JDBC client driver:
1. Open the folder \xDBC\JDBC Client Driver Installer, then double-click sljcinstaller.jar.
The DataDirect SequeLink for JDBC 5.5 Installer window appears.
Note Your Java Runtime environment should be associated with .JAR archive files. Other applications
may also be associated with .JAR archive files, such as WinZip or Stuffit. If so, they can prevent the
JDBC Installer from opening. If the Installer window does not open, start either a command window
(Windows) or Terminal window (Mac OS) and change to the JDBC Client Driver folder. From here, you
can start the installer by typing the following command:
2. Click Next.
Review the license agreement.
3. If the license agreement is acceptable, select I accept the terms of the license agreement, then click Next.
A window of installation options appears.
4. Select Install Developer’s Tools.
The tools include JDBCTest, which helps you verify your JDBC connections.
5. Enter an Install Directory.
java -jar sljcinstaller.jar.
1 Windows: Enter a path that includes your Java executable file (java.exe).
1 Mac OS: Enter /Library/Java/Extensions (or another location included in the ClassPath of your Java
application).
14 FileMaker ODBC and JDBC Guide
6. Click Next.
7. Confirm your installation selections, then click Install.
8. When the installation is complete, click Finish.
The JDBC client driver is now available for you to configure for accessing a FileMaker data source.
Configuring client drivers
Before using a client application to access a FileMaker data source, you must configure a client driver for
the data source. Configuration settings identify the client driver you’re using, the location of the data source,
and details on how you intend to connect.
Important When configuring a FileMaker client driver, you must specify 2399 as the port. For ODBC
(Windows), you’ll specify the port in the ODBC Data Source Administrator. For ODBC (Mac
specify the port in the ODBC Administrator. For JDBC, you’ll specify the port in the JDBC URL.
For additional information about the ODBC client driver on Windows, choose the Windows Start menu >
Programs
Note The Help system, provided by DataDirect Technologies, describes some functionality beyond the
scope of using the ODBC and JDBC client drivers for accessing FileMaker data sources.
> DataDirect SequeLink for ODBC 5.5 > Driver Help.
OS), you’ll
Where to go from here
After you install and configure a client driver, you can construct and execute SQL queries to access a
FileMaker data source.
Client applications sometimes use different terminology for accessing a data source via ODBC. Many
applications have menu items with names such as Get external data or SQL query. Review the documentation
or Help that comes with your application for details.
Chapter 3
Driver
Manager
Client
Application
Oracle
ODBC Driver
ODBC Client
Driver
SQL Server
ODBC Driver
Microsoft
SQL Server
FileMakerOracle
Using ODBC to share FileMaker data
Use the ODBC client driver to connect to a FileMaker data source from another application. The application
that uses the ODBC client driver can directly access the data in a FileMaker database file.
1 Windows: The FileMaker ODBC client driver is DataDirect 32-BIT SequeLink 5.5.
1 Mac OS: The FileMaker ODBC client driver is ivslk20.dylib.
Note You can also use FileMaker Pro as a client application, interacting with records from another data
source via ODBC using SQL. See FileMaker
via ODBC.
About ODBC
ODBC is an API that enables applications to access data from many database management systems. ODBC
gives client applications a common language for interacting with data sources and database services.
All applications that support ODBC recognize a common subset of statements. SQL lets you use other
applications (like spreadsheets, word processors, and reporting tools) to view, analyze, and modify
FileMaker data. See
that the ODBC client driver supports.
chapter 5, “Supported standards,” for the SQL statements, functions, and expressions
Pro Help for details about accessing an external data source
Your application can talk directly to a FileMaker database file by using the ODBC client driver. Your SQL
statements are delivered to the FileMaker host of the database file and the results of those statements are sent
back to you. If you use FileMaker
Server Advanced to host a FileMaker database file as a data source, the
database file can be located on another machine (the server machine) connected to the network, while your
client application is located on your machine (the client machine). This is referred to as a client/server
configuration.
16 FileMaker ODBC and JDBC Guide
Using the ODBC client driver
You can use the ODBC client driver with any ODBC-compliant application. Sharing your FileMaker
database file as a data source, you can:
1 perform mail merges with Microsoft Word
1 create charts with Microsoft Excel
1 move FileMaker data to a DBMS like Microsoft SQL Server
1 further analyze your FileMaker data with query or reporting tools to create charts, construct ad-hoc
queries, and perform drill-down analysis
1 create a Microsoft Visual Basic application that shares information with FileMaker Pro
To share a FileMaker database file as a data source, use FileMaker Pro to define accounts that need access to the
database file. Then, control access to the database file by assigning privilege sets to the accounts, including the
extended privilege of access via ODBC/JDBC. Finally, enable the FileMaker
host application to share data via ODBC/JDBC. For details, see FileMaker
Important The ODBC client driver replaces the FileMaker Pro ODBC driver released with a previous
version of FileMaker. If you have previously set up access to a FileMaker data source using the older driver,
you’ll need to re-define access by using and configuring the new driver.
Server Advanced or FileMaker Pro
Pro or FileMaker Server Help.
Overview of accessing a FileMaker database file
From an ODBC-compliant application, you can construct SQL queries to access a FileMaker database file.
The ODBC client driver must be installed on the computer generating the SQL query.
To access a FileMaker database file:
1. In FileMaker Pro, review the privilege sets you’ve assigned to accounts that will access the database file.
Accounts that need access must use a privilege set with the extended privilege of Access via ODBC/JDBC.
2. Enable the FileMaker Server Advanced (via FileMaker Server Admin Console) or FileMaker Pro host
application to share data via ODBC/JDBC.
FileMaker Server Admin Console: Click ODBC/JDBC then select Enable ODBC/JDBC.
FileMaker Pro: Choose File menu > Sharing > ODBC/JDBC and set ODBC/JDBC Sharing to On.
3. Make sure the FileMaker database file you want to access is hosted and available.
If your FileMaker database solution uses more than one FileMaker database file, all of the database files
must be on the same computer.
4. Connect to the FileMaker data source.
5. Construct and execute an SQL query in the client application.
Each FileMaker database file that is open and set up for access is a separate data source (you create a
DSN for each FileMaker database file you want to access as a data source).
Each database can have one or more tables. FileMaker fields are represented as columns. The complete
field name, including any non-alphanumeric characters, displays as the column name.
Note In Windows, Microsoft Access can import only 32 or fewer fields at one time via ODBC from a
FileMaker database file. If your database file has more than 32 fields, import them in increments of 32.
Chapter 3 | Using ODBC to share FileMaker data 17
Accessing a FileMaker database file from a Windows application
Specifying ODBC client driver properties for a FileMaker DSN (Windows)
Create a DSN for each FileMaker database file you want to access as a data source. The DSN identifies the
FileMaker ODBC client driver, the location of the FileMaker host application, and the FileMaker database
file you’re accessing as a data source.
To set up or change ODBC client driver properties:
1. Open the ODBC Data Source Administrator control panel.
In the Windows Control Panel, choose Administrative Tools > Data Sources (ODBC).
In Windows XP, Administrative Tools appear in the Performance and Maintenance category. In Windows
Vista, Administrative Tools appear in the System and Maintenance category.
2. Click the System DSN tab.
If you set up your data source as a User DSN or File DSN, click the corresponding tab.
3. Click Add.
Note If you’re changing the properties of an existing data source, select the data source, click Configure,
and skip to
step 6.
4. Choose DataDirect 32-BIT SequeLink 5.5 from the list of drivers.
If the driver is not listed in the ODBC Data Source Administrator, look for the (Default) entry of the
registry key HKEY_LOCAL_MACHINE\SOFTWARE\ODBC\ODBCINST.INI\ODBC Drivers using Regedit (choose
Start menu
string, right-click (Default), choose Delete, and click Yes to confirm. This resets the entry to (value
> Run > Regedit). The Data for this entry should be (value not set). If instead you see a blank
not set).
Uninstall and reinstall your ODBC client driver to see it in the ODBC Data Source Administrator.
5. Click Finish.
The DataDirect SequeLink for ODBC Setup dialog appears, with the General tab selected.
6. For Data Source Name, type a name that will be meaningful to others accessing the FileMaker data source.
An additional Description is optional.
Be sure Use LDAP is cleared. No translator .DLLs are included with the ODBC client driver (so clicking
Translate will not allow you to configure an ODBC translator).
7. For SequeLink Server Host, enter the location of your data source.
If you’re connecting to a FileMaker database file hosted by FileMaker Pro on your local machine, type
localhost (or 127.0.0.1).
If you’re connecting to a FileMaker database file hosted by FileMaker Server over a network, type the
IP address of FileMaker Server.
8. For SequeLink Server Port, type 2399.
Important When configuring a FileMaker data source, you must specify 2399 as the SequeLink Server Port.
9. For Server Data Source, type the filename of the FileMaker database file you’re using as a data source
(don’t type the filename extension).
18 FileMaker ODBC and JDBC Guide
10. If you’ve enabled sharing via ODBC/JDBC in the host application, click the button to the right of Server
Data Source to display the filenames of currently open FileMaker database files for you to choose from.
If your database name contains spaces, replace them with the escape characters %20. For example,
serverdatasource=MY%20DATABASE.
11. Click OK to save your data source information.
If you’re sharing another FileMaker database file, return to step 3 and set up the database file as a data
source.
12. Click OK to close the ODBC Data Source Administrator dialog box.
Verifying access via ODBC (Windows)
To verify that you’ve correctly configured the ODBC client driver to access the FileMaker data source:
1. Open the ODBC Data Source Administrator control panel.
In the Windows Control Panel, choose Administrative Tools > Data Sources (ODBC).
In Windows XP, Administrative Tools appear in the Performance and Maintenance category.
2. Click the System DSN tab.
If you set up your data source as a User DSN or File DSN, click the corresponding tab.
3. Choose the FileMaker data source that you previously configured.
The data source name you originally entered appears under Name, and DataDirect 32-BIT SequeLink 5.5
appears as the Driver.
4. Click Configure.
The DataDirect SequeLink for ODBC Setup dialog box appears.
5. Click Test Connect.
You are prompted to enter your FileMaker account name (in Database User Name) and password (in
Database Password).
If the connection is OK, you’ll receive the message Connection test was successful. If the connection fails:
1 Make sure the FileMaker database file is hosted and available.
1 Update or correct your connection information.
1 Make sure your FileMaker account uses a privilege set with the extended privilege of Access via ODBC/
JDBC.
1 Verify that the FileMaker Pro or FileMaker Server host application has been set up for sharing via
ODBC/JDBC.
Chapter 3 | Using ODBC to share FileMaker data 19
Accessing a FileMaker database file from a Mac OS application
If you build custom applications, use version 3.52.1 of the ODBC headers and libraries. Applications built
with version 3.51 might not be able to load the client driver.
Configuring the ODBC client driver (Mac OS)
Configure the client driver using the ODBC Administrator bundled with the ODBC driver manager software
recommended for your client application.
The client driver has been tested with ODBC Administrator 1.0.1 (available with Mac OS 10.4).
When configuring the client driver, you’ll be prompted to provide a brief description and the path to the
driver file:
If you copied SequeLink.bundle
to this library:
/Library/ODBC /Library/ODBC/SequeLink.bundle/Contents/MacOS/ivslk20.dylib
/Users/<user>/Library/ODBC /Users/<user>/Library/ODBC/SequeLink.bundle/Contents/MacOS/
The ODBC Administrator also allows you to optionally define keywords and a Setup File path, but the client
driver does not need that information.
Use this driver path during configuration:
ivslk20.dylib
Specifying ODBC client driver properties for a FileMaker DSN (Mac OS)
Create a DSN for each FileMaker database file you want to access as a data source. The DSN identifies the
FileMaker ODBC client driver, the location of the FileMaker host application, and the FileMaker database
file you’re accessing as a data source.
Important The ODBC client driver for Mac OS does not support upper-ASCII, double-byte, or Japanese
characters in database names or table names. If your FileMaker database file uses these characters, create a
second database and use only ASCII characters for the filename and table names. In the second database,
create a data source reference that points to the data in your original database file. Share both files with
ODBC/JDBC, but use the second database file when defining the DSN.
Additionally, you’ll need to specify these keyword values for the DSN:
Keyword Value
Host If you’re connecting to a FileMaker database file hosted by FileMaker Pro on your local
machine, type
If you’re connecting to a FileMaker database file hosted by FileMaker Server over a network,
type the IP address or hostname of FileMaker Server.
Port Type 2399.
ServerDataSource Type the filename of the FileMaker database file you’re using as a data source (don’t type the
filename extension). If your database name contains spaces, replace them with the escape
characters %20. For example,
are not supported.
localhost (or 127.0.0.1).
ServerDataDource=MY%20DATABASE. Double-byte characters
20 FileMaker ODBC and JDBC Guide
Chapter 4
FileMaker
JDBC driver
Java application
Client machine Database server
Using JDBC to share FileMaker data
If you’re a Java programmer, you can use the JDBC client driver with any Rapid Application Development
(RAD) tool to visually create a Java application or applet that connects to a FileMaker data source. The Java
application or applet that uses the JDBC client driver can directly access the data in a FileMaker database file.
About JDBC
JDBC is a Java API for executing SQL statements, the standard language for accessing relational databases.
JDBC is a name and not an acronym — although it is thought of as standing for “Java Database
Connectivity” because it is the Java equivalent for ODBC. JDBC is a low-level interface, which means that
it is used to call SQL commands directly. It is also designed to be used as a base for higher level interfaces
and tools.
Your Java applet or application can talk directly to a FileMaker database file by using the JDBC client driver.
Your SQL statements are delivered to the FileMaker host of the database file and the results of those
statements are sent back to you. If you use FileMaker
using as a data source can be located on another machine (the server machine) connected to the network,
while your Java applet or client application is located on your machine (the client machine). This is referred
to as a client/server configuration.
Server to host, the FileMaker database file you’re
Using the JDBC client driver
You can use the JDBC client driver with a Java compiler or RAD tool to connect with your database while
you build the code for your Java application or applet. After the Java application or applet has been created,
the JDBC client driver must be present with the files or included within the code in order for the application
or applet to communicate with the database.
To use the JDBC client driver, your Java application or applet must register the driver with the JDBC driver
manager and you must specify the correct JDBC URL from within the application or applet. You need the
JDBC URL to make the connection to the database.
22 FileMaker ODBC and JDBC Guide
About the JDBC client driver
The JDBC client driver provides partial support for the JDBC 3.0 specification. The following features are
not supported by FileMaker:
1 Savepoint support
1 Retrieval of auto-generated keys
1 Passing parameters to a callable statement object by name
1 Holdable cursor support
1 Making internal updates to the data in Blob and Clob objects
1 Retrieving and updating the object referenced by a Ref object
1 Updating of columns containing BLOB, CLOB, ARRAY and REF data types
1 Boolean data type
1 DATALINK data type
1 Transform groups and type mapping
1 Relationship between the JDBC SPI and the Connector architecture
For additional details, see www.filemaker.com/support/technologies. Also see the SequeLink Developer’s
Reference available at www.datadirect.com for information about JDBC compatibility and developing
JDBC applications for SequeLink.
The JDBC client driver has been tested against the Java Development Kit (JDK) 1.4 and 1.5. It is a Type 4
driver — a native protocol, pure Java driver that converts JDBC calls directly into the network protocol used
by FileMaker. This type of driver offers all the advantages of Java including automatic installation (for
example, downloading the JDBC driver with an applet that uses it). The driver works with JDK 1.3 and
Java
2 as long as you only use JDBC 1.2 calls in a Java 2 environment.
The driver class and main entry point for the driver is named:
com.ddtek.jdbc.sequelink.SequeLinkDriver
Important The JDBC client driver replaces the FileMaker JDBC driver released with a previous version of
FileMaker. If you have previously set up access to a FileMaker data source using the older driver, you’ll
need to re-define access by using and configuring the new driver.
Using a JDBC URL to connect to your database
In Java, most resources are accessed through URLs (Uniform Resource Locators). A JDBC URL is used to
identify the database so the JDBC client driver can recognize and establish a connection with the database.
The JDBC URL consists of three main parts separated by colons:
jdbc:<subprotocol>:<subname>
The first part in the JDBC URL is always the JDBC protocol (“jdbc”). The subprotocol is the driver name or
the mechanism that supports multiple drivers. For the JDBC client driver, the subprotocol is
The subname is the IP address of the machine that is hosting the FileMaker data source.
sequelink.
Chapter 4 | Using JDBC to share FileMaker data 23
Registering the JDBC client driver and connecting to a FileMaker data source (an example)
Here is a snippet of a JDBC client application that:
1. Registers the JDBC client driver with the JDBC driver manager.
2. Establishes a connection with the FileMaker data source (the JDBC URL is jdbc:sequelink://
17.184.17.170:2399).
3. Returns error codes.
import java.sql.*;
class FMPJDBCTest
{
public static void main(String[ ] args)
{
// register the JDBC client driver
try {
Driver d =
(Driver)Class.forName("com.ddtek.jdbc.sequelink.SequeLinkDriver").newInstance();
} catch(Exception e) {
System.out.println(e);
}
// establish a connection to FileMaker
Connection con;
try {
con =
DriverManager.getConnction(“jdbc:sequelink://17.184.17.170:2399;
user=some user;password=some password;serverDataSource=database”);
} catch(Exception e) + ";serverdatasource=" + dbName{
System.out.println(e);
}
// get connection warnings + ";serverDataSource=" + dbName
SQLWarning warning = null;
try {
warning = con.getWarnings();
if (warning == null) {
System.out.println("No warnings");
return;
}
while (warning != null) {
System.out.println("Warning: "+warning);
warning = warning.getNextWarning();
}
} catch (Exception e) {
Sysem.out.println(e);
}
}
}þ
Note This example is not meant to be compiled.
24 FileMaker ODBC and JDBC Guide
Specifying driver properties in the URL subname
Specify the user and password driver properties in the subname of the JDBC URL. These are the properties
that could be passed to the connection when calling the DriverManager.getConnection method via the
Properties parameter.
1 user: an account in the FileMaker database file that uses a privilege set with the extended privilege
Access via ODBC/JDBC
1 password: the password for the account in the FileMaker database file
Basic JDBC URL connection
Format: jdbc:sequelink://<sequelink host IP address>:<port>
This is the URL to connect to the FileMaker database file with no passwords. The port number is always
2399 (you can’t change the JDBC sharing to a different port).
If you are executing the JDBC URL connection on the same machine where the file is located, you can use
jdbc:sequelink://localhost:2399
Example: jdbc:sequelink://17.184.17.170:2399
JDBC URL connection with user name and password defined in the URL
Format:
jdbc:sequelink://<sequelink host IP
address>:<port>;user=<userName>;password=<password>
Example: jdbc:sequelink://17.184.17.170:2399;user=phil;password=jsp
JDBC URL connection with the database name specified in the URL
Format:
jdbc:sequelink://<sequelink host IP address>:<port>;
serverDataSource=<databasename>
Example: jdbc:sequelink://17.184.17.170:2399;serverDataSource=publications
If your database name contains spaces, replace them with the escape characters %20.
Example: jdbc:sequelink://17.184.17.170:2399;serverDataSource=MY%20DATABASE
Chapter 4 | Using JDBC to share FileMaker data 25
JDBC URL connection with the database name, user name, and password specified in the URL
Format 1 (using the data store user name and password): jdbc:sequelink://<sequelink host IP
address>:<port>;serverDataSource=<databasename>;DBUser=<databaseusername>;
DBPassword=<databasepassword>
Format 2 (using the host user name and password): jdbc:sequelink://<sequelink host IP
address>:<port>;serverDataSource=<databasename>;HUser=<username>;HPassword=<pa
ssword>
If your FileMaker database solution uses many FileMaker database files, create an additional database file
that contains all the necessary external data source references, table occurrences, and relationships for your
solution. Then define this additional database file as your data source in the JDBC URL. All of the
FileMaker database files must be on the same computer.
Note Secure Socket Layer (SSL) encryption is not supported. To create a more secure JDBC solution, set
up an environment such as .ASP or .JSP, where the web server is hosting via https and communicating with
the FileMaker database file behind a firewall.
Verifying access via JDBC
When you install the JDBC client driver, you have the option of installing JDBCTest to help verify your
connections. When installing the JDBC client driver, select Install Developer’s Tools to get JDBCTest. See
“JDBC client driver installation (Windows and Mac OS)” on page 13 for more information.
When verifying access to a FileMaker database file via JDBC, make sure:
1 The FileMaker database file is hosted and available.
1 Your FileMaker account uses a privilege set with the extended privilege of Access via ODBC/JDBC.
1 The FileMaker Pro or FileMaker Server Advanced host application has been set up for sharing via
ODBC/JDBC.
To share a FileMaker database file as a data source, use FileMaker Pro to define accounts that need
access to the database file. Then, control access to the database file by assigning privilege sets to the
accounts, including the extended privilege of access via ODBC/JDBC. Finally, enable the
FileMaker
details, see FileMaker Pro Help.
Server Advanced or FileMaker Pro host application to share data via ODBC/JDBC. For
1 The JDBC client driver registration and the JDBC URL are correct (the driver can be included inside the
Java Application or located on the client machine).
For additional information on using JDBC to share FileMaker data, see www.filemaker.com/support/technologies.
26 FileMaker ODBC and JDBC Guide
Chapter 5
Supported standards
This chapter describes the SQL statements and constructs supported by the FileMaker ODBC and JDBC
client drivers. Use the client drivers to access a FileMaker database solution from an ODBC- or JDBCcompliant application. The FileMaker database solution can be hosted by either FileMaker
FileMaker
The ODBC client driver supports ODBC 3.5 Level 1 with some features of Level 2. The JDBC client driver
provides partial support for the JDBC 3.0 specification. See www.filemaker.com/support/technologies and
the SequeLink Developer’s Reference available at www.datadirect.com for more information. The ODBC and
JDBC client drivers support SQL-92 entry-level conformance, with some SQL-92 intermediate features.
Server Advanced.
Support for Unicode characters
The ODBC and JDBC client drivers support the Unicode API. However, if you’re creating a custom
application that uses the client drivers, use ASCII for field names, table names, and filenames (in case a nonUnicode query tool or application is used).
Note To insert and retrieve Unicode data, use SQL_C_WCHAR (the SQL_C_BINARY data type is not
supported).
Pro or
SQL statements
The ODBC and JDBC client drivers provide support for the following SQL statements:
SELECT (see below) DELETE (page 33) INSERT (page 33) UPDATE (page 34)
CREATE TABLE (page 35) ALTER TABLE (page 35) CREATE INDEX (page 36) DROP INDEX (page 36)
The client drivers also support FileMaker data type mapping to ODBC SQL and JDBC SQL data types. See
appendix A, “Mapping FileMaker fields to ODBC data types” and appendix B, “Mapping FileMaker fields
to JDBC data types” for data type conversions. For more information on constructing SQL queries, refer to
a third-party book.
Note The ODBC and JDBC client drivers recognize only the first repetition in a repeating field. Also, the
drivers do not support portals in FileMaker
SELECT statement
Use the SELECT statement to specify which columns you're requesting. Follow the SELECT statement with
the column expressions (similar to field names) you want to retrieve (for example,
Expressions can include mathematical operations or string manipulation (for example,
Pro.
last_name).
SALARY * 1.05).
28 FileMaker ODBC and JDBC Guide
The SELECT statement can use a variety of clauses:
SELECT [DISTINCT] {* | column_expression [[AS] column_alias],...}
FROM table_name [table_alias], ...
[ WHERE expr1 rel_operator expr2 ]
[ GROUP BY {column_expression, ...} ]
[ HAVING expr1 rel_operator expr2 ]
[ UNION [ALL] (SELECT...) ]
[ ORDER BY {sort_expression [DESC | ASC]}, ... ]
[ FOR UPDATE [OF {column_expression, ...}] ]
Items in brackets are optional.
Note SELECT * on larger databases and SELECT statements that use table aliases or literals in the
projection list might not function correctly. To avoid potential confusion, avoid wildcards and specify table
and column names without aliases.
column_alias can be used to give the column a more descriptive name, or to abbreviate a longer column
name. For example, to assign the alias
SELECT dept AS department FROM emp
department to the column dept:
Field names can be prefixed with the table name or the table alias. For example, EMP.LAST_NAME or
E.LAST_NAME, where E is the alias for the table EMP.
The DISTINCT operator can precede the first column expression. This operator eliminates duplicate rows
from the result of a query. For example:
SELECT DISTINCT dept FROM emp
SQL clauses
The ODBC and JDBC client drivers provide support for the following SQL clauses.
Use this SQL clause To
FROM (see below) Indicate which tables are used in the SELECT statement.
WHERE (page 29) Specify the conditions that records must meet to be retrieved (like a FileMaker Pro find
request).
GROUP BY (page 29) Specify the names of one or more fields by which the returned values should be grouped.
This clause is used to return a set of aggregate values by returning one row for each group
(like a FileMaker Pro subsummary).
HAVING (page 30) Specify conditions for groups of records (for example, display only the departments that
have salaries totaling more than $200,000). This clause is only valid if you have already
defined a GROUP BY clause.
UNION (page 29) Combine the results of two or more SELECT statements into a single result.
ORDER BY (page 30) Indicate how the records are sorted
FOR UPDATE (page 31) To perform Positioned Updates or Positioned Deletes via SQL cursors
Note If you attempt to retrieve data from a table with no columns, the SELECT statement fails.
Chapter 5 | Supported standards 29
FROM clause
The FROM clause indicates the tables that are used in the SELECT statement. The format is:
FROM table_names [table_alias]
table_names can be one or more simple table names in the current working directory or complete pathnames.
table_alias can be used to give the table a more descriptive name, or to abbreviate a longer table name.
Field names can be prefixed with the table name or the table alias. For example, given the table specification
FROM employee E, you can refer to the LAST_NAME field as E.LAST_NAME. Table aliases must be
used if the SELECT statement joins a table to itself. For example:
SELECT * FROM employee E, employee F WHERE E.manager_id = F.employee_id
The equal sign (=) includes only matching rows in the results.
If you are joining more than one table, and you want to discard all rows that don’t have corresponding rows
in both source tables, you can use INNER JOIN. For example:
SELECT *
FROM Salespeople INNER JOIN Sales_Data
ON Salespeople.Salesperson_ID = Sales_Data.Salesperson_ID
Note OUTER JOIN is not currently supported.
WHERE clause
The WHERE clause specifies the conditions that records must meet to be retrieved. The WHERE clause
contains conditions in the form:
WHERE expr1 rel_operator expr2
expr1 and expr2 can be field names, constant values, or expressions.
rel_operator is the relational operator that links the two expressions. For example, the following
SELECT statement retrieves the names of employees who make $20,000 or more.
SELECT last_name,first_name FROM emp WHERE salary >= 20000
Note If you use fully qualified names in the SELECT (projection) list, you must also use fully qualified
names in the related WHERE clause.
GROUP BY clause
The GROUP BY clause specifies the names of one or more fields by which the returned values should be
grouped. This clause is used to return a set of aggregate values. It has the following format:
GROUP BY column_expressions
column_expressions must match the column expression used in the SELECT clause. A column
expression can be one or more field names of the database table separated by commas, or one or more
expressions separated by commas.
The following example sums the salaries in each department.
SELECT dept_id, SUM (salary) FROM emp GROUP BY dept_id
This statement returns one row for each distinct department ID. Each row contains the department ID and
the sum of the salaries of the employees in the department.
30 FileMaker ODBC and JDBC Guide
HAVING clause
The HAVING clause enables you to specify conditions for groups of records (for example, display only the
departments that have salaries totaling more than $200,000). This clause is valid only if you have already
defined a GROUP BY clause. It has the following format:
HAVING expr1 rel_operator expr2
expr1 and expr2 can be field names, constant values, or expressions. These expressions do not have to
match a column expression in the SELECT clause.
rel_operator is the relational operator that links the two expressions. The following example returns only
the departments whose sums of salaries are greater than $200,000:
SELECT dept_id, SUM (salary) FROM emp
GROUP BY dept_id HAVING SUM (salary) > 200000
UNION operator
The UNION operator combines the results of two or more SELECT statements into a single result. The
single result is all of the returned records from the SELECT statements. By default, duplicate records are
not returned. To return duplicate records, use the ALL keyword (UNION ALL). The format is:
SELECT statement UNION [ALL] SELECT statement
When using the UNION operator, the select lists for each SELECT statement must have the same number
of column expressions, with the same data types, and must be specified in the same order. For example:
SELECT last_name, salary, hire_date FROM emp UNION SELECT name, pay,
birth_date FROM person
This example has the same number of column expressions, and each column expression, in order, has the
same data type.
The following example is not valid because the data types of the column expressions are different (SALARY
from EMP has a different data type than LAST_NAME from RAISES). This example has the same number
of column expressions in each SELECT statement, but the expressions are not in the same order by data type.
SELECT last_name, salary FROM emp UNION SELECT salary, last_name FROM raises
ORDER BY clause
The ORDER BY clause indicates how the records are to be sorted. The format is:
ORDER BY {sort_expression [DESC | ASC]}, ...
sort_expression can be field names, expressions, or the positional number of the column expression to
use. The default is to perform an ascending (ASC) sort.
For example, to sort by last_name then by first_name, you could use either of the following SELECT
statements:
SELECT emp_id, last_name, first_name FROM emp ORDER BY last_name, first_name
or
SELECT emp_id, last_name, first_name FROM emp ORDER BY 2,3
In the second example, last_name is the second column expression following SELECT, so ORDER BY 2
sorts by
last_name.
Chapter 5 | Supported standards 31
FOR UPDATE clause
The FOR UPDATE clause performs Positioned Updates or Positioned Deletes via SQL cursors. The format is:
FOR UPDATE [OF column_expressions]
column_expressions is a list of field names in the database table that you intend to update, separated by
a comma.
The following example returns all records in the employee database that have a SALARY field value of more
than $20,000. When each record is fetched, it is locked. If the record is updated or deleted, the lock is held
until you commit the change. Otherwise, the lock is released when you fetch the next record.
SELECT * FROM emp WHERE salary > 20000 FOR UPDATE OF last_name, first_name,
salary
Additional examples:
Using Sample SQL
text constant SELECT 'CatDog' FROM Salespeople
numeric constant SELECT 999 FROM Salespeople
date constant SELECT DATE '2004-06-05' FROM Salespeople
column_expressions is optional.
time constant SELECT TIME '02:49:03' FROM Salespeople
timestamp constant SELECT TIMESTAMP '2004-06-05 02:49:03' FROM Salespeople
text column SELECT Company_Name FROM Sales_Data
SELECT DISTINCT Company_Name FROM Sales_Data
numeric column SELECT Amount FROM Sales_Data
SELECT DISTINCT Amount FROM Sales_Data
date column SELECT Date_Sold FROM Sales_Data
SELECT DISTINCT Date_Sold FROM Sales_Data
time column SELECT Time_Sold FROM Sales_Data
SELECT DISTINCT Time_Sold FROM Sales_Data
timestamp column SELECT Timestamp_Sold FROM Sales_Data
SELECT DISTINCT Timestamp_Sold FROM Sales_Data
BLOBa column
Wildcard * SELECT * FROM Salespeople
a. A BLOB is a FileMaker database file container field.
SELECT Company_Brochures FROM Sales_Data
SELECT GETAS(Company_Logo, 'JPEG') FROM Sales_Data
SELECT DISTINCT * FROM Salespeople
Notes from the examples
A column is a reference to a field in the FileMaker database file (the field can contain many distinct values).
The asterisk (*) wildcard character is shorthand for “everything”. For the example SELECT * FROM
Salespeople
* FROM Salespeople
, the result is all the rows in the Salespeople table. For the example SELECT DISTINCT
, the result is all the unique rows in the Salespeople table (no duplicates).
Note SELECT * statements on larger databases might not function correctly. To avoid potential confusion,
avoid wildcards and specify table and column names (without aliases).
32 FileMaker ODBC and JDBC Guide
Retrieving the contents of a container field: CAST() function and GetAs() function
You can retrieve binary data, file reference information, or data of a specific file type from a container field.
To retrieve binary data, use a standard SELECT statement. For example:
SELECT Company_Brochures FROM Sales_Data
If file or JPEG data exists, the SELECT statement retrieves the data in binary form; otherwise, the SELECT
statement returns <null>.
To retrieve file reference information (such as the file path), use the CAST function with a SELECT
statement. For example:
SELECT CAST(Company_Brochures AS VARCHAR(NNN)) FROM Sales_Data
In this example, if you:
1 Inserted a file into the container field using FileMaker Pro but stored only a reference to the file, the
SELECT statement retrieves the file reference information as type SQL_VARCHAR.
1 Inserted the contents of a file into the container field using FileMaker Pro, the SELECT statement
retrieves the name of the file.
1 Imported a file into the container field from another application, the SELECT statement displays '?' (the
file displays as Untitled.dat in FileMaker
Pro).
To retrieve data of a specific file type from a container field, use the GetAs function and specify the file’s
type. For example:
SELECT GetAs(Company_Logo, 'JPEG') FROM Sales_Data
The possible file types (case sensitive) you can retrieve from a container field in a FileMaker database file are:
File type Description File type Description
'EMBO' OLE container data 'PDF ' Portable Document Format
'EMF+' Windows Enhanced Metafile Plus 'PICT' Mac OS (does not have 512-byte file-based header)
'EPS ' Embedded PostScript 'PNGf' Bitmap image format
'FILE' Result of an Insert File command 'PNTG' MacPaint
'FPix' Flash (FPX) 'qtif' QuickTime image file
'FORK' Resource fork (Mac OS) '.SGI' Generic bitmap format
'GIFf' Graphics Interchange Format 'snd ' Standard sound (Mac OS raw format)
'JPEG' Photographic images 'TIFF' Raster file format for digital images
'JP2 ' JPEG 2000 'TPIC' Targa
'META' Windows Metafile (enhanced) 'XMLO' Layout objects
'METO' Windows Metafile (original) '8BPS' PhotoShop (PSD)
'moov' Old QuickTime format (Mac OS)
Chapter 5 | Supported standards 33
DELETE statement
Use the DELETE statement to delete records from a database table. The format of the DELETE statement is:
DELETE FROM table_name [ WHERE { conditions } ]
Note The WHERE clause determines which records are to be deleted. If you don’t include the WHERE
keyword, all records in the table are deleted (but the table is left intact).
An example of a DELETE statement on the Employee table is:
DELETE FROM emp WHERE emp_id = 'E10001'
Each DELETE statement removes every record that meets the conditions in the WHERE clause. In this case,
every record having the employee ID E10001 is deleted. Because employee IDs are unique in the Employee
table, only one record is deleted.
INSERT statement
Use the INSERT statement to create records in a database table. You can specify either:
1 A list of values to be inserted as a new record
1 A SELECT statement that copies data from another table to be inserted as a set of new records
The format of the INSERT statement is:
INSERT INTO table_name [(column_name, ...)] VALUES (expr, ...)
column_name is an optional list of column names that provides the name and order of the columns whose
values are specified in the VALUES clause. If you omit
column_name, the value expressions (expr) must
provide values for all columns defined in the table and must be in the same order that the columns are defined
for the table.
expr is the list of expressions giving the values for the columns of the new record. Usually the expressions
are constant values for the columns (but they can also be a subquery). You must enclose character string
values in pairs of single quotation marks ('). To include a single quotation mark in a character string value
enclosed by single quotation marks, use two single quotation marks together (for example, 'Don''t'). Date,
time, and timestamp values must be enclosed in braces {}. Logical values that are characters must be
enclosed in periods (for example, .T. or .F.). Subqueries must be enclosed in parentheses.
The following example inserts a list of expressions:
INSERT INTO emp (last_name, first_name, emp_id, salary, hire_date)
VALUES ('Smith', 'John', 'E22345', 27500, {6/5/2004})
Each INSERT statement adds one record to the database table. In this case a record has been added to the
employee database table, EMP. Values are specified for five columns. The remaining columns in the table
are assigned a blank value, meaning Null.
Note In container fields, you can INSERT only text.
34 FileMaker ODBC and JDBC Guide
The SELECT statement is a query that returns values for each column_name value specified in the column
name list. Using a SELECT statement instead of a list of value expressions lets you select a set of rows from
one table and insert it into another table using a single INSERT statement.
Here's an example of an INSERT statement that uses a SELECT statement:
INSERT INTO emp1 (first_name, last_name, emp_id, dept, salary)
SELECT first_name, last_name, emp_id, dept, salary from emp
WHERE dept = ‘D050’
In this type of INSERT statement, the number of columns to be inserted must match the number of columns
in the SELECT statement. The list of columns to be inserted must correspond to the columns in the SELECT
statement just as it would to a list of value expressions in the other type of INSERT statement. For example,
the first column inserted corresponds to the first column selected; the second inserted to the second, and so on.
The size and data type of these corresponding columns must be compatible. Each column in the SELECT
list should have a data type that the ODBC or JDBC client driver accepts on a regular INSERT/UPDATE of
the corresponding column in the INSERT list. Values are truncated when the size of the value in the
SELECT list column is greater than the size of the corresponding INSERT list column.
The SELECT statement is evaluated before any values are inserted.
UPDATE statement
Use the UPDATE statement to change records in a database table. The format of the UPDATE statement is:
UPDATE table_name SET column_name = expr, ... [ WHERE { conditions } ]
column_name is the name of a column whose value is to be changed. Several columns can be changed in
one statement.
expr is the new value for the column. Usually the expressions are constant values for the columns (but they
can also be a subquery). You must enclose character string values in pairs of single quotation marks ('). To
include a single quotation mark in a character string value enclosed by single quotation marks, use two
single quotation marks together (for example, 'Don''t'). Date, time, and timestamp values must be enclosed
in braces {}. Logical values that are characters must be enclosed in periods (for example, .T. or .F.).
Subqueries must be enclosed in parentheses.
The WHERE clause is any valid clause. It determines which records are updated.
An example of an UPDATE statement on the Employee table is:
UPDATE emp SET salary=32000, exempt=1 WHERE emp_id = 'E10001'
The UPDATE statement changes every record that meets the conditions in the WHERE clause. In this case
the salary and exempt status are changed for all employees having the employee ID E10001. Because
employee IDs are unique in the Employee table, only one record is updated.
Here's an example using a subquery:
UPDATE emp SET salary = (SELECT avg(salary) from emp) WHERE emp_id = 'E10001'
In this case, the salary is changed to the average salary in the company for the employee having employee
ID E10001.
Note In container fields, you can UPDATE only with text.
Chapter 5 | Supported standards 35
CREATE TABLE statement
Use the CREATE TABLE statement to create a table in a database file. The format of the CREATE TABLE
statement is:
CREATE TABLE table_name table_element_list [NOT NULL]
Within the statement, you specify the name and data type of each column.
table_name and table_element_list have a 100 character limit. Defining a column to be NOT NULL
automatically selects the Not Empty Validation Option for the corresponding field in the FileMaker database file.
The field is flagged as a Required Value in the Fields tab of the Manage Database dialog box in FileMaker
Examples
Using Sample SQL
text column
text column, NOT NULL
CREATE TABLE T1 (C1 VARCHAR, C2 VARCHAR (50), C3 VARCHAR (1001),
VARCHAR (500276))
C4
CREATE TABLE T1NN (C1 VARCHAR NOT NULL, C2 VARCHAR (50) NOT NULL,
C3 VARCHAR (1001) NOT NULL, C4 VARCHAR (500276) NOT NULL)
Pro.
numeric column
date column
time column
timestamp column
BLOB column
CREATE TABLE T2 (C1 DECIMAL, C2 DECIMAL (10,0), C3 DECIMAL (7539,2),
C4 DECIMAL (497925,301))
CREATE TABLE T3 (C1 DATE, C2 DATE, C3 DATE, C4 DATE)
CREATE TABLE T4 (C1 TIME, C2 TIME, C3 TIME, C4 TIME)
CREATE TABLE T5 (C1 TIMESTAMP, C2 TIMESTAMP, C3 TIMESTAMP, C4 TIMESTAMP)
CREATE TABLE T6 (C1 BLOB, C2 BLOB, C3 BLOB, C4 BLOB)
ALTER TABLE statement
Use the ALTER TABLE statement to change the structure of an existing table in a database file. You can
modify only one column in each statement. The formats of the ALTER TABLE statement are:
ALTER TABLE table_name ADD [COLUMN] column_definition
ALTER TABLE table_name DROP [COLUMN] unqualified_column_name
You must know the table’s structure and how you want to modify it before using the ALTER TABLE statement.
Examples
To Sample SQL
add columns
remove columns
ALTER TABLE Salespeople ADD C1 VARCHAR
ALTER TABLE Salespeople DROP C1
36 FileMaker ODBC and JDBC Guide
CREATE INDEX statement
Use the CREATE INDEX statement to speed searches in your database file. The format of the CREATE
INDEX statement is:
CREATE INDEX [ index_name ][ON] table_name.column_name
CREATE INDEX is supported for a single column (multi-column indexes are not supported). Indexes are
not allowed on columns that correspond to container field types, summary fields, fields that have the global
storage option, or unstored calculation fields in a FileMaker database file.
Creating an index for a text column automatically selects the Storage Option of Minimal in Indexing for the
corresponding field in the FileMaker database file. Creating an index for a non-text column (or a column
formatted as Japanese text) automatically selects the Storage Option of All in
field in the FileMaker database file.
Creating an index for any column automatically selects the Storage Option of Automatically create indexes as
needed in Indexing for the corresponding field in the FileMaker database file.
Example
CREATE INDEX myIndex ON Salespeople.Salesperson_ID
Indexing for the corresponding
DROP INDEX statement
Use the DROP INDEX statement to remove an index from a database file. The format of the DROP INDEX
statement is:
DROP INDEX [ON] table_name.column_name
Remove an index when your database file is too large, or you don’t often use a field in queries.
If your queries are experiencing poor performance, and you’re working with an extremely large FileMaker
database file with many indexed text fields, consider dropping the indexes from some fields. Also consider
dropping the indexes from fields that you rarely use in SELECT statements.
Dropping an index for any column automatically selects the Storage Option of None and clears Automatically
create indexes as needed in Indexing for the corresponding field in the FileMaker database file.
The PREVENT INDEX CREATION attribute is not supported.
Example
DROP INDEX ON Salespeople.Salesperson_ID
SQL aggregate functions
Aggregate functions return a single value from a set of records. You can use an aggregate function as part
of a SELECT statement, with a field name (for example, AVG(SALARY)), or in combination with a column
expression (for example, AVG(SALARY * 1.07)).
You can precede the column expression with the DISTINCT operator to eliminate duplicate values. For
example:
COUNT (DISTINCT last_name)
In this example, only unique last name values are counted.
Important Use uppercase letters for SQL function names (some are case sensitive).
Chapter 5 | Supported standards 37
Aggregate function Returns
SUM The total of the values in a numeric field expression. For example, SUM(SALARY)
returns the sum of all salary field values.
AVG The average of the values in a numeric field expression. For example, AVG(SALARY)
returns the average of all salary field values.
COUNT The number of values in any field expression. For example, COUNT(NAME) returns the
number of name values. When using COUNT with a field name, COUNT returns the
number of non-null field values. A special example is COUNT(*), which returns the
number of records in the set, including records with null values.
MAX The maximum value in any field expression. For example, MAX(SALARY) returns the
maximum salary field value.
MIN The minimum value in any field expression. For example, MIN(SALARY) returns the
minimum salary field value.
Examples
SELECT SUM (Sales_Data.Amount) AS agg FROM Sales_Data
SELECT AVG (Sales_Data.Amount) AS agg FROM Sales_Data
SELECT COUNT (Sales_Data.Amount) AS agg FROM Sales_Data
SELECT MAX (Sales_Data.Amount) AS agg FROM Sales_Data WHERE
Sales_Data.Amount <
SELECT MIN (Sales_Data.Amount) AS agg FROM Sales_Data WHERE
Sales_Data.Amount <
3000
3000
SQL expressions
Use expressions in WHERE, HAVING, and ORDER BY clauses of SELECT statements to form detailed
and sophisticated database queries.Valid expression elements are:
Field names Numeric operators Relational operators
Constants and literals Character operators Logical operators
Exponential notation Date operators Functions
Field names
The most common expression is a simple field name, such as calc or Sales_Data.Invoice_ID.
Constants and literals
Constants are values that do not change. For example, in the expression PRICE * 1.05, the value 1.05 is a
constant. Or you might assign a value of 30 to the constant Number_Of_Days_In_June.
A literal is another kind of constant; but instead of having an assigned value, the literal itself is the value,
such as 'Paris' or '14:35:10'. A literal is a “what you see is what you get” constant.
You must enclose character constants (such as literals) in pairs of single quotation marks ('). To include a
single quotation mark in a character constant enclosed by single quotation marks, use two single quotation
marks together (for example, 'Don''t').
38 FileMaker ODBC and JDBC Guide
You must enclose date, time, and timestamp constants in braces ({}), for example, {D '2005-06-05'},
{14:35:10}, and {TS
'2005-06-05 14:35:10'}. The one exception: SQL-92 syntax requires ISO date and time
formats with no brackets:
1 DATE 'YYYY-MM-DD'
1 TIME 'HH:MM:SS'
1 TIMESTAMP 'YYYY-MM-DD HH:MM:SS'
Constant Acceptable syntax (examples)
Text 'Paris'
Number 1.05
Date DATE '2005-06-05'
{ D '2005-06-05' }
{ 06/05/2005 }
{ 06/05/05 }
Time TIME '14:35:10'
{ T '14:35:10' }
{14:35:10}
Timestamp TIMESTAMP '2005-06-05 14:35:10'
{ TS '2005-06-05 14:35:10'}
{ 06/05/2005 14:35:10 }
{2005-06-05 14:35:10}
{ 06/05/05 14:35:10 } Make sure Strict data type: 4-Digit Year Date is not selected as a
validation option in the FileMaker database file for a field using this 2-digit year syntax.
When entering date and time values, match the format of the database file locale. For example, if the
database was created on an Italian language system, use Italian date and time formats.
Logical values that are characters must be enclosed in periods. The logical constants are .T. and 1 for True
and .F. and 0 for False. For portability, use 1 and 0.
Exponential/scientific notation
You can include exponential notation.
Example
SELECT column1, 3.4E+7 FROM table1 WHERE calc < 3.4E-6 * column2
Numeric operators
You can include the following operators in number expressions: +, -, *, /, and ^ or ** (exponentiation).
You can precede numeric expressions with a unary plus (+) or minus (-).
Character operators
You can concatenate characters.
Examples
In the following examples, last_name is 'JONES ' and first_name is 'ROBERT ':
Operator Concatenation Example Result
+ Keep trailing blank characters first_name + last_name 'ROBERT JONES '
- Move trailing blank characters to the end first_name - last_name 'ROBERTJONES '
Chapter 5 | Supported standards 39
Date operators
You can modify dates.
Examples
In the following examples, hire_date is {01/30/2004}.
Operator Effect on date Example Result
+ Add a number of days to a date hire_date + 5 {02/04/2004}
- Find the number of days between two dates,
or subtract a number of days from a date
hire_date - {01/01/2004}
hire_date - 10
Additional examples:
SELECT Date_Sold, Date_Sold + 30 AS agg FROM Sales_Data
SELECT Date_Sold, Date_Sold - 30 AS agg FROM Sales_Data
Relational operators
Operator Meaning
= Equal
<> Not equal
> Greater than
>= Greater than or equal to
< Less than
<= Less than or equal to
LIKE Matching a pattern
NOT LIKE Not matching a pattern
IS NULL Equal to Null
29
{01/20/2004}
IS NOT NULL Not equal to Null
BETWEEN Range of values between a lower and upper bound
IN A member of a set of specified values or a member of a subquery
NOT IN Not a member of a set of specified values or a member of a subquery
EXISTS ‘True’ if a subquery returned at least one record
ANY Compares a value to each value returned by a subquery (operator must be preceded by =,
<>, >, >=, <, or <=); =Any is equivalent to In
ALL Compares a value to each value returned by a subquery (operator must be preceded by =,
<>, >, >=, <, or <=)
Examples
SELECT Sales_Data.Invoice_ID FROM Sales_Data
WHERE Sales_Data.Salesperson_ID = 'SP-1'
SELECT Sales_Data.Amount FROM Sales_Data WHERE Sales_Data.Invoice_ID <> 125
SELECT Sales_Data.Amount FROM Sales_Data WHERE Sales_Data.Amount > 3000
40 FileMaker ODBC and JDBC Guide
SELECT Sales_Data.Time_Sold FROM Sales_Data
WHERE Sales_Data.Time_Sold < '12:00:00'
SELECT Sales_Data.Company_Name FROM Sales_Data
WHERE Sales_Data.Company_Name LIKE '%University'
SELECT Sales_Data.Company_Name FROM Sales_Data
WHERE Sales_Data.Company_Name NOT LIKE '%University'
SELECT Sales_Data.Amount FROM Sales_Data WHERE Sales_Data.Amount IS NULL
SELECT Sales_Data.Amount FROM Sales_Data WHERE Sales_Data.Amount IS NOT
NULL
SELECT Sales_Data.Invoice_ID FROM Sales_Data
WHERE Sales_Data.Invoice_ID BETWEEN 1 AND 10
SELECT COUNT(Sales_Data.Invoice_ID) AS agg
FROM Sales_Data WHERE Sales_Data.INVOICE_ID IN (50,250,100)
SELECT COUNT(Sales_Data.Invoice_ID) AS agg
FROM Sales_Data WHERE Sales_Data.INVOICE_ID NOT IN (50,250,100)
SELECT COUNT(Sales_Data.Invoice_ID) AS agg FROM Sales_Data
WHERE Sales_Data.INVOICE_ID NOT IN (SELECT Sales_Data.Invoice_ID
FROM Sales_Data WHERE Sales_Data.Salesperson_ID = 'SP-4')
SELECT *
FROM Sales_Data WHERE EXISTS (SELECT Sales_Data.Amount
FROM Sales_Data WHERE Sales_Data.Salesperson_ID IS NOT NULL)
SELECT *
FROM Sales_Data WHERE Sales_Data.Amount = ANY (SELECT Sales_Data.Amount
FROM Sales_Data WHERE Sales_Data.Salesperson_ID = 'SP-1')
SELECT *
FROM Sales_Data WHERE Sales_Data.Amount = ALL (SELECT Sales_Data.Amount
FROM Sales_Data WHERE Sales_Data.Salesperson_ID IS NULL)
Logical operators
You can combine two or more conditions. The conditions must be related by AND or OR, such as:
salary = 40000 AND exempt = 1
The logical NOT operator is used to reverse the meaning, such as:
NOT (salary = 40000 AND exempt = 1)
Examples
SELECT * FROM Sales_Data WHERE Sales_Data.Company_Name
NOT LIKE '%University' AND Sales_Data.Amount > 3000
SELECT * FROM Sales_Data WHERE (Sales_Data.Company_Name
LIKE '%University' OR Sales_Data.Amount > 3000)
AND Sales_Data.Salesperson_ID = 'SP-1'
Chapter 5 | Supported standards 41
Functions
The ODBC and JDBC client drivers support many functions you can use in expressions. Some of the
functions return characters strings, some return numbers, and some return dates.
Important Use uppercase letters for SQL function names (some are case sensitive).
Functions that
return character
strings
CHR Converts an ASCII code to a one-character
RTRIM Removes trailing blanks from a string RTRIM('ABC ') returns ABC
Description Example
CHR(67) returns C
string
TRIM Removes leading and trailing blanks from a
TRIM(' ABC ') returns ABC
string
LTRIM Removes leading blanks from a string LTRIM(' ABC') returns ABC
UPPER Changes each letter of a string to uppercase UPPER('Allen') returns ALLEN
LOWER Changes each letter of a string to lowercase LOWER('Allen') returns allen
LEFT Returns leftmost characters of a string LEFT('Mattson',3) returns Mat
RIGHT Returns rightmost characters of a string RIGHT('Mattson',4) returns tson
SUBSTR Returns a substring of a string, with parameters
of the string, the first character to extract, and the
SUBSTR('Conrad',2,3) returns onr
SUBSTR('Conrad',2) returns onrad
number of characters to extract (optional)
SPACE Generates a string of blanks SPACE(5) returns ' '
STRVAL Converts a value of any type to a character
string
STRVAL('Woltman') returns Woltman
STRVAL(5 * 3) returns 15
STRVAL(4 = 5) returns 'False'
STRVAL({12/25/2004}) returns 12/25/2004
TIME Returns the time of day as a string At 9:49 PM, TIME() returns 21:49:00
USERNAME Returns the login ID specified at connect time
Examples
SELECT CHR(67) + SPACE(1) + CHR(70) FROM Salespeople
SELECT RTRIM(' ' + Salespeople.Salesperson_ID) AS agg FROM Salespeople
SELECT TRIM(SPACE(1) + Salespeople.Salesperson_ID) AS agg FROM Salespeople
SELECT LTRIM(' ' + Salespeople.Salesperson_ID) AS agg FROM Salespeople
SELECT UPPER(Salespeople.Salesperson) AS agg FROM Salespeople
SELECT LOWER(Salespeople.Salesperson) AS agg FROM Salespeople
SELECT LEFT(Salespeople.Salesperson, 5) AS agg FROM Salespeople
SELECT RIGHT(Salespeople.Salesperson, 7) AS agg FROM Salespeople
SELECT SUBSTR(Salespeople.Salesperson_ID, 2, 2) +
SUBSTR(Salespeople.Salesperson_ID, 4, 2) AS agg FROM Salespeople
SELECT SUBSTR(Salespeople.Salesperson_ID, 2) +
SUBSTR(Salespeople.Salesperson_ID, 4) AS agg FROM Salespeople
42 FileMaker ODBC and JDBC Guide
SELECT SPACE(2) + Salespeople.Salesperson_ID AS Salesperson_ID FROM
Salespeople
SELECT STRVAL('60506') AS agg FROM Sales_Data WHERE Sales_Data.Invoice_ID
=
1
SELECT TIME() AS agg FROM Sales_Data WHERE Sales_Data.Invoice_ID = 1
SELECT USERNAME() AS agg FROM Sales_Data WHERE Sales_Data.Invoice_ID = 1
Functions that
return numbers Description Example
MOD Divides two numbers and returns the remainder of
MOD(10,3) returns 1
the division
LEN Returns the length of a string
MONTH Returns the month part of a date
DAY Returns the day part of a date
YEAR Returns the year part of a date
MAX Returns the larger of two numbers
DAYOFWEEK Returns the day of week (1-7) of a date expression
MIN Returns the smaller of two numbers
POW Raises a number to a power
INT Returns the integer part of a number
X Returns the decimal equivalent of a hexadecimal
number
B Returns the decimal equivalent of a binary number
ROUND Rounds a number
NUMVAL Converts a character string to a number; if the
character string is not a valid number, returns 0
VAL Converts a character string to a number; if the
character string is not a valid number, returns 0
LEN('ABC') returns 3
MONTH({01/30/2004}) returns 1
DAY({01/30/2004}) returns 30
YEAR({01/30/2004}) returns 2004
MAX(66,89) returns 89
DAYOFWEEK({05/01/2004}) returns 7
MIN(66,89) returns 66
POW(7,2) returns 49
INT(6.4321) returns 6
X'b9' returns 185
B'1001' returns 9
ROUND(123.456,0) returns 123
ROUND(123.456,2) returns 123.46
ROUND(123.456,-2) returns 100
NUMVAL('123') returns 123
VAL('123') returns 123
Functions that
return dates Description Example
DATE Returns today’s date If today is 11/21/2005, DATE() returns {2005-11-21}
DATEVAL Converts a character string to a date
DATEVAL('01/30/2006') returns {2006-01-30}
Chapter 5 | Supported standards 43
Operator precedence
As expressions become more complex, the order in which the expressions are evaluated becomes important.
This table shows the order in which the operators are evaluated. The operators in the first line are evaluated
first, and so on. Operators in the same line are evaluated left to right in the expression.
Precedence Operator
1 Unary '-', Unary '+'
2 ^, **
3 *, /
4 +, -
5 =, <>, <, <=, >, >=, Like, Not Like, Is Null, Is Not Null, Between, In, Exists, Any, All
6 Not
7 AND
8 OR
The following example shows the importance of precedence:
WHERE salary > 40000 OR hire_date > {01/30/2004} AND dept = 'D101'
Because AND is evaluated first, this query retrieves employees in department D101 hired after January 30,
2004, as well as every employee making more than $40,000, no matter what department or hire date.
To force the clause to be evaluated in a different order, use parentheses to enclose the conditions to be
evaluated first. For example:
WHERE (salary > 40000 OR hire_date > {01/30/2004}) AND dept = 'D101'
retrieves employees in department D101 that either make more than $40,000 or were hired after January 30, 2004.
ODBC Catalog functions
The ODBC client driver supports the following Catalog functions:
1 SQLTables - catalog information is stored and reported as single part names (table name only).
1 SQLColumns
1 SQLColumnPrivileges
1 SQLDescribeCol
1 SQLGetTypeInfo
44 FileMaker ODBC and JDBC Guide
JDBC Meta Data functions
The JDBC client driver supports the following Meta Data functions:
1 getColumns
1 getColumnPrivileges
1 getMetaData
1 getTypeInfo
1 getTables
1 getTableTypes
Reserved SQL keywords
The following table lists reserved keywords that should not be used as names for columns, tables, aliases,
or other user-defined objects. If you are getting syntax errors, these errors may be due to using one of these
reserved words. If you want to use one of these keywords, you need to use quotation marks to prevent the
word from being treated as a keyword.
For example, the following Create Table statement shows how to use the "OID" keyword as a data element name.
create table t ("oid" numeric)
Reserved keywords
ABSOLUTE
ACTION
ADD
AFTER
ALIAS
ALL
ALLOCATE
ALTER
AND
ANY
ARE
AS
ASC
ASSERTION
ASYNC
AT
AUTHORIZATION
AV G
BEFORE
BEGIN
BETWEEN
BIT
BIT_LENGTH
BOOLEAN
BOTH
BREADTH
BY
CALL
CASCADE
CASCADED
CASE
CAST
CATALOG
CHAR
CHARACTER
CHARACTER_LENGTH
CHAR_LENGTH
CHECK
CHR
CLOSE
COALESCE
COLLATE
COLLATION
COLUMN
COLUMNS
COMMIT
COMPLETION
CONCAT
CONNECT
CONNECTION
CONSTRAINT
CONSTRAINTS
CONTINUE
CONVERT
CORRESPONDING
COUNT
CREATE
CROSS
CURDATE
CURRENT
CURRENT_DATE
CURRENT_TIME
CURRENT_TIMESTAMP
CURRENT_USER
CURSOR
CURTIME
CYCLE
DATA
DATE
DAY
DAYOFMONTH
DAYOFWEEK
DEALLOCATE
DEC
DECIMAL
DECLARE
DEFAULT
DEFERRABLE
DEFERRED
DELETE
DEPTH
DESC
DESCRIBE
DESCRIPTOR
DIAGNOSTICS
DICTIONARY
DISCONNECT
DISTINCT
DOMAIN
DOUBLE
DROP
EACH
ELSE
ELSEIF
END
END_EXEC
EQUALS
ESCAPE
EXCEPT
EXCEPTION
EXEC
EXECUTE
EXISTS
EXTERNAL
EXTRACT
FALSE
FETCH
FIRST
FLOAT
FLOOR
FOR
FOREIGN
FOUND
FROM
FULL
GENERAL
GET
GLOBAL
GO
GOTO
GRANT
GROUP
HAVING
HOUR
IDENTIFY
45 FileMaker ODBC and JDBC Guide
Reserved keywords
IF
IFNULL
IGNORE
IMMEDIATE
IN
INDEX
INDICATOR
INITIALLY
INNER
INPUT
INSENSITIVE
INSERT
INT
INTEGER
INTERSECT
INTERVAL
INTO
IS
ISOLATION
JOIN
KEY
LANGUAGE
LAST
LCASE
LEADING
LEAVE
LEFT
LEN
LENGTH
LESS
LEVEL
LIKE
LIMIT
LOCAL
LOOP
LOWER
LT RI M
MATCH
MAX
MIN
MINUTE
MOD
MODIFY
MODULE
MONTH
NAMES
NATIONAL
NATURAL
NCHAR
NEW
NEXT
NO
NONE
NOT
NOW
NULL
NULLIF
NUMERIC
OBJECT
OCTET_LENGTH
OF
OFF
OID
OLD
ON
ONLY
OPEN
OPERATION
OPERATORS
OPTION
OR
ORDER
OTHERS
OUTER
OUTPUT
OVERLAPS
PA D
PARAMETERS
PA RTI A L
PENDANT
POSITION
POW
POWER
PRECISION
PREORDER
PREPARE
PRESERVE
PRIMARY
PRIOR
PRIVATE
PRIVILEGES
PROCEDURE
PROTECTED
PUBLIC
RCASE
READ
REAL
RECURSIVE
REF
REFERENCES
REFERENCING
RELATIVE
REMOVE
REPLACE
RESIGNAL
RESTRICT
RETURN
RETURNS
REVOKE
RIGHT
ROLE
ROLLBACK
ROUND
ROUTINE
ROW
ROWS
RTR IM
SAVEPOINT
SCHEMA
SCROLL
SEARCH
SECOND
SECTION
SELECT
SENSITIVE
SEQUENCE
SESSION
SESSION_USER
SET
SIGNAL
SIMILAR
SIZE
SMALLINT
SOME
SPACE
SQL
SQLCODE
SQLERROR
SQLEXCEPTION
SQLSTATE
SQLWARNING
STATISTICS
STRUCTURE
SUBSTR
SUBSTRING
SUM
SYSTEM_USER
TA BL E
TEMPORARY
TEST
THEN
THERE
TIME
TIMESTAMP
TIMEZONE_HOUR
TIMEZONE_MINUTE
TO
TRAILING
TRANSACTION
TRANSLATE
TRANSLATION
TRIGGER
TRIM
TRUE
TYPE
UCASE
UNDER
UNION
UNIQUE
UNKNOWN
UPDATE
UPPER
USAGE
USER
USERNAME
USING
VA L U E
VALUES
VARCHAR
VA R I A B L E
VA R Y I N G
VIEW
VIRTUAL
VISIBLE
WA I T
WHEN
WHENEVER
WHERE
WHILE
WITH
WITHOUT
WORK
WRITE
YEAR
ZONE
46 FileMaker ODBC and JDBC Guide
Appendix A
Mapping FileMaker fields to ODBC data types
This table illustrates how FileMaker field types map to the standard ODBC data types.
FileMaker field type
text SQL_VARCHAR The maximum column length of text is 1 million
number SQL_DOUBLE The FileMaker number field type can contain positive or
date SQL_DATE
time SQL_TIME The FileMaker time field type can contain the time of day
timestamp SQL_TIMESTAMP
container (BLOB) SQL_LONGVARBINARY You can retrieve binary data, file reference information, or
calculation The result is mapped to the corresponding ODBC data type.
Converts to ODBC data
type
About the data type
characters, unless you specify a smaller Maximum number
of characters for the text field in FileMaker. FileMaker
returns empty strings as NULL.
negatives values as small as 10
with up to 15 significant digits.
or a time interval. A time interval is returned as a time of
day, unless it is less than 0 or greater than 24 hours (both
return a value of 0).
data of a specific file type from a container field.
Within a SELECT statement, use the CAST function to
retrieve file reference information, and use the GetAs
function to retrieve data of a specific file type.
-308
, and as large as 10
+308
,
String length is optional in table declarations. All strings are stored and retrieved in Unicode.
Notes
1 You can SELECT up to 170 fields at one time from a FileMaker database file; you can UPDATE up to
100 fields at one time.
1 FileMaker supports repeating fields (array data types), but ODBC does not. FileMaker exports
repetitions to tab-delimited or comma-delimited files and separates each repetition with a group separator
(Unicode decimal value 29). Text columns separated with the group separator are concatenated. All other
data types return only the first repetition.
48 FileMaker ODBC and JDBC Guide
Appendix B
Mapping FileMaker fields to JDBC data types
The JDBC client driver uses the following mappings when converting FileMaker data types to JDBC SQL
types. (For information about these types, see the JDK 1.5 documentation web pages at www.javasoft.com.)
FileMaker field type Converts to JDBC SQL type
text java.sql.Types.VARCHAR
number java.sql.Types.DOUBLE
date java.sql.Types.DATE
time java.sql.Types.TIME
timestamp java.sql.Types.TIMESTAMP
container java.sql.Types.BLOB
calculation specified by the data type of the calculation’s result
The JDBC client driver converts the FileMaker calculation data type to the JDBC SQL type matching the
calculation’s result. For example, the JDBC client driver converts a FileMaker calculation that results in a
timestamp data type to java.sql.Types.TIMESTAMP.
50 FileMaker ODBC and JDBC Guide
Appendix C
ODBC and JDBC error messages
Here are the basic formats of error messages you receive when working with FileMaker and ODBC/JDBC.
For a listing of error numbers and explanations, see www.datadirect.com.
For more information about working with errors in FileMaker, see the Get(LastError) or Get(LastODBCError)
functions described in FileMaker
ODBC error messages
Error messages can come from:
1 ODBC driver errors
1 ODBC Driver Manager errors
1 SequeLink Client errors
1 SequeLink Server errors
1 the data source or database management system
ODBC driver error messages
Pro Help.
An error reported by the SequeLink ODBC driver has the following format:
[DataDirect] [ODBC SequeLink driver] message
For example:
[DataDirect] [ODBC SequeLink driver] Invalid precision specified
If you get this type of error, check the last ODBC call your application made for possible problems or
contact your ODBC application vendor.
ODBC Driver Manager error messages
An error reported by the ODBC Driver Manager has the following format:
[Microsoft] [ODBC Driver Manager] message
For example:
[Microsoft] [ODBC Driver Manager] Function sequence error
If you get this type of error, check to see that you have the proper ODBC support files and drivers.
SequeLink Client error messages
An error reported by the SequeLink ODBC Client has the following format:
[DataDirect] [ODBC SequeLink driver] [SequeLink Client] message
For example:
[DataDirect] [ODBC SequeLink driver] [SequeLink Client] The specified transliteration module is not found
52 FileMaker ODBC and JDBC Guide
SequeLink Server error messages
An error reported by the SequeLink Server has the following format:
[DataDirect] [ODBC SequeLink driver] [SequeLink Server] message
For example:
[DataDirect] [ODBC SequeLink driver] [SequeLink Server] Only SELECT statements are allowed in this read-only
connection.
Data source error messages
An error that occurs in the data source includes the data source name, in the following format:
[DataDirect] [ODBC SequeLink driver] [data_source] message
For example, you might get the following message from your FileMaker data source:
[DataDirect] [ODBC SequeLink driver] [FileMaker] Invalid Username/Password
If you get this type of error, you did something incorrectly with the database system. Check your FileMaker
documentation for more information or consult your database administrator.
Consecutive messages for errors in different columns can sometimes display an incorrect column name.
JDBC error messages
The SequeLink for JDBC driver reports errors to the calling application by returning SQLExceptions. Error
messages can come from:
1 JDBC driver errors
1 SequeLink Server errors
1 the data source or database management system
JDBC driver error messages
An error reported by the JDBC driver has the following format:
[DataDirect] [SequeLink JDBC Driver] message
For example:
[DataDirect] [SequeLink JDBC Driver] Timeout expired
If you get this type of error, check the last JDBC call your application made for possible problems or contact
your JDBC application vendor.
SequeLink Server error messages
An error reported by SequeLink Server has the following format:
[DataDirect] [SequeLink JDBC Driver] [SequeLink] message
If no SequeLink Server errors exist, you see:
[DataDirect] [JDBC SequeLink driver] [SequeLink]
Appendix C | ODBC and JDBC error messages 53
Data source error messages
An error that occurs in the data source includes the data source name, in the following format:
[DataDirect] [SequeLink JDBC Driver] [data_source] message
For example, you might get the following message from your FileMaker data source:
[DataDirect] [SequeLink JDBC Driver] [FileMaker] Invalid Username/Password
If you get this type of error, you did something incorrectly with the database system. Check your FileMaker
documentation for more information or consult your database administrator.
54 FileMaker ODBC and JDBC Guide
Index
A
Access via ODBC/JDBC extended privilege 16
Access, Microsoft. See Microsoft Access
accounts and privileges
aggregate functions in SQL 36
aliases with SELECT statement 28, 31
ALL operator 39
ALTER TABLE (SQL statement) 35
AND operator 40
ANY operator 39
APIs 7
ARRAY data type 22
auto-generated keys 22
16
B
B function 42
BETWEEN operator 39
bitmap files in container fields 32
blank characters 38
blank space in database name 19, 24
blank value in columns 33
BLOB data type
JDBC limitation
use in CREATE TABLE 35
use in SELECT 31
Boolean data type 22
22
C
CAST function 32, 47
catalog functions for ODBC 43
character operators in SQL expressions 38
CHR function 41
client application, using FileMaker as 7
client drivers. See drivers
CLOB data type
column aliases 28
column names 16
configuring a FileMaker data source
via JDBC
via ODBC (Mac OS) 19
via ODBC (Windows) 17
connections, database 8
constants in SQL expressions 37
22
24
container field
JDBC data type mapping
ODBC data type mapping 47
with INSERT statement 33
with SELECT statement 32
with UPDATE statement 34
CREATE INDEX (SQL statement) 36
CREATE TABLE (SQL statement) 35
cursors
in JDBC
in ODBC 31
22
49
D
data source
configuring for access via JDBC
configuring for access via ODBC (Mac OS) 19
configuring for access via ODBC (Windows) 17
disabling a shared FileMaker database file 8
one DSN for each FileMaker database file 9
using FileMaker as 7
verifying access via JDBC 25
verifying access via ODBC (Windows) 18
data source names. See DSNs
data type mapping
JDBC client driver 49
ODBC client driver 47
database connections, number supported 8
database name considerations
Mac OS
Windows 18
DATALINK data type 22
DATE function 42
date operators in SQL expressions 39
DATEVAL function 42
DAY function 42
DAYOFWEEK function 42
DELETE (SQL statement) 33
disabling a shared FileMaker database file 8
DISTINCT operator 28
driver properties
JDBC client driver
ODBC client driver (Mac OS) 19
ODBC client driver (Windows) 17
19
24
24
56 FileMaker ODBC and JDBC Guide
drivers
installing FileMaker JDBC
installing FileMaker ODBC 12
uninstalling old 9
DROP INDEX (SQL statement) 36
DSNs
creating (Mac OS)
creating (Windows) 17
keyword values for (Mac OS) 19
one per file 9
19
13
E
error message formats 51
escape character 19, 24
EXISTS operator 39
exponential notation in SQL expressions 38
expressions in SQL 37
extended privileges 16
F
field names in SQL expressions 37
fields
mapping to JDBC
mapping to ODBC 47
FileMaker client drivers. See drivers
FileMaker products
filename limitations (Mac OS) 19
files
organizing on one computer
setting up access to 16
use in container fields 32
FOR UPDATE (SQL clause) 31
FROM (SQL clause) 29
functions in SQL expressions 41
49
8
8
G
Get(LastError) function 51
Get(LastODBCError) function 51
GetAs function 32, 47
GROUP BY (SQL clause) 29
H
HAVING (SQL clause) 30
holdable cursor 22
hosting a FileMaker data source 7
I
image files in container fields 32
INNER JOIN 29
INSERT (SQL statement) 33
installation requirements 11
installing
FileMaker JDBC client drivers
FileMaker ODBC client drivers 12
INT function 42
13
J
JAR archive files 13
Java Development Kit (JDK) 22
Java version 12
JDBC
client driver, described
described 21
error messages 52
overview of using 7
JDBC client driver
driver class and main entry point
installing 13
mapping data types 49
meta data functions 44
registering with the JDBC driver manager 23
repeating fields 27
specifying the JDBC URL 22
Unicode support 27
verifying access 25
JDBC SPI 22
JDBCTest 13
join 29
22
22
K
keywords
for DSNs (Mac OS)
reserved SQL 44
19
L
LEFT function 41
LEN function 42
LIKE operator 39
literals in SQL expressions 37
Local Data Access Companion (LDAC) 9
logical operators in SQL expressions 40
LOWER function 41
LTRIM function 41
| Index 57
M
Mac OS
creating a DSN
installing JDBC client driver 13
installing ODBC client driver 13
JDBC client driver requirements 12
ODBC Administrator 19
ODBC client driver requirements 11
mapping data types
JDBC client driver
ODBC client driver 47
MAX function 42
meta data functions for JDBC 44
Microsoft Access
client application
importing fields into 16
Microsoft Query Wizard 8
MIN function 42
MOD function 42
MONTH function 42
19
49
8
N
network requirements 8
NOT NULL (SQL clause) 35
NOT operator 40
null value 33, 47
numeric operators in SQL expressions 38
NUMVAL function 42
O
ODBC
described
error messages 51
overview of using 7
repeating fields 47
standards compliance 27
ODBC Administrator (Mac OS) 19
ODBC client driver
catalog functions
installing (Mac OS) 13
installing (Windows) 12
mapping data types 47
maximum number of FileMaker fields 47
repeating fields 27
Unicode support 27
verifying access (Windows) 18
ODBC Data Source Administrator (Windows) 17
operator precedence in SQL expressions 43
15
43
OR operator 40
ORDER BY (SQL clause) 30
OUTER JOIN 29
overview
setting up privileges and sharing
using ODBC and JDBC with FileMaker 7
16
P
password
with JDBC
with ODBC 18
port
specifying for JDBC
specifying for ODBC (Mac OS) 19
specifying for ODBC (Windows) 17
portals 27
positioned updates and deletes 31
POW function 42
privileges, extended 16
24
24
Q
QuickTime files in container fields 32
R
Rapid Application Development (RAD) tools 21
REF data type 22
registering the JDBC client driver 23
relational operators in SQL expressions 39
remote access 8
Remote Data Access Companion (RDAC) 9
repeating fields 27, 47
requirements for installation 11
reserved SQL keywords 44
RIGHT function 41
ROUND function 42
RTRIM function 41
S
savepoint support 22
scientific notation in SQL expressions 38
Secure Socket Layer encryption 25
SELECT (SQL statement) 27
SequeLink Server Host 17
SequeLink Server Port 17
Server Data Source 17
sharing, setting up ODBC/JDBC 16
sound files in container fields 32
58 FileMaker ODBC and JDBC Guide
SPACE function 41
space in database name 19, 24
SQL aggregate functions 36
SQL expressions 37
character operators 38
constants 37
date operators 39
exponential or scientific notation 38
field names 37
functions 41
literals 37
logical operators 40
numeric operators 38
operator precedence 43
relational operators 39
SQL standards compliance 27
SQL statements
ALTER TABLE
CREATE INDEX 36
CREATE TABLE 35
DELETE 33
DROP INDEX 36
INSERT 33
reserved keywords 44
SELECT 27
supported by client drivers 27
UPDATE 34
SQL_C_BINARY data type 27
SQL_C_WCHAR data type 27
SQL-92 27
SQLExceptions 52
standards compliance 27
string functions 41
STRVAL function 41
subqueries 33
SUBSTR function 41
syntax errors 44
system requirements 11
35
U
Unicode support 27
UNION (SQL operator) 30
UPDATE (SQL statement) 34
UPPER function 41
URL (Uniform Resource Locator) for the JDBC
client driver
USERNAME function 41
22
V
VAL function 42
VALUES (SQL clause) 33
verifying access
JDBC client driver
ODBC client driver (Windows) 18
25
W
WHERE (SQL clause) 29
wildcards with SELECT statement 28, 31
Windows
creating a DSN
importing fields into Microsoft Access 16
installing JDBC client driver 13
installing ODBC client driver 12
JDBC client driver requirements 12
ODBC client driver requirements 11
verifying ODBC access 18
17
X
X function 42
Y
YEAR function 42
T
table aliases 28, 29
testing access
JDBC client driver
ODBC client driver (Windows) 18
TIME function 41
TRIM function 41
25
Loading...
